An Extensive Literature Review on Power Quality Improvement using DSTATCOM

(1)

International Journal of Emerging Technology and Advanced Engineering

Website: www.ijetae.com (ISSN 2250-2459,ISO 9001:2008 Certified Journal, Volume 4, Issue 5, May 2014)

591

An Extensive Literature Review on Power Quality

Improvement using DSTATCOM

Anju Tiwari

1

, Prof. Minal Tomar

2

1_{M-Tech Research Scholar Department of Electrical Engineering}

2

Sr. Asst. Professor Department of Electrical & Electronics Engineering

Abstract-Distribution Static Compensator (DSTATCOM) is a custom Power gadget utilized for power quality change within dissemination framework. The control procedures connected to the DSTATCOM assume a real part in its execution. Throughout the previous three decades, a substantial scale mix of circulated era (DG) is starting to change the electrical circulation system from detached to dynamic. Thus, specialized challenges are made by huge effects produced by DG with voltage variety being the prevailing impact. This paper manages operation and control of a dispersion static synchronous compensator (D-STATCOM) for power quality change in offbeat machine-based disseminated era as the nonconcurring generator has poor voltage regulation exceptionally, throughout top burden conditions. Provision of D-STATCOM as voltage controller enhances the general execution of the circulation framework fundamentally. In this paper a three stages three wire Dissemination Static Compensator (DSTATCOM) is inspected for power quality change. DSTATCOM is dependent upon a three leg VSC and is controlled to remunerate sensitive power, symphonious current and unbalances in the heap. IGBT based VSC is capacitor upheld and is controlled for the obliged payment of the heap current. It is watched that DSTATCOM is powerful in remunerating responsive power, burden adjusting and symphonious disposal and enhancing the power nature of the circulation framework.

Keywords- D-STATCOM, distributed generation, voltage regulation, induction generator.

I. INTRODUCTION

Lately there has been an expanded use of delicate and discriminating supplies in different businesses. This has prompted the prerequisite of continuous power, as well as excellent power. Subsequently the issue of power quality (PQ) in circulation framework has ended up progressively imperative and measures are, no doubt taken by power utilities and buyers to enhance the nature of power. A portion of the significant Power Quality concerns of both clients and utilities as specified in [1] are poor power component, unequal burden, consonant substance, voltage hang/swell, voltage gleam and so forth.

[image:1.612.339.553.416.539.2]

In any power framework, the dynamic and responsive power necessities shift constantly. The framework recurrence is influenced by progressions in genuine power although responsive power is identified with voltage size [2]. Consequently voltage and recurrence control has ended up progressively paramount to give the nature of power that meets the guidelines as proposed by Worldwide Electro specialized Requisition (IEC) and Establishment of Electrical and Electronic Designers (IEEE). Power electronic gadgets giving answer for the previously stated issue have been connected as a basic a piece of a custom power framework. Around these power electronic gadgets, a shunt associated Dissemination Static Compensator (DSTATCOM) has been generally utilized for enhancing the voltage quality [3].

Figure 1. Single line diagram of a DSTATCOM

(2)

International Journal of Emerging Technology and Advanced Engineering

592

Cases of such requisitions broadly utilized are movable rate engine drives, diode and thyristors rectifiers, uninterruptible power supplies, machines and their peripherals, buyer gadgets apparatuses (television sets for instance), around others. Those power hardware gadgets offer sparing and solid answers for better oversee and control the utilization of electric vitality. Be that as it may, given the qualities of most power hardware circuits, these semiconductor gadgets present nonlinear operational aspects, which acquaint pollution with voltage and current waveforms at the purpose of normal coupling of streamlined loads as in [5-6]. These gadgets, amassed in thousands, have turned into the principle polluters and the primary distorters of the cutting edge power frameworks. In the meantime, microelectronics processors have discovered their path into numerous requisitions: From mechanized streamlined sequential construction systems, to healing facility diagnostics and estimation plans, to home machines, for example, feature and DVD units. These requisitions are delicate and powerless against power quality issues, for example, either electrical aggravations or power framework music. Anyway microelectronics-based requisitions are not by any means the only ones confronting the dangers of poor power quality. Those same semiconductor-based burdens, which are the real givers to power framework contamination, are additionally extremely touchy to that contamination. Likewise, the different customary payment plans are accessible like SVC, TCSC and STATCOM [7]

