Solar combiner boxes for

solar photovoltaic installations

Solar Combiner Boxes for

Solar Photovoltaic Installations

Connecting the

Power of the Sun

(2)

Solar energy

is heating up

Interest in renewable energy sources has never been

greater, and the fastest growing of these new green

technologies is the use of photovoltaic (PV) panels

(modules) to generate power from the sun. PV modules

directly convert the sun’s light into electricity, providing

power during daylight hours. PV systems are being

installed on virtually every type of building, resulting in

a growing need for products to meet the requirements

of these systems.

(3)

Eaton’s solar combiner boxes

Solar photovoltaic (PV) installations convert sunlight

into electricity, providing clean, renewable energy.

Solar PV systems contain many separate DC source

circuits that must be combined into a single circuit

prior to inversion into clean, usable AC power for

the electric grid.

Eaton is proud to offer a line of solar combiner boxes that provides customers with a high-quality product good enough to bear the Eaton brand.

Solar combiner boxes aggregate the many DC source circuits present in a solar PV system, and provide the overcurrent protection requirements of the National Electrical Code.T

Containing input fuse holders for source protection, the load sides of the fuse holders are connected together on a common bus that contains the output lugs, allowing multiple circuits to be combined into one outgoing circuit.

Eaton’s combiner boxes are available in two styles—source combiners and array combiners. Source combiners are located closer to the source, or the solar panels. They have smaller input fuse holders and lower output currents.

Array combiners (sometimes referred to as re-combiners) are found in larger installations. They aggregate the outputs from several source combiners into a single circuit. Array combiners feature larger input fuse holders and higher output currents. With the full selection of inputs and fuse holder ratings, Eaton’s solar combiner boxes allow for the complete management of solar DC circuits. Until now, these products have been available only from companies specializing in the solar market. With Eaton’s recently announced DC photovoltaic switch, this offering gives Eaton customers a one-stop shop for solar PV balance-of-system electrical equipment.

(4)

Array combiner features



ETL listed to UL 1741 standard

B

Rated for 600 Vdc continuous duty

C

Poured-in-place gaskets for superior moisture resistance

D

Suitable for either positive or negative grounded arrays

E

Available in 6 and 12 circuit configurations

F

100 or 200A input fuse holders (Class R)

otee:

N Fuses not included.

Technical Details NEMA 3R Catalog Number NEMA 4 Catalog Number Number of

Circuits Maximum Fuse Size  Dimensions (H x W x D) Weight Incoming Wire Range Output Conductors

Maximum Continuous DC Current

Source

Combiners SC8R_SC10R SC8P_SC10P 8₁₀ ₃₀30 16 x 12 x 6_{16 x 12 x 6} 30₃₀ _#16–#4#16–#4 _{1–#6 to 350 kcmil}1–#6 to 350 kcmil 310₃₁₀

SC12R SC12P 12 30 16 x 12 x 6 30 #16–#4 1–#6 to 350 kcmil 310

SC16R SC16P 16 30 16 x 16 x 6 36 #16–#4 2–#6 to 350 kcmil 400

SC24R SC24P 24 20 B 20 x 20 x 6 45 #16–#4 2–#6 to 350 kcmil 400 B

Array

Combiners AC6100R_AC12100R AC6100P_AC12100P 6₁₂ ₁₀₀100 36 x 36 x 8_{48 x 36 x 8} 156₂₂₇ _#6–2/0#6–2/0 _{4–#4 to 500 kcmil}2–#4 to 500 kcmil 720₁₅₂₀

AC6200R AC6200P 6 200 42 x 36 x 8 206 #6–4/0 4–#4 to 500 kcmil 1520

AC12200R AC12200P 12 200 B 48 x 36 x 8 278 #6–4/0 4–#4 to 500 kcmil 1520 2

 Fuses not included.

B _{Total installed fuse capacity shall not exceed maximum continuous DC current rating.}

Source combiner features



ETL listed to ULT 1741 standard

B

Touch-safe midget class fuse holders (non load-break) are rated for 600 Vdc continuous duty (fuses not included)

C

Poured-in-place gaskets for superior moisture resistance

D

Suitable for either positive or negative grounded arrays

E

Available in 8, 10, 12, 16 and 24 circuit configurations

6

NEMAT 3R or NEMA 4 powder-coated steel enclosures

7

White back pan with high-contrast labeling for easier, faster installation

8

Padlockable latch



B

C

8

6 E

F

E



B

C

D

7

4 EATON CORPORATION

(5)

B C

A

B C

A

Source Combiner Dimensions Array Combiner Dimensions

Source Combiner Dimensions

Catalog Number A B C Number of Circuits Output Lug Capacity

SC8R/P 16.00 12.00 6.00 8 #6 AWG—350 kcmil Cu/Al

Array Combiner Dimensions

Catalog Number A B C Number of Circuits Output Lug Capacity

AC6100R/P 30.00 30.00 9.25 6 (2) #4 AWG—500 kcmil Cu/Al
