ALUMINUM CONDUCTOR CABLE

Table Of Contents

Aluminum Service Entrance Cable Type SE Style R

. . . .2

Aluminum Service Entrance Cable Type SE Style U

. . . .3

Aluminum XHHW-2

. . . .4

Aluminum RHH/RHW-2/USE-2

. . . .5

Mobile Home Feeder . . . .6

ACSR (Steel Reinforced)

. . . .7-8

AAC . . . .9

AAAC . . . .10

Single Conductor 600 Volt URD

. . . .11

Duplex Conductor 600 Volt URD

. . . .11

Triplex Conductor 600 Volt URD

. . . .12

Quadruplex Conductor 600 Volt URD

. . . .13

8000 Series 600 Volt URD

. . . .14

Covered Line Wire

. . . .15

Duplex Overhead (Service Drop)

. . . .16

Triplex Overhead (Service Drop)

. . . .17-18

Quadruplex Overhead (Service Drop)

. . . .19

TYPE SE, STYLE R. 600 VOLT. ALUMINUM ALLOY (AA-8000)

CONDUCTORS: INDIVIDUAL CONDUCTORS RATED XHHW-2.

OVERALL SUNLIGHT RESISTANT PVC JACKET.

APPLICATION:

Primarily used as panel feeder in multiple unit dwellings and other branch circuits. Maximum operating temperature not to exceed 90°C in wet locations. Voltage rating is 600 volts.

SPECIFICATIONS:

SER conductors are designed according to the internationally recognized and accepted standards: ASTM B800, B801 • UL 44 854

CONSTRUCTION:

Conductor: 8000 series aluminum alloy compact stranded • Insulation: Cross-linked polyethylene (XLPE) type XHHW-2. •Colored insulation identification: 2 insulated conductors: black and white. 3 insulated conductors: black, white, and red. 4 insulated conductors: black, white, red, and blue. • Assembly: Two, three, or four insulated conductors and a bare grounded conductor cabled together and covered with a reinforced binder tape. Jacket: Grey sunlight resistant polyvinyl chloride (PVC).

ALUMINUM SERVICE ENTRANCE

CABLE – TYPE SE STYLE R

Insulated Conductor Size/AWG Bare Conductor Size/AWG Nominal Outside Diameter (Inches) Aluminum Weight Lbs./1000 Approx. Net Weight Lbs./1000 Approx. Gross Weight Lbs./1000 AMPS 90 Deg. C AMPS Dwelling Alum Weight lb/kft Per ASTM *no twist factor

8 8 0.488 47 97 203 45 N/A 46.5 AWG Size lb/kft 6 6 0.574 74 138 253 60 N/A 74.1 8 15.5 4 6 0.632 104 177 305 75 N/A 103.3 6 24.7 4 4 0.669 118 193 321 75 N/A 117.9 4 39.3 2 4 0.748 165 254 397 100 100 164.3 2 62.5 2 2 0.788 188 280 423 100 100 187.5 1 78.8 1 1 0.884 237 349 514 115 110 236.4 1/0 99.4 1/0 2 0.915 261 384 571 135 125 261.3 2/0 125 1/0 1/0 0.964 299 423 610 135 125 298.2 3/0 158 2/0 1 0.951 330 459 668 150 150 328.8 4/0 199 2/0 2/0 1.050 377 513 722 150 150 375 250 235 4/0 2/0 1.193 526 690 999 205 200 523 300 282 4/0 4/0 1.264 599 766 1075 205 200 597 8 8 0.571 62 128 243 45 N/A 62 6 6 0.650 99 182 303 60 N/A 98.8 4 6 0.736 143 240 268 75 N/A 142.6 2 4 0.863 227 346 500 100 100 226.8 1 3 0.973 286 435 622 115 110 285.9 1/0 2 1.061 362 526 735 135 125 360.7 2/0 1 1.164 455 637 880 150 150 453.8 3/0 1/0 1.274 573 776 1085 175 175 573.4 4/0 2/0 1.390 726 948 1279 205 200 722 250 3/0 1.601 868 1106 1437 230 225 863 300 4/0 1.741 1052 1311 1642 255 250 1045 FOUR CON-2 4 0.973 290 438 659 100 100 289.3 2/0 1 1.299 581 807 1138 150 150 578.8 4/0 2/0 1.557 926 1204 1689 205 200 921 250 3/0 1.798 1105 1404 1889 230 225 1098 300 4/0 1.950 1335 1662 2147 255 250 1327

THREE CONDUCTOR SER WITH A BARE GROUND TWO CONDUCTOR SER WITH A BARE GROUND

FOUR CONDUCTOR SER WITH A BARE GROUND

ASTM REF

*no twist factor

NOTE: Standard Packaging: Bulk, 1000', 500'

*Allowable Ampacities: Allowable ampacities shown are for general use as specified by the National Electric Code, 2005 edition, section 310-15. 60ºC – when terminated to equipment for circuits rated 100 amperes or less or marked for #14 through #1 conductors.

NOTE: Standard Packaging: Bulk, 1000', 500'

*Allowable Ampacities: Allowable ampacities shown are for general use as specified by the National Electric Code, 2005 edition, section 310-15. 60ºC – when terminated to equipment for circuits rated 100 amperes or less or marked for #14 through #1 conductors.

70ºC – when terminated to equipment for circuits rated over 100 amperes or less or marked for conductors larger than #1. 90ºC – wet or dry locations

Dwelling – for dwelling units, conductors shall be permitted at listed ampacities to be utilized as 120/240-volt, 3-wire, single-phase service conductors that supply the total load. *Except as permitted by UL standard 44, UL standard 854 and ASTM B-801.

ALUMINUM SERVICE ENTRANCE

CABLE – TYPE SE STYLE U

TYPE SE, STYLE U. 600 VOLT. ALUMINUM ALLOY (AA-8000) CONDUCTORS INDIVIDUAL CONDUCTORS RATED XHHW-2. ALUMINUM ALLOY CONCENTRIC NEUTRAL

OVERALL SUNLIGHT RESISTANT PVC JACKET.

APPLICATION:

Mainly used to convey power from the service drop to the meter base and from the meter base to the distribution panel board. SEU can also be used in certain branch circuits as permitted by the 2005 National Electrical code. It is used in wet or dry locations. It is designed for use at 600 volts or less.

SPECIFICATIONS:

SEU conductors are manufactured and tested according with UL standards 44 and 854. Federal Specifications J-C-30B and requirements of the National Electrical Code.

CONSTRUCTION:

• Conductor: aluminum alloy compact stranded. • Cable: composed of concentrically applied neutral and reinforcement tape. • Jacket: Grey sunlight resistant polyvinyl chloride (PVC).

Insulated Conductor Size/AWG Bare Conductor Size/AWG Nominal Outside Diameter (Inches) Aluminum Weight Lbs./1000

Approx. Net Weight Lbs./1000

Approx. Gross Weight Lbs./1000 AMPS 90 Deg. C AMPS Dwelling 8 8 0.407 47 104 210 45 N/A 6 6 0.458 75 143 259 60 N/A 4 6 0.502 104 184 312 75 N/A 4 4 0.505 118 198 326 75 N/A 2 4 0.559 165 259 402 100 100 2 2 0.559 188 282 421 100 100 1 1 0.625 236 353 519 115 110 1/0 2 0.647 261 387 574 135 125 1/0 1/0 0.661 298 438 626 135 125 2/0 1 0.702 329 467 677 150 150 2/0 2/0 0.719 376 516 728 150 150 4/0 2/0 0.818 524 692 1003 205 200 4/0 4/0 0.857 599 770 1072 205 200

APPLICATION:

XHHW-2 conductors are primarily used in conduit or recognized raceways for services, feeders, and branch circuit wiring as specified in the National Electrical Code. XHHW-2 conductors may be used in wet or dry locations at temperatures not to exceed at 90°C. Voltage rating for XHHW-2 conductors is 600 volts.

DESCRIPTION:

XHHW-2 aluminum conductors are AA-8000 series aluminum alloy, compact stranded. Insulation is flame retardant, abrasion resistant, moisture and heat resistant black cross-linked polyethylene.

SPECIFICATIONS:

XHHW-2 conductors meet or exceed UL standard 44, Federal Specification J-C-30B, and requirements of the National Electrical Code B • ASTM standards B800 and B801.

