LTE Rrc Connection Attach Procedure

(1)

RRC CONNECTION REQUEST TILL ESTABLISHMENT OF DEFAULT RADIO BEARER

2012 Nov 1 05:20:05.339 [00] 0xB0C0 LTE RRC OTA Packet -- UL_CCCH Pkt Version = 2

RRC Release Number.Major.minor = 9.5.0 Radio Bearer ID = 0, Physical Cell ID = 321 Freq = 39075

SysFrameNum = N/A, SubFrameNum = 0

PDU Number = UL_CCCH Message, Msg Length = 6 Interpreted PDU: value UL-CCCH-Message ::= { message c1 : rrcConnectionRequest : { criticalExtensions rrcConnectionRequest-r8 : { ue-Identity randomValue : '11010101 10101001 01000110 10011111 00000001'B, establishmentCause mo-Signalling, spare '0'B } } } Length: 31 Header: 1F 00 C0 B0 00 34 AF 30 F4 ED C0 00 Payload: 02 09 50 00 41 01 A3 98 00 00 07 06 00 5D 5A 94 69 F0 16

2012 Nov 1 05:20:05.347 [00] 0xB167 LTE Random Access Request (MSG1) Report Version = 5

Preamble Sequence = 11 Physical Root Index = 242 Cyclic Shift = 352 PRACH Tx Power = 18 dBm Beta PRACH = 242 PRACH Frequency Offset = 8 Preamble Format = 0 Duplex Mode = TDD f_ra = 0

t_0_ra = Resource reoccurring in all radio frames t_1_ra = RA resources in first half frame

t_2_ra = 0 Density Per 10 ms = 1

(2)

PRACH Timing SFN = 364

PRACH Timing Sub-fn = 2

PRACH Window Start SFN = 364 RACH Window Start Sub-fn = 5 PRACH Window End SFN = 365

PRACH Window End Sub-fn = 5 RA RNTI = 3

PRACH Actual Tx Power = 18

Length: 40 Header: 28 00 67 B1 00 94 B5 30 F4 ED C0 00 Payload: 05 14 44 00 8B 3C 60 01 12 F2 40 80 00 B9 6C 21 6C 51 6D 51 03 00 0F 00 12 00 00 00 2012 Nov 1 05:20:05.359 [00] 0xB168 LTE Random Access Response (MSG2) Report Version = 1

SFN = 364

Sub-fn = 9

Timing Advance = 3

Timing Advance Included = Included RACH Procedure Type = Contention Based RACH Procedure Mode = Initial Access RNTI Type = TEMP_C_RNTI RNTI Value = 9892

Length: 24 Header: 18 00 68 B1 00 84 BE 30 F4 ED C0 00 Payload: 01 00 BB EB 6C 91 03 00 43 A4 26 00 2012 Nov 1 05:20:05.359 [00] 0xB169 LTE UE Identification Message (MSG3) Report Version = 1

TPC = 0

MCS = 2

RIV = 286

CQI = Disabled UL Delay = Don't Delay Hopping Flag = Disabled SFN = 365

Sub-fn = 7

Starting Resource Block = 86 Num Resource Blocks = 3

Transport Block Size = 2

Modulation Type = QPSK Redundancy Version Index = 0 HARQ ID = 2

Length: 24

Header: 18 00 69 B1 00 B0 BE 30 F4 ED C0 00 Payload: 01 F4 45 00 10 8F D0 56 67 1D 88 10

(3)

2012 Nov 1 05:20:05.379 [00] 0xB16A LTE Contention Resolution Message (MSG4) Report Version = 1

SFN = 366 Sub-fn = 9 Contention Result = Pass UL ACK Timing SFN = 367 UL ACK Timing Sub-fn = 3

Length: 20

Header: 14 00 6A B1 00 90 CE 30 F4 ED C0 00 Payload: 01 B4 06 00 6E E5 B7 06

2012 Nov 1 05:20:05.379 [00] 0xB0C0 LTE RRC OTA Packet -- DL_CCCH Pkt Version = 2

SysFrameNum = 366, SubFrameNum = 9

PDU Number = DL_CCCH Message, Msg Length = 34 Interpreted PDU: value DL-CCCH-Message ::= { message c1 : rrcConnectionSetup : { rrc-TransactionIdentifier 3, criticalExtensions c1 : rrcConnectionSetup-r8 : { radioResourceConfigDedicated { srb-ToAddModList { { srb-Identity 1, rlc-Config explicitValue : am : { ul-AM-RLC { t-PollRetransmit ms45, pollPDU p16, pollByte kB125, maxRetxThreshold t32 }, dl-AM-RLC { t-Reordering ms45, t-StatusProhibit ms30 }

