Solution panorama. Electrical Energy

(1)

Electrical Energy

(2)

Your requirements…

Increased power availability

Optimized solutions for power generation, transmission and distribution networks to increase power quality, to reduce SAIDI*

and network outages.

* SAIDI: System Average Interruption Duration Index

Lowest Total Cost of Ownership (TCO)

Preferred architectures for renewable energy solutions: to reduce capital costs and to increase your revenue.

Automated and remote controlled solutions: for centralized generation and distribution network to reduce operation costs.

Implementation agility

Fast implementation and easy operation: ability to scale fast, to adapt your electrical network easily and to reduce skill requirements.

(3)

18.3B¤

revenues in 2008.

120.000

people in 106 countries.

WE HELP our customers…?

To achieve more while using less.

@

To optimize their electrical network.

@

To develop their initiatives for

@

sustainable development.

WE DESIGN energy

management solutions…

Safe: Protecting people & assets.

Reliable: Delivering ultra-secured power for critical applications.

Efficient: Building integrated solutions for energy efficiency.

High-performing: Deploying lifecycle services & connectivity everywhere. Green: Implementing state of the art solutions for renewable energies.

WE ARE the privileged

partner in all the markets:

Energy & Infrastructure

@

Industry

@

Data Centres & Networks

@ Buildings @ Residential @

210

productions

sites.

…Solutions from the global

specialist in energy

(4)

Enhance electrical

(5)

Up to 50%

increase in

continuity of

service

Our full packaged solution ensures

high level of quality and reliable electrical

@

network

resilient installation at all times

@

optimized investments

@

guaranteed long-lasting installation with

@

(6)

Make the most of your Electrical Distribution Network

Panorama of Schneider Electric solutions

Wind Farm generation and connection to the grid:

Optimized productivity thanks to dedicated SCADA.

@

Smart and consistent offer to comply to your grid

@

code.

Thermal and nuclear power generation:

Enhanced installation reliability and

@

people safety.

Nuclear qualified offer for Electrical

@

Distribution and UPS.

Biosco : Prefabricated MV/LV substations

To ensure the safety of people

@

and goods.

To contribute to the network

@

continuity of service.

Small and micro hydro plants:

Cost effective architectures.

@

Global solution (power & control).

(7)

Make the most of your Electrical Distribution Network

Panorama of Schneider Electric solutions

Photovoltaic solar farm generation:

Comprehensive solution from DC/AC conversion

@

to grid connection and remote monitoring.

Primary Substation:

Simple & reliable

@ operations. Optimized maintenance. @ Reduced footprint. @ Demand response to reduce peak consumption on the network:

Software and power

@

monitoring for demand response application.

Undergound Feeder Automation:

50% of your network supply restored

@

within a few minutes thanks to a step by step solution to fit your needs in the frame of your operating budget.

SCADA Distribution Management System:

Increased continuity of service.

@

Easy network control and operation.

@

Interface with utility IT management

@

systems.

Overhead Feeder Automation:

Switchgear reliability and flexibility.

@

Powerful monitoring and analysis

@

tools.

Residential and small building solar:

Fast and sustainable ROI.

@

Power quality monitoring and revenue metering:

Improved network

@

reliability.

Lower operation costs.

(8)

Electrical energy

solutions by

(9)

Centralized generation

10-11...Thermal and nuclear

Renewable energies

12-15 ...Solar photovoltaic

16-17 ...Wind generation

18-19 ...Hydro power

T&D networks

20-21 ...Power monitoring and analysis

22-23 ...Revenue metering 24-27 ...Distribution automation 28-29 ...Primary substations 30-31 ...Secondary MV/LV substations

Energy supply

32-33 ...Demand Response

Services

34-35 ...Electrical Energy services

(10)

Main benefits of Schneider Electric solution

Complete solutions for plant

(including auxiliaries):

LV and MV electrical distribution. @

Automation. @

Global services. @

Solutions qualified for nuclear

applications:

Electrical distribution. @

UPS. @

Optimized automation architectures:

Open. @ Flexible. @ Fast to scale. @

Global service offer:

Design. @ Commissioning. @ Maintenance. @ Retrofit. @

Centralized generation

Thermal and nuclear plants

Solutions for electrical

distribution & control

Centralized thermal and nuclear generation are the main source of electrical energy in the world. With current climate situation, governments require these power plants to follow the highest standards of safety and environment. Moreover operators request the highest energy efficiency at the lowest cost.