ALUMINUM XHHW-2

Conductor Size (AWG or kcmil) Conductor Number of Wires Conductor Diameter (mils) Insulation Thickness (mils) Approx. Outside Diameter (inches) Approx. Cable Weight lbs./1000 ft. Ampacities* 90°C 8 7 134 45 0.227 30 45 6 7 169 45 0.262 42 60 4 7 213 45 0.306 58 75 2 7 268 45 0.361 86 100 1 18 299 55 0.412 110 115 1/0 18 335 55 0.449 134 135 2/0 18 378 55 0.489 163 150 3/0 18 423 55 0.536 200 175 4/0 18 476 55 0.588 247 205 250 35 520 65 0.653 296 230 300 35 571 65 0.703 359 255 350 35 614 65 0.749 401 280 400 35 657 65 0.792 453 305 500 35 736 65 0.869 556 350 600 58 815 80 0.979 679 385 700 58 877 80 1.040 782 420 750 58 909 80 1.071 833 435 900 58 999 80 1.162 987 480 1000 58 1059 80 1.223 1090 500

NOTE: Standard Packaging: Bulk, 1000', 500'

*Ampacities for not more than three conductors in raceway or cable or earth (directly buried), based on ambient temperature of 30°C per Table 310-16 of the 1990 National Electrical Code (NFPA 70-1990).

UNDERGROUND SERVICE ENTRANCE CABLE. 600 VOLT. ALUMINUM ALLOY (AA-8000) CONDUCTOR.

CROSS-LINKED POLYETHYLENE (XLPE) INSULATION. HIGH HEAT AND MOISTURE RESISTANT.

APPLICATION:

The product can be installed as a General Purpose Building Wire, used in service entrance, feeders and branch circuits applications for residential, commercial, industrial, and transportation environments for permanent installations utilizing 600 volts or less. Thanks to its excellent performance in overload or short circuit situations, and its heavy wall thickness, the product is ideal for underground service entrance (USE) in wet locations. RHH/RHW-2/USE-2 conductors are suitable for directly buried installations. RHH-RHW-2/USE-2 conductors can be used in environments where superior insulation toughness and chemical resistance is required. The product’s high resistance to humidity make this cable suitable for wet locations, for outdoors, and for weather resistant use.

DESCRIPTION:

Type RHH/RHW-2/USE-2, is a single insulated conductor of AA-8000 series aluminum alloy, compact stranded insulated with black thermoset crosslinked polyethylene (XLPE), designed to operate not over 600 volts, nominal, and at a maximum operating temperature of 90°C dry or wet.

INSTALLATION:

RHH/RHW-2/USE-2 conductors can be installed in electrical metallic tubing, PVC conduits and other raceways, in free air messenger support or directly buried. It is recommended that the installation instructions indicated by the Local Electric Code, or any equivalent be followed so that the safeguarding of persons and the integrity of the product will not be affected by deficiencies in the installation.

NOTE: Standard Packaging: Bulk, 1000', 500'

*Allowable Ampacities: Allowable ampacities shown are for general use as specified by the National Electrical Code, 2005 Edition, section 310-15. 60°C - when terminated to equipment for circuits rated 100 amperes or less or marked for #14 through #1 conductors.

75°C - when terminated to equipment for circuits rated over 100 amperes or less or marked for conductors larger than #1. 90°C - RHH dry locations. RHW-2 and USE-2 wet or dry locations.

*Except as permitted by UL standard 44, UL standard 854 and ASTM B-801.

ALUMINUM RHH/RHW-2/USE-2

AWG Conductor Diameter (inches) Insulation Thickness (mils) Nominal O.D. (inches) 60°C. 75°C 90°C Approx.net Weight per 1000 feet (lbs.) 8 0.134 60 0.257 30 40 45 36 6 0.169 60 0.292 40 50 60 49 4 0.213 60 0.336 55 65 75 65 2 0.268 60 0.391 75 90 100 94 1 0.299 80 0.462 85 100 115 126 1/0 0.335 80 0.499 100 120 135 151 2/0 0.378 80 0.539 115 135 150 182 3/0 0.423 80 0.586 130 155 175 221 4/0 0.476 80 0.638 150 180 205 269 250 0.520 95 0.713 170 205 230 326 300 0.571 95 0.763 190 230 255 381 350 0.614 95 0.809 210 250 280 435 400 0.657 95 0.852 225 270 305 489 500 0.736 95 0.929 260 310 350 595 700 0.877 110 1.100 310 375 420 829 750 0.909 110 1.131 320 385 435 881 1000 1.059 110 1.283 375 445 500 1145 Allowable Ampacities*

DESCRIPTION:

Mobile Home Feeder is designed for mobile homes as service entrance cable. The cable meets the requirements of Underwriters Laboratories Inc., Standard #854 for Type USE-2 and Standard #44 for Types RHH and RHW-2. The cable has a maximum operating temperature of 90°C in dry and wet locations. Rated at 600 volts, the cable is sunlight resistant and is approved for use in accordance with the recommendations of the National Electrical Code in raceways and underground installations. Aluminum alloy conductor is recognized by ASTM in Standards B800 and B801.

CONDUCTOR:

Aluminum compact stranded (AA-8000 Series aluminum alloy).

INSULATION:

Sunlight Resistant Black cross-linked polyethylene (XLPE).

CONSTRUCTION:

Quadruplexed type USE-2/RHH/RHW-2 aluminum alloy conductors. The grounded (neutral) conductor is identified by a continuous white longitudinal stripe. The equipment grounding conductor is identified by total green surface coating.

MOBILE HOME FEEDER

Cable Construction AMPS Insulation (mils) Diameter (inches) Insulation (mils) Diameter (inches) Insulation (mils) Diameter (inches) Cable Diameter (inches) Nominal Weight Lbs./1000 2-2-4-6 100 60 0.390 60 0.335 60 0.290 0.944 295 2-2-2-4 100 60 0.390 60 0.390 60 0.335 0.944 343 2/0-2/0-1-4 150 80 0.540 80 0.460 60 0.335 1.301 548 2/0-2/0-2/0-1 150 80 0.540 80 0.540 80 0.460 1.301 664 4/0-4/0-2/0-4 200 80 0.635 80 0.540 60 0.335 1.540 778 4/0-4/0-4/0-2/0 200 80 0.635 80 0.635 80 0.540 1.540 1018 Insulated Equipment Grounding Conductor Insulated Grounded (Neutral) Conductor Insulated Phase Conductor

APPLICATIONS:

Used as bare overhead transmission cable and as primary and secondary distribution cable. ACSR offers optimal strength for line design. Variable steel core stranding for desired strength to be achieved without sacrificing ampacity.

CONSTRUCTION:

Aluminum alloy 1350-H19 wires, concentrically stranded around a steel core. Core wire for ACSR is available with class A, B or C galvanizing; aluminum coated (AZ); or aluminum-clad steel core. (AL). Additional corrosion protecton is available through the application of grease to the corer or infusion of the complete cable with grease.

SPECIFICATIONS:

ACSR bare conductor meets or exceeds the following ASTM specifications:

B-230Aluminum wire, 1350-H19 for Electrical Purposes

B-231Aluminum Conductors, Concentric-Lay-Stranded

B-232Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR)

B-341Aluminum-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR/AZ)

B-498Zinc-Coated Steel Core Wire for Aluminum Conductors, Steel Reinforced (ACSR)

B-500Metallic Coated Stranded Steel Core for Aluminum Conductors, Steel Reinforced (ACSR)

