July 2008

2008 Fairchild Semiconductor Corporation FDW2521C Rev D1(W)

FDW2521C

Complementary PowerTrench









MOSFET

General Description

This complementary MOSFET device is produced using

Fairchild’s advanced PowerTrench process that has

been especially tailored to minimize the on-state

resistance and yet maintain low gate charge for

superior switching performance.

Applications

•

DC/DC conversion

•

Power management

•

Load switch

Features

•

Q1: N-Channel

5.5 A, 20 V. R

DS(ON)

= 21 m

Ω

@ V

GS

= 4.5 V

R

DS(ON)

= 35 m

Ω

@ V

GS

= 2.5 V

•

Q2: P-Channel

–3.8 A, 20 V. R

DS(ON)

= 43 m

Ω

@ V

GS

= –4.5 V

R

DS(ON)

= 70 m

Ω

@ V

GS

= –2.5 V

•

High performance trench technology for extremely

low R

DS(ON)

•

Low profile TSSOP-8 package

D1 S1 S1 G1 D2 S2 S2 G2

TSSOP-8

Pin 1

8

7

6

5

1

2

3

4

Q1 Q2

Absolute Maximum Ratings

T_A = 25°C unless otherwise noted

Symbol Parameter

Q1

Q2 Units

V

DSS

Drain-Source

Voltage

20

–20

V

V

GSS

Gate-Source

Voltage

±

12

±

12

V

I

D

Drain Current - Continuous

(Note 1a) 5.5

–3.8 A

-

Pulsed

30

–30

P

D

Power

Dissipation

(Note 1a) 1.0 W

(Note 1b)

_0.6

T

J

, T

STG

Operating and Storage Junction Temperature Range

-55 to +150

°

C

Thermal Characteristics

R

θJA

Thermal Resistance, Junction-to-Ambient

(Note 1a) 125

°

C/W

(Note 1b)

₂₀₈

Package Marking and Ordering Information

Device Marking

Device

Reel Size

Tape width

Quantity

2521C FDW2521C

13’’

12mm

2500

units

Electrical Characteristics

T_A = 25°C unless otherwise noted

Symbol

Parameter Test

Conditions

Type Min

Typ Max Units

Off Characteristics

BV

DSS

Drain-Source Breakdown

Voltage

V

GS

= 0 V, I

D

= 250 µA

V

GS

= 0 V, I

D

= –250 µA

Q1

Q2

20

–20

V

∆

BV

DSS

∆

T

J

Breakdown Voltage

Temperature Coefficient

I

D

= 250 µA, Referenced to 25

°

C

I

D

= –250 µA, Referenced to 25

°

C

Q1

Q2

14

–16

mV/

°

C

I

DSS

Zero Gate Voltage Drain

Current

V

DS

= 16 V, V

GS

= 0 V

V

DS

= –16 V, V

GS

= 0 V

Q1

Q2

1

–1

µ

A

I

GSS

Gate-Body

Leakage V

GS

= +12 V, V

DS

= 0 V

V

GS

= +12 V, V

DS

= 0 V

Q1

Q2

+100

+100

nA

On Characteristics

(Note 2)

V

GS(th)

Gate Threshold Voltage

V

DS

= V

GS

, I

D

= 250 µA

V

DS

= V

GS

, I

D

= –250 µA

Q1

Q2

0.6

–0.6

0.8

–1.0

1.5

–1.5

V

∆

V

GS(th)

∆

T

J

Gate Threshold Voltage

Temperature Coefficient

I

D

= 250 µA, Referenced to 25

°

C

I

D

= –250 µA, Referenced to 25

°

C

Q1

Q2

–3.2

3.0

mV/

°

C

R

DS(on)

Static

Drain-Source

On-Resistance

V

GS

= 4.5 V, I

D

= 5.5 A

V

GS

= 2.5 V, I

D

= 4.2 A

V

GS

= 4.5 V, I

D

= 5.5 A, T

J

= 125

°

C

Q1

17

24

23

21

35

34

m

Ω

V

GS

= –4.5 V, I

D

= –3.8 A

V

GS

= –2.5 V, I

D

= –3.0 A

V

GS

= –4.5 V, I

D

= –3.8 A, T

J

= 125

°

C

Q2

36

56

49

43

70

69

I

D(on)

On-State Drain Current

V

GS

= 4.5 V, V

DS

= 5 V

V

GS

= –4.5 V, V

DS

= –5 V

Q1

Q2

30

–15

A

g

FS

Forward

Transconductance

V

DS

= 5 V, I

D

= 5.5 A

V

DS

= –5 V, I

D

= –3.5 A

Q1

Q2

26

13.2

S

Dynamic Characteristics

C

iss

Input

Capacitance

Q1

Q2

1082

1030

pF

C

oss

Output

Capacitance

Q1

Q2

277

280

pF

C

rss

Reverse

Transfer

Capacitance

Q1:

