2.1 Introduction

2.2 Hard Disks

2.3 RAIDs

2.4 SANs and NAS

2.5 Case Study

(4)

• DBMS needs to retrieve, update and process

persistently stored

data

–

Storage consideration is an important factor in

planning a database system (physical layer)

–

Remember:

The data has to be securely stored, but

access to the data should be declarative!

4 2.1 Physical Storage Introduction

(5)

• Data is stored on a

storage media

. Media highly

differ in terms of

–

Random Access

Speed

–

Random/Sequential Read/Write

speed

–

Capacity

–

Cost

per Capacity

(6)

• Capacity:

Quantifies the amount of data

which can be stored

–

Base Units: 1 Bit, 1 Byte = 2

3 _{Bit = 8 Bit}

–

Capacity units according to IEC, IEEE, NIST, etc:

• Usually used for file sizes and primary storage (for higher

degree of confusion, sometimes used with SI abbreviations…)

•

1 KiB

= 1024

1 _{Byte; 1}

_MiB

_{= 1024}

2 _{Byte ; 1}

_GiB

_{= 1024}

3 _Byte;

…

–

Capacity units according to SI:

• Usually used for advertising secondary/tertiary storage

•

1 KB

= 1000

1 _Byte

_≈

_{0.976 KiB; 1}

_MB

_{= 1000}

2 _Byte

_≈

_{0.954 MiB;}

1 GB

= 1000

3 _Byte

_≈

_{0.931 GiB; …}

–

Especially used by the networking community:

•

1 Kb

= 1000

1 _Bit

₌

_{0.125 KB}

_≈

_{0.122 KiB ;}

1 Mb

= 1000

2 _Bit

₌

_{0.125 MB}

_≈

_{0.119 MiB}

6

(7)

(8)

• Random Access Time:

Average time to access

a random piece of data at a known media position

–

Usually measured in ms or ns

–

Within some media, access time can vary depending

on position (e.g. hard disks)

• Transfer Rate:

Average amount consecutive of

data which can be transferred per time unit

–

Usually measured in KB/sec, MB/sec, GB/sec,…

–

Sometimes also in Kb/sec, Mb/sec, Gb/sec

8

(9)

• Volatile:

Memory needs constant power to keep data

–

Dynamic:

Dynamic volatile memory needs to be “refreshed”

regularly to keep data

–

Static:

No refresh necessary

• Access Modes

–

Random Access:

Any piece of data can be accessed in

approximately the same time

–

Sequential Access:

Data can only be accessed in sequential

order

• Write Mode

–

Mutable

Storage: Can be read and written arbitrarily

–

Write Once Read Many (

WORM

)

(10)

• Online

media

–

„always on“

–

Each single piece of data can be accessed fast

–

e.g. hard drives, main memory

• Nearline

media

–

Compromise between online and offline

–

Offline media can automatically put “on line”

–

e.g. juke boxes, robot libraries

• Offline

media (disconnected media)

–

Not under direct control of processing unit

–

Have to be connected manually

–

e.g. box of backup tapes in basement

10

2.1 Online, Nearline, Offline

(11)

• Media characteristics result in a

storage hierarchy

• DBMS optimize data distribution among the storage

levels

–

Primary Storage:

Fast, limited capacity, high price,

usually volatile electronic storage

• Frequently used data / current work data

–

Secondary Storage:

Slower, large capacity, lower price

• Main stored data

–

Tertiary Storage:

Even slower, huge capacity, even lower

price, usually offline

(12)

12

2.1 The Storage Hierarchy

Cos

t

Spe

ed

Optical Disks, Tape

Primary

Secondary

Tertiary

Cache, RAM

Flash, Magnetic Disks

~100 ns

~10 ms

(13)

Type

Media

Size

Random

Acc. Speed

Transfer

Speed

Characteristics

Price

Price/GB

Pri

L1-Processor Cache

32 KB

5 x 10

-10

_s

_{15.4 GB/sec}

_{Vol, Stat,}

RA,OL

Pri

DDR3-Ram

(Corsair Dominator

Platinum Series)

