CATALOG. (+39)

(1)

(2)

MOTOCROSS

ENDURO

SUPERMOTO

COLOR

KEY

RED - ROSSO

R

BLUE - BLU

B

GOLD - ORO

G

SILVER - ARGENTO

S

BLACK - NERO

K

GREEN - VERDE

N

ORANGE - ARANCIONE

O

HOW TO CHOOSE A COLOR

Es. AA-0000-HD.R

to indicate the choice

(3)

NISSIN

COVERS

FRONT

REAR

HANDGUARD MOUNTS

ATTACCHI PER PARAMANI CHIUSI

MODELLO - MODEL CODICE - CODE

Motard for Ø 22 handlebars MK-5900-UN

MK-5901-UN Motard for Renthal Twin Wall

Motard for Ø 28,6 handlebars

Cross/Enduro for Ø 22 handlebars

MK-5902-UN EK-5909-UN Cross/Enduro for Ø 28,6 handlebars EK-5910-UN Cross/Enduro for Renthal Twin Wall EK-5911-UN

- Different bushing system to fit on all kind of handlebar - The best solution between strength and lightness - M8 screws to guarantee a perfect fix of the hand guard - Made of 6082 aluminum alloy

FRONT MASTER CYLINDER COVER

COPERCHIO POMPA FRENO ANTERIORE

Nissin for Honda

Nissin for Kawasaki - Suzuki – Yamaha …/’07

AA-5011-NS AA-5007-NS Nissin for Yamaha ’08/…

Brembo

AA-5012-NS AA-5014-BR

Magura AA-5034-MG

- CNC machined from solid part - Made of 6082 aluminum alloy

REAR MASTER CYLINDER COVERS

COPERCHIO POMPA FRENO POSTERIORE

Nissin for Honda

Nissin for Kawasaki and Suzuki

AA-1029-NS AA-1019-NS Nissin for Yamaha

Brembo

AA-1030-NS AA-1039-BR

CODICE - CODE

AA-1020-NS

REAR MASTER CYLINDER COOLING COVER

COPERCHIO POMPA FRENO POSTERIORE ALETTATO

MODELLO - MODEL

Nissin for Kawasaki and Suzuki

- Improve the braking liquid cooling

- Improve the braking system performance and cooling - Made of 6082 aluminum alloy

(4)

FORK

ADJUSTERS

USD

2010

REAR MASTER CYLINDER RESERVOIR

SERBATOIO AGGIUNTIVO POMPA FRENO POSTERIORE

Nissin for Kawasaki and Suzuki Brembo

AK-1021-NS AK-1040-BR

- Improve the oil pump capacity, to reach a better circulation of braking liquid - Improve the braking system performance

SHOCK PRE-LOAD RING

GHIERA PRECARICO MOLLA

Kayaba Ø 60 Ohlins TTX AK-3029-KB AK-3030-HN Showa Ø 60 WP (no PDS) AK-3028-SW AK-3057-WP

- Made to have a smooth and precise pre-load adjustment

- Works with hands only, no hammer and punch, just a 4mm hex key to lock and unlock - Made of 6082 aluminum alloy

REGOLAZIONE RAPIDA REGISTRO COMPRESSIONE FORCELLE

Showa USD closed cartridge Ø 47 Showa 2010 closed cartridge

AK-2002-SW AK-2024-SW

Kayaba USD closed cartridge Ø 48 Ak-2023-KB

- Allow a quick compression adjust simply with your hand, not using tools - Assembled with inner O-ring for perfect precision and cleanliness - Safe fixing using stainless steel AISI 304 grub screws

- Made of 7075 T6 Ergal and 6082 aluminum alloy

(5)

MX - EN FOOTPEGS

PEDANE CROSS - ENDURO

Beta All Models …/’14 Gas Gas All Models …/’14

CK-1915-UN CK-1916-UN Honda CR 125/250 '02-'07 - CRF 250/450 '02-'15

Husaberg All Models …/’14

CK-1901-UN CK-1914-UN Husqvarna All Models '99-'13

Kawasaki KX/KXE 125/250 '05-'07

CK-1905-UN

Husqvarna All Models '15 CK-1921-UN

CK-1906-UN Kawasaki KX-F/KXE-F 250 '06-'13 - 450 '07/'11 Kawasaki KX-F/KXE-F 250 '04-'05 - 450 '06 CK-1907-UN CK-1908-UN Kawasaki KX-F 250 ‘15 - 450 ‘12/’15 KTM All Models '98-'15 CK-1920-UN CK-1904-UN Sherco All Models …/'15