II. SYSTEM MODEL

DSTATCOM is a directing gadget utilized as a part of air conditioning conveyance framework. It is dependent upon a power electronic voltage source converter and can go about as either a source or sink of responsive power to a power system. DSTATCOM has been utilized for power element rectification, voltage regulation and burden adjusting. DSTATCOM is shunt associated and utilizes a three stage, 3 legs; protected entryway bipolar intersection transistor (IGBT) based voltage source inverter (VSI) scaffold circuit. It uses info air conditioning inductors and a dc transport capacitor (CDC) to give self supporting dc transport.

The displaying of DSTATCOM is possible in synchronous reference outline system. Figure 2 shows rearranged single line chart of a DSTATCOM, including a DC join capacitor, IGBT based VSC, coupling channel and the PCC voltage.

The changing touchy power prerequisites of the heap are satisfied by the DSTATCOM. For sensitive power remuneration, DSTATCOM gives receptive power as required by the heap and subsequently the source current stays at solidarity power component (UPF). Since just genuine power is constantly supplied by the source, burden adjusting is accomplished by making the source reference current adjusted.

The reference source current used to choose the exchanging of the DSTATCOM has genuine crucial recurrence segment of the heap current which is constantly extricated by these procedures. A STATCOM at the transmission level handles just principal sensitive power and gives voltage help while as a DSTATCOM is utilized at the circulation level or at the heap end for power variable change and voltage regulation. DSTATCOM could be one of the reasonable choices to SVC in an appropriation system. Also, a DSTATCOM can likewise act as a shunt dynamic channel, to kill unbalance or bends in the source current or the supply voltage according to the IEEE-519 standard breaking points. Since a DSTATCOM is such a multifunctional gadget, the fundamental destination of any control calculation ought to be to make it adaptable and simple to execute notwithstanding misusing its multi practicality to the most extreme [8].

The principle target of any recompense plan is that it ought to have a quick reaction, adaptable and simple to execute. The control calculations of a DSTATCOM are essentially actualized in the accompanying steps:

• Estimations of framework voltages and current

• Indicator molding

• Count of remunerating indicators

(3)

International Journal of Emerging Technology and Advanced Engineering

593

The per phase instantaneous PCC voltage is given as:

Where Vs is the rms value of the PCC voltage. The relationship between the PCC voltage, inverter output voltage and the current is given as:

The above equation can be written in matrix form as

Transforming equations to synchronous frame by Park’s transformation, equations become:

Where ω is the system frequency and m is the modulation index of the converter. Writing equation in matrix form,

Where

As per the power balance theory, the instantaneous power at the ac-dc terminals of the inverter is equal.

On substituting Vcd and Vcq and we get

Combining all equations, DSTATCOM model in state space can be written as:

Where A is given by

Since d-q axes are not stationary, and they follow the trajectory of the voltage vector, within this synchronous rotating frame, Vs=Vsd and Vsq=0.

From Instantaneous Reactive Power Theory instantaneous active and reactive powers are

Observing the RHS, it can be concluded that the DSTATCOM performance can be controlled by controlling the active and reactive component of current, id and iq.

III. LITERATURE REVIEW

Yogesh Rohilla, Yash Buddy [9],this paper gives power element rectification, sounds disposal, burden adjusting and nonpartisan current payment of direct and non-straight, adjusted and unequal burdens utilizing custom power gadget DSTATCOM for three-stage four-wire (3p4w) framework. Flawless Symphonious retraction

(4)

International Journal of Emerging Technology and Advanced Engineering

594

A three-leg voltage source converter topology with T-joined transformer as circulation static compensator (DSTATCOM) is utilized within this paper. T-joined transformer is presented here for nonpartisan current recompense. Ability of this course of action is showed utilizing effects got from MATLAB-Simulink nature.

