Dispersed Reference Interferometry for
On-Machine Metrology
James Francis Williamson
A thesis submitted to the University of Huddersfield in partial fulfilment of the
requirements for the degree of Doctor of Philosophy
The University of Huddersfield
2
Copyright statement
i. The author of this thesis (including any appendices and/or schedules to this thesis) owns any copyright in it (the “Copyright”) and he has given The University of Huddersfield the right to use such Copyright for any administrative, promotional, educational and/or teaching purposes.
ii. Copies of this thesis, either in full or in extracts, may be made only in accordance with the regulations of the University Library. Details of these regulations may be obtained from the Librarian. This page must form part of any such copies made.
iii. The ownership of any patents, designs, trademarks and any and all other intellectual property rights except for the Copyright (the “Intellectual Property Rights”) and any reproductions of copyright works, for example graphs and tables (“Reproductions”), which may be described in this thesis, may not be owned by the author and may be owned by third parties. Such Intellectual Property Rights and Reproductions cannot and must not be made available for use without the prior written permission of the owner(s) of the relevant Intellectual Property Rights and/or Reproductions
3
Abstract
The reliance of emerging engineering and scientific applications on nanometre scale surfaces has led to the requirement for embedded metrology instrumentation for on-machine measurement in precision and ultra-precision manufacturing processes. In-situ measurement provides reduction in waste, cost and production cycle time of manufactured components however the presence of environmental noise and difficulties of integration make embedded metrology challenging.
In this thesis a review of on-machine methods of optical metrology is provided and commercially available instruments are summarised. The requirement for highly miniaturised methods of distance and surface topography measurement for operation within volume limited manufacturing environments is presented and the necessity for smaller, faster probes with increased range, resolution and robustness outlined. The potential for dispersed reference interferometry (DRI) to exceed the capability of existing single-point remote fibre probing instruments is then introduced.
DRI as a technique for single-point distance and surface topography measurement is first evaluated in a bulk optics configuration using a short coherence light source and chromatic dispersion within the reference arm. The resulting spectral interferograms have symmetry positions which are directly related to absolute surface position to yield measurement with a 279 nm axial resolution over a 285 μm axial range.
Improvement of this resolution results from introduction of template matching, a signal processing technique which correlates a measured interferogram with a set of pre-calculated template interferograms resulting in a relative method of measurement with an axial resolution of 0.6 nm across the 285 μm axial range. Combination of this high resolution, relative measurement method with low resolution but absolute position data is then explored to improve the robustness of DRI to discontinuous and structured surfaces. Determination of high resolution wraparound order using low resolution absolute data is demonstrated over a 30 μm range, with extension to the full range of DRI expected as future improvements increase the measurement rate.
Next a DRI topology is introduced which makes use of miniature common-path probes linked by fibre to a remote interrogation interferometer allowing reduction in size of the on-machine metrology apparatus. Modifications to the DRI are described to enable this common-path remote fibre probing, along with changes to the light source, spectrometer and dispersive element which allow extension of the range of DRI to 800 μm while maintaining nanometre axial resolution.
Finally, a further work section offers insights into methods to improve miniaturisation of DRI probes as well as providing discussion of methods of hardware and signal processing optimisation to augment the instrument measurement rate.
4
Acknowledgements
The last four years of my PhD have been some of the most rewarding of my life. The people I’ve met, the knowledge I’ve gained, the encouragement I’ve received and the faith in me I’ve experienced are something I shall always remember.
My sincere thanks and respect go to my supervisors Jane Jiang and Haydn Martin. Jane for her inspiration, encouragement and vast knowledge of the subject area. Haydn for his invaluable experience, patience, skill with words and friendship. The trust and encouragement they have given me have been above and beyond. My parents, John and Jennie undoubtedly deserve my thanks. Their support and encouragement through my undergraduate studies, and their faith in me to return to academia as well as their ever positive advice have been essential to everything I feel I have achieved.
Thanks also to my partner Michelle. Her patience, love and kindness throughout my research and her confidence in me as both my best friend and as a colleague have proved invaluable to me.
Thank you to all of my colleagues at the Centre for Precision Technologies. The opportunity to work with such a diverse but skilled and knowledgeable group of people has been a joy.
The author gratefully acknowledges the UK’s Engineering and Physical Sciences Research Council funding of the Centre for Innovative Manufacturing in Advanced Metrology (EP/I033424/1) and the European Research Council Surfund Project (ERC-228117).
