Linux. Managing your server with service and productivity tools

(1)

Linux

Managing your server with service and productivity tools

(2)

(3)

Linux

Managing your server with service and productivity tools

(4)

Note

Before using this information and the product it supports, read the information in “Notices” on page 33.

(5)

Managing your server with service and

productivity tools

. . . 1

What's new in Managing your server with service and productivity tools . . . 1

Installing service and productivity tools . . . 2

Installing tools by using a server package manager 2 Installing specific tools by using the rpm command . . . 2

Installing tools by using the IBM Installation Toolkit . . . 3

Displaying package man pages . . . 4

Middleware and infrastructure . . . 6

DynamicRM . . . 6

ServiceRM . . . 7

Service and productivity tools . . . 7

Hardware inventory . . . 7

Inventory scout . . . 8

Platform diagnostics (ppc64-diag) . . . 9

Extended error handling . . . 12

servicelog . . . 12

Environmental and power management features 14 Service aids . . . 15

Handling errors in guests with FWNMI . . . 19

IBM Performance Management for Power Systems . . . 19

Large page analysis. . . 20

IBM Power RAID adapter utilities (iprutils). . . 20

IBM Electronic Service Agent . . . 22

Diagnosing RTAS events . . . 23

Displaying RTAS events in the kernel ring buffer 23 Displaying RTAS events in the servicelog database . . . 23

Displaying RTAS events logged in the /var/log/platform file . . . 24

Collecting support data . . . 27

Running stand-alone diagnostics on a PowerKVM system . . . 28

Getting support . . . 30

Online version . . . 31

Notices

. . . 33

Trademarks . . . 34

Code license and disclaimer

information . . . 35

||

|| ||

(6)

(7)

Managing your server with service and productivity tools

Linux on Power® service and productivity tools are also known as RAS (reliability, availability, and serviceability) tools. This topic collection provides information about hardware service diagnostic aids, productivity tools, and installation aids for Linux operating systems on IBM®servers based on

POWER8™, POWER7®, POWER6®, and POWER5 technology.

Note: By using the code examples, you agree to the terms of the “Code license and disclaimer information” on page 31.

What's new in Managing your server with service and productivity

tools

Managing your server with service and productivity tools introduces the following new topics.

IBM Serviceable Event Provider for PowerKVM systems

The IBM Serviceable Event Provider provides key functions, which identifies serviceable problems and sends the respective SNMP traps. IBM Serviceable Event Provider also provides a registration mechanism to receive the SNMP traps. See IBM Serviceable Event Provider for IBM PowerKVM Systems for more information.

Extended error handling capabilities

On systems running IBM PowerKVM with OPAL firmware, you can take advantage of extended error handling (EEH) capabilities for detecting and reporting a variety of PCI bus error conditions. See “Extended error handling” on page 12 for more information.

Firmware assisted non-maskable interrupts

On systems running IBM PowerKVM virtualization, you can use firmware assisted non-maskable

interrupts (FWNMI) for error handling and recovery of machine checks in guests. See “Handling errors in guests with FWNMI” on page 19 for more information.

Environmental and power management features

POWER8 systems with OPAL firmware provide new features for safeguarding your system's environment and power supply. See “Environmental and power management features” on page 14 for details.

Reliability, availability, and service tools for PowerKVM environments

Statements of support and new tools for PowerKVM environments were added to the following topics:

v _{“Hardware inventory” on page 7} v _{“Inventory scout” on page 8}

v _{“IBM Power RAID adapter utilities (iprutils)” on page 20} v _{“Platform diagnostics (ppc64-diag)” on page 9}

(8)

Stand-alone diagnostics

Use these instructions to diagnose hardware problems on a system using IBM PowerKVM virtualization. The stand-alone diagnostics tool cannot be run on a system while the system is in PowerKVM mode, so these instructions will guide you through changing the mode from PowerKVM to PowerVM®, running the diagnostics tool, and changing the mode back to PowerKVM. See “Running stand-alone diagnostics on a PowerKVM system” on page 28 to learn more.

Installing service and productivity tools

You can install service and productivity tools by using your server package manager, therpmcommand, or the IBM Installation Toolkit.

Installing tools by using a server package manager

You can install service and productivity tools from the IBM Linux on Power tools repository by using your server package manager.

Note: On servers connected to the internet but without graphics support, you might find that using a line-mode web browser likew3m orlynxsimplifies downloading files directly to your server.

See the instructions for installing packages using the IBM Linux on Power tools repository in the IBM Linux on Power tools repository (http://pic.dhe.ibm.com/infocenter/lnxinfo/v3r0m0/topic/liaae/ liaaetoolsrepository.htm) topic. You can use the repository to install all service tools, or a subset of the tools.

For information about service and productivity tools package support, see “Getting support” on page 30.

Installing specific tools by using the rpm command

You can install specific service and productivity tools from the IBM Tools Repository by using therpm

command. Tool availability can vary by server type and Linux distribution.

Note: On servers connected to the internet but without graphics support, you might find that using a line-mode web browser likew3m orlynxsimplifies downloading files directly to your server.

Complete the following steps:

1. Review this package prerequisite diagram to understand which packages to obtain: https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/FlowChart.pdf.

2. Obtain the RPM package files for specific tools and their prerequisites as described at one of the following sites corresponding to your server type and Linux distribution. Tool packages must be installed in the order listed in the site table.

Blade server

Red Hat Enterprise Linux 6

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/bladecenter/ rhel6.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/bladecenter/ rhel5.html

SUSE Linux Enterprise Server 11

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/ bladecenter/sles11.html

(9)

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/ bladecenter/sles10.html

HMC-managed or IVM-managed server Red Hat Enterprise Linux 6

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/ hmcmanaged/rhel6.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/ hmcmanaged/rhel5.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/ hmcmanaged/sles11.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/ hmcmanaged/sles10.html

Stand-alone server

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/other/ rhel6.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/redhat/other/ rhel5.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/other/ sles11.html

https://www14.software.ibm.com/webapp/set2/sas/f/lopdiags/suselinux/other/ sles10.html

Note: For Ubuntu packages, see the Ubuntu Package Search page. Ubuntu packages are provided by the distribution in .deb format. RSCT packages are not currently available for the Ubuntu distribution.

