GENERAL PURPOSE ELECTRODES - MILD STEEL

Austarc 12P ... 6-7 Austarc 13S ... 8-9

HyDROGEN CONTROLLED ELECTRODES

Austarc 16TC ...10-11 Austarc 18TC ... 12-13 Austarc 77 ... 14-15

IRON POWDER ELECTRODES

Austarc 24 ... 16-17

CELLULOSE ELECTRODES

Austarc 11 ... 18-19

STAINLESS STEEL ELECTRODES

Staincord 309Mo-16 ... 20-21 Staincord 316L-16 ... 22-23 Unicord 312 ... 24-25

CAST IRON ELECTRODES

Supercast Ni ... 26-27 Suercast Ni/Fe ... 28-29

GOUGING AND CUTTING ELECTRODES

Austarc C&G ... 30-31

(8)

AUSTARC

12 P

SUMMARy

• General Purpose Rutile Type Electrode

• Versatile/All Positional Capabilities Including Vertical Down • Smooth Performance on Low OCV AC Welding Machines

IDENTIFICATION

Coating - Brown Tip - Red Imprint - WIA 4313A

CLASSIFICATION

• AS/NZS 4855-B - E43 13 A • AWS A5.1: E6013

DESCRIPTION AND APPLICATION

Austarc 12P is a smooth running, rutile type electrode for all positional welding of mild steel. It is characterised by a moderately forceful and extremely stable arc. Superb arc starting and restriking on low voltage AC welding machines. A stiff fast freezing slag for all positional (especially vertical down) fillet welding capabilities. Typical applications include, the all positional welding of galvanised gates/fences, steel furniture, trailers and wrought iron.

OPERATIONAL DATA

ELECTRODE

SIZE (mm) LENGTH (mm)ELECTRODE WELDING CURRENT RANGE *(A) ARC VOLTAGE RANGE **(V)

2.0 300 40-60 19

2.5 300 60-85 20

3.2 380 90-130 21

4.0 380 130-180 22

5.0 450 180-230 23

(9)

SHIPPING APPROVALS

LR 2Ym ABS 2 DNV 2

TyPICAL ALL WELD METAL CHEMICAL ANALySIS

C Mn Si Fe

0.07 0.5 0.3 Bal

TyPICAL ALL WELD METAL MECHANICAL ANALySIS

Yield Stress 450 MPa Tensile Strength 500 MPa Elongation 26% CVN Impact Values 70J @ 0°C In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.0 2.5 12.5 103 12P20 2.5 2.5 12.5 67 12P25 3.2 5.0 15 31 12P32 4.0 5.0 15 20 12P40 5.0 5.0 15 11 12P50

TRODES

-GENER

AL PUR

PO

SE EL

ECT

RO

DES

- MIL

D S

TEEL

(10)

AUSTARC

13 S

SUMMARy

• General Purpose/Rutile Type Electrode

• Versatile/All Positional (especially vertical up) Capabilities • Ideal for Down Hand Fillet Welding of Mild Steel • Smooth Performance on Low OCV AC Welding Machines

IDENTIFICATION

Coating - Blue/White Stripe Tip - Plain Imprint - WIA 4313A

CLASSIFICATION

• AS/NZS 4855-B - E43 13 A • AWS A5.1: E6013

Austarc 13S is the popular “blue and white striped” general purpose electrode for smooth mitre fillet welding applications. 13S has a soft and stable arc and produces flat, uniform fillet welds with ease and a self peeling slag action.

Austarc 13S is formulated primarily for fillet welding in all down hand positions. It is ideal for the general purpose and structural welding of sheet and plate steels (galvanised or otherwise) and tubular components, including trailers, duct work, hoppers and storage tanks, etc.

ELECTRODE

2.0 300 40-60 19

2.5 300 60-85 20

3.2 380 100-130 21

(11)

LR 2m ABS 2 DNV 2

C Mn Si Fe

0.07 0.55 0.45 Bal

Yield Stress 450 MPa Tensile Strength 520 MPa Elongation 26% CVN Impact Values 60J @ 0°C In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.0 2.5 12.5 99 13S20 2.5 2.5 12.5 63 13S25 3.2 5.0 15 29 13S32 4.0 5.0 15 10 13S40 5.0 5.0 15 6 13S50 6.0 5.0 15 6 13S60

TRODES

-GENER

AL PUR

PO

SE EL

ECT

RO

DES

- MIL

D S

TEEL

(12)

AUSTARC

16 TC

SUMMARy

• Basic/Twin Coated (TC) Manual Arc Electrode • Low Hydrogen, “H10” Status

• Versatile/All Positional (Especially Vertical Up) Capabilities • Reliable, Low Temperature Impact Toughness

• Easy to Strike and Re-Strike

• Smooth Performance on Low OCV AC Welding Machines

IDENTIFICATION

Coating - Light Grey Tip - Bronze Imprint - WIA 4916A

CLASSIFICATION

• AS/NZS 4855-B - E49 16-A U H10 • AWS A5.1: E7116-1 H8

Austarc 16TC is a smooth running, basic low hydrogen electrode, developed for all positional (except vertical down) welding, using AC or DC power sources. The electrode gives exceptional arc stability and weldability for its class and produces high quality weld deposits with reliable notch toughness to -40°C. Austarc 16TC is manufactured using a unique twin coating extrusion process, which produces electrodes with two concentric flux coatings. Arc stabilising elements are concentrated in the inner coating of the electrode for significantly improved arc stability on AC welding machines. Other features of 16TC include, a smooth rippled weld profile with excellent edge wetting and a fluid, easily removed glassy slag. Austarc 16TC deposits X-ray quality weld metal with typical diffusible hydrogen levels of 5-8 mls of hydrogen per 100 gms of deposited weld metal, for “as manufactured” product, thus satisfying the “H10” low hydrogen category of AS/NZS 4855 and “H8” of AWS A5.1.