ACSR – ALUMINUM CONDUCTOR

STEEL REINFORCED

Code Word Size (AWG or KCM) STR (AL/ STL) AL STL Steel Core Comp. Cable OD AL STL Total AL AL STL Rate Breaking Strength (lbs) DC @ 20ºC AC @ 75ºC Rating (AMPS) Turkey 6 6/1 0.0661 0.0661 0.0661 0.198 24.5 11.6 36.1 67.9 32.1 1,190 0.641 0.806 105 Swan 4 6/1 0.0834 0.0834 0.0834 0.25 39 18.4 57.4 67.9 32.1 1,860 0.403 0.515 140 Swanate 4 7/1 0.0772 0.1029 0.1029 0.257 39 28 67 58.13 41.87 2,360 0.399 0.519 140 Sparrow 2 6/1 0.1052 0.1052 0.1052 0.316 62 29.3 91.3 67.9 32.1 2,850 0.254 0.332 164 Sparate 2 7/1 0.0974 0.1299 0.1299 0.325 62 44.7 105.7 58.13 41.87 3,640 0.251 0.338 184 Robin 1 6/1 0.1181 0.1181 0.1181 0.354 78.2 36.9 115.1 67.9 32.1 3,550 0.201 0.258 212 Raven 1/0 6/1 0.1327 0.1327 0.1327 0.398 98.7 46.6 145.3 67.9 32.1 4,380 0.149 0.217 242 Quail 2/0 6/1 0.1489 0.1489 0.1489 0.447 124.3 58.7 183 67.9 32.1 5,300 0.126 0.176 276 Pigeon 3/0 6/1 0.1672 0.1672 0.1672 0.502 156.7 74 230.7 67.9 32.1 6,620 0.1 0.144 315 Penguin 4/0 6/1 0.1878 0.1878 0.1878 0.563 197.7 93.4 291.1 67.9 32.1 8,350 0.0795 0.119 357 Waxwing 266.8 18/1 0.1217 0.1217 0.1217 0.609 250.3 39.2 289.5 86.45 13.55 6,880 0.0643 0.0787 449 Partridge 266.8 26/7 0.1013 0.0788 0.2364 0.642 251.7 115.6 367.2 68.53 31.47 11,130 0.0637 0.0779 475 Ostrich 300.0 26/7 0.1074 0.0835 0.2505 0.68 282.9 129.8 412.7 68.53 31.47 12,700 0.0567 0.0693 492 Merlin 336.4 18/1 0.1367 0.1367 0.1367 0.683 315.8 49.5 365.2 86.45 13.55 8,680 0.051 0.0625 519 Linnet 336.4 26/7 0.1137 0.0884 0.2642 0.72 317.1 145.4 462.5 68.53 31.47 14,100 0.0505 0.0618 529 Oriole 336.4 30/7 0.1059 0.1059 0.3177 0.741 3182 208.9 527.1 60.35 39.65 17,800 0.0505 0.0613 535 Chickadee 397.5 18/1 0.1486 0.1486 0.1486 0.743 373.1 58.5 431.6 86.45 13.55 9,940 0.0432 0.0529 576 Brant 397.5 24/7 0.1287 0.0858 0.2574 0.772 375 137 512 73.23 26.77 14,500 0.043 0.0526 584 Ibis 397.5 25/7 0.1236 0.0961 0.2882 0.783 374.7 171.9 546.6 68.53 31.47 16,300 0.0428 0.0523 587 Lark 397.5 30/7 0.1151 0.1151 0.3453 0.806 375.8 246.8 622.6 60.35 39.65 20,300 0.0425 0.0519 594 Pelican 477.0 18/1 0.1628 0.1628 0.1628 0.814 447.8 70.2 518 86.45 13.55 11,800 0.036 0.0442 646 Flicker 477.0 24/7 0.141 0.094 0.282 0.846 450.1 164.4 614.5 73.23 26.77 17,200 0.0358 0.0439 655 Hawk 477.0 26/7 0.1354 0.1053 0.3159 0.858 449.6 205.4 656 68.53 31.47 19,500 0.0356 0.0436 659 Hen 477.0 30/7 0.1261 0.1261 0.3783 0.883 451.1 296.2 747.3 60.35 39.65 23,800 0.0354 0.0433 666 Osprey 556.5 18/1 0.1758 0.1758 0.1758 0.879 522.2 81.8 604 86.45 13.55 13,700 0.0308 0.0379 711 Parakeet 556.5 24/7 0.1523 0.1015 0.3045 0.914 525.1 191.7 716.8 73.23 26.77 19,800 0.0307 0.0376 721 Dove 556.5 26/7 0.1463 0.1138 0.3414 0.927 525 241 766 68.53 31.47 22,500 0.0306 0.0375 726 Eagle 556.5 30/7 0.1362 0.1362 0.4086 0.953 526.3 345.6 871.9 60.35 39.75 27,800 0.0303 0.0372 734 Peacock 605.0 24/7 0.1588 0.1059 0.3177 0.953 570.4 208.7 779.6 73.23 26.77 21,600 0.0282 0.0346 760 Squab 605.0 26/7 0.1525 0.1186 0.3558 0.966 570.4 261.8 832.2 68.53 31.47 24,300 0.0281 0.0345 765 Wood Duck 605.0 30/7 0.142 0.142 0.426 0.994 572 375.6 947.6 50.35 39.55 28,900 0.0279 0.0342 774 Teal 605.0 30/19 0.142 0.0852 0.426 0.994 572 367.4 939.4 60.89 39.11 30,000 0.0278 0.0342 773 Kingbird 636.0 18/1 0.188 0.188 0.188 0.94 497.2 93.6 690.8 86.45 13.55 15,700 0.027 0.0332 773 Swift 636.0 36/1 0.1329 0.1329 0.1329 0.93 596.9 46.8 643.7 92.8 27.2 13,800 0.0271 0.0334 769 Rook 636.0 24/7 0.1628 0.1085 0.3255 0.977 600 219.1 819.1 73.23 26.77 22,600 0.0268 0.033 784 Grosbeak 636.0 26/7 0.1564 0.1216 0.3648 0.99 599.2 276.2 874.1 68.53 31.47 25,200 0.0267 0.0328 789 Scoter 636.0 30/7 0.1456 0.1456 0.4368 1.019 601.4 394.9 996.3 60.35 39.55 30,400 0.0256 0.0325 798 Egret 636.0 30/19 0.1456 0.0874 0.437 1.019 601.4 386.6 988 60.89 39.11 31,500 0.0266 0.0326 798

Diamenter (INS) Weight per 1000ft (lbs) Content % Resistance OHMS/1000ft

1. Resistance is calculated using ASTM standard increments of stranding, and metal conductivies of 61.2% lACS for EC (1350) and 8% of ACS for steel. AC (60Hz) resistance included current dependent hysteresis loss factor for 1 and 3 layer constructions.

2. Current ratings are based on 75ºC conductor temperature, 25ºC ambient, 2st wind, 96 watts/sq. foot sun. 0.5 coefficients of emissivity and absorption.

ACSR – ALUMINUM CONDUCTOR

STEEL REINFORCED

(continued)

Flamingo 666.6 24/7 0.1667 0.1110 0.3330 1.000 629.1 229.7 858.8 73.23 26.77 23,700 0.0256 0.0315 807 Gannet 666.6 26/7 0.1501 0.1245 0.2725 1.014 628.7 288.5 917.2 68.53 31.47 26,400 0.0255 0.0313 812 Stilt 715.5 24/7 0.1727 0.1151 0.3453 1.036 675.2 246.5 921.7 73.23 26.77 25,500 0.0239 0.0294 844 Starling 715.5 26/7 0.1659 0.1290 0.3870 1.051 675.0 309.7 984.7 68.53 31.47 28,400 0.0238 0.0292 849 Redwing 715.5 30/19 0.1544 0.0926 0.4630 1.081 676.3 434.0 1110.0 60.89 39.11 34,600 0.0236 0.0290 859 Coot 795.0 36/1 0.1486 0.1486 0.1486 1.040 746.2 58.5 804.7 92.80 7.20 16,800 0.0217 0.0268 884 Cuckoo 795.0 24/7 0.1820 0.1213 0.3640 1.092 749.9 273.8 1024.0 72.23 26.77 27,900 0.0215 0.0265 901 Drake 795.0 26/7 0.1749 0.1360 0.4080 1.108 750.3 344.2 1094.0 68.53 31.47 31,500 0.0214 0.0261 907 Tern 795.0 45/7 0.1329 0.0886 0.2660 1.063 749.8 146.1 895.9 83.69 16.31 22,100 0.0216 0.0269 887 Condor 795.0 54/7 0.1213 0.1213 0.3639 1.092 749.5 273.6 1023.0 73.25 26.75 28,200 0.0215 0.0272 889 Mallard 795.0 30/19 0.1628 0.0977 0.4885 1.140 751.9 483.1 1235.0 60.89 39.11 38,400 0.0213 0.0261 918 Ruddy 900.0 45/7 0.1414 0.0943 0.2829 1.131 848.7 165.5 1014.0 83.69 16.31 24,400 0.0191 0.0239 958 Canary 900.0 54/7 0.1291 0.1291 0.3873 1.162 849.0 309.9 1149.0 73.25 26.75 31,900 0.0190 0.0241 961 Rail 954.0 45/7 0.1456 0.0971 0.2913 1.165 899.9 175.5 1075.0 83.69 16.31 25,900 0.0180 0.0225 993 Cardinal 954.0 54/7 0.1329 0.1329 0.3987 1.196 900.7 328.4 1228.0 73.25 26.75 33,800 0.0179 0.0228 996 Ortolan 1033.5 45/7 0.1515 0.1010 0.3030 1.212 974.3 189.8 1164.0 83.69 16.31 27,700 0.0167 0.0209 1043 Curlew 1033.5 54/7 0.1383 0.1383 0.4149 1.245 974.3 355.6 1330.0 73.25 26.75 36,600 0.0165 0.0211 1047 Bluejay 1113.0 45/7 0.1573 0.1049 0.3147 1.259 1050.0 204.8 1225.0 83.69 16.31 29,800 0.0155 0.0194 1092 Finch 1113.0 54/19 0.1436 0.0862 0.4310 1.293 1056.0 276.1 1432.0 73.75 26.75 39,100 0.0154 0.0197 1093 Bunting 1192.5 45/7 0.1628 0.1085 0.3255 1.302 1125.0 219.1 1344.0 83.69 16.31 32,000 0.0144 0.0182 1139 Grackle 1192.5 54/19 0.1486 0.0892 0.4460 1.338 1130.0 402.7 1533.0 73.75 26.25 41,900 0.0144 0.0184 1140 Bittern 1272.0 45/7 0.1681 0.1121 0.3363 1.345 1200.0 233.9 1433.0 83.69 16.31 34,100 0.0135 0.0171 1184 Pheasant 1272.0 54/19 0.1535 0.0921 0.4605 1.382 1206.0 429.3 1635.0 73.75 26.25 43,500 0.0135 0.0173 1187 Dipper 1351.5 45/7 0.1733 0.1155 0.3465 1.386 1275.0 248.3 1525.0 83.69 16.31 36,200 0.0127 0.0162 1229 Martin 1351.5 54/19 0.1582 0.9049 0.4745 1.424 1281.0 455.8 1737.0 72.75 26.25 46,300 0.0127 0.0163 1232 Bobolink 1431.0 45/7 0.1783 0.1189 0.3567 1.427 1350.0 263.1 1613.0 83.69 16.31 38,300 0.0120 0.0153 1272 Plover 1431.0 54/19 0.1628 0.0977 0.4885 1.465 1357.0 483.1 1840.0 73.75 26.25 49,100 0.0120 0.0155 1275 Nuthatch 1510.5 45/7 0.1832 0.1221 0.3663 1.465 1425.0 277.4 1702.0 83.69 16.31 40,100 0.0144 0.0146 1313 Parrot 1510.0 54/19 0.1672 0.1003 0.5015 1.505 1431.0 509.2 1940.0 73.75 26.25 51,700 0.0114 0.0147 1318 Lapwing 1590.0 45/7 0.1880 0.1253 0.3759 1.504 1499.0 292.2 1793.0 83.69 16.31 42,200 0.0108 0.0139 1354 Falcon 1590.0 54/19 0.1716 0.1030 0.5150 1.545 1499.0 537.0 2044.0 73.75 26.25 54,500 0.0180 0.0137 1359 Chukar 1780.0 84/19 0.1456 0.8740 0.4370 1.602 1688.0 386.6 2975.0 81.30 18.70 51,000 0.0097 0.0125 1453 Bluebird 2156.0 84/19 0.1602 0.0961 0.4805 1.762 2044.0 467.4 2511.0 81.30 18.70 60,300 0.0081 0.0106 1623 Kiwi 2167.0 72/7 0.1735 0.1157 0.3471 1.735 2055.0 248.9 2303.0 89.20 10.80 49,800 0.0080 0.0106 1607 Thrasher 2312.0 76/19 0.1744 0.0814 0.4070 1.802 2191.0 335.4 2527.0 86.73 13.27 56,700 0.0075 0.0100 1673 Code Word Size (AWG or KCM) STR (AL/ STL) AL STL Steel Core Comp. Cable OD AL STL Total AL STL Rate Breaking Strength (lbs) DC @ 20ºC AC @ 75ºC Rating (AMPS) Diamenter (INS) Weight per 1000ft (lbs) Content % Resistance

