Sanko Printing Co. Ltd
Sanko Printing Co. Ltd, in Tokyo, selects Allied Telesis Management
Framework
TM(AMF) to optimize the management and efficiency of their
new network.
The customer
Sanko Printing Co., Ltd. was founded
in 1928. Recently they redesigned
their company-wide network using
Allied Telesis Management Framework
(AMF), together with advanced Allied
Telesis equipment. Sanko now have a
highly effective network solution which
functions with optimal efficiency, thanks
to centralized management.
2
Customer profile
■ Who: Sanko Printing Co., Ltd.
■ Where: The company headquarters is in Tokyo,
and the factory is in the Chiba Prefecture.
■ Established: April 1928
■ Number of employees: 254 people, as of
June 2014
■ About: Sanko are a printing company,
specializing in large scale commercial grade printing. They aim to provide printing of the highest quality, and to keep pace with changing technologies. Sanko provide a wide range of services, including but not limited to: design, planning, printing of graphics and documents, as well as plate making, binding, and digital content production.
Sanko print magazines, books, comics, catalogs, brochures, advertising inserts, posters, calendars, and much more.
The customer’s requirements
Sanko needed a reliable network, capable of supporting their many printing systems. They had a number of requirements for their network redesign.
The network had to be:
■ Simple – both in design and in ease of use
■ Centrally managed – for maximum efficiency
■ High-speed – they wanted to reduce their data transmission
time to a third of its previous rate.
■ Non-stop – to facilitate transmission of time-critical data
■ Future-proof – able to integrate new network
infrastructure and facilitate new systems
Digitization creates a need for new strategies In 2014, Sanko launched the Network Strategy Development Office. Mr. Koichi Nishida, section chief of the Development Office, says: “We have been actively involved in print digitization, as a focus for the modernization of our business. It used to be standard to transport print proofs by bicycle courier, but in recent years it has become much more common to send proofs electronically, over an FTP server. Also, from our headquarters in Tokyo we transmit print data to our factory in Chiba. We do this over the network, and the data is uploaded to the factory’s server over a VPN connection.”
Sanko launched a project to revamp the network in May 2013. This timing was chosen to coincide with the scheduled network equipment renewal the following year.: “The opportunity for the project was provided by the scheduled equipment renewals. But at that time, the network had a variety of challenges in addition to just equipment renewal.” said Mr. Koichi Nishida.
Simplification
Firstly, simplification of the network was a key requirement in the redesign. Due to the preceding few years of rapid digitization, the factory had insufficient internal IP addresses available, and extending their corporate network had become difficult. Effective management
In addition, the increase in network complexity had added to their administration workload. Managing the network effectively and efficiently, with their small network administration team, was another very important requirement. With company headquarters in Tokyo and the factory in the Chiba Prefecture, any configuration changes required staff to travel, further increasing management overhead.
“Due to repeated expansions, the network had become very complex, and our management workload had increased. We needed to optimize our network management, to achieve more with less. The network needed to be simplified.” says Mr. Nishida.
High speed, high performance
Sanko were extremely busy, and required an increase in the speed and overall performance of their network.
A non-stop network
Sanko prints weekly magazines, which added the requirement that data transmissions absolutely must not be disrupted. Sanko needed a “non-stop network”. So redundancy, and robustness were very important requirements.
Wireless LAN
Sanko wanted to be able to support new mobile devices, which added a requirement to install wireless LAN equipment.
“The exchange of data in-house also
increased, further driving - year after year
- our need for a high capacity, high quality
and high performance data network”
Mr. Kakutani, Deputy Director of the Data Division of the Accounting Department
Prior to the upgrade, Sanko had not used Allied Telesis products in their network. Since they needed a complete redesign of their network, they began an investigation process during which competing vendors were contacted. For over six months, Mr. Nishida met with multiple companies to hear their proposals, and examined the options available. He also actively participated in visits to see demonstrations of the equipment that was on offer.
