Henry David Thoreau, American writer and philosopher
«The question is not what you look at,
but what you see.»
Those who have developed high-quality products are faced with two options: to declare themselves satisfied with what has already been achieved or to improve his performance systematically. We have decided on the second option and have invested more than others in research and development. In that we regard nothing as given and are dogged in our insistence on following new paths, surprising prospects with respect to both general and economic efficiency open up for you.
We set ourselves the highest standards in respect to convenience and energy savings. This is why we consider efficiency to be a comprehensive attitude. We define added value for customers and the environment as a triad made up of uncompromising quality, ecologically long service life and intelligent thriftiness.
We question what is already there.
Energy yield Expenditure of energy without S gearbox Expenditure of energy with S gearbox 2 3 1 EfficiEncy ExpErIEncE 5
Our gear wheels have been given a completely new, non-linear geometry. This unconventional adaptation is exceptionally effective: The motors become smaller and are given a new break-away – precisely when they need it. For example, when a butterfly valve moves out of the sleeve gasket while opening or closing. This means that you are getting actuators with even greater ease of handling and thriftiness.
conventional motor and gearbox combinations create a linear torque. This makes the actuators very energy-intensive. The S gearbox in the Belimo motors achieve a very high torque for the first couple of degrees of rotation – a so-called breakaway torque with unchanging current – and reduces this to an absolute minimum for the remainder of travel to the required angle of rotation.
Force
Angle of rotation
We are redesigning the gearbox.
You receive compact, economical actuators.
1 2
7
Our patented motor control is equipped with a dynamic holding force detection. This means that only exactly the required curret is used to keep the dampers or valves in their position. This results in a lowering of the annual energy consumption of the actuator by as much as 70%.
Dampers and valves are in movement only 5 to 15% of the time. At the same time, the actuators are used to hold the final controlling elements in their current position – independent of changes in the forces or pressures, respectively. conventional motor controls do not recognise such changes. In order to ensure that the dampers or valves do not move, they must apply twice as much safety current as the Belimo actuators.
We detect the holding force dynamically.
You save energy.
Time Moving Holding Energy yield Moving/holding: conventional Moving/holding: With dynamic holding force detection 2
3 current
1 Example: globe valve
actuator
1 2
9
The trend-setting Supercap technology is the intelligent and energy-efficient alternative to the mechanical spring-return. Because of the fact that the final controlling elements move electronically into their safety positions, the permanent energy against the spring is dispensed with. This means that you reduce electricity consumption of the actuators by up to 80%.
conventional emergency control actuators with spring assemblies require considerable energy in order to tighten the springs on a regu-lar basis and hold the final controlling elements in position. Supercap actuators with condensers store energy – in a way comparable to a reservoir – and do not release it until there is an electricity interruption, in order to move the damper or the valve into the desired safety posi-tion. The specially low-friction gearbox makes it possible to keep the size of the condensers small and the design of the actuators compact.
We put our faith in Supercaps.
You require less current.
Energy yield Movement with mechanical spring Movement with Supercap 1 2 3 Time 1 current 3 2
Example: butterfly valve
11
If valves do not close completely tight, heating or cooling energy disappears unused in the pipe network on a continuous basis. Our compact, air bubble tight closing characterised control valves prevent such circulation losses – even with high differential pressures. In contrast to conventional metal seats, the spherical valve cones with precisely fitting resilient jointing do not cause any additional losses as they age. You then save energy on a perma-nent basis throughout the entire service life.
The secret lies in the spherical shape of the valve cone and in the special arrangement of seals which adjusts itself dynamically to the sphere. The air bubble tightness is ensured for years as a result. By contrast, conventional valves with metal seats experience increasing wear and leakage losses can double over time. The patented charac-terising disk of the characterised control valves ensures in addition an equal-percentage valve characteristic curve. This means that you can dispense with solid globe valves in many cases.
We make valves leak-proof.
You avoid circulation losses.
1 2 3 4 5 Years
Energy yield With conventional valves
With air bubble tight characterised control valves 1 2 3 1
Energy loss through leakages
3 2
13
EfficiEncy
ExpErIEncE
In addition to the flow rate, the sensors in our electronically regulated valves also measure the temperatures in the supply and return lines, e.g. with heat exchangers. The values are saved in the integrated webserver for up to 13 months and are visible, e.g. onsite on the laptop. The current consumption can also be depicted on the management system. This way, you can analyse and document which direction the energy is flowing to and optimise the energy flows of the hot and cold water circuits at any time.
The consumption of energy-intensive component such as coolers, boilers and pumps is often much too high if heat exchangers are not working efficiently. The integrated monitoring in our Energy Valve offers points of reference for recognising this. The «ΔT Manager» that is also included permits a fine-tuning of the system and ensures that the exchanger is operated only within the range of its optimum performance in terms of energy.
We make energy currents visible.
You optimise the water circuits.
Volumetric flow V· Energy savings = pump energy power output exchanger (a-value) Temperature differential [°c] Adjustable ΔT limitation Saturation limit 1 2 3 4 5 power output exchanger ΔT
Differential temperature limitation for heat exchanger
4 3 2
1 5
15
More comfort and at the same time massive energy savings: The Mp-Bus® from Belimo con-veys the actual damper positions of the volumetric flow units and the needs signals from the room temperature controllers to our Fan Optimiser on a continuous basis. The Fan Optimiser calculates from this the actual requirements of the system and generates the control values for the ventilators. This way they achieve a considerable reduction in pressure loss and elec-tricity consumption and an audible reduction the flow noise.
real-time information at the field/room level is required in order to operate a system in an optimum manner in terms of energy. With the Mp-Bus®
technology from Belimo, temperature, pressure cO2 and other sensors
can be integrated in higher-level field bus systems in the simplest manner imaginable. This means that the system can be readily monitored at any time and that energy consumption can be optimised. The marked reduction in cabling requirements (in terms of both material and time) also has a positive influence on the ecological balance.
We control the fans.
You minimise consumption.
Supply air volumetric flow [m3/h]
Energy yield consumption with conventional ventilator control consumption with Belimo Fan Optimiser Supply air ventilator power consumption [kW]
1 3
2
1 2