APPLICATION:

Stranded 1350 aluminum conductors:

Class AAfor bare conductors used in overhead lines.

Class Afor conductors to be covered with weather-resistant materials and for bare conductors where greater flexibility is required. Class is an indication of relative conductor flexibility, AA being the least flexible, AAC the most flexible.

SPECIFICATIONS:

AAC bare conductors meet or exceed the following ASTM specifications:

B-230Aluminum Wire, 1350-H19 for Electrical Purposes.

B-231Aluminum Conductors, Concentric-Lay-Stranded Aluminum 1350 conductors.

1. Resistance is calculated using ASTM standard increments of stranding and metal conductivity of 52.5% lACS, AC resistance at 60 Hz

2. Current ratings are based on 75°C conductor temperature, 25°C ambient. 2ft1s wind, 961 watts/sq. foot sun, 0.5 coefficients of emissivity and absorption.

AAC - ALL ALUMINUM CONDUCTOR

CODE WORD AWG NUMBER OF WIRES CLASS INDIVIDUAL WIRE COMP. CABLE CROSS SECTIONAL AREA (SQ. IN) WEIGHT PER 1000 (LBS) FT RATED BREAKING STRENGTH (LBS) DC @ 20ºC AC @ 75ºC RATING (AMPS) Iris 2 7/W AA,A 0.0974 0.292 .0521 62.3 1,235 0.26 0.318 185 Poppy 1/0 7/W AA,A 0.1228 0.368 0.0829 99.1 1,990 0.164 0.202 247 Aster 2/0 7/W AA,A 0.1379 0.414 0.1045 124.9 2,510 0.130 0.159 286 Phlox 3/0 7/W AA,A 0.1548 0.464 0.1318 157.5 3,040 0.103 0.126 331 Oxllp 4/0 7/W AA,A 0.1739 0.522 0.1662 198.6 3,830 0.0817 0.0999 383 Valerian 250 19/W A 0.1147 0.574 0.1964 234.7 4,520 0.0591 0.0846 425 Laurel 266.8 19/W A 0.1185 0.593 0.2095 250.5 4,970 0.0648 0.0793 444 Tulip 336.4 19/W A 0.1331 0.666 0.2642 315.8 6,150 0.0514 0.0630 513 Daffodil 350 19/W A 0.1357 0.679 0.2749 328.6 6,390 0.0435 0.0605 526 Canna 397.5 19/W AA,A 0.1447 0.724 0.3122 373.2 7,110 0.0435 0.0534 570 Cosmos 477 19/W AA 0.1584 0.793 0.3746 447.8 8,360 0.0362 0.0445 639 Syringa 477 37/W A 0.1135 0.795 0.3746 447.8 8,690 0.0362 0.0445 639 Hyacinth 500 37/W A 0.1162 0.813 0.3927 469.4 9,110 0.0346 0.0425 658 Dahlia 556.5 19/W AA 0.1711 0.856 0.4371 522.4 9,750 0.0311 0.0382 703 Orchid 636 37/W AA,A 0.1311 0.918 0.4995 597.0 11,400 0.0272 0.0335 765 Petunia 750 37/W AA 0.1424 0.997 0.5891 704.5 13,000 0.0230 0.0286 847 Arbutus 795 37/W AA 0.1446 1.026 0.6244 746.3 13,900 0.0217 0.0271 878 Magnolia 954 37/W AA 0.1606 1.124 0.7493 895.6 16,400 0.0181 0.0226 982 Goldenrod 954 61/W A 0.1251 1.126 0.7493 895.6 16,900 0.0181 0.0226 983 Bluebell 1033.5 37/W AA 0.1671 1.170 0.8177 970.2 17,700 0.0167 0.0210 1031 Larkspur 1033.5 61/W A 0.1302 1.172 0.8177 970.2 18,300 0.0167 0.0210 1032 Marigold 1113 61/W AA,A 0.1351 1.216 0.8742 1045.0 19,700 0.0155 0.0195 1079 Narcissus 1272 61/W AA,A 0.1441 1.300 0.999 1194.0 22,000 0.0136 0.0173 1169 Coreopsis 1590 61/W AA 0.1614 1.454 1.249 1493.0 27,000 0.0109 0.0141 1333 Cowslip 2000 91/W A 0.1482 1.630 1.571 1877.0 34,200 0.00864 0.0115 1518 Lupine 2500 91/W A 0.1657 1.823 1.964 2370.0 41,900 0.00698 0.00969 1706 STRANDING

APPLICATIONS:

Bare overhead conductor used for primary and secondary distribution. Designed utilizing a high-strength aluminum alloy to achieve a high strength-to-weight ratio; better sag characteristics. AAAC has higher resistance to corrosion than ACSR.

SPECIFICATIONS:

AAAC bare conductor meets or exceeds the following ASTM specifications:

B-398Aluminum Alloy 6201-T81 Wire for Electrical Purposes

B-399Concentric-Lay-Stranded Aluminum Alloy 6201-T81 Conductors.

CONSTRUCTION:

Standard 6201-T81 high strength aluminum conductors, conforming to ASTM specification B-399, are concentric-lay-stranded, similar in construction and appearance to 1350 grade aluminum conductors. DC resistance at 20ºC of the 6201-T81 alloys have a greater resistance to abrasion than conductors of 1350-H19 grade aluminum.

H19 grade aluminum.

1. Resistance is calculated using ASTM standard increments of stranding, and metal conductivity of 52.5% lACS AC resistance at 60 Hz. 2. Current ratings are based on 75° conductor temperature. 25ºC ambient, 2ft watts/sq. foot sun, .05 coefficients of emissivity and absorption.

