Control and Monitoring
Anywhere
Anytime
Today, managing assets and infor-mation in the field is at a premium. Protecting your investments and get-ting critical data in a cost effective manner has never been more impor-tant. Creating more efficient work processes that save time and money are critical. Control and monitoring (SCADA systems) have traditionally been expensive and complicated to configure and manage.
AMI has changed the rules of the game and has a system that is both simple to use AND cost effective.
AMI is a cloud technology company. AMI provides cloud infrastructure for communication, hardware, software, data storage and servers. Market segments include water manage-ment, agriculture, turf irrigation, pumping solutions, oil and gas, min-ing, lighting as well as other indus-trial processes.
The company specializes in cloud based solutions that allow customers to manage, monitor and trouble-shoot a variety of field based assets
via any web enabled device while storing data in a cloud based data warehouse.
Solutions from pumping systems to VFDs (variable frequency drives) and much more are now available in a simple, easy to use and cost effective package.
AMI™ understands the challenges of today’s business climate. Doing more with less has become a way of life. The problem is how do we manage our time and resources better? How do we manage our assets and get information from the field better? How do we manage our resources (water and power) better? And how can we do this in a simple, cost effective method?
Imagine better asset and resource management that actually saves time and money. Fewer man hours visiting sites, fewer associated costs (gas) and less wasted resources such as water and power. And imagine a system simple enough for a novice but with the technical capabilities to please the seasoned engineer. AMI provides proven technology and superior service to make all of this a reality.
The AMI Vapor™ allows for remote “cloud” based management, alert-ing, schedulalert-ing, reporting and more for a variety of field based assets…all from any device; desktop, laptop, cell phone, tablet. No configuration OR software required.
Manage any device anywhere in the world. AMI Vapor uses patented technology that allows it to com-municate anywhere at anytime via the cellular network, (available in 97 countries) Ethernet OR satellite communication. No system is too remote and every system is fully secured over our encrypted network. AMI provides true turn key solutions. No SIM cards to source or tiered data communication plans to navigate. AMI provides it all to simplify your life and to help you get things done.
Our solutions are ready to use out of the box and we provide unlimited training and technical support. The AMI Vapor is an application driven product, so one product fits ALL of your needs. Multiple vendors can be frustrating. AMI provides a single login for all of your systems, a single virtual dashboard and a single technical support desk for all of your support needs.
Are you a manufacturer who under-stands the importance of going to “the cloud” today instead of spend-ing years of R&D and millions of dollars in development? AMI offers several private label and OEM options that can get you there NOW.
AMI™ provides complete control and monitoring of any pump…ANYWHERE. With patented AMI VAPOR™ technology you can now program, schedule, manage, receive alerts and have access to full reporting features from your computer, smart phone or tablet. Anywhere, anytime…without phone lines, complicated SCADA sys-tems or expensive software.
Imagine the time and money you can save by reducing trips to the field. Troubleshoot or simply reset your pump from your computer, laptop tablet and smartphone. Automated alerts for leaks, pressure changes, flow fluctuations and other critical data are in place to help conserve resources and SAVE MONEY.
