Outline iMode is proprietary technology, conceived to re-think the state of the art in the world of loudspeaker system control. Devices using this technology have a single on-board DSP that optimises the response of Outline enclosures and enables users to control numerous parameters. The processor can be divided logically into two parts: one containing default “factory” settings, necessary for the electro-acoustic components to operate in the most effi cient way, and a “user” part, which allows users to create bespoke system parameters for specifi c applications.
The “user” part allows users to select the input (digital or analogue), adjust sensitivity and regulate both groups of speakers and individual enclosures. The parameters that can be controlled are: level, delay (up to two seconds), polarity inversion, equalisation and mute. The “factory” part is not accessible to users, but includes all the settings necessary for ensuring enclosures operate at maximum efficiency within their design parameters. Each iMode processor has the same number of processed channels as the frequency ranges covered by the loudspeakers of the enclosure in question. On each of these, it is possible to set level, delay, equalisation, crossover, 64-bit IIR filters and FIR filters, according to user requirements. A proprietary
double compressor/limiter stage on each channel protects the transducers and amplifiers from excessively high signals, and thus ensures that the system will retain its stability, reliability and sonic characteristics even when operating at its maximum potential.
The iMode processors are also specifi cally designed to communicate with the amplifi ers to which they feed signals. This information is then made available to the end user via the network.
The completely Ether-net-based communica-tion protocol enables several iMode devices to be linked, using eas-ily-sourced standard cables and compo-nents.
The choice of this technology enables very
high communication speeds and
also for data to be transmitted via wireless if necessary, with the aid of an access-point.
Once a wireless network has been created, enclosures can be controlled via iPad, iPhone or iPod touch devices. Apps specifically designed for each series of products are available on the App Store. The choice of control hardware and the immediacy of the network access delivers detailed and accurate system monitoring that is extremely useful for audio engineers and system technicians alike.
For each connected enclosure, it is possible to monitor the levels of the input and the outputs for the system’s sections by means of dedicated VU-meters, the status and activity of limiters, a ‘clip record’ since last power-up, and information from the amplifi er (with temperature and protection indications). Some devices are fi tted with a sensor that measures
the average impedance of each transducer when the enclosure receives a test signal (generated by the remote app). Developed entirely by Outline, iMode technology delivers solutions designed for real-life applications, some of which are specific for each type of enclosure. For example, users will find a white LED on each enclosure that enables them to
with which they are communicating, stage monitors offer the possibility of storing and selecting user presets (even without an iPad), which can be recalled according to application, and Mini-COM.P.A.S.S. enclosures provide information on their horizontal configuration (sixteen different combinations of horizontal dispersion, from 60° to 150°, are available).
In short, iMode technology enables precise electro-acoustic optimisation of the components it controls, while simultaneously providing all the adjustment possibilities required by end users, thus effectively eliminating the need for external processors, equalisers or similar equipment. This means enhanced operational and commercial efficiencies via reduced costs and space required for storing or transporting other equipment.
As a consequence of the extremely rapid communication, monitoring and total control of all the enclosures connected is ensured via a single interface.
Further, thanks to the on-board processing, the operating status of individual components is easily monitored, enabling diagnostic work to be carried out remotely, thus cutting maintenance costs.
All this - in a word - is “iMode”: technology that delivers an “all-in-one” system that is reliable and on which each parameter can be regulated. An investment which reduces operating and maintenance costs, by concentrating processing power and control into individual devices.
For further info, visit the Web site:
• Self-powered dual-angle wedge monitor loudspeaker.
• Four presets (three of which are adjustable by the user) selectable via a button on the LED panel or via software.
• Very low physical profi le combined with extremely high-level audio output - only 39.5 cm (15.6 inches) high yet can deliver up to 139 dB SPL.
• The patented folded wave guide provides tight and consistent control of the emitted frequencies in both the horizontal and vertical planes, achieving the defi ned pattern control. • Mirrored LED arrays on both sides of the cabinet provide visual status data.
• Internal PWM amplifi cation eliminates need for heavy and space-hungry amplifi er racks.
• Transducers: a single 15” high-pass loaded neodymium woofer plus a 2.5” diaphragm compression driver with a folded waveguide.
• Frequency response: 59 Hz ÷ 18 kHz (processed).
• Amplifi er rated power: 750 W EIAJ on 4 Ω plus 370 W EIAJ on 8 Ω. • Type: compact self-powered line array element.
• Adjustable horizontal directivity from 60° to 150° in 16 different combinations.
• Transducers: four 5” woofers in bass-refl ex confi guration plus two 1.75” diaphragm compression drivers loaded onto 2 x D.P.R.W.G. (Outline’s patented waveguide).
• Integrated two-channel amplifi er, delivering 2 x 500 W EIAJ on 4 Ω.
• Vertical angle between elements selectable from 0° to 7.5° with minimum steps of 0.5°. • Applicable as front of house system in installations and small tours.
• Frequency response: 100 Hz ÷ 20 kHz (processed). • Max acoustic output: 131 dB SPL peak @ 1 m.
mini-COM.P.A.S.S. iSP
• Type: self-powered arrayable subwoofer.
• Low frequency reinforcement unit for mini-COM.P.A.S.S. array.
• Transducer: a single 15” double-spider woofer, customized to create very low distortion at very high output levels.
• Crossover frequency and type, selectable via the iPad application so can be adapted to any situation.
• Integrated amplifi er rated power: 1000 W EIAJ on 8 Ω in bridge mode.
• Integrated light weight, high strength rigging hardware. Fully compatible with mini-COM.P.A.S.S. system.