ELECTRODE

(13)

LRS 4Ym H10 ABS 3 H10 DNV 3Y H10

C Mn Si P S Fe

0.06 1.2 0.4 0.015 0.010 Bal

Yield Stress 460 MPa Tensile Strength 560 MPa Elongation 28% CVN Impact Values 130J @ -20°C 110J @ -40°C PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.5 12.5 61 16TC25 3.2 5.0 15 29 16TC32 4.0 5.0 15 19 16TC40 5.0 5.0 15 10 16TC50 6.0 5.0 15 7 16TC60 MATERIALS TO BE WELDED CODE TyPE Structural Steel AS 1163 C250, C350, C450 AS 1397 G250, G300, G350, G450 AS 1450 C/H200, C/H250, C/H350, C/H450, AS/NZS 3679.1 250, 300, 350, 400 AS/NZS 3678.1 AS/NZS 3679.2 200, 250, 300, 350, 400, 450, A1006, XK1016, WR350 Pressure Equipment Steel AS 1548 7-430, 7-460, 5-590, 7-490 Fine Grain Steel AS/NZS 1594

HAI, HA3, HA4N, HA200, HA250, HA300, HA1006, HA1010, HA1016,

HA350, HA400 Cast Steel AS2074 C2, C3, C7A-1, C1, C4-1, C4-2, C7A-2

TRODES

-HYDROG

EN CON

TROL

LED

EL

EC

TRODES

(14)

AUSTARC

18 TC

SUMMARy

• Basic Twin-Coated (TC) Iron Powder Electrode • Very Low Hydrogen H5 Status

• Suitable for all Positional Welding Except Vertical Down • Excellent Low Temperature Fracture Toughness • Easy to Strike and Re-Strike

• Smooth Performance on Low OCV AC Welding Machines

IDENTIFICATION

Coating - Light Grey Tip - Blue Imprint - WIA 4918-1A

CLASSIFICATION

• AS/NZS 4855-B - E49 18-A U H5 • AWS A5. 1: E7018-1

Austarc 18TC is a basic iron powder electrode used primarily on C-Mn and low alloy structural steels. The unique twin-coat design for 18 type low hydrogen electrode offers excellent AC arc stability and superb DC+ arc transfer, excellent re-strike, reduced spatter level and extraordinary ease of use for out-of-position welding. Typical applications include oil and gas, pipe welding, structural steel construction, off-shore where Ni-alloying is prohibited, mining equipment, heavy girders and earth moving plant repair and maintenance.

ELECTRODE

SIZE (mm) LENGTH (mm)ELECTRODE WELDING CURRENT RANGE *(A) 2.5 300 60-90 3.2 380 90-135 4.0 380 140-190 *Please note, the recommended welding polarity for

(15)

C Mn Si P S Fe

0.06 1.55 0.54 0.010 0.02 Bal

Yield Stress 530 MPa Tensile Strength 602 MPa Elongation 24% CVN Impact Values 87J @ -50°C PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.5 12.5 45 18TC25 3.2 5.0 15 26 18TC32 4.0 5.0 15 17 18TC40 MATERIALS TO BE WELDED CODE TyPE Structural Steel AS 1163 C250, C350, C450 AS 1397 G250, G300, G350, G450 AS 1450 C/H200, C/H250, C/H350, C450 AS 1450 250, 300, 350, 400 C/H200, C/ H250, 200, 250, 300, 350, 400, 450, A1006, XK1016, WR350 AS/NZS 3679.1 250, 300, 350, 400 AS/NZS 3678.1 AS/NZS 3679.2 200, 250, 300, 350, 400, 450, A1006, XK1016, WR350 Pressure Equipment Steel AS 1548 7-430, 7-460, 5-590, 7-490 Fine Grain Steel AS/NZS 1594

HA1, HA3, HA4N, HA200, HA250, HA300, HA1006, HA1010, HA1016,

HA350, HA400 Cast Steel AS2074 C2, C3, C7A-1, C1, C4-1, C4-2, _C7A-2

TRODES

-HYDROG

EN CON

TROL

LED

EL

EC

TRODES

(16)

SUMMARy

• Basic Coated Iron Powder Electrode • Low Hydrogen Status

• Suitable for All Positional Welding Except Vertical Down • Excellent Low Temperature Fracture Toughness

IDENTIFICATION

Coating - Light Grey Tip - Black Imprint - WIA 4918-1A

CLASSIFICATION

• AS/NZS 4855-B - E49 18-1 U H5 • AWS A5.1: E7018-1

The Austarc is a smooth running basic type of low hydrogen iron powder electrode used for all positional welding except vertical down. The arc is very quiet with little spatter and the welds are exceptionally smooth with excellent wash in at the toes of the weld, thus giving minimum undercut. This electrode is used where the highest restrained work pieces are fabricated for mining equipment, pressure vessels, heavy girders, earth moving plant, repair and maintenance etc.

For the highest weld quality with low hydrogen levels, Austarc 77 electrodes should be baked at 400˚C for one hour to obtain <5mL/100g weld metal. After baking, the electrodes should be used from a hot box set at 100 -150 ˚C.

ELECTRODE

2.5 305 60-105 20

(17)

LR 4Ym H5 ABS 3Y H5

C S Mn P Si Fe

0.05 0.011 1.28 0.022 0.30 Bal

Yield Stress 455 MPa Tensile Strength 534 MPa Elongation 30% CVN Impact Values 123J @ -50°C In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.2 11 45 7725 3.2 5.0 15 26 7732 4.0 5.0 15 17 7740 5.0 5.0 15 9 7750

TRODES

-HYDROG

EN CON

TROL

LED

EL

EC

TRODES

(18)

SUMMARy

• High Iron Powder, Rutile Type Electrode • High Deposition Rates and Efficiencies

• Suitable for Fast Downhand Fillet and Butt Welding

IDENTIFICATION

Coating - Brown Tip - Yellow Imprint - WIA 4924A

CLASSIFICATION

• AS/NZS 4855-B - E49 24 A • AWS A5.1: E7024

Austarc 24 is a high iron powder, rutile type electrode designed for the fast down hand welding of mild steel using AC or DC power sources. Features include high deposition rates/efficiencies and flat to slightly concave fillet welds with excellent “edge wash” and slag detachability. With its smooth running, positive re strike and high current carrying capacity, Austarc 24 is the ideal fillet welding electrode for down hand positions aimed at higher productivity. Austarc 24 is suited to long, heavy fillet and butt welding applications using a touch welding or `short arc’ technique. Such applications include the production welding of tanks, structural members/frames and truck and tractor bodies etc.

ELECTRODE

3.2 380 120-170 24

4.0 450 200-240 25

5.0 450 270-320 26

(19)

LR 2Ym ABS 2 DNV 2

C Mn Si Fe

0.06 0.7 0.4 Bal

Yield Stress 455 MPa Tensile Strength 510 MPa Elongation 27% CVN Impact Values 60J @ 0°C In as welded condition PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 3.2 5.0 15 18 2432 4.0 5.0 15 12 2440 5.0 5.0 15 6 2450

TRODES

-IRON

P

OW

DE

R E

LEC

TRODES

(20)

SUMMARy

• High Cellulose Coating • All Positional/High Penetration • Ideal for Site Welding

IDENTIFICATION

Coating - White Tip - Brown Imprint - WIA 4311A

CLASSIFICATION

• AS/NZS 4855-B - E4311A • AWS A5.1: E6011

Austarc 11 is a high cellulose electrode developed for all positional welding on both AC and DC power supplies.

