Datacentre
South London
South London Datacentre
With 10 datacentres, over 4,500 racks and a 10Gb resilient core network
between our datacentre locations, Pulsant has the infrastructure to
support you.
Tier 3 Datacentre site 20 minutes from Central London, 10 minutes to East Croydon Station, 17 minutes to Victoria Station, 22 minutes to London Bridge servicing a wide range of business critical systems for financial services, telecoms and retail customers.
A high density colocation facility, designed to criteria 1.3 PUE, making Croydon one of the most efficient market leading Datacentres in the UK.
Find out how we can help your business:
call
0845 119 9911
Unit 1, 35 Imperial Way Croydon London CR0 4RR United Kingdom
Find us
Datacentre
South London
Site Overview
Capacity - Supporting a total of 308 racks in 42U or 48U 600mm x
1,000mm up to dual 10kW diverse power supplies. Available from ¼ rack to caged environments.
Configuration - 2 Secure Data Halls – data halls available in Amp, kW
per annum and kWh models in singular rack to caged configurations. A PCI DSS compliant facility with expansion capacity for up to 1,200 further racks.
Support - 24x7 on-site remote hands, monitoring and support
available to all customers. On-site Cloud, Managed Services and Colocation.
Security - Steel perimeter fencing, secure 24x7 manned security
entrance with HD CCTV cameras, PAC access controlled into each
Power - 3.25MVA incoming supply from SSE to on-site substation and
resilient HV network and TFX. Option for further 6MW from a separate substation via 11kV resilient ring supply to the site to support expansion. Power delivery is N+1 to each rack on the site.
Cooling - Blended Fresh Air technologies and Variable DX redundant
cooling solutions to 1,400kW.
UPS - 2N+1 Blended Emerson and MGE Galaxy units with up to 30
minutes autonomy.
Standby Generation - 2 x FG Wilson 2,250 kVA Prime Rated units in
South London site colocation propositions
Rack Capacity - 308 1U Server 1/4 Rack 1/2 Rack Full Rack Oversized Rack Dual PDU Cage Suite 1Mb – 1Gb Transit Dark Fibre Site Backhaul Carriers - 6 PCI-DSS SP 2.0 ISO 27001:2013 Managed Server Colocation BackupDC Connectivity On-Net Services - BT, Virgin Media, SSE, GEO,
Vodafone, and Colt
Data sheet
Technical specification
Data sheet South London Datacentre
South London site specifications
Total Technical DC Sq Ft - 28,000No of Data Halls - 2 Total Rack Capacity - 308 Building Floors - 2 Floor Void - 800mm Tier Rating - Tier 3
Total Power Provision - 3.3MVA/2MW Total Power Protection - N+1 Total UPS Provision - 2.25MVA/2MW Total UPS Protection - N+1
Rack Provision - Dual 16 or 32Amp – 3Phase up to 32Amps Total Generator Provision - 4.50MVA/4MW
Total Generator Protection - N+1
Total Generator Fuel Storage - 15,000 Litres Total Cooling Provision - 1,400kW
Total Cooling Protection - N+1 Cooling Type - DX
CCTV - Total Cameras - 48 Cameras CCTV - Retention Period - Minimum 90 Days
Access Control - Type - Swipe Entry/Exit External Doors Swipe & PIN Access Control - Retention Period - Minimum 12 Months
Fire Protection Systems - Floor and Ceiling Sensors/VESDA system Fire Suppressant Systems on-site - Argonite + (IG55) FM200
“
With Pulsant, we have access to secure
enterprise class datacentre facilities without
unnecessary capital expense”.
GRAHAM STOTT – IT DIRECTOR AT AWARD WINNING FINANCIAL SERVICE COMPANY, 7IM.Find out how we can help your business:
call 0845 119 9911 Cadogan House, Rose Kiln Lane Reading, RG2 0HP [email protected]
Backed by our Triple A Support
24/7/365 Technical Support - One call takes you straight through to
our dedicated technical teams at a Pulsant datacentre in the UK.
Skilled system and network admin - All Pulsant’s operatives are
industry qualified and experienced.
Our aim is first time every time - Rapid triage and escalation
Energy is vital to power and cool servers, we reduce energy
consumption and costs by using ultra-efficient systems and advanced cold aisle and pod technology.
Pulsant have built a number of client facilities into the site to ensure any time you spend on-site is comfortable. There is ample provision for client IT staff who may be required on-site, this includes parking, rest rooms, kitchen, build facilities, dedicated offices and meeting rooms.