Your key applications

Electrical distribution and control for auxiliaries:

Turbine auxiliaries: motors, pumps, protections,… @

Building power supply. @

UPS. @

Balance of plant process control:

Boiler and turbine control. @

Water treatment and desalinization. @

Combustible supply and waste @

processing.

Plant building automation:

HVAC. @

Access control. @

(11)

Adapted for

all type of

centralized

power plants:

Oil. @ Coal. @ Gas. @ Nuclear. @ HV substation230 kV20 kV 15 kV 15 kV 6.6 kV 20 kV 6.6 kV 400 kV

Plant auxiliary MV _switchboards Low voltage_switchboards Plant auxiliary

Control Room

Auxiliaries _{MV / L}V substation

Main step up _transformer 15 kV / 230 kV_{15 kV / 20 kV}

6.6 kV

G

Schneider Electric _scope

MCset & Motorpact

Centralized generation - Thermal and nuclear plants

Solution for nuclear power plants

(RCC-E & NQA-1 Qualifications)

Motor Control Centres (MCC):

Okken power switchboard @

LV electrical distribution:

LV/LV transformers @

Masterpact and Compact NS @

MV distribution and control:

MV primary cubicles MCset (up to 6,6kV) @

Trihal cast-resin MV/LV transformers @

(6,6kV/480V)

Power protection:

Gutor Uninterruptible Power Supply @

PLC Quantum. Okken

LV boards and switchgear for plant auxiliaries (Okken).

Motor starters and drives for pumps and fans (Altivar and

Altistar).

Plant process automation and supervision (Quantum PLC, Magelis HMI, V

ijeo Scada). Building automation: HVAC and access & light contro l (TAC and Pelco ranges).

Services: Design, Commissioning, Maintenance, Retrofit and Trainings.

Generator protection (Sepam relays). MV for plant auxiliaries:

switchboards, transformers, protection, power quality

, metering and filtering (MCset, CBGS, CGSet). UPS for plant continuity

of service (Gutor and APC ranges). LV process control for material handling (Quantum PLC, Scada, Magelis HMI).

Electrical distribution for a thermal power plant Ex.: combined cycle gas plant

(12)

Renewable energies

Solar photovoltaic

Electrical distribution and control:

For photovoltaic solar farms (from LV DC up to MV grid

@

connection including monitoring, supervision, security and services).

Complete and coherent solutions:

Power conversion.

@

Grid connection.

@

Supervision and monitoring.

@

Long term maintenance services

(20 years).

Time to market optimized.

@

Modular and industrialized solutions.

@

Local everywhere.

@

Efficiency and reliability:

Supervision and monitoring platforms

@

are dedicated to solar applications.

Extensive range of inverters:

Xantrex range from 100 kW to 500 kW.

@

97,5%

availability level

ensured for

20 years.

Solutions for Solar Farms

Solar photovoltaic generation is an alternative to answer the increasing demand of energy. Moreover, it is a clean renewable energy with no emission impact to the environment. Schneider Electric provides the complete solution from DC to grid connexion, including supervision and security.

(13)

Turnkey solution includes:

Solar panel movement control

M340 PLC, Lexium drives

@

DC low voltage

Range of array boxes

@

Power conversion substation

Xantrex inverter range

@

LV AC protection, LV/MV Oil and Cast

@

resin transformers MV Cubicles (RM6, SM6)

@

Grid connection substation

Power quality and revenue metering

@

(ION software and hardware) MV cubicles (AIS and GIS)

@

Monitoring and supervision

Power meters PM800, W325 gateway

@

and Kerwin Scada

Schneider Electric dedicates its

competency to the development of solar photovoltaic renewable energy solutions.

