08
RAM
®
MOUNT GPS CATALOG
GARMIN l TOMTOM l MAGELLAN l LOWRANCE l DELORME l SPOT SATELLITE l MIO
SIMPLE AS 1, 2, 3, 4
laptop mounts on the market, RAM allows you to mount GPS devices, laptops and tablets where you need them most. Whether its in an aircraft,
automobile, boat, ATV, truck, snowmobile, farming vehicle, motorcycle, fork lift or any other situation, RAM's family of more than 1500 interchangeable
mounting accessories will offer you solutions to your most challenging mounting problems. If you need to mount a GPS, laptop, pda, tablet, radar, camera,
light, computer, cellular phone, speaker, mirror, antenna, or just about anything else look no further. RAM Mount will help you make a professional job easy
and affordable. RAM Mounts are unique in design, providing easy installation, mobility, strength, versatility, vibration protection and durability, all at a low
cost. RAM Mounts are backed by NPI's renowned Lifetime Warranty which makes them the mounting systems of choice. To provide light weight strength
and corrosion resistance, RAM Mounts are made of marine grade aluminum with a powder coated finish, stainless steel hardware and rubber balls.
Recognized and accepted by the U.S. Patent Office, RAM is the only universal ball-and-socket system that holds tremendous amounts of weight in high
vibration applications for military, commercial and private use. Look further into our web site and see the newest mount products and learn more about this
revolutionary mounting system that is quickly becoming the industry standard. Remember when faced with a difficult mounting situation, Just RAM It!
Customizing your RAM Mount is quite simple. First, choose a mounting base; this is based upon the location where you will be mounting. Second, choose
a double socket arm, ranging from short, standard to long sizes. Third, choose a top base that will be mounted directly to the cradle. Finally, choose your
cradle or Aqua Box.
STEP 1
Choose Mounting Base
Choose Arm
STEP 2
Choose Top Base
STEP 3
Choose Cradle
STEP 4
RAM-B-201-A RAM 1.75” Short Length Double 1”
Socket Arm
RAM-B-238U RAM Diamond Base
with 1” Ball RAM-B-201U RAM 3” Standard Length Double 1” Socket Arm RAM-B-201-C RAM 5.25” Long Length Double 1” Socket Arm RAM-B-231ZU
RAM Motorcycle Zinc Coated 0.75" to 1.25" Rail or Handlebar
U-Bolt Base
RAM-B-202U RAM 2.5” Round Diameter Base with
1” Ball
RAM-B-202U RAM 2.5” Round Diameter Base with
1” Ball RAM-B-309-1U RAM Motorcycle Brake/Clutch Reservoir Base RAM-B-224-1U RAM 3.25” Diameter Base Suction Cup Base
Motorcycle Bases: (Page 78-79) Suction Cup Bases: (Page 77) Aviation Bases: (Page 80)
Garmin Cradles: (Page 4-34) TomTom Cradles: (Page 35-43) Magellan Cradles: (Page 44-55) Lowrance Cradles: (Page 56-64) Delorme Cradles: (Page 65-67) Spot Satellite Cradles: (Page 68-70) Mio Cradles: (Page 71-74)
Aqua Boxes: (Page 81)
Composite Arms:
RAP-B-201U (Standard Size Arm) RAP-B-201-A (Short Size Arm)
Composite Bases:
RAP-B-238U (Diamond Base) RAP-B-202U (Round Base)
Note:
Most cradles contain hole patterns that match with the diamond bases. Aqua Boxes utilize the round base for attachment.
RAP-B-121BU RAM Composite, Universal Yoke/Glare,
Shield Clamp Mount without extra removable
ball.
The RAM Handheld GPS Mount Catalog is a complete guide for all your GPS needs. The information contained in this catalog is consistently growing;
therefore, please check the
www.ram-mount.com
site for updates, or solutions for all your mounting needs.
GARMIN GPS MOUNTS...
TOMTOM GPS MOUNTS...
MAGELLAN GPS MOUNTS...
LOWRANCE GPS MOUNTS...
DELORME GPS MOUNTS...
SPOT SATELLITE GPS MOUNTS...
MIO GPS MOUNTS...
ACCESSORIES...
CONTACT INFORMATION...
4-34
35-43
44-55
56-64
65-67
68-70
71-74
75-83
84
SIMPLE AS 1, 2, 3, 4
laptop mounts on the market, RAM allows you to mount GPS devices, laptops and tablets where you need them most. Whether its in an aircraft,
automobile, boat, ATV, truck, snowmobile, farming vehicle, motorcycle, fork lift or any other situation, RAM's family of more than 1500 interchangeable
mounting accessories will offer you solutions to your most challenging mounting problems. If you need to mount a GPS, laptop, pda, tablet, radar, camera,
light, computer, cellular phone, speaker, mirror, antenna, or just about anything else look no further. RAM Mount will help you make a professional job easy
and affordable. RAM Mounts are unique in design, providing easy installation, mobility, strength, versatility, vibration protection and durability, all at a low
cost. RAM Mounts are backed by NPI's renowned Lifetime Warranty which makes them the mounting systems of choice. To provide light weight strength
and corrosion resistance, RAM Mounts are made of marine grade aluminum with a powder coated finish, stainless steel hardware and rubber balls.