AAAC - ALL ALUMINUM ALLOY

(6201) CONDUCTOR

Code Word SIZE (KCM) STRAND

APROX EC COND. WITH EQUIVALENT RESISTANCE STRANDING INDIV. WIRE OD COMP. CABLE CROSS SECTIONAL AREA (SQ. IN) WEIGHT PER 1000 FT (LBS) RATED STRENGTH (LBS) DC @ 20 deg C AC @ 75 deg C RATING (AMPS) Akron 30.58 7 6 6/1 0.0661 0.198 0.0240 28.7 1,110 0.6590 0.785 107 Alton 48.69 7 4 6/1 0.0834 0.250 0.0382 45.7 1,760 0.4140 0.4930 143 Ames 77.47 7 2 6/1 0.1052 0.316 0.0608 72.7 4,270 0.2600 0.3100 191 Azusa 123.3 7 1/0 6/1 0.1327 0.398 0.0968 115.7 4,460 0.1630 0.1950 256 Anaheim 155.4 7 2/0 6/1 0.1490 0.447 0.1221 145.9 5,390 0.1300 0.1540 296 Amherst 195.7 7 3/0 6/1 0.1672 0.502 0.1537 183.7 6,790 0.1030 0.1230 342 Alliance 246.9 7 4/0 6/1 0.1878 0.563 0.1939 231.8 8,560 0.0816 0.0973 395 Butte 312.8 19 266.8 26/7 0.1283 0.642 0.2456 293.6 10,600 0.6440 0.0769 460 Canton 394.5 19 336.4 26/7 0.1441 0.721 0.3098 370.3 13,300 0.0511 0.0610 532 Cairo 465.4 19 397.5 26/7 0.1565 0.783 0.3655 436.9 15,600 0.0433 0.0518 590 Darien 559.5 19 477.0 26/7 0.1716 0.858 0.4394 521.2 18,800 0.0360 0.0420 663 Elgin 652.4 19 556.5 26/7 0.1853 0.927 0.5124 612.4 21,900 0.0309 0.0371 729 Flint 740.8 37 636.0 26/7 0.1414 0.991 0.5818 685.5 24,400 0.02720 0.0327 790 Greenly 927.2 37 795.0 26/7 0.1583 1.108 0.7282 870.4 30,500 0.02170 0.0263 908

DIAMETER (IN) RESISTANCE

NOMINAL APPROX AMPACITVITY

CONDUCTOR INSULATION O.D. DIRECTLY

CODE WORD SIZE MILS INCHES ALUMINUM TOTAL BURIED

PRINCETON 6 60 0.298 25 44 108 MERCER 4 60 0.345 39 63 140 CLEMSON 2 60 0.403 62 92 180 KENYON 1 80 0.473 78 121 203 HARVARD 1/0 80 0.512 99 146 231 YALE 2/0 80 0.555 125 177 263 TUFTS 3/0 80 0.603 157 215 299 BELOIT 4/0 80 0.658 198 263 338 HOFSTRA 250 95 0.732 234 314 368 GONZAGA 300 95 0.784 281 367 407 RUTGERS 350 95 0.831 328 420 444 DARTMOUTH 400 95 0.875 376 476 475 EMORY 500 95 0.956 469 577 540 DUKE 600 110 1.060 562 697 595 FURMAN 700 110 1.127 656 804 645 SEWANEE 750 110 1.159 703 853 667 FORDHAM 1000 110 1.304 937 1108 800

SECONDARY TYPE UD CABLE-ALUMINUM CONDUCTOR

APPLICATIONS:

Directly buried or installed in ducts for 600 volt or less secondary distribution.

CONSTRUCTION:

Concentric stranded or compressed 1350-H19 aluminum conductor, cross linked polyethylene insulation. Insulated conductors surface printed, neutral, yellow striped.

SPECIFICATIONS:

ASTM B-230, B-231, B-609, B-901 and ICEA S-105-692. Federal specification JC-30B NEC

OPTIONS:

Cable in Duct • Abrasion Resistant

DUPLEX CONDUCTOR 600 VOLT URD

Code Word Size AWG Strand

Insulation Thickness

(mils) Size AWG Strand

Insulation Thickness (mils) Single Phase Conductor (in.) Outside Diameter (in.) Weight per 1000 ft. (lbs) Direct Burial In Duct Bard 8 7/w 60 8 7/w 60 0.262 0.524 76 70 70 Claflin 6 7/w 60 6 7/w 60 0.299 0.596 91 95 70 Delgado 4 7/w 60 4 7/w 60 0.345 0.69 129 125 90 Everett 2 7/w 60 2 7/w 60 0.403 0.800 189 187 100 Ampacity (Amps) Neutral Phase Conductor

SINGLE CONDUCTOR

600 VOLT URD

NOTE: Ampacity 90°C conductor temperatures, 20°C ambient temperature. RHO 90. 100% load factor. UL Standard 854 available upon request. Ampacity not for NEC applications.

SECONDARY TYPE UD CABLE-ALUMINUM CONDUCTOR

APPLICATION:

Directly buried or installed in ducts for 600 volt or less secondary distribution.

CONSTRUCTION:

Concentric stranded or compressed 1350-H19 aluminum conductor, cross-linked polyethylene insulation.

SPECIFICATIONS:

ASTM B-230, B-609, and ICEA S-105-692

OPTIONS:

Cable in Duct (CIC) • Abrasion Resistant

ESTIMATED WEIGHT LBS/1000FT

SECONDARY TYPE UD CABLE – ALUMINUM CONDUCTOR

APPLICATION:

Directly buried or installed in ducts for 600 volt or less secondary distribution.

CONSTRUCTION:

Concentric stranded or compressed 1350-H19 aluminum conductors, cross-linked polyethylene insulation. Insulated conductors surface printed, neutral, yellow striped. Two phase and one neutral conductor twisted together (LH lay).

SPECIFICATIONS:

ASTM B-230, B-231, B-609, B-901, ICEA S-105-692, Federal Specification J-C-30B, J-C-3.

OPTIONS:

Cable in Duct (CIC) • Abrasion Resistant.

TRIPLEX CONDUCTOR

600 VOLT URD

Code Word Size AWG Stranding Insulation Thickness (mls) Size AWG Stranding Insulation Thickness (mls) Single Phase Conductor (inches) Outside Diameter (inches) Weight per 1000 ft. (lbs) Direct Burial In Duct

Phase Conductor Neutral Allowable Ampacity+

Note: Ampacity: 90ºC conductor temperatures, 20ºC ambient, RHO 90, 100% load factor for three conductor triples with neutral carrying only unbalanced load. All yellow extruded stripe cable is XLP insulation.

UL Standard 854 available upon request. Ampacity not for NEC applications.

Erskine 6 7 60 6 7/W 60 0.299 0.646 143 95 70 Vassar 4 7 60 4 7/W 60 0.345 0.754 203 125 90 Stephens 2 7 60 4 7/W 60 0.403 0.842 264 165 120 Ramapo 2 7 60 2 7/W 60 0.403 0.874 294 165 120 Brenau 1/0 19 80 2 7/W 60 0.522 1.064 408 215 160 Bergen 1/0 19 80 1/0 19/W 80 0.522 1.133 465 215 180 Converse 2/0 19 80 1 19/W 80 0.566 1.174 502 245 180 Hunter 2/0 19 80 2/0 19/W 80 0.566 1.228 560 245 180 Hollins 3/0 19 80 1/0 19/W 80 0.616 1.276 608 280 205 Sweetbriar 4/0 19 80 2/0 19/W 80 0.672 1.389 739 315 240 Monmouth 4/0 19 80 4/0 19/W 80 0.672 1.457 828 315 240 Pratt 250 37 95 3/0 19/W 80 0.748 1,538 893 345 265 Wesleyan 350 37 95 4/0 19/W 80 0.851 1.736 1166 415 320 Rider 500 37 95 350 37/W 95 0.979 2.035 1663 495 395

SECONDARY TYPE UD CABLE-ALUMINUM CONDUCTOR

APPLICATION:

Directly buried or installed in ducts for 600 volts or less secondary distribution.

CONSTRUCTION:

Concentric stranded or compressed 1350-H19 aluminum conductors, cross-linked polyethylene insulation. Insulated conductors surface printed, neutral, yellow striped. Three phase and one neutral conductor cable together (LH lay).

SPECIFICATIONS:

ASTM B-230, B-231, B-609, B-901, ICEA S-105-692, Federal Specification JC-30B and NEC.

QUADRUPLEX CONDUCTOR

600 VOLT URD

Code Word Size AWG Strand

Insulation Thickness

(Mils) Size Strand AWG

Insulation Thickness (Mils) Outside Diameter (in.) Weight per 1000 ft. (lbs) Direct Burial In Duct Tulsa 4 7/w 60 4 7/w 60 0.893 258 119 85 Dyke 2 7/w 60 4 7/w 60 0.938 346 153 115 Wittenberg 2 7/w 60 2 7/w 60 0.973 375 153 115 Notre Dame 1/0 19/w 80 2 7/w 60 1.188 541 198 150 Syracuse 2/0 19/w 80 1 19/w 80 1.316 664 225 170 Davidson 3/0 19/w 80 3/0 19/w 80 1.487 874 250 195 Wake Forest 4/0 19/w 80 2/0 19/w 80 1.560 979 290 225 Earlham 4/0 19/w 80 4/0 19/w 80 1.623 1066 290 225 Rust 250 37/w 95 3/0 19/w 80 1.760 1203 325 210 Slippery Rock 350 37/w 95 4/0 19/w 80 1.945 1544 385 305 Wofford 500 37/w 95 350 37/w 95 2.348 2174 467 420 Windham 750 61/w 110 500 37/w 95 2.850 3147 615 492

Neutral Ampacity (Amps)Neutral

Phase Conductor

Ampacity: 90° conductor temperature, 20°C ambient temperature, RHO 90. 100% load factor for three conductor triplex, with neutral carrying only unbalanced load. UL Standard 854 available upon request.

