CREATING LOCKING SOLUTIONS...

(1)

LOCKING

SOLUTIONS...

DOCUMENTATION A1-SERIES

(2)

Pagina 2 Pagina 2 Pagina 3 Pagina 4 Pagina 5 Pagina 6 Pagina 7 Pagina 8 Pagina 9 Pagina 10-11 Pagina 12 Pagina 14-15 Pagina 16 Pagina 17 Pagina 18-19 Pagina 20 Pagina 21-37 Pagina 38-39 Pagina 40 Pagina 41 Pagina 42 Pagina 43-56 Back cover

T

able of content

TABLE OF CONTENT:

Description of the product... Characteristics... Certificates... Models without handle... Models with handle... Programmation... Explanation of parts... Installation instructions... Mounting possibilities... Accessories... Notes... Connection diagram A1-BASIC... Connection diagram A1-SRC... Notes... Connection diagram A1-Multipoint... Notes... Technical drawings (locks)... Technical drawings (security escutcheons)... Technical drawings (baseplate fixation blocks)... Technical drawings (surface mount brackets)... Notes... Prescription texts... Contact details... ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

(3)

CHARACTERISTICS:

• 24V DC stabilized (+/- 5%)

consumption:

2,2 A activation current (0,2sec) 130 mA holding current

• controlled and manageable access

• automatic locking when the door closes

• always locked with the main bolt when the door is closed (bolt is ejected 20 mm)

• mechanical opening with the cylinder is always possible

• from the inside the lock (HA, HX and HE) can always be opened mechanically

using the handle or panic bar (emergency exit)

• integrated signalisation of the bolt position (unlocked / locked)

integrated signalisation of the door position (open / closed)

• stainless steel locking components, cylinder block, baseplate and striker plate

• the locking components are mounted on the solid baseplate using M6 axes,

which improves the free movement of the components and the lifespan of the lock

• integrated microprocessor controlled intelligence

• anti-saw pin in the bolt

• standard striker plate with casted on striker cup included

• adjustable striker plate with re-enforced striker cup (optional)

• possibility to have the PCB protected in a polyurethane casted resin (optional)

• door detection by 3 Hall-sensors instead of 1 (optional)

• tested to achieve 1.000.000 cycles

• tested to a frequency of 600 cycles a day

• resistance up to 25.000 N lateral pressure

• opening under considerable lateral pressure is still possible

• specially designed security escutcheons (SE-17, SE-22, SEH-17 and SEH-22)

are available (optional)

• available for both 17mm and 22mm cylinders

• available in backsets of 25, 30 & 50mm (SA, SX & SE models)

available in backsets of 35 & 60mm (HA, HX & HE models) available with 2 cylinder openings (PSX, PSE & PME models)

?

? ?

The B&B Locks A1-series are high security locks of superior quality. Because of their very solid construction, these locks offer an extreme high resistance against all forms of agression and burglary attempts. The A1 locks are made to allow for a high frequency use. To ensure a fast and precise action, the hardened locking components are driven by a powerful solenoid. This solenoid was especially designed to have the best possible balance between activation and holding current. A low power consumption and very little heating are additional advantages of the new solenoid. Unlocking is done by giving an impulse with a push button, card reader, code, fingerprint or any other type of acces control. Mechanical unlocking is always possible using a key. The automatic locking mechanism guarantees that the door will be locked as soon as it closes.

(4)

? CE-certified:

EN-certificates:

Ref. Nr. TCF-LDN 06.09.003 lock

(according to standards EN 61000 & EN 55022)

The models A1 HA, HX en HE (all handle versions) in combination with the B&B security escutcheons SEH-17 en SEH-22 are certified to be used in emergency exit doors.

?