Recognized and accepted by the U.S. Patent Office, RAM is the only universal ball-and-socket system that holds tremendous amounts of weight in high
vibration applications for military, commercial and private use. Look further into our web site and see the newest mount products and learn more about this
revolutionary mounting system that is quickly becoming the industry standard. Remember when faced with a difficult mounting situation, Just RAM It!
Customizing your RAM Mount is quite simple. First, choose a mounting base; this is based upon the location where you will be mounting. Second, choose
a double socket arm, ranging from short, standard to long sizes. Third, choose a top base that will be mounted directly to the cradle. Finally, choose your
cradle or Aqua Box.
STEP 1
Choose Mounting Base
Choose Arm
STEP 2
Choose Top Base
STEP 3
Choose Cradle
STEP 4
RAM-B-201-A RAM 1.75” Short Length Double 1”
Socket Arm
RAM-B-238U RAM Diamond Base
with 1” Ball RAM-B-201U RAM 3” Standard Length Double 1” Socket Arm RAM-B-201-C RAM 5.25” Long Length Double 1” Socket Arm RAM-B-231ZU
RAM Motorcycle Zinc Coated 0.75" to 1.25" Rail or Handlebar
U-Bolt Base
RAM-B-202U RAM 2.5” Round Diameter Base with
1” Ball
RAM-B-202U RAM 2.5” Round Diameter Base with
1” Ball RAM-B-309-1U RAM Motorcycle Brake/Clutch Reservoir Base RAM-B-224-1U RAM 3.25” Diameter Base Suction Cup Base
Motorcycle Bases: (Page 78-79) Suction Cup Bases: (Page 77) Aviation Bases: (Page 80)
Garmin Cradles: (Page 4-34) TomTom Cradles: (Page 35-43) Magellan Cradles: (Page 44-55) Lowrance Cradles: (Page 56-64) Delorme Cradles: (Page 65-67) Spot Satellite Cradles: (Page 68-70) Mio Cradles: (Page 71-74)
Aqua Boxes: (Page 81)
Composite Arms:
RAP-B-201U (Standard Size Arm) RAP-B-201-A (Short Size Arm)
Composite Bases:
RAP-B-238U (Diamond Base) RAP-B-202U (Round Base)
Note:
Most cradles contain hole patterns that match with the diamond bases. Aqua Boxes utilize the round base for attachment.
RAP-B-121BU RAM Composite, Universal Yoke/Glare,
Shield Clamp Mount without extra removable
ball.
The RAM Handheld GPS Mount Catalog is a complete guide for all your GPS needs. The information contained in this catalog is consistently growing;
therefore, please check the
www.ram-mount.com
site for updates, or solutions for all your mounting needs.
GARMIN GPS MOUNTS...
TOMTOM GPS MOUNTS...
MAGELLAN GPS MOUNTS...
LOWRANCE GPS MOUNTS...
DELORME GPS MOUNTS...
SPOT SATELLITE GPS MOUNTS...
MIO GPS MOUNTS...
ACCESSORIES...
CONTACT INFORMATION...
4-34
35-43
44-55
56-64
65-67
68-70
71-74
75-83
84
08
GARMIN GPS MOUNTS
RAM
®MOUNT
PAGE RAM HOLDER/ADAPTER
GARMIN MODEL RAM HOLDER/ADAPTER PAGE
BMW NAVIGATOR I BMW NAVIGATOR II COLORADO 300 COLORADO 400C COLORADO 400I COLORADO 400T EMAP ETREX LEGEND ETREX LEGEND C ETREX LEGEND CX ETREX SUMMIT ETREX VENTURE ETREX VENTURE CX ETREX VISTA ETREX VISTA C ETREX VISTA CX ETREX VISTA HCX GPS 12 GPS 12CX GPS 12MAP GPS 12XL GPS 195 GPS 38 GPS 40 GPS 45 GPS 48 GPS 60 GPS 72 GPS 76 GPS 89 GPS 90 GPS 92 GPS 96 295 GPS II GPS II PLUS GPS III GPS III PILOT GPS III PLUS GPS V GPS V DELUXE GPSMAP 176 GPSMAP 176C GPSMAP 196 GPSMAP 276C GPSMAP 295 GPSMAP 296 GPSMAP 376C GPSMAP 378 GPSMAP 396 GPSMAP 478 GPSMAP 496 GPSMAP 60 GPSMAP 60C GPSMAP 60CS GPSMAP 60CSX GPSMAP 60CX GPSMAP 72 GPSMAP 76 GPSMAP 76C GPSMAP 76CS GPSMAP 76CSX GPSMAP 76CX GPSMAP 76S GPSMAP 96 RAM-HOL-GA2U RAM-HOL-GA9U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA4U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA5U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-B-202-G1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA12U RAM-HOL-GA6U RAM-HOL-GA6U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA6U RAM-B-202-G1U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-B-202-G1U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA6U RAM-HOL-GA6U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA6U RAM-HOL-GA14U 8 15 30 30 30 30 10 11 21 21 11 11 21 11 21 21 21 7 7 7 7 33 7 7 9 9 18 12 12 9 9 9 12 33 8 8 8 8 8 8 8 13 13 13 13 33 13 13 13 13 13 13 18 18 18 18 18 12 12 19 19 19 19 12 19
08
GARMIN GPS MOUNTS
RAM
®MOUNT
PAGE RAM HOLDER/ADAPTER
GARMIN MODEL RAM HOLDER/ADAPTER PAGE
BMW NAVIGATOR I BMW NAVIGATOR II COLORADO 300 COLORADO 400C COLORADO 400I COLORADO 400T EMAP ETREX LEGEND ETREX LEGEND C ETREX LEGEND CX ETREX SUMMIT ETREX VENTURE ETREX VENTURE CX ETREX VISTA ETREX VISTA C ETREX VISTA CX ETREX VISTA HCX GPS 12 GPS 12CX GPS 12MAP GPS 12XL GPS 195 GPS 38 GPS 40 GPS 45 GPS 48 GPS 60 GPS 72 GPS 76 GPS 89 GPS 90 GPS 92 GPS 96 295 GPS II GPS II PLUS GPS III GPS III PILOT GPS III PLUS GPS V GPS V DELUXE GPSMAP 176 GPSMAP 176C GPSMAP 196 GPSMAP 276C GPSMAP 295 GPSMAP 296 GPSMAP 376C GPSMAP 378 GPSMAP 396 GPSMAP 478 GPSMAP 496 GPSMAP 60 GPSMAP 60C GPSMAP 60CS GPSMAP 60CSX GPSMAP 60CX GPSMAP 72 GPSMAP 76 GPSMAP 76C GPSMAP 76CS GPSMAP 76CSX GPSMAP 76CX GPSMAP 76S GPSMAP 96 RAM-HOL-GA2U RAM-HOL-GA9U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA27U RAM-HOL-GA4U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA5U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA5U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA16U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-B-202-G1U RAM-HOL-GA1U RAM-HOL-GA1U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA12U RAM-HOL-GA6U RAM-HOL-GA6U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA3U RAM-HOL-GA6U RAM-B-202-G1U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA2U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-B-202-G1U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA7U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA12U RAM-HOL-GA6U RAM-HOL-GA6U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA14U RAM-HOL-GA6U RAM-HOL-GA14U 8 15 30 30 30 30 10 11 21 21 11 11 21 11 21 21 21 7 7 7 7 33 7 7 9 9 18 12 12 9 9 9 12 33 8 8 8 8 8 8 8 13 13 13 13 33 13 13 13 13 13 13 18 18 18 18 18 12 12 19 19 19 19 12 19