3. If the package files are in compressed, gzip format (<filename>.gz), uncompress them by entering the following command for each file:

gunzip <filename>.gz

Otherwise, continue to the next step.

4. Install RPM files by entering the following command for each file: rpm -Uvh <filename>.rpm

For information about service and productivity tools package support, see “Getting support” on page 30.

Installing tools by using the IBM Installation Toolkit

You can install service and productivity tools by using the IBM Installation Toolkit.

For information about installing service and productivity tools by using the IBM Installation Toolkit while installing Linux on your server, see Installing a Linux distribution (http://publib.boulder.ibm.com/ infocenter/lnxinfo/v3r0m0/topic/liaan/ppwelcomeinstalllinux.htm).

| |

(10)

For information about installing service and productivity tools by using the IBM Installation Toolkit when Linux is already installed on your server, see Updating an installed system (http://

publib.boulder.ibm.com/infocenter/lnxinfo/v3r0m0/topic/liaan/ppcreaetenetwork.htm). For an overview of the IBM Installation Toolkit, see Introducing IBM Installation Toolkit (http://publib.boulder.ibm.com/infocenter/lnxinfo/v3r0m0/topic/liaan/ppintroduction.htm).

Displaying package man pages

This topic explains how to display man pages provided by packages installed on your system.

The version of a service and productivity tools package can vary between Linux distributions. You might also want to install the latest version of an open source package that is available online. Given this variance and flexibility, the best source of accurate and relevant information for commands in a package are the man pages installed with the commands.

To determine the man pages provided by a package installed on your system, list the file content of the package by runningrpm -qlpackage-name. Man page path names typically contain/man/:

# rpm -ql servicelog /usr/bin/log_repair_action /usr/bin/servicelog /usr/bin/servicelog_manage /usr/bin/servicelog_notify /usr/bin/v1_servicelog /usr/bin/v29_servicelog /usr/sbin/slog_common_event /usr/share/doc/packages/servicelog /usr/share/doc/packages/servicelog/COPYING /usr/share/man/man8/log_repair_action.8.gz /usr/share/man/man8/servicelog.8.gz /usr/share/man/man8/servicelog_notify.8.gz

(11)

# man log_repair_action

LOG_REPAIR_ACTION(8) POWER Diagnostic Tools LOG_REPAIR_ACTION(8)

NAME

log_repair_action - create a log entry to indicate that a device was repaired

SYNOPSIS

/usr/sbin/log_repair_action -l location-code [-q] /usr/sbin/log_repair_action -l location-code -d date [-q]

DESCRIPTION

The log_repair_action command creates an entry in the error log to indicate that the device at the specified location code has been repaired. When viewing a list of platform errors, all errors on the device at the specified location code prior to the specified date will be considered closed (fixed).

OPTIONS

-l location-code or --location="location-code"

Specify the lcoation code of the device which was repaired.

-d date or --date="date"

Specify the date and time on which the device was repaired. If not speci-fied, defaults to the current date/time.

-q or --quiet

Do not prompt for confirmation or print error messages.

AUTHOR

Written by Michael Strosaker ([email protected])

Middleware and infrastructure

Some service and productivity tools use middleware that provides an infrastructure for accessing system data, logs, and events.

DynamicRM

Dynamic Resource Manager (DynamicRM) is a Reliable, Scalable, Cluster Technology (RSCT) resource manager.

DynamicRM allows a Hardware Management Console (HMC) to do the following tasks:

Note: DynamicRM cannot be used on systems using IBM PowerKVM virtualization.

v _{Dynamically add or remove processors, memory, or I/O slots from a running partition.} v _{Concurrently update system firmware.}

v _{Perform certain shutdown operations on a partition.}

v _{Migrate a partition from POWER6 to POWER7 processor-based servers.}

v _{Enable end-to-end virtual device view. The end-to-end virtual device view shows how virtual disks}

map to disk names in Linux, and how virtual Ethernet devices map to Linux Ethernet interfaces. The DynamicRM package does not ship any user commands. The package depends upon RSCT.

(13)

ServiceRM

Service Resource Manager (ServiceRM) is a Reliable, Scalable, Cluster Technology (RSCT) resource manager.

ServiceRM creates serviceable events from the output of platform diagnostics (ppc64-diag). ServiceRM sends these events to the Service Focal Point™on the Hardware Management Console (HMC) or the Integrated Virtualization Manager (IVM).

Note: ServiceRM cannot be used on systems using IBM PowerKVM virtualization.

The ServiceRM package does not ship any user commands. The package depends upon RSCT.

Service and productivity tools

Several service and productivity tools are available.

Hardware inventory

Hardware inventory provides a simple way of finding basic information about your installed hardware. Hardware includes processors, memory, serial ports, parallel ports, power supplies, fans, graphics adapters, network adapters, and SCSI and IDE devices such as disks.

Hardware inventory consists of several different commands that you can use to gather data about your hardware. This data can be viewed by you or accessed by higher-level serviceability tools.

The commands access the Vital Product Data (VPD) database. The default VPD is the

/var/lib/lsvpd/vpd.dbfile. You can direct the commands to access other VPD files that contain previous

hardware inventory databases that are replaced by the system.

Some systems feature dynamic VPD. The commands access the dynamic VPD only when started by the root user.

The utilities described here are supported in the following Linux distributions and virtualized environments:

Table 1. Support for hardware inventory utilities Utility

PowerVM partition on any level of

Power processor POWER8 PowerKVM support

libvpd Library All current versions of the following distributions:

v _{Red Hat Enterprise Linux} v _{SUSE Linux Enterprise Server}

Supported on host, not applicable on guests

lscfg All current versions of the following distributions:

lsmcode All current versions of the following distributions:

(14)

Table 1. Support for hardware inventory utilities (continued) Utility

lsvio All current versions of the following distributions:

Not supported

lsvpd All current versions of the following distributions:

v _{Red Hat Enterprise Linux} v _{SUSE Linux Enterprise Server} v _Ubuntu

vpdupdate All current versions of the following distributions:

For Linux distributions currently supported on Power systems, see Linux on Power overview.

Hardware inventory commands are provided by thelsvpdpackage. The commands that are typically included are:

vpdupdate

Update the VPD database.

