Defender
Quick Troubleshooting Guide: Authentication Issues
Introduction
This guide is provided for use by Defender administrators to help troubleshoot common Defender authentication issues. It also provides information on how to gain additional diagnostics for use by Quest Support.
Troubleshooting Common Authentication Issues
General Authentication Issues
If users are experiencing problems authenticating via an existing Defender system, there are a number of possible causes, ranging from VPN issues through to individual token failures.
To help identify the cause, the information below is useful to collect and send to Quest Support, providing important contextual and diagnostic information.
For help understanding specific log messages, refer also to Analyzing the Defender Security Server log in the following section.
Troubleshooting Stage 1: Gathering the Required Information
1. What error message is the user receiving? Screenshot or copy and paste the full error message. 2. How many users are affected? The total number of Defender users is also useful to put into context. 3. Were the affected users working previously? If so when?
4. What token type(s) are the affected users using? Go-3, Desktop Token, Quest® Soft Token for BlackBerry etc. 5. What version and platform of Defender is being used? The Defender Security Server version is available
under Security Servers in the Administration Console, eg 5.5.0.907 on Windows 2003 32bit.
6. When did the issue start occurring? It is useful to have a time approximation to help match up with the logs.
7. Have any changes been made recently? For example to Defender, Active Directory, VPN server or network etc?
8. Obtain a copy of the Defender Security Server log. Location: <DEFENDER_HOME>\DSS Active Directory Edition\Logs\
9. Obtain a couple of user IDs of the affected users. These are required to locate the user in the log. Make sure to obtain the user’s user ID rather than the user’s name.
Defender Quick Troubleshooting Guide: Authentication Issues
2
Troubleshooting Stage 2: Analyzing the Defender Security Server log
The default location for the Defender Security Server log is:<DEFENDER_HOME>\DSS Active Directory Edition\Logs\
Follow the steps below:
1. Try to locate an affected user in the DSS log by searching for their user ID. Each request received by Defender will appear in the DSS log. The examples below show a user ID of ‘testuser’.
If the user ID cannot be found in the log then verify that any deployed VPN servers
are functioning correctly. See also Go-x token issues to help rule out hardware token failures.
The log message shown below would be seen for each request received by Defender regardless of whether or not it was successful.
<Time> Radius request: Access-Request for <Userid> from <Client_IP> through NAS:<Access Node Name> Request ID: <N/A> Session ID: <Unique Session ID>
2. Using the Unique Session ID, cycle through the log messages associated with the user’s session. For example a successful session will look like:
Tue 18 Aug 2009 11:57:10 Radius Request from 192.168.10.106:2951 Request ID: 31 Tue 18 Aug 2009 11:57:10 Radius request: Access-Request for testuser from 192.100.10.106:2951 through NAS:WebMail Request ID: 31 Session ID: 8A89040F
Tue 18 Aug 2009 11:57:10 User testuser authenticated with Active Directory Password Session ID:8A89040F
Tue 18 Aug 2009 11:57:10 Radius response: Authentication Acknowledged User-Name: testuser, Request ID: 31 Session ID: 8A89040F
Defender Quick Troubleshooting Guide: Authentication Issues
3
3. Locate the relevant error message in the table below and take the appropriate action:
Log Message Meaning Action
Tue 18 Aug 2009 10:28:38 Reason: Invalid response Session ID 8A74430E
Tue 18 Aug 2009 10:28:38 Radius response: Authentication Rejected User-Name: testuser, Request ID: 4 Session ID: 8A74430E
Incorrect token response
i) Verify the correct response is being entered. ii) Check the response in the administration con- sole.
iii) Check if PIN configured for user. Tue 18 Aug 2009 11:51:30 Reason: Account
locked out due to invalid attempts Session ID 8A87B20B
Tue 18 Aug 2009 11:51:30 Radius response: Authentication Rejected User-Name: testuser, Request ID: 28 Session ID: 8A87B20B
User’s account is locked in Defender
Reset the user’s “Violation Count” via the administration console
Tue 18 Aug 2009 11:09:09 Reason: Invalid password Session ID 8A7D911C
Tue 18 Aug 2009 11:09:09 Radius response: Authentication Rejected User-Name: testuser, Request ID: 12 Session ID: 8A7D911C
Incorrect AD Password
Verify the correct password is being entered
Tue 18 Aug 2009 11:39:07 authentication abandoned user testuser Session ID: 8A83ED05
Session Abandoned (timed out) while waiting for user response
Verify connectivity between the Client and the DSS on the configured RADIUS port
Tue 18 Aug 2009 11:30:16 Reason: User not valid for this route Session ID 8A82B803 Tue 18 Aug 2009 11:30:16 Radius response: Authentication Rejected User-Name: testuser, Request ID: 23 Session ID: 8A82B803
User is not a member of access node or
User does not have a token
or
User is not a Defender user or there is no license available for the user
or
Client IP not permitted by the access node
i) Verify the members of the access node ii) Verify the user has a Defender token assigned iii) Verify that suitable licenses exist
iv) Verify the IP
Tue 18 Aug 2009 10:15:38 Domain Search from CN=testuser,CN=Users,DC=child,DC=democor p,DC=local took 57 seconds
Tue 18 Aug 2009 10:15:38 LDAP failed (-1) finding user testuser
AD search failure - for example if the required child domain is unavailable
Check DSS Log for errors relating to DC or LDAP connection
Tue 18 Aug 2009 11:22:06 LDAP failed (50) writing token data for
CN=PDWIN1348400003,OU=Tokens,OU=Defe nder,DC=democorp,DC=local
Tue 18 Aug 2009 11:22:06 Failed to write token data to LDAP Session ID 8A80CE0C
Insufficient AD permissions to update the user’s token information for the Defender service account
Verify that the Defender service account has suitable permissions or is a member of the domain administrators group
Defender Quick Troubleshooting Guide: Authentication Issues
4
Troubleshooting Stage 3: Gathering Further Diagnostics
If the above troubleshooting steps have not resolved the issue, further diagnostics may be required, including further environmental details and tracing.
