For autonomous driving, Long Range

Radar (LRR) is a key technology. For the

last few years, devices have been built

using SiGe BiCMOS technology, which

allows high power and high-resolution

radar. But as the number of radars grows

as autonomous driving emerges, low

power

consumption

and

low-cost

chipsets will be needed. Radio frequency

(RF) CMOS technology is therefore newly

being used in radar chipsets in order to

satisfy these requirements. Beside the

main players like Texas Instruments (TI)

or NXP, small players like Calterah can

also compete. Ainstein chose Calterah for

its Kanza-77 (K-77) LRR designed for

Advanced

Driver-Assistance

System

(ADAS) applications like forward collision

warning

or

assist

brake

functions,

pedestrian and cyclist collision warnings

and adaptive cruise control.

The K-77 is built on RF CMOS Technology

from Calterah featuring two transmitters

and four receivers designed for low

power consumption and unit cost. The

chipset allows cascading in order to

increase the number of receiving and

transmitting paths. Using embedded

wafer level ball grid array (eWLB)

packaging

reduces

parasitic

signals,

making this new chipset compact and

powerful. Both monolithic microwave

integrated circuits (MMICs) are soldered

on an asymmetric printed circuit board

(PCB) with a hybrid PTFE/FR4 substrate.

The radar is based on 77 GHz technology

and provides two measurement modes,

mid- and long-range, within a single

package. Moreover, Ainstein developed

advanced signal processing algorithms

supported by Xilinx’s dual-core ARM®

Cortex™-A9 based processing system. It

enables detection and tracking of static

and dynamic objects up to 64 targets in

the vehicle’s path, while allowing to the

sensor to be highly customizable for

customer applications.

Based on a complete teardown analysis of

the Ainstein radar, we are releasing two

reports. One report provides the

bill-of-material (BOM) and the manufacturing

cost of the radar sensor. The other report

reviews the CAL77A2T4R transceiver,

including a complete die analysis, cost

analysis, and price estimate for the chips.

It also includes a physical and technical

comparison with TI’s AWR1243, which

targets long-range radar detection and

radar imaging.

COMPLETE TEARDOWN WITH

Detailed photos

Precise measurements

Materials analysis

Block diagram

RF chipset

PCB cross-section and material analysis

Die picture and cost estimation of the

Texas Instruments AFE Receiver

Complete and priced bill-of-materials

Manufacturing process flow

Supply chain evaluation

Manufacturing cost analysis

Estimated sales price

Comparison with Texas Instruments

AWR1243

A next-generation mid- and long-range, wideband and high-resolution radar

sensor for ADAS based on RF CMOS technology using eWLB packaging.

REVERSE COSTING®

– STRUCTURE, PROCESS & COST REPORT

Title: Ainstein K-77

Radar & Calterah

CAL77A2T4R

Pages: 70 & 89

Date: January 2019

Format:

2 PDF & Excel file

Price:

EUR 3,990

Ainstein K-77 Long Range Radar featuring Calterah

CAL77A2T4R FOWLP Transceiver

(2)

TABLE OF CONTENTS

SYSTEM REPORT

Overview/Introduction

Company Profile

Executive Summary

Block Diagram

Company Profile

Physical Analysis

Views and Dimensions of the Radar

Radar Opening

Electronic Boards

External View

High Definition Photo

Components Markings and Identification

Cost Analysis

Substrate Cross Sections and EDX Analysis

BOM Cost – Electronic Boards

BOM Cost – Housing

Material Cost Breakdown

Accessing the Added Value (AV) cost

Manufacturing Cost Breakdown

Estimated Price Analysis

Estimation of the Selling Price

AUTHORS

CHIPSET REPORT

Overview/Introduction

Calterah - Company Profile

Radar Chipset - Market Analysis

Physical Analysis

Physical Analysis - Methodology

Package Assembly: Overview and Cross-Section

Die: Overview, Process and Cross-Section

Physical and Cost Comparison

Calterah vs. Texas Instruments

Manufacturing Process Flow

Die/eWLB Packaging Process and Fabrication Unit

Cost Analysis

Cost Analysis Overview

Main Steps Used in the Economic Analysis

Yield Hypotheses

Die Cost : Front-End and Wafer Cost

eWLB Packaging Assembly Cost

Component Cost

Estimated Price Analysis
