VoIP Softphone for MAC

Dial91.com’s announces its new MAC based VoIP app for international calling to India. Our Mac/Apple based app provides a premium VoIP service combined with standard prepaid calling card card/PIN functionality so you can easily control your international and India calling expenses. The app features easy to use options such as Balance Display, Redial and low international rates to call any country. Dial91.com is the best VoIP app for making all your international calls.

The Dial91 VoIP Softphone for MAC is simple to activate purchase a PIN at http://www.dial91.com form to $2 to $30, then register you’re PIN in the Dial91 App and start calling clearly for less.

(2)

Install Application



For installing application you need to download it from Dial91 website follow this URL

https://www.dial91.com/softphones/Dial91.zip and click “Save” button, download the application Setup at your MAC PC. (As Shown in Fig-1)

Fig-1

Note: Make sure MAC PC is connect with Internet

Now download “Dial91.Zip” folder on your MAC PC and Unzip “Dial91.Zip” folder. After Unzip the folder you will find

Dial91.dmg” file and double click the “Dial91.dmg” to open it up.

The finder window will be appear, drag and drop Dial91 icon in to Applications Folder. (As shown in Fig-2)

Fig-2



(3)

Now Dial91 has been installed in Applications Folder

To Run

Either

Double click it in Applications folder -> Applications -> Dial91. (As Shown in Fig-3)

Fig-3

OR

Double click Dial91 icon in the finder window. (As Shown in Fig- 4)

(4)

Now Dial91 VoIP Softphone for MAC application successfully installed on your MAC PC and ready to use. You will be see one blank field PIN. (As Shown in Fig-5)

Fig-5

Using Dial91 VoIP Softphone for MAC



Now fill up the PIN then click on “Done” button to Sign in Dial91 VoIP Softphone for MAC. (As Shown in Fig-6).

(5)

After click “Done” button, your entered PIN has been saved and Softphone Dial Pad will be open. Status message will be displayed “Available”. (As Shown in Fig-7)

Fig-7

Placing a Call



You can make a Voice call by using Dial91 VoIP Softphone for MAC.

1. Enter desired number through Dial Pad or Keyboard. 2. Press “Call” button. (As shown in Fig-8)

(6)

After Press “Call” button, Call Windows will be open desired message will be displayed “Calling”. (As Shown in Fig-9)

Fig-9

Once call established session message displayed “Ringing...” and your call is connect and call timer start. (As shown in Fig-10)

Fig-10

Ending a Call

1. Press “Cross” button on your screen to end a call.

2. Session message displayed “call ended”. (As shown in Fig-11)

(7)

Handling an Incoming Call

On Incoming call status message displayed “Incoming Call...” Click “Answer” button to receive Incoming Call. (As Shown in Fig-12)

Fig-12

After click “Answer” button call is connect and Call timer Start. (As Shown in Fig-13)

Fig-13 Click on “Cross” button to end Incoming Call. (As shown in Fig-14)

(8)









Address Book



In Dial91 VoIP Softphone for MAC, users able to access contacts from MAC PC Address Book by entering name in the Phone Number field. (As Shown In fig-15)

Fig-15

Select on any Number in the MAC PC Address Book. And click on “Call” button to make a call. (As Shown in Fig-16)

(9)

Preferences



Dial91 VoIP Softphone for MAC Preferences has following setting options:

General

Account

Sound

Network



Go to top at the MAC PC and click on Dial91 - > Preferences. (As Shown in fig-17)



Fig-17

General



After Click “Preferences” tab, you will be see below screen. You can set here your General settings in Dial91 VoIP Softphone for MAC. (As Shown in Fig-18)

(10)

Account



Click on “Account” tab. You can set here your Account as per your wish on Dial91 VoIP Softphone for MAC. (As Shown in fog-19)

Fig-19

Sound



By clicking on “Sound” tab. You can set here Sound as per your wish on Dial91 VoIP Softphone for MAC. (As Shown in fig-20)

(11)

Network



Click on “Network” tab, you can set Network settings as per your wish on Dial91 VoIP Softphone for MAC. (As Shown

in fig-21)

Fig-21

Quit Dial91 VoIP Softphone for MAC

If you want to quit Dial91 VoIP Softphone for MAC. Click on “Dial91” tab -> “Quit Dial91” to quit Dial91 VoIP Softphone for MAC. (As Shown in Fig-22)

(12)

Troubleshooting

7. Trouble Shooting

Problem

Possible Reason

Suggestion

Problem in starting after

Login

Any other SIP software is

running

Close that software

Keep showing

Registering…

Internet Connection is too

slow or Drop / Server Not

responding

Check your Internet Connection /

server setting

User and password is

wrong

Cross check username and

password (password is case

sensitive)

Voice is too slow / voice is

not audible

System volume is Low /

sound driver not present /

disable

Increase Volume by using

system volume / Install proper

Sound driver / enable driver

Voice is not Clear

Codec is not properly set.

Contact to your server

administrator And Configure

Codec priority

Call get disconnected

before connected

Codec is not properly set.

Contact to your server