DIN EN 179 : 2008 (Emergency Exits)

DIN EN 1125 : 2008 (Panic Exits)

3 7 6 0 1 4 5 2 A B

The models A1 HA, HX en HE (all handle versions) in combination with push bar are

certified to be used in panic exit doors. The certificates have been obtained in

combination with the following hardware: - ECO EPN 900 panic bar

- WSS PS 99 panic bar - WSS PD 79 push bar

All A1 models have been certified with the highest possible level of this norm

regarding the static pressure on the bolt.

regarding locks and escutcheons.

regarding burglary resistance. (Table C1 - protection against pushing back the bolt).

3 7 6 0 1 4 2 2 A B 3 7 6 0 1 4 2 2 A B 3 7 6 0 1 4 2 2 B B DIN 18251 - part 1 (class 5) DIN EN 12209 : 2004 (class 7) DIN V EN V 1627 : 1999 (class 6)

Certificates

CERTIFICATE of COMPETENT BODY

in the framework of article 10.2 of the European Directive 89/336/EEC for EMC

for

Secure Lock-system model B&B A1 slot of Manufacturer B&B Locks s.a., Chemin de Tecnax 27, CH-1973 Nax, SWITZERLAND

(5)

AVAILABLE BACKSETS : 25, 30 & 50 mm

SA:

SX:

SE:

no cylinder block

unlocked without power -w i t h c y l i n d e r b l o c k ( m e c h a n i c a l o p e n i n g always possible with key)

locked without power -w i t h c y l i n d e r b l o c k ( m e c h a n i c a l o p e n i n g always possible with key)

locked without power (only when door is closed) -w i t h c y l i n d e r b l o c k ( m e c h a n i c a l o p e n i n g always possible with key)

Standard Striker Plate with striker cup 3mm

Adjustable Striker Plate with striker cup 6mm ORDER NR FORMAT: A 1 _ . . . - . . _ . . 1) Lock model 2) Space 3) Programmation (BASIC or SRC) 4) Dash 5) Backset (25, 30 or 50) 6) Space

7) Lock type (SA, SX or SE)

1 2 3 4 5 6 7

EXAMPLE:

A1 BASIC-30 SX + ASP

Standard Striker Plate is normally

included. If you would like to

upgrade to the Adjustable Striker

Plate please add behind

the order number.

+ ASP

(6)

AVAILABLE BACKSETS : 35 & 60 mm Standard

Striker Plate with striker cup 3mm

Adjustable Striker Plate with striker cup 6mm

HA :

HX :

HE :

Unlocked without power.

Mechanical opening with key is always possible from both sides. Mechanical opening with the handle is always possible from the secure side.

Locked without power.

Locked without power (only when the door is closed).

ORDER NR FORMAT: A 1 _ . . . - . . . . _ . . 1 2 3 4 5 6 7 8 1) Lock model 2) Space 3) Programmation (BASIC or SRC) 4) Dash 5) Backset (35 or 60)) 6) Cylinder type (17 or 22) 7) Space

8) Lock type (HA, HX or HE))

Standard Striker Plate is normally

included. If you would like to

upgrade to the Adjustable Striker

Plate please add behind

the order number.

+ ASP

(7)

The A1 locks are available with 2 different types of programmation: BASIC program

SRC program

The SRC (serial communication) programmation was developped in order to be able to communicate more information about the lock to the consumer.

The A1 lock has a 5-pole connector at the bottom of its printed circuit board. This allows for an easy connection of both power and signalisation wires (combined in the B&B A1 BASIC CABLE).

In the A1-BASIC version pin 4 and 5 of this connector serve as the signalisation of the bolt and the door position respectively. These outputs are not potential free (used only to activate a relais or illuminate a LED). On page 15 you can find the instructions of how these outputs can be made potential free if so desired.

Using the SRC programmation the lock gives us more information. It continuously communicates the status of the bolt and the door, but also tells us whether or not the key and the handle are being used. This information is transmitted over a data line, but needs to be translated in order for us to understand it. Therefore we use the SRC-1 interface, which translates this information into potential free outputs (see page 16 for more details).

?

