Data Structures

Algorithm Performance and Big O

Analysis

What’s an Algorithm?

• … a clearly specified set of instructions to be followed to solve a problem.

• In essence: A computer program.

• In detail: Defined mathematically in a

course on Theory of Computation (Turing).

What’s Big “O” do?

• Measures the growth rate of an algorithm as the size of its input grows.

• Huh? “O” is a math function that helps estimate how much longer it takes to run n inputs versus n+1 inputs (or n+2, 2n, 3n…) .

• Doesn’t care what language you use! Only cares

about the underlying algorithm.

What Doesn’t “O” do?

• Doesn’t tell you that algorithm A is faster than algorithm B for a particular input.

– Why not? Only tells you if one grows faster than another in a general sense for all inputs.

– Usually concerned with very large data inputs.

Called asymptotic algorithm analysis.

Example: Doesn’t Care About Particular Input

public void algorithm1(Object xInput) {

…16 million lines of code…

}

public void algorithm2(Object xInput) {

if (xInput.size() == 2074) {

return;

} else {

…16 million different lines…

} }

Which one is faster? Always?

We only care about the “average” behavior of the 16 million lines.

How Calculate Run Time?

1. Each basic operation in the code counts for 1 time unit.

• A basic operation executes in the same time no matter what values it is supplied.

• Examples:

• Adding two integers is a basic operation.

• Reading a[1] is a basic operation (independent of array size).

• Summing the values in an array is NOT a basic operation (why?).

2. Ignore actual time units (seconds, days, etc.).

• Could be 1 ns for a fast computer or 1 day for a really slow computer. But for large inputs, won’t matter.

3. Ignore time for method calls, returns, and declarations.

• Doesn’t matter in the long run.

Run Time Example 1

Calculating

public int sum(int num) {

int partialSum = 0;

for(int i=1; i<= num; i++) {

partialSum += i * i * i;

}

return partialSum;

}



i

i

1

3

How long to run this code?

Run Time Example 1 (cont.)

Calculating

public int sum(int num) {

int partialSum = 0;

for(int i=1; i<= num; i++) {

partialSum += i * i * i;

}

return partialSum;

}



i

i

1 3

no cost

costs 1 (to init/store in memory)

costs N+1 (once for each test of <=)

(and +1 because of last time through, when it fails)

costs 2 N (once for each + and =…

recall i++ is just i = i + 1) total cost of 4N

(costs 4 per execution… 1 addition, 2 multiplications, 1 assignment)

no cost

Final tally: 1+1+(N+1)+2N+4N = 7N+3

How long to run this code?

costs 1 (to init/store in memory)

Run Time Example 2

public int sum(int num) {

int partialSum = 0;

for(int i=1; i<= num; i++) {

for(int j=1; j<= num; j++) {

partialSum += i * j;

} }

return partialSum;

}

no cost

no cost costs 1 costs N+1 costs 2N costs N*1

costs N*(N+1) costs N*2N costs N*N*3

Final tally: 1+1+(N+1)+2N+N*1+N*(N+1) +N*2N+N*N*3 = 6N²+5N+3 costs 1

But This is Overkill!

public int sum(int num) {

int partialSum = 0;

for(int i=1; i<= num; i++) {

for(int j=1; j<= num; j++) {

partialSum += i * j;

} }

return partialSum;

}

Really only one operation, and it happens N

times

So we say order of N ² ,

or O(N ² )

Likewise, More Overkill

Calculating

public int sum(int num) {

int partialSum = 0;

for(int i=1; i<= num; i++) {

partialSum += i * i * i;

}

return partialSum;

}



i

i

1 3

Really only one operation, and it happens N times

So we say order of N,

or O(N)

Another “Order Of” Example

public void cool(int n) {

for(int i=2; i<=n; i++) {

int j = (1 + i * i % 3 % i) / (i + 2);

} }

Also, run time, T(N) = 10N - 8.

Can you show me?

The heart of the code is this line.

And it happens N times.

So order of N.

Or say O(N).

