Energy-Efﬁ cient

Laboratory Design

By Nicolas Lemire, Eng., Member ASHRAE, and Roland Charneux, Eng., Fellow ASHRAE

School HVAC

Nicolas Lemire, Eng., is associate and design engineer at Pageau Morel and Associates in Montreal. Roland Charneux, Eng., is associate, senior design engineer, COO and operations vice president at Pageau Morel and Associates in Montreal. Lemire won a 2005 ASHRAE Technology Award (1st Place Institutional Buildings [New]).

L

ocated on the Loyola Campus in Montreal, the Concordia University Science Complex (Richard J.

Renaud Pavilion) is a 345,000 ft

2

_{(32 000 m}

2

_{) L-shaped building consisting of two subbasements}

and up to six aboveground ﬂ oors. This facility houses academic and research laboratories, classrooms

and ofﬁ ces. It serves 2,300 students, researchers and staff. The main activities are teaching and

re-search in ﬁ elds such as biology, chemistry, biochemistry, psychology and physical education.

Energy Efﬁ ciency

Energy effi ciency was a primary goal when designing the pa-vilion. Early on, Concordia University decided to remain the most effi cient university campus in the province of Quebec even with a laboratory building housing 250 fume hoods. This project was registered with Natural Resources Canada’s (NRCan’s) Offi ce of Energy Effi ciency’s Commercial Build-ing Incentive Program (CBIP). The main objective of the CBIP is to design a building with an energy consumption of at least 25% lower than the reference building designed It is also home of the Science College and the Centre

for Structural and Functional Genomics. About 45% of the building is teaching, research and development, or wet laboratories, including about 250 fume hoods.

Modularity and Distribution: For obvious reasons, ﬁ tting a 480,000 cfm (226 540 L/s) HVAC system in a me-chanical room and distributing air to an L-shaped building is no easy task. Furthermore, redundancy was mandatory for several reasons.

Four 80,000 cfm (37 750 L/s) systems were installed in the A wing supplying air to the eight-story North wing, while two identical systems were installed in the C wing supplying air to the four-story B and C wings. Two dedi-cated 25,000 cfm (11 800 L/s) systems also are installed to supply 100% fresh air to the animal quarters located in the lowest basement.

© 2005, American Society of Heating, Refrigerating and Air-Conditioning Engineers, Inc. (www.ashrae.org). Reprinted by permission from ASHRAE Journal, (Vol. 47, No. 5, May 2005). This article may not be copied nor distributed in either paper or digital form without ASHRAE’s permission.

(2)

to strictly comply with the Model National Energy Code of Canada for Buildings (MNECB).

At Concordia’s Science Complex, those objectives are met and exceeded, as the complex is about 50% more efﬁ cient than the MNECB. Comparisons with the ANSI/ASHRAE/IESNA Standard 90.1-1999, Energy Standard for Buildings Except

Low-Rise Residential Buildings, reference building were not

done. However, LEED Canada-NC 1.0 documentation gives an equivalent Standard 90.1-1999 efﬁ ciency of 44% compared to its reference building.

Motion detectors were installed in all rooms to directly shut off lights after an adjustable delay. While doing so, a signal also is sent to the building automation system (BAS) to reduce ventilation rates. In labs, 10 air changes per hour (ACH) are maintained at all times when the lab

is occupied. However, this ventilation rate falls to 6 ACH when motion detectors don’t detect any occupants during the day. At night, it even falls deeper at 3 ACH giving a total strategy for labs of 10/6/3. If occupants are detected at night, the ventilation rate climbs back to its secure position at 10 ACH. This strategy also is applicable for non-lab usage where the rates are slightly modiﬁ ed to 6/3/0.

The manifolding laboratory exhaust system presents several advantages. The most signiﬁ cant are probably energy savings and lower capital costs and are directly linked to diversity. Since not all fume hoods are operating at maximum capacity at the same time, a diversity factor was agreed with Concordia, allowing for smaller systems.

Flow tracking is done on each lab unit totalling air supplied, exhausted and returned to ensure contin-uous balancing of lab units, departments and floors. Each floor is maintained at neutral pressure by modulating the general return boxes located in public corridors. Airﬂ ow tracking also is done at the system level on the supply and return fans.