8 GB

2.6 x 10

-8

_s

_{12.3 GB/sec}

_{Vol, Dyn, Ra,}

OL

€ 160

€ 20

Sec

Harddrive SSD

(Samsung 840 PRO)

256 GB

4 x 10

-6

_s

_{513 MB/sec}

_{Stat, RA, OL}

_{€ 187}

_{€ 0.73}

Sec

Harddrive Magnetic

(Seagate ST2000DM001)

2000 GB

5.7 x 10

-4

_s

_{153 MB/sec}

_{Stat, RA, OL}

_{€ 100}

_{€ 0.05}

Ter

Blank recordable

DVD-R disk

4.7 GB

9.8 x 10

-2

_s

_{11 MB/sec}

_{Stat, RA, OF,}

WORM

€ 0.15

/Disk

€ 0.03

Ter

LTO-5 tape

(TDK - LTO Ultrium 5 Data Cartridge)

1500 GB

58 s

280 MB/sec

Stat, SA, OF

€ 15

/Tape

€ 0.01

2.1 Storage Media – Examples

Pri= Primary, Sec=Secondary, Ter=Tertiary

(14)

• Hard drives are currently the standard for

large, cheap and persistent storage

–

Usually used as the

main storage

media

for most data in a DB

• DBMS need to be

optimized

for

efficient disk storage and access

–

Data access needs to be as fast as possible

–

Often used data should be accessible with highest speed,

rarely needed data may take longer

–

Different data items needed for certain reoccurring tasks

should also be stored/accessed together

14

(15)

• Directionally

magnetization of a ferromagnetic

material

• Realized on hard disk platters

–

Base platter made of non-magnetic aluminum or glass substrate

–

Magnetic grains worked into base platter to form

magnetic regions

• Each region represents 1 Bit

–

Read head

can detect

magnetization direction of

each region

–

Write head

may change

direction

(16)

• G

iant

M

agneto

r

esistance Effect (

GMR

)

–

Discovered 1988 simultaneously by Peter Grünberg and Albert

Fert

• Both honored with the 2007 Nobel Prize in Physics

–

Allows the construction of efficient

read heads:

• The electric resistance of an alternating ferro- and non-magnetic

material giantally changes within changing directed magnetic fields

–

http://www.research.ibm.com/research/demos/gmr/cyberdemo1.htm

16

(17)

• Perpendicular

Recording (used since 2005)

–

Longitudal Recording limited to ~200 Gb/inch

2 _{due to}

superparamagnetic effect

• Thermal energy may spontaneously change magnetic direction

–

Perpendicular recording allows for up to 1000 Gb/inch

2 –

Very simplified:

Align

magnetic field orthogonal

to surface instead of

parallel

• Magnetic regions can be

smaller

(18)

• Usage of magnetic

grains

instead of continuous

magnetic material

–

Between magnetic direction transitions,

Neel Spikes

are

formed

• Areas of unsure magnetic direction

–

Neel Spikes are larger for continuous materials

–

Magnetic regions can be smaller as the transition width can be

reduced

18

(19)

• A hard disk is made up of multiple

double-sided platters

–

Platter sides are called

surfaces

–

Platters are fixed on main

spindle

and rotate at equal and constant speed

(common: 5400 rpm / 7200 rpm)

–

Each surface has it’s own

read

and

write head

–

Heads are attached to

arms

• Arms can position heads

along the surface

• Heads cannot move

inde-pendently

–

Heads have no contact

to surface and hover on

top of an air bearing

(20)

• Each surface is divided into circular

tracks

–

Some disks may use spirals

• All tracks of all surfaces with the same diameter

are called

cylinder

–

Data within the same cylinder can be accessed very

efficiently

20

EN 13.2

(21)

• Each track is subdivided into

sectors

of equal

capacity

a) Fixed angle sector subdivision

• Same number of sectors per track, changing density,

constant speed

b) Fixed data density

• Outer tracks have more sectors than inner tracks

• Transfer speed higher on

outer tracks

• Adjacent sectors can be

(22)

• Hard drives are not completely reliable!