Ah, Back to the Big-O (Definition)

• Call T(N) the run time.

• Definition: T(N) = O(f(N)) if there are positive constants c and n

such that

T(N)  c f(N) when N > n

.

• What’s it mean? The run time is always less than f(N) for big enough N. (Only the highest order term matters!) (And constants don’t matter.)

Note: f(N) should be the smallest such function such that c and n₀exist.

Example Using Big-O Definition

• In last example, T(N) = 10N - 8

• So, let’s guess T(N) = 10N - 8 = O(N

)

• To show that, must show 10N+1  c N³ for some big enough N.

• Let c=1.

• Then 10N - 8  c N³ is true for all N > 10.

• In fact, true for all N > 4.

» i.e., in definition, let n₀ = 4

• So by definition, 10N - 8 = O(N³).

But that’s not as good as we can do! Let’s try O(N).

Another Example Using Definition

• Let’s guess T(N) = 10N-8 = O(N)

• To show that, must show 10N-8  c N for some big enough N.

• Let c=10.

• Then 10N-8  c N is true for all N > 0.

» i.e., in definition, let n₀ = 1

• So by definition, 10N-8 = O(N).

No matter how hard you try, that’s the smallest

exponent on N that will work. i.e., O(N) is the best

we can do. And O(N) matches our intuition from

the example code!

Example: O Constants

• If T(N) = 23N ² – 562 Then T(N) = O(N ² )

• Which means: We guarantee that T(N) grows at a rate no faster than N ² .

• We say c N ² is an upper bound on T(N).

• for c >23

Wait, you say…

• Ok, T(N) = 23N ² – 562 = O(N ² ).

But 23N ² grows faster than N ² .

• What’s up with that? Shouldn’t it be O(23N ² )?

• NO! We are concerned with the rate of

growth as N increases.

Wait, you say… (Part 2)

• Consider 23N

and N

.

• If N doubles in size, how much longer does it take to run?

23 (2N)² = 4 * (23 N²) – and –

(2N)² = 4 * (N²)

• In both cases, takes 4 times as long. The rate of growth is just N

.

• The constant didn’t matter!!!

Another Example

• Consider T(N) = 5 N

versus N

• If we triple the number of inputs, how much longer does it take to run?

5 (3N)³ = 27 * (5 N³) – and –

(3N)³ = 27 * (N³)

• In both cases, takes 27 times as long. The rate of growth is just N

.

• The constant didn’t matter!!!

Yet Another Example

• If T(N) = 7N ³ – N + 56 Then T(N) = O(N ³ )

• Which means: We guarantee that T(N)

grows at a rate no faster than N ³ .

Wait a cotton, pickin’…

• T(N) = 7N ³ – N + 56= O(N ³ )

• You mean to say the N doesn’t matter?

Yup!

• We are concerned with the asymptotic

behavior for big N.

Wait a cotton, pickin’…(Part 2)

• As N gets huge, N

dwarfs N.

• N

= 1000

= 1,000,000,000 which is a lot bigger than N = 1000.

• For even bigger values, it’s quickly 1 part in a billion billion.

• Only the biggest exponent matters.

(Called asymptotic analysis.)

Wait a cotton, pickin’…(Part 3)

• Consider T(N) = 7N

– N + 56 versus N

• If we take 1000 times the number of inputs, how much longer does it take to run?

7 (1000N)³ – 1000 N + 56= 1,000,000,000 * (7 N³) – 1000 N + 56 – and –

(1000N)³ = 1,000,000,000 * (N³)

• The first term is MUCH bigger than the other terms.

• For any value of N, like 10, the smaller terms subtract an insignificant amount from the total.

• Smaller terms don’t matter

Review: The Difference Between T(N) and O(N)

• T(N)

• is total run time.

• O(N)

• is the approximation to the run time where we ignore constants and lower order terms. We call it the “growth rate.” Also called “asymptotic approximation.”

