ORACLE USER PRODUCTIVITY KIT

V3.6.1 TECHNICAL SPECIFICATIONS

(WITH ENABLEMENT SERVICE PACK 3)

KEY FEATURES AND BENEFITS

DRIVE USER PRODUCTIVITY AND MITIGATE RISK. FEATURES

Single, synchronized authoring session for system process documents, test scripts, training manuals, simulations, performance support, presentations, and quick reference guides Multiple learning methods: watch and practice simulations, knowledge tests and in-application

performance support Content workflow and management including check-in and checkout, versioncheck-ing, rollbacks, and status updates SmartMatch context sensitive help for most web-based applications

Multilanguage translation Full-feature sound recording and editing

BENEFITS

Maximize ROI on enterprise applications by educating users quickly and keeping support documents current Reduce the costs associated with multilanguage software implementations

Mitigate compliance risk by ensuring users consistently follow process steps Manage knowledge by delivering training within the application itself

Record simulations in a way that mirrors how users complete tasks Reduce training,

documentation, and ongoing help desk costs

Create engaging conceptual and transactional content with full-feature recording and editing

Oracle User Productivity Kit is a collaborative content development

platform that allows enterprises to drive user productivity and

mitigate risk throughout all phases of the software ownership

lifecycle. This document provides the minimum system requirements

for various Oracle User Productivity Kit components. Your

organization might be implementing some or all of these

components, so refer to the sections that are applicable to you.

Multi-user Install

Content authors use the Oracle User Productivity Kit (UPK) development tool to create content. This section outlines the technical requirements for a multi-user installation of the UPK development tool. In a multi-user installation, the core UPK development tool files are installed on a central server for content sharing, and a client version of the UPK development tool is installed locally on the content author‘s workstation.

Server Requirements for a Multi-user Install

Hardware

Processor 1GHz or greater System memory 1GB or greater

Physical storage 360 MB for program files

Network connection

100Mb connection capable of communicating via HTTP(S) and TC P/IP

Connection utilized for communication between the Development server and the Database server. Increased bandwidth typically improves performance.

Software

Operating system

Microsoft Windows 2003 Server 32-bit SP2 or 64-bit SP2, 2008 Server 32-64-bit (SP1 or SP2) or 64-64-bit (SP1 or SP2), or 2008 Server R2 32-bit or 64 bit Web server Microsoft Internet Information Services is required Software framework Microsoft .NET Framework 3.5

(2)

Reduce performance support costs with context sensitive help

Reduce translation and localization costs

RELATED PRODUCTS

Pre-built application-specific content is available to jump-start any implementation or upgrade for the following enterprise software applications:

PeopleSoft Enterprise JD Edwards EnterpriseOne & JD Edwards World

Oracle E-Business Suite Agile PLM

Demantra Siebel CRM Hyperion

A full list of available content titles can be found online at oracle.com/applications/tutor/up k_collateral.html.

Oracle User Productivity Kit Professional is the leading solution for creating, deploying, and accessing content for major enterprise application deployments. It comprises the following:

Oracle User Productivity Kit Oracle User Productivity Kit Professional’s Knowledge Pathways designer, manager, and player modules Oracle Tutor creates, customizes, and maintains process documentation for enterprise applications.

Server Requirements for a Multi-user Install (continued)

Database

Database

Oracle Database v9.2.0.8, v10.1, v10.2, v11.1, or v11.2 --OR-- Microsoft SQL Server 2005 SP3 or SQL Server 2008 (RTM or SP1)

Physical storage

500MB for initial installation; additional storage possibly required depending on amount of content created.

Client Requirements for a Multi-user Install

Hardware

Physical storage 1120 MB (520 MB for program files; 600 MB for locally stored content)

Network connection

Broadband or faster (1.5 mb/s download, 512 kb/s upload ) connection capable of communicating via HTTP(S) and TCP/IP

Connection utilized for communication between the UPK Developer client and the UPK server. Increased bandwidth typically improves performance.

