1 Remarks before you start
The dashboard described requires an installation of SAP NetWeaver Application Server Java 7.40 with usage type BI Java installed and configured to work with your SAP NetWeaver Application Server ABAP 7.40.
All screenshots have been made in AS ABAP System with SID “B4S” and “A4H”. Please consider to adapt this based on the SID of your System.
2 System Configuration
2.1 Configuration for SAP NetWeaver BW Technology Components
2.1.1 Objective
The Open Items Analytics Dashboard is using SAP NetWeaver BW technology. In order for this to work, some basic BW settings need to be maintained. Please note that this usage of SAP NetWeaver BW technology is called “Embedded Use Case” and is very much different from setting up a separate BW Hub system that is used as a Data Warehouse.
2.1.2 Steps in Detail
1. Prerequisite: You need to run the following steps with a user that is not DDIC. 2. Go to transaction SE38 and start the report “RSRTS_ACTIVATE_R3IS”.
4. This will trigger the creation of a background job called BI_TCO_ACTIVATION as shown here:
5. Once completed, the job log details should show an all-green status.
2.2 Installation and Configuration of Usage Type BI Java
2.2.1 Objective
In order to run the dashboard which is technically built as a BEx Web Application 7.x, you need to install and configure an Application Server Java with Usage Type BI Java.
2.2.2 Steps in Detail
Follow the steps described in the NetWeaver Installation/Upgrade guide to install the Usage Type BI Java and use the CTC Template for BI Java to configure it to connect to your AS ABAP.
2.3 Activating Objects from BI Content
2.3.1 Objective
2.3.2 Steps in Detail
1. Execute transaction RSA1 which will notify you that the definition of a logical system is missing.
2. Press “Create” to create this definition.
3. Press the “New entries” button and create a new entry with “Log. System” as well as “Name” conforming to the naming scheme <SID>CLNT<MANDT>, so in this example A4HCLNT001 for SID A4H and SAP Client 001:
5. When prompted for a workbench request it is ok to create a new local one:
6. Once the data was saved go back to the “Logical System” popup.
7. Press the “Assign” button and highlight the line corresponding of your SAP Client.
9. Enter the newly created logical system identifier in the “Logical System” input field and save the changes:
10. When prompted to “Replicate Metadata”, select “Only Activate”:
12. Navigate to the “BI Content” tab and switch to the display of “Object Types”:
13. Expand the type “BEx Web Template”
14. In the “Grouping” dropdown, select “Dataflow Before and Afterwards”:
15. Double-click “Select Objects”, select the Web Template
17. When done, select “Install” Install
2.4 Activating Virtual Time Hierarchy
2.4.1 Objective
The activation of hierarchies for time-dependent characteristics needs to be done after activating the Dashboard from BI Content. By default in newly setup systems the hierarchies for time dependent characteristics are not active and hence need to be activated manually.
To check if the Hierarchy is inactive, execute the Dashboard and you should see a message on the “Time Based Analysis” tab stating “There is no Hierarchy Assigned to Characteristic”. If you get this message, you should do the steps given below to activate the time dependent hierarchy in the system.
2.4.2 Steps in Detail
1. Log on to backend and go to transaction RSRHIERARCHYVIRT where all the Virtual Time Hierarchies are maintained.
3. Click on “Date” button on the left side of the page.
4. You should see all the time hierarchies that are available in the system.
6. Expand the “Quarter” node in the tree and double-click on 0QUA1_MON2_DAY. The icon will turn from grey to green.
8. After saving the changes a success message as shown below states that the time-dependent hierarchy is successfully activated in the system.
2.5 Adapting Report-Report-Interface Navigation Targets
2.5.1 Objective
The objective of having RRI is to make the BI Dashboard connect to external Floor Plan Manager Application by opening the application on click of a button or other UI metaphors. An added advantage is that you can pass any of the parameters used in the BI Dashboard to the external web application via URL parameters using RRI for further processing in the web application opened. For RRI to work, it is mandatory to maintain the URL of the external web application along with the parameter details in transaction RSBBS.
In this case explained below, the Business Partner ID (technical name: BP_ID) is passed from the BI Dashboard to an external web application via URL parameters.
Note:
The Default Sender Receiver Assignments that are pre-configured when activating the template and dependent objects from BI Content will work if both ABAP and BI JAVA are installed on the same host, meaning they are accessible with the same protocol (HTTP/HTTPS) and server name.
The following steps need to be done only when AS ABAP and BI JAVA are installed on different hosts and therefore are reachable with different server names (different URL prefixes).
2.5.2 Steps in Detail
1. Open transaction RSBBS by logging on to the backend system 2. Follow the steps “3” to “7” for all the queries listed:
a. 0EPM_AN_OPEN_INVOIC_TIME_BASED b. 0EPM_VP_I_DUE_DATE_ANALYSIS c. 0EPM_AN_OPEN_INVOIC_DETAILED_A d. 0EPM_VP_D_DUNNING_ANALYSIS
4. After selecting the “Receiver” assignment entry, click on “Change” button from the toolbar. 5. This will open a popup window “Maintain Sender Receiver Assignment”
6. In this window, open the value help for the “Receiver Object” field in the “Report” section (click in the input field and press “F4”).
8. Click “Apply” on the “Web Address” dialog box and “Apply” on the “Maintain Sender/Receiver Assignment” dialog box.
9. Save the changes in the transaction page. This is required for activating the assignments for usage.
2.6 Result of Configuration
After you have executed the above steps, you’ll be able to launch the dashboard via the following URL:
[http/https]://[J2EE_server]:[J2EE_port]/irj/servlet/prt/portal/prtroot/pcd!3aportal_content!2fco m.sap.pct!2fplatform_add_ons!2fcom.sap.ip.bi!2fiViews!2fcom.sap.ip.bi.bex?TEMPLATE=0EPM_O PEN_ITEM_ANALYTICS_DASHB