Note: The information that the other commands in thelsvpd package provide is correct only if thevpdupdate command is run after any changes are made to the system configuration. If you are unsure that any changes were made, run thevpdupdatecommand.

lscfg List hardware configuration information for the system and its components.

lsmcode

List hardware microcode and firmware levels.

lsvio List virtual I/O adapters and devices.

lsvpd List VPD for the system and its components.

The commands that are provided by this package, and their features and usage, might vary by

distribution and release. Consult the man pages on your system for the most accurate description of their features and usage. For more information about how to list and display the man pages for commands that are provided by this package, see “Displaying package man pages” on page 4.

For more information about thelsvpdpackage, see lsvpd: Utility to List Device Vital Product Data (VPD) (http://linux-diag.sourceforge.net/Lsvpd.html).

Inventory scout

Inventory scout surveys the system for Vital Product Data (VPD).

Inventory scout commands are provided by theIBMinvscoutpackage. The commands that are typically included are:

invscout

(15)

Table 2. Support for inventory scout utilities

Utility

Linux distributions running on a PowerVM partition on any level of

invscout All current versions of the following distributions:

Not applicable

For Linux distributions currently supported on Power systems, see ../liaam/liaamoverview.dita. The commands that are provided by this package, and their features and usage, might vary by

Platform diagnostics (ppc64-diag)

Platform diagnostics report firmware events, provide an automated response mechanism to urgent events, and provide event notifications to system administrators and service frameworks.

Table 3. Support for ppc64-diag utilities

Utility

rtas_errd All current versions of the following distributions:

All current versions of the following distributions on guests:

opal_errd Not applicable Host only. Not applicable on guests. opal-elog-parse Not applicable Host only. Not applicable on guests. opal-dump-parse Not applicable Host only. Not applicable on guests. diag_encl All current versions of the following

distributions:

Not applicable

encl_led All current versions of the following distributions:

Not applicable

usysident All current versions of the following distributions:

Not supported

(16)

Table 3. Support for ppc64-diag utilities (continued) Utility

usysattn All current versions of the following distributions:

Not supported

ppc64-diag Error Log Analyzer (ELA) All current versions of the following distributions:

Not supported

For Linux distributions currently supported on Power systems, see Linux on Power overview.

Platform diagnostics for systems using PowerVM virtualization

The platform diagnostics rtas_errd daemon logs platform events that are detected by firmware to servicelog. Platform events are also known as RTAS events. The rtas_errd daemon might also take more action on certain types of events, such as failures of fans or power supplies. It is configured to start automatically when Linux boots.

Platform diagnostics commands and the rtas_errd daemon are provided by the ppc64-diag package. The commands that are typically included are:

explain_syslog

Read a file (or stdin) that is in the format that is produced by the syslogd daemon, and print an explanation for each line that matches a message in the/etc/ppc64-diag/message_catalog message catalog. The explanations include probable cause and recommended action. If run with the-Mflag, the command reads from the/var/log/messagesfile. For example:

explain_syslog -M

syslog_to_svclog

Read a file (or stdin) that is in the format that is produced by the syslogd daemon, and log an event to the servicelog database for each line that matches a message in the/etc/ppc64-diag/

message_catalogmessage catalog. It is not automatically started when Linux boots. If run in the

background with the-Mflag, it continuously monitors the/var/log/messagesfile. For example: syslog_to_svclog -M &

usysident

Use this utility to operate device identification, or to view and modify system identification indicators. This utility was previously in thepowerpc-utilspackage, and now resides in the

ppc64-diagpackage as of SUSE Linux Enterprise Server 11 SP3.

usysattn

If you run theusysattnutility without arguments, the system prints a list of all of the attention indicators on the system along with their current status (on or off). This utility was previously in

thepowerpc-utils package, and now resides in theppc64-diagpackage as of SUSE Linux

Enterprise Server 11 SP3.

Enclosure diagnostics (

diag_encl

)

As of SUSE Linux Enterprise Server 11 SP3, you can use additional options to diagnose problems on the 5888 PCIe storage enclosure. Thediag_enclutility is contained in theppc64-diagpackage.

(17)

Thediag_enclutility can be run as part of a Linux CRON job (recommended), or run independently. For more information on setting up a CRON job, including thediag_enclutility, see Connecting and

configuring the disk drive enclosure in a system running Linux (http://www.ibm.com/support/ knowledgecenter/POWER7/p7ham/scsidiskdriveenclosurelinux.htm).

Run the following command to access enclosure diagnostics as part of a CRON job:

:/usr/sbin/diag_encl -scl

Options for thediag_enclutility include the following:

v _{-h: Print this help message.}

v _{-s: Generate serviceable events for any failures and write events to the service log.}

v _{-c: Compare with previous status and report only new failures.}

v _{-l: Turn on fault LEDs for serviceable events.}

v _{-v: Verbose output.}

v _{-V: Print the version of the command and exit.}

v _{-f: For testing, read SCSI enclosure services (SES) data from path.pg2 and VPD from path.vpd.}

v _{<scsi_enclosure>: The SCSI generic (sg) device on which to operate, such as}_sg7_{. If you do not specify a}

device, all such devices are diagnosed.

For more information, see the 5888 PCIe storage enclosure topic (http://www.ibm.com/support/ knowledgecenter/POWER7/p7ham/p7ham_5888_kickoff.htm).

Note: You can also use thediag_encl utility on the IBM TotalStorage EXP24 Ultra320 SCSI Expandable Storage Disk Enclosure (7031).

Light path diagnostics

Light path diagnostics is a system of light emitting diodes (LEDs) on various external and internal components of the server. When an error occurs, LEDs are lit throughout the server. Use the following utilities to gather information about light path diagnostics:

usysident

Use this utility to view and turn on or off the indicators that identify devices on Power systems. This utility was previously in thepowerpc-utils package, and now resides in theppc64-diag package as of SUSE Linux Enterprise Server 11 SP3.

usysattn

If you run theusysattnutility without arguments, the system prints a list of all of the attention indicators on the system along with their current status (on or off). This utility was previously in

thepowerpc-utils package, and now resides in theppc64-diagpackage as of SUSE Linux

Enterprise Server 11 SP3.

Example: Locating a faulty Ethernet card

1. The service log notifier alerts the light path diagnostics subsystem, lp_diag, that the Ethernet card is not functioning. Typically, thelp_diag utility runs automatically through an script that is registered when theppc64-diagpackage is installed.

