QbD based Development and Characterization of a Cell Culture Process for Therapeutic Proteins

(1)

QbD based Development and

Characterization of a Cell Culture

Process for Therapeutic Proteins

2015. 06. 09

Green Cross Corp.

Green Cross Research Center

Yong Jae Kim ([email protected])

(2)

Agenda

• _{Company Introduction}

• QbD and Cell Culture Process Development

(3)

1967

1971

1983

1988

1993

2009

Production of the Nation’s First Plasma Fractionation Product

World’s 1st Epidemic Hemorrhagic Fever Vaccine (

Hantavax

)

World’s 2nd Varicella Vaccine (

Suduvax

)

Established as Sudo Microorganism Medical Supplies Co.

Hepatitis B Vaccine for the 3rd Time in the World

(Hepavax

)

Approval of Seasonal Influenza Vaccine (

GC Flu

)

H1N1 Influenza Vaccine (

GreenFlu

)

2009

_{Construction of Ochang Plant for Bioproducts}

2009

Construction of Hwasun Plant for Vaccine Products

2010

Approval of Recombinant Human Factor VIII (

GreenGene F

)

2011

_{Approval of}

_Shinbaro

₍

_{Herbal Drug}

₎

2012

_{Approval of}

_Hunterase

₍

_{Hunter Syndrome}

₎

2013

_{Construction of R&D Center}

(4)

Sales Trends

Established

IPO(KOSPI)

Employees

Market Capital

1967

1978

1,500

$1.37B

2013

$807M

2014

$887M

$950M

Operating

Profit

$71.6M

$84.6M

$85.4M

2015(E)

(5)

Investment in R&D

2013

2014

2015(E)

$71M

$80M

$91M

8.8%

9.0%

9.6%

R&D Spending

as a % of Sales

Sales Composition

R&D Spending

PD

32.5%

Vx

31.6%

Rx

19.4%

Others

16.5%

(6)

Seoul

Ochang Plant

Eumseong Plant

Hwasun Plant

Head Office and R&D Center

Yongin

Facility Overview

- Plasma Fractionation

- Recombinant

- Vaccine (FLU and

Others)

(7)

R&D Capability

Recombinant Protein

Vaccine

Antibody Engineering

Plasma Fractionation

(8)

What is Quality by Design?

QRM

DOE

MVDA

Statistics

Process

Understanding

Risk Assessment

Design Space

QbD

Systematic

Approach

(9)

Overall QbD Approach

European Journal of Pharmaceutics and Biopharmaceutics 81 (2012) 426-437

FDA’s “GMPs for the 21

st

Century” and the PAT initiative

QbD related guidelines

ICH Q8, 9, 10, 11

(10)

Systematic approach to Applying QbD

(11)

Upstream Process Development

(12)

Upstream Manufacturing Process

(13)

Cell Culture Process Operating Parameters

Affect Process Performance & Product Quality

(14)

Identification of Operational Parameters

• Potential Critical Process Parameters in Cell Culture Production

–

Temperature

–

pH

–

Agitation

–

Dissolved oxygen

–

Medium constituents

–

Feed type and rate

(15)

Combination of Risk Assessment &

(16)

Process Development and Characterization

Case I : Flask Inoculum Expansion

• Project: Therapeutic Proteins I

• Cell line: CHO-DG44

• Medium: Commercial Medium

• Culture vessel: Shake Flask

• Culture volume: 100mL

(17)

Operational Parameters Analysis of the

Flask Inoculum Expansion

Failure Mode Effect Analysis (FMEA)

- Severity of the excursion: S

- Occurrence of the excursion: O

- Detection of the excursion: D

(18)

Design of Experiments

Run Initial VCD Temp. CO2 Duration Remarks (E5 cells/mL) (℃) (%) (hr) 1 -1 -1 -1 -1 Resolution IV 4 center points 2 -1 -1 +1 +1 3 -1 +1 -1 +1 4 -1 +1 +1 -1 5 +1 -1 -1 +1 6 +1 -1 +1 -1 7 +1 +1 -1 -1 8 +1 +1 +1 +1 9 0 0 0 0 10 0 0 0 0 11 0 0 0 0 12 0 0 0 0 13 +1 0 0 0 Augmentation Axial points 14 -1 0 0 0 15 0 +1 0 0 16 0 -1 0 0 17 0 0 +1 0 18 0 0 -1 0 19 0 0 0 +1 20 0 0 0 -1