The AMI pump solution includes…
• Remote scheduling • On/off/reset • Real time alerts via text message and email • Remotely monitor… o Pressure o Level o Flow o And more • Add an “app” for your Variable Frequency Drive • Full reporting features with unlimited access to historical data • Custom access levels over a secured network
Pump
Industry
Management features
• Pump status – ON/OFF • Pump outlet pressure (PSI) • Pump flow-rate and accumulation (GPM and gallons) • Pump intake pressure or water-source level (pond, well or other underground water storage) • Pump system differential pressure state, where a pressure threshold can be used to detect clogged filters or main line breaksRemote Control features
• Pump Start – connected in parallel to the pump manual start button • Pump Stop – connected in parallel to the pump manual stop button • Pump Control Reset - reset the power to the pump system to allow its control (PLC) system recovery
Alerts
• Outlet Low Pressure (under threshold for X minutes) • Outlet High Pressure (over threshold for X minutes) • Low water-source (pond/reservoir/well) level is high/low • Pump is on • Pump is off • High/low flow - rate - pump is ON and flow/rate is outside of the expected flowSchedules
• Up to eight weekly different operational schedules with up to 12 start-times per day • Start-time ---- (run pump for X minutes)---> Stop • Conditional pump cycles • Enable pump if level is higher than threshold (enough water to use) • Disable pump if level is lower than threshold (not enough water to use) • Start pump on specific time and stop pump after a certain amount (gallons) of water is pumped. Ideal for water-budget controlled well operationPump
and Pool
Aqua Pump Controller
Mobile User Online User
Level Monitor
Aqua Pool and Pump System is a cellular based (no phone line or ethernet wires required!)
control system that enables pump and pool remote monitoring & control, using web browsers and mobile devices such as phones and tablets. This solution is ideal for tank fills, cisterns,
ponds, wells and single or multi pump control.
Pool Monitoring features
• 4-20 ma Level Sensor Inputs • 0-10 V Level Sensor Inputs
• 4 dry contact digital input for low level, mid level, high level and critical level
Power Options
• Solar Panel with Battery Backup for sites with no onsite power source
• 110v & 220v
• Multi Pump Trigger - reset the power to the pump system to allow its control (PLC) system recovery
Alerts
• High level alert • Low level alert
Manage your variable frequency drive remotely. AMI™ provides applications (apps) for many VFDs on the market today. No more having to visit the site to get critical data and troubleshoot technical issues. All of this information is now available on your computer, smart phone or tab-let…where ever you are 24/7.
Proactively know about a potential problem before it causes damage, lost resources or lost revenue. AMI allows you to monitor and trouble-shoot your drives anywhere at anytime.
AMI lets you take the guess work out of your day and allows you to dispatch your field crews armed with the RIGHT information.
Our list of supported VFDs continues to grow.
AMI currently offers cloud solutions for
most major manufacturers VFDs.
Call us for details.
888
V
F
D Connect
™
AMI VFD interface solution connects any VFD drive to the cloud allowing for remote
monitoring and fault management.
AMI VFD controllers are cellular or satellite based (no phone lines or Ethernet wires required!)
and easy to install. Simply connect the device to the ModBus connection of the VFD drive.
Monitoring Features
• Log pressure and flow data to provide user quality of service (QoS) parameters • Physical connection uses twisted-per-half-duplex RS-485 connection • Pump flow-rate and accumulation (GPM and gallons) • Graphing tool for pressure and flow log • I/O terminal statusRemote Control Management Features
• Fault reset
• Clear the fault
• Switch the drive to serial command • Run the drive (back to auto) after clearing the alert
• Frequency reference • Fault history clear
Alerts
• Customized alerting • Automatic alerts sent via text message and e-mailControl Pump
& Monitor Tank / Well Levels Internet
Mobile User
Online User Temprature
& Wind Sensor
High Speed Counter / Flow Meter
Pressure Sensor
4-20 mA, 0-3 & 0-10 VDC Sensor
-On Demand Live Reports with Data Export Option
ioConnect
™
Manage your pumps and monitor sensors remotely. AMI™ ioConnect brings 7 inputs and 8 outputs to the palm of your hand. ioConnect can be used with any 4-20 mA, 0-3 & 010 VDC sensors... such as frost protec-tion, remote sensor monitor or multi-pump controllter. No more having to visit the site to get critical data and troubleshoot technical issues. All of this information is now available on your computer, smart phone or tablet…where ever you are 24/7.
Proactively know about a potential problem before it causes damage, lost resources or lost revenue.
AMI™ allows you to set high and low treshholds to recieve text messages and emails while logging important data points and setting rules to control logic. AMI™ lets you take the guess work out of your day and allows you to dispatch your field crews armed with the RIGHT information.
