Highway Rehab. Corp.
2258 Route 22
Brewster, NY 10509
Tel (845) 278-9645
Fax (845) 278-0747
www.highwayrehab.com
ASPHALT PAVEMENT
RECYCLING
Hot In-Place
alt
ec cl n
The Energy Saving Method!
ASPHALT PAVEMENT RECYCLING
A History of Highway Rehab. Corp.
Highway Rehab. Corp. has more than 30 years experience in Asphalt Milling and Hot In-Place Asphalt Recycling. Founded by Ken Carr and Jerry Starbuck in 1973, Highway Rehab. Corp.
first introduced asphalt milling to the United States when the pair purchased a German-made Wirtgen Milling Machine for use in the US.
Road and bridge deck milling became commonplace throughout the United States in the 1970s, leading to the development of Hot In-Place Asphalt Recycling, a low-cost maintenance strategy that effectively re-uses existing material.
Hot In-Place Asphalt Recycling is now the oldest recycling discipline within the Asphalt Recycling & Reclaiming Association. (ARRA), an organization founded in 1976, with a membership comprised of contractors who performed heater-scarification work. Ken and Jerry are among its founding members.
In addition to performing the work, Highway Rehab. Corp. now manufactures the recycling machines at their Cheektowaga, NY facility.
HIGHWAY REHAB. CORP.
IN
PLACE • ASPHALT • RECYCLING
Hot In-Place
HOT IN-PLACE RECYCLING
Definition:
Heater scarification is a rehabilitation process that restores cracked, brittle, and irregular pavement in preparation for final thin wearing course as selected by the awarding authority.
Application:
Roadways that possess a stable and structural adequate base are appropriate candidates for this process. The depth and nature of the existing material must be evaluated prior to constructions.
Two machines operating in tandem insure deep heating and softening of the aged payment.
A truck mounted surface recycler is capable of recycling speeds and highway speeds with a change in gears.
Application of rejuvenating agent along with dual milling heads improves the viscosity of the aged asphalt.
Multiple rows of spring loaded scarifiers penetrate the softened asphalt to the desired depth.
The recycled material levels the previously deformed surface in preparation for an overlay or seal coat.
HOT IN-PLACE RECYCLING APPLICATIONS
Hot In-Place Asphalt Recycling
Hot In-Place Recycling is an on-site, in-place method that rehabilitates deteriorated bituminous pavements, minimizing the use of new materials.
Because asphalt is a unique construction material that can be effectively and economically restored, Hot In-Place Recycling encourages restoration rather than applying new material over deteriorating pavement or losing the asphalt altogether through grinding the material. The process involves heating, scarifying/milling, adding a rejuvenating agent, mixing, placing and re-compacting the new bituminous pavement.
Hot In-Place Asphalt Recycling presents the opportunity to spread available funds over a much greater area, especially during times of rapidly increasing costs and limited funding. In other words, the process allows communities and property owners to address roadway deterioration, ensuring that pavements are preserved and upgraded, and costly reconstruction is avoided.
Benefits
Hot In-Place recycling effectively addresses the classic symptoms of deteriorated oxidized pavement. In addition to being financially practical, the benefits of asphalt recycling include:
• Cracks are interrupted and filled.
• Aggregate stripped of the bitumen is remixed and recoated.
• Ruts and holes are filled, shoves and bumps are leveled, drainage and crowns are re-established. • Flexibility is restored by chemically rejuvenating the aged and brittle pavement.
• Aggregate gradation and asphalt content may be modified by some variations of this process. • Pavement is corrected without applying a leveling course.
• The use of in-place material reduces the amount of new asphalt applied in the overlay. • Stronger bonding of old and new asphalt compared to conventional overlay.
• Later occurrences of reflection cracking in the overlay is eliminated or significantly reduced.
• Thinner overlays produce longer retention of draining capacity of in-place curbs and gutters, allowing grade
restrictions to be met with greater ease.
• Enhanced highway safety through improved ride and skid resistance. • Flexibility restored by rejuvenating aged asphalt.
• Lower engineering and traffic control costs.
HIGHWAY REHAB. CORP.
IN
HOT IN-PLACE RECYCLING APPLICATIONS
FIRST IN THE PAVEMENT MAINTENANCE LINE OF DEFENSE
Source: World Bank
Each $1.00 spent during the first 40% drop in quality will cost $4.00 to $5.00 if delayed until the pavement loses 80% of its original quality.
TYPICAL PAVEMENT CROSS SECTION
DESIGN CONSIDERATIONS
DESIGN CONSIDERATIONS FOR HOT IN-PLACE RECYCLING
1. Pavement Must Be Structurally Sound
2. Material Testing
3. Traffic
4. Environment
HIGHWAY REHAB. CORP.
IN
BEFORE
AFTER
BEFORE
AFTER
CONTACT US
Corporate Headquarters
2258 Route 22 Brewster, NY 10509 Phone: 845-278-9645 Fax: 845-278-0747 [email protected]Manufacturing/Maintenance Location
100 Stradtman Street Cheektowaga, NY 14206 Phone: 716-892-1655 Fax: 716-892-2257Lower Hudson Valley Region
Ken Carr 2258 Route 22 Brewster, NY 10509 Phone: 845-278-9645 Mobile: 845-721-6010 Fax: 845-278-0747 [email protected]
Western/Central NY Region
Terry Lucey 100 Stradtman Street Cheektowaga, NY 14206 Phone: 716-892-1655 Mobile: 845-721-6008 Fax: 716-892-2257 [email protected]Upper Hudson Valley/Capital Region
Dan Poley
P.O. Box 774
Hunter, NY 12442
Mobile: 518-965-5315 [email protected]
New England Region
Kurt Freudenreich
19A Fairway Drive Mechanicville, NY 12118 Mobile: 518-378-7876 Fax: 518-664-9313 [email protected] Dave Capelle P.O. Box 81 Shrewsbury, MA 01545 Mobile: 508-208-8467 [email protected]
Thank You Past, Present, & Future Customers
