OUR WIRELESS SENSOR NETWORK
decrease environmental risk, liability and costs
Pag. 2
THE MARKET
“…real-time environmental sensing is
growing rapidly…”
[1]“This year alone, the RFID market appears set to reach a
size of
$4.47 Billion
...”
[3]“Market prospects of M2M … expected to reach
€
200 Billion
in 2010”
[2][1] The Gartner Group, 2009
[2] Machine-‐to-‐Machine: An Emerging Communication Paradigm, 2010 [3] Report: RFID Market To Reach $5.35 Billion In 2010, March 08, 2010
THE COMPANY
Minteos was founded in 2005 in Turin.
The company is focused in the development of applications based on the Wireless Sensor Network technology for monitoring and alerting on Environment and Industrial risks.
In the 2005 Minteos was admitted at I3P – Turin Politechnic incubator - and named « Best Wireless idea of the year – Torino Wireless ».
In 2008 Minteos owners decided to launch EnvEve in Lugano, Switzerland; EnvEve has been admitted at the « Tecnopolo di Lugano ».
Since the foundation, EnvEve and Minteos have continuously invested in research , and have completed industrial projects in Italy, Greece and Switzerland.
EnvEve e Minteos have build a consolidated distributor network in various countries (Nederland, Spain, Israel, Greece, Brasil, Iran).
Pag. 4
CURRENT CUSTOMERS
4
Regione Piemonte -‐ Italian Region
Comune di Imperia -‐ Italian Municipality
Comune di Roma -‐ Italian Municipality
UISP -‐ Italian Association
WSL -‐ Swiss Federal Institute for Forest, Snow and Landscape Research
Politecnico di Torino -‐ Italian Engineering Institute
DICHI, Chemical Engineering Department of Politecnico di Torino -‐ Italian Engineering Institute
Civil Protection of Bolzano and CNR National Research Council
Byte Computer S.A.-‐ System Integrator, Greece
CVA -‐ Hydroelectric power provider, Italy
Agrindustria -‐ Agroalimentary Company, Italy
GENERAL TECNOLOGY ARCHITECTURE
Communication Channels Technology Architecture HW & SW Modules
Gateway Central Sw User Interfaces Sentry H ard w are So ftw are Repeater RF mesh 433MHz RF 433MHz GPRS INTERNET WWW (+ 3G) Console Te le co mmu ni ca tio n C ha nn el s Wi-Fi INTERNET
The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
Pag. 6
EARLY DETECTION AND PREVENTION
HELP TO REDUCE DISASTERS AND THEIR COSTS
TINY WIRELESS COMPUTERS
WORKS AS ELECTRONIC SENTRIES 24/7
Our innovative monitoring and detection technology helps companies
reduce their risk, liability and drastically reduces asset costs.
MODULES & TECHNOLOGY KEY ADVANTAGES
Long distance Communication up to 1km (optimized radio and antenna)
Low cost
Very Low power consumption: up to 10 year life with 900mA battery Easy to integrate to many sensors and to adapt do other frenquencies
Se
n
tr
ie
s
High reliability and resistant to harsh environment condition Low cost
Very Low power consumption: up to 2 years powered on battery
G
ate
w
ay
High reliability (software installed on 2 data center with db synchronization)
Unlimited customer management
Easy integration with external applications (APIs)
So ftw ar e Sy ste m
Complete technology (from sensor to web interface and phone call)
Totally owned technology (hardware, firmware, µOS and software) Fast, easy and cheap creation of new applications
Pag. 8
Why it’s different and unique
What are the characteristics that make unique and advantageous our solutions and tecnologies compared to traditional systems :
Wireless: it doesn't requires wires, cables and power – it is a fast, economical and reliable installation
Low consumption solution: since it installed, lives and works without operation
Online system: from your computer, you can see the status of sensors positioned in the field and the history of their signal
Georeferenced: each sensor tells us exactly where something is happening
Proactive: when it reaches an alert level, it automatically notifies by SMS / phone / web that there is a danger or alarm situation
RUSSIA
, 2010
:
$300
billion
damage
(based on timber market prices and reforestation costs)
Gulf of Mexico,
2010
:
$29.5
billion
damage
(cleanup costs + victims compensation)
Hungary,
2010
: $ …. still counting them
(huge toxic contamination)
Pakistan,
2010
:
$43
billion
damage
(crop damage, infrastructure destroyed, 20 Billion people displaced)
Brasil, 2011: +600 deaths … continuing
http://www.scientificamerican.com/article.cfm?id=brazil-‐rains-‐death-‐toll-‐rises
Pag. 10
Vicenza, 2010: 1.2 bil damages, 150.ooo death animals
http://www.ilgiornale.it/interni
Fiume Lambro, Lombardia, 2010: 2,5 mil liter oil spill
http://it.wikipedia.org/wiki/Disastro_ambientale_del_fiume_Lambro
Italian Landslides: 1.475 deaths from 1950
25 bil damages -‐ 52 bil investments