Suzuki RM-Z/RMZ-E 250 '04-'06 CK-1913-UN CK-1909-UN Suzuki RM-Z/RMZ-E 250 '07-'08 Suzuki RM-Z/RMZ-E 450 '05-'08 CK-1910-UN CK-1911-UN Suzuki RM/RME 125/250 '03-'08

Suzuki RM-Z/RMZ-E 250/450 ’09 (color on request) (1) Suzuki RM-Z/RMZ-E 250/450 ‘10-’13 (color on request) (1) TM All Models …/'07 Yamaha YZ-F/WR-F 250-450 '98-'15 Yamaha YZ/WR 125/250 '97-'12 CK-1912-UN CK-1918-SZ CK-1919-SZ CK-1917-UN CK-1902-UN CK-1903-UN

MAXI ENDURO FOOTPEGS

PEDANE MAXI ENDURO

(1) stock attachment version, without possibility of two position wiht bushing

- Made of 7075 T6 Ergal aluminum alloy

- Interchangeable stainless steel grub screw AISI 304 with two different profile - The bushing allow two fitting positions, standard or lower, for taller rider - Comes complete of springs, spacers to adjust the tilt and assembly kit - Extreme grip in every situation of use

KTM Enduro/Adventure CK-1904-UN

ALL FOOTPEGS MODELS ARE AVAILABLE IN THE FOLLOWING COLORS

FOOTPEGS REPLACEMENT PARTS

RICAMBI PEDANE

Stainless steel grub screw – kit 30 pieces Springs pair

CD-7000-UN CD-7001-UN Stainless steel bushings pair Pedane - Footpegs

(6)

FRONT QUICK AXLE WHEEL EXTRACTOR

ESTRATTORE PERNO RUOTA ANTERIORE

Honda CRF 250/450 Kawasaki KX-F 250/450 EK-4010-KW EK-4010-KW KTM all models Suzuki RM-Z 250/450 EK-4020-KT EK-4010-KW

Yamaha YZ-F/WR-F 250/450 EK-4010-KW

REAR QUICK AXLE WHEEL EXTRACTOR

ESTRATTORE PERNO RUOTA POSTERIORE

Honda CRF 250/450 Kawasaki KX-F 250/450 EK-4007-KW EK-4007-KW Suzuki RM-Z 250/450 Yamaha YZ-F/WR-F 250/450 EK-4007-KW EK-4007-KW

- Very fast and simple wheel disassembly

- Designed for enduro competion when the tyre change time is essential - Assembled in the axle's hole with an expansion system

- Position and shape designed to avoid the contact with stone and obstacles - Made of 7075 T6 Ergal aluminum alloy

FRONT WHEEL AXLE NUT

DADO PERNO RUOTA ANTERIORE

Honda CRF 250/450 Husqvarna All Models

EA-4015-HD EA-4017-HQ Kawasaki KX-F 250/450 Suzuki RM 125 RM-Z 250/450 EA-4009-KW EA-4009-KW Yamaha WR-F 250/450 Yamaha YZ-F 250/450 EA-4013-YH EA-4022-YH

REAR WHEEL AXLE NUT

DADO PERNO RUOTA POSTERIORE

Honda CRF 250/450 Kawasaki KX-F 250/450 EA-4008-KW EA-4008-KW Suzuki RM-Z 250/450 Suzuki RM 125 EA-4008-KW EA-4014-SZ Yamaha WR-F 250/450 Yamaha YZ-F 250/450 EA-4012-YH EA-4008-KW

- Closed top to protect the axle's thread - Made of 7075 T6 Ergal aluminum alloy

REAR BRAKE CONNECTING ROD

TIRANTE FRENO POSTERIORE

Honda CR 125/250 '00/'07 CRF 150/250/450 '03-’15 Kawasaki KX 125/250 '00-‘13 KXF 250/450 '04-’15 CK-0029-UN CK-0043-UN Suzuki RM 125/250 '00-'13 RMZ 250 '04-'06 Suzuki RMZ 250 '07-'13 450 '05-'15 CK-0042-UN CK-0041-UN Yamaha YZ 125/250 '00-‘15 YZF 250/450 '05-’15 Yamaha WR 125/250 '04-‘15 WRF 250/450 '05-‘15 CK-0041-UN CK-0041-UN