(8)

SECURITY ESCUTCHEON Adding a security escutcheon offers a strong protection against agression on the cylinder. It is a solid casted piece fixed with 2 x M8 srews. CYLINDER BLOCK is casted in 1 piece a n d o f f e r s t h e possibility to use b o t h 1 7 m m e u r o p r o f i l e a n d 2 2 m m s w i s s cylinders.

The are hardened

steel casted parts (HRC45). Their

construction principle is such that when pressure is applied to the bolt, these parts are locking even more. Together with the very high resistance against vandalism and lateral pressure this makes for the best solution in anti-intrusion locking systems.

LOCKING PARTS

The locking components in the A1-lock are

driven by a , which allows for a

very fast locking or unlocking action. It also ensures the lock to go back to its starting position when there is no power; open in fail safe and locked in fail secure version. The solenoid was especially designed to have the best possible balance between activation and holding current, to have low consumption and no heating.

SOLENOID

The intelligence of the lock comes from a microprocessor on the

, which is mounted in a plastic cup and on the baseplate. It is possible to protect the printed circuit board b y c o v e r i n g i t c o m p l e t e l y i n a polyeurathane casted resin. This will protect the PCB against humidity etc.

PRINTED CIRCUIT BOARD

Two different types of (both with a cup protecting the ejected bolt) are available. T h e

version has oval holes for adjustment at the initial installation. The version has a movable insert that allows for adjustments any time after installation (to c o m p e n s a t e d o o r imperfections). STRIKER PLATES S TA N D A R D A D J U S T A B L E T h e are very strong stainless steel p l a t e s o f 3 m m (standard) and 6mm ( a d j u s t a b l e ) thickness.

The striker plates have 1

b u i l t i n (invisible), which is detected by a

on the PCB for door detection.

S T R I K E R PLATES permanent m a g n e t Hall-sensor CONNECTION DIAGRAM

Explanation of parts

(9)

· Use B&B A1-BASIC CABLE (2 x 1,5mm² + 3 x 0,22mm² - shielded) !

· Use 24V DC regulated POWER SUPPLY of minimum 2,5A per lock !

· Make sure the distance between the power supply and the lock is maximum 25m !

· Mesure the voltage coming to the lock and make sure that this never drops below 22,8V

(24V DC +/- 5%). (important especially when the solenoid is activated !)

· Make sure the distance between the lock and striker plate is min. 2mm and max. 6mm !

· Make sure the lock and striker plate are installed in a proper matter where the 2 are

perfectly aligned (in closed door position they should be straight accross from eachother, both laterely and in height) !

· Make sure that there is no friction on the bolt when being ejected and retracted (this

should be tested after installation of the rubbers on the profile) !

· Make sure the holes for inserting the cylinder are large enough so the cylinder can be

easily installed without being forced.

· Filings that end up in or around the lock

will be attracted when the solenoid is activated and will eventually damage the lock !

· Make sure the door is equiped with adequate hinges (according to door size and weight)

to avoid « hanging » of the door !

· Make sure the door is equiped with an adequate door closer (according to door size and

weight) !

DO NOT FILE with the lock already installed!

Please note that in order for the lock to function correctly the above mentioned specifications need to be strictly followed. B&B LOCKS S.A. can not be held accountable for on-site interventions and reparations under warranty if the installation was not done according to these specific instructions !

BASEPLATE FIXATION BLOCKS

A1 locks can of course also be installed in existing doors. Since it is not always easy to make very accurate adaptions to a door when you are on site, we have developed

Baseplate Fixation Blocks ( ). Using

these blocks the A1 lock will end up flush mounted on the profile (when profile used is 2mm).