Bhim Singh, Sabha Raj Arya [10], This paper manages a product stage bolted circle (SPLL) based control calculation for a three stage dispersion static compensator (DSTATCOM) for power quality change under direct/nonlinear loads in an appropriation framework. In this control approach, plentifulness of central dynamic and receptive power segments of burden momentums is concentrated for estimation of reference source flows. The DSTATCOM is demonstrated in the Matlab environment utilizing Simulink and Sim Power Framework (SPS) tool stash. Matlab based created model of DSTATCOM is utilized to reproduce its execution. Reproduced execution of DSTATCOM is discovered agreeable under time shifting and unequal direct and nonlinear customer loads. Syed.Karimulla, P.S.Niranjan Kumar and Gulam Amer [11], the execution of the DSTATCOM relies on upon the control calculation i.e. the extraction of the current segments. In this way, for this, there are different control calculations for the control of DSTATCOM piece relying upon different hypotheses and methodologies like stage movement control, quick PQ hypothesis, synchronous edge hypothesis, Adaline based hypothesis. Each of the calculations specified have their benefits and faults. This paper concentrates on power quality change of little disengaged alternator bolstering a three stage three wire circulation framework with a straight load. Voltage regulation and amendment of straight loads, effectiveness of power, for example, power variable rectification are examined and executed with the assistance of DSTATCOM. Furthermore likewise different control calculations specified are explored and broke down through advanced recreations. The models are produced and mimicked in MATLAB utilizing Simulink and power framework piece set (PSB) tool stash. It is watched that DSTATCOM is viable in remunerating receptive power and enhancing the power nature of appropriation frameworks.

Bhim Singh, P. Jayaprakash, Sunil Kumar, and D. P. Kothari [12], in this paper, a neural-system (NN)-controlled appropriation static compensator (DSTATCOM) utilizing a processor is executed for power quality change in a three-stage four-wire circulation framework. A three-leg voltage- source-converter (VSC)-based DSTATCOM with a crisscross trans- previous is utilized for the payment of receptive power for voltage regulation or for power element revision alongside burden adjusting, disposal of symphonious momentums, and unbiased current remuneration at the purpose of regular coupling. The Adeline (versatile straight component)-based NN is utilized to actualize the control plan of the VSC. This system gives comparable execution as that of other control strategies, however it is easy to execute and has a quick reaction and gives almost zero stage shift. The crisscross transformer is utilized for giving a way to the zero- succession present in a three-stage four-wire dissemination framework. This lessens the multifaceted nature and additionally the expense of the DSTATCOM framework.

(5)

International Journal of Emerging Technology and Advanced Engineering

[image:5.612.39.582.159.567.2]

595

Table 1

Summary of Literature Review

Year Author Title Approach Output Parameters Results

2013 Yogesh Rohilla, Yash Pal,

T-connected Transformer Integrated

Three-leg VSC based 3P4W DSTATCOM for Power Quality

Improvement T-connected transformer as distribution static compensator (DSTATCOM)

Three-phase load is changed to two-phase

load at time 0.5s and to single-phase at 0.56s. And loads are reapplied from single-phase to

two-phase a phase at 0.68s.

Power factor correction, harmonics elimination 2012 Bhim Singh, Sabha Raj Arya,

Software PLL Based Control Algorithm for Power Quality Improvement in Distribution System

Software phase locked loop (SPLL)

based control algorithm

Voltage regulation and load balancing under linear loads (at

t=1.75 s to 1.85 s

Satisfactory under time varying and unbalanced linear 2011 Syed.Karimulla, P.S.Niranjan Kumar and Gulam Amer Enhancement of Power Transmission System Performance

Control algorithm Unbalanced Inductive Load .2 Sec Capacitive Load with .4 Sec

Effective in compensating reactive power and improving the power

quality

2011

Bhim Singh, P. Jayaprakash, Sunil Kumar, and D. P.