- The best solution between strength and lightness

- Improve the control on the rear brake thanks to the loop that give more precision - Made of 6082 aluminum alloy

(7)

ADJUSTABLE LINKAGE ARM

TIRANTE LEVERAGGIO REGOLABILE

KTM SX/SXF 125-450 ‘11-’14 / Husqvarna ‘14 All models

Yamaha YZ-F 250/450 ‘09-’15 Sherco SE 2.5/3.0/4.5/5.1

CHAIN GUIDE

CRUNA PASSACATENA

Honda CRF 250R/250X/450R '07-'14 Husqvarna all models 4T 250/450/510 '04-’13

CK-1024-HD CK-1038-HQ KTM all models '90-'07 no SX '07 Suzuki RM 2T ‘99/’08 RM-Z 250 '07-’15 RM-Z 450 ‘05/’15 CK-1025-KT CK-1022-SZ

Yamaha YZ-F/WR-F 250/450 '07-'14 CK-1023-YH

Yamaha WR-F 250/450 '98-'06 CK-1022-SZ

- Special polymeric charged material for high resistance - Designed to avoid cracks and folds that can block the chain

INCREASED IMPELLER KIT

KIT GIRANTE POMPA ACQUA MAGGIORATA

KTM 250/300 2T '04-'15 and Husaberg 250/300 2T EK-0905-KT KTM 350 4T SX-F ‘11/’15 e EXC ‘12/’15 - Freeride 350 EK-0906-KT

- Comes in complete kit: bigger water fan, spacer, O-Ring and longer screws - Improve the cooling liquid circulation

- Improve the system capacity

- Shape and detail designed to avoid the formation of bubbles in the cooling circuit - Made of 6082 aluminum alloy

- Design to change the rear suspension progression, to have more stability on high speed or more reactivity on slow speed

- It can be also used to modify the bike’s height

- Allows an adjustment from -5 mm to +5 mm of the center-to-center distance

- The octagonal inserts are sold separately too, drilled in standard or in customized positions - Comes in kit with a pair of inserts (specify the code for the inserts you choose) and with special bearings and seals (different from the stocks)

- Made of 2024 aluminum alloy

CK-3100-KT

CK-3095-YH CK-3090-SH

(8)

ADJUSTABLE LINKAGE ARM INSERTS

INSERTI TIRANTE LEVERAGGIO REGOLABILE

Honda standard Honda ± 2 mm Honda ± 1,5 mm CD-3041-HD CD-3061-HD CD-3060-HD Honda ± 3 mm Honda ± 5 mm CD-3042-HD CD-3043-HD Suzuki/Sherco standard CD-3082-KW Suzuki/Sherco ± 1,5 mm Suzuki/Sherco ± 3 mm Suzuki/Sherco ± 2 mm Kawasaki standard Kawasaki ± 1,5 mm Kawasaki ± 5 mm Kawasaki ± 3 mm CD-3083-KW CD-3085-KW CD-3084-KW Suzuki/Sherco ± 5 mm Yamaha standard CD-3044-SZ CD-3058-SZ Yamaha ± 3 mm CD-3059-SZ Yamaha ± 5 mm GasGas ± 1,5 mm GasGas standard CD-3045-SZ CD-3051-YH CD-3046-SZ GasGas ± 3 mm GasGas ± 5 mm CD-3052-YH CD-3053-YH CD-3047-GG CD-3062-GG CD-3048-GG CD-3049-GG

LINKAGE

ARM

FRAME SIDE

LONGER

_{- Bike more steady at high speeds}

HOLES DISTANCE

- Lower backside

- Bike more more agile at low speeds

- Higher backside

SHORTER

HOLES DISTANCE

OCTAGONAL INSERTS PAIR

COPPIA INSERTI OTTAGONALI

- Every pair of inserts (except the one in standard position) allows two adjusting positions, increases or decreases the holes’ distance

- Are available on request inserts with holes eccentricity customized - Made of stainless steel AISI 303

- Spare parts that have to be fitted with the older version of adjustable linkage arm