Features include: Forceful, deep penetrating arc with

fast freezing slag. Particularly suited for vertical and incline pipe welding where complete root penetration is required. The thin brittle slag is easily removed.

Austarc 11 is recommended for specific applications including pipeline welding and storage tank construction where either the “Stove Pipe” or “Flick” techniques can be used to obtain full root penetration in critical structural joints.

ELECTRODE

2.5 300 60-95 20

3.2 380 90-125 21

4.0 380 115-175 22

5.0 450 160-220 23

(21)

LR 3M ABS 3

C Mn Si Fe

0.13 0.5 0.1 Bal

Yield Stress 416 MPa Tensile Strength 510 MPa Elongation 32% CVN Impact Values 70J @ -30°C In as welded condition PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.5 12.5 66 1125 3.2 5.0 15 33 1132 4.0 5.0 15 21 1140 5.0 5.0 15 14 1150

TRODES

-CE

LLU

LOSE

EL

EC

TRODES

(22)

SUMMARy

• All Positional, Rutile Type Stainless Steel Electrode • Moisture Resistant Flux Coating/”Extra” Low Carbon Deposit • Suitable for the Dissimilar Welding of Stainless Steel to Mild/Low Alloy Steels.

IDENTIFICATION

Coating - Grey Tip - Black Imprint - WIA 309MO-16

CLASSIFICATION

• AS/NZS 4854-B - E309LMo-16 • AWS A5.4: E309MoL-16

Staincord 309Mo-16 is an extra low carbon, rutile type electrode exhibiting superior all positional (except vertical down performance with an improved moisture resistant coating for weld metal of high radiographic integrity. The smooth arc action of Staincord 309Mo-16, together with low spatter and excellent slag control/ detachability, promotes exceptional weld appearance and profile. Staincord 309Mo-16 is a Molybdenum bearing, highly alloyed 23Cr/12Ni/2.5Mo stainless steel electrode for welding matching 309 and 309Mo base metals. Major applications of Staincord 309 Mo-16 also involve the welding of a wide range of 300 and 400 series stainless steels to mild/low alloy steels. 309M is also suitable for general welding applications with alloyed and non-alloyed dissimilar ferrous metal combinations.

ELECTRODE

2.5 300 50-75 22

(23)

C Mn Si Cr Ni Mo Fe

0.025 0.8 0.7 23.5 13.0 2.4 Bal

Yield Stress 400 MPa Tensile Strength 670 MPa Elongation 38% In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.5 12.5 86 SC309MO25 3.2 2.5 12.5 55 SC309MO32

TRODES

-ST

AIN

LES

S STE

EL E

LECTR

OD

ES

(24)

SUMMARy

• All Positional, Rutile Type Stainless Steel Electrode • Moisture Resistant “Colour Coated” Flux Coating • Extra Low Carbon Weld Deposit

• For the Critical Welding of Matching Type 316 and 316L Steels

IDENTIFICATION

Coating - Pink Tip - Green Imprint - WIA 316L-16

CLASSIFICATION

• AS/NZS 4854-B - ES316L-16 • AWS A5.4: E316L-16

New generation Staincord 316L-16 is an extra low carbon, rutile type electrode exhibiting superior all positional (except vertical down) performance with an improved moisture resistant “Pink” flux coating for weld metal of high radiographic integrity. The smooth arc action of Staincord 316L-16, together with low spatter and excellent slag control/detachability, promotes exceptional weld appearance and profile. Other features include high arc stability and easy restriking on low voltage AC welding machines. Staincord 316L-16 deposits Molybdenum bearing, 19Cr/12Ni/2.5Mo filler metal to meet the requirements for welding type 316 and 316L stainless steels in critical applications. Staincord 316L-16 is also recommended for the general purpose welding of common 300 series stainless steels, such as 301, 302, 304 and 304L. It is also suitable for the general welding of ferritic stainless steel alloys, such as 409, 444 and 3Cr12.

STAINCORD

316 L-

16 STAINCORD

316 L-

16

(25)

ELECTRODE

2.0 300 30-50 20

2.5 300 50-75 21

3.2 350 75-110 26

*Recommended for DC +/- or AC (minimum 45 OCV) operation. **Voltage is determined by arc current and electrode arc length. Arc voltage shown is typical and is only to be used as a guide.

C Mn Si Cr Ni Mo Fe

0.025 0.7 0.7 18.5 12.0 2.4 Bal

Yield Stress 380 MPa Tensile Strength 600 MPa Elongation 40% In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.0 2.5 12.5 86 SC31620 2.5 2.5 12.5 55 SC31625 3.2 2.5 12.5 27 SC31632

TRODES

-ST

AIN

LES

S STE

EL E

LECTR

OD

ES

(26)

SUMMARy

• Universal AC/DC Maintenance Electrode for Welding Ferrous Metals

• Ideal for Joining Dissimilar Steel Components • Suitable as a Buffer Layer Prior to Hard Surfacing • Stable Performance on Low OCV Welders

IDENTIFICATION

Coating - Grey Tip - Red Imprint - Unicord 312

CLASSIFICATION

• AS/NZS 4854-B - ES312-16 • AWS A5.4: E312-16

Unicord 312 is a basic, rutile type electrode depositing a 29%Cr/9%Ni stainless steel weld metal for the high strength welding of a wide range of alloy steels and dissimilar ferrous metals. The high ferrite, austenitic stainless steel deposit has excellent resistance to hot cracking, even under dilution by high carbon, alloy and tool steels. Unicord 312 is a universal maintenance electrode combining high strength, toughness, wear and corrosion resistance with compatibility to most ferrous metals. Unicord 312 is suitable for many repair and maintenance applications on steels of unknown composition. It is an ideal electrode for welding medium to high carbon steels, low alloy steels and dissimilar ferrous metal combinations. Unicord 312 is also suitable as a buffer or intermediate layer prior to the application of hard surfacing.