Heat recovery is used on fresh air and exhaust using a runaround glycol loop. Coils and ﬁ lters in main systems are selected at 400 fpm (2.03 m/s) to reduce static pressure loss. Variable frequency drives (VFD) are installed on all fans, and motors are direct coupled to avoid belt losses and minimize maintenance. A closed loop steam system is implemented in the new facility to prevent ﬂ ash steam. A low tempera-ture (85°F to 105°F [29.4°C to 40.6°C]) water heating loop also is used to recover heat from various equipment such as

Lemire won a 2005 ASHRAE Technology Award (1st Place Institutional Buildings [New]) for Concordia University Science Complex.

Concordia University Science Complex.

(3)

Energy (kWh/ft2₎

Reference Building Simulated Building

DHW Process 8.2 8.2 Lights 5.24 4.01 Equipment 6.96 6.96 Heating 65.43 29.95 Cooling 5.48 3.77 Pumps 5.93 2.45 Fans 15.51 7.25 Total 112.75 62.59 Table 1: Energy consumption.

Case Building Natural Gas (ft3₎ _{Electricity (kWh)} _{Total (kWh eq.)}

Reference 86,698,220 13,496,400 38,898,750

Simulation 44,921,050 8,431,800 21,593,550

Actual 40,572,200 8,083,350 19,978,300

Natural Gas Electricity Total (kWh eq./ft2₎ _{(kWh eq./ft}2₎ _{(kWh eq./ft}2₎

Reference 73.63 39.12 112.75

Simulation 38.15 24.44 62.59

Actual 34.45 23.43 57.88

Natural Gas (CDN $) Electricity (CDN $) Total (CDN $)

Reference 1,041,496 749,050 1,790,546

Simulation 539,632 467,965 1,007,597

Actual 487,295 448,626 935,921

Annual Savings $854,625 (CDN $)

1CDN$ equals $0.80 U.S.

Table 2: Energy consumption (building comparison) & related costs.

boiler stack with direct contact heat recovery boiler, chiller condensing water (summer) and heat recovery chiller (winter) condensing water. This chiller is mounted directly between the chilled water loop and the low-temperature water heating loop. It basically is used to recover all internal heat from cold room compressors, growth chambers, freezer rooms, electrical substation, electrical and telecom rooms, computer rooms, etc. The low temperature water heating loop is used for heating and reheating purposes. Summer chillers have been selected to operate at maximum of 0.6 kW/tons (0.17 kW/kW) at full load and cooling towers are equipped with direct-drive low power axial fans coupled with VFD.

A summary of energy consumptions for both reference and simulated buildings is shown in Table 1, while Table 2 shows an energy comparison for the

refer-ence, simulated and actual building and the related costs. By reviewing lit-erature on existing laboratories, it was possible to estimate that energy con-sumption averages 94 kWh/ft2₍₁₀₁₂

kWh/m2_{) for ﬁ ve very efﬁ cient similar}

laboratory installations as published by Labs 21, a program sponsored by the U.S. Environmental Protection Agency and the U.S. Department of Energy. Table 2 shows that

the new pavilion is competi-tive with its total energy con-sumption of 57.88 kWh/ft2

(623 kWh/m2_{) (62.59 kWh/ft}2

[674 kWh/m2_{] simulated),}

proving the efﬁ ciency of all measures detailed during de-sign phases and implemented during construction.

Concordia and the design engineers insisted on having a commissioning program to ensure the performance and ﬁ ne-tuning of all mechanical equipments. Commission-ing was done particularly on

the BAS to comply with ASHRAE Guideline 1, The HVAC

Commissioning Process. This helped to improve energy

efﬁ ciency.

Indoor Air Quality

Ventilation Strategies: The ventilation rate procedure of ANSI/ASHRAE Standard 62, Ventilation for Acceptable Indoor

Air Quality, was used to determine required outdoor air

quanti-ties based on occupancy information provided in the functional program of Concordia. As discussed earlier, motion detectors were installed to save energy. However, the detectors also are

used for ventilation rate strategies, making sure air change rates are adequate when people are present in labs, whatever the time of day.