–

Drives do

fail

–

Means for physical failure recovery are necessary

• Backups

• Redundancy

• Hard drives age and

wear

down.

Wear significantly increases by:

–

Contact

cycles (head parking)

–

Spindle start-stop

–

Power-on

hours

–

Operation outside ideal environment

• Temperature too low/high

• Unstable voltage

22

2.2 HD – Reliability

(23)

• Reliability

measures are

statistical

values assuming

certain usage patterns

• Desktop usage (all per year): 2,400 hours, 10,000 motor

start/stops, 25°C temperature

• Server usage (all per year): 8,760 hours, 250 motor start/stops,

40°C temperature

–

Non-Recoverable read errors:

A sector on the surface

cannot be read anymore – the data is lost

• Desktop disk: 1 per 10

14 _{read bits, Server: 1 per 10}

15 _{read bits}

• Disk can detect this!

–

Maximum

contact cycles

: Maximum number of allowed

head contacts (parking)

(24)

–

Mean Time Between Failure (

MTBF

): Statistically

anticipated time for a large disk population failing to

50%

• Drive manufactures usually use optimistic simulations to

guess the MTBF

• Desktop: 0.7 million hours (80 years), Server: 1.2 million

hours (137 years) –

Manufacturers values

–

Annualized Failure Rate (

AFR

): Probability of a failure

per year based on MTBF

• AFR = OperatingHoursPerYear / MTBF

_hours

• Desktop: 0.34%, Server: 0.73%

24

2.2 HD – Reliability

(25)

• Failure rate during a hard disks lifespan is not constant

• Can be better modeled by the “

bathtub curve

” having

3 components

–

Infant Mortality Rate

–

Wear Out Failures

–

Random Failures

(26)

• Report by Google

–

100,000 consumer grade disks

(80-400GB, ATA Interface,

5,400-7,200 RPM)

• Results (among others)

–

Drives fail often!

–

There is infant mortality

–

High usage increases infant

mortality, but not later failure

rates

–

Observed AFR is around

7%

and

MTBF

16.6 years

!

Relational Database Systems 2 – Wolf-Tilo Balke – Institut für

Informationssysteme

26

Failure trends in a large disk drive population

E. Pinheiro, W.-D. Weber, L. A. Barroso 5th USENIX conference on File and Storage Technologies, 2007

2.2 Real World Failure Rates

(27)

• Seagate ST32000641AS 2 TB (Desktop Harddrive, 2011)

–

Manufacturer’s specifications

2.2 HD – Example Specs

Specification

Value

Capacity

2 TB

Platters

4 Heads

8 Cylinders

16,383

Sectors per track

63 Bytes per sector

512 Spindle Speed

7200 RPM

MTBF

85 years

(28)

• Assume a storage need of 100 TB. Only following

HDs are available

–

Capacity:

1 TB

capacity each

–

MTBF: 100,000 hours each (ca.

11 years

)

• Consider using 100 of these disks independently

(w/o RAID).

–

Total Storage: 100,000 GB = 100 TB

–

MTBF: 1,000 hours (ca.

42 days

)

–

THIS IS BAD!

• More sophisticated ways of using multiple disks are

needed

28

(29)

• Alternative to hard-drives:

SSD

–

Use microchips which retain data in non-volatile

memory chips

and contain

no moving parts

• Use the same interface as hard disk drives

–

Easy replacement in most applications possible

• Key components

–

Memory

–

Controller

(30)

• Flash-Memory

–

Most SSDs use NAND-based flash memory

–

Retains memory even without power

–

Slower than DRAM solutions

–

Single-level cell versus multi-level cell

–

Wears down!