PAGE RAM HOLDER/ADAPTER PAGE
RAM HOLDER/ADAPTER
GARMIN MODEL RAM HOLDER/ADAPTER PAGE
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: GPS 12 GPS 12CX GPS 12MAP INCLUDED COMPONENTS: (1) RAM-HOL-GA1U (1) RAM-B-138U RAM-B-138-GA1U Flat Surface Mount
GPS 12XL GPS 38 GPS 40 INCLUDED COMPONENTS: (1) RAM-HOL-GA1U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA1U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-166U
RAM-B-166-GA1U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAP-105-6D224U
RAP-105-6224-GA1U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAP-B-104-224U
RAP-B-104-224-GA1U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-149ZU
RAM-B-149Z-GA1U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-174U
RAM-B-174-GA1U Brake/Clutch Reservoir Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball GPSMAP 96C IQUE 3000 IQUE 3200 IQUE 3600 IQUE M3 IQUE M4 IQUE M5 NUVI 200 NUVI 200W NUVI 250 NUVI 250W NUVI 260 NUVI 260W NUVI 270 NUVI 300 NUVI 310 NUVI 350 NUVI 360 NUVI 370 NUVI 5000 NUVI 600 NUVI 610 NUVI 650 NUVI 660 NUVI 670 NUVI 680 NUVI 710 NUVI 750 NUVI 760 NUVI 770 NUVI 780 NUVI 800 NUVI 850 NUVI 880 QUEST QUEST2 RINO 110 RINO 120 RINO 130 RINO 520 RINO 520HCX RINO 530 RINO 530HCX STREETPILOT 2610 STREETPILOT 2620 STREETPILOT 2650 STREETPILOT 2660 STREETPILOT 2720 STREETPILOT 2730 STREETPILOT 2820 STREETPILOT 7200 STREETPILOT 7500 STREETPILOT C310 STREETPILOT C320 STREETPILOT C330 STREETPILOT C340 STREETPILOT C530 STREETPILOT C550 STREETPILOT C580 STREETPILOT I2 STREETPILOT I3 STREETPILOT I5 STREETPILOT III zumo 550 NUVI 255 NUVI 255W RAM-HOL-GA14U RAM-HOL-GA11U RAM-HOL-GA10U RAM-HOL-GA10U RAM-HOL-GA11U RAM-HOL-GA11U RAM-HOL-GA11U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA28U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA30U RAM-HOL-GA30U RAM-HOL-GA30U RAM-HOL-GA15U RAM-HOL-GA15U RAM-HOL-GA8U RAM-HOL-GA8U RAM-HOL-GA8U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-B-202-G3U RAM-B-202-G3U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-B-202-G1U RAM-HOL-GA24U RAM-HOL-GA25U 19 17 16 16 17 17 17 27 28 27 28 27 28 27 28 27 24 24 24 24 24 31 26 26 26 26 26 29 29 29 29 29 32 32 32 20 20 14 14 14 23 23 23 23 15 15 15 15 15 15 15 34 34 22 22 22 22 25 25 25 25 25 25 33 34
PAGE RAM HOLDER/ADAPTER PAGE
RAM HOLDER/ADAPTER
GARMIN MODEL RAM HOLDER/ADAPTER PAGE
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: GPS 12 GPS 12CX GPS 12MAP INCLUDED COMPONENTS: (1) RAM-HOL-GA1U (1) RAM-B-138U RAM-B-138-GA1U Flat Surface Mount
GPS 12XL GPS 38 GPS 40 INCLUDED COMPONENTS: (1) RAM-HOL-GA1U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA1U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-166U
RAM-B-166-GA1U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAP-105-6D224U
RAP-105-6224-GA1U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAP-B-104-224U
RAP-B-104-224-GA1U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-149ZU
RAM-B-149Z-GA1U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA1U (1) RAM-B-174U
RAM-B-174-GA1U Brake/Clutch Reservoir Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball GPSMAP 96C IQUE 3000 IQUE 3200 IQUE 3600 IQUE M3 IQUE M4 IQUE M5 NUVI 200 NUVI 200W NUVI 250 NUVI 250W NUVI 260 NUVI 260W NUVI 270 NUVI 300 NUVI 310 NUVI 350 NUVI 360 NUVI 370 NUVI 5000 NUVI 600 NUVI 610 NUVI 650 NUVI 660 NUVI 670 NUVI 680 NUVI 710 NUVI 750 NUVI 760 NUVI 770 NUVI 780 NUVI 800 NUVI 850 NUVI 880 QUEST QUEST2 RINO 110 RINO 120 RINO 130 RINO 520 RINO 520HCX RINO 530 RINO 530HCX STREETPILOT 2610 STREETPILOT 2620 STREETPILOT 2650 STREETPILOT 2660 STREETPILOT 2720 STREETPILOT 2730 STREETPILOT 2820 STREETPILOT 7200 STREETPILOT 7500 STREETPILOT C310 STREETPILOT C320 STREETPILOT C330 STREETPILOT C340 STREETPILOT C530 STREETPILOT C550 STREETPILOT C580 STREETPILOT I2 STREETPILOT I3 STREETPILOT I5 STREETPILOT III zumo 550 NUVI 255 NUVI 255W RAM-HOL-GA14U RAM-HOL-GA11U RAM-HOL-GA10U RAM-HOL-GA10U RAM-HOL-GA11U RAM-HOL-GA11U RAM-HOL-GA11U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA25U RAM-HOL-GA24U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA21U RAM-HOL-GA28U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA23U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA26U RAM-HOL-GA30U RAM-HOL-GA30U RAM-HOL-GA30U RAM-HOL-GA15U RAM-HOL-GA15U RAM-HOL-GA8U RAM-HOL-GA8U RAM-HOL-GA8U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA20U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-HOL-GA9U RAM-B-202-G3U RAM-B-202-G3U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA19U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-HOL-GA22U RAM-B-202-G1U RAM-HOL-GA24U RAM-HOL-GA25U 19 17 16 16 17 17 17 27 28 27 28 27 28 27 28 27 24 24 24 24 24 31 26 26 26 26 26 29 29 29 29 29 32 32 32 20 20 14 14 14 23 23 23 23 15 15 15 15 15 15 15 34 34 22 22 22 22 25 25 25 25 25 25 33 34
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-174U
RAM-B-174-GA2U Brake/Clutch Reservoir Mount
4
9
7
47
9
Plus, GPS V & GPS V Deluxe.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-138U
