Study on Apriori Algorithm and its Application in Grocery Store

(1)

Study on Apriori Algorithm and its Application in

Grocery Store

Pragya Agarwal

Department of CSE ASET,Amity University Sector-125,Noida,UP,India

Madan Lal Yadav

Nupur Anand

ABSTRACT

Among the many mining algorithms of associations rules, Apriori Algorithm is a classical algorithm that has caused the most discussions; it can effectively carry out the mining association rules. With large database, the process of mining association rules is time consuming. The efficiency becomes crucial factor. Moreover, Apriori algorithm is improved by reducing the number of scanning data base. The proposed algorithm reduces the storage room, improves the competency of performance with negligible error of the algorithm. Finally, the improved Apriori algorithm can solve the problem of traditional Apriori algorithm. After analyzing the Apriori algorithm, this algorithm is incapable due to it scans the database several times. Based on the planning of getting to database once, a new recoverd algorithm formed on the Apriori is put forward in this paper. Experiments show that it can mostly adds computation competency, i.e. minimize the calculating time and space. This algorithm has been broadly used for Grocery rooms in customer consumer knowledge mining.

1. INTRODUCTION

Data Mining is the core process of KNOWLEDGE DISCOVERY IN DATABASE [28]. It is the process of extraction of useful patterns from the large database[28]. To analyze the large amounts of collected information, the area of Knowledge Discovery in Databases (KDD) provides techniques which extract interesting patterns in a reasonable amount of time. Therefore, KDD employs methods at the cross point of machine knowledge, statistics and database technology. Data mining is the application of competent algorithms to detect the desired patterns contained within the given data.

Data mining has recently attracted considerable attention from database practitioners and researchers because it has been applied to many fields such as market planning, financial forecasts and decision support. Many algorithms have been proposed to obtain useful and invaluable information from huge databases. One of the most important algorithms is mining association rules, which was first introduced. Association rule mining has many important applications in our life. An association rule is of the form X => Y. And each rule has two measurements:

support and confidence. The association rule mining difficulty is to get rules that satisfy user-specified minimum support and minimum confidence.

Among the many mining algorithms of associations rules, Apriori Algorithm is a classical algorithm that has caused the most discussions; it can effectively carry out the mining association rules. With large database, the process of mining association rules is time consuming. The efficiency becomes crucial factor. Moreover, Apriori algorithm is improved by reducing the number of scanning data base. The algorithm reduces the storage room, improves the competency of performance and correctness of the algorithm. Data mining is the extraction of hidden descriptive or predictive information from large databases. It has been described as “the task of discovering interesting patterns from large amount of data where the data can be stored in databases, data warehouses or other information store houses.

1.1 Association

rule

and

Apriori

algorithm

An “association rule” is a rule like "If a customer buys pizza base and butter, he/she often buys ketchup too." It expresses an association between (sets of) items, which may be products of a market or a mail-order department, special equipment options of a cabe, optional services offered by telecommunication factories etc.

An association rule states that if we pick a customer at random and find out that he/she selected some items (bought some products, chose some options etc.), we can be assured, indicate the quantity by a percentage, that he/she also selected some other items (bought some other products, chose some other options etc.). Of course, we do not want just any association rules, we want "good" rules, rules that are "expressive" and "reliable". The standard measures to assess association rules are the “support” and the “confidence” of a rule, both of which are computed from the help of some item sets.

(2)

repetitive approach called as a breadth-first search (level-wise search) through the search room, where k-things are used to explore (k+1)-things.

1.2 Need of improved Apriori algorithm

There are some drawbacks or limitations of classical Apriori algorithm.

Limitations of Apriori algorithm-

• Needs many repititions of the data.

• Uses a same minimum support threshold.

• Difficulties to get rarely occuring happenings.

• With large database, the procedure of mining association rules is time taking.

• The competency becomes crucial factor.

2. METHODOLOGY

Data mining is the core process of KNOWLEDGE DISCOVERY IN DATABASE [28]. It is the process of extraction of useful patterns from the large database [28]. To analyze the large amount of collected information, the area of Knowledge Discovery in Database (KDD) provides techniques which extract interesting patterns in a reasonable amount of time [28]. Data mining is the application of efficient algorithms to detect the desired patterns contained within the given data. Data mining is the extraction of hidden descriptive or predictive information from large databases [27].