(4)

}, logicalChannelConfig explicitValue : { ul-SpecificParameters { priority 1, prioritisedBitRate infinity, bucketSizeDuration ms500, logicalChannelGroup 0 } } } }, mac-MainConfig explicitValue : { ul-SCH-Config { maxHARQ-Tx n4, periodicBSR-Timer sf5, retxBSR-Timer sf320, ttiBundling FALSE },

drx-Config release : NULL,

timeAlignmentTimerDedicated infinity, phr-Config setup : { periodicPHR-Timer sf10, prohibitPHR-Timer sf0, dl-PathlossChange dB1 } }, physicalConfigDedicated { pdsch-ConfigDedicated { p-a dB0 }, pucch-ConfigDedicated {

ackNackRepetition release : NULL, tdd-AckNackFeedbackMode bundling }, pusch-ConfigDedicated { betaOffset-ACK-Index 8, betaOffset-RI-Index 10, betaOffset-CQI-Index 8 }, uplinkPowerControlDedicated { p0-UE-PUSCH 1, deltaMCS-Enabled en0, accumulationEnabled FALSE, p0-UE-PUCCH 1, pSRS-Offset 3 }, tpc-PDCCH-ConfigPUCCH setup :

(5)

{

tpc-RNTI '00111010 01111011'B, tpc-Index indexOfFormat3 : 11 },

tpc-PDCCH-ConfigPUSCH release : NULL, cqi-ReportConfig { cqi-ReportModeAperiodic rm20, nomPDSCH-RS-EPRE-Offset 0, cqi-ReportPeriodic setup : { cqi-PUCCH-ResourceIndex 0, cqi-pmi-ConfigIndex 84,

cqi-FormatIndicatorPeriodic widebandCQI : NULL, ri-ConfigIndex 40, simultaneousAckNackAndCQI TRUE } }, soundingRS-UL-ConfigDedicated setup : { srs-Bandwidth bw0, srs-HoppingBandwidth hbw0, freqDomainPosition 0, duration TRUE, srs-ConfigIndex 30, transmissionComb 0, cyclicShift cs0 }, antennaInfo explicitValue : { transmissionMode tm2,

ue-TransmitAntennaSelection release : NULL }, schedulingRequestConfig setup : { sr-PUCCH-ResourceIndex 0, sr-ConfigIndex 22, dsr-TransMax n32 } } } } } } Length: 59 Header: 3B 00 C0 B0 00 98 CE 30 F4 ED C0 00 Payload: 02 09 50 00 41 01 A3 98 E9 16 05 22 00 78 12 98 08 49 D2 31 83 C0 F9 80 3C 01 FF C9 15 09 24 E7 4F 6A 64 E0 00 54 05 18 02 0F 00 50 00 2C C0

(6)

2012 Nov 1 05:20:05.382 [00] 0xB0C0 LTE RRC OTA Packet -- UL_DCCH Pkt Version = 2

PDU Number = UL_DCCH Message, Msg Length = 71 Interpreted PDU: value UL-DCCH-Message ::= { message c1 : rrcConnectionSetupComplete : { rrc-TransactionIdentifier 3, criticalExtensions c1 : rrcConnectionSetupComplete-r8 : { selectedPLMN-Identity 1, registeredMME { mmegi '10000000 00000000'B, mmec '00001010'B }, dedicatedInfoNAS '1796B7A226070741510BF604F41380000AE001060902E0E000200203D011271A808021100100 0010810600000000830600000000000D00000A005204F4130008E0'H } } } Length: 96 Header: 60 00 C0 B0 00 24 D1 30 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 08 47 00 26 20 80 00 0A 41 17 96 B7 A2 26 07 07 41 51 0B F6 04 F4 13 80 00 0A E0 01 06 09 02 E0 E0 00 20 02 03 D0 11 27 1A 80 80 21 10 01 00 00 10 81 06 00 00 00 00 83 06 00 00 00 00 00 0D 00 00 0A 00 52 04 F4 13 00 08 E0