RAM-B-138-GA2U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-166U
RAM-B-166-GA2U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAP-105-6D224U
RAP-105-6224-GA2U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAP-B-104-224U
RAP-B-104-224-GA2U Ratchet/Pivot, Suction Cup Mount COMPATIBLE GARMIN MODELS:
BMW Navigator I GPS II GPS II Plus GPS III GPS III Pilot GPS III Plus GPS V GPS V Deluxe INCLUDED COMPONENTS: (1) RAM-HOL-GA2U (1) RAM-B-149ZU RAM-B-149Z-GA2U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-121-238U
RAM-B-121-GA2U Aviation Yoke Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: GPS 45 GPS 48 GPS 89 INCLUDED COMPONENTS: (1) RAM-HOL-GA3U (1) RAM-B-138U RAM-B-138-GA3U Flat Surface Mount
GPS 90 GPS 92 INCLUDED COMPONENTS: (1) RAM-HOL-GA3U (1) RAM-B-166U RAM-B-166-GA3U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAP-105-6D224U
RAP-105-6224-GA3U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAP-B-104-224U
RAP-B-104-224-GA3U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-174U
RAM-B-174-GA3U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-125U
RAM-B-125-GA3U Aviation Yoke Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-149ZU
RAM-B-149Z-GA3U Handlebar or Rail Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-174U
RAM-B-174-GA2U Brake/Clutch Reservoir Mount
4
9
7
47
9
Plus, GPS V & GPS V Deluxe.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-138U
RAM-B-138-GA2U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-166U
RAM-B-166-GA2U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAP-105-6D224U
RAP-105-6224-GA2U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAP-B-104-224U
RAP-B-104-224-GA2U Ratchet/Pivot, Suction Cup Mount COMPATIBLE GARMIN MODELS:
BMW Navigator I GPS II GPS II Plus GPS III GPS III Pilot GPS III Plus GPS V GPS V Deluxe INCLUDED COMPONENTS: (1) RAM-HOL-GA2U (1) RAM-B-149ZU RAM-B-149Z-GA2U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA2U (1) RAM-B-121-238U
RAM-B-121-GA2U Aviation Yoke Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: GPS 45 GPS 48 GPS 89 INCLUDED COMPONENTS: (1) RAM-HOL-GA3U (1) RAM-B-138U RAM-B-138-GA3U Flat Surface Mount
GPS 90 GPS 92 INCLUDED COMPONENTS: (1) RAM-HOL-GA3U (1) RAM-B-166U RAM-B-166-GA3U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAP-105-6D224U
RAP-105-6224-GA3U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAP-B-104-224U
RAP-B-104-224-GA3U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-174U
RAM-B-174-GA3U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-125U
RAM-B-125-GA3U Aviation Yoke Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA3U (1) RAM-B-149ZU
RAM-B-149Z-GA3U Handlebar or Rail Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
4
9
7
47
9
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: eMap
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-138U
RAM-B-138-GA4U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA4U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-299-2U
RAP-299-2-GA4U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-SB-178U
RAP-SB-178-GA4U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-B-166-2U
RAP-B-166-2-GA4U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-166U
RAM-B-166-GA4U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-105-6D224U
RAP-105-6224-GA4U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-B-104-224U
RAP-B-104-224-GA4U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-149ZU
RAM-B-149Z-GA4U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-174U
RAM-B-174-GA4U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA4U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA4-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA4U (1) RAP-B-231-2U RAP-B-231-2-GA4U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
The Garmin eTrex Color Series WILL NOT fit this cradle. Please see (RAM-HOL-GA16U) on page 21.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-138U
RAM-B-138-GA5U Flat Surface Mount COMPATIBLE GARMIN MODELS: eTrex Legend eTrex Summit eTrex Venture eTrex Vista eTrex Camo INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA5U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-299-2U
RAP-299-2-GA5U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-SB-178U
RAP-SB-178-GA5U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-B-166-2U
RAP-B-166-2-GA5U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-166U
RAM-B-166-GA5U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-105-6D224U
RAP-105-6224-GA5U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-B-104-224U
RAP-B-104-224-GA5U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-149ZU
RAM-B-149Z-GA5U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-174U
RAM-B-174-GA5U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA5U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA5-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAP-B-231-2U RAP-B-231-2-GA5U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
4
9
7
47
9
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: eMap
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-138U
RAM-B-138-GA4U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA4U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-299-2U
RAP-299-2-GA4U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-SB-178U
RAP-SB-178-GA4U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-B-166-2U
RAP-B-166-2-GA4U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-166U
