Acute Ischaemic Stroke-
Multi modal Imaging and
Stroke outcomes
Dr Bharathkumar Cheripelli
MBBS, MRCP, CCT (Neurology)
A thesis which fulfils the requirements of the University of Glasgow for the degree of Doctorate of Medicine
Institute of Neuroscience and Psychology University of Glasgow
Abstract
Introduction
Acute stroke Imaging plays a crucial role in understanding the cerebral tissue states and multimodal imaging with perfusion, collaterals and vessel occlusion provides more information on tissue dynamics in individual patient which can be useful for tailored treatments and prognosis. Perfusion parameters and their validation are important in achieving clinical practicality. A novel tissue
parameter, Capillary transit time heterogeneity has been suggested to identify micro vascular flow patterns. The clinical utility of this is not yet established. Stroke outcome is dependant not only on the imaging parameters but also on patient demographics, co morbidities and probably on complex socio-economic and other unidentified patient factors.
Methods
Using a database of single centre multi modal imaging I derived perfusion metrics in commercial software (MIstar). I conducted a few different analyses on:
penumbra relationship with time, collaterals; haemorrhage, oedema relationship with recanalisation; Safety in Stroke Thrombolysis (SITS) registry Stroke outcomes; Deriving a new perfusion parameter called ‘Capillary transit time heterogeneity (CTTH)’ and comparing the values in different tissue compartments.
Results
In a cross-sectional sample imaged within 6h, neither the proportions of
penumbral tissue nor “target mismatch” varied by time from onset. A trend for reducing penumbra proportion only among those with poor collaterals may have pathophysiological and therapeutic importance.
Among patients treated with IV thrombolysis, 24h recanalisation was not independently associated with significant early (24h) vasogenic oedema or significant haemorrhage, although incidence of HI/HI2 ICH was higher. Large ischaemic core was associated with both significant brain oedema and poor
outcome. There was no interaction of recanalisation and large core lesions for any imaging outcomes. Early major clinical improvement as a marker of probable early reperfusion was associated with lower incidence of both significant haemorrhage and oedema.
In SITS registry study, poorer 90 day outcomes after IV thrombolysis occurred frequently at a hospital (Southern General Hospital) that accepted secondary transfer patients compared to a hospital in the same city (Western Infirmary Glasgow) that did not routinely take such patients.
Capillary transit time heterogeneity (CTTH) voxel wise maps were derived successfully using “vascular model” in Brain Lab, Arhus, Denmark. The CTTH values are closely related with MTT. There is no significant difference of CTTH between Core, penumbra.
Conclusion
Multimodal imaging can provide us with valuable information on understanding ischemic brain tissue, predict patient outcomes in stroke. Patient imaging and clinical outcomes depend on recanalisation, and patient factors. A novel perfusion parameter, CTTH has been successfully derived and its utility and validity is yet to be evaluated.