• Example:

if T(N) = 3 N² + N + 1 then T(N) = O(N²)

if T(N) = 3 N log(N) + 2 then T(N) = O(N log(N))

Review: The Difference Between T(N) and O(N)

• What do we mean by the equal sign?

• T(N) = O(N

)

– Says the growth rate for T(N) is N².

• T(N) = O(N log(N))

– Says T(N) has a growth rate of N log(N).

Big-O Is Worst Case

• Remember, Big-O says nothing about specific inputs, or specific input sizes.

• Suppose I give Bubble Sort the list 1, 2, 3, 4, 5

» Stops right away. Fast!

• Suppose I give Bubble Sort the list 5, 4, 3, 2, 1

» Worst case scenario! Slow.

• So need to calculate the max number of times code goes through a loop.

• e.g., if use a “while” loop, then the number of times code iterates should be calculated for the worst case.

» By the way, a “while” loop is just like a “for” loop when calculating run time and growth rates.

Predicting How Long To Run: A Cool Application of Big-O

• Can predict how long it will take to run a program with a very large data set.

• Do a test with a small practice data set.

• Then use big-O to predict how long it will take with a real (large) data set.

• Cool!

• Suppose we are using a program that is O(N

).

• Our test shows that it takes 1 minute to run 100 inputs. How long will it take to run 1000 inputs?

• Set it up this way:

   

min 1000

min 1

100

x takes

inputs takes

inputs 

That’s the growth rate!

100²inputs per minute.

Predicting How Much Data Will Run: A Cool Application of Big-O

• Can predict how much data can be processed in a fixed amount of time.

• Do a test with a small data set.

• Then predict with big-O.

• Suppose we are using a program that is O(N

).

• Our test shows that it takes 1 minute to run 100 inputs. How many inputs will run in 60 minutes?

• Set it up this way:

   

min 60

min 1

100

takes

inputs N

takes

inputs 

General O Rules: Rule 1

• Rule 1

if T

(N) = O(f(N)) and T

(N) = O(g(N)) then (a) T

(N) + T

(N) = max( O(f(N)), O(g(N)) ).

(b) T

(N) * T

(N) = O( f(N)*g(N) ).

These are big-O rules, not run-time rules.

They apply equally well to any other math class!

Example

for(int i=1; i<= nNum; i++) {

nPartialSum += i * i * i;

}

for(int i=1; i<= nNum; i++) {

for(int j=1; j<= nNum; j++) {

nPartialSum += i * j;

} }

T

(N) = O(N)

T

(N) = O(N

)

So the total run time is

T₁(N) + T₂(N) = max(O(N), O(N²)) = O(N²)

General O Rules: Rule 2

• Rule 2

(logN)^k = O(N) for any constant k.

What…?

Remember: T(N) = O(f(N)) when T(N)

 cf(N)

So, we’re just saying that (logN)^k grows more slowly than N.

In other words:

logarithms grow VERY slowly.

Comparison of Growth Rates

0 20 40 60 80 100 120 140

1 3 5 7 9 11 13 15 17

LogN (LogN)^2 N

NLogN N^2 N^3

good

bad

N (number of inputs)

run ti me T( N)

Rules For Programs

• Previous rules were general math rules.

• The following rules apply to computer programs.

• will still need to use the math rules!

Rules For Calculating Growth Rate: Rule 0

• Rule 0: declarations, method calls, returns…

Zero cost.

• Example

int myVariable;

return 0;

No cost. O(1). Constant growth rate. In other words, if we double the # of inputs, takes the same amount of time to run. We describe growth rates in terms of N.

So, T(N) = 0 = 0 * N⁰ = O(N⁰) = O(1).

Rules For Calculating Growth Rate: Rule 1

• Rule 1: “for loops”

• The growth rate of a “for loop” is at most the

growth rate of the statements inside the “for loop”

times the number of iterations.

• Example: O(N)

for(i=0; i<n; i++) {

i++;

}

One addition and one assignment operation Happens N/2 times!