2012 Nov 1 05:20:05.415 [00] 0xB0C0 LTE RRC OTA Packet -- DL_DCCH Pkt Version = 2

RRC Release Number.Major.minor = 9.5.0 Radio Bearer ID = 1, Physical Cell ID = 321

(7)

Freq = 39075

PDU Number = DL_DCCH Message, Msg Length = 5 Interpreted PDU: value DL-DCCH-Message ::= { message c1 : ueCapabilityEnquiry : { rrc-TransactionIdentifier 0, criticalExtensions c1 : ueCapabilityEnquiry-r8 : { ue-CapabilityRequest { eutra, geran-cs, geran-ps, utra, cdma2000-1XRTT } } } } Length: 30 Header: 1E 00 C0 B0 00 8C EB 30 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 06 05 00 38 10 08 C5 00

PDU Number = UL_DCCH Message, Msg Length = 18 Interpreted PDU: value UL-DCCH-Message ::= { message c1 : ueCapabilityInformation : { rrc-TransactionIdentifier 0, criticalExtensions c1 : ueCapabilityInformation-r8 : { ue-CapabilityRAT-ContainerList {

(8)

{ rat-Type eutra, ueCapabilityRAT-Container '81380001953810381D1814600000'H } } } } } =================================

Further decode UE EUTRA capability PDU: ================================= value UE-EUTRA-Capability ::= { accessStratumRelease rel8, ue-Category 3, pdcp-Parameters { supportedROHC-Profiles { profile0x0001 TRUE, profile0x0002 TRUE, profile0x0003 FALSE, profile0x0004 FALSE, profile0x0006 FALSE, profile0x0101 FALSE, profile0x0102 FALSE, profile0x0103 FALSE, profile0x0104 FALSE }, maxNumberROHC-ContextSessions cs2 }, phyLayerParameters { ue-TxAntennaSelectionSupported FALSE, ue-SpecificRefSigsSupported FALSE }, rf-Parameters { supportedBandListEUTRA { { bandEUTRA 38, halfDuplex FALSE }, { bandEUTRA 40, halfDuplex FALSE } } }, measParameters { bandListEUTRA

(9)

{ { interFreqBandList { { interFreqNeedForGaps TRUE }, { interFreqNeedForGaps TRUE } } }, { interFreqBandList { { interFreqNeedForGaps TRUE }, { interFreqNeedForGaps TRUE } } } } }, featureGroupIndicators '01000110 00000101 00011000 00000000'B, interRAT-Parameters { } } Length: 43 Header: 2B 00 C0 B0 00 28 EC 30 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 08 12 00 38 01 00 E8 13 80 00 19 53 81 03 81 D1 81 46 00 00 00

PDU Number = DL_DCCH Message, Msg Length = 3 Interpreted PDU:

value DL-DCCH-Message ::= {

message c1 : securityModeCommand : {

(10)

rrc-TransactionIdentifier 1, criticalExtensions c1 : securityModeCommand-r8 : { securityConfigSMC { securityAlgorithmConfig { cipheringAlgorithm eea2, integrityProtAlgorithm eia2 } } } } } Length: 28 Header: 1C 00 C0 B0 00 B8 3E 31 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 06 03 00 32 02 20

PDU Number = UL_DCCH Message, Msg Length = 2 Interpreted PDU: value UL-DCCH-Message ::= { message c1 : securityModeComplete : { rrc-TransactionIdentifier 1, criticalExtensions securityModeComplete-r8 : { } } } Length: 27 Header: 1B 00 C0 B0 00 58 40 31 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 08 02 00 2A 00

(11)