RAM-B-166-GA4U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-105-6D224U
RAP-105-6224-GA4U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAP-B-104-224U
RAP-B-104-224-GA4U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-149ZU
RAM-B-149Z-GA4U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA4U (1) RAM-B-174U
RAM-B-174-GA4U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA4U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA4U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA4U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA4-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA4U (1) RAP-B-231-2U RAP-B-231-2-GA4U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
The Garmin eTrex Color Series WILL NOT fit this cradle. Please see (RAM-HOL-GA16U) on page 21.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-138U
RAM-B-138-GA5U Flat Surface Mount COMPATIBLE GARMIN MODELS: eTrex Legend eTrex Summit eTrex Venture eTrex Vista eTrex Camo INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA5U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-299-2U
RAP-299-2-GA5U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-SB-178U
RAP-SB-178-GA5U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-B-166-2U
RAP-B-166-2-GA5U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-166U
RAM-B-166-GA5U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-105-6D224U
RAP-105-6224-GA5U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAP-B-104-224U
RAP-B-104-224-GA5U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-149ZU
RAM-B-149Z-GA5U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA5U (1) RAM-B-174U
RAM-B-174-GA5U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA5U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA5-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA5U (1) RAP-B-231-2U RAP-B-231-2-GA5U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
4 9 7 47 9
76S.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-138U
RAM-B-138-GA6U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPS 72 GPS 76 GPS 96 GPSMAP 72 GPSMAP 76 GPSMAP 76S INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA6U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-299-2U
RAP-299-2-GA6U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-SB-178U
RAP-SB-178-GA6U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-B-166-2U
RAP-B-166-2-GA6U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-166U
RAM-B-166-GA6U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-105-6D224U
RAP-105-6224-GA6U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-B-104-224U
RAP-B-104-224-GA6U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-149ZU
RAM-B-149Z-GA6U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-174U
RAM-B-174-GA6U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA6U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA6-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAP-B-231-2U RAP-B-231-2-GA6U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
GPSMAP 296, GPSMAP 376C, GPSMAP 378, GPSMAP 396, GPSMAP 478 & GPSMAP 496.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-138U
RAM-B-138-GA7U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA7U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-299-2U
RAP-299-2-GA7U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-SB-178U
RAP-SB-178-GA7U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-B-166-2U
RAP-B-166-2-GA7U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-166U
RAM-B-166-GA7U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-105-6D224U
RAP-105-6224-GA7U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-B-104-224U
RAP-B-104-224-GA7U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-149ZU
RAM-B-149Z-GA7U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-174U
RAM-B-174-GA7U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA7U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA7-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAP-B-231-2U RAP-B-231-2-GA7U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
GPSMAP 176 GPSMAP 176C GPSMAP 196 GPSMAP 276C GPSMAP 296 GPSMAP 376C GPSMAP 378 GPSMAP 396 GPSMAP 478 GPSMAP 496 INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAM-B-121-238U RAM-B-121-GA7U Aviation Yoke Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
4 9 7 47 9
76S.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-138U
RAM-B-138-GA6U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPS 72 GPS 76 GPS 96 GPSMAP 72 GPSMAP 76 GPSMAP 76S INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA6U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-299-2U
RAP-299-2-GA6U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-SB-178U
RAP-SB-178-GA6U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-B-166-2U
RAP-B-166-2-GA6U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-166U
RAM-B-166-GA6U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-105-6D224U
RAP-105-6224-GA6U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAP-B-104-224U
RAP-B-104-224-GA6U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-149ZU
RAM-B-149Z-GA6U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA6U (1) RAM-B-174U
RAM-B-174-GA6U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA6U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA6-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA6U (1) RAP-B-231-2U RAP-B-231-2-GA6U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