From Annuario ISPRA
Thyssen, Torino, 2007: 4 deaths
http://it.wikinews.org/wiki/
Torino:_quattro_i_morti_nell'incendio_alla_ThyssenKrupp
Saras, Sardegna, 2009: 3 deaths
http://lanuovasardegna.gelocal.it/dettaglio/articolo/1640552
Ppg, Napoli, 2003: 4 deaths
http://www.repubblica.it/online/cronaca/vernici/vernici/vernici.html
TECHNICAL SPECIFICATIONS
Ø RF : 433 MHz
Ø Communication range : 1,5km line of sight
Ø Typical power consumption :
• Active mode : 2mA
• Power-down mode : 4,5uA
• Transmission mode : 30mA
Ø Expected lifetime : 10 years
Ø Operating temperature : from -20°C to 80°C
SENTRY
GATEWAY
Ø RF : 433MHz / GPRS Communication
Ø Communication range : 1,5km line of sight
Ø Average power consumption: 50mW/h
Ø Power sources : solar power, back-up battery
Ø Status autocheck & notification
Ø Interference avoidance mechanisms
Ø Integrability : UMTS, HSDPS, Ethernet, WiFi
Ø Configurable and updatable via Internet
Ø Expected lifetime: > 2 years
OPERATING CENTER
Ø 2 distinct locations for redundancy
è 100% availability
Ø Integrity test on each field message
è 100% data reliability
Ø Data back-up : 5 years
Ø Autocheck modules on the whole hierarchy
è Real-time notification in case of system anomaly
NATURALERT SW
Ø Available via Internet
Ø Login access
Ø Real-time monitoring
Ø G.I.S Based
Ø Google-Earth Interface
Ø Historical database (5 years minimum)
Ø Customizable (interface, language)
Pag. 12
MARKET SEGMENTATION
APPLICATION’S TARGET MARKET
Environmental
Sustainability
Industrial Security
Process Efficiency
Improvements in Process Efficiency can reduce the need for investment in energy infrastructure, cut fuel costs, increase competitiveness and improve consumer welfare.
ü 25% commercial building energy reduction will be attributed to
WSN in 2013,worth $7.4 billion in global energy savings.
Environmental sustainability is of great importance in such geographical locations in the world, where it could be improved through sensor monitoring, by protecting valuable resources, and collecting valuable information previously considered too difficult and too costly.
The Industrial Sector is likely to undergo workflow churn as WSN applications increase safety, reliability and efficiency of industrial facilities. Frequency agility requirements are driving evolution toward industrial standards
MARKET SEGMENTATION
APPLICATION’S TARGET MARKET
Smart Environmental
FIRELESS: early detec>on of fires in remote and risky loca>ons
• Torino (Italy): pilot project of 2 ha, 50 sentries, 2 GW
• Filiatra (Greece): pilot project of 2ha, 50 sentries, 2 GW
• Lecce: industrial site, 20 ha, 110 sentries, 1 GW, 2 R
• Imperia: pilot project, 1.5 ha, 37 sentries, 2 GW
• Roma: industrial site, 40 ha, 1000 sentries, 2GW, 6 R
FIRELESS 2: frequent data update of environmental condi>ons that may lead to fires
• Lecce: industrial site, 1 meteogateway, 4 sentries
• Roma: indutrial site, 1 meteogateway, 4 sentries
• Bellinzona: pilot project, 1 meteogateway, 4 sentries
FLOODALERT: monitoring of water level in remote loca>ons with high probability of floods
Pag. 14
MARKET SEGMENTATION
APPLICATION’S TARGET MARKET
Smart Industrial and
Safety Building
SMART ENERGY: Allows to op>mize building energy consump>on based on humidity, temperature, CO, methane and lightness
DAM WATCH: constant monitoring of bridges and dams movement to prevent disaster
OIL & GAS SUITE: detec>on of intrusion or leakage of hazard gas and/or oil in pipelines or industrial sites
• Iraq
FIRESENSE: fire detec>ons for industrial warehouses thorugh CO monitoring
• Tecco Agroindustria
CONTAMINATION ALERT: density monitoring of liquid to determine if it has been contamined, preven>ng process inefficiencies
MARKET SEGMENTATION
APPLICATION’S TARGET MARKET
Smart city
SEWAGE: real >me level monitoring. Can ac>vate pumps in overflow risk. Useful to sewage management
• Athens: 90 sentries, 45 GW
ELETTROSMOG: electromagne>c environmental pollu>on monitoring • Imperia
ZTL MONITORING: air water and noise control measurement • Torino
Pag. 16
MARKET SEGMENTATION
APPLICATION’S TARGET MARKET
Smart Agriculture
AGRISENSE: measurement of different environmental factors providing agriculturists a greater control of their resources and take adequate measures at key points in the crop cycle. Main advantages are: saving water (up to 50%) and saving on chemical treatment
CONTACTS
Minteos srl
Via San Quintino, 3 10121 Torino
Tel +39 0110200455 Fax +39 0114785226
Website: http://www.minteos.com
E-mail: [email protected]
Sales contact: [email protected]
Enveve SA
Via della Posta, 10 CH-6934 Bioggio Lugano Switzerland Tel +41 916053303
Website: www.enveve.com
E-mail: [email protected]