Finally, the decision was made to adopt a solution propsed by network integrator OSINet, utilizing Allied Telesis equipment. Preparations for the introduction started in January 2014, and the network design was altered and improved over time. “We met several times and had regular discussions with OSINet’s partner company who were responsible for the network installation” Mr. Takeshi MomijiSawa, President of OSINet explains. “The theme that was repeatedly requested in the design was to simplify the network. We had to work hard to meet a variety of requirements, which was challenging”.
Section chief of the Development Office
Mr. Koichi Nishida
“We chose Allied Telesis because
their proposed network met all
our requirements, and because
using AMF simplifies and automates
network management, reducing our
operational costs.”
| Allied Telesis Success Story alliedtelesis.com
4
The solution
Sanko: the new network
WAN 10 Gigabit link 1 Gigabit link Link aggregation Master Member Server Farm Member x510 Network Attached Sorage x210 x210 Router x510 Router Router Router VPN x510 x510 SBx8100 Switch Blade x8100 Tokyo Headquarters Chiba Prefecture Factory
The new network design incorporates an Allied Telesis SwitchBlade x8100 core switch which acts as the AMF Master. The switch is designed to deliver high availability, wire-speed performance, and a high port count.
AT-x510 Series Switches and AT-x210 Series Switches were chosen for aggregation and edge deployment.
The network is divided between the production system and the administrative system, in a multi-layer structure. The operation of the entire network — from headquarters in Tokyo across WAN links to the factory in Chiba — is managed centrally using Allied Telesis Management Framework (AMF).
AMF is a sophisticated suite of management tools that provide a simplified approach to network management. Common tasks are automated and every-day running of the network made extremely simple. Powerful features like centralized
management, auto-backup, auto-upgrade, auto-provisioning and auto-recovery enable plug-and-play networking and zero-touch management.
In addition, the network backbone was upgraded to 10Gbps. “By using link aggregation, pairs of 10Gbps links have been bundled together to create resilient 20Gbps links. This provides improved performance, and gives us a network that does not stop,” said Mr. MomijiSawa.
Allied Telesis AT-TQ2450 and AT-TQ2403 access points have been used for wireless connectivity.
Mr. Nishida says: “We were able to install the wireless LAN efficiently. The power and the area coverage of the wireless network have been no problem, and we have introduced a stable wireless LAN environment.“
“With AMF we have achieved centralized
network management across the WAN
network outside the main plant. Now,
even if there is a problem in a remote
location, we can manage it from our
central site. ”
Mr. Kakutani
Benefits of the new network
With the network design completed, the holiday break in May 2014 was used for implementing the new network. Mr Shiratori notes: “We had a window of just four days to install the network. It would have been very difficult to adjust the schedule beyond that window.”
Fortunately the time taken to implement the network was short, partly thanks to meticulous preparation in advance. The network was installed without any major problems and the job was completed smoothly. Since then, the network has continued to run steadily, and Sanko are enjoying the significant features and benefits of their new network.
Allied Telesis not only provided the equipment, but also provided consultancy services, such as network administrator training in advance. To support the strengthening of Sanko‘s digital printing system, Allied Telesis have created a reliable network infrastructure.
Simple, and easy to manage
The Allied Telesis Management Framework (AMF) provides practical network virtualization, by using a management plane technology that achieves integrated management in the network. With AMF, multiple devices can be upgraded, or have configuration updates done simultaneously.
Furthermore, management and configuration changes can be performed from a remote location. It is even possible to perform zero-touch device replacement.
This means that Sanko’s staff no longer need to travel between headquarters in Tokyo and the factory in the Chiba Prefecture, simply to reconfigure or upgrade a network device. AMF takes care of these needs. The resulting reduction in network operation and management effort provides real operating cost reductions.
High performing, high-speed
“The network speed has significantly improved. For example, when we are uploading print data to the factory, transfers that used to take 45 minutes are now completed in 15 minutes. In addition, the time it takes us to perform in-house print jobs has also become much shorter. This is a major benefit of the network performance improvement, “said Mr. Sumiya.
Mr. Nishida says: “Even as the amount of desktop publishing data has increased, the bandwidth is not being oversubscribed. This is a big improvment in our network performance.”