ELECTRODE ELECTRODE WELDING CURRENT ARC VOLTAGE

(27)

C Mn Si Cr Ni Fe

0.04 0.9 0.85 30.0 9.0 Bal

Yield Stress 500 MPa Tensile Strength 770 MPa Elongation 45% Deposit Hardness 28-35 HRc In as welded condition. PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 2.5 2.5 12.5 52 UC31225 3.2 2.5 12.5 27 UC31232

TRODES

-ST

AIN

LES

S STE

EL E

LECTR

OD

ES

(28)

SUMMARy

• Pure Nickel Core Wire/Basic, Graphite Coating

• Soft Machineable Nickel Deposit for the Lower Strength Welding of Cast Irons

IDENTIFICATION

Coating - Black Tip - Plain Imprint - WIA SC Ni

CLASSIFICATION

• AWS A5.15: ENi-Cl

Supercast Ni is a basic, graphite coated AC/DC electrode for the lower strength welding of cast irons. It is characterised by a soft, smooth arc with low penetration and spatter levels on both AC and DC power sources. Ease of striking is a feature of Supercast Ni and it also has a particularly good wetting action resulting in well bonded welds of regular contour and attractive appearance. This electrode is made from a pure nickel core wire and produces a ductile, fully machineable weld deposit. Supercast Ni may be used for the repair and reclamation of all standard grades of grey cast iron, malleable iron, austenitic cast iron and some grades of mechanite cast iron.

ELECTRODE

3.2 350 50-100 23

*Recommended for DC +/- or AC (minimum 45 OCV) operation. **Voltage is determined by arc current and electrode arc length. Arc voltage shown is typical and is only to be used as a guide.

(29)

Mn Ni S Fe

0.3 97.0 0.006 Bal

Yield Stress 220 MPa Tensile Strength 400 MPa Deposit Hardness 150-170 HV (30) PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 3.2 2.5 12.5 37 SNI32

TRODES

-CAS

T I

RON

EL

EC

TRODES

(30)

SUMMARy

• Nickel -Iron Core Wire/Basic, Graphite Coating

• Machineable Nickel-Iron Deposit for the Higher Strength Welding of Cast Irons, Particularly SG Irons

IDENTIFICATION

Coating - Black Tip - Green Imprint - WIA SC NiFe

CLASSIFICATION

• AWS A5.15: ENiFe-Cl

Supercast Ni/Fe is a basic, graphite coated AC/DC electrode for the higher strength welding of cast irons. It is characterised by a soft, smooth arc with low penetration and spatter levels on both AC and DC power sources. Ease of striking is a feature of Supercast Ni/Fe.

This electrode is made from a Nickel-Iron core wire and produces a ductile, machineable weld deposit with the extra strength required for welding SG (Spheroidal Graphite) irons. Supercast Ni/Fe may also be used for the repair and reclamation of all standard grades of grey cast iron, malleable iron, austenitic cast iron and some grades of mechanite cast iron. It is ideally suited to the dissimilar welding of these irons to steels.

ELECTRODE

3.2 350 50-100 23

*Recommended for DC +/- or AC (minimum 45 OCV) operation. **Voltage is determined by arc current and electrode arc length.

(31)

Mn Ni S Fe

0.85 57.8 0.007 Bal

Yield Stress 300 MPa Tensile Strength 500 MPa Deposit Hardness 200-220 HV (30) PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 3.2 2.5 12.5 39 SNIFE32

TRODES

-CAS

T I

RON

EL

EC

TRODES

(32)

SUMMARy

• Heavy Coated Manual Electrode for Cutting, Gouging or Piercing Steels

IDENTIFICATION

Coating - Black End Tip - Plain

Austarc C&G is a heavy coated electrode providing a highly mobile means of cutting, gouging and piercing most steels, using standard AC or DC arc welding equipment. Austarc C&G produces a very high arc force and can be used for general cutting and grooving in joint preparation, removing defective welds and reclaiming scrap metal, etc.

Oxy-acetylene and carbon arc-air cutting and gouging are two processes available to industry capable of giving high quality, smooth preparations. Austarc C&G will not replace these processes but rather provide a convenient, easy to use and mobile tool for the arc gouging and cutting of most metals. It is particularly useful to the maintenance welder operating in awkward locations to remove welds, open up joints and trim off bolt or rivet heads, etc. Similarly, the rural welder will find C&G handy in repairing or preparing joints when operating away from (or without) oxy-acetylene equipment.

Cutting - Direct the electrode into the work in the desired cutting

direction, working from the outside edge. Use an up and down sawing motion, the “up” arc length being increased to increase heating, the “down” arc length being decreased to contact point to force the molten metal out of the groove. Angle of electrode should be approx 70° to the horizontal.

(33)

Gouging - Point the electrode in the direction of gouging at

approx 10-20° to the plate surface. Strike the arc and move forward rapidly. If slag and molten metal start to clog the groove bring the electrode up to clear and, without breaking the arc, circle backwards and move forward again. This latter technique may prove more necessary than straight forward motion on lower amps or as the electrode becomes hotter. If amps are excessive, C&G will tend to “cut out” on AC and overheat, causing premature charring of the coating and reduced arc force.

Piercing - For holes, plunge the electrode into the plate at slightly

off right angles. With a small circular motion to the holder, force the electrode into the plate until full penetration is achieved. Once the hole has been made it may be trimmed with an up and down sawing motion.

ELECTRODE

SIZE (mm) LENGTH (mm)ELECTRODE PACKAGING (KG) WELDING CURRENT _Packet _Carton RANGE *(A)

3.2 380 4 12 170-250 4.0 380 4 12 220-350

TRODES

-GOUG

ING

A

ND

CU

TTING

EL

EC

TRODES

(34)

(35)

SOLID MIG WIRES

Austmig ES6

...

34-35

SOLID MIG WIRES - LOW ALLOy STEEL

Austmig ESD2 ... 36-37 Austmig NiCrMo ... 38-39

SOLID MIG WIRES - ALUMINIUM

Austmig 5183 ... 40-41 Austmig 5356 ... 42-43

METAL CORED GAS SHIELDED WIRES

Austfil 70C-6M ... 44-45

FLUX CORED GAS SHIELDED WIRES

Austfil 71T ... 46-47 Austfil 71T-1M ... 48-49 Hobart XL-525 ... 50-51 TM-71HYD ... 52-53 TM-811N2 ... 54-55

FLUX CORED SELF SHIELDED WIRES

Fabshield 4 ... 56-57 Fabshield 23 ... 58-59 Fabshield 21B ... 60-61 Fabshield XLR-8 ... 62-63

(36)

SUMMARy

• Electrostatically Copper Coated Gas Metal Arc (MIG) Wire • All Positional Welding of Mild and Medium Strength Steels • Precision Layer Wound, Very Low Diffusable Hydrogen • Suitable for all Transfer Modes

• Designed for use with Argon/CO₂ and CO₂ Shielding Gases

CLASSIFICATION

• AS/NZS 2717.1: ES6-GC-W503AH • AS/NZS 2717.1: ES6-GM-W503AH • AWS A5.18: ER70S-6

Austmig ES6 is a copper coated, low carbon steel GMAW wire, formulated for optimum performance under Argon/CO₂ mixed gases and welding grade CO₂. Arc transfer characteristics are excellent with Argon based gas mixtures, particularly in spray and pulsed transfer modes. Austmig ES6 is an electrostatically copper coated wire providing excellent wire feeding and electrical conductivity and reducing contact tip wear. The higher manganese and silicon content of Austmig ES6 provides effective weld metal deoxidation for resistance to porosity.