Renewable energies - Solar photovoltaic

Photovoltaic solution for Solar Farms

Video CCTV and access control

Pelco and TAC ranges

@

Services:

Design, commissioning and retrofit

@

(14)

Renewable energies

Solar photovoltaic

Electrical distribution and control:

For photovoltaic solar Residential and Small buildings

@

(from LV DC to grid connection).

Combined offer including energy efficiency and

renewable energy.

Designed for grid connected installations and for backup

@ or off-grid installations.

Easy to use:

Quick installation. @ Low maintenance. @

Up to

100%

of energy bill

reduction.

Solutions for Residential

& Small buildings

Investing in a photovoltaic installation for residential or small buildings allows to participate actively to the protection of the environment.

Thanks to the reselling of electricity you get fast ROI.

(15)

Photovoltaic solution for Residential & Small buildings

SunEzy and Xantrex solutions include:

1

Junction boxes.

2

Surge arresters for protection against lightning strokes.

3

Protection enclosures for installation security and safe maintenance.

4

Photovoltaic inverters (DC to AC conversion).

5

Control software for monitoring and communication functions.

6

Grid interface.

Schneider Electric leadership in power conversion and electrical distribution guaranties the quality, reliability and protection of the installation.

1 4 3 2 5 6

0,5

kg/kWh

of carbon

emission

savings.

Renewable energies - Solar photovoltaic

Protection enclosure.

(16)

Renewable energies

Wind generation

Solutions for wind farms

& wind turbines

Clean, emission free… All the components of wind power are seen as an obvious answer to the global crisis of energy security and climate changes. The planet says thank you!

Your key applications

Wind farms:

Solution for all aspects of the electrical operation and control, from design

@

to commissioning (local MV network, connection to the grid, control and supervision).

Wind turbines:

A wide range of products to make the design and manufacturing of turbine nacelles

@

as efficient as possible (main power circuit, auxiliary circuits, control of wind turbine).

Reduced capital and operation costs:

Faster ROI.

@

Maximize power generated with a small

@

investment.

Quick intervention on-site.

@

Maintenance cost reduction.

@

Lower cost/kWh produced.

@

Main benefits of Schneider Electric solution

Enhanced quality of service

and network reliability:

Reduced outage time.

@ Increased revenue. @

100%

of power quality

standards

achieved.

(17)

Renewable energies - Wind farms and wind turbines

Schneider Electric solutions for wind farms are dedicated to interconnect the turbines to the electric utility grid through substations. Specific solutions for wind turbines provide the turbine auxiliary control and the LV/MV electricity protection, conversion and transformation.

Solution for Wind farms

LV/MV step-up substations:

SM6, RM6, DVCAS36 and CAS36

@

cubicles, Trihal cast resin transformers

Grid connection substations:

AIS and GIS cubicles (CBGS, MCset),

@

Sepam protection relays, ION power quality

LV boards for auxiliary supply

Prisma LV board @

Remote control:

T200 RTU @

Supervision:

Scada systems (local and remote)

@

Access control and video

monitoring:

TAC and Pelco ranges

@

Services:

Engineering @ Project study @

Development and commissioning

@

Retrofit

@

Solution for Wind turbines

& auxiliaries

For wind turbine:

LV contactors (Tesys)

@

Circuit breakers (Compact)

@

Converters (Xantrex)

@

Step up LV/MV transformers (Trihal)

@

MV & LV capacitors banks

@

Medium Voltage cubicles (SM6, RM6,

@

DVCAS36, CAS36) Kiosks (Biosco)

@

For turbine control auxiliaries:

Speed drives (Altivar)

@

Auxiliary Circuit Contactors (Tesys)

@ Capacitor Control @ Switchboards (Prisma) @ PLC (M340) @ HMI (Magelis) @ Tesys T. MV Capacitor. DVCAS36.