TRIPLEX 600V SECONDARY UD RHH OR RHW-2 OR USE-2 8000 SERIES

ALUMINUM ALLOY (AA-8000) CONDUCTORS.

CROSS LINKED POLYETHYLENE (XLP) INSULATION.

APPLICATIONS:

Triplex Type RHH or RHW-2 or USE-2 is primarily used for secondary distribution and underground service at 600 volts or less, either direct burial or in ducts, where increased flexibility is needed. May also be used with conduit as specified by the NEC.

SPECIFICATIONS:

Triplex Type RHH or RHW-2 or USE-2 600 volt cable meets or exceeds the following applicable ASTM specifications: B-800 8000 Series Aluminum Alloy Wire for Electrical Purposes • Annealed and intermediate tempers. B-801 Compressed Conductors of 8000 Series. Aluminum Alloy for Subsequent Covering or Insulations. Triplex 600 Volt secondary UD Cable meets or exceeds all applicable requirements of S-105-682 for cross-linked polyethylene insulated conductors, UL Standard 44 for type RHW-2, and UL Standard 854 for Type USE-2.

CONSTRUCTION:

Type RHW-2 or USE-2 conductors are compressed stranded AA-8000 series Aluminum Alloy insulated with cross-linked polyethylene. A triplex construction consists of two-phase conductors and one neutral. The neutral conductor contains yellow extruded stripes and sequential footage marks. Conductors are surface printed for identification.

8000 SERIES

600 VOLT URD

Code Word Size AWG Stranding

Insulation Thickness

(mls) Size AWG Stranding

Insulation Thickness (mls) Single Phase Conductor Complete Cable Weight per 1000 ft. (lbs) Direct Burial In Duct Vassar 4 7 60 4 7 60 345 745 191 125 90 Stephens 2 7 60 4 7 60 403 870 249 165 120 Ramapo 2 7 60 2 7 60 403 870 278 165 120 Brenau 1/0 19 80 2 7 60 512 1106 387 215 160 Converse 2/0 19 80 1 19 80 555 1199 478 245 180 Sweetbriar 4/0 19 80 2/0 19 80 658 1421 709 315 240 Monmouth 4/0 19 80 4/0 19 80 658 1421 796 315 240 Pratt 250 37 95 3/0 19 80 732 1581 853 345 265 Wesleyan 350 37 95 4/0 19 80 831 1795 1118 415 320

Phase Conductor Neutral Allowable Ampacity+

TRIPLEXED WITH YELLOW EXTRUDED STRIPE NEUTRAL

TRIPLEXED WITH YELLOW EXTRUDED STRIPE NEUTRAL

Ampacity: 90° conductor temperature, 20°C ambient temperature, RHO 90. 100% load factor for three conductor triplex, with neutral carrying only unbalanced load. Ampacity not for NEC applications.

APPLICATIONS:

Used primarily for overhead secondary distribution lines. Not an electrically insulated conductor and is treated as bare conductor when installed.

CONSTRUCTION:

Conductors are aluminum alloy 1350-H19, 6201-T81, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HD) or cross-linked polyethylene (XLP).

SPECIFICATIONS:

Covered Line Wire meets or exceeds the following ASTM specifications: B-230 Aluminum Wire, 1350-H19 for electrical purposes • B-231 Aluminum conductors, Concentric-lay-Stranded • B-232 Aluminum conductors, Concentric-lay-Stranded, Coated Steel Reinforced (ACSR) • B-399 Concentric-lay-Stranded, 6201-T81 Aluminum

Covered Line Wire

Aluminum Conductor

Code Word Size AWG Strand

Insulation Thickness (MILS) Outside Diameter (in.) Rated Strength (lbs/mft) XLP POLY Ampacity (Amps) XLP Walnut 6 6/1 30 0.258 1131 49.0 47.0 105 Butternut 4 6/1 30 0.303 1760 71.8 70.0 135 Hickory 4 7/1 30 0.309 2240 81.6 79.8 135 Pignut 2 6/1 45 0.397 2710 118.1 114.8 180 Beech 2 7/1 45 0.405 3460 134.1 130.7 180 Chestnut 1 6/1 45 0.434 3370 145.5 141.8 210 Almond 1/0 6/1 60 0.506 4160 190.4 184.9 235 Pecan 2/0 6/1 60 0.554 5040 234.2 227.9 270 Filbert 3/0 6/1 60 0.607 6290 288.5 281.4 305 Buckeye 4/0 6/1 60 0.666 7930 365.5 348.5 345 Hackberry 266.8 18/1 60 0.711 6540 354.8 346.8 435 Weight

COVERED LINE WIRE-ALUMINUM CONDUCTOR ACSR

*NOTE: The code words as given apply to conventional polyethylene line wire. The data is approximate and subject to normal manufacturing tolerances.

For 6201, aluminum conductors diameter equivalent to ACSR construction or 1350 aluminum equivalent. Ampacity ratings based on 75°C conductor temperature 25" Cambient temperature elevation- sea level.

APPLICATION:

To supply 120 volt aerial service for temporary service at construction sites, outdoor or street lighting. For service at 600 volts or lower at a conductor temperature of 75ºC maximum.

CONSTRUCTION:

Concentric strand or compressed 1350-H19 conductor, polyethylene or cross-linked polyethylene insulation, concentric strand AAC, ACSR, or 6201 alloy neutral messenger.

SPECIFICATIONS:

Duplex service drop cable meets or exceeds the following ASTM specifications: B-230 Aluminum Wire, 1350-H19 or electrical purposes • B-231 Aluminum conductors, Concentric-lay-Stranded. • B-232 Aluminum conductors, Concentric-lay-Stranded, Coated Steel Reinforced (ACSR) • B-399 Concentric-lay-Stranded, 6201-T81 Aluminum • Service Drop cable meets or exceeds all applicable requirements of ICEA S-76-474

DUPLEX OVERHEAD

(Service Drop)

ALUMINUM CONDUCTOR

*NOTE: Designated sizes are ACSR 6/1 diameter equivalent resistivity per ASTM-B-399 for 6201. Conductor temperature of 90°C for XLP, 75°C for Poly; ambient temperature of 40°C emissivity 0.9; 2ft/sec. Wind in sun.

CODE WORD SIZE AWG STRAND

INSULATION THINKNESS (MLS)

SIZE AWG STRAND_{(LBS) STRENGTH}BREAKING XLP POLY XLP POLY

Pekingese 6 SOLID 45 6 7/W 563 63.5 61.7 85 70 Collie 6 7/W 45 6 7/W 563 66.8 63.1 85 70 Dachshund 4 SOLID 45 4 7/W 881 95.5 93.4 110 90 Spaniel 4 7/W 45 4 7/W 881 100.5 95.4 110 90 Doberman 2 7/W 45 2 7/W 1,350 152.7 145.7 150 120 Malamute 1/0 19/W 60 1/0 7/W 1,990 242.6 234.2 200 60 Setter 6 SOLID 45 6 6/1 1,190 75.0 73.2 85 70 Shepherd 6 7/W 45 6 6/1 1,190 78.3 74.6 85 70 Eskimo 4 SOLID 45 4 6/1 1,860 113.7 111.6 110 90 Terrier 4 7/W 45 4 6/1 1,860 118.7 113.6 110 90 Chow 2 7/W 45 2 6/1 2,850 181.7 174.7 150 115 Bull 1/0 19/W 60 1/0 6/1 4,380 288.7 280.3 200 155 Chihuahua 6 SOLID 45 6 7/W 1,110 67.6 65.8 85 70 Vizsla 6 7/W 45 6 7/W 1,110 70.9 67.2 85 70 Harrier 4 SOLID 45 4 7/W 1,760 102.0 99.9 110 90 Whippet 4 7/W 45 4 7/W 1,760 107.0 101.9 110 90 Schnauzer 2 7/W 45 2 7/W 2,800 163.3 156.2 150 115 Heeler 1/0 19/W 60 1/0 7/W 4,460 259.2 250.8 200 155

PHASE CONDUCTORS BARE NEUTRAL MESSENGER WEIGHT PER

1000FT (LBS) RATING (AMPS)

AAC

ACSR NEUTRAL MESSENGER

APPLICATION:

To supply power from the utility lines to the consumer weather head. For service at 600 volts or less (phase to phase) at a conductor temperature of 75°C maximum for polyethylene insulation or 90°C maximum for cross-linked insulation.

CONSTRUCTION:

Concentric strand or compressed 1350-H19 conductor, polyethylene or cross-linked polyethylene insulation, concentric strand AAC, ACSR or 6201 alloy neutral messenger.