BFB-1

Installation instructions

S U R FA C E M O U N T B R A C K E T S

In case it is impossible to install the A1 lock in the door or the frame because of the width of the lock (30mm), a

a p p l i c a t i o n c a n b e

considered. The Surface

Mount Bracket ( )

consists of 4 mounting blocks and 2 stainless steel covers (1 for the lock and 1 for the striker plate),

w h i c h a r e m o u n t e d

vertically or horizontally on the secure side.

surface mount

(10)

Sanocyl SA SX SE Sanocyl SA Sanocyl SA SX SE HA HX HE min. 2mm max. 6mm

Mounting possibilities

(11)

B&B A1-BASIC CABLE

Cable with 2 x ø1,5mm and 3 x ø0,22mm wires + shielding

RED : power +24V

BLUE : GND (0V)

BLACK : unlucking impulse (to GND)

BROWN : bolt signal

YELLOW : door signal

CB1 - PUSH BUTTON WITH BOLT & DOOR SIGNALIZATION The CB1 control box has the following functions:

push button (1 time opening) rocker switch (continuous opening) bolt status signalization LED’s door status signalization LED’s ?

? ? ?

REL-1 (POTENTIAL FREE CONTACTS BOLT & DOOR)

Turns the bolt and door signals coming from the A1-BASIC into potential free outputs.

(see page 15 for connection diagram)

SRC-1 (POTENTIAL FREE CONTACTS BOLT, DOOR, KEY & HANDLE)

Turns signal-A and signal-B lines coming from the A1-SRC into potential free outputs.

(see page 16 for connection diagram) ?

? ?

CON1 = INPUT 220V/50Hz 120VA

CON2 = connection to back-up batteries (3 x 12V) CON3 = Extra output 12V/DC maximum 0,2A

CON4 = Output 24V/DC, 4A peak, 1A continuous (LOCK1) CON5 = Output 24V/DC, 4A peak, 1A continuous (LOCK2) All outputs have a short-circuit protection, in case of a short circuit on the 24V, LED1 will illuminate.

In case of overheating because of a surcharge, LED1 will also indicate an error.

A possible voltage drop (which is possible over a long line) can partially be compensated by adjusting the TRIM2 (current compensation in power supply). The principle is such that the outgoing voltage only increases when a voltage peak is needed (not continuously).

(12)

B&B SE17 (for models SA, SX & SE)

Security escutcheon for 17mm europrofile cylinder.

B&B SE22 (for models SA, SX & SE) Security escutcheon for 22mm Swiss cylinder.

B&B SEH17 (for models HA, HX & HE)

Security escutcheon with handle for 17mm europrofile cylinder.

B&B SEH22 (for models HA, HX & HE)

Security escutcheon with handle for 22mm Swiss cylinder.

BFB-1 (BASEPLATE FIXATION BLOCK)

In order to make the installation of the A1 locks in existing doors easier. Using these blocks the A1 lock will end up flush mounted on the profile (when the profile used is 2mm).

SMB (SURFACE MOUNT BRACKET) SMB

The surface mount bracket ( ) consists of 2 fixation blocks and

1 stainless steel cover. The installation needs to be done on the secure side of the door and can be vertical as well as horizontal. Available models:

SMB-SN: for the A1 Sanocyl and the striker plate - this

cover has no cylinder opening

SMB-L: for the A1 with backset 30mm and 17 or 22mm

cylinder, when the lock is installed to the Left of the striker plate; fixation holes are made for mounting the security

escutcheons (SE-17 or SE-22). In case the security

escutcheon is not used cylinder cover plates are available (CC-17 and CC-22 for 17 and 22mm cylinders respectively)

SMB-R: idem, but used when the lock is installed to the

Right of the striker plate

SMBH-L: for the A1 with backset 35mm and 17 or 22mm

cylinder, when the lock is installed to the Left of the striker plate; fixation holes are made for mounting the security escutcheons with handle (SEH-17 or SEH-22).

SMBH-R: idem, but used when the lock is installed to the

? ? ? ? ?

Accessories

(13)

Notes

...