(19)

(20)

Prediction Formulas

Response Polynomial equation of the response in terms of coded factors

Statistical significance R2_R2 _Adj_p-Value

VCD CP*+3.23A-6.09B+2.39C+4.41D-0.58AB-4.32B2_+2.06C2_{-3.08BD-4.61D}2_{0.983 0.970 <0.0001}

Viability CP*-10.57B+5.56C-2.2D-7.96B2_{+5.86BC-2.19BD-4.11D}2_{0.961 0.942 <0.0001}

A: Initial VCD, B: Temp., C: CO2, D: Duration

(21)

Design Space (Contour Plots)

(22)

Process Development and Characterization

Case II : Production Bioreactor

• Project: Therapeutic Proteins II

• Cell line: CHO-DG44

• Medium: In-house medium

• Culture system: Glass type STR

• Culture volume: 2.5 L

(23)

Failure Mode Effect Analysis (FMEA)

- Severity of the excursion: S

- Occurrence of the excursion: O

- Detection of the excursion: D

- Risk Priority Number(RPN) = S X O X D

Operational Parameters Analysis of the

Production Bioreactor

(24)

Design of Experiments

Run Temp. pH Timing of Prod. shift (℃) (E5 cells/mL) 1 -1 -1 -1 2 -1 -1 +1 3 -1 +1 -1 4 -1 +1 +1 5 +1 -1 -1 6 +1 -1 +1 7 +1 +1 -1 8 +1 +1 +1 9 0 0 0 10 0 0 0 11 0 0 0

(25)

(26)

Response Polynomial equation of the response in terms of coded factors Statistical significance R2_R2 _Adj_p-Value

Yield CP*-416A+156B+662C-439AB-327AC-435BC–901A2_{+101ABC 0.998 0.991 0.0074}

Impurities#1 CP*+1.07A+1.59B+6.04C+3.25AC+1.61BC-8.79C2_{0.937 0.843 0.0216}

Impurities#2 CP*+7207A+5040B+2401C+3425AB+967AC+700BC+5116C2 _{0.994 0.979 0.0026}

QA#1 CP*+3.72A+5.90B+1.97C-2.00AB+1.54AC–0.77BC–8.62B2_{–2.07ABC 0.999 0.999 0.0009}

QA#2 CP*+11.91A+7.92B+1.61C–0.88AB+1.55AC-0.02BC-13.39A2_{–2.51ABC 0.999 0.999 0.0009}

QA#3 CP*+8.25A+5.99B –2.11AB–12.54A2_{0.915 0.858 0.0023}

QA#4 CP*+1.1A+1.13B+0.15C–0.19AB+0.33AC+0.24BC–2.25B2_{–0.64ABC 0.996 0.982 0.0141}

QA#5 CP*+8.68A+4.83B+0.41C+0.44AB–1.52AC+3.36BC–9.07A2_{–1.23ABC 0.999 0.995 0.0040}

A: Production Temp., B: Production pH, C: Timing of production shift CP*: prediction of the response at the Center Point

Regression models for the production

bioreactor responses

(27)

X : pH , Y : Temp. X : Prod. shift timing , Y : pH X : Prod. shift timing , Y : Temp.

*NOR: Normal Operational Range

Design Space (Contour Plots)

(28)

Summary

• The concept of QbD aims at gaining a deeper knowledge of the product and

the manufacturing process starting with product development.

• Case studies describe the application of QbD principles to the flask inoculum

expansion step and the production bioreactor step of therapeutic protein,

which resulted in the definition of a design space for the cell culture process.

• Characterization studies were performed using a multi-fractional DoE

approach to determine the impact of the identified potential CPPs, both

individually and as interactions, on CQAs

• The design space was set in such a way to ensure consistent delivery of a cell

culture process for the requirements set for the therapeutic proteins.