Monitoring Features 7 inputs
• Log pressure, flow and any sensor data to provide reports
• Monitor irrigation line pressure and alert the user on pressure outside defined boundaries • Set thresholds for sensor to be notified via text or email
• Alert the user on pump activation or temperature threshold cross • Start/Stop pump based on sensor threshold cross
• Enable Pump control remotely
• Read temperature and pressure remotely
Cloud Control Management Features 8 outputs
• Schedule or manually turn on and off pump • Schedule or command start/stop relays • Activiate outputs based on input value change
Agri
culture
Complete agricultural irrigation system integration. AMI™ provides seamless integration of ag irrigation systems to provide cloud based management and monitoring.
Information is at a premium in farming. Good informa-tion leads to good decision making…higher yields at lower costs.
AMI offers the most cost effective solution on the market for remote wireless soil moisture loggers. Soil moisture information now available in the palm of your hand… anywhere at anytime.
Integrate single components or
your ENTIRE agricultural irrigation
system. AMI provides cloud based
and wireless solutions for:
• Soil moisture sensors • Tank/well level • Pumps • Fertilizer • Chemical injectors • Filters • Remote valve actuation • Other sensors • ph • chemical • etc.
Pump Monitor & Control VFD and Pump Panel Integration
Wireless DC Valve Controller
Battery Operated Wireless Flow-Meter
Filter and Back Wash Management
Fertilizer and Tank Level Management
Agri
culture
WEATHER STATION
Battery Operated Wireless Data-Logger Soil Moisture, Temperature Sensors and Level Sensor
Web Browser
Tablet / Smart Phone Access Aqua Agriculture Controller Online Weather Resource
Benefits
• One system to manage irrigation, fertilization, filter backwash, sensor (moisture, ph, etc.), VFD, pump and wireless valves
• Reduce irrigation management time • Web based system operational alerts (ex. no-flow, low pressure etc.) are sent to e-mail and cellphone • Simple and easy remote access via any web enabled device, such as computers, tablets and cellphone • Cloud based data storage for historical comparisons • Increase yield by controlling fertigation • Reduce water usage by using irrigation feedback from sensors • Reduce pump power consumption by using efficient irrigation methods or pump run schedules
AMI
™Cloud Based Agricultural System
™Access / log / monitor and control your irrigation system and remote valves. Anytime, anywhere monitoring and control using your laptop, desktop, tablet or mobile phone. The AMI Cloud based agricultural irrigation system allows for user manage their irrigation based on volume, soil moisture and weather, fertigation injection and fertilizer pump, water pump and VFD, filters and filter flushing all from one dashboard.
Irrigation Control
• Remote pump or master valve control
• Automatic start/stop based on remote sensor inputs such as soil-moistures
• Flow control (alerts for overflow, underflow, no flow and uncontrolled water)
• Acid injection for pH control
• Fertilizer injection (up to 5 channels) for EC control (optional)
• Filter flushing (unlimited number of flushes)
• Historical water and fertilizer usage per zone
• Historical flow rates, pressure and other metrics
Valve Control
• Automatic solenoid control via radio communication
• Irrigation programs with specific fertilizer and acid requirements per valve
Cloud Based Acid Injection System
™Access / log / monitor and change acid injection amounts based on web/cloud based sensor. Anytime, anywhere monitoring and control using your laptop, desktop, tablet or mobile phone. The AMI Cloud based acid injection system allows for user defined target pH. The controller adjusts the injection rate of the acid pump using informa-tion provided by the flow meter and pH sensor to maintain the appropriate pH level.
AMI Cloud Bases Acid Injection System may be used as a standalone application or as a component of a more inte-grated online irrigation system.