(14)

Connection diagrams

CONNECTION

DIAGRAMS

(15)

POWER SUPPLY PS24D52 PUSH BUTTON with DOOR and BOLT SIGNALISATION

CB 1

A1 BASIC - connection

Maximumtotalcable length = 25m Always connect shielding to GND or EARTH only on 1 side 3 = EARTH

1&2 = 220V/50HZ

3 = charger I out = 0.2A / U out max ~ 41,0V

2 = 12Vdc/0.2A 1 = GND 1 = GND

2 = split at 2/3 = 24V (only input !)

1 = GND 3 = EARTH/GND 12 34 5 GND / blue +24V / red Unlock / black BOLT SIGN / brown DOOR SIGN / yellow CON1 12 CON2 +24V/DC GND SCHIELDING to GND A1 LOCK B&B LOCKS A1-BASIC

B&B LOCKS A1-BASIC

SCHIELDING to EARTH/GND CON1 = power input

CON3 = EXTRA 12V POWER SUPPLY OUTPUT CON2 = BATTERY CHARGER 3X12V

CON4 = CONNECTION LOCK 1

2 = +24V/DC 24V POWER SUPPL Y -PS24D52 +24V (wire ø 1,5 mm) 0V (GND) (wire ø 1,5 mm) Openingsimpulse to GND Bolt Signalisation (Bolt out = 0V) Door Signalisation (Door closed = 0V)

(16)

A1 LOCK

+24V/DC

DOOR SIGNAL BOLT SIGNAL

OPTION 1: make the outputs potential free

OPTION 2: illuminate LED s’

The bolt and door signals are transistor switches inside the lock, which are put to GND when activated (max 20mA with 24V DC). These outputs are not potential free!

It is possible to activate a relais switch (which in turn makes the output potential free), or to light up a LED (when put in series with a resistance).

The positive terminal (of the relais or the LED) has to be connected to the +24V DC (= pin 1) and the other side to pin 4 and/or pin 5 for bolt and door signalisation respectively.

When the bolt and/or door signalisation are active they are put to GND (= pin 2) and the relais are activated or the

LED are lit.’s

FUNCTION:

Connect 1 relais to the +24V and the bolt signal. When the bolt is out, the transistor switch in the lock closes, which will activate the relais (so the NO of the relais will be closed and the NC of the relais will be open). The following values can be measured with an Ω-meter:

between C and NO: infinity when open, 0Ω when closed between C and NC: infinity when open, 0Ω when closed

Connect 1 relais to the +24V and the door signal. When the door is closed, the transistor switch in the lock closes, which will activate the relais (so the NO of the relais will be closed and the NC of the relais will be open). The following values can be measured with an Ω-meter:

between C and NO: infinity when open, 0Ω when closed between C and NC: infinity when open, 0Ω when closed

? ?

REL1:

In order to make it easy for the installer and the end-user to use the A1 locks to their full potential, we are offering the REL-1. This is a small printed circuit board, which can easily be connected to the lock in case the bolt and door signals are needed potential free.

COM/1 - BOLTSIGNAL

NC/1 - BOLTUNLOCKED

NO/1 - BOLT LOCKED COM/2 - DOOR SIGNAL

NC/2 - DOOR OPEN

NO/2 - DOOR CLOSED

OUTPUTS POTENTIAL FREE

A1 BASIC - connection

123 45 GND blue +24vDC red In-UnlockCommand black CON1 Transistor switch to GND Current limitation = 20mA Maximum = 24V/DC

S1 S2

with short circuit protection.