KTM SX/SXF 125-450 ‘11-’14 / Husqvarna ‘14 All models ± 0 mm

CA-3101-KT

CA-3103-KT CA-3102-KT

Sherco SE 2.5/3.0/4.5/5.1 ± 0 mm CA-3104-KT CA-3091-SH Sherco SE 2.5/3.0/4.5/5.1 ± 1 mm CA-3092-SH Sherco SE 2.5/3.0/4.5/5.1 ± 2 mm Yamaha YZ-F 250/450 ‘09-’15 ± 0 mm Sherco SE 2.5/3.0/4.5/5.1 ± 3 mm CA-3093-SH CA-3096-YH CA-3094-SH Yamaha YZ-F 250/450 ‘09-’15 ± 1 mm Yamaha YZ-F 250/450 ‘09-’15 ± 2 mm CA-3097-YH CA-3098-YH Yamaha YZ-F 250/450 ‘09-’15 ± 3 mm CA-3099-YH

(9)

OIL FILLER PLUG

TAPPO CARICO OLIO

Honda CR 125/250 '00-'07 CRF 250/450 ‘02-’15 Honda CRF 250 ‘10-’15 (with dip stick)

CA-0031-HD CA-0037-HD Honda CRF 450 ‘09-’15 (with dip stick)

Honda CRE-X 250/450

CA-0067-HD CA-0053-HD Honda CRE-X 250/450 (with dip stick)

Husqvarna all 4T '03/’12 CA-0054-HD CA-0050-HQ Kawasaki KX 250 KXF 250/450 '04-'15 KTM SX 125/250 SXF 250/450 EXC 125/250 EXCF 250/450 '00/'15 CA-0017-KW CA-0033-KT Sherco SE 2.5/3.0/4.5/5.1 Suzuki RMZ 250 '04-'06 EA-0057-SH CA-0017-KW Suzuki RM 125/250 '00/'13 RMZ 250 '07/'15 450 '05-'15 Yamaha WR-F/YZF 250/450 '03-'15 YZ 125/250 '00-'15 CA-0018-SZ CA-0032-YH - Hexagonal spanner 10 or 14 mm

- With a hole designed to fit the safe wire - Made of Ergal 7075 aluminum alloy

ENGINE PLUGS "SMALL"

TAPPO PICCOLO ACCENSIONE

Honda CRF 250 Kawasaki KX-F 250/450 CA-0038-HD CA-0019-KW Suzuki RM-Z 250/450 Yamaha WR-F 250 CA-0022-SZ EA-0039-YH

- Made of Ergal 7075 aluminum alloy

ENGINE PLUGS "BIG"

TAPPO GRANDE ACCENSIONE

Kawasaki KX-F 250 Kawasaki KX-F 450 CA-0020-KW CA-0021-KW Sherco SE 2.5/3.1 Suzuki RM-Z 250/450 EA-0069-SH CA-0023-SZ Yamaha WR-F 250 EA-0040-YH - Hexagonal spanner 10 or 14 mm - Made of Ergal 7075 aluminum alloy

ENGINE INSPECTION PLUGS

TAPPO ISPEZIONE MOTORE

Honda CRF 250/450 clutch carter Honda CRF 250 cylinder head

CA-0051-HD CA-0038-HD

- Made of Ergal 7075 aluminum alloy - Standard 6 mm hex socket key - Racing style for your engine

(10)

TUBES PLUG

TAPPO VALVOLA CAMERA ARIA

ALL MODELS - TUTTI I MODELLI AK-4011-UN

- A detail for racing style on your bike - Made of 2011 aluminum alloy

TUBE STOPPER LIT

DADO E RONDELLA PER FERMA COPERTONE

ALL MODELS M8 CH 12 - TUTTI I MODELLI AK-4900-UN

- Close top to protect the thread from dirt and crash

- Ideal for a quick disassembly of the stopper for the tyre change - Comes with the nylon or alu alloy washer

INCREASED CARBURETOR SUMP PLUG

TAPPO VASCHETTA MAGGIORATO

Keihin FCR AA-0107-KH

- Designed to increase the fuel quantity around the main jet

- Avoid any carburation lack due to strong jolts, as at jumps landing or on big bumps - Made of aluminum allot 2011

CARBURETOR IDLE ADJUSTMENT SCREW

VITE REGOLAZIONE MINIMO CARBURATORE

Keihin PWK Ø33/39 AA-0001-KH

- CNC machined from solid part

- Shape designed and manufactured for the adjustment by hand without the use of tools - Made of 7075 T6 aluminum alloy

CARBURETOR MIXTURE ADJUSTMENT SCREW

VITE REGOLAZIONE ARIA CARBURATORE

Keihin PWK Ø33/39 AA-0068-KH

(11)