PDU Number = DL_DCCH Message, Msg Length = 243 Interpreted PDU: value DL-DCCH-Message ::= { message c1 : rrcConnectionReconfiguration : { rrc-TransactionIdentifier 2, criticalExtensions c1 : rrcConnectionReconfiguration-r8 : { measConfig { measObjectToAddModList { { measObjectId 1, measObject measObjectEUTRA : { carrierFreq 39075, allowedMeasBandwidth mbw6, presenceAntennaPort1 FALSE, neighCellConfig '01'B, cellsToAddModList { { cellIndex 1, physCellId 322, cellIndividualOffset dB0 }, { cellIndex 2, physCellId 323, cellIndividualOffset dB0 }, { cellIndex 3, physCellId 92, cellIndividualOffset dB0 }, { cellIndex 4, physCellId 90, cellIndividualOffset dB0

(12)

}, { cellIndex 5, physCellId 91, cellIndividualOffset dB0 }, { cellIndex 6, physCellId 329, cellIndividualOffset dB0 }, { cellIndex 7, physCellId 328, cellIndividualOffset dB0 }, { cellIndex 8, physCellId 327, cellIndividualOffset dB0 }, { cellIndex 9, physCellId 268, cellIndividualOffset dB0 }, { cellIndex 10, physCellId 267, cellIndividualOffset dB0 }, { cellIndex 11, physCellId 269, cellIndividualOffset dB0 }, { cellIndex 12, physCellId 138, cellIndividualOffset dB0 }, { cellIndex 13, physCellId 192, cellIndividualOffset dB0 }, { cellIndex 14, physCellId 169, cellIndividualOffset dB0 }, { cellIndex 15, physCellId 107, cellIndividualOffset dB0 }, {

(13)

cellIndex 16, physCellId 106, cellIndividualOffset dB0 }, { cellIndex 17, physCellId 145, cellIndividualOffset dB0 }, { cellIndex 18, physCellId 296, cellIndividualOffset dB0 } } } } }, reportConfigToAddModList { { reportConfigId 10, reportConfig reportConfigEUTRA : { triggerType event : { eventId eventA3 : { a3-Offset 6, reportOnLeave FALSE }, hysteresis 0, timeToTrigger ms256 }, triggerQuantity rsrp, reportQuantity both, maxReportCells 3, reportInterval ms1024, reportAmount r1 } } }, measIdToAddModList { { measId 1, measObjectId 1, reportConfigId 10 } }, quantityConfig { quantityConfigEUTRA { } }, s-Measure 0,

(14)

speedStatePars setup : { mobilityStateParameters { t-Evaluation s60, t-HystNormal s60, n-CellChangeMedium 4, n-CellChangeHigh 8 }, timeToTrigger-SF { sf-Medium lDot0, sf-High lDot0 } } }, dedicatedInfoNASList { '270418EDDC0707420149064004F4130008005C5203C10509FFFFFFFF220A61697274656C6770 727303636F6D066D6E63303331066D636334303404677072730501756325DB5E04FEFE624E272 2808021100300001081067AA0EDC98306CA38E607000D047AA0EDC9000D04CA38E607500BF604 F41380000AE001063B172C59494A0604F40304F454'H }, radioResourceConfigDedicated { srb-ToAddModList { { srb-Identity 2, rlc-Config explicitValue : am : { ul-AM-RLC { t-PollRetransmit ms45, pollPDU p16, pollByte kB125, maxRetxThreshold t32 }, dl-AM-RLC { t-Reordering ms45, t-StatusProhibit ms30 } }, logicalChannelConfig explicitValue : { ul-SpecificParameters { priority 3, prioritisedBitRate infinity, bucketSizeDuration ms500, logicalChannelGroup 0 } } } },

(15)

drb-ToAddModList { { eps-BearerIdentity 5, drb-Identity 3, pdcp-Config { discardTimer ms1500, rlc-UM { pdcp-SN-Size len12bits },

headerCompression notUsed : NULL }, rlc-Config um-Bi-Directional : { ul-UM-RLC { sn-FieldLength size10 }, dl-UM-RLC { sn-FieldLength size10, t-Reordering ms45 } }, logicalChannelIdentity 3, logicalChannelConfig { ul-SpecificParameters { priority 11, prioritisedBitRate kBps0, bucketSizeDuration ms500, logicalChannelGroup 3 } } } }, mac-MainConfig explicitValue : { ul-SCH-Config { maxHARQ-Tx n4, periodicBSR-Timer sf5, retxBSR-Timer sf320, ttiBundling FALSE },

drx-Config release : NULL,

timeAlignmentTimerDedicated infinity, phr-Config setup : { periodicPHR-Timer sf1000, prohibitPHR-Timer sf10, dl-PathlossChange dB3 } },