2. The lp_diagutility enables an indicator LED.

3. You notice that one of the LEDs on your system is lit and not flashing. You run the usysattnutility from the command line to get the location code of the LED indicator.

4. To gather more information about card, you run thelscfg utility.

(18)

For more information, see Light path diagnostics topic (http://www.ibm.com/support/ knowledgecenter/POWER7/p7eal/p7eal_lightpathdiagnostics.htm).

For more information about the ppc64-diag package, see ppc64 Platform Diagnostics (http://linux-diag.sourceforge.net/ppc64-diag/).

Platform diagnostics for systems using PowerKVM virtualization and OPAL

firmware

The platform diagnostics opal_errd daemon logs platform events that are detected by the PowerKVM host. The daemon stores logs in the/var/log/opal-elogdirectory.

One file for each log is saved, and one message is displayed in syslog. For example,

"May 20 10:44:16 llmjuno03b ELOG[34914]: LID[5034a000]::SRC[11007201]::External Environment:: Predictive Error::Service action required"

The events logged in syslog can be one of the following three types:

v _{Service action and call home are required} v _{Service action is required}

v _{No service action is required}

Internally, the opal_errd daemon calls theextract_opal_dumpcommand, which extracts platform dump data and stores it in/var/log/dump.

opal-elog-parse

Use this tool to parse error logs on the PowerKVM host system. This tools parses logs from the

/var/log/opal-elogdirectory and gives detailed info about the log.

opal-dump-parse

When Power systems running OPAL firmware crash, the FSP generates a system dump

(SYSDUMP). When the PowerKVM hosts reboots, it stores the SYSDUMP in the/var/log/dump directory, along with other platform dumps. Use theopal-dump-parseutility to extract OPAL logs and kernel raw buffer information from SYSDUMP.

Extended error handling

On systems running IBM PowerKVM with OPAL firmware, you can take advantage of extended error handling (EEH) capabilities for detecting and reporting a variety of PCI bus error conditions.

The EEH hardware features allow PCI bus errors to be cleared and a PCI card to be "rebooted" and recovered to anoperative state automatically, without having to reboot the operating system. This feature is enabled on real PCI cards, which are passed through to the guest from the host. This feature is not available on emulated PCI cards.

servicelog

Use the servicelog and related utilities to manage events that require service.

The utilities described here are supported in the following Linux distributions and virtualized environments: | | | | | | | |

(19)

Table 4. Support for servicelog utilities

Utility

Linux distributions running on a PowerVM partition on any level of

servicelog library and all servicelog tools

All current versions of the following distributions:

Not applicable

For Linux distributions currently supported on Power systems, see ../liaam/liaamoverview.dita. The servicelog packages provide a library for logging service-related events to the service log database, and commands for viewing the contents of the database. This database allows for the logging of serviceable and informational events, and service procedures that are performed upon the system. If an event occurs that requires a service action to repair, the event is logged in the servicelog database.

Example events include hardware failures that require the replacement of a Field Replaceable Unit (FRU), or issues that require a firmware update to fix. After you repair a hardware device, run the

log_repair_actioncommand to mark all of the associated events as closed. An example of a repair action is the replacement of an FRU.

To use servicelog, run theservicelogcommand. The statistics that are stored in the servicelog database, similar to the following, are displayed:

# servicelog

Servicelog Statistics:

There are 3 open events requiring action. Summary of Logged Events:

Type Total Open Closed Info

RTAS 5 3 2 0

---5 3 2 0

Logged Repair Actions: 2

Registered Notification Tools: 3

Platform diagnostics (ppc64-diag) is an example of a service and productivity tool that writes to servicelog.

The servicelog library is provided by thelibservicelogpackage.

The servicelog commands are provided by theservicelog package. The commands that are typically included are:

log_repair_action

Create a log entry to indicate that a device was repaired.

servicelog

Query and display the contents of the servicelog database.

servicelog_manage

Perform management or maintenance operations on the servicelog database.

servicelog_notify

Add, modify, view, or remove tools to be notified when events are logged in the servicelog database.

(20)

For more information about the servicelog packages, see servicelog: System Service Database (http://linux-diag.sourceforge.net/servicelog/).

Environmental and power management features

POWER8 systems with OPAL firmware provide features for safeguarding your system's environment and power supply. These features are currently provided as a limited technical preview offering.

The following features are included on POWER8 PowerKVM systems running OPAL firmware as a limited technical preview.

Environmental and power warnings (EPOW)

The EPOW feature monitors the environmental and power status of the system. EPOW events are communicated from the system to the firmware and the hypervisor. When potentially dangerous events are detected, the hypervisor takes corrective action to minimize damage to the system. The following events are monitored by EPOW:

v _{Power supply:}

– On uninterruptible power supply (UPS) – Power configuration changes

– Impending power failures – Incomplete power

v _Temperature:

– Ambient temperature issues – Internal temperature issues – Ambient humidity issues

v _Cooling:

– Insufficient cooling

If any of these conditions are detected, the hypervisor notifies the host. The host system can then take corrective action.

Delayed power off (DPO)

On Power systems, you can initiate machine shutdown from either the front operations panel or via the Advanced Systems Management (ASM) interface. Because machines may be running critical workloads that need to be shut down gracefully, DPO provides a safeguard against abrupt shutdowns.

When you initiate a shutdown, the Flexible Service Processor (FSP) sends a DPO initiation command to the OPAL firmware. The OPAL firmware acknowledges the receipt of the DPO command, then informs the hypervisor of the impending system shutdown. The hypervisor starts the process of gracefully bringing down the system, ultimately resulting in the Central Electronic Complex (CEC) power down.

After receiving the acknowledgement from the OPAL firmware for the initial DPO command, the FSP waits for a maximum of 45 minutes to receive a power down command from the hypervisor. If the FSP does not receive a power down command within this 45 minutes, it assumes that there is nothing critical running and powers down the system.

Similar environmental and power management features are available on systems running PowerVM with ® | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |

(21)

Service aids

Service Aids includes a wide variety of commands to help you manage your system.