(18)

Renewable energies

Hydro power

Solutions for Micro & Small

plants

From several kW up to tens of MW, micro and small hydro power plants are a perfect alternative to centralized power plants. They require safe and cost

efficient solutions for control and electrical distribution.

Your key applications

Micro hydro power plants:

Lower than 1MW.

1 turbine generator unit or several small generators (multi site) and local control.

Main applications:

Turbine-Generator unit management.

@

Protection of generator set.

@

Synchronization to grid network.

@

HMI and remote monitoring.

@

Small hydro power plants:

Between 1MW and 30MW.

1 and more turbine generator units (multi site) and remote control.

Main applications:

Control of auxiliaries: pumps, ventilations, batteries.

@

Protections and monitoring: generator circuit protection,

@

transformer protections, power monitoring.

Control of parameters: water levels, flow, valves, temperature,

@

oil levels, cooling systems.

Generators / turbines: start up, synchronization, regulation

@

(speed, voltage).

For Micro hydro power plants:

Cost effective and compact solution.

@

“Plug and play”.

@

Advanced remote control: communicate

@

and manage alarms and data.

For Small hydro power plants:

Easy to integrate, implement, and operate.

@

Cost competitive (reducing cabling cost).

@

Reliable and high availability solution.

@

Global solution: power and control.

@

Efficient plant management.

@

Open and easy to extend.

(19)

Local display

Remote I/O Extension or PLC

Ethernet Network

ADSL Maintenance_operator

Automation and control, food gate, valves, temperature, oil…

Pump, motor,

starter… Generator, transformer, circuit breakers

HT protection unit GSM/GRS, PSTN, Radio, LL 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

G

E

Generator exitation control

Renewable energies - Hydro power

Automation architecture of Schneider Electric global solution. It is pre-tested for Micro and Small hydro power plants.

1 _{Remote control Web navigator or SCADA.} 2 Programmable Logic Controller M340. 3 Magelis Touch screen HMI.

4 ETG 3000, W315, W320, W325 gateways. 5 Advantis STB or M340 - optic fiber connection for

long distance.

6 Instrumentation flow water level. 7 Valves, gates, deflectors, injectors.

8 Ventilation, grease bearing system with motor starter (Tesys) & Speed drives (Altivar).

Electrical distribution for auxiliary

supply and step-up substation:

AIS and GIS cubicles, protection relays,

@

power quality, transformers, LV boards

Automation and supervision:

Generator synchronization and

@

protection

Control of motor and pumps (auxiliaries)

@

Supervision (PLC), monitoring (HMI)

@

and remote control

Access control and video monitoring

@ SM6. Masterpact. W325.

Services:

Engineering @ Development @ Commissioning @ Retrofit @

Solution for Micro and small hydro power plants

9 Synchronizer, protection & monitoring module. 10 Sepam digital relay, cubicles, transformers. 11 Remote data acquisition W310.

12 Power house webcam control. 13 Ethernet IP network.

14 Switch.

(20)

T&D networks:

Power monitoring and analysis

Solutions for Power quality

How to save time, cost and energy? How to optimize power quality?

These are the main stakes that every T&D network meets in term of monitoring and power data analysis.

Monitoring & power quality analysis of T&D networks.

Identify the cause of the event:

Classify events for filtering and reporting.

@

Group events to identify problems.

@

Detect disturbance direction.

@

Create views and reports of: Customer/

@

Utility-caused events, Planned/ Unplanned events, Weather events.

Show improvement to your customer:

Benchmark system performance.

@

Trend performance over time.

@

Support performance-based rates.

@

Proof of ROI in case of capital

@

expenditures.

Increase revenue:

Power quality threshold guaranteed.

@

Provide your customer a view of their

@

power quality.

Implement performance-based rates.

@

Save time:

Reduce the number of points to analyse.

@

Use classification to identify the problem.

@

Share analysis over web-based platform.

@

Event analysis on several sites.

(21)

T&D networks - Power monitoring and analysis

From power generation, through transmission and distribution to power supply, power quality solutions allow managing efficiently the network.