Kothari

Implementation of Neural-Network-Controlled Three-Leg VSC and a Transformer as Three-Phase Four-Wire DSTATCOM Neural-network (NN)-controlled distribution static compensator (DSTATCOM)

At 0.5 s, a three-phase linear load is changed to two-phase load and again to single-phase load

at 0.6 s.

Reduces the complexity

2010

Ms. Manju Aggarwal, Prof.

S. K. Gupta Prof. Madhusudan,

Dr. Gaurav Kasal

D-STATCOM control in Low

Voltage Distribution System with Distributed Generation Distribution static synchronous compensator (D-STATCOM)

Single/Three Phase with Balanced & Unbalanced Resistive Load.

Single Phase Load of 2.5 kW

DSTATCOM is effective in compensating reactive power

IV. CONCLUSION

Power quality has turned into a paramount situation as of late. This paper has inspected the advancement of DSTATCOM for power quality change of 3 stage 3 wire appropriation framework. Execution of DSTATCOM comprising of 3-leg VSC with T-associated transformer for the 3p4w circulation framework is explored and the particular dissection has been contemplated for Power variable revision, burden adjusting, impartial current remuneration and music diminishment for different direct, nonlinear and unequal burdens.

(6)

International Journal of Emerging Technology and Advanced Engineering

596

REFERENCES

[1] Arindam Ghosh and Gerard Ledwich, “ Power Quality Enhancement Using Custom Power Devices”, Springer, 2009. [2] A.Soundarrajan, S.Sumathi and C.Sundar, “Particle Swarm

Optimization Based LFC and AVR of Autonomous Power Generating System ”, IAENG, International Journal of Computer Science, Special Issue,37:1, IJCS_37_1_10, 2009.

[3] M.Arun Bhaskar, Dr.S.S.Dash, C.Subramani, M.Jagdeesh Kumar, Deepika Harish, R.Shalini, “Non Linear Control of STATCOM”, International Conference on Recent Trends in Information, Telecommunication and Computing, IEEE, 2010.

[4] Masand, D.; Jain, S.; Agnihotri, G, IEEE International Symposium on Industrial Electronics, 9-13 July 2006, PP 1830 – 1834.

[5] Don A.G. Peedder, A.D.Brown, “A parallel connected active filter for reduction of supply current distortion”, IEEE Trans. Ind.Elect. , Vol.47, No.5, pp 1108-1117.Oct 2000

[6] C.W.Edwards, K.E.Mattern, E.J.Stacey, P.R.Nannery, J.Gubernick, “Advanced Static VAR generator employing GTO thyristors,” IEE Trans. on Power Delivery, vol.3,no.4,pp 1622-1627, Oct.1998.

[7] S.Mori, K.Mansuno, M.Takeda and M.Seto, “Development of a large static var generator using self-commutated inverter for improving power system stability”, IEEE Trans.Power Systems , vol.8,no.1,pp 371-377 Feb.1993

[8] Deepika Masand, , Shailendra Jain, Gayatri Agnihotri, Control Strategies for Distribution Static Compensator for Power Quality Improvement, Year : 2008, Page : 421-428

[9] Yogesh Rohilla, Yash Pal, “T-connected Transformer Integrated Three-leg VSC based 3P4W DSTATCOM for Power Quality Improvement” 2013 Nirma University International Conference on Engineering (NUiCONE) IEEE.

[11] Syed.Karimulla, P.S.Niranjan Kumar and Gulam Amer , “Enhancement of Power Transmission System Performance ” Proceedings of ICETECT 2011 IEEE.

[12] Bhim Singh, P. Jayaprakash, Sunil Kumar, and D. P. Kothari, “ Implementation of Neural-Network-Controlled Three-Leg VSC and a Transformer as Three-Phase Four-Wire DSTATCOM” IEEE Transactions On Industry Applications, Vol. 47, No. 4, July/August 2011

[13] Ms. Manju Aggarwal, Prof. S. K. Gupta Prof. Madhusudan, Dr. Gaurav Kasal, “D-STATCOM control in Low Voltage Distribution System with Distributed Generation” Third International Conference on Emerging Trends in Engineering and Technology, 2010 IEEE.