Components
• Electric Pump (8-20 gallons per hour) • pH transducer • pH monitor • Flow meter • Electronic controller• AMI Vapor (gateway to the Cloud)
Remote Access
• Current pH levels
• Target pH level
• Average pH level
• % Pump operation
• Water flow rate
• Historical pH readings
Alerts via Text and E-mail
• High / Low pH readings
AMI
™Agricultural Logger
™Access and log your field soil moisture and temperature sensors online, anytime, anywhere, using your laptop, desktop, tablet or mobile phone. The AMI Logger collects and stores the sensor’s data and brings it to the “Cloud”. It is one of AMI’s Cloud based systems and is used as a standalone application or as a component of a more integrated online irriga-tion system.
Features
• Easy to install, includes pre connected soil moisture sensors
• Battery operated solar panel/low power device
• Sleep mode induced between data upload for power conservation
• E-mail notifications for user defined sensor threshold (high/low reading)
• Online data reporting including: graphs and tables with Excel exporting option
• Programmable up to twelve uploads per day
•
Optional “Upload Data Now” feature for on site user operation as needed
Cloud Control Management
Features
• Fully integrated with AMI’s Ag Cloud Solution
• Automatically start/stop irrigation based on preset sensor values
• AMI event logger and e-mail/text notification services
Mobile User
Online User Temperature
& Wind Sensor
4-20 mA, 0-3 & 0-10 VDC Sensor
The turf irrigation industry has long sought compre- hensive water management solutions at an affordable price. AMI™ pioneered cloud technology in this industry and today is a leader in systems that provide true water management features that conserve water and save money. All at a price that makes sense for the customer. In addition to new stand alone and central control sys-tems, AMI also provides solutions for retrofits. The Aqua Connect™ provides a simple plug-n-play replacement for Maxicom systems.
By combining remote management capabilities, ET and weather based schedule adjustments, flow management and leak detection, AMI is able to provide a comprehen-sive water management tool for landscape contractors and water management professionals. From simple run time programming to more complex hydraulic manage-ment options, AMI provides stand alone and central con-trol systems that are simple to work with while achieving great results…all available from any computer, tablet or smart phone.
AMI turf irrigation controllers
provide:
• Central control capabilities • Remote programming • ET and real time weather based adjustments • True flow management • Leak detection • Automatic alerts • Automatic shut down for leaks and weather related events• Simple point and click programming and management
• Unlimited training and technical support
Water budgeting, reporting and
irrigation based on volume:
• Irrigation based on true volume rather than time • Daily, weekly, monthly and annual water budgeting • Stop/Start irrigation based on weather conditions • Tier based water management and reporting • Tier balancing across multiple meters in complex looped systems
ET / Weather / Sensor based automated
Scheduling using patented AMI Q
TM• Use local ET from public and private systems such as CIMIS • Use local weather station • Use moisture sensor or Aqua LoggerTM to automate irrigation • Use AMI Q to eliminate the need for running field wires
Remote asset and information management is vital in the oil, gas and mining industries. Process automation saves time and money. Remote areas can be especially trouble-some when it comes to data and information manage-ment.
AMI™ has solved that with the AMI Vapor™ and its patented communication technology. Satellite communication allows us to talk to any device, anywhere in the world.
Today’s ever changing regulations can make compliance very challenging. AMI’s logging technology solves this age old problem. Our customized reporting features allow you stay in compliance when regulations change. Our cloud based data warehouse allows you to track and store your data indefinitely. In today’s world, information is power.
AMI provides complete cloud based solutions for
oil, gas and mining operations management.
Remotely monitor and manage your
processes from A to Z…
Well source Well source Well source
Pond/Pit or other water source to pump from
Diesel pump 3" or 4" poly lines Diesel booster pump Fill-up manifold top or ground positioned 10" aluminum Or Lay-Flat 10" aluminum Or Lay-Flat
Production water supply
Tanks outtake
10" flowmeter – pumped water
10" fl owmeter delivered water 4" flowmeter x number of poly lines 1 1 2 3 4 5 6 7 8 9 10 11
Monitor one or all points within the
system from one dashboard.