Austmig ES6 is suitable for a wide range of welding applications on mild and medium strength steels providing consistently very low “H5” weld metal diffusible hydrogen levels when used with suitable shielding gases.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 0.6 40-100 12-16 0.8 60-180 14-22 0.9 70-230 15-26

(37)

LR 3S, 3YS

C Mn Si S P Fe

0.1 1.45 0.88 0.02 0.022 Bal

Gas Type CO₂ Ar+18% CO₂ Yield Stress 460 MPa 480 MPa Tensile Stress 560 MPa 580 MPa

Elongation 28% 26%

CVN Impact Values 80J @ -20ºC 70J @ -30ºC

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.6 _{15kg spool}5kg spool ES606M5KG _ES606S 0.8 _{15kg spool}5kg spool ES608M5KG _ES608S 0.9 _{15kg spool}5kg spool ES609M5KG _ES609S 1.0 15kg spool ES610S 1.2 15kg spool ES612S 1.6 15kg spool ES616S

-SO

LID

MI

G WIR

ES

MIL

D S

TEEL

(38)

SUMMARy

• Copper Coated, High Manganese-Molybdenum Gas Metal Arc (MIG) Welding Wire

• For the all Positional Welding of Medium to Higher Strength Steels

CLASSIFICATION

• AS/NZS 2717.1: ESD2-GC-W559AH • AS/NZS 2717.1: ESD2-GM-W559AH • AWS A5.18: ER80S-D2

Austmig ESD2 is a copper coated, low alloy steel wire used for welding medium to higher strength steels, particularly where service temperatures up to 500°C are encountered. ESD2 gives excellent resistance to porosity using CO₂ or Argon based gas mixtures (i.e. Ar/CO₂, Ar/O₂, Ar/CO₂/O₂). When porosity is a potential problem due to dirty or rusty surfaces or higher than normal sulphur contents, Austmig ESD2 will provide a consistently sound weld deposit.

Austmig ESD2 is also suitable for out-of-position welding due to its quick freezing weld pool. ESD2 produces high quality welds on plain carbon and C-Mn steels, low alloy steels and higher strength used in pressure vessels and boilers, such as petrochemical and power generation industries, operating at elevated temperatures. Austmig ESD2 may also be used for the fillet welding of higher tensile, quenched and tempered steels, such as Bisalloy 70 and 80 where the lower strength weld metal may be compensated by larger fillet sizes.

When used with suitable shielding gases, Austmig ESD2 will consistently produce very low “H5”, weld metal diffusible hydrogen levels, for excellent resistance to HAZ or hydrogen induced cracking.

(39)

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 0.9 70-230 15-26 1.2 120-350 18-32 Welding Current DC +

*Voltage is determined by arc current and electrode arc length. Welding currents and voltage shown are operational guides only.

C Mn Si Mo Fe

0.1 1.95 0.75 0.5 Bal

Gas Type CO₂ Ar+18% CO₂ Yield Stress 560 MPa 570 MPa Tensile Stress 645 MPa 660 MPa

Elongation 19% 20%

CVN Impact Values 35J @ -20ºC 50J @ -30ºC

In as welded condition.

NOTE: The use of less oxidizing Argon based gas mixtures will result

in higher manganese and silicon weld metal recovery, leading to higher tensile properties, particularly in heavy multi pass butt welds.

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.9 15kg spool ESD209S 1.2 15kg spool ESD209S

-SO

LID M

IG W

IRE

S - L

OW A

LLOY STE

EL

(40)

SUMMARy

• Copper Coated, Low Allloy Gas Metal Arc (MIG) Welding Wire • All Positional Welding of Medium and High Strength Steels • Welded Strength 760 MPa Tensile Class

CLASSIFICATION

• AS/NZS 2717.1: ESMG-GM-W769AH-G • AWS A5.28: ER110S-G

Austmig NiCrMo is a copper coated, low alloy solid wire suitable for the all positional welding of high strength steels using Argon + CO₂ gas mixtures.

Austmig NiCrMo is ideal for the full strength welding of quenched and tempered structural steels, of the 760 MPa tensile class, such as USS-T1, CcMo Pipe, Welten 80, Weldox 700, X80, N-A-XTRA and Bisplate 80.

WIRE

NOTE: Austmig NiCrMo is NOT to be used in weldments which

are to be stress relieved.

(41)

C Mn Si Ni Cr Mo V Fe

0.07 1.22 0.37 1.42 0.29 0.24 0.07 Bal

Gas Type Ar+18% CO₂ Yield Stress 732 MPa Tensile Stress 799 MPa Elongation 18% CVN Impact Values 78J @ -30ºC

In as welded condition

NOTE: The use of less oxidizing argon based gas mixtures

(ie Ar/O₂, Ar/CO₂, Ar/CO₂/O₂), will result in higher alloy recovery in the weld metal, leading to higher tensile properties.

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.9 15kg spool MNICRMO09S 1.2 15kg spool MNICRMO12S

-SO

LID M

IG W

IRE

S - L

OW A

LLOY STE

EL

(42)

SUMMARy

• Aluminium-Magnesium-Manganese, Metal Inert Gas (MIG) Welding Wire

• Precision Layer Wound and Double Shaved for Superb Feedability

• For Welding of Alloys of the same Composition

CLASSIFICATION

• AS/NZS ISO 18273 - S AI 5183 • AWS A5.10: E5183

Austmig 5183 is a precision layer wound aluminium wire alloyed with Mg, Mn and Cr.

It is recommended for welding Al/Mg material of the 5083 type in the annealed condition, particularly for low temperature applications where good ductility and toughness are required, ie cryogenic plant. It may also be used for welding medium strength Al/Zn/Mg alloys of the 7020 type and joining 5083 alloy to 5456 alloy. Welding grade Argon or Argon/Helium shielding gas combinations are recommended with flow rates of 10-20 litres/minute.

