TowerJazz High Performance SiGe BiCMOS processes

(1)

TowerJazz High Performance

SiGe BiCMOS processes

(2)

(3)

Comprehensive Technology Portfolio

Mixed-Signal Digital CMOS 0.35 µm 0.50 µm BiCMOS, SiGe Power/BCD BCD

RFCMOS RFCMOS and SOI CMOS

BCD

RFCMOS and SOI CMOS

Power/BCD

0.13µm

SiGe SiGe SiGe

0.25 µm 0.18/0.16/0.152 µm 0.13 µm Mixed-Signal Digital CMOS Mixed-Signal Digital CMOS Mixed-Signal Digital CMOS Mixed-Signal Digital CMOS eNVM Image Sensor

(X-Ray & Visible)

Image Sensor

(X-Ray & Visible)

eNVM Image Sensor

(X-Ray & Visible)

RFCMOS and SOI CMOS

(4)

RF CMOS and SiGe BiCMOS

 Cell Phone, WiFi TxRx

 Basestation, Specialty Wireless

 TV, Satellite, STB Tuners

High Performance SiGe

 Optical Fiber Networks

 Automotive Radar

 60 GHz WiFi, 24GHz Backhaul

 Light Peak and Thunderbolt

 GPS LNA

SOI Switch and SiGe Power Amplifiers

 Power Amplifiers

 Antenna Switch

 PA Controllers

Complementary BiCMOS

 Line Drivers DSL, HomePlug, ATE

 HDD PreAmp

 DAC, ADC

RF and HPA Applications and Technology

Best-in-class SiGe, RF CMOS, RF models and Design Enablement

RF and Tuners

_{Front-End Modules}

(5)

RF CMOS Controller Platform

 5V, 0.18um optimized CMOS

 Up to 50% die size shrink vs. 0.25um

 1.8V Logic, Bipolar, LDMOS options

SiGe PA, through-silicon-via (TSV), IPD

 SiGe PA cells for WiFi and Cellular

 TSV for low-inductance ground

 1.8/3.3/5V CMOS, high res options

 IPD (5um dual-Cu in development)

Platform for integration of FEM

 Thin-Film SOI (best in class Ron-Coff)

 Thick-Film SOI for ease of integration

 5V control, LNA, PA/Driver options

Models, design tools and IP

 Example: PA Design Library (PADL)

 Example: 4T, 6T, 9T SOI Switch IP

 Analog / RF Design Services

Front-End Module Technology

Best-in-class SiGe, RF CMOS, RF models and Design Enablement

Controller

_{SOI Switch}

(6)

Schematic of Key Features in SiGe BiCMOS platform

 The SiGe HBJTs are embedded into complimentary

BiCMOS platforms offering high performance RF , analog and digital performances.

(7)

SiGe HBJT device structure

 The high-performance bipolar transistors are built “vertically”

meaning that the n-p-n structure is created perpendicularly from the top of the wafer down.

(8)

TowerJazz High Speed SiGe Processes

SBC18HA SBC18H2 SBC18H3 SBC13HA SBC13H3

Status Prod. Prod. Proto. Proto. Devel. CMOS Voltages 1.8/3.3V 1.8/3.3V 1.8/3.3V 1.2/3.3V 1.2/3.3V HS Bipolar F_T (GHz) 150 200 240 200 240 F_MAX (GHz) 190 200 270 200 270 BV_CEO (V) 2.2 1.9 1.6 1.9 1.6 Capacitor fF/µm2 _2.8/5.6 _2/4 _2.8/5.6 _2.8/5.6 _2.8/5.6 Varactor Q at 20 GHz ₁₀ _NA ₁₅ _NA ₁₅ LPNP Beta 32 7 30 7 30

 There are numerous other SBC18 flavors in production with

variations in back end configuration, selection of available devices etc.

(9)

SiGe HBJT’s current and power gain

 240 GHz Ft / 270 GHz Fmax devices in mass production.

 High frequency performances sustained for wide collector current range. 0.1 1 10 0 50 100 150 200 250 SBC18H2 SBC18H3 F PEA K T (GH z ) J_C (mA/µm2) V_CB = 0.5V F_MEAS=20GHz 3µm Emitter 122 Device 0.1 1 10 0 50 100 150 200 250 300 SBC18H2 SBC18H3 F PEA K MA X (GH z ) J_C (mA/µm2) V_CB = 0.5V F_MEAS=20GHz 3µm Emitter 122 Device

(10)

SiGe HBJT’s gain vs DC power density

 TowerJazz Devices are optimized for low power consumption.