GPSMAP 296, GPSMAP 376C, GPSMAP 378, GPSMAP 396, GPSMAP 478 & GPSMAP 496.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-138U
RAM-B-138-GA7U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA7U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-299-2U
RAP-299-2-GA7U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-SB-178U
RAP-SB-178-GA7U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-B-166-2U
RAP-B-166-2-GA7U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-166U
RAM-B-166-GA7U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-105-6D224U
RAP-105-6224-GA7U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAP-B-104-224U
RAP-B-104-224-GA7U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-149ZU
RAM-B-149Z-GA7U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA7U (1) RAM-B-174U
RAM-B-174-GA7U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA7U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA7-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAP-B-231-2U RAP-B-231-2-GA7U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
GPSMAP 176 GPSMAP 176C GPSMAP 196 GPSMAP 276C GPSMAP 296 GPSMAP 376C GPSMAP 378 GPSMAP 396 GPSMAP 478 GPSMAP 496 INCLUDED COMPONENTS: (1) RAM-HOL-GA7U (1) RAM-B-121-238U RAM-B-121-GA7U Aviation Yoke Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
4
9
7
47
9
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: Rino 110 Rino 120 Rino 130 INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAM-B-138U RAM-B-138-GA8U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA8U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-299-2U
RAP-299-2-GA8U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-SB-178U
RAP-SB-178-GA8U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-B-166-2U
RAP-B-166-2-GA8U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-166U
RAM-B-166-GA8U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-105-6D224U
RAP-105-6224-GA8U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-B-104-224U
RAP-B-104-224-GA8U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-149ZU
RAM-B-149Z-GA8U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-174U
RAM-B-174-GA8U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA8U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA8-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAP-B-231-2U RAP-B-231-2-GA8U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
StreetPilot 2660, StreetPilot 2720, StreetPilot 2730 & StreetPilot 2820.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-138U
RAM-B-138-GA9U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA9U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-299-2U
RAP-299-2-GA9U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-SB-178U
RAP-SB-178-GA9U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-B-166-2U
RAP-B-166-2-GA9U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-166U
RAM-B-166-GA9U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-105-6D224U
RAP-105-6224-GA9U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-B-104-224U
RAP-B-104-224-GA9U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-149ZU
RAM-B-149Z-GA9U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-174U
RAM-B-174-GA9U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA9U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA9-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA9U (1) RAP-B-231-2U RAP-B-231-2-GA9U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
BMW Navigator II StreetPilot 2610 StreetPilot 2620 StreetPilot 2650 StreetPilot 2660 StreetPilot 2720 StreetPilot 2730 StreetPilot 2820 RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
4
9
7
47
9
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: Rino 110 Rino 120 Rino 130 INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAM-B-138U RAM-B-138-GA8U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA8U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-299-2U
RAP-299-2-GA8U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-SB-178U
RAP-SB-178-GA8U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-B-166-2U
RAP-B-166-2-GA8U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-166U
RAM-B-166-GA8U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-105-6D224U
RAP-105-6224-GA8U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAP-B-104-224U
RAP-B-104-224-GA8U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-149ZU
RAM-B-149Z-GA8U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA8U (1) RAM-B-174U
RAM-B-174-GA8U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA8U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA8-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA8U (1) RAP-B-231-2U RAP-B-231-2-GA8U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
StreetPilot 2660, StreetPilot 2720, StreetPilot 2730 & StreetPilot 2820.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-138U
RAM-B-138-GA9U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA9U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-299-2U
RAP-299-2-GA9U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-SB-178U
RAP-SB-178-GA9U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-B-166-2U
RAP-B-166-2-GA9U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-166U
RAM-B-166-GA9U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-105-6D224U
RAP-105-6224-GA9U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAP-B-104-224U