TRIPLE CLAMPS WITH

ADJUSTABLE OFFSET

(12)

TRIAL

COLOR

KEY

RED - ROSSO

R

BLUE - BLU

B

GOLD - ORO

G

SILVER - ARGENTO

S

BLACK - NERO

K

GREEN - VERDE

N

ORANGE - ARANCIONE

O

HOW TO CHOOSE A COLOR

Es. AA-0000-HD.R

to indicate the choice

(13)

STANDARD FOOTPEGS PAIR

COPPIA PEDANE STANDARD

Without steel inserts With steel inserts

TK-1004-UN TK-1005-UN

- Classic design, good grip in most situations - Made of 7075 T6 Ergal aluminum alloy

REARWARD 7 MM FOOTPEGS PAIR

PEDANE ARRETRATE 7 mm

TK-1052-UN TK-1053-UN

- 7 mm rearward position to get more weight on the rear wheel - Made of 7075 T6 Ergal aluminum alloy

REARWARD 14 MM FOOTPEGS PAIR

PEDANE ARRETRATE 14 mm

TK-1006-UN TK-1007-UN

- 14 mm rearward position to get more weight on the rear wheel - Made of 7075 T6 Ergal aluminum alloy

FOOTPEGS MY 2009 PAIR

COPPIA PEDANE MODELLO “2009”

TK-1000-UN TK-1001-UN

- Designed to slide perfectly on every obstacles - Large central hole to allow a perfect mud evacuation - Made of 7075 T6 Ergal aluminum alloy

REARWARD 5 MM FOOTPEGS MY 2009 PAIR

COPPIA PEDANE MODELLO “2009” ARRETRATE 5 mm

TK-1003-UN TK-1002-UN

- Designed to slide perfectly on every obstacles

- 5 mm rearward position to get more weight on the rear wheel - Large central hole to allow a perfect mud evacuation

(14)

FOOTPEGS HOLDERS

COPPIA PORTAPEDANE

Montesa 4RT Montesa 315

TK-1010-MT TK-1026-MT

- Designed to be strong and to slide on rocks and obstacles - Made of 7075 T6 Ergal aluminum alloy

SKID ENGINE PLATE

PIASTRA PARAMOTORE

- Larger than the stock to improve protection of the engine’s carter and the frame in the footpegs attachment area

- Made of 2024 Avional aluminum alloy

- All the bash plates are ready to fit the Steel pawls kit - Colored anodization treatment on request

- Custom logo or name on the front side of the plate on request Beta EVO Gas Gas TA-1059-BT TA-1060-GG Jotagas Montesa TA-1061-JT TA-1063-MT Ossa Sherco TA-1062-SS TA-1058-SH

SKID ENGINE PLATE STAINLESS STEEL PAWLS KIT

KIT DENTI IN ACCIAIO PER PIASTRA PARAMOTORE

Kit 10 pcs (Beta/Montesa/Sherco) Kit 6 pcs (GasGas/Jotagas/Ossa)

TK-1951-UN TK-1952-UN

- For the Avional made skid engine plates - Made of stainless steel AISI 304

(15)

REAR BRAKE BUSHING

BOCCOLA FRENO POSTERIORE

Kit bushing + cap Montesa 4RT TK-1953-MT

- Special anodized hard treatment to improve endurance and strenght - Made of 7075 T6 Ergal aluminum alloy

SWING ARM COVERS

COPPIA PARAPOLVERE FORCELLONE

Montesa 4RT TA-4016-MT

REAR WHEEL NUTS

TIRARAGGI RUOTA POSTERIORE

Single nut TA-4001-MT

Kit for one wheel (32 nuts+1) TK-4902-MT

- Plastic deformation thread to improve strenght

- For wheels with nuts in the spoke’s middle (Beta, GasGas, Jotagas, Montesa, Sherco) - Made of 7075 T6 Ergal aluminum alloy

CARTER GUARD

PROTEZIONE CARTER

- A sure and safe protection for the engine carter from chain crashes - Made of 7075 T6 Ergal aluminum alloy

