A B O U T U S

McLachlan Marine Workboats Aberdeen is a major operator within the inshore & offshore

workboat sector in Scotland, with a wealth of experience in Marine Operations, making

us an excellent strategic partner for your next project.

With our ability to provide a variety of vessel sizes and specifications to projects all over

Scotland, coupled with a strong team of over 20 multi-industry staff, our medium sized

business offers flexibility and supporting projects within the Offshore Wind, Marine

Construction, Dredging, Diving, Survey & Renewables sectors.

Our large site and Head Office at Fordoun Airfield, Aberdeenshire boasts modern office

facilities, workshops and showroom, servicing our fleet of vessels, providing a project

base for international customers and housing our range of Suzuki, Icom & Garmin

dealership items.

We also retain Operational Support Offices at both Aberdeen and Montrose Harbour

which are strategically positioned to enable us to mobilize quickly and efficiently on the

North & East coasts.

(3)

S E R V I C E S

With a diverse portfolio of vessels and services our customers refer to our fleet as the

“Marine Multitool” that can support projects of all sizes.

S a f e t y B o a t s

M a r i n e

P e r s o n n e l

D i v e /

C o n s t r u c t i o n

V e s s e l

C r e w T r a n s f e r

V e s s e l s

P r o j e c t S o u r c i n g

& L o c a l S u p p o r t

M a r i n e S e r v i c e s

S u r v e y V e s s e l s

M u l t i p u r p o s e

W o r k b o a t H i r e

(4)

P R O J E C T S U P P O R T

> Dedicated Survey Boat

> Survey Boat (Cable Lay)

> Linesman Team

> Crew Transfer

> UXO Vessels

> Fast Response Vessels

> Quayside Safety

A b e r d e e n O F F s h o r e W i n d f a r m

McLachlan Marine provided support during the installation and commissioning of the

EOWDC providing specialist support through our Linesman teams, survey boats and crew

transfer services to the LiDAR buoy.

K O W L ( K i n c a r d i n e W i n d f a r m P r o j e c t )

McLachlan Marine provided a number of services to the KOWL project from quayside

setup, logistics, warehousing, through to local project planning support and a dedicated

crew transfer vessel.

> Windfarm Crew

Transfer Vessel

> Logistics

> Project Support

> Local project planning

> Quayside setup

(5)

P R O J E C T S U P P O R T

A H E P ( A b e r d e e n S o u t h H a r b o u r , N i g g B a y )

McLachlan Marine was the preferred operator to supply 24hr safety boats and a

dedicated multibeam survey boat for the 3 year project.

Other services provided throughout the project:

ROV Inspection works

Sub bottom profile of hard to access areas

Marine Safety/ Marine Control

> 24/7 Safety Boats

> Dedicated Survey Boat

> Survey /

Inspection Services

> ROV Services

> Marine Co-ordinators

> General Workboat

> Marine Safety

(6)

Classification / Flag

Flag: UK

Trading area: 60 miles from safe haven Call sign: 2GEE9

Classification society: MCA/SCMS

Class ship type: Crew Transfer Vessel

Class notation: Work boat Code Category 2

Principal Dimensions

Length o.a.: 25,14 m Breadth o.a.: 8,02 m

Draft: 1 - 1,225 m

GRT: 65,62

Free deck space: Tot. 50 m² Fwd. 20 m² Aft 30 m² Max. Deadweight: 18 ton Cargo Capacity: max. 10 ton Maximum speed: 23 knots - 455 L/h Service speed: 20 knots - 370 L/h Range: 300 Nm at 20 knots

Accommodation

Passenger: 12x suspension seats

Crew: 3

Navigation And Communication Systems

GMDSS: A1 + A2

Safety & Rescue: Sea Marshall Search and Rescue System Jason’s Cradle Rescue zone Machinery / Propulsion Power output: 2x 910 kW Propulsion: 2x waterjets MJP Main engines: 2x Deutz TBD-620

Auxiliary engines: 2x Deutz D229.6 - 51,8 kW

Deck Equipment

Hydraulic deck crane: Furakawa 500

Load-range deck crane: Winch 1800 kg at 5 m, 3000 kg at 3,4 m.

Tank Capacities

Fuel: 2x 3000 Ltr.

Fresh water: 1000 Ltr.

O C E A N T I T A N

25m Windfarm Support Vessel with large forward & aft deck space, large deck crane, XL passenger seating areas

and internal operations area and survey pole system. Suitable for inshore or offshore survey & crew transfer.

(7)

Vessel Particulars

Vessel Type: Twin screw, twin hull workboat Classification: UK MCA Workboat Code Area of Operation: Cat 2 – 60nm from

safe haven Construction: Welded steel

Dimensions Length Overall: 18.75m Beam Overall: 8.7m Depth Moulded: 1.75m Draft Loaded: 1.3m Performance

Bollard Pull: 5 tonnes

Speed: 8 knots

Cargo Capacity: 40 Tonnes (Total inc liquids)

Propulsion & Manouvering

Main Engines: 2 x Doosan L086TIH

Power: 2 x 285hp

(210kW) @ 2100rpm Stern Gear: 700 Ø open props Steering: Twin rudder –

hand hydraulic Tanks Fuel Bunkers: 2 x 2.6m3 Fresh Water: 0.2m3 Black Water: 0.2m3 Liquid Cargo: 2 x 9m3_{, 2 x 12m}3 Deck Equipment

Hydraulic deck cranes: 2 x Furakawa 500 Load-range deck crane: Winch 1800 kg at 5 m,

3000 kg at 3,4 m.

