Datacentre
South Gyle 1
South Gyle Datacentre
With 10 datacentres, over 4,500 racks and a 10Gb resilient core network
between our datacentre locations, Pulsant has the infrastructure to
support you.
Tier 3 Datacentre site 15 minutes outside Edinburgh servicing a wide range of business critical systems for Scottish customers and major telecommunications hub.
A high performance datacentre with diverse power feeds, just outside Edinburgh. A Tier 3 designed facility, ISO 27001, ISO 9001 accredited and PCI compliant.
Find out how we can help your business:
call
0845 119 9911
The Clocktower Estate South Gyle Cresent Edinburgh EH12 9LB Scotland
Find us
Datacentre
South Gyle 1
Site Overview
Capacity - Supporting a total of 612 racks in 42U or 48U 600mm x
1,000mm up to dual 32A diverse power supplies. From ½ rack options and above.
Configuration - 15 Secure Data Halls – data halls from 60m²,
available in Amp, kW per m², kW per annum and kWh models in singular rack, caged or dedicated halls to custom builds. IL2, IL3 and PCI DSS compliant facility.
Support - 24x7 on-site remote hands, monitoring and support
available to all customers. On-site Cloud, Government Cloud, Managed Services and Colocation.
Security - Secure 24x7 manned security entrances with HD CCTV
cameras, PAC access controlled into each area of the site.
Power - 6,800kVA diverse 11kV incoming supplies from SPEN to two
on-site substations and redundant transformers. Power delivery is 2N to each rack in the site.
Cooling - Blended Chilled Water, Free Air and DX redundant cooling
solutions to 1,800kW.
UPS - 2N Blended Emerson Chloride units with up to 15 minutes
autonomy to 2,800kW.
Standby Generation - 2 x Cummins 1,400kVA Standby Rated + 1 x
South Gyle P1 site colocation propositions
Rack Capacity - 612 1U Server 1/4 Rack 1/2 Rack Full Rack Oversized Rack Dual PDU Cage Suite 1Mb - 1Gb Transit Dark Fibre Site Backhaul Carriers - 20+ PCI-DSS SP 2.0 ISO 27001:2013 Managed Server Colocation BackupDC Connectivity On-Net Services - SSE, Vtesse, BT, Cogent,
Vodaphone, Geo Networks, AT&T, EasyNet, Level 3, Verizon, T-Systems, Neos, Virgin Media, JANET, Fluency, IXScotland and many more.
Data sheet
Technical specification
Data sheet South Gyle 1 Datacentre
South Gyle P1 site specifications
Total Technical DC Sq Ft - 31,000No of Data Halls - 15 Total Rack Capacity - 612 Building Floors - 2 Floor Void - 600mm Tier Rating - Tier 3
Total Power Provision - 6.8MVA/6,000kW Total Power Protection - 2N+1
Total UPS Provision - 14.28MVA/12,850kW Total UPS Protection - 2N+1
Rack Provision - Single 16Amp or 32Amp - 3Phase Total Generator Provision - 2N+1
Total Generator Protection - N+1
Total Generator Fuel Storage - 50,000 Litres Total Cooling Provision - 1,800kW
Total Cooling Protection - N+1
Cooling Type - Chilled Water/DX and Free Cooling CCTV - Total Cameras - 48 Cameras
CCTV - Retention Period - Minimum 90 Days
Access Control - Type - Swipe Entry/Exit External Doors Swipe & PIN Access Control - Retention Period - Minimum 12 Months
Fire Protection Systems - Floor and Ceiling Sensors
Fire Suppressant Systems on-site - Inergen, IG451 and FM200
“
With Pulsant, we have access to secure
enterprise class datacentre facilities without
unnecessary capital expense”.
GRAHAM STOTT – IT DIRECTOR AT AWARD WINNING FINANCIAL SERVICE COMPANY, 7IM.Find out how we can help your business:
call 0845 119 9911 Cadogan House, Rose Kiln Lane Reading, RG2 0HP [email protected]
Backed by our Triple A Support
24/7/365 Technical Support - One call takes you straight through to
our dedicated technical teams at a Pulsant datacentre in the UK.
Skilled system and network admin - All Pulsant’s operatives are
industry qualified and experienced.
Our aim is first time every time - Rapid triage and escalation
Energy is vital to power and cool servers, we reduce energy
consumption and costs by using ultra-efficient systems and advanced cold aisle and pod technology.
Pulsant have built a number of client facilities into the site to ensure any time you spend on-site is comfortable. There is ample provision for client IT staff who may be required on-site, this includes parking, rest rooms, kitchen, build facilities, dedicated offices and meeting rooms.