Contact Quest Support for advice on how to enable tracing. They will need to know which version of console and/or DSS is being used:
• Administration Console (MMC snap-in) – The About dialog contains the version information for the console. This can be found on the Defender menu option which is available when the Defender OU is selected within AD Users & Computers.
• Defender Security Server – The version number for the DSS can be found on the DSS
Properties dialog within AD Users & Computers or from within the DSS logs.
In general, trace files are located in:
For 2003/XP
C:\Documents and Settings\All Users\Application Data\Quest Software\Diagnostics
or
C:\Document and Settings\All Users\Application Data\PassGo Technologies\Diagnostics
For 2008/Vista
Defender Quick Troubleshooting Guide: Authentication Issues
5
Go-x Token Issues
This section is designed to facilitate the troubleshooting process for Defender Go-x, eg Go-3, token issues in particular.
It is designed for use by Defender Helpdesk users, who may receive an initial report from a user that their token is ‘not working’.
Troubleshooting Stage 1: Determining the Type of Failure
1. Confirm the token type. The instructions provided in this guide are only for troubleshooting Go-x tokens.
Figure 1: Defender Go-3 Token
Figure 2: Defender Go-6 Token
If a user reports a software token as ‘not working’, please refer to the previous section and/or
Quest Knowledgebase solution SOL45446. 2. Determine if this is a token hardware failure:
If the answer is Yes to any of the following questions, refer to the Token returns procedure described in Quest Knowledgebase solution SOL45444.
Does the token only display ‘000000’?
Is the token display blank when the token button is pressed? Is the token display intermittent?
Does the token display the same number every time? Note that the number is set to change every 36 seconds.
Does the token display batt x, where x indicates the number of months the battery has left? If the answer is No to the above questions, go to the next step.
Defender Quick Troubleshooting Guide: Authentication Issues
6
3. Does the token display dp G0-3 before a number is displayed?
If so, this means the token is set to display it’s type, ie Digipass Go-3, before the number – this is not an error. Ask the user to log on with the number displayed – if this is not successful go to the next step.
If a six digit number is displayed immediately, go to the next step.
4. If a token number is displayed as expected, but logon fails, further investigation within Defender and Active Directory may be required.
Gather and record the following information:
Has the user ever successfully logged on with this token? If so, when was the last time the user successfully logged on with the token?
What is the user ID and the token serial number? What is the error the user sees when they try to log on?
Defender Quick Troubleshooting Guide: Authentication Issues
7
Troubleshooting Stage 2: Verifying the Defender Configuration
If a hardware issue has been ruled out by the previous steps, and user logon is failing, refer to the steps below.
Typically the user will receive the message ‘invalid synchronous response’ – this may have a number of causes. Follow the process of elimination below to help diagnose the error.
1. Check the Token Violation count and reset if necessary - username Properties page,
Defender tab. Re-test user authentication. Ask the user to retry their token.
If the issue is not resolved, go to the next step.
2. Check for the use of a PIN on the token. It may be that the user has forgotten to use the PIN or is using an invalid PIN - reset PIN if necessary. Ask the user to retry their token.
If the issue is not resolved, go to the next step.
3. Reset the token - username Properties page in AD Users & Computers, Defender tab, Select
Token, click the Helpdesk button and select Reset. Ask the user to retry their token.
If the issue is not resolved, go to the next step.
4. If the user receives an ‘Access Denied’ message, check whether their account is listed on the
Members tab of the access node that they are using, or that their account is a member of a group
listed for the access node. The DSS log will show the error message ‘User not valid for this route’ if the user is not defined.
If the issue is not resolved by adding the user to this access node, go to the next step. 5. Unassign and re-assign the token to the user. Re-test user authentication.
If the user is still unable to authenticate using their token, refer to the next section for guidance on raising this issue with Quest Support.
Defender Quick Troubleshooting Guide: Authentication Issues
8
Troubleshooting Stage 3: Gathering Further Diagnostics
The following information may be useful to help diagnosis of the issue when raising with Quest Support. It is use- ful to also indicate any relevant observations from the results of the tests on the previous pages. Diagnostics:
• Send the DSS logs corresponding to the time of the authentication request from
<DEFENDER_HOME>\DSS Active Directory Edition\Logs\.
User/Token Information:
• Confirmation of token type, ie Go-3 and serial number.
• Confirmation of token color, ie blue Quest-branded or black PassGo-branded. • What is the User ID of the user affected?
• Which OU stores the user’s account in AD?
• Does the user have more than one token assigned to their account? Circumstantial Information:
• Has the user ever successfully logged on with this token?
• If so, when was the last time the user successfully logged on with the token? • What is the error the user sees when they try to log on?
• Do other/all users authenticating via the same route, eg VPN, experience the same issue? • Can a helpdesk response be assigned for this user successfully?
Token Verification:
Determine whether the token tests successfully or not via the Defender Administration Console by running the following test:
Test the token response in AD Users & Computers - username Properties page in AD Users &
Computers, Defender tab, Select Token, click the Test button and enter the token response from the token.