1. Flow meter reading 2. Pump management
3. Diesel booster pump management with fuel level monitoring
4. Fill up and tank-top manifold monitoring
5. Tank level monitoring 6. Leak detection
7. Level monitroing of wells and cisterns 8. Water source fill meter vs. well source meter resolution comparison
9. Well source level monitor with multi-source switching
10. Fill up polly line pressure monitoring 11. Touch and video surveilance monitor
for tank outtake.
OEM/Private Label
Lighting
AMI™ provides custom cloud based lighting applica-tions for lighting and controls manufacturers. AMI specializes in commercial outdoor lighting applications such as ball fields, parks, parking lots, street lights, etc. The AMI system provides secure access to users who can control, monitor and make schedule changes from any computer, laptop, tablet or smart phone.
Anywhere, anytime lighting control.
Our wireless systems allow us to communicate to light-ing anywhere without the need for radios or phone lines. Our simple and easy to use system is fully automated, no need to call a dispatcher to program lights.
Program, monitor, or simply turn on/off the targeted lights from any web enabled device. Scheduling can be done on-line or automatically via photo cell technology. How do today’s manufacturers keep up with new
tech-nology? Most manufacturers are experts at designing, engineering and building of their own products. How-ever, when it comes to cloud technology they don’t know where to turn.
In today’s rapidly changing technology world many com-panies are faced with tough decisions when it comes to R&D of new products. Many manufacturer’s understand the need to “bring their products to the cloud” today. Utilizing the latest technology is paramount in providing customers what they need while at the same time keep-ing ahead of the competition.
AMI™ specializes in communication solutions…so there is never a need to worry about 2G to 3G…and 3G to 4G…and 4G to LTE…AMI’s engineers are working on the next level of communication solutions before they are even available to the public. Keeping ahead of this fast moving technology is one of the many things that sets AMI apart from the competition. Uptime, reliability and security come with every AMI engineered solution. AMI offers customized cloud technology solutions for manufacturers. Wherever you are in your project, AMI can help bring you to the cloud on time and under budget.
OEM Solutions available for:
• Hardware
• Software
• Communication • Server farms
• Data storage
• Services
Your Company Here
AMI
™
ES (Engineered Solutions)
In addition to off the shelf, turn-key solutions, AMI™ specializes in custom engineering solutions. AMI has developed patented custom engineering software that allows us to help solve your engineering challenges in the way we know best…on time, under budget and within the cloud.
AMI™ ES included all of AMI’s standard cloud solution offerings...access from anywhere at anytime. No software to purchase, no dedicated computer systems, no radios or phone lines needed…simple, easy to use and all with unlimited technical support.