Table 5. Support for powerpc-utils utilities

Utility

activate_firmware All current versions of the following distributions:

Not applicable

amsstat All current versions of the following distributions:

Not applicable

apport-collect Not applicable All current versions of the following distributions in guests:

v _Ubuntu

bootlist All current versions of the following distributions:

Not supported

drmgr All current versions of the following distributions:

All current versions of the following distributions in guests:

Some functions, including PCI hot plug, may not be fully supported. hvcsadmin All current versions of the following

distributions:

Not applicable

lparstat All current versions of the following distributions:

Not supported

lsdevinfo All current versions of the following distributions:

Not supported

lsprop All current versions of the following distributions:

Also supported on the host system.

||| | |

(22)

Table 5. Support for powerpc-utils utilities (continued) Utility

lsslot All current versions of the following distributions:

Not supported

v _ls-vsci v _ls-veth v _ls-vdev

All current versions of the following distributions:

Not supported

nvram All current versions of the following distributions:

Also supported on the host system. ofpathname All current versions of the following

distributions:

ppc64_cpu All current versions of the following distributions:

Also supported on the host. rtas-dump All current versions of the following

distributions:

rtas_event_decode All current versions of the following distributions:

rtas_ibm_get_vpd All current versions of the following distributions:

Not supported

serv_config All current versions of the following distributions:

(23)

Table 5. Support for powerpc-utils utilities (continued) Utility

set_poweron_time All current versions of the following distributions:

snap All current versions of the following distributions:

v _{Red Hat Enterprise Linux} Note: Thesnapcommand is deprecated in Red Hat Enterprise Linux 7.0. Use thesosreport

command instead.

v _{SUSE Linux Enterprise Server} Note: Thesnap_{command is}

deprecated in SUSE Linux Enterprise Server 12. Use the

supportconfigcommand instead.

v _{Red Hat Enterprise Linux} Note: Thesnapcommand is deprecated in Red Hat Enterprise Linux 7.0. Use thesosreport

command instead.

v _{SUSE Linux Enterprise Server} Note: Thesnap_{command is}

deprecated in SUSE Linux Enterprise Server 12. Use the

supportconfigcommand instead.

v _Ubuntu

Note: Thesnapcommand is deprecated in all current versions of Ubuntu. Use theapport-collect

command instead. sys_ident All current versions of the following

distributions:

uesensor All current versions of the following distributions:

Not applicable

update_flash All current versions of the following distributions:

Supported on the host only.

vscsisadmin All current versions of the following distributions:

Not supported

For Linux distributions currently supported on Power systems, see Linux on Power overview. Service aids commands are provided by thepowerpc-utilspackage. The commands that are typically included are:

activate_firmware

Activate a firmware image that was updated concurrently.

amsstat

Display Active Memory™_{Sharing (AMS) statistics.} |

| | |

(24)

bootlist

View or update the system bootlist stored in NVRAM.

drmgr Perform DLPAR operations on a client LPAR.

hvcsadmin

The hypervisor virtual console server administration utility.

lparstat

Display current LPAR-related parameters, LPAR utilization statistics, and hypervisor information.

lsdevinfo

Display information about virtual devices.

lsslot List DLPAR and hotplug capable slots.

ls-vdev

Display information about virtual SCSI adapters and devices.

ls-veth

Display information about virtual Ethernet devices.

ls-vscsi

Display information about virtual SCSI devices.

nvram Display or modify data that is stored in the non-volatile RAM (NVRAM).

nvsetenv

A wrapper to call various forms of thenvramcommand.

ofpathname

Translate between Open Firmware and logical device names.

ppc64_cpu

Display or set the processor SMT, cores, DSCR, smt-snooze-delay, run mode and frequency settings.

rtas_dump

Display the contents of RTAS events in the/var/log/messages,/var/log/platform, and

/var/log/boot.msgfiles in a human-readable form.

rtas_event_decode

Display the contents of one RTAS event in a human-readable form.

rtas_ibm_get_vpd

Display dynamically changing vital product data.

serv_config

Display and configure system service policies and settings.

set_poweron_time

Set a time in the future for the system to be powered on.

snap Generate a configuration snapshot for service.

sys_ident

Generate unique identification numbers.

uesensor

Display the state of system environmental sensors.

update_flash

Update, manage, or validate firmware.

On certain POWER8 systems , you cannot update your firmware if your system entitlement has expired. You will see the following output when you attempt to run theupdate_flashcommand:

(25)

The selected firmware image cannot be applied.

The Build Date of the firmware image selected is <date>. The System’s Update Access Key Expiration Date is <date>. Please go to http://www.ibm.com/servers/eserver/ess to obtain a replacement update access key.

Note: This information applies only to systems running PowerVM virtualization. This information does not apply to Linux-only POWER8 systems.

Follow the link to the Entitled software support website to update your system.

On systems that have Petitboot installed, you can run theupdate_flashcommand to update your firmware from the Petitboot shell. For more information about Petitboot, see Using Petitboot. The commands that are provided by this package, and their features and usage, might vary by

For more information about thepowerpc-utilspackage, see Powerpc-utils (http://powerpc-utils.sourceforge.net/).

Handling errors in guests with FWNMI

On systems running IBM PowerKVM virtualization, you can use firmware assisted non-maskable interrupts (FWNMI) for error handling and recovery of machine checks in guests.

The FWNMI feature provides firmware support for platform-dependant error recovery for recoverable non-maskable machine check interrupts. Using FWNMI, analysis of and information about interrupts is passed to the guest operating system via QEMU.

PowerVM also has this support for better error recovery for Linux on Power logical partitions. Now, equivalent support is also available for Linux on Power PowerKVM guests. The FWNMI feature is automatically enabled on all guests, regardless of the Linux distribution running on the guest. To activate the FWNMI feature on a guest, issue the following runtime abstraction layer (RTAS) call: ibm.nmi-register

This calls registers the machine check (MC) handler with QEMU. Whenever a guest receives a machine check interrupt, control will go to QEMU first. QEMU will then build memory error information, and will pass it to the guest operating system.

IBM Performance Management for Power Systems

IBM Performance Management for Power Systems™_{provides you with critical information about current} and long-term system utilization trends. It also provides insight on what extra capability your system has, and what upgrades you might need for future applications.

IBM Performance Management for Power Systems enables automated performance analysis and capacity planning for PowerLinux™_{servers. With IBM Performance Management for Power Systems, utilization} information can be automatically collected from the servers with logical partitions (LPARs) that you elect to monitor. You have the choice of transmitting the daily collected data to IBM on a routine basis with IBM Electronic Service Agent™for PowerLinux. You can re-examine your utilization and capacity

environment from up to 24 months prior with ongoing, interactive access. With this information, you can visualize system workloads, and server consolidation and virtualization possibilities.

