We manufacture and distribute

a wide range of cabling solutions

for the communications, mining,

industrial, security, integration and

transport industries.

From simple bell wire to high end

Optical Fibre cable, copper jacks to

field installable optical connectors,

internal MDF’s to external IPX rated

enclosures, Madison has a solution to

get you connected.

Con

sis

ten

t

Re

lia

ble

Whatever your connectivity needs,

Madison

is your trusted

expert

.

At Madison, we connect our customers

to smarter technology, solutions,

outcomes, concepts and services across

our five business verticals.

We have all the technology you need in one place, so we can deliver the extensive range of off-the-shelf products and custom-designed solutions you need, on time.

With a strong focus on quality, service and flexibility, Madison offers a tailored solution to meet specific needs across cabling, networking, wireless, broadcast, audio visual and testing markets.

Madison’s Cabling & Connectivity unit is your leading partner for comprehensive cabling solutions.

We are uniquely positioned to offer a range of data and communications solutions from a diverse portfolio of trusted brands.

Our dedicated research and development team has decades of experience working on major communications and IT infrastructure projects.

We pride ourselves in our ability to provide expert advice and support across all our product lines and can assist in all aspects of pre and post-sales support.

With Madison Cabling & Connectivity, you are connected to world leading brands such as Garland, Belden, 3M, R&M and AFL Global - all working together to deliver a robust

connectivity solution which best meets the individual requirements of your application.

> Network cabling infrastructure

> Copper & Optical Fibre cables

> Connectors, adaptors & enclosures

> Racks & cable management

> Copper & Optical Fibre patching systems & FOBOTs

> Test equipment & calibration

> System warranties

> Green Star BEP approved PVC in Garland Pro Series Cables

Broadcast & AV Industrial IT&C Telco & Wireless Test & Measurement

4

MINING + INDUSTRIAL

COMMUNICATION

Process Control

Factory Automation

Device Monitoring

Telephone

Networking

> Connectors & Accessories

> Racks

Data

Smarter

Solutions

Madison Technologies provides end-to-end

solutions for an extensive industry portfolio,

making us a key supplier to Australia’s cabling

& connectivity market.

TRANSPORT

SECURITY + INTEGRATION

Surveillance

Signalling

> Traffic Light Control

> Rail Signalling

Revenue

Management

Electronic Signage

Monitoring

Alarm

>Manual Trigger Systems

Building Automation

Access Control

6

In the last decade, new technology has brought many changes to the communications industry, with Optical Fibre becoming a dominant medium for high bandwidth

connectivity systems.

Madison Technologies has the know-how to connect you with specialist Optical Fibre solutions and LAN copper cabling and connectivity products. We can provide total product design, manufacturing and distribution services for broadcast, telecommunications and communications products and systems.

We stock a variety of product solutions for in-building and inter-building applications.

Product Highlights

> LAN copper cables & connectivity

> Passive Optical LAN; cabling & active equipment

> Coaxial cables & accessories

> RS232/422/485

> Telephone; internal & external

> Optical Fibre cable & accessories

> Patch panels & rack systems

> Specialty cables

Communication

Madison Technologies is your premier supplier

to the communications industry.

Hamer Hall, VIC

As a theatre production and concert venue, Hamer Hall requires a state of the art cabling solution which provides high speed networking for all data and communications, audio visual, broadcast, and automation technology on the one network.

Madison Technologies provided an end to end fibre and Ethernet cabling

and connectivity package designed specifically to provide Hamer Hall with a comprehensive, and integrated cabling system that offered flexibility, interoperability and ease of maintenance over the long term.

This project was the first of its kind in Australia to use the R&M ISO Cat6A jack which enables the use of applications above 10 Gigabit Ethernet, resulting in a longer life for the cabling infrastructure.

Case Study

Products Supplied

>Fibre connectivity components

>Copper based Category 3 cables for voice

>LAN copper cables & connectivity

>Audio connectivity components

>Copper connectivity products

Mining +

Industrial

Madison can custom design and manufacture cables

to suit your exact requirements.

Madison Technologies offer a range of cables for all industrial applications and infrastructure.

Our cable solutions include a wide range to suit Process Control, Factory Automation and Instrumentation environments. We have a complete range of DataBus, CANBus, DeviceBus, Foundation FieldBus™ and ProfiBus® _hardware from the best systems manufacturers such as Garland and Belden Cables.

Product Highlights

>Instrumentation

>Steel Wire Armoured

>Profibus®

>CAN Bus

> Industrial Ethernet

> Optical Fibre cable

> Foundation Fieldbus™

> RS232/422/485

Diamantina

Power Station, QLD

The Diamantina Power Station Project (DPS) is a $570 million investment in Mount Isa by APA Group and AGL Energy Limited to secure the power supply needs of North West Queensland now and into the future. Madison Technologies supplied instrumentation cables for the various monitoring and metering equipment

associated with the effective running of a power station. Due to our position as a producer and distributor of Garland Cables, Madison was able to meet a very tight timline for supply. Now complete, DPS’s 302 MW of power generation facilities site will provide the region with reliable, on demand natural gas-fired electricity. DPS will provide 242 MW Combined Cycle Gas Turbine power generation and the adjacent Leichhardt Power Station will deliver 60 MW of Open Cycle Gas Turbine power generation.

