Volume-5, Issue-3, June-2015

International Journal of Engineering and Management Research

Page Number: 509-513

Replacement of Conventional Material by Composite Materials

Considering Variable Loads

Bipin H M1, Dr. Mohamed Haneef2, Mohammed Imran3

1

PG student, M-Tech 4th Semester, Machine Design, Department of Mechanical Engineering, Ghousia College of Engineering, Ramanagaram, INDIA

2

Professor and Principal, Department of Mechanical Engineering, Ghousia College of Engineering, Ramanagaram, INDIA

3

Assistant Professor, Department of Mechanical Engineering, Ghousia College of Engineering, Ramanagaram, INDIA

ABSTRACT

Safety of the structure is the most important factor in each and every part of the automobile. dynamic loads will be considered to find the damage of the material. Leaf spring is the one of the most important part in the automobile field, for the better suspension system in automobile vehicles parts used are leaf springs and shock absorbers. The main function of leaf spring is not only to support vertical load but also to isolate road induced vibrations. It is subjected to millions of load cycles leading to fatigue failure. In the present work Al6061 and Az91cMg materials were used to find the stiffness and Number of cycles to failure, the results were discussed and tabulated.

Keywords— Leaf spring, Stiffness, Catia, Number of cycles to failure

I. INTRODUCTION

The major of the automobile structures has been failed due to repeated loads. Fatigue leads an important path for the finding the structural damages and need to be calculate the Factor of safety Stiffness and Failure cycles were considerable parameters. To conserve and utilizing properly the natural resources and proper from of energy weight reduction has been the main thing for automobile sectors in current situation it can be achieved initially by taking the good material proper design optimization and better manufacturing process one of the most effective potential items for weight reduction is the suspension leaf spring. The most important field of the automobile is a suspension system in which many of the researches has

been carried out thoroughly based on the comfort requirements.

Some of the papers has been mentioned that the different loading conditions of conventional material as well as other composite materials [3] [5] Some of the papers were given the Calculations, Proper standard designing and Formulae were be considered [1] [2].

II. METHODOLOGY

• Analysis of problems studied by the various literature surveys.

• Standard dimensions and boundary conditions were considered as per ASME

• Using Catia software Modeling and meshing of a leaf spring has been made.

• Using ANSYS, apply the boundary condition to the model of a leaf spring so that the stresses and displacements were found and calculated the Stiffness and failure cycles.

A. Geometric parameters

(2)

510 Copyright © 2011-15. Vandana Publications. All Rights Reserved.

Fig.1. 2d model of a mono leaf spring

The specifications all are represented in the fig.1, such that the thickness is considered as 10 mm for a mono leaf spring.

Variable load is varied from 2000 to 6000N at the time variation of 10 seconds.

ii. Meshed model of a mono leaf spring

Fig. 2. Meshed model of a leaf spring

iii. Boundary condition

Fig.3. Boundary conditions of a leaf spring

Boundary condition applied for leaf spring fixed in all directions and loaded centrally, cyclic loads were applied with varying time.

B. Material properties

Table I Represents the material properties

III. RESULTS AND DISCUSSION

Results

1. Analytical Results –For cyclic load A. For Al6061 material

(3)

511 Copyright © 2011-15. Vandana Publications. All Rights Reserved.

Fig.4 Stress analysis for 2000N at 5sec

• Displacement analysis

Fig.7 Displacement analysis for 2000N at 5sec

(4)

512 Copyright © 2011-15. Vandana Publications. All Rights Reserved.

C. Theoretical result

(5)

513 Copyright © 2011-15. Vandana Publications. All Rights Reserved.

Number of cycles to failure

Considering the loading condition as 2000N such that Ultimate strength of the Al6061 material is 910Mpa and Sa=160.46, Ultimate strength of the Az91cMg material is 845 and Sa=163.46 By using the formula [2], Nf has been

calculated.

The value of Nf of Al6061is 6.052 X 106cycles and

Az91cMg is 4.7 X 106cycles

Discussions

Table III Represents correlating results table

From Table III. represents the comparison of deflections in both Al6061 and Az91cMg materials. The Stiffness of the Al6061 material for Analytical and theoretical values are 549.63 and 487.89 N/mm respectively and for the Az91cMg material the Stiffness values are 516.7 and 461.51N/mm. By comparing all these stiffness values by the 2 different materials whereas the steel material would have less stiffness values with the same loading conditions because of lower Elastic modulus.

V. CONCLUSION

• Comparative study has been made between Al6061l and the Az91cMg material with respect to stress and deformation analytically and theoretically to find the Stiffness and failure cycles.

• While comparing the stiffness the A6061 amdAz91cMg materials were stiffer than steel in Analytical as well as Theoretical manner.

• The number of cycles to failure in Al606 and Az91cMg both the materials were having more than 105

• Hence concluding that the composite material Al6061 is better replacement material instead of steel material in all the considered parameters for a mono leaf spring.

cycles, which is more than the Steel material.
