Network development and design
A short introduction to the MOVE Meter:
a web based tool to support your
planning process
// 9-Jul-15 //
Content
// 9-Jul-15 //
pagina 3 Network development and design with the MOVE Meter
1. Introduction
2. MOVE Mobility
3. The MOVE Meter in AUSTIN (TX)
4. Other features of the MOVE Meter
5. Technical details of the MOVE Meter
6. Contact information
1. MOVE Mobility
// 9-Jul-15 //
MOVE MOBILITY
// 9-Jul-15 //
pagina 5 Network development and design with the MOVE Meter
• Founded in 2012
• Focus:
• Front office in business development for
our partners in international markets
• Europe (Germany, UK, Georgie)
• Outside Europe (US, Uganda, South
Africa, Kurdistan)
• Software development and applications
• MOVE Meter
• Monitoring tool
• Associate of Goudappel Coffeng
• Our ambition is to support cities in their
transition towards a Smart Moving City
2. Introduction
// 9-Jul-15 //
Road design
Network planning
Multimodal network design
Interdisciplinary planning
1950
1970
1990
2010
Evolution in transportation planning in NL
// 9-Jul-15 //
pagina 7 Network development and design with the MOVE Meter
Complexity: process, content, technically
Car
Public Transport
Bicycle
// 9-Jul-15 // Network development and design with the MOVE Meter pagina 8
Capacity of infrastructure per 3,5 m width
// 9-Jul-15 // Network development and design with the MOVE Meter pagina 9
Public
transport
Interdisciplinary planning
The result of a two day workshop
// 9-Jul-15 //
pagina 10 Network development and design with the MOVE Meter
Car
The MOVE Meter facilitated this process
// 9-Jul-15 //
pagina 11 Network development and design with the MOVE Meter
It is a web based tool that:
- let you play with different scenarios
- is easy to use by all planners
- presents results quickly (< 10 minutes per scenario)
In the case of Austin TX the tool was used to:
- show the bicycle potential
- demonstrate the impact of cycling on congestion
Basic functions of the MOVE Meter
// 9-Jul-15 //
3. The MOVE Meter in Austin (TX)
// 9-Jul-15 //
Where is my network congested?
// 9-Jul-15 //
pagina 14 Network development and design with the MOVE Meter
Who is using my network?
// 9-Jul-15 //
pagina 15 Network development and design with the MOVE Meter
Where to invest in cycling?
// 9-Jul-15 //
pagina 16 Network development and design with the MOVE Meter
What is the potential impact of cycling?
// 9-Jul-15 //
pagina 17 Network development and design with the MOVE Meter
Zoom in to get more detail
// 9-Jul-15 //
What did the MOVE Meter add to the process
in Austin ?
// 9-Jul-15 //
pagina 19 Network development and design with the MOVE Meter
…”Austin officials gave the firm (MOVE Mobility)
transportation planning data from its Metropolitan
Planning Organization (MPO), and they
now have a
tool by which to analyze how bicycle infrastructure
can affect the transportation system as a whole.
The
introduction to the tool allowed us to see one way
and one tool Dutch cities use to make transportation
decisions related to bicycles."
Impact of infill or sprawl in Utrecht
Network performance based on actual
speeds
Accessibility Index
4. Other MOVE Meter applications
// 9-Jul-15 //
Click on the zones where you want to build 20.000 houses.
The MOVE Meter calculates trips and divides them over the region.
Impact of infill or sprawl in Utrecht (1)
Scenario 1: Condense in the city Scenario 2: Urban sprawl
9-Jul-15
Impact of infill or sprawl in Utrecht (2)
Increase of traffic when condensing Increase when spreading
Building in the city induces an increase of (shorter) car trips.
9-Jul-15 Network development and design with the MOVE Meter 22
The use of the Accessibility Indicator (BBI)
9-Jul-15 Network development and design with the MOVE Meter pagina 24
Den Haag Centre :
AM arrivals and road sections with congestion based on actual data
9-Jul-15 Network development and design with the MOVE Meter pagina 25
Monitoring using actual speeds
2013 and 2014 including travel times
// 9-Jul-15 // Network development and design with the MOVE Meter pagina 27
5. Technical data
// 9-Jul-15 //
Difference with other transport modeling tools
// 9-Jul-15 //
pagina 30 Network development and design with the MOVE Meter
• Web based (you can use any PC/laptop anywhere);
• Easy to use (no need to know Transport Planning
Software);
• Quick scenario analyses;
• Based on data from your own Transportation Model;
• Scenario analyses ready after 10-15 minutes.
Why is the MOVE meter so fast?
1.
The MOVE Meter works with less
zones. It aggregates data from zones
that are further away from the area
you have pointed out as focus area.
2.
The MOVE meter focuses on the
issues addressed. So when you want
to assign an OD-matrix to get an idea
of the effects on V/C ratios, the MOVE
Meter assigns the OD matrix without
calculating new speeds or changes in
modal split.