Case Study

Products Supplied

> Overall screened Multi Paired Instrumentation cables

> Individual Multi Paired Instrumentation cables

> Profibus® _cables > Optical Fibre cables

8

Security +

Integration

Madison Technologies can connect you to specialist security application and integration cabling solutions for every system, from alarms to access control to audio visual and CCTV.

Our Garland security cables are designed for use with security systems, intercom, sound audio, addressable systems, monitoring and detection.

We stock a variety of core counts and wire gauges to suit your in-building and inter-building applications and have a complete range of composite and Banana Peel® cables that reduce installation times on security, CCTV and access control systems by eliminating the need to pull multiple cables.

Product Highlights

> Multicore security

> Coaxial cables

> Figure 8 cables

> LAN copper cables & connectivity

>Audio Visual & CCTV cables

>Optical Fibre cables

>Control cables

>Composite cables

Madison connects you to the latest cabling

and connectivity innovations for indoor and

outdoor applications.

Darwin Correctional Facility, NT

Recently Madison Technologies provided 200km of security cable to the Darwin Correctional facilities project.

The security cable on site operates to connect devices such as card readers, sliding doors, video cameras and mobile duress receivers.

Madison provided technical advice on the cable applications and ensured the supply of stock was to schedule so the deadlines could be met.

Case Study

Products Supplied

>200km security network cable

>Twin sheath Figure 8

>LAN cables & connectivity

>Coaxial cable

>Jelly Filled Cat6 cables

Madison Technologies’ transport solutions spans across an extensive range of traffic management, monitoring and rail signaling products.

Our cables are manufactured to the relevant State Government specifications and in accordance with Australian standards.

We continue to work with State Government traffic and rail authorities such as VicRoads, RMS and VRIOGS to expand our approvals and product offerings.

Product Highlights

>Multicore traffic

>Railway signaling cables

>Loop feeder & Loop detector

> Video monitoring cable

> Optical Fibre cable

> LAN copper cables & connectivity

Transport

Clem Jones

Tunnel, QLD

The 6.8 kilometre Clem Jones Tunnel (CLEM7) includes a range of safety features and systems designed to provide the safest driving environment possible.

The individually controlled electronic signage, cameras, traffic signals and messaging are operated by up to 40

technicians from the intelligence heart of this major infrastructure facility - the Tollway Control Centre. Madison Technologies helped implement a state of the art cabling system, enabling continuity of traffic signalling communication and other electronic messaging without interruption along the Optical Fibre cable network 23 times the length of the tunnel.

Case Study

Products Supplied

> Copper cables

> Optical Fibre cables

> R&M Security Level 2 Socket

> Associated connectivity, jointing and tooling

10

The Madison 20 Year Cabling System Warranty is designed to allow you to mix and match the very best features and benefits of multiple voice, data, and optical product brands and solutions.

The Warranty combines the performance and ease-of-installation strengths and benefits of a range of high quality products. The system supports the operation of the standards based applications and protocols you specify, over the appropriate category of end-to-end cabling performance – giving the customer ‘peace-of-mind’ that the whole solution is covered by a single 20 year warranty.

The System Warranty is provided by Madison Technologies Pty Ltd (ABN 56 010 669 379). For more information phone 1800 66 99 99.

Note: Expansion of the Madison Warranty to

incorporate other Garland Cable Solutions can be discussed on a case by case basis.

Learn more about the range of products and solutions at Madison by viewing our product guides and

catalogues online.

Visit the resource centre at www.madisontech.com.au

or phone us on 1800 66 99 99 for a hard copy.

Warranty

LAN Solutions Product Guide

Fibre, Data + Voice

www.madisontech.com.au

Fibre Optic Connectivity

Short Form Catalogue v1

www.madisontech.com.au

20 Year Cabling System Warranty

Voice Panel Patch Panel Active Switch Fobot

LAN Application

FIBRE

The range includes:

• External Fibre • Indoor Fibre Backbone • Fibre Trays (FOBOTS) • Accessories

VOICE

The range includes:

• Cable • Enclosures • Voice Panels • Disconnect Modules

Resources

DATA

The range includes:

• Category Cables • Patch Panels • RJ45 Outlets • Patch Leads

Achieve outstanding results and reduce the environmental impacts of PVC on your cabling projects with the complete range of Garland Pro Series copper cables.

Meeting the Vinyl Council of Australia’s Best Environmental Practice (BEP) Guidelines, Garland Pro Series cables can help you earn credits towards the Green Building Council of Australia (GBCA) Green Star Points.

Garland Cables has been a well-known and

respected brand in the Australian cable

industry, for over 40 years. The quality

range of industrial, data, security, and fibre

cables form the backbone of many critical

networks throughout Australia.

Build your

Green Star PVC Credits

with Garland Cables

> LAN & Data

> Security & Fire Control

> Coaxial

> Telephone

> Instrumentation & Control

> Audio Visual

> Power

> Optical Fibre