As shown in Figures 1 and 2and 2and , a physical segregation is present between lab units and ofﬁ ces as another way to prevent contami-nants from migrating from lab spaces to common areas.

As shown, the service corridor, only accessible by autho-rized personnel, is adjacent to lab units only. That kind of in-stallation was designed based primarily on containment level. Thus, the fume hood, being under negative pressure relative to its environment, represents the ﬁ rst level of containment. Since the lab unit also is under negative pressure relative to its environment, it represents a second level of containment. Finally, the service corridor is maintained under negative pressure relative to the common area but under positive pressure relative to the lab units, giving a third level of containment.

Combining both lab and non-lab functions on the same system pro-vides better than minimum prescribed amounts of outside air to all areas while reducing the total amount of outside air (since 100% outside air would have been required for labs and 20% outside air for other purposes).

Thermal Comfort: The special VAV system with predetermined air change rate and terminal reheat ef-ficiently provides effective temperature control with no risk of complaints. All zones in the building can maintain effective temperature within the ASHRAE comfort zone as deﬁ ned in ANSI/ASHRAE Standard 55, Thermal

Envi-ronmental Conditions for Hu-man Occupancy (average

oc-cupant activity level: 1.2 met, clothing: 1 clo). Light primarily sedentary activity and typical indoor clothing is the general design condition. A maximum of 60% RH is allowed during summer while a minimum of 30% is maintained during winter using steam humidiﬁ ers installed in main air-handling units.

Mechanical Systems and Equipment: Ventilation ducts and plenums are constructed to comply with the Sheet Metal and Air Conditioning Contractors’ National Association (SMACNA) Standards, the National Building Code of Canada and the National Fire Protection Association (NFPA), thus reducing op-portunity for growth and dissemination of microorganisms.

(4)

Acoustical insulation was allowed only from terminal boxes to diffusers on the supply network, and from return grilles to control boxes on the return network. Thermal insulation is installed on supply ductwork and media-less silencers are installed on the exhaust network to meet the acoustical level required in labs.

Draw-through type systems are used, reheating the saturated dehumidifi ed air just enough to lower the relative humidity to safer levels, at which microbial growth is less likely to occur. Those systems use at least two stages of fi ltration: 30% pre-fi lters and 85% bag fi lters. Effi ciencies rating the fi ltering media are according to ASHRAE Standard 52.1-1992, Gravimetric and Dust-Spot Procedures for Testing

Air-Cleaning Devices Used in General Ventilation for Removing Particulate Matter.

All equipment where condensation is likely to occur are equipped with accessible pans designed for self-drainage, precluding buildup of microbial slime. Coils also have been placed in systems and selected to allow easy access and fa-cilitate cleaning.

Laboratory Exhaust Contaminants and Acoustics: Con-cerns were raised during the design period about lab exhaust re-entrainments and impacts on other buildings in the neighbor-hood. Concordia University asked for a study of the proposed design in a wind tunnel. However, Concordia’s researchers in the ﬁ eld were able to perform that study to assess all concerns. It conﬁ rmed that, with minor stack height adjustments, dilution and dispersion of contaminants will not be of any harm for any wind velocity or direction. Acoustical concerns also were raised. Therefore, the exhaust stacks, as well as the air intake and air exhaust, were treated to avoid noise impact to the neighborhood (residential housing).

Innovation

Considering the two major types of activity occurring in the building, two basic options were analyzed: dedicated systems vs. centralized. The use of dedicated systems would have required a 100% outside air system for the laboratory and at least a 20% outside air system for other functions in the building. By combining both systems into a centralized one, we obtain a 480,000 cfm (226 540 L/s) system with about 65% of outside air. This resulted in a reduction of total quantity of outside air entered and an increase of the outside air ratio in systems, improving air quality in classrooms and elsewhere in the building. The centralized system enabled the reuse of quality air (from ofﬁ ces) that normally would have been exhausted.