Equipments:

Power Quality and Energy Metering

ION 8600, ION 8800, ION 7550/7650

@

Power Metering:

PM800 with waveform @

Circuit monitor:

CM4000 range @

Power management software:

ION Enterprise™

@

System Manager Software (SMS)

@

Services:

Commissioning

@

Customized report HMI

@

Consulting

@

Global communication system:

Local mastering: Data concentration

@

of serial/Ethernet metering devices Gateway functionality

@

Web-based presentment.

@

Email data transfers: Ethernet support

@

of metering, SCADA and PQ protocols

Solution for Power quality

Global

communication

system:

Open protocols. @ Advanced @ communication. Customized @ solution. Integration @ into existing infrastructure. Accommodation @ of third-party equipment. ION 8800. ION 7650. Ethernet, Internet, wireless, satellite, telephone network. Corporate LAM / W an.

Intelligent energy and power quality meters.

(22)

T&D networks:

Revenue metering

Solutions to enhance

revenue metering

Revenue metering is a serious business. Electric Utilities need reliable energy information technology to meet their targets: lower operation costs, improve network reliability and optimize business planning.

Main benefits of Schneider Electric solution

Communication technologies dedicated

@

to data acquisition and speed. Easy data treatment: available

@

in a ready-to-use format, for over appropriate media.

Comply with industry-standard: DNP

@

or Modbus protocols are available over TCP/IP for direct SCADA integration.

Your key applications

Automated and accurate billing data acquisition across the grid.

@

Advanced power quality monitoring and reporting.

@

Detailed information on loading, capacity and stress.

@

Billing systems interface: through DLMS,

@

IEC 60870-5-102 or MV-90. Customized view: power quality

@

information or alarms through pager alerts, emailed reports or web (depending on load profiles).

Access in real-time: critical data are

@

available from any computer (via web server).

(23)

T&D networks - Revenue metering

Schneider Electric solution includes all the revenue metering software, hardware and services to offer the most accurate and efficient billing information.

Revenue metering offer

Power quality and energy monitoring:

ION 8000/7000

@

Power management software:

ION Enterprise™ @ ION Setup @

Services:

Commissioning @

Customized report HMI

@

Consulting analysis

@

Installation and maintenance

@

Energy meters :

ION 8600 Power meters : ION 8800

Curtailment program support Automaded meter reading High accuracy generator metering Settlement between transfer points Industrial user: monitoring energy and power quality

(24)

T&D networks:

Distribution Automation

Solutions for Network

Management Systems (NMS)

Because a single failure is able to generate considerable financial losses, continuity of service is a strategic challenge. Distribution automation solutions are an efficient answer for underground and overhead network management.

Main benefits of Schneider Electric solution

Network management systems including DMS functionalities.

@

Primary substation automation.

@

Secondary substation automation.

@

Up to

50%

less

network

outages.

Improve global quality of service.

@

Reduce operational and maintenance costs.

@

Defer capital expenditures through step by step and easy implementation.

(25)

T&D networks - Distribution Automation

Seefox NMS Software

Schneider Electric offers you a complete solution to manage effectively and safely electrical distribution: simple to manage, user-friendly, open and especially designed for the needs of electricians and facility managers.

Solution for Network management

Seefox network management system is the adapted

solution for electrical installation from HV to LV. Seefox

ensures:

Support of tools that provide updated information on

@

the network status

Assistance to carry out safe and guaranteed complex switching

@

operations

Ability to perform several tasks simultaneously, to monitor

@

and control the team operating

Links with customer information services

@

Possibility to plan the network evolution

@

Tools analysis: to optimize safe and secure network for

@

an optimized energy distribution

Protection Relay Primary substation. MV/LV substation R TU. Overhead network R TU. Seefox Scada DMS in Control Centre.

(26)

T&D networks:

Distribution Automation

Solutions for Feeder

automation

A simple outage can cost up to million euros for a semiconductor production fab or for a banking company. Power outages are extremely costly without speaking about the damages on the company image: losses of credibility and customer confidence.