Software

Operating system

Microsoft Windows XP Professional 32-bit (SP2 or SP3)

Microsoft Windows XP Professional 64-bit (SP2) Microsoft Windows Vista 32-bit (RTM, SP1, or SP2)

Microsoft Windows Vista 64-bit (RTM, SP1, or SP2)

Microsoft Windows 7 32-bit Microsoft Windows 7 64-bit DPI setting 96 DPI Fonts

Browser

Required: Microsoft Internet Explorer 6.0 SP1,7.0, or 8.0

Optional: Mozilla Firefox 3.5 or 3.6, or Apple Safari 4.0 or 5.0

Software framework Microsoft .NET Framework 3.5

Word processing software

Microsoft Office 2002 Pro SP3 (PowerPoint requires KB957781)

Microsoft Office 2003 Pro SP3, 2007 (SP1 or SP2) Microsoft Office 2010 (32 bit or 64 bit versions) for document outputs (includes PDF format)

Other required applications

Microsoft Word 2010 (32 bit or 64 bit versions), 2007, 2003 or 2002 is required to publish and/or edit document styles or player styles using ―Print It!‖ mode, and to publish PowerPoint output. Word 2003 and 2002 require the ―Microsoft

(3)

Office Compatibility Pack (SP1 or SP2) for Word, Excel, and PowerPoint 2007 File Formats‖.

‗Microsoft Save As PDF‘ add-in is required to publish to .pdf using Microsoft Word 2007. Adobe Acrobat 8 or 9 Standard or Professional is required to create PDF documents with

Microsoft Word 2003 or earlier.

Adobe Flash 9 or 10 required for sound playback HP Test Director 9.0, 9.2, or 10.0 and HP Quality Center Microsoft Excel Add-on for Quality Center 9.0, 9.2, or 10.0 are required to create HP Quality Center documents.

Microsoft Excel 2007, 2003 or 2002 is required to view and/or export UPK-generated HP Quality Center documents into HP Quality Center. Excel 2003 and 2002 require the ―Microsoft Office Compatibility Pack (SP1 or SP2) for Word, Excel, and PowerPoint 2007 File Formats‖. Excel is not required to generate the documents.

IBM Rational Quality Manager, Microsoft Excel and Word to Rational Quality Manager Import Utility, and the UPK Best Practices: IBM Rational Quality Manager.zip are required to create test scripts in IBM Rational Test Manager. Additional info can be found at:

http://blogs.oracle.com/UPK/2010/05/upk_and_ rqm.html.

Single User Install

Content authors use the Oracle User Productivity Kit (UPK) development tool to create content. This section outlines the system requirements for a single user installation of the UPK development tool. In a single user installation, the core UPK development tool files are installed locally on the content author‘s workstation.

Technical Requirements for a Single User Install

Hardware

Physical storage

1.25GB of physical storage (650 MB for program files; 600 MB for content); additional physical storage possibly required depending the amount of content created

Software

Operating system

Microsoft Windows XP Professional 64-bit (SP2) Microsoft Windows Vista 32-bit (RTM, SP1, or SP2) Microsoft Windows Vista 64-bit (RTM, SP1, or SP2) Microsoft Windows 7 32-bit

Microsoft Windows 7 64-bit DPI setting 96 DPI Fonts

(4)

Software (continued)

Browser

Required: Microsoft Internet Explorer 6.0 SP1, 7.0, or 8.0

Optional: Mozilla Firefox 3.5 or 3.6, or Apple Safari 4.0 or 5.0

Software framework Microsoft .NET Framework 3.5

Word processing software

Microsoft Office 2002 Pro SP3 (PowerPoint requires KB957781),

Microsoft Office 2003 Pro SP3, 2007 (SP1 or SP2) Microsoft Office 2010 (32 bit or 64 bit versions) for document outputs (includes PDF format)

Other required applications

Microsoft Word 2010 (32 bit or 64 bit), 2007, 2003 or 2002 is required to publish and/or edit document styles or player styles using ―Print It!‖ mode, and to publish PowerPoint output. Word 2003 and 2002 require the ―Microsoft Office Compatibility Pack (SP1 or SP2) for Word, Excel, and PowerPoint 2007 File Formats‖.

‗Microsoft Save As PDF‘ add-in is required to publish directly to .pdf using Microsoft Word 2007. Adobe Acrobat 8 or 9 Standard or Professional is required to create PDF documents with Microsoft Word 2003 or earlier.

Adobe Flash 9 or 10 required for sound playback. HP Test Director 9.0, 9.2, or 10.0 and HP Quality Center Microsoft Excel Add-on for Quality Center 9.0, 9.2, or 10.0 required for HP Quality Center docs. Microsoft Excel 2010 (32 bit or 64 bit), 2007, 2003 or 2002 is required to view and/or export UPK-generated HP Quality Center documents into HP Quality Center. Excel 2003 and 2002 require the ―Microsoft Office Compatibility Pack (SP1 or SP2) for Word, Excel, and PowerPoint 2007 File Formats‖. Excel is not required to generate the documents.

