Java course - IAG0040. Unit testing & Agile Software Development

(1)

Unit testing &

Agile Software Development

Java course - IAG0040

(2)

Unit tests

●

How to be confident that your code works?

●

Why wait for somebody else to test your code?

●

How to provide up-to-date examples on using your API?

●

How to help yourself see your design better and therefore

improve it?

The answer: write Unit Tests!!!

●

Unit tests are executable test cases for your modules (units),

expressed in code

●

Unit tests are executed automatically to ensure that your code

(3)

Benefits of unit tests

●

Unit testing isolates each module and shows that it is correct.

It provides a strict written contract that the code must satisfy

●

Facilitates change

– unit tests provide regression testing,

make refactoring safer

●

Simplifies integration

– integration testing is easier, if

parts are already proven to work correctly

●

Documentation

– unit tests show how to use the API

●

Separation of interface from implementation

– unit tests

(4)

A simple example

●

public class Concatenator {

// this is a method under test

public String concat(String a, String b) {

return a + b;

}

// this is a simple test case

public static void main(String[] args) {

Concatenator c = new Concatenator();

assert “abc123”.equals(

c.concat(“abc”, “123”))

: “concat() failed!”;

}

(5)

JUnit

●

JUnit is the first and most popular unit and regression

testing framework for Java

●

Is a 3rd-party jar file

–

Obtainable from

http://www.junit.org/

–

Included and interfaced in IDEA, Eclipse, etc

●

JUnit 3

–

older but still very popular

●

JUnit 4

(6)

JUnit (cont)

● JUnit 3

– must extend the junit.framework.TestCase class – TestCase provides a lot of assertXXX() methods – setUp() method is run before each test

– tearDown() method is run after each test

● JUnit 4

– no extending is needed

– annotate test methods with @Test (from org.junit) – assertXXX() methods may be statically imported

import static org.junit.Assert.*;

(7)

JUnit 3 example

●

public class Concatenator {

// this is a method under test

public String concat(String a, String b) {

return a + b;

}

public class ConcatenatorTest extends TestCase{

// this is a simple test case

public void testConcat() {

Concatenator c = new Concatenator();

assertEquals(“concat() failed!”, “abc123”,

c.concat(“abc”, “123”));

}

(8)

JUnit 4 example

●

public class Concatenator {

// this is a method under test

public String concat(String a, String b) {

return a + b;

}

public class ConcatenatorTest {

// this is a simple test case

@Test

public void testConcat() {

Concatenator c = new Concatenator();

assertEquals(“concat() failed!”, “abc123”,

c.concat(“abc”, “123”));

}

(9)

JUnit (cont)

●

Naming convention

– Create at least one test class for each class, test classes usually

have the Test suffix (e.g. DogTest)

– Generally, create one test method per method under test

(e.g. @Test public void dogHasAName())

– Put tests into the the test directory (same package as the class

under test, then you can access package local methods from tests)

●

JUnit runs all tests,

–

defined in public void testXXX methods in classes extending

TestCase, or

(10)

Mock objects in tests

● Unit tests must isolate the unit under test (avoid dependencies) ● If an object under test uses other objects, they must be mocked ● A mock object has the same interface as the real object, but

different implementation (in many cases, it does nothing)

● Real objects being mocked should have their own separate unit tests ● Possible implementations:

– Overriding: class MockDog extends Dog { ... } – Anonymous classes: new Dog() { ... }

– Dynamic proxies: Proxy.newProxyInstance( ... )

(see javadoc of java.lang.reflect.Proxy)

(11)

Unit test tasks

●

Write unit tests for these your classes using JUnit 4

(see previous lectures' slides if you don't have them)

:

–

Fibonacci, Factorial

–

DuplicateRemoverImpl

–

WordFrequencyCalculatorImpl

–

ShapeAggregatorImpl

●

Use the above mentioned naming/coding convention

●

You no longer need main() methods in these classes

which demonstrate that the code works – these were

actually a sort of unit tests, too

(12)

Agile Software Development

●

Is a relatively new and more efficient software

development methodology (process)

●

Minimizes risks by splitting projects into small iterations

that look like separate projects

– Each iteration includes all tasks to release an increment in

functionality

● planning

● requirements analysis

● design & coding & testing ● documentation

(13)

Agile Manifesto

●

http://www.agilemanifesto.org/

● We are uncovering better ways of developing software by doing it

and helping others do it. Through this work we have come to value:

–

Individuals and interactions over processes and tools

–

Working software over comprehensive documentation

–

Customer collaboration over contract negotiation

–

Responding to change over following a plan

● That is, while there is value in the items on the right, we value the

(14)

So what is Agile?

● Way of creating software in lighter, faster, and people-centric way ● Adaptable, not predictable

● Working software is the primary measure of success and is delivered

frequently

● Agile software development requires strict discipline

● Project team sits together (face-to-face communication)

– programmers and customers at minimum

– testers, designers, technical writers, managers

(15)

Agile methodologies

●

There are many (some existed before the Agile

Manifesto)

–

Scrum, Crystal Clear, Lean Software Development,

XP (Extreme Programming), etc

●

Bad (but often used) alternatives:

–

Cowboy coding – no well-defined process

–

Waterfall – most predictive, steps through

requirements capture, analysis, design, coding,

testing in a strict sequence

(16)

Agile/XP project cycle

●

Kick-off meeting

●

Iterations:

–

Iteration planning meeting (a few hours)

–

Daily stand-up meetings (max 15 min)

–

Designing, coding, testing, communicating

●

Fixed deadline ends (or customer decides to

(17)

User stories and iterations

● User stories are written on small paper chunks

● They are are added/removed/prioritized during iteration planning meetings

● Each user story is estimated in abstract units ● Team's velocity is calculated

after each iteration

● Next iteration plan must be the same number of units completed during the

previous iteration

● After a few iterations, velocity stabilizes

(18)

TDD (Test Driven Development)

● TDD is one of the main practices of XP (Extreme Programming) ● TDD = TFD + refactoring

● TFD (Test First Development) means

– Write tests before the real (functional) code – Write real code only to satisfy failing tests – Eliminate duplication

● Refactoring means redesigning the code without changing or

braking existing functionality

– always ensure that you have the simplest design possible for the

(19)

TDD benefits

● Code is written in small steps

● You design your API before writing code, which results in better and

loosely coupled object model

● You get 100% unit test coverage

● After each test-code iteration you get a working code, you can

virtually stop anytime

● You don't waste time designing beforehand; initial designs cannot

predict everything

● You can change anything anytime (because requirements always

change)

(20)

Pair Programming

●

Pair Programming means there are two programmers sitting

and working together

●

Pairs help stay on track with TDD

●

Pairing helps to learn from each other

●

Instant (extreme) code review

●

Two people produce better ideas than any of them could alone

●

“Ping-pong” allows to turn development into a game

(21)

Continuous integration

● Regular automated builds of the software (e.g. after each commit)

– the whole program is recompiled – automated (unit) tests are run – documentation is generated

– software is packaged and therefore ready to run

● Provides short feedback to developers

● Helps to find integration problems and failed tests early

● The latest builds are always runnable and testable by e.g. customers ● Hudson is one of the tools used for this purpose

(22)

Hands-on: TDD Bowling

●

Rules/Requirements of 10-pin bowling:

–

A game of 10 frames (2 shots per frame)

–

Total score = sum of scores of all frames

–

Spare – all 10 pins are hit with two shots (frame)

●

Frame score += next shot (bonus)

–

Strike – all 10 pins are hit with one shot

●

Frame score += two next shots (bonus)

–

If last frame hits all pins, extra shot is awarded

–