2.1 Association rule mining

Association rules mining are one of the major techniques of data mining. The purpose of association analysis is to figure out the hidden association and some useful rules of data base, and uses these rules to speculate and judge the unknown matter from the already known information [25]. Association rule mining has many important applications in our life.

2.1.1 Association rule

 An Association rule is one of the form X=>Y. And each rule has two basic needs:

Support and confidence.

 Things that occur often together can be associated to each other.

 These together occurring things form a Frequent itemset.

 Conclusions based on the frequent itemsets make

Association rules.

Apriori algorithm is a fundamental algorithm mining association rule [19]. It contains two processes:

• Detect all frequent itemsets by scanning DB.

• Form strong association rules in the frequent itemsets. Process one needs to scan DB several times, which consumes a lot of time and space. As a result, what needs to be improved is the mining competency of frequent group of things in DB [19].

Apriori Algorithim is an significant algorithm for mining frequent itemsets for boolean association rules.

 Apriori algorithm is formed by AGRAWAL and

SRIKANT in 1994.

 It is the most fundamental and important algorithm for mining frequent itemsets.

 Apriori is used to detect all frequent itemsets in a provided database DB.

 The keynote of Apriori algorithm is to form multiple passes over the database.

 It employs an repetitive approach called as a

breadth-first search (level-wise search).

2.1.3 Key concepts

• Frequent itemsets: The itemsets which has minimum help (denoted by Li for ith-itemsets).

• Apriori Property: Any subgroup of frequent things must be frequent.

• Join Operation: To detect Lk, a group of candidate k-group of things is developed by adding Lk-1with itself.

3. HOW APRIORI WORKS?

Find all frequent itemsets.

o Get frequent things:

 Things whose occurrence in database is more than or equal to the minimum help threshold.

o Get frequent itemsets:

 Develop candidates from frequent things.  Prune the results to detect the frequent

itemsets.

Develop strong association rules from frequent itemsets.

(3)

High level design

Fig 1: High Level Design of Apriori Algorithm

Related products are placed together in such a manner that customers can logically find items he/she might buy which increases the customer satisfaction and the profit. Customers are segmented and association rules are separately generated to satisfy their specific needs in a cost effective manner using some special promotions for the common groups. From the results it is shown that the market basket analysis using K-Apriori algorithm for Grocery Stores improves its overall revenue.

[image:3.612.87.284.74.305.2]

4. TAKE AN EXAMPLE

Table 1. consisting of Transaction Id and List of items

TID

List of the items

T100

_1,2,5

T100

_2,4

T100

2,3

T100

1,2,4

T100

1,3

T100

_2,3

T100

_1,3

T100

_1,2,3,5

T100

1,2,3

Step 1: Generating 1-itemgroup Frequent Pattern

Item set Sup. Count

1 6

2 7

3 6

4 2

5 2

Scan D Candidate C1

At every count

Item set Sup. Count

1 6

2 7

3 6

4 2

5 2

Comparison of Candidate support count with minimum support count L1

Fig 2: Generating 1-itemgroup Frequent Pattern

Consider a database, D , consisting of 9 transactions. •Suppose min. support count required is 2 (i.e. min_sup = 2/9 = 22 % )

•Assume minimum confidence required is 70%.

•We have to first find out the frequent itemgroup using Apriori algorithm.

•Then, Association rules will be produced using minimum support & minimum confidence.

The set of frequent 1-itemgroups, L1, consists of the candidate 1-itemsets satisfying minimum support.

In the first loop of the algorithm, each item is a member of the set of candidate.

Start

Get frequent things

Produce Candidate item groups

Get frequent item groups

Produce set=null

[image:3.612.318.519.107.358.2]

(4)

Scan D for count of each candidate, we get C2

Item set Sup. Count

[1,2] 4

[1,3] 4

[1,4] 1

[1,5] 2

[2,3] 4

[2,4] 2

[2,5] 2

[3,4] 0

[3,5] 1

[4,5] 0

C2

Item set Sup. Count

[1,2] 4

[1,3] 4

[1,5] 2

[2,3] 4

[2,4] 2

[2,5] 2

[image:4.612.116.258.112.529.2]

•To discover the set of frequent 2-itemgroups, L2, the algorithm uses L1 Join L1to generate a candidate set of 2-itemsets, C2.

•Next work is,transactions in D are scanned and the support count for each candidate itemset in C2is accumulated (as shown in the middle table).