Your key applications

Feeder automation solutions to operate underground and

@

overhead distribution networks.

Increased quality of service and

network reliability:

Up to 50% less outage duration.

@

Areas affected by the faults divided by 2.

@

Monitored and improved power quality.

@

Operation and capital costs reduction:

Cost reduction: on non distributed

@

energy, on operating during major failure, on maintenance…

Fast fault location.

@

Network productivity improved.

@

Easier implementation than Scada

project:

Preconfigured architectures:

@

development time 50% shorter.

Less resource needed and easier project

@

management.

Faster scalability and implementation.

@

Up to

30%

costs

reduction for

operation

and capital.

Up to

50%

less

Outage

duration.

(27)

GPRS GSM / PSTN Ethernet Overhead Underground 2 5 5 6 4 3 3 3 3 7 8 9

T&D networks - Distribution Automation

6 Pre-fabricated MV/LV substation: Biosco. 7 Communicating fault passage indicator for

overhead networks: Easergy Flite 116-SA/G200. 8 Reclosers and circuit breakers: U, N and W series

- N series controlled by ADVC.

9 Sectionaliser: PM6 load break switch remote controlled by Easergy T200P.

10 Load-break switch: RL series. 1 Remote control system: Easergy L500.

2 SMS Alert.

3 Remote control unit for underground networks: Easergy T200I.

4 Communicating fault passage indicator for underground networks: Easergy Flair 200C. 5 Medium voltage ring main unit: RM6.

RM6. T200. Biosco. Recloser U series.

Schneider Electric offers you an easy and cost effective solution to maintain your customer satisfaction and reduce your operational costs.

Solution for Feeder automation

1

6 5

(28)

T&D networks:

Primary substations

Solutions for indoor and

unmanned outdoor primary

substations

Reduce operating cost, adapt solution according to the environment and the available space, ensure safety of people and assets… these are the main requirements of primary substations.

Your key applications

Indoor primary MV/MV substations for urban areas with limited space.

@

Outdoor unmanned MV/MV substations for rural and remote areas.

@

For Indoor primary substation:

Increased continuity of service.

@

People and installation safety.

@

Simple and reliable operation.

@

Low maintenance costs.

@

30 years service life minimum.

@

Main benefits of Schneider Electric solution

For Outdoor unmanned MV/MV

substation:

Lower operating cost: no need of

@

operator.

Lower space needed: no space in cities.

@

Lower construction cost and shorter time

@

to build: no civil work.

Lower cost for remote control based on

@

secured communication media.

30

years service

life minimum.

(29)

MV Network MV/L_substationsV MV feeders MV feeders MV Network MV/L_substationsV GIS/AIS_Incomers

GIS/AIS_{Bus sectionning}

GIS

Busbar_transfer MV intake

GIS/AIS_{Protection / control}

Indoor MV/MV Substation Ethernet Internet 33 kV _Isolators 2 x Sepam T87 relays with _Modbus

ADVC cubicle _controller ADVC cubicle _controller

ADVC cubicle _controller

GPRS Router ADSL_{static public PC} line with

Any access _{media to Internet} Remote VPN _access Main control _centre

N Series outdoor _{MV recloser} (33 kV)

33/1_transformer1 kV

U Series Compact _{MV recloser} (11 kV)

11 kV outdoor _{auto-recloser} U Series _{Compact MV}

recloser _{(11 kV)}

11 kV Feeders

T&D networks - Primary substations

Schneider Electric provides complete solution for Indoor MV primary substations and outdoor unmanned MV/MV

substations: safety of people and assets.

For Primary Indoor

MV/MV substations:

MV primary cubicles: Air Insulated Switchgear

@

(MCset, F400, NEX) Gas Insulated Switchgear

@

(CBGS, GMset, CGset) MV/MV power transformers Protection and monitoring:

Sepam protection relays

@

ION monitoring and energy meters

@

Services:

Design analysis

@

Installation and commissioning

@

Maintenance and retrofit.

@

Solution for Indoor MV/MV substations

Digital protection relays. Sepam series 20, 40 and 80.