SPECIFICATIONS:

Triplex service drop cable meets or exceeds the following ASTM specifications: B-230 Aluminum Wire, 1350-H19 for electrical purposes • B-231 Aluminum conductors, Concentric-Lay-Stranded • B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR) • B-399 Concentric-Lay-Stranded, 6201-T81 Aluminum Service Drop cable meets or exceeds all applicable requirements of ICEA S-76-474

TRIPLEX OVERHEAD

(Service Drop)

ALUMINUM CONDUCTOR

CODE WORD SIZE AWG STRAND INSULATION THICKNESS (MLS) SIZE AWG STRAND BREAKING STRENGTH (LBS) XLP POLY XLP POLY

6201 ALLOY NEUTRAL MESSENGER

Minex 6 Solid 45 6 7 1,110 106.6 102.9 85 70 Hippa 6 7 45 6 7 1,110 107.0 105.7 85 70 Prawn 4 Solid 45 4 7 1,760 158.4 154.1 110 90 Barnacles 4 7 45 4 7 1,760 160.0 157.0 110 90 Shrimp 2 7 45 2 7 2,800 243.0 238.0 150 115 Gammarus 1/0 7 60 1/0 7 4,460 390.0 384.0 200 155 Leda 1/0 19 60 1/0 7 4,460 384.0 378.0 200 155 Dungeness 2/0 7 60 2/0 7 5,390 481.0 474.0 230 180 Cyclops 2/0 19 60 2/0 7 5,390 473.0 467.0 230 180 Flustra 3/0 19 60 3/0 7 6,790 596.0 589.1 260 205 Lepas 4/0 19 60 4/0 7 8,560 725.0 716.0 300 235 6201 ALLOY REDUCED NEUTRAL MESSENGER

Artemia 4 Solid 45 6 7 1,110 134.0 132.0 110 90 Crab 4 7 45 6 7 1,110 144.0 141.2 110 90 Solaster 2 7 45 4 7 1,760 216.0 212.6 150 115 Sandcrab 1/0 7 60 2 7 2,800 348.0 341.0 200 155 Echinus 1/0 19 60 2 7 2,800 342.0 336.0 200 155 Crayfish 2/0 7 60 1 7 3,530 452.6 422.5 230 180 Sipho 2/0 19 60 1 7 3,530 441.0 422.5 230 180 Fulgar 3/0 19 60 1/0 7 4,460 525.0 518.0 260 205 Arca 4/0 19 60 2/0 7 5,390 640.0 632.0 300 235 AMPACITY (AMPS) WEIGHT PER 1000 FT (LBS)

BARE NEUTRAL MESSENGER PHASE CONDUCTOR

6201 ALLOY REDUCED NEUTRAL MESSENGER 6201 ALLOY NEUTRAL MESSENGER

TRIPLEX OVERHEAD

(Service Drop)

ALUMINUM CONDUCTOR

(continued)

CODE WORD SIZE AWG STRAND INSULATION THICKNESS (MLS) SIZE AWG STRAND BREAKING STRENGTH (LBS) XLP POLY XLP POLY Haiotis 6 Solid 45 6 7 563 102.5 98.8 85 70 Patella 6 7/w 45 6 7 563 104.0 101.6 85 70 Fusus 4 Solid 45 4 7 881 151.9 147.6 110 90 Oyster 4 7/w 45 4 7 881 154.0 151.7 110 90 Clam 2 7/w 45 2 7 1,350 232.0 228.0 150 115 Murex 1/0 7/w 60 1/0 7 1,990 374.0 367.0 200 155 Purpura 1/0 19/w 60 1/0 7 1,990 368.0 362.0 200 155 Nassa 2/0 7/w 60 2/0 7 2,510 461.0 453.0 230 180 Melita 3/0 19/w 60 3/0 19 3,310 585.2 562.9 260 205 Portunus 4/0 19/w 60 4/0 19 4,020 693.0 684.0 300 235 Nannynose 336 19/w 80 336 19 6,146 1111.0 1096.0 380 290 Paludina 6 Solid 45 6 6/1 1,190 114.0 113.0 85 70 Voluta 6 7/w 45 6 6/1 1,190 115.0 112.0 85 70 Whelk 4 Solid 45 4 6/1 1,860 163.0 161.0 110 90 Periwinkle 4 7/w 45 4 6/1 1,860 172.0 169.0 110 90 Conch 2 7/w 45 2 6/1 2,850 262.0 257.0 150 115 Neritina 1/0 7/w 60 1/0 6/1 4,380 420.0 414.0 200 155 Cenia 1/0 19/w 60 1/0 611 4,380 414.0 408.0 200 155 Runcina 2/0 7/w 60 2/0 6/1 5,310 519.0 512.0 230 180 Triton 2/0 19/w 60 2/0 6/1 5,310 511.0 505.0 230 180 Cherrystone 3/0 7/w 60 3/0 6/1 6,620 656.0 643.0 260 205 Mursia 3/0 19/w 60 3/0 6/1 6,620 633.0 626.0 260 205 Razor 4/0 7/w 60 4/0 6/1 8,350 814.0 799.0 300 235 Zuzara 4/0 19/w 60 4/0 6/1 8,350 785.0 777.0 300 235 Limpet 336 19/w 80 336 18/1 8,680 1161.0 1147.0 380 290 ACSR REDUCED SIZE MESSENGER

Scallop 4 Solid 45 6 6/1 1,190 142.0 139.0 110 90 Strombus 4 7/w 45 6 6/1 1,190 151.0 148.0 110 90 Cockle 2 7/w 45 4 6/1 1,860 228.0 224.0 150 115 Janthina 1/0 7/w 60 2 6/1 2,850 367.0 360.0 200 155 Ranella 1/0 19/w 60 2 6/1 2,850 361.0 356.0 200 155 Cavolinia 2/0 7/w 60 1 6/1 3,550 452.0 444.0 230 180 Clio 2/0 19/w 60 1 611 3,550 444.0 437.0 230 180 Sanddollar 3/0 7/w 60 1/0 6/1 4,380 570.0 557.0 260 205 Aega 3/0 19/w 60 1/0 6/1 4,380 565.0 552.0 260 205 Cuttlefish 4/0 7/w 60 2/0 6/1 5,310 706.0 691.0 300 235 Cerapus 4/0 19/w 60 2/0 6/1 5,310 678.0 670.0 300 235 AMPACITY (AMPS) WEIGHT PER 1000 FT (LBS)

BARE NEUTRAL MESSENGER PHASE CONDUCTOR

FULL SIZE ACSR MESSENGER AAC NEUTRAL MESSENGER

APPLICATIONS:

Used to supply 3 phase power. usually from a pole-mounted transformer, to the user's service head where connection to the service entrance cable is made. To be used at voltages of 600 volts or less phase to phase and at conductor temperatures not to exceed 75°C for polyethylene insulated conductors or 90ºC for cross-linked-polyethylene (XLP) insulated conductors

CONSTRUCTION:

Conductors are concentrically stranded, compressed 1350-H19 aluminum Insulated with either polyethylene or XLP cross-linked-polyethylene. Neutral messengers are concentrically stranded 6201, AAC, or ACSR.

SPECIFICATIONS:

Quadruplex service drop cable meets or exceeds the following ASTM specifications: B-230 Aluminum Wire, 1350-H19 for electrical purposes. B-231 Aluminum conductors, Concentric-Lay-Stranded. B-232 Aluminum Conductors, Concentric-Lay-Stranded, Coated Steel Reinforced (ACSR) B-399 Concentric-Lay-Stranded, 6201-T81 Aluminum. Service Drop cable meets or exceeds all applicable requirements of ICEA S-76-474

NOTE. Designated sizes are. ACSR 6/1 diameter equivalent and AAC with equivalent resistivity per ASTM B-399 for 6201. Conductor temperature of 90°C for XLP, 75°C for poly; ambient temp. of 40°C; emissivity 0.9; 2ft/sec/wind in sun.