Full desktop view:
screen with integrated
Google map
• Multi-Level Access from any computer • Integrated Google Map
• Remote OTAP
• Secure (highly encrypted)
Tablet view for quick
anywhere anytime
touch screen
enabled access
Mobile view for smart phone for
anywhere graphical access
AMI
Pump
Controller
functions
overview
General (full functionality using cloud access) P1 VFD Connect
Cloud cellular data connection GPRS/3G/4G ● ●
Cloud Ethernet LAN/WAN data connection ● ●
Control Panel - controller user interface (LCD + Knob)
Diagnostics da
ta
● ●Sensors monitoring ● ●
Cloud connection status + communication characteristic
s
● ●Communication interface
Integral RS-485 ● ●
RS-232 adapter ● ●
USB firmware update ● ●
Inputs/Outputs
Analog (0-3, 0-10VDC or 4-20mA) or discrete inputs 1 1
High-speed counter digital input (Max. 15VDC) 1 1
Relay outputs (contacts rating 10A 250V) NC|Com|NO 2
Additional relay output option (contacts rating 10A 250V) Modbus registers interface
Read command: Holding, Coils; Max. registers 128 128
Write command: Holding, Coils; Max. registers 128 128
Alert on register value change (use up/low thresholds) ● ●
Built-in reed-switch and high-speed flow meter integration ● ●
Log registers data ● ●
Scheduled “write” commands: ex. start/stop pump ● ●
Flow monitoring and control; detect high-flow, low-flow ● ●
Conditional “write” command based on “read” registers value
thresholds ● ●
Technical data
Voltage supply: 12 VDC
Voltage supply: 110-240 VAC ● ●
Rating: 12 VDC @ pick [mA] 300 300
Solar panel + Battery option
Ambient temperature: 0 - 150 Fahrenheit ● ●
Relative humidity: 90% ● ●
General (full functionality using cloud access) 8x7
Cloud cellular data connection GPRS/3G/4G •
Cloud ethernet LAN/WAN data connection ●
Control Panel - controller user interface (LCD + Knob)
Diagnostics da
ta
cloudSensors monitoring cloud
Cloud connection status + communication characteristic
s
cloudCommunication interface
Integral RS-485 ●
RS-232 adapter
USB firmware update ●
Inputs/Outputs
Analog (0-3, 0-10VDC or 4-20mA) or discrete inputs 6
High-speed counter digital input (Max. 15VDC) 1
Relay outputs (contacts rating 10A 250V) NC|Com|NO 2
DC latch Soleniod (8W max.) outputs 6
Additional relay output option (contacts rating 10A 250V) 5
Applications
Alert on input value change (use high/low thresholds ) ●
Built-in reed-switch and high-speed flow meter integration ●
Log registers data ●
Scheduled “write” commands: ex. start/stop relays ●
Flow monitoring and control; detect high-flow, low-flow; ●
Conditional “write” command based on “read” registers value thresholds. Ex. activate output based on input value change
● Technical data
Operation Voltage: 12 VDC ●
Voltage supply: 110-240 VAC (build-in power supply) ●
Rating: 12 VDC @ pick [mA] 200
Solar panel + Battery option ●
Ambient temperature: 0 - 150 Fahrenheit ●
Relative humidity: 90% ●
External AC->DC adapter optional
General (full functionality using cloud access) Description
Cloud cellular data connection GPRS/3G/4G Nationwide coverage with T-mobile,
AT&T and Verizon
Cloud Ethernet LAN/WAN data connection ●
Control Panel - controller user interface (LCD + Knob)
monitoring data All data which is available online is
viewable locally on the controller display Running stations/programs flow data
Controller operation Parameters setup, testing Run
manual stations/programs
Cloud connection status + communication characteristics ●
Communication interface
Integral RS-485 ●
RS-232 adapter ●
USB firmware update ●
Inputs/Outputs Max. # stations wired+wireless = 96
Analog (4-20mA or 1-5VDC) or digital inputs (discrete or counter) 16
High-speed counter digital input (Max. 15VDC) 1
24 VAC solenoid outputs 12
Relay outputs 4
Wireless Valves up to 80
Wireless RTU
UHF Radio base station 1-25 Watt Motorola CM200
Max. # of wireless RTU per controller 0 to 84
Wireless RTU battery Lithium 3.6V 7.2AH C-size
RTU models (max. # of outputs) DC Latch RTU2, RTU4
RTU antenna Integral
pH Sensor (optional)
Range 0-14
Output 4-40mA Max. 300 Ohm
Non-linearity (0-14) 0.03
Accuracy 0.05
EC Sensor (optional)
Range 0-10 mS
Output 4-40mA Max. 300 Ohm
Non-linearity (0-10mS) 0.02
Accuracy 0.04 ±2% of EC value
Measurement frequency 1350 ±50Hz
Electrode Temperature compensation element PT-100
Technical data
DC model Voltage supply 12 VDC
AC model Voltage supply 110-240 VAC
Rating: 12 VDC @ pick - no radio 300 mA
Rating: 12 VDC @ pick - with radio 5A
Solar panel + Battery option 5-10W (model depended)
Operating temperature 10 - 150 Fahrenheit
Relative humidity 90%
Turf and Landscape Irrigation
Data logging Description
Logging interval 1, 5, 15, 30 [minute] .. 1, 2, 3, 4 [hour]
Sensor scanning time 1 - 5 [minute]
Max. logged data uploads per day 12
Max. number of sensors logged 6
Sensors
Number of sensors 1 to 6
Sensor type (0-3V, 0-10V, 4-20mA) Tensiometers, SMS, level (tank, well), temperature, pres-sure, counters (etc. flow-meter, RPM)
Sensor connection Weather proof connector (IP67) with pigtail
Modes of operation
Standard power Logger is powered all time, scanning the sensors once a
minute for threshold checking.