REAR SHOCK LINK ARMS

BIELLETTE LEVERAGGIO

Beta TA-3021-BT

Beta + bearings TA-3022-BT

Gas Gas …/’11 TA-3019-GG

Gas Gas …/’11 + bearings TA-3020-GG

Gas Gas ’12/... TA-3063-GG

Gas Gas ‘12/... + bearings TA-3064-GG

Montesa 4RT + bearings TA-3002-MT

Linkage arm shelter Montesa 4RT TA-3001-MT

Sherco …/’11 TA-3005-SH

Sherco …/’11 + bearings TA-3007-SH

Sherco ‘12/... - Scorpa 2014 TA-3054-SH

Sherco ‘12/... - Scorpa 2014 + bearings TA-3055-SH

- Extremly strong and lightweight, with shapes designed to avoid contact with obstacles - The 7075 T6 3mm thick made shelter for Montesa link arm, protects the linkage for long and safe life of the part

(16)

REAR SHOCK LINKAGE SYSTEM

TRIANGOLATURA LEVERAGGIO

Beta

Beta + bearings

TA-3032-BT TA-3039-BT Montesa 4RT (plates pair)

Sherco …/’11

TA-3023-MT TA-3011-SH

- Made of 7075 T6 Ergal aluminum alloy and 2024 aluminum alloy

TITANIUM SCREW KIT FOR SHOCK LINK

KIT VITERIA TITANIO LEVERAGGIO

Beta Gas Gas

TK-3903-BT TK-3906-GG Jotagas + rear wheel axle bolt

Jotagas + rear wheel axle bolt - Stainless steel AISI 303

TK-3904-JT TK-3905-JT Montesa 4RT Sherco - Scorpa ‘14 TK-3900-MT TK-3901-SH

- Screws made by CNC machining of solid Titanium parts (Ti-6Al-4V ASTM gr.5) - The kits come complete of flange lock nuts

REAR WHEEL SPACERS

COPPIA DISTANZIALI RUOTA POSTERIORE

Beta, Sherco (with AJP/BK rear master cylinder) and Scorpa TA-4019-SH Sherco (with Formula rear master cylinder) TA-4026-SH

Gas Gas and Jotagas TA-4025-JT

REAR WHEEL AXES NUT

DADO PERNO RUOTA POSTERIORE

Beta

Montesa, Sherco and Scorpa

TA-4021-BT TA-4004-SH

- Heaxegonal spanner 21 mm to enjoy the spark plug tool - Made of 7075 T6 Ergal aluminum alloy

SNAIL CAMS

COPPIA TENDICATENA

Beta, Scorpa and Sherco Montesa 4RT

TA-4003-BT TA-4000-MT

- Ergonomic design for quick and simple adjustment of the pull-chain - Made of 7075 T6 Ergal aluminum alloy

(17)

GEAR LEVER TIP

SNODO PEDALE LEVA CAMBIO

Beta

GasGas and Jotagas

TK-0063-BT TK-0098-JT Montesa Ossa TK-0106-MT TK-0072-SS

Scorpa and Sherco TK-0026-SH

- The Sherco and Scorpa version is longer than stock of 5 mm to be easier to use - Made of 7075 Ergal aluminum alloy

BRAKE LEVER TIP

SNODO PEDALE LEVA FRENO

Beta TK-0095-BT

Montesa Ossa and GasGas

TK-0105-MT TK-0062-SS

Jotagas, Sherco and Scorpa ‘14 TK-0091-SH

- It replaces the stock one to be more readily achievable and have a more accurate braking - Made of 2024 aluminum alloy

FUEL TANK CAP

TAPPO SERBATOIO

Beta EVO AK-6004-BT

Jotagas Ossa

AA-6007-JT AK-6003-SS

Sherco ‘10/... AA-6002-SH

- CNC machined from solid part - A detail for racing style on your bike - Made of 2011 aluminum alloy

CARBURETOR IDLE ADJUSTMENT SCREW

VITE REGOLAZIONE MINIMO CARBURATORE

Keihin Beta (right side) AA-0001-KH

Keihin Gas Gas and Sherco (left side) Dell’Orto PHBL

AA-0027-KH AA-0096-DL

CARBURETOR MIXTURE ADJUSTMENT SCREW

VITE REGOLAZIONE ARIA CARBURATORE

Keihin PWK Ø28 AA-0028-KH

Dell’Orto PHBL AA-0097-DL

(18)

VITI

REGOLAZIONE

AK-5006-AJ

AK-5004-AJ

AK-5005-AJ

AK-5027-GM

BRAKE/CLUTCH MASTER CYLINDER ADJUSTMENT SCREWS

VITI REGOLAZIONE POMPA FRENO/FRIZIONE

AJP/Grimeca/Braktec brake/clutch plunger adj. screw AJP/Braktec clutch stop screw