(i++ is happening two places – sneaky)

Rules For Calculating Growth Rate: Rule 2

• Rule 2: Nested Loops

• Analyze inside out. Growth rate of a statement inside nested loops is the growth rate of the statement multiplied by the product of the sizes of the loops.

• Example:

for(int i=1; i<= num1; i++) {

for(int j=1; j<= num2; j++) {

a[i] = i * a[j];

} }

num2 num1

So total runtime = 4 * num2 * num1 = O(N

)

4

Rules For Calculating Growth Rate: Rule 3

• Rule 3: Consecutive statements

These just add (which means the maximum one counts).

• Example:

for(int i=1; i<3; i++) {

a[i] = i;

}

for(int i=1; i<n; i++) {

a[i] = i;

}

2

n-1

T(n) = 2+(n-1) = O(n)

(just a big-O math rule!)

Rules For Calculating Growth Rate: Rule 4

• Rule 4: if/else

Growth rate is never more than the longest of the

“if” or the “else” statements.

• Example

if(happyDog) {

print(“bow-wow”);

}

else if(happyCat) {

for(int i=1; i<35; i++) print(“meow”);

}

34 1

T(N) = 34 = 34 N⁰ = O(N⁰) = O(1)

Assume print runs in 1 time unit.

Example With Recursion

public long factorial(long n) {

if(n<=1)

return 1;

else

return n*factorial(n-1);

}

0

1 for multiplication, plus 1 for subtraction, plus the cost of the evaluation of

factorial(n-1)

T(n) = 2 + Cost(factorial(n-1)) - or -

T(n) = 2 + T(n-1)

(roughly… we are ignoring the n<=1 in the run time)

Example With Recursion 2

O(n) 1) - (n 2

0 2

2 2

2 2

3)))) -

rial(n Cost(facto

2 ( (2 2

2))) -

n factorial(

( Cost (2

2

1)) - rial(n Cost(facto

2 T(n)











































Last case of factorial(1) doesn’t cost anything.

Just returns.

Example With Recursion 3

O(n) 1) - (n 2

0 2

2 2

2 2

3))) -

T(n 2

( (2

2

2)) -

n ( T (2

2

1) - T(n 2

T(n)











































Same thing, but different notation.

Example With Recursion 4

(in fact, was just a for loop in disguise)

public long factorial(long n) {

if(n<=1)

return 1;

else

return n*factorial(n-1);

}

public long factorial(long n) {

long factorial = 1;

for(int i=1; i<=n; i++) {

factorial = i*factorial;

}

return factorial;

}

O(N) T(N) = 1+N+0 = O(N)

1

N

0

Another Recursion Example

(Fibonacci numbers)

public long fib(int n) {

if(n<=1)

return 1;

else

return fib(n-1) + fib(n-2);

}

0

3 for “–”, “+” and “–”, and also the cost of fib(n-1)and the cost of fib(n-2)

T(n) = 3 + Cost(fib(n-1)) + Cost(fib(n-2)) - or -

T(n) = 3 + T(n-1) + T(n-2)

(Job interviewer once asked me if this was a good way to program Fibonacci #’s!)

Another Recursion Example 2

T(n) = 3 + T(n-1) + T(n-2)

3 + T(n-2) + T(n-3) 3 + T(n-3) + T(n-4)

3 + T(n-3) + T(n-4) etc. etc. etc.

The cost keeps doubling in size!!!

Exponential: O(2

)

bad, bad, bad, bad, bad, bad…

Tree Doubling

• Called a binary tree.

• Keeps doubling.

• Exponential (2ⁿ) growth.

• Bad growth rate!

• But we’ll do some problems that traverse the tree in the other direction.

• Keeps halving.

• Opposite of exponential.

– And what’s the inverse (“opposite”) of exponential? Logs!

• Logarithmic log(n) growth.

• Great growth rate!

• Stay tuned for logarithmic growth…

Recursion NOT Always a “For”

Loop in Disguise

• The Fibonacci recursion is O(2 ^N ).

• Most for loops are O(N). But not all…

Stay tuned…

good!

bad!