• Frequency response: 35 Hz ÷ 550 Hz (unprocessed). • Max acoustic output: 140.5 dB SPL peak @ 1 m in half-space.
• Self-powered dual-angle wedge monitor loudspeaker.
• Four presets (three of which are adjustable by the user) selectable via a button on the LED panel or via software.
• Very low physical profi le combined with extremely high-level audio output - only 35.5 cm (14 inches) high yet can deliver up to 139 dB SPL.
• The patented folded wave guide provides tight and consistent control of the emitted frequencies in both the horizontal and vertical planes, achieving the defi ned pattern control. • Mirrored LED arrays on both sides of the cabinet provide visual status data.
• Internal PWM amplifi cation eliminates need for heavy and space-hungry amplifi er racks. • Transducers: a single 12” high-pass loaded neodymium woofer plus a 2.5” diaphragm
compression driver with a folded waveguide. • Frequency response: 68 Hz ÷ 18 kHz (processed).
• Amplifi er rated power: 750 W EIAJ on 4 Ω plus 370 W EIAJ on 8 Ω.
iSM 112
• Self-powered dual-angle wedge monitor loudspeaker.
• Four presets (three of which are adjustable by the user) selectable via a button on the LED panel or via software.
• Very low physical profi le combined with extremely high-level audio output - only 32.5 cm (12.8 inches) high yet can deliver up to 143 dB SPL.
• The patented folded wave guide provides tight and consistent control of the emitted frequencies in both the horizontal and vertical planes, achieving the defi ned pattern control. • Mirrored LED arrays on both sides of the cabinet provide visual status data.
• Internal PWM amplifi cation eliminates need for heavy and space-hungry amplifi er racks. • Transducers: two 12” high-pass loaded neodymium woofer plus a 3” diaphragm
compression driver with a folded waveguide. • Frequency response: 64 Hz ÷ 18 kHz (processed).
• Amplifi er rated power: 1050 W EIAJ on 8 Ω plus 570 W EIAJ on 16 Ω. • Type: high-power high-effi ciency amplifi ed subwoofer.
• High power integrated amplifi er: 3000 W EIAJ total power.
• Two 18” long-excursion low frequency transducers featuring innovative technologies to provide premium electro-acoustic performance to reliably deliver very high SPLs over extended periods.
• Optional trolley-board - using a “stack & strap” method of location - aids handling and transportation.
• Crossover frequency and type, selectable via the iPad application so can be adapted to any situation.
• Frequency response: 28 Hz ÷ 160 Hz (processed).
• Max acoustic output: 139.5 dB SPL peak @ 1 m in half-space.
DBS 18-2 iSP
• Self-powered two-way full-range system.
• Two-way power module (750 W EIAJ per channel) integrated with a two-way iMode DSP. • Average dispersion: 90° x 65° (H x V)
• Refl ex loaded 15” neodymium woofer and a 2.5” titanium diaphragm horn loaded compression driver, loaded onto a constant directivity horn.
• Trapezoidal cabinet with fl ying hardware on all panels to meet a wide range of mounting and fl ying requirements for fi xed applications or mobile use. Receptacle for fi tting support stand.
• Frequency response: 46 Hz ÷ 20 kHz (processed). • Max acoustic output: 135 dB SPL peak @ 1 m. • Self-powered two-way full-range system.
• Two-way power module (750 W EIAJ per channel) integrated with a two-way iMode DSP. • Average dispersion: 95° x 75° (H x V)
• Refl ex loaded 12” neodymium woofer and a 2.5” titanium diaphragm horn loaded compression driver, loaded onto a constant directivity horn.
• Trapezoidal cabinet with fl ying hardware on all panels to meet a wide range of mounting and fl ying requirements for fi xed applications or mobile use. Receptacle for fi tting support stand. • Frequency response: 53 Hz ÷ 20 kHz (processed).
• Max acoustic output: 133 dB SPL peak @ 1 m.
DVS 15 P iSP
DVS 12 P iSP
• High-effi ciency self-powered subwoofer. • Primarily designed for use with the DVS 12/15 P iSP.
• Single 18” subwoofer enclosure using phase inversion type loading, which, coupled with the use of several innovative loudspeaker technologies, allows it to deliver consistent performance at the highest levels over many years.
• A receptacle is available for mounting the optional support of a satellite. • Frequency response: 26 Hz ÷ 118 Hz (processed)
• Crossover frequency and type selectable via iPad application so can be adapted to any situation. The default crossover is a 24 dB/octave Linkwitz–Riley at 80 Hz. • Max acoustic output: 142 dB SPL peak @ 1 m in half-space.
• Amplifi er rated power: 1500 W EIAJ on 8 Ω.
• Loudspeaker’s power handling: 700 W AES, 2800 W peak. • High-effi ciency self-powered subwoofer.
• Primarily designed for use with the DVS 12/15 P iSP.
• Single 15” subwoofer enclosure using phase inversion type loading, which, coupled with the use of several innovative loudspeaker technologies, allows it to deliver consistent performance at the highest levels over many years.
• A receptacle is available for mounting the optional support of a satellite. • Frequency response: 39 Hz ÷ 147 Hz (processed).
• Crossover frequency and type, selectable via iPad application so can be adapted to any situation. The default crossover is a 24 dB/octave Butterworth at 100 Hz. • Max acoustic output: 141 dB SPL peak @ 1 m in half-space.
• Amplifi er rated power: 1000 W EIAJ on 8 Ω.
• Loudspeaker’s power handling: 600 W AES, 2400 W peak.
DVS 118 SW iSP
DVS 115 SW iSP