IBM Performance Management for Power Systems is provided by theibmPMLinuxpackage. | | | | | | | | | | | | | |

(26)

For more information about IBM Performance Management for Power Systems, see IBM Performance Management for Power Systems (http://www-03.ibm.com/systems/power/support/perfmgmt/).

Large page analysis

The IBM Large Page Analysis tool records runtime memory usage and generates a translation lookaside buffer (TLB) miss rate report.

The TLB miss rate report that is generated by the IBM Large Page Analysis tool can show you where using a larger page size might benefit application performance. TheINTERPRETING REPORTSsection of thelpaoverview man page describes the significance of the information in the TLB miss rate report. You can use a larger page size with libhugetlbfs. For more information about libhugetlbfs, see libhugetlbfs (http://libhugetlbfs.sourceforge.net/).

The IBM Large Page Analysis tool is provided by thelpapackage. The commands that are typically included are:

lpa_record

Run an application and record memory statistics by memory region. The recorded data is stored as a collection of trace files in the~/.lpa_logsdirectory for later processing by thelpa_report

command.

Memory regions include heap, stack, text, data, and bss (optional).

lpa_report

Compute the predicted cost in TLB miss rates from trace files that are created by thelpa_record

command for various page size mappings. Page size mappings include 4K, 64K, 16M, and 16G. Run thelpa_recordcommand before you run thelpa_reportcommand.

Note: There is also an overview man page that is called lpafor which there is no command. The commands that are provided by this package, and their features and usage, might vary by

IBM Power RAID adapter utilities (iprutils)

IBM Power RAID (IPR) adapter utilities provide tools that are required by the IBM Power RAID adapter device driver.

With IBM Power RAID adapter utilities, you can configure, update, and query the adapter. The information that you can query includes disk status, disk array status, and Serial-attached SCSI (SAS) path status. You also gather adapter failure information.

IBM Power RAID adapter utilities are provided by theiprutilspackage. The commands that are typically included are:

iprconfig

Configure IBM Power RAID storage adapters, display information about them, and recover adapters and disk units.

Note: Theiprconfig command can be run from the Petitboot shell to configure RAID on systems using PowerKVM virtualization. For more information, see Using Petitboot.

The options of this tool include:

Display hardware status.

(27)

Work with SCSI Bus Configuration.

Set some SCSI bus parameters such is Max Bus Throughput and host SCSI ID.

Work with Driver Configuration.

Adjust device drivers log levels.

Work with disk configuration.

Set device attributes, such as queue depth.

Download microcode.

Download microcode to adapters and SCSI disks.

Create a disk array.

Create a disk array.

Delete a disk array.

Delete existing disk arrays. Data that is stored on the devices is not preserved after you run this command.

Add a device to a disk array.

Add devices of similar capacity to an existing RAID 5 disk array.

Format Device for advanced function/Format Device for JBOD (Just a Bunch Of DASD) function.

Disk devices can either be formatted to 512 bytes/sector or 522 bytes/sector. Devices must be formatted to 522 bytes/sector, also known as advanced function format, to be used in a disk array or as a hot spare. Devices not in a disk array can be formatted to 512 bytes/sector so that they can be used directly by the operating system.

Create a hot spare.

Configure a disk to be a hot spare, which can be used by an adapter to automatically replace a failed device

Concurrent add device.

Concurrently add a SCSI disk to a running system.

Concurrent remove device.

Concurrently remove a SCSI disk from a running system.

Initialize and format disk.

Send a SCSI format command to SCSI disks. Use this option with caution.

Reclaim IOA cache storage.

Note: IOA stands for I/O Adapter.

This option is for IBM hardware service personnel. This option is potentially dangerous and might delete data from the non-volatile write cache on an adapter.

Rebuild disk unit data.

Reconstruct a device as an active array member.

Note: This option is generally used following concurrent maintenance after a failing array member device was replaced.

Work with Resources Containing Cache Battery Packs.

View the status of the Cache Battery on resources that contain battery packs. Use this option during maintenance actions on resources that contain battery packs.

Analyze Log.

View the error messages that are logged by the IPR device driver.

Information message reported by iprconfig

You might receive an error message in the following situations:

(28)

v _{You ran the iprconfig utility from a console while concurrently removing a physical device}

from the system.

The error message is similar to this example: EPOW <0x6240040000000b8 0x0 0x0>

RTAS: event: 5, Type: EPOW, Severity: 1

This message is for your information only. No action is necessary.

iprdump

Gather and dump information in the event of an adapter failure. By default, the dump data is saved in/var/log/iprdump.DUMP_ID, where DUMP_ID is the id of the dump. Theiprdump

command writes an entry to the system error log when it creates a dump. Theiprutilspackage provides an/etc/init.d/iprdumpscript to start the iprdumpcommand as a service during boot time.

iprinit Initialize IBM Power RAID adapters and devices for optimal performance, and load any configurations that are saved by theiprconfigcommand. The iprutilspackage provides an

/etc/init.d/iprinitscript to start theiprinit command as a service during boot time.

iprupdate

Attention: Deprecated. Use theiprconfigcommand to update and manage device microcode. The commands that are provided by this package, and their features and usage, might vary by

For more information about theiprutilspackage, see IPR Linux device driver (http:// iprdd.sourceforge.net/).

Note: This site includes information for both the IPR Linux device driver (iprdd) and theiprutilspackage. For more information about SAS RAID controllers for Linux on your Power Systems, see theSAS RAID

controllers for Linuxtopic corresponding to your system in the Systems Hardware Information Center.SAS

RAID controllers for Linuxcontains subtopics that illustrate various options of the iprconfigcommand.

POWER6 systems http://www.ibm.com/support/knowledgecenter/POWER6/arebk/sascontroller_kickoff.htm POWER7 Systems™ http://www.ibm.com/support/knowledgecenter/POWER7/p7ebk/p7ebkkickoff.htm PowerLinux systems http://www.ibm.com/support/knowledgecenter/POWERLINUX/p7ebkl/p7ebkkickoff.htm POWER8 http://www.ibm.com/support/knowledgecenter/8247-22L/p8ebk/commontasks.htm

IBM Electronic Service Agent

IBM Electronic Service Agent, along with the IBM Electronic Support website, make up IBM Electronic Services.