0.1 1 10 5 10 15 20 _SBC18H2 SBC18H3 70% Lower Power U G at 28GH z (d B ) DC Power Density (mW/µm2) 0.1 1 10 0 5 10 15 20 SBC18H2 SBC18H3 h 21 at 28GH z (d B ) DC Power Density (mW/µm2) 35% Lower Power

(11)

SiGe HBJT’s Noise

0 10 20 30 40 50 60 70 80 90 100 0 1 2 3 4 5 6 7 8 9 10 SBC18H2 SBC18H3 NF MIN (d B ) Frequency (GHz) -1.3dB 0 2 4 6 8 10 12 14 16 18 0.0 0.5 1.0 1.5 2.0 2.5 3.0

0.13x20 µm Single Emitter, Dual Base, Dual Collector

40 GHz 32 GHz 20 GHz NF MI N (d B ) I C (mA) 8 GHz

 SBC18H4 minimum noise figure at 20Ghz is measured less than 1dB and at 40GHz at only 2dB.

(12)

Circuit examples at ~100GHz: LNAs

5 6 7 8 9 10 11 12 13 14 15 70 75 80 85 90 95 100 105 110 Measur ed R ec eiv er NF (d B) Input RF Frequency (GHz) Receiver NF - Element 1 (H3) Receiver NF - Element 2 (H3) Receiver NF - Element 3 (H3) Receiver NF - Element 4 (H3) Receiver NF - Element 1 (H2) Receiver NF - Element 2 (H2) Receiver NF - Element 3 (H2) Receiver NF - Element 4 (H2) 0 5 10 15 20 25 30 35 40 70 75 80 85 90 95 100 105 110 Me as ur ed R ec eiv er Gain (dB) Input RF Frequency (GHz) Receiver Gain - Element 1 (H3) Receiver Gain - Element 2 (H3) Receiver Gain - Element 3 (H3) Receiver Gain - Element 4 (H3) Receiver Gain - Element 1 (H2) Receiver Gain - Element 2 (H2) Receiver Gain - Element 3 (H2) Receiver Gain - Element 4 (H2)

SBC18H2

 Broad band mm-wave LNAs fabricated in SBC18H2 and SBC18H3

 4 identical LNAs built for a 4-channel W-band phased-array receiver

 Nearly 30dB of gain above noise floor at 85GHz

(13)

RF Grounding:

Deep Silicon Vias vs. Through Silicon Vias

 Deep Silicon Vias and Through Silicon Vias are available for enhanced RF grounding.

Metal 1

Backside Metallization

Through-Silicon Vias

~100um

Deep Silicon Vias

~10um Metal 1 Backside Metallization p++ handle wafer p- Epi emitter collector ~1 5 0 um

(14)

Bipolar Roadmap

 next generation (SBC18H4) is in final development stage ,Fmax=350Ghz , improved noise figure.

 SiGe NPN on thick film SOI under development.

1 10 0 100 200 300 SBC18H2 SBC18H3 SBC18H4 (prototype) F PEA K MA X (GH z ) J_C (mA/µm2) V_CB = 0.5V F_MEAS=20GHz 3µm Emitter 122 Device 0 10 20 30 40 50 0 1 2 3 4 5 SBC18H2 SBC18H3 SBC18H4 (Prototype) NF MI N (d B ) Frequency (GHz) 0.13x20um 122 Device V BE=0.825V

(15)

Summary

 TowerJazz offer SiGe HBJT devices on 0.35µm, 0.18µm and 0.13µm technology nodes.

 TowerJazz SiGe HBJT offers Best in class SiGe Speed / Power and Best in class Noise.

 The SiGe HBJTs are embedded into complimentary

BiCMOS platforms offering high performance RF, analog and digital performances.

(16)

(17)

Complete SBC18H3 Device Roster

Family Device Characteristics

CMOS 1.8V CMOS Model-exact copy of all other TJ 0.18um CMOS 3.3V CMOS

Bipolar HS NPN 240 GHz F_T / 280 GHz F_MAX STD NPN 55GHz F_T / 3.2V BV_CEO

LPNP b=35

Resistors Poly 235 W/sq and 1000 W/sq Metal 25 W/sq TiN on M3

Capacitors Single MIM 2 or 2.8 fF/µm2

Stacked MIM 4 or 5.6 fF/µm2

Varactors 1.8V MOS Q @ 20GHz = 20

Hyper-abrupt junction Q @ 20GHz =15, Tuning Ratio = 21%

RF Diodes p-i-n Isolation <-15dB, Insertion loss > -3.5dB at 50GHz Schottky F > 800 GHz

(18)

SiGe HBJT basic layout-122 configuration

AA, EP BP SC AREA2 XN AA WN EW WN N+ for Nsub WN N+ for Nsub STI STI SC Implant SiGe-Based layer EW Emitter Poly

Collector Base Emitter Base Collector

Native P-sub WN N+ for Nsub WN N+ for Nsub STI STI SC Implant SiGe-Based layer EW Emitter Poly