V

DS

= 10 V, V

GS

= 0 V,

f = 1.0 MHz

Q2:

V

DS

= –10 V, V

GS

= 0 V,

f = 1.0 MHz

Q1

Q2

130

120

pF

Switching Characteristics

t

d(on)

Turn-On

Delay

Time

Q1

Q2

8

11

20

20

ns

t

r

Turn-On Rise Time

Q1

Q2

8

18

27

32

ns

t

d(off)

Turn-Off

Delay

Time

Q1

Q2

24

34

38

55

ns

t

f

Turn-Off Fall Time

Q1:

V

DD

= 10 V, I

D

= 1 A,

V

GS

= 4.5 V, R

GEN

= 6

Ω

Q2:

V

DD

= –5 V, I

D

= –1 A,

V

GS

= –4.5V, R

GEN

= 6

Ω

Q1

Q2

8

34

16

55

ns

Q

g

Total

Gate

Charge

Q1

Electrical Characteristics

(continued)

T_A = 25°C unless otherwise noted

Symbol

Parameter Test

Conditions

Type

Min

Typ Max Units

Drain-Source Diode Characteristics and Maximum Ratings

I

S

Maximum Continuous Drain-Source Diode Forward Current

Q1

Q2

0.83

–0.83

A

V

SD

Drain-Source

Diode

Forward

Voltage

V

GS

= 0 V, I

S

= 0.83 A (Note 2)

V

GS

= 0 V, I

S

= –0.83 A (Note 2)

Q1

Q2

0.7

–0.7

1.2

–1.2

V

Notes:

1. R_θJA is the sum of the junction-to-case and case-to-ambient thermal resistance where the case thermal reference is defined as the solder mounting surface of the drain pins. R_θJC is guaranteed by design while R_θCA is determined by the user's board design.

a) R_θJA is 125°C/W (steady state) when mounted on a 1 inch² copper pad on FR-4. b) R_θJA is 208°C/W (steady state) when mounted on a minimum copper pad on FR-4.

2. Pulse Test: Pulse Width < 300µs, Duty Cycle < 2.0%

Typical Characteristics: Q1

0 5 10 15 20 25 30 0 0.5 1 1.5 2 2.5 3 VDS, DRAIN-SOURCE VOLTAGE (V) ID , DRAIN CURRE NT ( A ) 3.0V 3.5V 2.5V 2.0V VGS = 4.5V 0.5 1 1.5 2 2.5 0 5 10 15 20 25 30

ID, DRAIN CURRENT (A)

RDS (O N) , NO RMALIZE D DRAIN-S O URCE O N-RE S IS TANCE VGS = 2.0V 3.5V 3.0V 4.0V _4.5V 2.5V

Figure 1. On-Region Characteristics.

Figure 2. On-Resistance Variation with

Drain Current and Gate Voltage.

0.6 0.8 1 1.2 1.4 1.6 -50 -25 0 25 50 75 100 125 150 TJ, JUNCTION TEMPERATURE ( o C) RDS (O N) , NO RMALIZE D DRAIN-S O URCE O N-RE S IS TANC E ID = 5.5A VGS = 4.5V 0 0.01 0.02 0.03 0.04 0.05 0.06 0.07 1 2 3 4 5

VGS, GATE TO SOURCE VOLTAGE (V)

RDS (O N) , O N -R E S IS TANCE ( O HM) ID = 2.8 A TA = 125o_C TA = 25 o C

Figure 3. On-Resistance Variation with

Temperature.

Figure 4. On-Resistance Variation with

Gate-to-Source Voltage.

0 5 10 15 20 25 30 0.5 1 1.5 2 2.5 3

VGS, GATE TO SOURCE VOLTAGE (V)

ID , DRAIN CURRE NT ( A ) TA = -55 o C 25o_C 125o C VDS = 5V 0.0001 0.001 0.01 0.1 1 10 100 0 0.2 0.4 0.6 0.8 1 1.2 VSD, BODY DIODE FORWARD VOLTAGE (V)

IS , R EVER SE DRAIN CURRE NT ( A ) TA = 125oC 25o C -55o C VGS = 0V

Figure 5. Transfer Characteristics.

Figure 6. Body Diode Forward Voltage Variation

with Source Current and Temperature.