• DRAM

–

Use volatile Random Access Memory

–

Ultrafast data access (< 10 microseconds)

–

Sometimes use internal battery or external power device to

ensure data persistence

–

Only for Applications that require even faster access, but do

not need data persistence after power loss

30

2.2 Memory

(31)

• The controller is an embedded processor

• Incorporates the electronics that bridge the

NAND memory components to the host

computer

• Some of its functions

–

error correction,

wear leveling

,

bad block

mapping

, read and write caching, encryption, garbage

collection

(32)

• Advantages

–

Low access time and latency

–

No moving parts



shock resistant

• MTBF about 2 million hours

–

Lighter and more energy-efficient than HDDs

• Disadvantages

–

Divided into blocks/pages

• If one byte changes the whole page has to be written

• The old page will be marked as stale

• Only whole blocks can be deleted

–

Limited ability of being rewritten (between 3,000 and 100,000

cycles per page)

• Wear leveling algorithms assure that write operations are equally

distributed to the pages

32

2.2 SSD – Summary

(33)

• The

disk controller

organizes low level

access to the disk

–

e.g. head positioning, error checking, signal

processing

–

Usually integrated into the disk

–

Provides

unified

and

abstracted

interface

to access the disks (e.g. LBA)

–

Connects disk to a peripheral bus (e.g. IDE,

SCSI, FiberChannel, SAS)

• The

host bus adapter

(HBA) bridges

between the peripheral bus and systems

internal bus (like PCIe, PCI)

–

Internal Bus usually integrated into systems

main board

–

Often confused as being the disk controller

• DAS

(Directly Attached Storage)

2.2 HD – Controller

Disk

Controller

Host Bus

Adapter

Peripheral

Bus

Internal Bus

Inner System / Mainboard

(34)

• Sectors can be logically grouped to

blocks

by the

operating system

–

Sectors in a block do not necessarily need to be

adjacent

–

e.g. NTFS defaults to 4 KiB per block

• 8 sectors on a modern disk

• Hardware address

of a block is combination of

–

Cylinder number, surface number, block number

within track

–

Controller maps hardware address to

logical block

address

(LBA)

34

2.2 HD – Controller

(35)

• Disk controller transfers content of whole blocks to

buffer

–

Buffer resides in

primary storage

and can be accessed

efficiently

–

Time needed to transfer a random block (4KiB/Block on

ST3100034AS): (<10 msec)

• Seek Time:

Time needed to position head to correct cylinder (<8

msec)

• Latency (Rotational Delay):

Time until the correct block arrives

below the head (<0.14 msec)

• Block Transfer Time:

Time to read all sectors of block (<0.01 msec)

–

Bulk Transfer Rate for

n

adjacent blocks (<20msec for

n

=10)

(36)

• Locating data on a disk is a major

bottleneck

–

Try operating on data already in buffer

–

Aim for bulk transfer, avoid random block transfer

36

2.2 HD – Controller

(37)

• A single HD is often not sufficient

–

Limited capacity

–

Limited speed

–

Limited reliability

• Idea: Combine multiple HD into a

RAID Array

(

R

edundant

A

rray of

I

ndependent

Disk

s)

–

RAID Array treats multiple hardware disks as a single

logical disk

• More HDs for increased capacity

(38)

• The RAID controller connects

to multiple hard disks

–

Disks are

virtualized

and

appear to be just one single

logical

disk

–

The RAID controller acts as an

extended specialized HBA

(Host Bus Adapter)

–

Still

DAS

(Directly Attached

Storage)

38

2.3 RAID Controller

RAID Controller

Peripheral Bus

Internal Bus

Represented

as single

logical Disk

(39)

• Mirroring

(or shadowing): Increases reliability by

complete redundancy

• Idea: Mirror Disks are

exact copies

of original disk

–

Not space efficient

• Read speed can be

n

times as fast, write speed does not

increase

• Increases reliability. Assume

–

Two disks with a MTBF 11 years each

• One original disk, one mirror disk

• Assume disk failures are independent of

each other (unrealistic)

–

Disk replacement time of 10 hours

(40)

• Striping:

Improve performance by parallelism

• Idea: Distribute data among all disks for increased

performance

• BitLevel Striping:

Split all bits of a byte to the disks

–

e.g. for 8 disks, write

i

-th bit to disk

i

–

Number of disk needs to be a power of 2

–

Each disk is involved in each access

• Access rate does not increase

• Read and write transfer speed linearly increases

• Simultaneous accesses not possible

–

Good for speeding up few, sequential and large

accesses

40

Silber 11.3

(41)

• Block Level Striping:

Distribute blocks among

the disks

–

Only one disk is involved reading a specific block

• Read and write speed of a single block not increased

•

• Read and write speed of multiple accesses increase

–

Good for large number of parallel accesses

(42)

• Error Correction Codes:

Increase reliability

with computed redundancy

• Hamming Codes

(~1940)

–

Can

detect

and

repair

1 bit errors within

a set of n

data bits

by computing k

parity bits

• n

= 2

k

_-

_k

_{– 1}

• n=1, k=2;

n=4, k=3;

n = 11, k=4;

n = 26, k=5; …

–

Especially used for in-memory and tape error

correction

• Media cannot detect errors autonomously

• Not really used for hard drives anymore

42

(43)

• Interleaved Parity

(Reed-Solomon Algorithm on

GD(2) Galois Field)

–

Can

repair

1-bit errors (when the error is known)

–

Hard Disks can detect read errors themselves, no need

for complete Hamming codes

–

Basic Idea:

• From

n

data pieces D

₁

,…,D

_n

compute a parity data D

_p

by

combining data using logical

XOR

(eXclusive OR)

–

XOR

is associative and commutative

–

Important: A

XOR

B

XOR

B = A

• i.e. D

_p

= D

₁

XOR

D

₂

XOR

…

XOR

D

_n

(44)

• Interleaved Parity. Example:

• A = 0101, B = 1100, C = 1011

• P

=

0010

= A

XOR

B

XOR

C

• C is lost.

–

P

= A

XOR

B

XOR

C

–

C =

P

XOR

A

XOR B

–

C =

A

XOR

B

XOR

C

XOR

A

XOR

B

–

C =

A

XOR

A

XOR

B

XOR

B

XOR

C

–

C = 0

XOR

C

–

C = 1011

44 2.3 RAID Principles – Interleaved Parity

0101

XOR

1100

XOR

1011

P

0010

XOR

0101

XOR

1100

C

1011

(45)

• The 3 RAID principles can be combined in multiple ways

–

Not every combination is useful

• This led to the definition of 7 core RAID

levels

–

RAID 0 – RAID 6

–

The most dominant levels are RAID 0, RAID 1, RAID 1+0, RAID 5

• In following examples, assume

–

A MTBF

of 100,000 hours (11.42 years) per disk

–

A Mean Time to Repair (MTTR) of 6 hours

–

Failure rate is constant and failures between disks are independent

–

MTBF

_raid

is the mean time to data loss within the raid if each failing

disk is replaced within the MTTR

–

D

is the number of drives in the RAID set

–

C=200 GB

is capacity of one disk, C

capacity of whole raid

(46)

• Mean Time to Repair (

MTTR

)

–

MTTR = TimeToNotice + RebuildTime

–

Assume time to notice of 0.5 hours

–

Rebuild time

is the time for completely writing back lost

data

• Assume disk capacity of 200GB

• Write back speed of 10 MB/sec

–

Consisting of reading remaining disks

–

Computing parity / Reconstructing data

• Rebuild time around 5.5 hours

–

During rebuild, a RAID is especially

vulnerable

–

MTTR = 6 hours

46

(47)

• File A (A1-Ax), File B (B1-Bx), File C (C1-Cx)

• Raid 0

–

Block-Level-Striping

only

–

Increased parallel access and transfer speeds, reduced

reliability

–

All disks contain data (0% overhead)

–

Works with any number of disks

–

MTBF

_raid

= MTBF

_disk

/ D

–

4 disks:

• MTBF

_raid

= 2.86 years

• C

_raid

= 800 GB

(0 GB wasted (0%))

–

Common size:

2 disks

(48)