BOLT out = S1 closed BOLT in = S1 open DOOR closed = S2 closed DOOR open = S2 open

+ RELAIS

24V/DC less than 20mA

COM NO NC

with limit diode

+ RELAIS

24V/DC less than 20mA

COM NO NC

with limit diode BOLT GALVANIC FREE

DOOR GALVANIC FREE

12 34 5 GND blue +24vDC red In-UnlockCommand black CON1 Transistor switch to GND Current limitation = 20mA

Maximum = 24V/DC

S1 S2

with short circuit protection

BOLT out = S1 closed BOLT in = S1 open DOOR closed = S2 closed DOOR open = S2 open LED1 LED2 R1 1K5 R2 1K5 15mA 15mA BOLT SIGNALISATION DOOR SIGNALISATION

(17)

SRC-1 POWER SUPPLY PS24D52

A1 SRC - connection

3 = EARTH LED1 LED2 LED3 LED4 32 1 CON1 21 CON3 32 1 CON2 32 1 CON4 32 1 CON5 1&2 = 220V/50HZ

3 = charger I out = 0.2A / U out max ~ 41,0V 1 = GND

2 = split at 2/3 = 24V (only input !)

GND +24V/DC EARTH/GND

PS 24 D52

SCHIELDING to EARTH/GND

Maxmium total cable length = 25m

Cable = B&B A1-BASIC CABLE (2x1,5 = 3x0,22 )

OPENING

B&B LOCKS A1-BASIC

B&B LOCKS A1-BASIC LN P E 12 3 45 67 8 9 10 1 1 SCHIELDING 24V= SCHIELDING 24V= LOCK1 LOCK2 12V= OUTPUT _SP ARE BA TTER Y BACK-UP 24V 36V 3x12V/4-6Ah 230 V ~ 50Hz 0,7 A EXTERNAL FUSE 250 V/ 2A T 0,2 A GND +12V/DC / 0,2A POWER BACK-UP BA TTER Y OVERLOAD ALARM CE INTERNE LED 24V= OVERLOAD 36V 3x12V/4-6Ah SPARE OUTPUT LOCK 1 24V 12V= 0,2A ALARM BACK-UP BATTERY SHIELDING BACK-UP BATTERY 8 7 6 3 2 15 4 PE 230 V~ 50 Hz 0,7 A _N L INTERNAL FUSE 250 V / 2A T

PS 24 D52

24 V DC POWER SUPPL Y technology sense SHIELDING LOCK 2 11 10 9 POWER 24V= CAUTION : to prevent electric shock do not remove cover when 230V input is switched on. For cable length adjustment, see note inside www.bb-locks.com

CON3 = EXTRA 12V POWER OUTPUT CON2 = BATTERY CHARGER 3X12V CON1 = power input

A1 LOCK A1 multi signal UNLOCK SIGNAL-B SIGNAL-A www .bb-locks.com 3 4 12 5 24V DC 2.5A +/-5%

24V POWER SUPPLY WITH BACK-UP BATTERY CONNEXION

IMPULS

OUTPUTS POTENTIAL FREE SRC-1

SERIAL DECODER ON DINRAIL

13 14 15 16 17 18 19 20 21 22 23 24 CON1 1 2 34 56 78 91 0 1 1 1 2 BOLT SIGNAL BOLT EJECTED BOLT RETRACTED DOOR SIGNAL DOOR CLOSED DOOR OPEN KEY SIGNAL KEY NOT IN USE KEY ACTIVATED HANDLE SIGNAL HANDLE NOT IN USE HANDLE USED NC2 NO2 COM2 NC1 NO1 COM1 NC4 NO4 COM4 NC3 NO3 COM3 GND IMPULSE 1 +24V/DC GND GND +24V/DC IMPULSE 1 SIGNAL/B SIGNAL/A +24V (wire ø 1,5 mm) 0V (GND) (wire ø 1,5 mm) Openingsimpulse to GND Signal 1 Signal 2

(18)

Notes

...

(19)

OPENING IMPULSE NC NC NC NC B&B A1 BASIC CABLE (2x1,5mm² +3x0,22mm²) 2x1,5mm² POWER SUPPL Y CABLE

CONNECTION TO THE LOCKS SUPPLY PS 24 D52 CONNECTION TO POWER

SRC-2

SERIAL DECODER ON DINRAIL

13 14 15 16 17 18 19 20 21 22 23 24 CON1 1 2 34 56 78 91 0 1 1 1 2 NC2 NO2 COM2 NC1 NO1 COM1 NC4 NO4 COM4 NC3 NO3 COM3 GND IMPULSE 1 +24V/DC GND GND +24V/DC IMPULSE 1 SIGNAL/B SIGNAL/A ATTENTION!!!