Typical Characteristics: Q1

0 1 2 3 4 5 0 2 4 6 8 10 12 14 Qg, GATE CHARGE (nC) VGS , G A TE -S O URCE V O LTAG E ( V ) ID = 5.5A VDS = 5V 15V 10V 0 300 600 900 1200 1500 1800 0 4 8 12 16 20

VDS, DRAIN TO SOURCE VOLTAGE (V)

CAP ACITANCE ( pF) CISS CRSS COSS f = 1MHz VGS = 0 V

Figure 7. Gate Charge Characteristics.

Figure 8. Capacitance Characteristics.

0.01 0.1 1 10 100 0.1 1 10 100 VDS, DRAIN-SOURCE VOLTAGE (V) ID , DRAIN CURRE NT ( A ) DC 10s 1s 100ms RDS(ON) LIMIT VGS = 4.5V SINGLE PULSE RθJA = 250oC/W TA = 25 o C 10ms 1ms 0 10 20 30 40 50 0.001 0.01 0.1 1 10 100 1000 t1, TIME (sec) P (pk ), P E AK TRANS IE NT P O WE R ( W ) _{SINGLE PULSE} RθJA = 250°C/W TA = 25°C

Figure 9. Maximum Safe Operating Area.

Figure 10. Single Pulse Maximum

Power Dissipation.

Typical Characteristics: Q2

0 6 12 18 24 30 0 1 2 3 4 5 -VDS, DRAIN-SOURCE VOLTAGE (V) VGS = -4.5V -2.5V -3.5V -3.0V -2.0V -4.0V 0.8 1 1.2 1.4 1.6 0 5 10 15 20 25 30

- ID, DRAIN CURRENT (A) VGS = -2.5V

-3.5V

-4.5V -3.0V

-4.0V

Figure 11. On-Region Characteristics.

Figure 12. On-Resistance Variation with

Drain Current and Gate Voltage.

0.6 0.8 1 1.2 1.4 1.6 -50 -25 0 25 50 75 100 125 150 TJ, JUNCTION TEMPERATURE ( o C) ID = -3.8A VGS = -4.5V 0 0.03 0.06 0.09 0.12 0.15 1.5 2 2.5 3 3.5 4 4.5 5

-VGS, GATE TO SOURCE VOLTAGE (V) ID = -1.9A

TA = 125oC

TA = 25

o_C

Figure 13. On-Resistance Variation with

Temperature.

Figure 14. On-Resistance Variation with

Gate-to-Source Voltage.

0 6 12 18 24 30 0.4 1.3 2.2 3.1 4

-VGS, GATE TO SOURCE VOLTAGE (V) TA = -55 o C 25o_C 125o_C VDS = -5.0V 0.0001 0.001 0.01 0.1 1 10 100 0 0.2 0.4 0.6 0.8 1 1.2 1.4 -VSD, BODY DIODE FORWARD VOLTAGE (V)

TA = 125

o_C

25o_C

-55o_C

VGS = 0V

Figure 15. Transfer Characteristics.

Figure 16. Body Diode Forward Voltage Variation

with Source Current and Temperature.

Typical Characteristics: Q2

0 1 2 3 4 5 0 3 6 9 12 Qg, GATE CHARGE (nC) ID = -3.8A VDS = -5V -10V -15V 0 300 600 900 1200 1500 1800 0 5 10 15 20

-VDS, DRAIN TO SOURCE VOLTAGE (V) CISS

CRSS

COSS

f = 1MHz VGS = 0 V

Figure 17. Gate Charge Characteristics.

Figure 18. Capacitance Characteristics.

0.01 0.1 1 10 100 0.01 0.1 1 10 100 VDS, DRAIN-SOURCE VOLTAGE (V) ID , DRAIN CURRE NT ( A ) DC 10s 1s 100ms 100µs RDS(ON) LIMIT VGS = -4.5V SINGLE PULSE RθJA = 250oC/W TA = 25 o_C 10ms 1ms 0 5 10 15 20 0.01 0.1 1 10 100 t1, TIME (sec) P (pk ), P E AK TRANS IE NT P O WE R ( W ) SINGLE PULSE RθJA = 250°C/W TA = 25°C

Figure 19. Maximum Safe Operating Area.

Figure 20. Single Pulse Maximum

Power Dissipation.

0.001 0.01 0.1 1 0.0001 0.001 0.01 0.1 1 10 100 1000 t1, TIME (sec) r(t), NORMALIZED EFFECTIVE

TRANSIENT THERMAL RESISTANCE

RθJA(t) = r(t) + RθJA RθJA = 250 °C/W TJ - TA = P * RθJA(t) Duty Cycle, D = t1 / t2 P(pk) t1 t2 SINGLE PULSE 0.01 0.02 0.05 0.1 0.2 D = 0.5

Figure 21. Transient Thermal Response Curve.

Thermal characterization performed using the conditions described in Note 1b. Transient thermal response will change depending on the circuit board design.