• Raid 1

–

Mirroring

only

–

Increased reliability, increased read transfer speed, low space

efficiency

–

MTBF

_raid

= MTBF

_disk

D

_{/ (D! * MTTR}

D-1

₎

–

4 disks

:

• MTBF

_raid

= 2.2 trillion years

• C

_raid

= 200 GB

(600 GB wasted (75%))

• Age of universe may be around 15 billion years…

–

Common size:

2 disks

• MTBF

_raid

= 95,130 years

• C

_raid

= 200 GB

(200 GB wasted (50%))

48

2.3 RAID Levels

(49)

• RAID 2

–

Not used anymore

in practice

• was used in old mainframes

–

Bit-Level-Striping

–

Use Hamming Codes

• Usually Hamming Code(7,4) – 4 data bits, 3 parity bits

• Reliable 1-Bit error recovery (i.e. one disk may fail)

–

3 redundant disks per 4 data disks (75% overhead)

• Ratio better for larger number of disks

–

MTBF

_raid

= MTBF

_disk

2 _{/ (D(D-1) MTTR)}

–

7 disks (does not really make sense for 4 –

not comparable

to other values)

• MTBF

= 4,530 years

(50)

• RAID 3

–

Interleaved-Parity

–

Byte-Level-Striping

–

Dedicated Parity Disk

• Bottleneck! Every write operation

needs to update the parity disk.

• No parallel writes

–

1 redundant disk per

n

data disks

• Overhead decreases with number of disks

while reliability decreases

• 25% overhead for 4 data disks

–

MTBF

_raid

= MTBF

_disk

2 _{/ (D(D-1) MTTR)}

–

4 disks

• MTBF

_raid

= 15,854 years

• C

_raid

= 600 GB

(200 GB wasted (25%))

50

2.3 RAID Levels

(51)

• RAID 4

–

Block-Level Striping

–

As RAID 3 otherwise

–

4 disks

(common size)

• MTBF

_raid

= 15,854 years

• C

_raid

= 600 GB

(200 GB wasted (25%))

–

5 disks

(also common size)

• MTBF

_raid

= 9,513 years

• C

_raid

= 800 GB

(200 GB wasted (20%))

(52)

• RAID 5

–

Parity is distributed

among the

hard disks

• May allow for parallel block writes

–

As RAID 4 otherwise

–

Bottleneck when writing many files

smaller than a block

• Whole parity block has to be read and

re-written for each minor write

–

Can recover from a single disk failure

–

MTBF

_raid

and C

_raid

as for RAID 3 & 4

52

2.3 RAID Levels

(53)

• RAID 6

–

Two independent parity blocks distributed

among the disks

• May be implemented by parity on orthogonal data or by using Reed-Solomon on

GF(2

8 ₎

–

As RAID 5 otherwise

–

2 redundant disks per

n

data disks

• Can recover from a

double disk failure

• No vulnerability during single failure rebuild

• Very suitable for larger arrays

• Writer overhead due to more complicated parity computation

–

MTBF

_raid

= MTBF

_disk

3 _{/ (D(D-2)(D-1) * MTTR}

2 ₎

–

4 disks

• MTBF

_raid

= 132 million years

• C

_raid

= 400 GB

(400 GB wasted (50%))

–

8 disks

(common)

(54)

• Additionally, there are hybrid levels combing the core levels

–

RAID 0+1, RAID 1+0, RAID 5+0, RAID 5+1, RAID 6+6, …

• Raid 1+0

–

Mirrored sets nested in a striped set

• RAID 0 on sets of RAID 1 sets

–

Very high read and write transfer speeds

, increased reliability, low space efficiency,

limited maximum size

–

Most performant RAID combination

–

D

₁

= Drives per RAID 1, D

₀

=Number of RAID1 sets

–

MTBF

_raid

= MTBF

_disk

D1

_{/ (D}

1 ! * MTTR

D1-1

) / D

0 –

4 disks

: D

₁

= 2, D

₀

= 2

• MTBF

_raid

= 47,565 years

• C

_raid

= 400 GB

(400 GB wasted (50%))