RAP-B-104-224-GA9U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-149ZU
RAM-B-149Z-GA9U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA9U (1) RAM-B-174U
RAM-B-174-GA9U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA9U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA9U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA9U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA9-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA9U (1) RAP-B-231-2U RAP-B-231-2-GA9U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
BMW Navigator II StreetPilot 2610 StreetPilot 2620 StreetPilot 2650 StreetPilot 2660 StreetPilot 2720 StreetPilot 2730 StreetPilot 2820 RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: iQue 3200 iQue 3600 INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAM-B-138U RAM-B-138-GA10U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA10U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-299-2U
RAP-299-2-GA10U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-SB-178U
RAP-SB-178-GA10U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-B-166-2U
RAP-B-166-2-GA10U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-166U
RAM-B-166-GA10U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-105-6D224U
RAP-105-6224-GA10U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-B-104-224U
RAP-B-104-224-GA10U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-149ZU
RAM-B-149Z-GA10U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-174U
RAM-B-174-GA10U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA10U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA10-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAP-B-231-2U RAP-B-231-2-GA10U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-138U
RAM-B-138-GA11U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA11U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-299-2U
RAP-299-2-GA11U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-SB-178U
RAP-SB-178-GA11U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-B-166-2U
RAP-B-166-2-GA11U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-166U
RAM-B-166-GA11U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-105-6D224U
RAP-105-6224-GA11U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-B-104-224U
RAP-B-104-224-GA11U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-149ZU
RAM-B-149Z-GA11U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-174U
RAM-B-174-GA11U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA11U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-GA11-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA11U (1) RAP-B-231-2U RAP-B-231-2-GA11U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
iQue 3000 iQue M3 iQue M4 iQue M5
Garmin Cradles from the Auto Mounts Garmin Cradles from the Swivel Mounts Garmin Cradles from the Suction Mounts Garmin Cradles from the Non Skid Mounts RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
COMPATIBLE GARMIN MODELS: iQue 3200 iQue 3600 INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAM-B-138U RAM-B-138-GA10U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA10U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-299-2U
RAP-299-2-GA10U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-SB-178U
RAP-SB-178-GA10U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-B-166-2U
RAP-B-166-2-GA10U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-166U
RAM-B-166-GA10U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-105-6D224U
RAP-105-6224-GA10U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAP-B-104-224U
RAP-B-104-224-GA10U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-149ZU
RAM-B-149Z-GA10U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA10U (1) RAM-B-174U
RAM-B-174-GA10U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA10U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA10-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA10U (1) RAP-B-231-2U RAP-B-231-2-GA10U EZ-ON/OFF™ Composite, Handlebar Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-138U
RAM-B-138-GA11U Flat Surface Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-138U (1) RAP-339U
RAM-B-138-339-GA11U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-299-2U
RAP-299-2-GA11U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-SB-178U
RAP-SB-178-GA11U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-B-166-2U
RAP-B-166-2-GA11U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-166U
RAM-B-166-GA11U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-105-6D224U
RAP-105-6224-GA11U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAP-B-104-224U
RAP-B-104-224-GA11U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-149ZU
RAM-B-149Z-GA11U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA11U (1) RAM-B-174U
RAM-B-174-GA11U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA11U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA11U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA11U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA11-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA11U (1) RAP-B-231-2U RAP-B-231-2-GA11U EZ-ON/OFF™ Composite, Handlebar Mount COMPATIBLE GARMIN MODELS:
iQue 3000 iQue M3 iQue M4 iQue M5
Garmin Cradles from the Auto Mounts Garmin Cradles from the Swivel Mounts Garmin Cradles from the Suction Mounts Garmin Cradles from the Non Skid Mounts RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
47
9 497
47
9
60CSx & GPSMAP 60Cx.
479INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-138U
RAM-B-138-GA12U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPS 60 GPSMAP 60 GPSMAP 60C GPSMAP 60CS GPSMAP 60CSx GPSMAP 60Cx INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA12U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-299-2U
RAP-299-2-GA12U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-SB-178U
RAP-SB-178-GA12 PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-B-166-2U
RAP-B-166-2-GA12U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-166U
RAM-B-166-GA12U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-105-6D224U
RAP-105-6224-GA12U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-B-104-224U
RAP-B-104-224-GA12U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-149ZU
RAM-B-149Z-GA12U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-174U
RAM-B-174-GA12U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-238U (1) RAM-B-201U
RAM-B-176-GA12U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAP-B-231-2U RAP-B-231-2-GA12U EZ-ON/OFF™ Composite, Handlebar Mount INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAM-B-238U (1) RAM-B-201U RAM-B-GA12-231Z-2 ATV/UTV Strap Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball 4 9 7 4 9 7
GPSMAP 96 & GPSMAP 96C.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-138U
RAM-B-138-GA14U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPSMAP 76C GPSMAP 76CS GPSMAP 76CSx GPSMAP 76Cx GPSMAP 96 GPSMAP 96C INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA14U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-299-2U
RAP-299-2-GA14U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-SB-178U
RAP-SB-178-GA14U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-B-166-2U
RAP-B-166-2-GA14U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-166U
RAM-B-166-GA14U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-105-6D224U
RAP-105-6224-GA14U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-149ZU
RAM-B-149Z-GA14U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-174U
RAM-B-174-GA14U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA14U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAP-B-231-2U RAP-B-231-2-GA14U EZ-ON/OFF™ Composite, Handlebar Mount INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-238U (1) RAM-B-201U RAM-B-GA14-231Z-2 ATV/UTV Strap Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-121-238U
RAM-B-121-GA14U Aviation Yoke Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-238U (1) RAM-B-201-A
RAM-B-177-GA14U Aviation Glare Shield Clamp
Mount INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-218-1 RAM-B-131-GA14 Aviation Seat Rail Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball 4 9 7 4 9 7
74
79 497
47
9
60CSx & GPSMAP 60Cx.
479INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-138U
RAM-B-138-GA12U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPS 60 GPSMAP 60 GPSMAP 60C GPSMAP 60CS GPSMAP 60CSx GPSMAP 60Cx INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA12U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-299-2U
RAP-299-2-GA12U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-SB-178U
RAP-SB-178-GA12 PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-B-166-2U
RAP-B-166-2-GA12U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-166U
RAM-B-166-GA12U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-105-6D224U
RAP-105-6224-GA12U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAP-B-104-224U
RAP-B-104-224-GA12U Ratchet/Pivot, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-149ZU
RAM-B-149Z-GA12U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA12U (1) RAM-B-174U
RAM-B-174-GA12U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-GA12U Fork Stem, Motorcycle Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAP-B-231-2U RAP-B-231-2-GA12U EZ-ON/OFF™ Composite, Handlebar Mount INCLUDED COMPONENTS: (1) RAM-HOL-GA12U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-231Z-2 RAM-B-GA12-231Z-2 ATV/UTV Strap Mount RAM-B-238U
Aluminum Diamond Base With 1” Ball
RAP-B-238U Composite Diamond Base
With 1” Ball 4 9 7 4 9 7
GPSMAP 96 & GPSMAP 96C.
INCLUDED WITH THE CRADLE:
The cradle includes a set of two nuts and bolts to connect the cradle to any of the RAM compatible mounts. The cradle does not ship with a RAM ball. To add a 1'' ball to this cradle you need to purchase either the:
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-138U
RAM-B-138-GA14U Flat Surface Mount COMPATIBLE GARMIN MODELS: GPSMAP 76C GPSMAP 76CS GPSMAP 76CSx GPSMAP 76Cx GPSMAP 96 GPSMAP 96C INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-138U (1) RAP-339U RAM-B-138-339-GA14U Flat Surface, Magnetic Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-299-2U
RAP-299-2-GA14U RAM-A-CAN™ II Vehicle Cup
Holder Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-SB-178U
RAP-SB-178-GA14U PSA Adhesive Flex Stick Base
Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-B-166-2U
RAP-B-166-2-GA14U Composite Twist Lock, Suction
Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-166U
RAM-B-166-GA14U Twist Lock, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAP-105-6D224U
RAP-105-6224-GA14U Flex Arm, Suction Cup Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-149ZU
RAM-B-149Z-GA14U Handlebar or Rail Mount
INCLUDED COMPONENTS:
(1) RAM-HOL-GA14U (1) RAM-B-174U
RAM-B-174-GA14U Brake/Clutch Reservoir Mount
INCLUDED COMPONENTS: (1) RAM-HOL-GA14U (1) RAM-B-238U (1) RAM-B-201U (1) RAM-B-342U RAM-B-176-G