IBM Rational Quality Manager, Microsoft Excel and Word to Rational Quality Manager Import Utility, and the UPK Best Practices: IBM Rational Quality Manager.zip are required to create test scripts in IBM Rational Test Manager. Additional info can be found at: http://blogs.oracle.com/UPK/2010/05/ upk_and_rqm.html.

(5)

Content Publication

This section discusses the system requirements for Oracle User Productivity Kit (UPK) published output—that is, the content that end users will view and use. After creating UPK content using the UPK development tool, content authors will publish the content to one or more different published outputs. There are three types of published outputs discussed in this document: Player, Learning Management System (LMS), and HTML Web site.

Server Requirements for Player, LMS Package, and HTML Web Site

Hardware

Physical storage Between 500MB and 4GB of physical storage adequate for most implementations

Network connection Network connection capable of communicating via HTTP(S) and TCP/IP

Software

Operating system Any Web server Any

LMS package

Compliant with AICC 3.5, SCORM 1.2, or SCORM 2004. Note: AICC deployments utilize a Java applet for LMS server communication. Sun JRE is required on client workstations.

End-User Requirements for Player, LMS Package, and HTML Web Site (One supported browser and OS combination required)

Browser Operating System

Microsoft Internet Explorer 6.0, 7.0, or 8.0

Microsoft Windows 2000 SP4

Microsoft Windows 7 32-bit Microsoft Windows 7 64-bit

Mozilla Firefox 3.5 or 3.6

Microsoft Windows 7 32-bit Microsoft Windows 7 64-bit Macintosh OS X 10.2.x or later Modern Linux distribution

(6)

Browser Operating System

Apple Safari 4.0 or 5.0

Microsoft Windows Vista N 32-bit Microsoft Windows Vista N 64-bit Microsoft Windows 7 32-bit Microsoft Windows 7 64-bit Macintosh OS X 10.2.x or later Other required

applications

Adobe Flash 9 or 10 is required for sound playback

Usage Tracking Component

Oracle User Productivity Kit (UPK) includes a usage tracking component that can be used to track end-user progress through the published training content. The usage tracking installation files are included on the Oracle User Productivity Kit

development tool CD. It is an optional component and is not required to create or deploy UPK content. This section discusses the requirements for implementing the optional usage tracking component.

Server Requirements for a Usage Tracking Install

Hardware

Physical storage

525 MB – 25 MB for initial software installation, between 500MB and 4GB of physical storage adequate for most implementations

Network connection 100 mb/s Network connection capable of communicating via HTTP(S) and TCP/IP

Software

Operating system

Microsoft Windows 2003 Server 32-bit SP2 or 64-bit SP2

Microsoft Windows 2008 Server 32-bit (SP1 or SP2) or 64-bit (SP1, or SP2)

Microsoft Windows 2008 Server R2 32-bit or 64-bit. Browser Microsoft Internet Explorer 6.0 SP1, –OR- 7.0, –

OR- 8.0 is required for the Usage Tracking Administration and Reporting components. Web server Microsoft Internet Information Services is required Software framework Microsoft .NET Framework 3.5

(7)

Database

Database

Oracle Database v9.2.0.8, v10.1, v10.2, v11.1, – OR- v11.2 --OR-- Microsoft SQL Server 2005 SP3 –OR-SQL Server 2008 (RTM or SP1)

Target Applications: Comprehensive Enterprise Application Support

Oracle User Productivity Kit provides enhanced object recognition and context-sensitive support for the following Enterprise Applications‘ 32-bit clients. Contact Oracle Support for the latest list of supported releases and patches.

Oracle Applications

Agile Customer Needs Management

Application Version

1.0

Agile Product Lifecycle Management

Application Version Versions Supported

9.3.1 9.3.1 9.3.0 9.3.0, 9.3.0.2

JD Edwards EnterpriseOne

Application Version PeopleTools Version

9.0 Latest version verified: 8.98.01 8.12 Latest version verified: 8.97 8.11 SP1 Latest version verified: 8.95

JD Edwards World

Application Version Client Verified

A9.1/A9.2 Web

Enablement MP5 LegaSuite GUI 4.1C10 and 4.1C14

Oracle CRM On Demand

Release 18

Additional Information

Context-sensitive deployment with Oracle CRM On Demand is supported with the SmartHelp add-in for browsers.

Oracle E-Business Suite

Application Version Last Patch Verified

R12 12.0.0, 12.1.1, 12.1.2, 12.1.3

11.5 11.5.10.x (with JInitiator versions 1.1.8.25 and 1.3.1.30)

(8)

Refer to the In-Application Support Guide prior to recording for details on setting up and verifying context capture.