–

6 disks

: D

₁

= 2, D

₀

= 3

• MTBF

_raid

= 31,706 years

• C

_raid

= 600 GB

(600 GB wasted (50%))

54

(55)

• RAIDs controllers

directly

connect storage to the

system bus

–

Storage available to only one system/ server/ application

• Number of disks is limited

–

Consumer grade RAID: 2-4 disks

–

Enterprise grade RAID: 8-24+ disks

• Solutions

–

NAS

(Network Attached Storage): Provide abstracted

file

systems

via network (

software solution

)

–

SAN

(Storage Area Network): Virtualized logical storage

within a specialized network on

block level

(

hardware

(56)

• Before discussing NAS, we need file

systems

• A file systems is a

software

for

abstracting

file operations on a

logical storage device

–

Files are a collection of binary data

• Creating, reading, writing, deleting, finding,

organizing

–

How does a file access translate into

top-level operations on a logical

storage device?

• e.g. which blocks have to be read/written?

• Bridge between

application software

and (abstracted)

hardware

56 2.4 File Systems vs. Raw Devices

Application

Software

File System

Logical

Storage

(57)

• Raw Devices access allows

applications to bypass the OS and

the file system

• Application may directly tune

aspects of physical storage

–

There is still the hard drive

controller…so, its not really direct

• May lead to very efficient

implementations

2.4 File Systems vs. Raw Devices

Application

Software

(58)

• Idea: Provide a remote

file system

using already

available

network

infrastructure

–

NAS

: Network Attached Storage

–

Use specialized

network protocols

(e.g. CIFS, NFS,

FTP, etc)

–

Easiest case: File Server (e.g. Linux+Samba)

• Advantages:

–

Easy

to setup, easy to use,

cheap

infrastructure

–

Allows

sharing

of storage among several systems

–

Abstracts on file system level (easy for most

applications)

• Disadvantages

–

Inefficient

and slow

• large protocol and processing overhead

–

Abstracts on file system level (not suitable for special

purposes like raw devices or storage virtualization)

58 2.4 NAS – Network Attached Storage

Application

Software

File System

Logical

Storage

Network

NAS

Ser

ver

(59)

• SANs offer specialized

high-speed networks

for storage devices

–

Usually uses local FibreChannel

networks

–

Remote location may be connected via Ethernet

or IP-WAN (Internet)

–

Network uses specialized storage protocols

• iFCP (SCSI on FiberChannel)

• iSCSI (SCSI on TCP/IP)

• HyperSCSI (SCSI on raw ethernet)

• SANs provide

raw block level

access to

logical storage

devices

–

Logical disks of any size can be offered by the SAN

–

For a client system using a logical disk, it might

appears like a local disk or RAID

–

Client system has full control over file systems on

2.4 SAN – Storage Area Network

Application

Software

File System

(60)

60 2.4 SAN – Storage Area Network

SAN HBA

SAN/RAID HBA

Peripheral Bus (SCSI, SAS, etc.)

SAN Switch

SAN HBA

SAN Bus (iFCP)

SAN

HBA

SAN

HBA

SAN Switch

NAS Protocol

(CIFS)

Ethernet

Network

WAN-SAN Bus (HyperSCSI)

NAS

Head

(61)

• Advantages:

–

Very efficient

• Highly optimized local network infrastructure

• Optimized protocols with low overhead

–

Very flexible

(any number of systems may use any number of

disks at any location)

–

Helps for disaster protection

• SAN can transparently span to even remote locations

–

May also employ

NAS heads

for NAS-like behavior

• Disadvantages

(62)

• There are different types of storage

–

Usually, there is a storage hierarchy

• Faster, smaller, more expensive storage

• Slower, bigger, less expensive storage

• Hard drives are currently the most popular media

–

Mechanical device

• High sequential transfer rates,

• Bad random access times, low random transfer rates

• Prone to failure

–

DBMS must be optimized for the used storage

devices!

62

2 Physical Storage

(63)

• Access Pathes

–

Physical Data Access

–

Index Structures

–

Physical Tuning