This topic collection provides information about installing, activating, configuring, using, and troubleshooting IBM Electronic Service Agent on PowerLinux servers.

The most current version of this information is in the IBM Knowledge Center for Linux. To access this information, use the following web address:

(29)

http://www-01.ibm.com/support/knowledgecenter/linuxonibm/liaao/liaaokickoff.htm.

Diagnosing RTAS events

You can install and use the ppc64-diag, libservicelog, servicelog, and powerpc-utils packages to diagnose RTAS (Run Time Abstraction Services) events.

RTAS events (also known as platform events) might occur while your system is booting or running. RTAS events might be logged in the following places:

v _{The console and the kernel ring buffer} v _{The servicelog database}

v _The_{/var/log/platform}_file

Displaying RTAS events in the kernel ring buffer

The kernel displays RTAS events in the console, and captures them in the kernel ring buffer. To display the kernel ring buffer, run the following command:

# dmesg

The following example shows RTAS events that are reported in the console and kernel ring buffer: RTAS: event: 2340, Type: Platform Error, Severity: 2

RTAS: event: 2341, Type: Dump Notification Event, Severity: 1

The event numbers displayed as 2340 and 2341 in the example identify events on your system. They have no diagnostic meaning.

Displaying RTAS events in the servicelog database

The ppc64-diag package includes the rtas_errd daemon, which logs RTAS events to the servicelog database with the libservicelog package. The servicelog package provides commands for viewing the database. Install each package. See ppc64-diag and libservicelog/servicelog for information about these packages.

You can display a summary of servicelog events to determine whether any RTAS events are saved to the servicelog database. To display the summary, run the following command:

# servicelog

The following sample output shows that there are 5 RTAS events: Servicelog Statistics:

There are 3 open events requiring action. Summary of Logged Events:

Type Total Open Closed Info

RTAS 5 3 2 0

---5 3 2 0

Logged Repair Actions: 2

Registered Notification Tools: 3

To display the servicelog database, run the following command: # servicelog --dump

(30)

Servicelog ID: 4

Log Timestamp: Fri Jul 27 04:51:31 2012 Event Timestamp: Fri Jul 27 08:51:29 2012 Update Timestamp: Fri Jul 27 04:51:31 2012

Type: Power Platform (RTAS) Event

Severity: 3 (EVENT)

Platform: ppc64

Model/Serial: 8406-71Y/108B7AA

Node Name: abc.ibm.com

Reference Code: B7004400 Serviceable Event: No Predictive Event: No

Disposition: 0 (Recoverable) Call Home Status: 0 (None Needed)

Status: Closed

Action Flags: 2000

Event Type: 228 - Dump Notification Event

Kernel ID: 2

Platform ID: 50142eee Creator ID: H - Hypervisor

Subsystem ID: 82 - Platform firmware

RTAS Severity: 00 - Informational or non-error event Event Subtype: 08 - Dump Notification

Extended Reference Codes:

2: 00000000 3: 00000000 4: 00000000 5: 00000000 6: 00000000 7: 00000000 8: 00000000 9: 00000000 Description:

Platform Firmware Informational (non-error) Event. Refer to the system service documentation for more information.

A platform dump was generated and downloaded to the filesystem (1739921 bytes): /var/log/dump/FSPDUMP.108B7AA.AA000000.20120727044812

For information associated with the reference code in an RTAS event logged in servicelog, search for the reference code in Knowledge center.

Displaying RTAS events logged in the /var/log/platform file

Install the powerpc-utils package, which provides thertas_dumpcommand. See powerpc-utils for information about the package.

You can display the RTAS events logged in the/var/log/platformfile in two ways:

v _{View the file in a text editor. The events display without formatting.}

v _{Run the}_{rtas_dump} _{command to display the events with formatting. For example:}

rtas_dump -f /var/log/platform

The following sample output shows several RTAS events logged in the/var/log/platform file: ==== RTAS Event Dump (1) Begin ======================================

Version: 00000006 Severity: 00000001 (Event)

Type 000000e4 (Dump Notification Event)

Status: new

==== Private Header =================================================

Date: 27 Jul 2012

Time: 4:50:52:5

Creator ID: PHyp (H).

Creator Subsystem Version: 0000000000000000.

Platform Log ID: 50142eee Log Entry ID: 820001fc

==== User Header ==================================================== Subsystem ID: 00000082 (Platform Firmware)

(31)

Event Type: 00000008 Dump notification.

Event Severity: 00000000 Informational or non-error event,

Action Flag: 00002000 Report Externally, (HMC and Hypervisor). ==== Primary SRC Section ============================================ Platform Data:

0x0000: 00000100 000048 [...H. ]

2: 00000000 3: 00000000 4: 00000000 5: 00000000 6: 00000000 7: 00000000 8: 00000000 9: 00000000

Primary Reference Code: "B7004400 "

==== Unknown Section ================================================

Section ID: EH Section Length: 0000004c

Version: 00000001 Sub_type: 00000000

Component ID: 00004552 Raw Section Data:

0x0000: 38343036 2d373159 31303842 37414120 [8406-71Y108B7AA ] 0x0010: 00000000 41583731 305f3131 39000000 [....AX710_119...] 0x0020: 00000000 30303034 30373031 30343036 [....000407010406] 0x0030: 30313836 00000000 00000000 00000000 [0186...] 0x0040: 00000000 [... ] ==== Machine Type =================================================== Model/Type: 8406-71Y (tttt-mmm)

Serial Number: 108B7AA

==== Dump Locator section ===========================================

Dump ID: 00000001 Dump Field Format: ascii

Dump Location: Partition Dump Size: 0000000012b4d790

==== Unknown Section ================================================

Section ID: LP Section Length: 00000018

Version: 00000001 Sub_type: 00000000

0x0000: 00000401 00000000 00000000 00010000 [...] ==== RTAS Event Dump (1) End ======================================== ==== RTAS Event Dump (2) Begin ======================================

Version: 00000006 Severity: 00000001 (Event)

Type 000000e4 (Dump Notification Event)

Status: new

==== Private Header =================================================

Date: 27 Jul 2012

Time: 4:51:29:71

Creator ID: PHyp (H).