Not all Oracle E-Business Suite applications have a configurable help menu to integrate context-sensitive content.

Oracle (Hyperion) Enterprise Performance Management

Application Version 11.1.2.1 11.1.1.3 11.1.1.2 11.1.1.1 Additional Information

*Context-sensitive deployment with Oracle Hyperion Performance Management is supported with SmartHelp add-in for browsers.

Oracle Transportation Management

6.1 6.0

Context-sensitive deployment with Oracle Transportation Management is supported with SmartHelp add-in for browsers.

PeopleSoft Enterprise

Application Version PeopleTools Version

9.1 Latest version verified: 8.51 9.0 Latest version verified: 8.50 8.9 Latest version verified: 8.49 8.8 Latest version verified: 8.46

Primavera

Application Version Versions Supported

(9)

Siebel CRM (On Premise)

Application Version Latest Releases Verified

8.2 8.2 8.1 8.1.1, 8.1.1, 8.1.1.2, 8.1.1.3 8.0 8.0.0.7, 8.0.0.8, 8.0.0.9, 8.0.0.10 7.8 7.8.2.12, 7.8.2.13, 7.8.2.14 7.7 7.7.2.10, 7.7.2.11, 7.7.2.12 Additional Information

Context-sensitive deployment with Siebel Analytics is supported with SmartHelp add-in for browsers.

Siebel high-interactivity modules require an ActiveX control for Help Integration deployment. For more information, see the In-Application Support Guide.

SAP Applications

SAP GUI for Windows and SAP GUI for HTML

Application Version Patches Supported

7.20 001, 002, 003

7.10 11, 12, 13, 14, 15, 16, 17, 18, 19 6.20 75, 76, 77, 78

The low-speed connection setting for SAP GUI for Windows must be turned off during recording and can be turned on during playback.

Minimum Support Package levels for SAP GUI for HTML are required. For external ITS 6.20, patch level 22. For integrated ITS 6.40, SP19 and kernel patch 124. For integrated ITS 7.10, SP10 and kernel patch 59.

SAP NetWeaver Portal

7.0 6.0

Oracle User Productivity Kit provides enhanced object recognition in the SAP NetWeaver Portal for a wide variety of user-interface technologies; some of this support includes HTML, Sun Java, SAP GUI for Windows, SAP GUI for HTML (WebGUI), Web Dynpro, HTMLB, BSP, and Accessibility-enabled Flash components.

For portal-embedded applications the context is captured to the page-level iView and, if available, the guided procedure step. When SAP GUI for HTML is embedded in the portal, SAP GUI context applies.

There are additional ―cross-domain scripting‖ requirements for context-sensitive deployment with the portal that are detailed in the In-Application Support Guide.

(10)

Microsoft Applications Microsoft Dynamics CRM

4.0 3.0

SmartHelp add-in for browsers is not supported with Microsoft Dynamics CRM version 3.0.

Technology Platform Support Browser-based HTML Applications

Internet Explorer 8.0 Internet Explorer 7.0 Internet Explorer 6.0 SP2

Enhanced support for enterprise applications (Oracle E-Business Suite, SAP applications, etc.) is dependent upon vendor validation of a particular browser version.

Microsoft Active Accessibility

Windows 7 Windows Vista Windows XP Office 2010 (32-bit) Office 2007 Office 2003 Office XP Additional Information

Many applications (including the list above) with support for Active Accessibility will benefit from enhanced object recognition during recording. Integrated context-sensitive help is not offered.

Active Accessibility enabled Flash/Flex applications and Browser embedded components benefit from enhanced object-recognition during recording.

SmartHelp Browser Button

Internet Explorer 8.0 Internet Explorer 7.0 Internet Explorer 6.0 Firefox 3.6 Firefox 3.5 Additional Information

(11)

SmartHelp setup for Firefox requires the .jar and .xpi MIME types configured on the web server.

SmartMatch Context Recording

Internet Explorer 8.0 Internet Explorer 7.0 Internet Explorer 6.0

SmartMatch context is available when recording content is performed using a SmartMatch Context supported browser.

For SmartMatch ranked results (context at content launch), see the section SmartHelp browser button for a list of supported browsers.

Sun Java Runtime

Sun Java Runtime Latest patch verified: 1.6.0_21, 22

Applications built with Java technology are supported for recording with object recognition; integrated context-sensitive help is not offered.

SWING and abstract windowing toolkit (AWT) component implementations for Sun Java are supported.

Contact Us

For more information about Oracle User Productivity Kit, please visit oracle.com or call +1.800.ORACLE1 to speak to an Oracle representative.