Log data records every logging interval minutes Upload data on the configured upload times The logger is always on and accessible online
Low power Logger is sleeping between sensors scanning once a minute
for threshold checking.
Cellular modem is off and comes on only for data upload or alert notification.
Log data records every logging interval minutes Upload data on the configured upload times
The logger configuration is batched at the server and up-dating once the logger connects online on upload or alert notification
Push button Pushing the button will wake up the logger (if sleeping)
and send the logged data records to the server. if in sleep mode, the logger will stay on for 15 min and go back to sleep.
Loggers and other systems
AMI AG connectivity AG controller irrigation control, start/stop irrigation
sched-ule, per logger sensors’ notification. Example:
• Irrigation start cycle once 6” soil moisture sensor sends a “dry” notification
• Irrigation stop cycle once 12” soil moisture sends “wet” notification
Technical data
DC model Voltage supply 12 VDC
Rating: 12 VDC @ pick 250 mA
Rating: 12 VDC @ sleep 5 mA
Solar panel + Battery option 5-10W (model depended)
Operating temperature 10 - 150 Fahrenheit
AC Irrigation Controllers Functions Overview
General (full functionality using cloud access) 12S 24S 36S 48S
Cloud cellular data connection ● ● ● ●
Cloud Ethernet LAN/WAN data connection ● ● ● ●
Control Panel - controller user interface (LCD + Knob)
Manual run station/progr
am
● ● ● ●Schedules edits ● ● ● ●
Sensor monitoring ● ● ● ●
Cloud connection status + communication characteristic
s
● ● ● ●Irrigation interface (sensors and solenoid outputs)
On-board solenoid outputs (24VAC activation) 12 24 36 48
High-speed (square pulse < 2KHz) Flow-meter input 1 1 1 1
Max. flow meters and Mainlines per controller 2 2 2 2
Analog (0-10VDC or 4-20mA) inputs 2 4 6 8
Sensors: Rain-bucket, rain-switch, solar radiation,
tem-perature, soil-moisture, pressure ● ● ● ●
Max. Q devices per controller; Q outputs are addition to the
on-board outputs. 12 24 36 48
Irrigation features
Max. daily irrigation schedules 24 24 24 24
Max runtimes per program; flexible runtime sequence 24 24 24 24
Any station can be assigned as Mainline Master Valve ● ● ● ●
Schedule by irrigation weekdays ● ● ● ●
Irrigate by time/volume per schedule ● ● ● ●
Schedule start/stop modes: start-time (max. 12 daily),
Cycle/soak, Input (sensor) start/suspend ● ● ● ●
Flow monitoring and control; detect Mainline break,
un-opened water, un-controlled water, high-flow, low-flow; ● ● ● ●
Irrigation loops support ● ● ● ●
Technical data
Voltage supply US model: 115VAC Voltage supply EU model: 240 V
AC
● ● ● ●
Rating 24VAC 96W (Max. 12 4W solenoids running concurrently) ● ● ● ●
Ambient temperature: 0 - 150 Fahrenheit ● ● ● ●
