FLASH MICROCONTROLLER

PROGRAMMING GUIDE

(2)

Pamphlet U17413EJ8V0PF Pamphlet U17413EJ8V0PF

2

3 A reliable and pleasant

programming environment

Flash Microcontroller Programming List

• Initial fee

• Marking

• Delivery time

• Quantity

• Support of large-volume programming

• Stable supply

• Marking possible

• Introduction of programmer not required NEC Electronics Products programmed by NEC Electronics • Programming fees • Possibility of programming products • Presence/absence of marking • Delivery time

• Flexible handling of programming changes

• Introduction of programmer not required

• Fast delivery

• Marking possible Programming house

Programming by programming house

Customer's production line

Programming by customer • Embedding of programming

circuit

• Introduction of programmer

• Low-cost programming

• Quick handling of programming changes

• Fast delivery

• Possibility of making program changes after mounting

• Low-cost programming

• Quick handling of programming changes

• Fast delivery Customer's production line

Off-board Off-board Off-board On-board

Points to Consider

Advantage

Programming Location

Programming Method

• Introduction of programmer and adapter

NEC Electronics offers a large array of microcontrollers with internal flash memory (hereafter, flash

microcontrollers) to satisfy the needs of customers.

To enable comfortable use of this large lineup of flash programmers, NEC Electronics and its partners

offer many programming tools, making easy programming possible in many different settings such as

in development environments and production lines.

Moreover, programming services for NEC Electronics’ flash microcontrollers are available from

programming houses both in Japan and overseas, and NEC Electronics is offering programmed

products, and an environment for supporting a large range of needs, from programming of small

quantities of devices with quick delivery to stable programming of mass-produced devices, is

available

Note

_.

Our All Flash products can help you handle sudden market changes by selecting the optimal solution

from the many types of available programming methods.

Programming

Board mounting

On-board programming by customer

On-board programming: Programming after mounting

Programming

Off-board programming by customer

Programming by programming house

Offering products programmed

by NEC Electronics

Flash microcontroller

ordering and delivery

acceptance

FLASH MICROCONTROLLER PROGRAMMING GUIDE

There are two main types of programming.

No

Yes

No

Yes

Programming by

programming house

Off-board programming

by customer

On-board programming

by customer

Please select the programming method best suited to customer needs.

Priority on fast

delivery?

Want to rewrite

program on

production line?

Want to rewrite

program on

board?

Software

development

proceeds until just

before mass

production start?

Selection of Programming Method

Program completion

Purchase

programmer?

Products programmed

by NEC Electronics

pp. 4 & 6 p. 5

(Please check ordering conditions with one of our sales representatives.)

Off-board programming: Programming before mounting

Board mounting

(3)

Software development

Hardware development

Ordering

Production

Software development

Hardware development

Ordering

Production

Software development

Hardware development

Ordering

Production

Assembly & mounting Testing (including programming) Final assembly Production

line

On-board programming by customer

• Code number markings are applied to Flash products.

• Special markings are also available.

This is a highly flexible programming method that allows the customer to rewrite

the flash microcontroller even after it has been mounted on the board.

This is a programming service characterized by fast delivery and flexibility (labeling, etc.).

Programming for NEC Electronics' flash microcontrollers is supported by programming houses both in Japan and overseas.

NEC Electronics offers programmed products, in the same manner as mask ROM products.

Programming before mounting

Off-board programming by customer

Many different types of programmers, including single programmers, gang programmers, and simple programmers, can be selected.

Refer to the list of flash memory programmers on page 6.

Once the software has been completed, the customer can directly perform programming.

<1> Ordering of blank products <2> Programmer (including adapter)

Assembly & mounting Testing (including programming) Final assembly Production

line

Programming by programming house

Shipment of products programmed by NEC Electronics

(for All Flash products

Note

)

Programming using the optimum process can be done on the customer's production line.

http://www.romtec.co.jp

ROMTEC, Inc.

http://www.sourcee.com

SOURCE Electronics Corporation

Asia

North America

Europe

Code

ordering

Programming

Shipping

Data

processing

A programmer is required for programming samples for evaluation during debugging.

