Fakult ¨at II – Informatik, Wirtschafts- und Rechtswissenschaften Department f ¨ur Informatik
Coupled Model Transformations
for QoS Enabled
Component-Based Software Design
PhD thesis to gain the degree of ”Doktor der Ingenieurwissenschaften”
by
Dipl.-Wirtsch.-Inform. Steffen Becker
Referees:
