25.4 Radiation in Your Life >

Chapter 25

Nuclear Chemistry

25.1 Nuclear Radiation

25.2 Nuclear Transformations 25.3 Fission and Fusion

(2)

How does a smoke

detector work?

CHEMISTRY & YOU

CHEMISTRY & YOU

A typical household smoke detector

contains a small amount of americium, Am, in the form of AmO₂.

Americium-241 is a radioisotope.

(3)

25.4 Radiation in Your Life > Detecting RadiationDetecting Radiation

Detecting Radiation

(4)

Radiation emitted by radioisotopes has

enough energy to knock electrons off

some atoms of a bombarded substance,

producing ions.

(5)

It is not possible for humans to see, hear,

smell, or feel ionizing radiation.

(6)

It is not possible for humans to see, hear,

smell, or feel ionizing radiation.

• People must rely on detection devices to alert them to the presence of radiation and to monitor its level.

(7)

Radiation can expose a photographic plate.

• When the plate is developed, its

darkened areas show where the plate has been exposed to

radiation.

(8)

Radiation emitted in a smoke detector

ionizes the nitrogen and oxygen in the

air, and a current flows. When smoke

particles attach to the ions, the ions

lose their charge. What happens next?

CHEMISTRY & YOU

(9)

Radiation emitted in a smoke detector

ionizes the nitrogen and oxygen in the

air, and a current flows. When smoke

particles attach to the ions, the ions

lose their charge. What happens next?

CHEMISTRY & YOU

CHEMISTRY & YOU

Once the ions in the air inside the smoke

(10)

(11)

Geiger Counter

A Geiger counter uses a gas-filled metal

tube to detect radiation.

• When ionizing radiation penetrates a thin

window at the end of the tube, the gas inside the tube becomes ionized.

• Each time a Geiger tube is exposed to radiation, current flows.

(12)

Geiger Counter

Geiger counters can detect

alpha, beta, and gamma

radiation.

• Astronomers use Geiger counters to detect cosmic rays from outer space.

• Geologists use Geiger counters to search for radioactive minerals.

(13)

Scintillation Counter

A scintillation counter uses a

phosphor-coated surface to detect radiation.

• When ionizing radiation strikes the surface, the phosphor produces bright flashes of light, or scintillations.

(14)

Scintillation Counter

Scintillation counters are more sensitive

than Geiger counters.

• They can detect some radiation that would not be detected by a Geiger counter.

• Scintillation counters are used to track the path of radioisotopes through the body.

(15)

Film Badge

This is a diagram of a typical film badge.

• The badge

contains layers of photographic film covered with black light-proof paper. • To reach the film,

radiation must pass through a filter, which

(16)

Film Badge

People who work with or near ionizing

radiation must wear a film badge to monitor

their exposure while they are at work.

• At specific intervals, the film is removed and developed.

(17)

Which of the following detectors would

you use to locate uranium ores in a soil

sample?

A. Geiger counter

B. scintillation counter

(18)

Which of the following detectors would

you use to locate uranium ores in a soil

sample?

A. Geiger counter

B. scintillation counter

(19)

25.4 Radiation in Your Life > Using RadiationUsing Radiation

Using Radiation

(20)

Using Radiation

What are some practical uses of

radioisotopes?

(21)

(22)

Scientists use radiation to detect trace

amounts of elements in samples.

• This process is called neutron activation analysis.

(23)

Analyzing Matter

• A sample is bombarded with neutrons from a radioactive source.

• Some atoms in the sample become radioactive.

• The half-life and type of radiation emitted can be detected and analyzed by a computer.

– Because this data is unique for each isotope,

scientists can determine what radioisotopes were produced and infer what elements were in the

(24)

Analyzing Matter

• Museums use this process to detect art

forgeries.

(25)

Radioisotopes called tracers are used in

agriculture to test the effects of herbicides,

pesticides, and fertilizers on plants.

• A tracer is introduced into the substance being tested.

• Next, plants are treated with the tagged substance.

• Devices that detect radioactivity are used to locate the substance in the plants.

(26)

The tracer may also be monitored in

animals that consume the plants, as well as

in water and soil.

(27)

Radioisotopes can be used to detect disorders of the thyroid gland, which is located in the throat.

• To diagnose thyroid disease, the patient is given a drink containing a small amount of the radioisotope iodine-131. • After about two hours, the

amount of iodide uptake is measured by scanning the patient’s throat with a

radiation detector.

(28)

• The radioisotope technetium-99m is

used to detect brain tumors and liver

disorders.

• Phosphorus-32 is used to detect skin

cancer.

(29)

Radiation is one method used in the

treatment of some cancers.

Treating Diseases

• Cancer is a disease in which abnormal cells in the body are produced at a rate far beyond

the rate for normal cells.

(30)

Fast-growing cancer cells are more

susceptible to damage by high-energy

radiation such as gamma rays than are

healthy cells.

Treating Diseases

(31)

Some normal cells are also killed, however,

and cancer cells at the center of the tumor

may be resistant to the radiation.

Treating Diseases

(32)

Some normal cells are also killed, however,

and cancer cells at the center of the tumor

may be resistant to the radiation.

Treating Diseases

• The benefits of the treatment and the risks to the patient must be carefully evaluated before radiation treatment begins.

(33)

Salts of radioisotopes can also be sealed in

gold tubes and directly inserted in tumors.

Treating Diseases

• This method of treatment is called seeding. • The salts emit beta and gamma rays that kill

the surrounding cancer cells.

(34)

Prescribed drugs containing radioisotopes

of gold, iodine, or phosphorus are

sometimes used in radiation therapy.

Treating Diseases

• A dose of iodine-131 larger than that used to detect thyroid diseases can be given to a

patient to treat the disease.

• The iodine that collects in the gland emits beta particles and gamma rays, which provide

(35)

(36)

Describe the benefits and risks of

radiation therapy for cancer.

(37)

25.4 Radiation in Your Life > Key ConceptsKey Concepts

Geiger counters, scintillation

counters, and film badges are

commonly used to detect radiation.

(38)

25.4 Radiation in Your Life > Glossary TermsGlossary Terms

ionizing radiation: radiation with enough

(39)

Electrons and the Structure of Atoms

• The ability to detect particles emitted when

nuclei decay helps scientists study processes that take place in living organisms.

• This ability also allows scientists to determine the age of fossils and other objects.

BIG IDEA