A programmer is required for programming samples for evaluation during debugging. Secure signal lines for

on-board programming*

Programming on production line

Programming on production line Customer's board

(Perform customization as required and introduce on production line) * For the required signal lines, refer to the Hardware User's

Manual of each product.

The programmed products are mounted on the boards.

Software development

Hardware development

Product ordering

Ordering of programming

Production

Ordering of blank products

The programmed products are mounted on the boards.

Following software completion, order programming.

(Specify conditions such as marking at this time.)

Flash memory programmer

Following software completion, order programming.

(Please consult your NEC Electronics sales representative in advance regarding your order plans.)

http://www.synchro.co.jp/en/index_en.html Synchro-Work Corporation <1> Ordering of blank products <2> Programmer

http://www.mtbrk.com

Matsubara.k Corporation

http://www.liberty-rom.com

Liberty Corporation

Check with the manufacturers about what services are provided.

Note Please consult a NEC Electronics sales representative or distributor for information on corresponding devices.

http://www.ertec.de

ertec GmbH

http://www.arrowne.com

ARROW Electronics(UK) Ltd Japan U.S.A. Germany U.K.

http://www.msc.de

MSC Vertriebs GmbH

Gleichmann & Co. Electronics GmbH Japan, China (Shanghai)

Singapore

http://www.telfordgp.com

Telford Industries Pte Ltd

(4)

Pamphlet U17413EJ8V0PF Pamphlet U17413EJ8V0PF

SuperFlash is a registered trademark of Silicon Storage Technology, Inc. in several countries including the

United States and Japan.

The names of other companies and products are the registered trademarks or trademarks of each company.

Caution: Some of the products use SuperFlash

®

_{under the license obtained from Silicon Storage Technology, Inc.}

To meet these desires, we can prepare

**application notes and sample programs*.**

Target product series

*The development circumstances differ depending on the product series. Check with an NEC Electronics sales representative or distributor.

78K0S/Kx1+,78K0/Kx1+,78K0/Kx2,78K0/Kx2-L,78K0/Ix2,78K0/Lx2,78K0/Lx3,78K0R/Kx3,

78K0R/Kx3-C,78K0R/Ix3,78K0R/Kx3-L,V850ES/Kx2,V850ES/Jx2,V850ES/Hx2,V850ES/IE2,

V850ES/Jx3,V850E/IF3,V850E/IG3,V850ES/Jx3-L,V850ES/Jx3-H,V850ES/Jx3-U,V850ES/Hx3

6

7 The following resources are available for comfortable programming by the customer.

Flash memory programmer

Wouldn't you like to have an original programmer?

Are you in a situation like one of these?

Increase your productivity with NEC Electronics' PG-FP5 flash memory programmer,

which features a superior programming GUI for mass production.

Menu buttons

Programmer parameters window

Action log

window

History recording

is possible.

PG-FP5

NEC Electronics

FLASH MICROCONTROLLER PROGRAMMING GUIDE

• The source code can be

made available.

The PG-FP5's GUI has evolved

into a powerful interface that

sup-ports mass production!

The FPterm (Under development) Screen shot Naito Densei Machida Mfg, Co. Ltd.

•Your company is developing on its own

mainte-nance equipment for each set, and you want to

rewrite programs with this equipment.

•You want to completely embed an original

pro-grammer in an in-house production system.

NET IMPRESS Series

Yokogawa Digital Computer Corporation

Y3000-8 Series

Wave Technology Co., Ltd.

Stick GANG Writer

Flash Support Group,Inc.

SmartPRO5000U

Guangzhou ZHIYUAN Electronics Co.,Ltd

Naito Densei Machida Mfg. Co., Ltd.

StickWriter

NEC Electronics Partners

ITF2000

Interface Co., Ltd.

FlashPAK

Data I/O Corporation

Check with the manufacturers about whether these programmers can be used with mass-produced products.