(16)

sps-Config {

sps-ConfigDL release : NULL, sps-ConfigUL release : NULL }, physicalConfigDedicated { pdsch-ConfigDedicated { p-a dB0 }, pucch-ConfigDedicated {

ackNackRepetition release : NULL, tdd-AckNackFeedbackMode bundling }, pusch-ConfigDedicated { betaOffset-ACK-Index 8, betaOffset-RI-Index 10, betaOffset-CQI-Index 8 }, uplinkPowerControlDedicated { p0-UE-PUSCH 1, deltaMCS-Enabled en0, accumulationEnabled FALSE, p0-UE-PUCCH 1, pSRS-Offset 3 }, tpc-PDCCH-ConfigPUCCH setup : { tpc-RNTI '00111010 01111011'B, tpc-Index indexOfFormat3 : 11 },

tpc-PDCCH-ConfigPUSCH release : NULL, cqi-ReportConfig { nomPDSCH-RS-EPRE-Offset 0, cqi-ReportPeriodic setup : { cqi-PUCCH-ResourceIndex 0, cqi-pmi-ConfigIndex 84,

cqi-FormatIndicatorPeriodic widebandCQI : NULL, ri-ConfigIndex 40, simultaneousAckNackAndCQI TRUE } }, soundingRS-UL-ConfigDedicated setup : { srs-Bandwidth bw0, srs-HoppingBandwidth hbw0, freqDomainPosition 0, duration TRUE, srs-ConfigIndex 30, transmissionComb 0, cyclicShift cs0

(17)

},

antennaInfo explicitValue : {

transmissionMode tm3,

codebookSubsetRestriction n2TxAntenna-tm3 : '11'B, ue-TransmitAntennaSelection release : NULL

}, schedulingRequestConfig setup : { sr-PUCCH-ResourceIndex 0, sr-ConfigIndex 22, dsr-TransMax n32 } } } } } } Length: 268 Header: 0C 01 C0 B0 00 38 43 31 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 06 F3 00 24 16 15 A8 00 04 4C 51 83 10 50 9E 1A 1B C4 5C 78 CB 4F 21 6D E5 A4 BC D4 87 9E 8E F4 43 1E 98 5B D5 0D 7A D1 4F 63 01 ED 54 BD C6 B7 BC D4 F8 24 5F 19 43 C0 90 52 00 EA 40 00 01 28 00 49 37 F0 80 88 27 04 18 ED DC 07 07 42 01 49 06 40 04 F4 13 00 08 00 5C 52 03 C1 05 09 FF FF FF FF 22 0A 61 69 72 74 65 6C 67 70 72 73 03 63 6F 6D 06 6D 6E 63 30 33 31 06 6D 63 63 34 30 34 04 67 70 72 73 05 01 75 63 25 DB 5E 04 FE FE 62 4E 27 22 80 80 21 10 03 00 00 10 81 06 7A A0 ED C9 83 06 CA 38 E6 07 00 0D 04 7A A0 ED C9 00 0D 04 CA 38 E6 07 50 0B F6 04 F4 13 80 00 0A E0 01 06 3B 17 2C 59 49 4A 06 04 F4 03 04 F4 54 6E 70 21 27 48 C6 4F 00 7D 44 BA 3A 43 A0 99 F3 00 7E 2B 1F FC 91 50 92 4E 74 F6 A2 70 00 2A 02 8C 01 07 81 43 40 00 B3

(18)

Radio Bearer ID = 1, Physical Cell ID = 321 Freq = 39075

PDU Number = UL_DCCH Message, Msg Length = 2 Interpreted PDU: value UL-DCCH-Message ::= { message c1 : rrcConnectionReconfigurationComplete : { rrc-TransactionIdentifier 2, criticalExtensions rrcConnectionReconfigurationComplete-r8 : { } } } Length: 27 Header: 1B 00 C0 B0 00 B8 46 31 F4 ED C0 00 Payload: 02 09 50 01 41 01 A3 98 00 00 08 02 00 14 00
