This TechNote applies to MaxSea TimeZero Navigator and Explorer v1.9.5 and above
Description:
MaxSea display the following error when starting (in Navigation or Home Planning):
Resolution:
MaxSea TimeZero uses Microsoft SQL server to store routes, waypoints, logbook and track information. Microsoft SQL server is installed as part of the MaxSea TimeZero installation. In some instances, the installation of Microsoft SQL fails or the service is not properly launched. Follow the steps below (in the order) to correct the problem.
1) Remove any existing Microsoft SQL component
Close MaxSea and open the “Add or Remove Programs” utility from the Control Panel.
Note: under Vista/7, you need to open “Programs” (or “Programs and Features”) from the Control Panel.
Look for anything starting with “Microsoft SQL”.
Note: If you don’t see any “Microsoft SQL” item in the Control Panel, proceed to the next step
2 To remove Microsoft SQL, start with the main component (“Microsoft SQL Server 2008”
or “Microsoft SQL server 2005”) then remove all the other components (when applicable).
Note: Please refer at the Appendix (chapter 1)) for an example of all the steps involved in the un-installation under Vista/7
When all the “Microsoft SQL” items are removed from the Control Panel, go to the
“Program Files” folder (Computer -> Local Disk (C:) -> Program files) and delete any folder beginning with “Microsoft SQL Server”.
Note: Under 64Bit Operating System, you also have to delete the “Microsoft SQL Server” folder from “Program Files (x86)” (Computer -> Local Disk (C:) -> Program files(X86))
Once all the Microsoft SQL components are removed and the folder(s) deleted, restart the computer.
Note: If you cannot delete the “Microsoft SQL Server” from the program file, you have to manually stop the “SQL Server (MAXSEASQLEXPRESS” service. Please refer to
chapter 3 to access the SQL service Window and click on “Stop”.
2) Install (or re-install) Microsoft SQL Server
a) Disable any Anti-virus/Anti-Spyware and Firewall that could be running in the background. Make sure that the computer is logged as an Administrator.
b) If you have the MaxSea TimeZero DVD: Insert the MaxSea TimeZero v1.9.5 install DVD into the computer. If the Autorun starts, cancel it. Go to “My
Computer” (or “Computer” under Vista and Windows 7) and locate the CD/DVD drive. Right click on it and choose “Explore” to browse the content of the DVD.
Browse to “Tools -> SetupPrerequisites ->
MSQL_Server_2008_Express_R2_MaxSeaInstance” and double click on
“Setup.exe” to launch the manual installation of Microsoft SQL 2008.
If you don’t have the DVD: Download and run the standalone SQL Installer for MaxSea TZ:
http://download.maxsea.com/MSQL_Server_2008_Express_R2_MaxSeaInstance.exe
3 Note: If you have an error about the .NET framework not being installed (required for SQL server installation and MaxSea TZ), you can manually launch the .NET framework installation from the MaxSea DVD “Tools\SetupPrerequisites\Frame Work 3.5”. Just double click on “dotnetfx35.exe”.
c) The SQL installer will ask you to accept agreements and to confirm multiple steps: simply leave the default setting and click on “OK”, “Next” or “install” when asked.
Note: Please refer to the Appendix (chapter 2)) to see all the steps and the prompts of the Microsoft SQL installation under Vista/7
d) If the installation is successful restart the computer.
Note: If a problem occurs during the installation, you can usually click on “view detail report” to have a description of the error. Please check the Appendix(at the very end of this document) for a list of all the known errors and fixes
e) Open MaxSea. If you still have an error, proceed to the next step.
3) Checking for Microsoft SQL service
a) Ensure that the Microsoft SQL service is running and properly configured to be launched at Startup.
I. Under XP
Right click on “My Computer”, available on the Desktop or from the Start Menu, and choose “Manage”.
4 Expand “Service and Applications”; and then, “Services”. Scroll the window until the line appears containing the name “SQL Server (MAXSEASQLEXPRESS)”. In the “Status”
column, check that “Started” is present. In the “Startup Type” column, ensure that it is set for “Automatic”.
If changes are needed, double click on the line to open the property window:
Ensure the “Startup Type” is set for “Automatic” and the “Service Status” is started by clicking on “Start” if necessary.
II. Under VISTA/7
Click on “Start”, Windows Icon on the bottom left, and search for “Services” on the bottom of the page. Click on “Services” on the top of the Window to launch the Services Manager.
5 Scroll the window until the line appears containing the name “SQL Server
(MAXSEASQLEXPRESS)”. In the “Status” column, ensure that “Started” is present. In the “Startup Type” column, ensure that it is set for “Automatic”.
If changes are needed, double click on the line to open the property window.
6 Make sure that the “Startup Type” is set for Automatic and that the “Service Status” is started by clicking on “Start” if necessary.
Note: Other SQL services (such as “SQL Server Active Directory”) might not be started.
This is normal. Just make sure that the service “SQL Server (MAXSEASQLEXPRESS)”
is started.
Open MaxSea. If you still have an error, proceed to the next step.
4) Reset the MaxSea database a) Under XP:
Go to “C:\Documents and Settings\All Users\Application Data\MaxSea Int\Data” and delete all the “.mdf” and “.ldf” files (do NOT delete any folder inside the Data folder)
7 Note: The folder “Application Data” is a Hidden folder. The display of hidden folders from the “Tool” menu must be enabled:
b) Under Vista
Go to “C:\ProgramData\MaxSea Int\Data” and delete all the “.mdf” and “.ldf” files (do NOT delete any folder inside the Data folder)
8 Note: The folder “ProgramData” is a Hidden folder. To show Hidden Folder under
Vista/7, go to the Control Panel and select “Appearance” then “Folder Option” then select the “View” tab and change the setting (“Show Hidden Files and Folder”)
Once the databases have been erased, launch MaxSea and try again.
5) Change Services Properties
Open the MAXSEASQLEXPRESS service properties windows (please refer to previous step) and select the “Log On” tab:
Change the logon to “Local System account”, click on apply then click on “OK” when the warning appears:
Select the “General” tab, click on “Stop”, wait 30 seconds then click on “start”
9 Open MaxSea and try to make a mark. If this is successful, you must set back the
original settings:
Open the MAXSEASQLEXPRESS service properties windows (please refer to previous step) and select the “Log On” tab, set the Log on as “This account” and click on
“Browse”
Click on “Advanced”
Click on “Find Now” then select “Network service” in the list then press OK
Click OK to validate.
10 When you are back on the Properties windows, erase the password (leave it blank) then click on Apply
Select the “General” tab, click on “Stop”, wait 30 seconds then click on “start”
11
Appendix
1) SQL Un-installation Example under VISTA/7
12
13 2) SQL Installation Example under VISTA/7
14
15
16
17
18 3) Microsoft SQL Installation problems
Here are some of the known problems that can happen during the Installation of SQL server:
- Microsoft SQL will not install on compressed Hard-Drive. Right click on the drive letter of your hard-drive (from “My Computer”), select “Properties” and make sure
19 that the option is unchecked:
- Sometimes, the installer of Microsoft SQL asks you to restart your computer during the installation. This can be normal, however, if it prompt you to restart over and over (at the same step each time), you have to delete a registry key.
Open Regedit, browse to “HKLM \ System \ CurrentControlSet \ Control \ SessionManager” and delete the key “PendingFileRenameOperations”
Note: Make sure to select (and highlight) the “SessionManager” folder in order for the key to appear on the right.