@

Recloser and controller circuit-breakers. U-series, N-series, W-series.

@

Communicative breaker control cubicles. Advanced Controllers (ADVC).

@

For Primary Outdoor unmanned 33/11kV MV/MV substations:

Windows Switchgear Operating System (WSOS):

Remote configuration, control and

@

monitoring of reclosers.

GPRS mobile communication media.

(30)

T&D networks:

Secondary MV/LV substations

Solutions for

MV/LV substations

Why choose between safety of people and reliability of the electrical installation when prefabricated substation offers you both.

For Utilities:

Much better safety for public

@

and operators: compliance with IEC 62271-202.

Cost savings: factory assembled and

@

type tested.

Time savings: solution ready to be

@

connected (Plug & Play).

Your key applications

Secondary MV/LV substations including protection cubicles, transformers, prefabricated kiosk, remote control,

@

LV switchboard and capacitors.

For Panelbuilder partner:

Market differentiation: compliance with

@

IEC62271-202, Schneider Electric expertise and brand image.

Cost savings: engineering already done

@

by Schneider Electric.

Faster time-to-market: immediate

@

availability.

Compared to traditional civil work substations, prefabricated solution brings

many user benefits:

(31)

1

2 3

4 5

T&D networks - Secondary MV/LV substations

Biosco. Minera. RM6.

Technical benefits of Schneider Electric solution can be sum up in 3 main items: type tested, “Plug & Play” and safe solution.

Biosco prefabricated substation offer

is available in 4 models:

Biosco W: Walk-in type with corridor.

@

Operation protected from weather conditions

Biosco N: Non walk-in type with external

@

operation. Ground space savings Biosco H: Half-buried, with external

@

operation and limited visual impact Biosco U: Underground kiosk. Perfect

@

integration into the environment

Solution for Secondary MV/LV substations

Biosco solution includes:

Metal or concrete enclosures

@

LV switchboard (Prisma, Opus)

@

MV cubicles: modular (SM6), compact

@

(RM6, Ringmaster, CAS36)

MV/LV transformers: Cast resin (Trihal)

@

and oil transformers (Minera) Fault detection (Flair) and Remote

@

control (Easergy T200) LV capacitor banks

@

1 Remote control unit. 2 LV capacitors.

3 MV/LV transformer up to 36kV. 4 LV Panel board.

(32)

Energy supply:

Demand Response

Solutions for Demand

Response

In case of peak consumption, Demand Response are the mechanisms used by electricity operators and suppliers to encourage their consumers to: reduce electricity demand by disconnecting loads

or increase electricity supply by starting back-up private generation systems.

Your key applications

Occasional storms and heat waves, as well as periodic shut down for maintenance can affect the supply/demand for electricity. When demand is high and supply is short, the price of kWh can be multiplied by more than 10. In this critical context, it is essential to lower the demand on one side (Demand) to be able to respond for peak demand periods on the other side (Response).

Moreover, Demand Response solutions allow much more efficient use of generation and T&D network capacity. It helps protecting the environment avoiding start up of huge CO₂ emitters like gas, coal or oil generation units.

Identify the best Demand Response programs to optimize your energy savings.

@

Customized Demand Response services to reach up to 25% annual energy cost

@

reduction.

Comprehensive offer providing energy meters and software tool for control, metering

@

(33)

Energy analysis system

Demand Response

monitoring & control system

1

Notification

2

Curtailment

Decision

3

Control

Action

4

Participation

Response

Demand Response aggregator

Energy supply - Demand Response

5%

Demand

Response

can lower

electricity price

by

50%

Solution for Demand Response

Determining which Demand Response programs are right for your needs.

@

Performing Demand Response energy auditing to assess the best load reduction

@

strategies for your facility.

Estimating the financial opportunity that Demand Response participation will mean

@

for your facility.

Enabling your facility with the proper control, metering and data management tools

@

so you can earn the most amount of money possible.

1

Notification is sent by Demand Response

provider.

2

Viewing energy and demand profiling to determine when and if you can curtail your energy usage.