WIRE

(43)

LR WC/1-1S ABS AWS A5. 10-92/ER5183

DNV 5183

Si Fe Cu Mn Mg Cr Zn Ti AI

0.4 0.4 0.1 0.5-1.0 4.3-5.2 0.05-0.25 0.25 0.15 Bal

Gas Type Ar Yield Stress 110 MPa Tensile Stress 240 MPa Elongation 17%

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 6kg spool M518312S 1.6 6kg spool M518316S

-SO

LID

MI

G WIR

ES

A

LUMINIUM

(44)

SUMMARy

• Aluminium - 5% Magnesium Alloy, Metal Inert Gas (MIG) Welding Wire

• Double Shaved and Precision Layer Wound for Superb Feedability

• For Welding Cast and Wrought Aluminium Alloys Containing Magnesium

CLASSIFICATION

• AS/NZS ISO 18273 - S AI 5356 • AWS A5.10: ER5356

Austmig 5356 is a precision layer wound Aluminium - 5% Magnesium wire suitable for a wide range of gas metal arc welding applications on wrought or cast aluminium alloys containing magnesium as a major alloying element. Some grades of wrought aluminium - magnesium alloys which can be welded with Austmig 5356 are, 5083, 5086, 5454 and 5456.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 0.9 80-190 16-22 1.0 100-230 18-22 1.2 150-250 20-27 1.6 200-330 23-30 Welding Current DC +

(45)

LR WC/I-1,S; ABS AWS A5. 10-92/ER 5356; DNV 5356

Zn Mg Mn Cr Si Fe Ti AI

0.1 5.2 0.15 0.1 0.25 0.4 0.15 Bal

Gas Type Ar Yield Stress 125 MPa Tensile Stress 275 MPa Elongation 17%

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.9 2kg spool _{6kg spool} M5356092KG _M535609S 1.0 2kg spool _{6kg spool} M5356102KG _M535610S 1.2 2kg spool _{6kg spool} M5356122KG _M535612S 1.6 6kg spool M535616S

-SO

LID

MI

G WIR

ES

A

LUMINIUM

(46)

SUMMARy

• Gas Shielded, Metal-Cored Wire • Slag-Free Weld Bead

• Higher Deposition Rates • Low Spatter/Smooth Appearance • Better Fusion Profile

CLASSIFICATION

• AS/NZS ISO 17632-B - T 492T15 0MA-UH5 • AWS A5.18: E70C-6M

Austfil 70C-6M is a metal-cored wire designed for high speed fillet and butt welding in the downhand position using Argon + 18-25% CO₂ shielding gas mixture. Weld beads are almost completely slag free with only minimal silicon islands, reducing the time and effort spent between runs and on cleanup prior to surface finishing.

Austfil 70C-6M is recommended for single and multi pass welding in both flat and horizontal positions for mild steel, carbon and maganese carbon steels with minimum clean up and where high deposition rates and efficiencies are required in high productivity, semi automatic and fully automatic welding installations. Suitable applications include mining buckets, structural fabrication and tank construction where high speed welding is required.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 1.2 200-350 29-35 1.6 300-450 27-34

(47)

LR 3S, 3YS

C Mn Si S P Cu Fe

0.038 1.46 0.68 0.009 0.012 0.02 Bal

Gas Type Ar+25%CO₂ Yield Stress 628 MPa Tensile Stress 587 MPa Elongation 29% CVN Impact Values 51J @ -20ºC

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 15kg spool 70C6M12S 1.6 15kg spool 70C6M16S 1.2 250kg drum 70C6M12D

-ME

TAL

C

OR

ED

G

AS S

HIEL

DED

WIR

ES

(48)

SUMMARy

• All Purpose Rutile Flux Cored Wire • For Both Single or Multiple Pass Welds • All Positional Wire

• Formulated Exclusively For CO₂ Gas

CLASSIFICATION

• AS/NZS ISO 17632-B - T492T1-1CA-UH10 • AWS A5.20: E71T-1 H8

Austfil 71T is a rutile flux cored wire designed for excellent performance in all positional fillet and butt-welding applications. Austfil 71T is formulated exclusively for use with cost effective CO₂ shielding gas.

Austfil 71T is recommended for general purpose all positional welding of mild, carbon and carbon-manganese steels where excellent weld profile and penetration is required. Suitable for applications such as storage tanks, structural fabrication, bridge construction, machinery and earthmoving equipment. Suitable for AS/NZS 1554.5 of the structural code; Part 5: Welding of the steel structures subject to high levels of fatigue loading.

WIRE

Welding parameters shown above are for DC electrode positive using 100% CO₂ shielding gas at a flow rate of 15-20 litres/minute. *Voltage is determined by arc current and wire arc length.

(49)

LR 3S, 3YS

C Mn Si S P Fe

0.03 1.28 0.44 0.01 0.013 Bal

Gas Type CO₂ Yield Stress 531 MPa Tensile Stress 580 MPa Elongation 26% CVN Impact Values 93J @ -20ºC

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 15kg spool 71T112S 1.6 15kg spool 71T116S

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

(50)

SUMMARy

• Rutile Type Flux Cored Joining Wire, Micro Alloyed • Formulated Exclusively for use with Ar/CO₂ Shielding Gas Mixtures

• Excellent Operator Appeal “Smooth Spray Arc Transfer” • Versatile all Positional Capabilities

• Grade 3 Weld Metal Impact Properties

CLASSIFICATION

• AS/NZS ISO 17632-B - T492T1-1MA-UH10 • AWS A5.20: E71T-1M

An all positional rutile micro alloyed type flux cored welding wire specifically formulated for optimum performance using Ar/CO₂ shielding gas mixtures.

The exceptionally smooth arc performance produces a superb weld for single or multipass welding with low spatter losses in all positions and applications (except vertical down). Austfil 71T-1M is recommended for the welding of mild, carbon and carbon-manganese medium steels where good impact properties at -20°C are required.

This high deposition wire offers excellent operator appeal for general steel fabrications and constructions such as plate sections, beams, girders, truck chassis/bodies, shipbuilding, earth moving equipment, storage tanks, bridge construction etc.

Recommended shielding gases are: Argon + 18-25%CO₂

(51)

WIRE

SIZE (mm) POSITIONWELD WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 1.2 Flat Flat Fillet

Vertical - up 250-300 230-280 170-220 29-35 28-30 24-28 1.6 Flat Flat Fillet

Vertical - up 300-350 200-350 200-250 28-34 24-34 26-28 Recommended electrical stick out is 15-20mm.

Welding Current DC +

*Voltage is determined by arc current and wire arc length. Welding currents and voltage shown are operational guides only.