•The set of frequent 2-itemgroups, L2, is then determined,

•We haven’t used Apriori Property till now.

Item set

[1,2,3]

[1,2,5]

Item set Sup. Count

[1,2,3] 2

[1,2,5] 2

Scan D for count of each candidate, we get C3

Item set Sup. Count

[1,2,3] 2

[1,2,5] 2

[image:4.612.354.516.131.569.2]

•The generation of the set of candidate 3-itemgroups, C3, involves use of the Apriori Property.

•In order to get C3, we compute L2JoinL2.

(5)

•Now, Join step is complete and Prune step will be used to reduce the size of C3. Prune step is used to avoid heavy computation due to large Ck.

Based on the Apriori property that all subsets of a frequent item group must also be frequent so that we can determine that four latter candidates cannot possibly be frequent. How ?

•For example , lets take [1, 2, 3].The 2-item subsets of it are [1, 2], [1, 3] & [2, 3]. Since all 2-item subsets of [1, 2, 3] are members of L2, We will keep [1, 2, 3] in C3.

•Lets take another example of [2, 3, 5]which shows how the pruning is performed. The 2-item subsets are [2, 3], [2, 5] & [3,5].

•BUT, [3, 5] is not a member of L2and hence it is not frequent violating Apriori Property. Thus we will have to remove [2, 3, 5] from C3.

•Therefore, C3= [[1, 2, 3], [1, 2, 5]] after checking for all members of result of Join operation for Pruning.

•Finally the transactions in D are scanned in order to determine L3, consisting of those candidates 3-itemsets in C3 having minimum support.

•The algorithm uses L3 JoinL3to generate a candidate set of 4-itemsets, C4. Although the join results in [[1, 2, 3, 5]], this itemset is pruned since its subset [[2, 3, 5]]is not frequent.

•Thus, C4= φ, and algorithm terminates and we have found all of the frequent things. This completes our Apriori Algorithm.

5. RESULTS

We can see the results of these transactions by the following screenshots.

Fig 5: shows the Home page.

[image:5.612.110.564.417.657.2]

Fig 6: Open the file of stored transaction database. Fig 7: Shows the desired output.

(6)

[image:6.612.72.566.69.345.2] [image:6.612.76.573.384.676.2]

(7)

6. CONCLUSION

The conclusion of the project is to overcome the disadvantages of traditional Apriori algorithm and efficiently mine association rules without generating candidate itemsets. This project has studied the classic association rules mining algorithm and discussed shortcomings of the Apriori algorithm. It takes the grocery store’s consumer knowledge mining for example to compare.

In this project we presented the use of an ARM (Association rule mining) driven application is to manage retail businesses that provide retailers with reports regarding prediction of product sales trends and customer behavior. Our goal of project is to find a new scheme for finding the rules out of the transactional dataset which outperforms in terms of running time, number of database scan, memory consumption and the interestingness of the rules over the classical APRIORI Algorithm.

We have proposed mining algorithm for incremental generation of large itemsets. Frequent itemsets discovered depends on value of parameters like support and number of transactions read at a time. Thus execution time of the algorithm depends on transactional datagroups, minimum support value.

7. FUTURE WORK

To overcome these limitations of traditional Apriori algorithm, a frequent pattern-tree (FP-Growth) structure is proposed. Association Rules form an very applied data mining approach. Association Rules are obtained from frequent itemsets. The Apriori algorithm is an competent algorithm for finding all frequent itemsets. A great advantage of FP-tree is that overlapping itemsets share the same prefix path. So the information of the data set is mostly compressed. It only needs to scan the data set twice and no candidate itemsets are required.

7.1 Obtaining frequent patterns without candidate generation

Shorten a large database into a compact, Frequent-Pattern tree (FP-tree)structure.

–Highly compressed, but complete for frequent pattern mining.

–avoid costly database scans.

Develop a competent, FP-tree-based frequent pattern mining method.

–A divide-and-conquer methodology: distill mining tasks into smaller ones.

–Evade candidate generation: sub-database test only!

7.2 Advantages of FP-growth algorithm

The main advantages of FP-Growth algorithm is, • Uses compact data structure

• Eliminates repeated database scan

FP-growth is faster than other association mining algorithms. The algorithm reduces the total number of candidate item sets by producing a compressed version of the database in terms of an FP-tree. The FP-tree stores relevant information and allows for the efficient discovery of frequent item sets.