There is 1 main lock (when a lock with handle is installed this is always the main lock), which is programmed with the multi-signal program (SRC - serial communication). The additional locks are programmed with the BASIC program.

the different locks are connected in parrellel (both the power supply and the opening impulses)

all connected locks will unlock simultaneously (both in case of an electrical impulse from the access control and in case of opening of the main lock by key or handle)

in case 1 bolt can be vandalised the other bolts will remain locked

the potential free outputs give all the information about the main lock (position of the door, position of the bolt, key being used, handle being used)

the PS24D52 is strong enough to supply 2 doors with 3 locks each simultaniously

the total length of cable from the power supply to the locks can be 25m max

? ? ? ? ? ? MAIN LOCK -with SRC program ADDITIONAL LOCK -with BASIC program

ADDITIONAL LOCK -with BASIC program

OUTPUTS POTENTIAL FREE

A1 MUL

TIPOINT - connection

BOLT SIGNAL BOLT EJECTED BOLT RETRACTED DOOR SIGNAL DOOR CLOSED DOOR OPEN KEY SIGNAL KEY NOT IN USE KEY ACTIVATED HANDLE SIGNAL HANDLE NOT IN USE HANDLE USED

(20)

ON 1 2 1 2 ON 1 2 ON 1 2 ON SRC-2

The normal function of this multi-point locking solution is that each opening impulse (whether given by access control, key or handle) will simultaneously open all locks. This is the case when you put both switch 1 (=key) and switch 2 (=handle) in the ON position.

If so desired it is possible to deactivate the transfer of the opening impulse (from key and/or handle). The main lock will still open but the additional locks will remain in the locked position so the door can not be opened.

The opening impuls given by access control will always open all locks simultaneously.

Both switches in the ON position:

opening impulse given by access control is transferred and all locks open simultaneously

opening impulse given by the key is transferred and all locks open simultaneously opening impulse given by the handle is transferred and all locks open simultaneously ?

? ?

Switch 1 = ON, switch 2 = OFF:

opening impulse given by the key is transferred and all locks open simultaneously

opening impulse given by the handle is transferred and only the main lock opens

? ?

? not

Switch 1 = OFF, switch 2 = ON:

opening impulse given by the key is transferred and only the main lock opens

opening impulse given by the handle is transferred and all locks open simultaneously ?

? ?

not

Switch 1 = OFF, switch 2 = OFF:

opening impulse given by access control is transferred and all locks open simultaniously

opening impulse given by the key is transferred and only the main lock opens

opening impulse given by the handle is transferred and only the main lock opens

? ? ? not not

A1 MUL

TIPOINT - connection

(21)

Notes

...

(22)

TECHNICAL

DRAWINGS

T

(23)

(24)

A1 SANOCYL

+

(25)

(26)

A1 25 +

(27)

(28)

A1 30 +

(29)

(30)

A1 50 +

(31)

(32)

A1 3517 +

(33)

(34)

A1 6017 +

(35)

(36)

A1 3522 +

(37)

(38)

A1 6022 +

(39)

SECURITY

ESCUTCHEONS WITHOUT HANDLE SE-17 and SE-22

SE-17

(40)

SECURITY

ESCUTCHEONS WITH HANDLE SEH-17 and SEH-22

SEH-17

(41)

(42)

SMB - surface mount brackets

SMB-SN SMB-R

SMB-L SMBH-L SMBH-R

(43)

Notes

...