Non-stop
Redundancy protocols plus options for bandwidth management and redundant power supplies make the network resilient, and ensure a very high level of network service availability. The Allied Telesis devices are compact without compromising performance, and feature redundant power supplies which are integrated in the switches – meaning they use less rack space. An optimized horizontal cooling system allows the devices to operate even in very high temperatures. High performance, extensive Quality of Service (QoS), and effective management guarantee accurate control of the network.
Ready for innovative applications in the future Sanko are currently working to reform their mission-critical systems. Mr. Kakutani says: “Replacing mission-critical systems is a big project. I think it is good that we have revamped the network prior to this next project. In order to continue to expand, a good underlying system infrastructure is important.” Mr. Shiratori, of OSINet, adds: “Sanko will be handling increasing amounts of data. It is important that both the network and servers can keep up with this increase. We will continue to support and advise Sanko on their future infrastructure projects as they increase their capacity, speed and resiliency.”
Simplifying Network Management with AMF Managing network infrastructure is time intensive, costly, and has traditionally required expensive, third-party applications to effectively manage larger networks. Cloud computing and converged infrastructures deliver a great deal of business value to the enterprise, but they also add complexity. In turn, networks must be more fluid and evolve at increasingly greater speeds in order to keep pace with the modern applications and service delivery models that are driving that complexity. For everything from virtualization to mobility and BYOD, networks must be able to keep pace with business. Allied Telesis Management Framework (AMF) helps IT do just that by greatly reducing the time and cost of managing network infrastructure.
Based on Software-Defined Networking (SDN) principles, AMF is an embedded technology native to Allied Telesis switches that delivers real and immediate value to businesses. Many enterprises see SDN as the “silver bullet” to simplifying
The products
and optimizing the management and performance of their environment. But many applications of SDN today are relevant only to very large data centers. However, IT’s most pressing needs demand a single, converged infrastructure that can be managed as a single entity, reducing complexity and TCO and allowing more to be done with less.
AMF achieves this and more by delivering:
■ unified network management from any device across the
network
■ network automation that simplifies and automates tasks
across the network
■ network intelligence that reacts to changes within the
network and automatically changes the topology of the network
■ automatic backup, restore, and recovery of devices as they
are added to the network
Through this combination of robust features, AMF drives lower network operating expenses by reducing the complexity and level of effort required to maintain the network. One Allied Telesis customer has reported a 60% reduction in operational costs by deploying AMF.
ALLIED TELESIS MANAGEMENT FRAMEWORK
TQ2450
IEEE 802.11N WIRELESS ACCESS POINTS
The Allied Telesis AT-TQ2450 Enterprise-grade access point features two concurrent IEEE 802.11n dual-band radios.
The AT-TQ2450 offers two-spatial-stream Multiple Input and Multiple Output (MIMO) technology and antenna diversity, improving wireless bandwidth, efficiency, and robustness.
The access point operates in either standalone mode or companion mode with a wireless controller, meeting Enterprise business needs.
x210 Series
ENTERPRISE EDGE SWITCHES
The Allied Telesis x210 Series Layer 2+ switches offer an impressive set of features in an affordable package, ideal for applications at the network edge.
x510 Series
STACKABLE GIGABIT SWITCHES
The Allied Telesis x510 Series of stackable Gigabit switches includes a full range of security and resiliency features, coupled with easy management, making them the ideal choice for network access applications.
Allied Telesis x510 Series switches are a high-performing and feature-rich choice for today’s networks. They offer a versatile solution for enterprise applications.
Switch
Blade x8100 Series
NEXT GENERATION INTELLIGENT LAYER 3+ CHASSIS SWITCH Allied Telesis SwitchBlade x8100 Series Advanced Layer 3+ chassis switches are designed to deliver high availability, wirespeed performance, and a high port count. Two control card options, CFC400 and CFC960, provide solutions for medium and large networks. The ability to stack two chassis when using the CFC960 provides a powerful and completely resilient network core solution, which can even be distributed over long distance.