AK-5006-AJ AK-5004-AJ AJP/Braktec brake stop screw

Grimeca brake/clutch stop screw

AK-5005-AJ AK-5027-GM AJP/Braktec screws set (2x AK-5006-AJ, 1x AK-5004-AJ, 1x AK-5005-AJ)

Grimeca screws set (2x AK-5006-AJ, 2x AK-5027-GM)

AK-5913-AJ AK-5914-GM

- Shape designed and manufactured for the adjustment by hand without the use of tools - Made of 2011 aluminum alloy

CLUTCH/BRAKE MASTER CYLINDER COVER

COPERCHIO POMPA FRENO/FRIZIONE

AJP master cylinder “large” AJP master cylinder “small”

AA-5000-AJ AA-5001-AJ Braktec brake side

Braktec clutch side Formula (brake/clutch)

AA-5035-BK AA-5036-BK AA-5029-FR

Grimeca (Beta) clutch side AA-5002-GM

Grimeca (Beta) brake side AA-5003-GM

HANDLEBAR ENDS

TAPPI MANUBRIO

All models - Tutti i modelli AK-5912-UN

- Mechanical fastening with expansion system - They protect perfectly the handlebar grips - Made of aluminum alloy Ergal 7075

(19)

Ossa TR (Tech forks Ø 39 mm) TK-2912-SS Sherco ST …/’11 – Scorpa SR ‘11/’13 (Ceriani forks Ø 38 mm) TK-2907-SH

- CODE

TRIPLE CLAMPS KIT

KIT PIASTRE FORCELLA

MODELLO - MODEL CODICE

Beta EVO (Beta forks Ø 38 mm) TK-2903-BT

Jotagas JT (Marzocchi forks Ø 40 mm)

TK-2913-BT TK-2906-JT

Jotagas JT (Tech forks Ø 39 mm) TK-2910-JT

Sherco ST ‘12/… - Scorpa SR ’14 (Tech forks Ø 39 mm) TK-2902-SH

Ossa TR (Marzocchi forks Ø 40 mm) TK-2911-SS

Beta EVO (Tech forks Ø 39 mm)

- Perfect balance between rigidity and lightness

- They avoid the torsional effect between wheel axle and forks, improving driving sensibility - In case of crashes they decrease the possibility of rotation between the upper and lower clamp which causes the "usual" misalignment between the wheel and the handlebar

- 4 position to adjust the handlebar (stock, + 6 mm, +12 mm and – 6 mm)

- Possibility to lift up the handlebar position woth the dedicated spacers (sold separately) - Made of 2024 Avional aluminum alloy and 7075 T6 Ergal aluminum alloy (pivot)

- CODE

UPPER TRIPLE CLAMPS KIT

KIT PIASTRA FORCELLA SUPERIORE

MODELLO - MODEL CODICE

Beta EVO .../’13 (Beta forksØ 38 mm) TK-2905-BT Sherco ST …/’11 – Scorpa SR (Ceriani forks Ø 38 mm) TK-2908-SH Sherco ST ‘12/… (Tech forks Ø 39 mm) TK-2904-SH

- Perfect balance between rigidity and lightness - Applicable to the bike with the stock bottom clamp

- 4 position to adjust the handlebar (stock, + 6 mm, +12 mm and – 6 mm)

- Possibility to lift up the handlebar position woth the dedicated spacers (sold separately) - A special racing great look

- Made of 2024 Avional aluminum alloy

CODICE - CODE

HANDLEBAR CLAMP SPACERS FOR CSP TRIPLE CLAMPS

SPESSORI ATTACCHI MANUBRIO PER PIASTRE CSP

MODELLO - MODEL

5 mm TK-2066-UN

10 mm TK-2067-UN

15 mm TK-2068-UN

- Adding more spacers, allow to lift up the handlebars in steps of 5 mm - Comes in pairs

(20)

QUICK FORK ADJUSTER

REGOLAZIONE RAPIDA FORCELLA

Tech Ø 39 mm AK-2082-TC

- Allows quick adjustment of the rebound register, without using the screwdriver - Fitted on the fork cap with stainless teel M3 grub screw