3

Load control scheduling is performed with predefined curtailment scripts.

4

Accept/reject curtailment response creating the cost saving for your business

(34)

Services:

Electrical Energy services

Electrical energy services

for your peace of mind

Services are integral part of our solutions. Our expertise is present all along

the projet, from design to retrofit. Schneider Electric commitment is to be your privileged partner: able to bring you turnkey solutions and to help you to make the most of your energy.

Turnkey project design

Global and innovative solutions.

Integration of complete Schneider Electric offer and other @

supplier equipments.

Added value with a high level of expertise. @

Involved during the complete life cycle of the solution.

Maintain level of performances.

@

CAPEX and OPEX optimization. @

Existing asset improvement. @

Worldwide support

High quality level during project design, installation, @ maintenance. Optimization of investment. @ Investment optimization. @

Reach 100%

of your potential

Schneider Electric customised service contracts include 3 packages:

1

Predict

Preventive maintenance. @

Periodic diagnosis. @

Emergency on-site intervention. @

24/7 hotline. @

2

Predict+

Emergency on-site intervention cost @

included.

3

Predict++

Full budget control. @

(35)

Design

Build

Operate Recycle

Improve

Services - Electrical Energy services

Extend the service life of your solution

Repair

Faulty equipment fixed. @

Compliance with international standards. @

Refurbishment

To recover the original performances @

of Schneider Electric equipments: for obsolete or worn-out equipments.

Retrofit

To upgrade performances of Schneider @

Electric solution without replacing your equipments.

End of life services

To recycle your obsolete equipments @

(36)

They already made the most of their energy!

Centralized power

generation

Liaoning Hongyanhe and Fujian

Ningde nuclear power plants (China).

Schneider Electric solution: Gutor UPS.

Hrazdan thermal power plant

electrical distribution system

(Armenia).

Schneider Electric solution: Renovation and completion.

China Guangdong Nuclear Power

Company (China).

Schneider Electric solution: Electrical distribution from turnkey project design to installation and services.

Renewable distributed

generation

4,2 MW solar farm

(Vinon-sur-Verdon - France).

Schneider Electric solution: Complete electrical distribution with Solar Direct.

Car plant roof in Zaragoza - Spain.

The largest rooftop solar farm in the

world

(10 MW).

Schneider Electric solution: Electrical distribution and grid connection.

4 MW Solar farm

(Albuquerque - Spain).

Schneider Electric solution: Electrical distribution.

Largest onshore windfarm in Europe

(Whitelee - Scotland).

Schneider Electric solution: Electrical distribution and grid connection.

33 MW Rucar hydro power plant

(Romania).

Schneider Electric solution: Automation and electrical distribution.

(37)

They already made the most of their energy!

Transmission & Distribution

network

ENDESA (Spain), IBERDROLA

(Spain), ERDF (France), EDF

Networks (UK)…

Public distribution solutions for main utilities.

33/11 kV unmanned outdoor

substations for ASEB Utility (India).

Schneider Electric solution: Automation and electrical distribution.

Walk-in type MV/LV substation (Iran).

Schneider Electric solution: Biosco.

Utility in Marakech (Morocco).

L500 feeder automation divides by 3 the cost of the SCADA.

Transelectrica (Romania).

Schneider Electric solution: Power quality & revenue metering.

EDEMSA (Argentina).

Schneider Electric solution: minimize losses and maximize profit with ION.

Energy supply

USA.

Central Illinois Light Company (CILCO) Software for demand reponse program.

USA

New England Utility: Software and ION meters for real time data sharing.

(38)

(39)

(40)

Head Office 35 rue Joseph Monier

CS30323

92506 Rueil-Malmaison Tel. : +33 (0)1 41 29 85 00

http://www.schneider-electric.com

Printed on ecological paper

Schneider Electric Industries SAS

As standards, specifications and designs change from time to time, please ask for confirmation of the information given in this publication.

Publishing: Schneider Electric Industries SAS Design - Layout: SEDOC