Table of Contents
Chapter 0
Table of Contents
Abstract ... 2
Table of Contents ... 4
List of Tables ... 7
Table of Figures ... 8
Publications and Presentations ... 10
Acknowledgement ... 13
Contribution to the thesis work and Stroke Research activity during fellowship .. 14
Author’s declaration ... 15
Definitions/Abbreviations ... 16
Chapter 1 Introduction ... 19
1.1 Acute Ischaemic stroke (overview) ... 19
1.2 Pathophysiology ... 21
1.2.1 Cellular pathology of ischaemic stroke ... 22
1.2.2 Cerebral haemodynamics in response to ischaemia ... 22
1.3 Types of Cerebral oedema ... 24
1.4 Haemorrhagic Transformation (HT) in Ischaemic stroke ... 25
1.5 Evidence from animal studies ... 26
1.5.1 Multimodal imaging of tissue outcomes in focal ischaemia animal models 27 1.5.2 Evidence for irreversible (Core) and reversible (Penumbra) ischaemia and evolution over time ... 28
1.5.3 Tissue Thresholds... 30
1.6 Human Positron Emission Tomography (PET) studies ... 34
1.7 Acute stroke imaging in Humans ... 35
1.7.1 Non-contrast CT (NCCT) ... 35
1.8 Perfusion Imaging ... 36
1.8.1 CT perfusion (CTP) ... 37
1.8.2 Post acquisition CT perfusion processing ... 39
1.9 Role of capillaries in haemodynamic regulation ... 49
1.10 Magnetic Resonance Imaging (MRI) ... 53
1.10.1 MRI for penumbra identification ... 54
1.10.2 NCCT vs. MRI... 56
1.11 Non-core-non-penumbral Infarction: ... 57
1.12 Intravenous thrombolysis (IVT): ... 57
1.14 Intra arterial therapy (IAT) ... 61
1.15 Cerebral angiogram... 62
1.16 Cerebral Collateral circulation ... 63
Chapter 2 Study Population and Methods ... 65
2.1 Study population ... 65
2.2 Imaging... 67
2.2.1 Imaging acquisition ... 67
2.2.2 Imaging processing and analysis ... 68
2.3 Collateral grading: ... 76
2.4 Recanalisation ... 78
2.5 Haemorrhage classification ... 78
2.6 Oedema classification ... 79
2.7 Modified Rankin Scale ... 80
Chapter 3 Methods for Capillary Transit Time Heterogeneity (CTTH) work in Chapters 6, 7 ... 82
3.1 Introduction ... 82
3.2 Detailed steps ... 83
3.3 Study population of CTTH work ... 99
Chapter 4 Does the Penumbra Shrink over Time? Penumbra volume and collaterals in the first 6 hours after acute ischemic stroke ... 101
4.1 Introduction ... 101
4.2 Methods ... 102
4.2.1 Study Population ... 102
4.2.2 Imaging acquisition ... 103
4.2.3 Imaging processing and analysis ... 103
4.2.4 Penumbra definition ... 103 4.2.5 Collateral scores ... 104 4.2.6 Target mismatch ... 104 4.2.7 Statistical analysis ... 104 4.3 Results ... 104 4.4 Discussion ... 111 4.5 Conclusions ... 114
Chapter 5 Interaction of Recanalisation, Intracerebral Haemorrhage and Cerebral Oedema after Intravenous thrombolysis ... 115
5.1 Introduction ... 115
5.2 Methods ... 116
5.2.1 Study population ... 116
5.2.2 Image acquisition ... 117
5.2.3 Image analysis ... 117
5.2.5 Collateral grading ... 118
5.2.6 Haemorrhage, oedema classification ... 118
5.3 Results ... 119
5.4 Discussion ... 132
5.5 Conclusions ... 135
Chapter 6 Explore Capillary transit time heterogeneity (CTTH) within different components of the tissue – core, penumbra, ‘non-core-non-penumbra’ infarct, normal brain ... 136 6.1 Introduction ... 136 6.2 Methods ... 138 6.3 Results ... 139 6.4 Discussion ... 148 6.5 Conclusions ... 150
Chapter 7 What are the clinical characteristics of subjects with ‘non-core-non-penumbral’ infarction? ... 151 7.1 Introduction ... 151 7.2 Methods ... 152 7.3 Results ... 152 7.4 Discussion ... 155 7.5 Conclusions ... 157
Chapter 8 Is secondary transfer for stroke thrombolysis optimal? - Comparing outcomes between two hospitals with different model of care and with the rest of UK 158 8.1 Introduction ... 158 8.2 Methods ... 159 8.3 Results: ... 162 8.3.1 Regression analysis ... 169 8.3.2 Survival analysis ... 173
8.3.3 Propensity score matching of SGH with UK subjects ... 176
8.4 Discussion ... 180
8.5 Conclusions ... 183
Chapter 9 : Summary of chapters: Exploration of Perfusion Imaging; Applicability of Capillary transit time heterogeneity (CTTH) in perfusion Imaging; Stroke outcomes in different Care settings ... 184
9.1 Introduction ... 184
9.2 Imaging factors ... 184
9.3 Stroke care model and/ or Organisational factors: ... 186