LR 3S, 3YS

C Mn Si S P B Fe

0.04 1.20 0.42 0.012 0.013 0.001 Bal

In as welded condition

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PALLET SIZE (KG) PART NUMBER 1.2 15kg spool 1080 71T1M12S 1.6 15kg spool 1080 71T1M16S

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

(52)

SUMMARy

• Low Diffusible Hydrogen

• Excellent Toughness at Low Temperatures • Outstanding Weldability

• Exceeds 27J CVN @ -40℃

CLASSIFICATION

• AS/NZS ISO 17632-B - T494T1-1MA-UH5 • AWS A5.20: E71T-1M, E71T-12MJ H8

A rutile flux cored all position wire designed for welding mild and carbon steels, especially when good impact toughness is required at sub zero temperatures. Ideal for single and multi-pass applications, it delivers outstanding welding performance and produces high quality X-ray clear weld deposit with a bead contour that is flat to slightly convex. It can be used over rust, mill scale and some primers with no pre-cleaning of the steel necessary. Formula XL-525 has outstanding mechanical properties that resemble those of E7018 MMAW (SMAW) electrodes, plus high operator appeal with low fume levels, low spatter and easy slag removal. Recommended for ship building, storage vessels, off-shore structures, earth moving equipment and pipe welding.

(53)

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 1.2 150-300 24-31 1.6 200-350 24-34 Recommended electrical stick out is 15-20mm. Welding Current DC +

LR 3S, 3YS; ABS 3SA, 3YSA Impact @ -40̊C 34 ft, lbs

DNV Y40MS BV 3YM; CWB E491T-12MJ-H4;

C Mn Si Ni Fe

0.04 1.24 0.29 0.37 Bal

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 15kg spool S283212-029 1.6 15kg spool S283219-029

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

(54)

SUMMARy

• Low Diffusible Hydrogen • Exceeds 27J CVN @ -40℃

• Outstanding Weldability in all Positions • Actual Certification to AWS A5.01 Lot Class: T3

CLASSIFICATION

• AS/NZS ISO 17632-B - T494T1-1CA-UH5 • 1.2mm, AWS E71T-1C, E71T-12CJ H4 • 1.6mm, AWS E71T-1C, E71T-12CJ H8

Formulated to provide extremely low hydrogen levels. This outstanding all positional wire produces a high quality X-ray clear weld deposit with high impact values at low temperature. Every batch of the TM-71HYD is actual tested to certify the quoted mechanical property, and the vacuum sealed packaging further ensures the product integrity upon delivery.

Applications include ship building and repair, earth moving equipment, structures, pressure vessel and storage vessels.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 1.2 100-350 22-34 1.6 200-350 24-34 Recommended electrical stick out is 15-20mm. Welding Current DC +

(55)

MIL-71T-1-HYD

C Mn Si S P Ni Fe

0.05 1.17 0.25 0.014 0.12 0.5 Bal

Gas Type 100% CO₂ Yield Stress 533 MPa Tensile Stress 585 MPa Elongation 26.6% CVN Impact Values 150J @ -18ºC 137J @ -40ºC Aged 48 hours @ 104ºC In as welded condition. PACKAGING DATA WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 15kg spool S245112-K53 1.6 15kg spool S245019-K53

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

(56)

SUMMARy

• Fast-Freezing Slag • Low Spatter

• Excellent Arc Characteristics

• High Impact Strengths at Low Temperatures

CLASSIFICATION

• AS/NZS ISO 17632-B - T555T1-1C/MA-2Ni-UH5 • AWS A5.29: E81T1-Ni2C/MJ H8

Offers excellent arc stability and low spatter using either CO₂ or Ar/CO₂ mixtures with up to 80% Argon. These weldability features, combined with low diffusible hydrogen levels and good impact values makes the wire a good choice for single and multiple pass welding in all positions.

Applications include ship building, offshore drilling rigs, HSLA steels and weathering steels with no colour match requirement..

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 1.2 100-350 22.34 Recommended electrical stick out is 15-20mm. Welding Current DC +

(57)

ABS 3YSA; DNV Y40MS; LR 3Ys

Shielding Gas C Mn Si P S Ni

100% CO₂ 0.04 1.02 0.29 0.010 0.007 2.09 75% Ar/25% CO₂ 0.05 1.26 0.44 0.010 0.007 2.07

Gas Type 100% CO₂ 75% Ar/25% CO₂ Yield Stress 535 MPa 579 MPa Tensile Stress 600 MPa 662 MPa Elongation 27.5% 26% CVN Impact Values 126J @ -40˚C 95J @ -51˚C 104J @ -40˚C 71J @ -51˚C In as welded condition. PACKAGING DATA WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.2 15kg spool S283712-K29

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

(58)

SUMMARy

• Self Shielded or “Gasless” Flux Cored Joining Wires • For Fast Downhand Fillet and Butt Welding Applications • Excellent Bead Appearance/Low Spatter Levels

• Crack Resistant Weld Deposits/Tolerant to Poor Joint Fit-up

CLASSIFICATION

• AS/NZS ISO 17632-B - T49ZT4-0NA-H15 • AWS A5.20: E70T-4

Fabshield 4 is an outstanding, high deposition rate, (up to 12.7kg/ hr using 2.4mm size wire) self-shielded or “gasless” flux cored wire for downhand single or multi-pass welding applications. It is specifically designed to de-sulphurise the weld deposit and thereby resist cracking. Fabshield 4 is particularly suited to the fast fillet welding of mild and medium strength steels. Typical applications include the welding of structural members and machinery. Due to its self shielding arc, Fabshield 4 is ideal for “on site” field construction and repair applications.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V) 2.4 250-500 28-34 3.0 450-680 28-37 Welding Current DC -

(59)

C Mn Si P S AI Fe

0.27 0.73 0.30 0.11 0.005 1.42 Bal

Yield Stress 432 MPa Tensile Stress 652 MPa Elongation 25% CVN Impact Values Not Required

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 2.4 22.7kg spool S224529-014 3.0 22.7kg spool S224541-014

-FLU

X CORE

D SE

LF SH

IEL

DE

D W

IRES

(60)

SUMMARy

• Self Shielded or “Gasless” Flux Cored Joining Wires • All Positional Welding Capabilities

• Suitable for Single-Pass Applications only • Ideal for Mild and Galvanized Steels

CLASSIFICATION

• AS/NZS ISO 17632-B - T49ZTG-1SNA • AWS A5.20: E70T-GS

Fabshield 23 is a general-purpose self-shielded tubular wire that is designed for welding thin gauge mild or galvanized steel. Suitable for single-pass applications, especially for fillet lap welds, you will get outstanding welding performance as Fabshield 23 produces a smooth spray arc type of transfer with goods wetting action.

Great for welding outdoors in draughty conditions, this all-positional wire also provides very low splatter levels, resulting in a weld bead that is excellent in appearance. Perfect for on site applications such as welding mild steel/ galvanized gates, fences, frames, sheds, prefab building fabrications, ornamental ironwork, general fabrication, etc.