Creator Subsystem Version: 0000000000000000.

Platform Log ID: 50142eee Log Entry ID: 820001ff

==== User Header ==================================================== Subsystem ID: 00000082 (Platform Firmware)

Event Data 00000003

Event Type: 00000008

(32)

Event Severity: 00000000 Informational or non-error event,

Action Flag: 00002000 Report Externally, (HMC and Hypervisor). ==== Primary SRC Section ============================================ Platform Data:

0x0000: 00000100 000048 [...H. ]

2: 00000000 3: 00000000 4: 00000000 5: 00000000 6: 00000000 7: 00000000 8: 00000000 9: 00000000

Primary Reference Code: "B7004400 "

==== Unknown Section ================================================

Section ID: EH Section Length: 0000004c

Version: 00000001 Sub_type: 00000000

0x0000: 38343036 2d373159 31303842 37414120 [8406-71Y108B7AA ] 0x0010: 00000000 41583731 305f3131 39000000 [....AX710_119...] 0x0020: 00000000 30303034 30373031 30343036 [....000407010406] 0x0030: 30313836 00000000 00000000 00000000 [0186...] 0x0040: 00000000 [... ] ==== Machine Type =================================================== Model/Type: 8406-71Y (tttt-mmm)

==== Dump Locator section ===========================================

Dump ID: aa000000 Dump Field Format: ascii

Dump Location: Partition Dump Size: 00000000001a8c91

==== Unknown Section ================================================

Section ID: LP Section Length: 00000018

Version: 00000001 Sub_type: 00000000

0x0000: 00000401 00000000 00000000 00010000 [...] ==== RTAS Event Dump (2) End ======================================== ==== RTAS Event Dump (3) Begin ======================================

Version: 00000006 Severity: 00000002 (Warning)

Type 000000e0 (Platform Error)

Status: unrecoverable new

==== Private Header =================================================

Date: 27 Jul 2012

Time: 4:48:6:8

Creator ID: Service Processor (E). Creator Subsystem Name: .

Platform Log ID: 50142eee Log Entry ID: 50142eee

==== User Header ==================================================== Subsystem ID: 00000000

Event Data 00000003

Event Type: 00000000

Unknown event type (0). Event Severity: 00000040 Unrecoverable error, general.

(33)

Action Flag: 0000a902 Unknown action flag (0x0000a902). ==== Primary SRC Section ============================================ Platform Data:

0x0000: 04000900 000048 [...H. ]

2: 000000f0 3: 00000c00 4: 00000000 5: 20000000 6: 070c001c 7: 00000000 8: 00000000 9: 00000000

Primary Reference Code: "A1003000 "

==== Unknown Section ================================================

Section ID: EH Section Length: 00000060

Version: 00000001 Sub_type: 00000000

0x0000: 38343036 2d373159 31303842 37414100 [8406-71Y108B7AA.] 0x0010: 00000000 41583731 305f3131 39000000 [....AX710_119...] 0x0020: 00000000 62313130 39625f31 3139302e [....b1109b_1190.] 0x0030: 37313200 00000000 00000000 00000000 [712...] 0x0040: 00000014 41313030 33303030 5f303030 [....A1003000_000] 0x0050: 30304330 30000000 [00C00.... ] ==== Unknown Section ================================================

Section ID: UD Section Length: 0000009c

Version: 00000002 Sub_type: 00000004

0x0000: 00003300 2f6f7074 2f666970 732f6269 [..3./opt/fips/bi] 0x0010: 6e2f6475 6d707379 7374656d 00000000 [n/dumpsystem....] 0x0020: 00000000 00000000 00000000 00000000 [...] 0x0030: 00000000 00000000 00000000 00000000 [...] 0x0040: 00000000 00000000 00000000 00000000 [...] 0x0050: 00000000 00000000 66697073 3731322f [...fips712/] 0x0060: 62313130 39625f31 3139302e 37313200 [b1109b_1190.712.] 0x0070: 00000000 00000000 00000001 00000002 [...] 0x0080: 00000804 00000005 0000000f 000131cc [...1.] 0x0090: 00000000 [... ] ==== Machine Type =================================================== Model/Type: 8406-71Y (tttt-mmm)

==== Unknown Section ================================================

Section ID: SW Section Length: 00000014

Version: 00000002 Sub_type: 00000001

Component ID: 0000f000 Raw Section Data:

0x0000: 00000b00 00030008 00000001 [... ] ==== RTAS Event Dump (3) End ========================================

For information associated with the primary reference codes in each RTAS event logged in the

/var/log/platformfile, search for the reference code in Knowledge center.

Collecting support data

You can collect support data to facilitate addressing hardware or system issues. You can collect Linux operating system support data by running thesnapcommand: snap -h

Linux. Managing your server with service and productivity tools

Linux

Managing your server with service and productivity tools

Linux

Managing your server with service and productivity tools

Contents

Managing your server with service and

productivity tools

. . . 1

Notices

. . . 33

Code license and disclaimer

information . . . 35

Managing your server with service and productivity tools

What's new in Managing your server with service and productivity

tools

IBM Serviceable Event Provider for PowerKVM systems

Extended error handling capabilities

Firmware assisted non-maskable interrupts

Environmental and power management features

Reliability, availability, and service tools for PowerKVM environments

Stand-alone diagnostics

Installing service and productivity tools

Installing tools by using a server package manager

Installing specific tools by using the rpm command

Installing tools by using the IBM Installation Toolkit

Displaying package man pages

Middleware and infrastructure

DynamicRM

ServiceRM

Service and productivity tools

Hardware inventory

Inventory scout

Platform diagnostics (ppc64-diag)

Platform diagnostics for systems using PowerVM virtualization

Enclosure diagnostics (

diag_encl

)

Light path diagnostics

Example: Locating a faulty Ethernet card

Platform diagnostics for systems using PowerKVM virtualization and OPAL

firmware

Extended error handling

servicelog

Environmental and power management features

Service aids

Handling errors in guests with FWNMI

IBM Performance Management for Power Systems

Large page analysis

IBM Power RAID adapter utilities (iprutils)

IBM Electronic Service Agent

Diagnosing RTAS events

Displaying RTAS events in the kernel ring buffer

Displaying RTAS events in the servicelog database

Displaying RTAS events logged in the /var/log/platform file

Collecting support data