Aux Machinery & Deck Equipment

Generator: Beta 21kVA 415V 3 phs Deck Crane: Iron Fist IFG450M6

[email protected]

Deck Winch: NSW 10t tugger winch

O c e a n S u p p o r t e r

A multi-purpose road transportable workboat designed for the hardiest of tasks in locations the average workboat would struggle to get to. Ideal for large construction projects, dive support, harbour maintenance

(8)

Length overall 17.0m Beam overall 7m Weight 22t

Main Features

• Bow transfer arrangement • 12 KVA generator

• Large Wheelhouse refurbished with 12 • Coded 3 crew and 12 passengers

Engines

Working Area

• 20NM O shore

• Max wave height 4-5m

Work Scope

• Survey

• Crew Transfer • Safety Boat

• Cargo Transfer area

L I N Z I S

This Wave Commander catamaran built by Alnmaritec is a powerful vessel designed for offshore wind farm support. The vessel has just undergone a major refit to her cabin with the addition of crew accommodation, kitchen & seating area including 12 new passenger

adjustable suspension seating.

(9)

Length overall 12.0m Beam overall 6.0m Weight 13.0t

Main Features

• Removable rails for waterline access • Palfinger 6ton deck crane

• Large deck space

• Coded 2 crew and 4 passengers

Engines

• 2 x 180 BHP Diesel Inboards

Working Area

• 20NM O shore • Max wave height 2m

Work Scope

• Equipment Deployments • Dive Support

• Cargo runs

O C E A N V I K I N G

12m GRP Multicat fitted with a Palfinger marine crane and 2ton capstan this vessel is perfect for supporting construction projects, data buoy deployment and maintenance. With a large deck space and 5ton deck capacity this versatile workboat is a cost-effective

(10)

Main Features

• 700mm sq. survey moon pool • Survey grade LD5 GPS System • Coded 3 crew and 12 passengers

Engines

• 2 x 370 BHP Iveco Diesel Engines

Working Area

• 20NM O shore • Max wave height 4m

Work Scope • Survey • Crew Transfer • Safety Boat • Cargo Transfer • Dive Support

O C E A N P R E D A T O R

Built in 2011 specifically for the task of transporting and transferring personnel to ships waiting off Aberdeen. With a large open plan cabin

with seating, toilet and cooking facilities onboard. Deck space of 20m2_{and survey moon pool / pole system this vessel is a safe stable}

(11)

Length overall 11.5m Beam overall 4.8m Weight 13t

Main Features

• Survey wheelhouse with table and workbench • 700mm sq. survey moon pool

Engines

• 2 x 270 BHP Iveco Diesel Engines

Working Area

• 20NM O shore

Work Scope • Survey • Crew Transfer • Safety Boat • Dive Support

T R U E N O R T H

True North was our first Inshore survey vessel, overhauled in 2014 with new cabin layout, new engines, generator, new deck and 700mm

(12)

Main Features

• Bespoke Transfer Nose

• Jason’s Cradle for MOB recovery • Coded 2 crew and 4 passengers

Engines

• 2 x 200HP Petrol Outboards Working Area

• 20NM O shore

• Max wave height 3-4m Work Scope

• Safety Boat Day/Night • Dive Support

• Shallow Water Surveys •Crew Transfer

• Windfarm Support • Fast Response

O C E A N I N T E R C E P T O R

11m Ultimate Boat. This hard sided safety boat can handle difficult weather and large waves with the innovative wave piercing hull for fast response and load capacity operating up to 20NM offshore. Due to the hard side design the cabin and deck space is wider and more spacious

than a conventional cabin RIB boat. Rapid response speed of 40knts powered by 2 x 200hp Outboards.

(13)

Main Features

• Bow transfer arrangement

• Low freeboard for rescue / dive works • Stretcher bed in cabin

Engines

• 2 x 225 BHP Petrol Outboards

Working Area

• 20NM O shore

Work Scope

• Safety Boat • Dive Support • Fast Response

O C E A N G U A R D I A N

10.5m fast response Humber Cabin RIB is an all-weather safety boat, operating up to 20NM offshore and can operate in 2-3m wave height, good sized cabin, stretcher bed, toilet & cooking facilities for crew with

(14)

Main Features

• Jasons Cradle for MOB recovery

• Good sized wheelhouse for up to 4 people • Coded 2 crew and 4 passengers

Engines

• 2 x 40HP Petrol Outboards

Working Area

• 20NM O shore

Work Scope

• Safety Boat Day/Night • Dive Support

• Shallow Water • Crew Transfer

H O L L I J

7.5m fast response North Craft Cabin RIB. Fully road transportable by 4x4 & trailer.

This compact safety boat can be deployed anywhere In Scotland within hours, seating in the cabin for 2 and fast response speed

(15)

With a depth range of 500ft and small size it can penetrate areas where human divers could not go safely, inspecting for leaks, sediment level, coating condition, and assessing

the general condition of ships tanks or subsea installations.

Features

Display: 15 inch integrated video display • ROV Dimensions: 36.8 x 22.8 x 21.6 cm • Submersible Weight: 4.5 kgs

• Total System Size & Weight: 61 kgs • 3 Umbilicals N, + Buoyant & - Buoyant

• Maximum Speed: 6 knots • Upgraded GTO Thrusters McLachlan Marine are experienced

equipment and can o er a full “turn key package” or survey vessel and equipment package through our local partnerships with rental companies.

ROV & SURVEY SERVICES

We own and operate a VideoRay Pro 3 GTO ROV, one of the world’s most popular small ROVs for inshore & offshore applications. We have used this system successfully on a range of projects; from seabed inspection, salvage works to ships hull and propeller inspections. This portable system