WIRE

SIZE (mm) WELDING CURRENT RANGE (A) ARC VOLTAGE RANGE *(V)

TyPICAL STICKOUT (mm) 0.8 25-125 14-16 12 0.9 55-120 17-20 12 Welding Current DC -

*Voltage is determined by arc current and wire arc length.

(61)

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

C Mn Si S P AI Fe

0.18 0.65 0.40 0.01 0.01 1.30 Bal

Tensile Stress 572 MPa

NOTE: Yield Stress and impact values not applicable.

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.8 4.5kg spool S222306-022 0.9 4.5kg spool S222308-022 0.9 15kg spool S222308-029

(62)

SUMMARy

• Self Shielded or “Gasless” Flux Cored Joining Wires • All Positional Welding Capabilities

• Suitable For Single Pass/Multi-pass Applications • Suitable for Mild/Galvanised Steels

CLASSIFICATION

• AS/NZS ISO 17632-B - T49ZT11-1NA-H15 • AWS A5.20: E71T-11

Fabshield 21B is a general purpose self-shielded tubular wire that is designed for single and multi-pass welding of thin gauge to 20mm thick mild or galvanized steels. Great for welding fillet or lap welds, you will find that this all-position wire has high operator appeal, producing a smooth spray-like transfer with low spatter levels, excellent weld appearance and easy to remove slag. Perfect for on-site applications such as the welding of machine parts, galvanized steels tanks, gates, frames, sheds, prefab construction, light structures, general fabrication etc.

Welding parameters shown below are for DC Electrode negative only.

WIRE

TyPICAL STICKOUT (mm) 0.9 55-120 17-20 12 1.2 130-160 15-18 12 1.6 150-250 18-20 19 2.0 200-300 16-23 19

FABSHIELD

21 B

(63)

-FLU

X CORE

D G

AS SH

IEL

DE

D W

IRES

C Mn Si S P AI Fe

0.28 0.34 0.15 0.008 0.003 1.04 Bal

Yield Stress 427 MPa Tensile Stress 627 MPa Elongation 22% CVN Impact Values Not Required

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 0.9 4.5kg spool S222108-022 1.2 4.5kg spool S222112-022 1.2 15kg spool S222112-029 1.6 15kg spool S222119-029 2.0 15kg spool S222125-029

(64)

SUMMARy

• Welds Out of Position at High Currents • Low Hydrogen Weld Deposit • Excellent Slag Removal • No Shielding Gas Required

• High Impact Strength at Low Temperatures • Excellent Mechanical Properties Under a Wide Range of Heat Input

CLASSIFICATION

• AS/NZS ISO 17632-B - T494T8-1NP-H10 • AWS A5.20: E71T-8JD H8

Low hydrogen T-8 self-shielded, all positional flux cored wire, producing a stable arc and flat bead profile, especially suited for vertical-up welds at high currents with excellent mechanical properties and a tensile strength of 490 MPa. Capable of depositing X-ray quality welds, making it highly suitable for critical welding applications requiring a high degree of crack resistance due to its low diffusible hydrogen levels, less than 6.7ml per 100g of weld metal deposited. XLR-8 has been designed for single and multi-pass welding applications with improved productivity in out-of-position welding, offering high impact strength of (42J) at sub zero temperatures to -40˚C. Specifically designed for increased productivity and high deposition rates on challenging structural steel erection, heavy equipment repair, mining equipment, bucket repairs, storage tanks, pipe spooling, ship construction and site work applications.

WIRE

(65)

-FLU

X CORE

D SE

LF SH

IEL

DE

D W

IRES

ABS 3YSA; AWS D1.8 Conformance

C Mn Si P S AI Fe

0.19 0.51 0.17 0.009 0.006 1.51 Bal

Yield Stress 470 MPa Tensile Stress 580 MPa Elongation _25% CVN Impact Values 42J @ -40˚C

Diffusible Hydrogen 6.7ml/100g of weld deposited

PACKAGING DATA

WIRE

SIZE (mm) PACK SIZE AND TyPE PART NUMBER 1.6 15kg spool S225719-053 1.8 15kg spool S225724-053 2.0 15kg spool S225725-053 2.0 22.7kg coil S225725-014

(66)

(67)

HARDFACING ELECTRODES Abrasocord 43 ... 66-67 Abrasocord 350... 68-69 Abrasocord 700... 70-71 Tubecord D - 2355 ... 72-73 Tubecord E - 2460 ... 74-75

HARDFACING SOLID MIG WIRES

Austmig TD-600 ... 76-77

HARDFACING SELF SHIELDED FLUX CORED WIRES

Mckay Tube-Alloy 240-0... 78-79 Mckay Tube-Alloy 258-0... 80-81 Mckay Tube-Alloy A43-0 ... 82-83

HARDFACING GAS SHIELDED FLUX CORED WIRES

Mckay Vertiwear-600 ... 84-85

(68)

SUMMARy

• Tough, Wear Resistant Complex Carbide Type Deposit • For Hard Surfacing Components Subjected to Extreme Abrasion and Moderate to Heavy Impact

• Similar Deposit Type to Tubecord E-2460

IDENTIFICATION

Coating - Black Tip - Plain Imprint - WIA AC 43

CLASSIFICATION

• AS/NZS 2576: 2465-A4

Abrasocord 43 is a heavy coated, hard surfacing electrode depositing extremely hard, abrasion resistant Chromium/ Niobium carbides in an austenitic matrix. It is ideal for hard surfacing applications where resistance to extreme abrasion (in particular sliding abrasion) and moderate to heavy impact are required. Due to the nodular shape of the complex carbides, Abrasocord 43 deposits are capable of withstanding heavier impact levels than standard chromium carbide grades. Typical applications include bucket teeth/lips, grizzlies, press screws, crusher hammers and ripper teeth to name but a few. Abrasocord 43 deposits are non-machineable, grindable, prone to fine relief checking and should be restricted to 3 layers high. While two layers of Abrasocord 43 may be required for maximum wear resistance, this complex carbide alloy has lower dilution sensitivity than straight chromium carbide deposits.

ELECTRODE

(69)

ACI

NG

P

RODUC

TS

-HARDF

ACI

NG

EL

EC

TRODES

C Mn Cr Nb Fe

5.0 0.7 22.0 7.0 Bal

Single Layer onto Mild Steel Typical Hardness 60-65 HRc Multi-Layer Typical Hardness 64-69 HRc

Single layer deposit hardness may vary depending on base metal type and degree of dilution

PACKAGING DATA ELECTRODE SIZE (mm) PACKAGING (KG) APPROX NO. OF RODS PER KG PART NUMBER Packet Carton 3.2 5 15 16 AC4332 4.0 5 15 11 AC4340 5.0 5 15 6 AC4350