QUADRUPLEX OVERHEAD

(Service Drop)

ALUMINUM CONDUCTOR

CODE WORD SIZE_AWG STRAND

INSULATION THICKNESS (MLS) SIZE AWG *STRAND BREAKING STRENGTH (LBS) XLP POLY XLP POLY Clydesdale 4 Solid 45 4 7 881 208 201 100 80 Pinto 4 7/W 45 4 7 881 223 207 100 80 Mustang 2 7/W 45 2 7 1,350 333 312 135 105 Criollo 1/0 19/W 60 1/0 7 1,990 529 504 180 135 Percheron 2/0 19/W 60 2/0 7 2,510 649 620 205 155 Hanoverian 3/0 19/W 60 3/0 19 3,310 799 765 235 180 Oldenburg 4/0 19/W 60 4/0 19 4,020 986 946 270 205 Lippizaner 336.4 19/W 80 336.4 19 6,146 1546 1,519 330 240 Morchuca 6 Solid 45 6 6/1 1,190 152 147 75 60 Chola 6 7/W 45 6 6/1 1,190 162 151 75 60 Morgan 4 Solid 45 4 6/1 1,860 226 220 100 80 Hackney 4 7/W 45 4 6/1 1,860 241 226 100 80 Palomino 2 7/W 45 2 6/1 2,850 362 342 135 105 Costena 1/0 19/W 60 1/0 6/1 4,380 575 550 180 135 Grullo 2/0 19/W 60 2/0 6/1 5,310 707 678 205 155 Suffolk 3/0 19/W 60 3/0 6/1 6,620 872 838 235 180 Appaloosa 4/0 19/W 60 4/0 6/1 8,350 1079 1,039 270 205 Bronco 336.4 19/W 80 336.4 18/1 8,580 1613 1,568 330 240 Gelding 336.4 19/W 80 4/0 6/1 8,350 1548 1,494 330 240 Bay 6 Solid 45 6 7 1,110 145 140 75 60 French Coach 6 7/W 45 6 7 1,110 155 144 75 60 German Coach 4 Solid 45 4 7 1,760 214 208 100 80 Arabian 4 7/W 45 4 7 1,760 229 214 100 80 Belgian 2 7/W 45 2 7 2,800 344 323 135 105 Shetland 1/0 19/W 60 1/0 7 4,460 546 521 180 135 Thoroughbred 2/0 19/W 60 2/0 7 5,390 670 641 205 155 Trotter 3/0 19/W 60 3/0 7 6,790 825 791 235 180 Walking 4/0 19/W 60 4/0 7 8,560 1019 979 270 205

PHASE CONDUCTORS BARE NEUTRAL MESSENGER WEIGHT PER 1000 FT (LBS)

AMPACITY (AMPS)

AAC - NEUTRAL MESSENGER

ACSR - NEUTRAL MESSENGER

METAL CLAD CABLE

ALUMINUM CONDUCTOR

CONDUCTOR SIZE

(AWG/kcmil) W/O JKT. JKT. W/O JKT. JKT. 75 DEGREE 90 DEGREE

6-6-6-6 0.83 0.93 237 320 50 50 4-4-4-6 0.93 1.03 308 399 65 70 2-2-2-6 1.03 1.13 402 503 90 90 1-1-1-4 1.16 1.26 504 617 100 100 1/0-1/0-1/0-4 1.23 1.33 584 703 120 125 2/0-2/0-2/0-4 1.28 1.38 674 798 135 150 3/0-3/0-3/0-4 1.36 1.46 796 928 155 175 4/0-4/0-4/0-2 1.51 1.63 1005 1181 180 200 250-250-250-2 1.63 1.75 1166 1355 205 225 300-300-300-2 1.72 1.84 1337 1536 230 250 350-350-350-2 1.80 1.92 1505 1713 250 250 400-400-400-1 1.91 2.03 1692 1913 270 300 500-500-500-1 2.04 2.16 2023 2258 310 350 600-600-600-1 2.24 2.36 2416 2674 340 350 700-700-700-1/0 2.39 2.53 2765 3115 375 400 750-750-750-1/0 2.44 2.59 2926 3278 385 400 6-6-6-6-6 0.92 1.02 286 377 50 50 4-4-4-4-6 1.04 1.14 373 474 65 70 2-2-2-2-6 1.17 1.27 503 617 90 90 1-1-1-1-4 1.31 1.41 630 757 100 100 1/0-1/0-1/0-1/0-4 1.40 1.5 736 871 120 125 2/0-2/0-2/0-2/0-4 1.47 1.64 887 1071 135 150 3/0-3/0-3/0-3/0-4 1.58 1.70 1051 1235 155 175 4/0-4/0-4/0-4/0-2 1.73 1.85 1280 1480 180 200 250-250-250-250-1 1.89 2.01 1510 1730 205 225 300-300-300-300-1 2.01 2.13 1738 1970 230 250 350-350-350-350-1/0 2.13 2.25 1985 2231 250 250 400-400-400-400-1/0 2.23 2.35 2207 2468 270 300 500-500-500-500-2/0 2.43 2.58 2677 3028 310 350 500-500-500-500-250 2.51 2.66 2798 3166 310 350 600-600-600-600-2/0 2.68 2.83 3199 3591 340 350 600-600-600-600-400 2.84 2.99 3473 3886 340 350 700-700-700-700-2/0 2.83 2.98 3630 4043 375 400 750-750-750-750-3/0 2.93 3.08 3880 4300 385 400 750-750-750-750-750 3.20 3.37 4469 4998 385 400

DIAMETER (Inches) WEIGHT (LBS/MFT) AMPACITY

FOUR CONDUCTOR WITH GROUND THREE CONDUCTOR WITH GROUND

Note: Ampacities are based on Table 310.16 of the NEC, 2005 Edition.

‡Allowable ampacities shown are for general use as specified by the National Electrical Code, 2005 Edition, Section 310.15. If the equipment is marked for use at higher temperatures, the conductor ampacity shall be limited to the following per NEC 110.14(C). 75°C – When terminated to equipment for circuits rated over 100 amperes or marked for conductors larger than size 1 AWG. 90°C – For ampacity derating purposes.

Per NEC 310.15(B)(2)(a), the ampacity of 4/C cables shall be reduced by a factor of 0.80 when the neutral is considered a current-carrying conductor. †Available with oversized grounding conductor when used for parallel feeds on special orders.

COLOR CODING Standard Products

NUMBER OF CONDUCTORS COLOR SEQUENCE120/20BY 3 1-Black, 2-Red, White or White Striped

Type MC-Aluminum Conductors 8000 Series Aluminum Alloy AA-8000 Conductors • 600 Volt • Cross-Linked-Polyethylene (XLP) • Insulated singles rated XHHW -2 • Bare Aluminum Alloy Grounding Conductor • Lightweight Aluminum Interlocked Armor • Sizes 6 AWG through 750 kcmil

APPLICATIONS:

Suitable for use as follows: Branch, feeder and service power distribution under high ambient temperature in commercial, industrial, institutional, casinos, and multi-residential buildings • Power, lighting, control, and signal circuits • Concealed or exposed installations • Environmental air-handling spaces per NEC 300.22 • Places of Assembly per NEC 518.4 and theaters per NEC 520.5 • As aerial cable on messenger • Installation in cable tray and approved raceways • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) and 645.5(D)(2) • Class 1 Div. 2., Class 11 Div. 2, and Class 111 Div. 1 Hazardous Locations

STANDARDS & REFERENCES:

Priority's MC Cable meets or exceeds the requirements of UL Standard 44, UL Standard 1569 for Type MC, ICEA S-95-658 (NEMA WC70) for 0-2000 V Nonshielded Cables, Federal Specifications A-A59544 (formerly J-C-30B), IEEE 1202 (70,000 BTU/hr) Vertical Cable Tray Flame Test, and the National Electrical Code.

CONSTRUCTION:

Priority's Aluminum Conductor MC Cable is constructed with Type XHHW-2 conductors and a bare equipment grounding conductor. Conductors are Aluminum AA-8000 series aluminum alloy compact stranded. A binder tape is wrapped over the conductors with interlocked aluminum tape applied over the assembly. Aluminum interlocking armor is applied over the assembly.

1-800-945-5542

www.prioritywire.com

Little Rock

1800 East Roosevelt Road Little Rock, AR 72206 1-800-945-5542 501-372-1103 Fax Baton Rouge 6801 Pecue Lane Baton Rouge, LA 70817 1-888-754-5707 225-754-5750 Fax Houston 9600 Wallisville Road Houston, TX 77013 1-888-388-6280 713-673-8485 Fax Las Vegas 2970 N Lamb Blvd, Suite 113 Las Vegas, NV 89115 702-696-0001 702-856-0001 Fax

The Combination Program Lineup

3 Product Lines

$3,000 Freight Prepaid

• Aluminum XHHW Building Wire

• Airport Lighting Cable

• Aluminum 600 Volt Underground

• Tinned Copper

• Aluminum SER, SEU

• Medium Voltage (5KV-15KV)

• Aluminum 600 Volt Overhead

• EPR/PVC-MV105

• Aluminum ACSR-AAC-AAAC

• Security / Fire Alarm

• Aluminum XLP-USE 8000 Series

• Range / Dryer Cords

• Aluminum XLP-USE 1350 (Utility)

• Flexible Conduit

• Aluminum Conductor MC Cable

•

(EFLT,UALT,NMLT,RWA, RWS)

• Portable Cord SOOW, SJOW

• MC Cable

• Portable Cables

• Telephone Wire (Inside & Outside)

• Type G-GC,Welding, W, DLO

• 20/10 Control Cable

• Coax Cable

• SIS - Switchboard

• Category 5E Wire

• High Temperature

• Thermostat Wire

•

(MG, TGGT,SRML)

• Copper Ground Rod, Galvanized

• MTW,TFN,TFFN

•

Ground Rods & Accessories

• SPT Lampcord

• Tray Cables - VNTC

• Landscape Wire

• Instrumentation &

• Aluminum Tie Wire

•

Thermocouple

• Bare Copper