As mentioned earlier, the 480,000 cfm (226 540 L/s) system was split in six modules of 80,000 cfm (37 750 L/s). This strat-egy allowed this system to be built at a reasonable cost. It has the additional advantages of redundancy and easier maintenance of smaller systems, even during occupied periods, by isolating one module at a time. Flexibility of mechanical systems (with

the service corridor) allows the retroﬁ t of labs without disturb-ing any adjacent modules, which helps to maintain safety and security at all times.

A bypass opens around heat recovery coils to reduce static pressure when heat recovery is not needed. Combining efﬁ cient window glazing with linear ﬂ oor grilles on perimeter maintains comfort in rooms without downdrafts, even at low outside tem-peratures.

Installing small dedicated exhaust chimneys in the central core of a high ﬂ ow general exhaust helped provide good velocity and dilution of that particular exhaust. It also was an efﬁ cient way of maintaining a lower amount of apparent chimneys.

Operation and Maintenance

Accessibility of Equipment: Air-handling units, exhaust units and mechanical components are centrally grouped in two large mechanical rooms located on top of both A and C wings. They are accessible by service elevators. Replacement equipment can travel easily from the truck dock to the penthouses. All major equipment is located high above ﬂ oor level and is accessible through permanent ladders, stairs and catwalks. Maintenance can

Exhaust to Common Collector Exhaust to Common Collector In Penthouse

Horizontal Exhaust Collector

Tel/Data Cabling To Labs

Service Corridor

Vertical Plumbing Labs Services Occupancy Sensor (Typical) Lab Bench Lab Lab General Exhaust Variable Variable Air Volume Air Volume Fume Hood

Figure 2: Cross section of lab units with service corridor.

Accessible Service Shafts for Labs

(Typical)

General Return Shafts

Service Corridor

General Return Shafts

Public Corridor (Natural Lighting) Main Supply Shafts

Wet Labs

Wet Labs Ofﬁ ces

Figure 1: Lab units vs. ofﬁ ces & common areas in the north wing.

(5)

CDN $ CDN $/m² CDN $/m²

Mechanical 20,900,000 60.60 652.00

Electrical 6,400,000 18.55 199.60

Building 59,500,000 172.46 1,855.00

1 CDN $ equals $0.80 U.S.

Table 3: Construction costs.

Summer Boiler $60,000

Airﬂ ow Reduction

During Unoccupied Periods $560,000

Motion Detectors $114,300

Glycol Heat Recovery $494,000

Static Pressure Reduction $376,560

Direct Contact Heat Recovery Boiler $90,000 Low Temperature Heating Water Loop

And Peripheral Forced Air Heating ($339,000)

Total $1,355,860

1 CDN $ = $0.80 US

Table 4: Additional construction costs.

Additional Costs (Table 4) $1,355,860

Annual Savings (Table 2) $854,625

Payback 1.58 Year (19 Months)

1 CDN $ = $0.80 U.S.

Table 5: Simple payback.

be performed on each air-handling unit without disturbing occupants. Builtup plenums and air-handling units have large access doors, inspection windows and are well lit. Walk-in access sections are provided between all components of the air-handling units.

Control and Monitoring: A central-ized BAS links all mechanical compo-nents through a centralized direct digital control network. Building operators have access to that network using a computer interface to view remote monitoring of component status, operating conditions, measuring stations, alarms and prese-lected trend logs. Operators also can modify sequences, setpoints, schedules or issue live commands.

Flexibility of Design: As shown earlier in Figure 1 and demonstrated in Figure 2, laboratory units are adjacent to the service corridors, giving easy access to special

labora-tory services such as compressed air, special gases, DI water, laboratory drainage, telecom, electrical panels, etc. It also gives easy access to the manifold exhaust system located in the ceiling of the service corridor. All this accessibility is useful when modifi cations or retrofi t occur. Modi-fi cations can be performed on a lab unit without interrupting activities occurring in neighboring units. Fur-thermore, mechanical equipment has been designed to accept increase in supply and exhaust capacities for laboratory units. Diversity in the use of HVAC-dependent equipment (fume hoods, capture arms, etc.) can infl u-ence directly the remaining capacity of the installations.

Commissioning: As mentioned earlier, commissioning of the building was performed placing emphasis on performances of primary air-handling