- Made of Ergal 7075 T6 aluminum alloy

HANDLEBAR SPACERS D. 28,6 mm

SPESSORI ATTACCHI MANUBRIO D. 28,6 mm

Montesa 4RT +20 mm TK-2030-MT

Sherco …/’11 +10 mm TK-2047-SH

Sherco …/’11 +15 mm TK-2048-SH

Sherco ‘12/... +10 mm TK-2057-SH

Sherco ‘12/... +15 mm TK-2058-SH

- Made to have an higher bar attachment, to reach the ideal position on the bike - Made of 6082 aluminum alloy

CODICE - CODE

INCREASED IMPELLER KIT

KIT GIRANTE POMPA ACQUA MAGGIORATA

MODELLO - MODEL

Beta TK-0908-BT

Gas Gas (impeller only) TA-0007-GG

Jotagas TK-0915-JT

Sherco …/’10 – Scorpa ‘11/’13 TK-0907-SH

Sherco ’11/… - Scorpa ‘14 TK-0909-SH

- Comes in complete kit: bigger water pump, spacer, O-Ring and longer screws - Improve the cooling liquid circulation

- Shape and detail designed to avoid the formation of bubbles in the cooling circuit - Made of 6082 aluminum alloy

(21)

ENGINE PLUGS

TAPPI MOTORE

Beta 2Strokes

Gas Gas, Jotagas and Ossa

TA-0101-BT TA-0102-GG Montesa 4RT oil filler plug without dip stick

Montesa 4RT oil filler plug with dip stick

CA-0053-HD TA-0103-MT Montesa 4RT ignition carter inspection plug

Sherco and Scorpa

CA-0038-HD TA-0100-SH

- Racing style parts for your bike

- Very strong material to ensure the hex key even after many tightenings - Made of ergal 7075 T6 aluminum alloy

CLUTCH BASKET WITH RIGID ATTACHMENT

CAMPANA FRIZIONE CON ATTACCO RIGIDO

Beta

Sherco .../’12 – Scorpa (Sherco engine)

TD-0025-BT TD-0009-SH

Sherco ‘13/... TD-0004-SH

- Special anodized hard treatment to improve endurance and strenght

- Very strong to improve performance if hardly stressed and long life for the basket - Designed with holes and profiles to improve the oil penetration between the plates - Made of 7075 T6 Ergal aluminum alloy

“P2G – PRECISION TO GRIP” COMPLETE CLUTCH

FRIZIONE COMPLETA “P2G - PRECISION TO GRIP”

Complete clutch kit “P2G” for Sherco .../’12

Update kit from CSP basket for Sherco

TK-0911-SH

TK-0912-SH Complete clutch kit “P2G” for Sherco ‘13/... TK-0916-SH

Complete clutch kit “P2G” for Beta EVO Update kit from CSP basket for Beta EVO

TK-0913-BT TK-0914-BT N.6 steel disc replacement kit for P2G clutch TK-7900-UN

- Comes in complete kit: basket, primary gear fitting plate, inner hub, pressure plate, special spring’s washer, n.6 steel discs with dedicated profile’s design and 1 kg of special “P2G Lubricant” engine oil - A clutch designed for racing use, with a very strong and precise starting grip, even in situations of extreme stress and use

- Made with holes and profiles designed to increase the oil flow between the discs - Made of ergal 7075 T6, 6082 aluminum alloys and steel

(22)

CLUTCH COVER

COPERCHIO CARTER FRIZIONE

Beta

Sherco …/’10 - Scorpa ‘11/’13

TA-0076-BT TA-0093-SH

Sherco ‘11/… - Scorpa ’14 TA-0074-SH

- Extremely strong against cracks and rubbings

- Can be personalized with name / logo / number of the rider - A racing parts for great aesthetic impact

TUBES PLUG

TAPPO VALVOLA CAMERA ARIA

TUTTI I MODELLI - ALL MODELS AK-4011-UN

- A detail for racing style on your bike - Made of 2011 aluminum alloy

TUBES STOPPER LIT

DADO E RONDELLA PER FERMA COPERTONE

TUTTI I MODELLI M8 CH 13 - ALL MODELS AK-4901-UN

- Close top to protect the thread from dirt and crash

- Ideal for a quick disassembly of the stopper for the tyre change - Comes with the nylon or alu alloy washer

KEY RING

PORTACHIAVI

Portachiavi - Keyring - Porte-clés AK-8000-UN

- Realizzato in lega di alluminio

(23)