(44)

PRESCRIPTION

TEXTS

(45)

no current is supplied. Due to its solid construction (massive casted base plate and case-hardened locking components), the characteristics of a security lock are combined with those of an anti-panic lock.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by a single acting electro-magnet and immediately blocked by means of a deadlock. The lock will now switch from activation to holding current. In order to unlock , a connection must be made, by means of a switch, between terminal clamp 2 and 3. The current to the solenoid is then interrupted by the internal printed circuit board, forcing the bolt to retract by means of springs. The bolt will remain retracted until the door closes and the sriker plate has been detected (when no permanent contact is made between the 2 terminal clamps mentioned before).

· Base plate : stainless steel AISI 304 (investment casting) – 10mm thick

· Bolt and locking mechanism : case hardened (45 RC) chromium-nickel steel

(investment casting)

· Housing, cover plates and striker plate : stainless steel AISI 304 (partly laser cut,

partly investment casting)

· electro-mechanical security lock working with 24 V and low consumption (using a

custom made solenoid for fast action and low heating):

o 2,2 A activation current (moment of locking)

o 130 mA holding current (permanent locking)

· controlled and manageable access

· unlucking by impuls

· unlocked without power

· automatic locking when the door closes

· always locked with the main bolt when the door is closed (bolt is ejected 20 mm)

· integrated signalisation of the bolt position (unlocked/locked) and the door position

(open/closed)

· which can signal the status of the lock at a remote control room

· stainless steel locking components, baseplate and striker plate

· the locking components are mounted on the solid, 10mm thick, baseplate using M6 axes,

· integrated microprocessor controlled intelligence

· symmetrical bolt with anti-saw pin, for both bumper doors and revolving (180°) doors.

· standaard striker plate (3mm) with casted on striker cup included

· adjustable striker plate (6mm) with re-enforced striker cup (optional)

OPERATION: MATERIALS: FEATURES:

Prescription T

ext : B&B

A1 Basic SANOCYL

(46)

· possibility to have the PCB protected in a polyurethane casted resin (optional)

· doordetection by 3 Hall-sensors instead of 1 (optional)

· tested to achieve 1.000.000 cycles

· tested to a frequency of 600 cycles a day

· resistance up to 25.000 N lateral pressure

· opening under lateral pressure still possible up to 500 N (depending on installation)

· restart : the lock will re-do 3 attempts to close after the first attempt when not properly

locked

· power supply PS24D52 : 24V = direct current +/- 5%. Warranty of lock invalid if this

power supply is not used !

· connection via removable plugs with screw clamps (wire section 1,5 mm²)

· B&B Locks Cable (2 x 1,5 mm² + 3 x 0,22mm²) – Warranty of lock invalid if this cable is

not used !

Merchandise interlocking units; entrance and communicating doors in public buildings, hotels,

airports, shopping centers, parliament buildings, hospitals etc. Possibility to mount them

horizontally above the door.

Installation instructions and connection diagram : see documentation.

When installing the lock, make sure there is a proper and spotless recess. Furthermore, make sure the clearance between the cover plate of the lock and the striker plate is at least 2mm and maximum 6mm.

In case of a revolving (180°) door, it must perfectly stop in the 0-position; a door which is not in the exact position cannot be locked. A proper floor spring with adjustable stop and 0-position is a good solution. With these doors it is advisable to provide more lateral clearance. It also goes without saying that both door and doorframe must be sufficiently rigid and that the lock must be firmly installed for correct operation.

· Solid striker plate (6mm thick) with adjustable striker cup (a movable insert that allows

adjustments : 2mm to the left and 2mm to the right).

· PCB protected in polyurethane casted resin against humidity, etc. & door detection by 3

Hall-sensors instead of 1 Hall-sensor.

· BFB-1: Baseplate fixation blocks

· SMB: Surface mount bracket

· REL-1: Printed circuit board to transform the bolt and door signals coming from the

A1-BASIC lock into potential free outputs.

APPLICATIONS: INSTALLATION: OPTIONS:

Prescription T

ext : B&B

A1 Basic SANOCYL

(47)

a cylinder. Due to its solid construction (massive casted base plate and case-hardened locking components), the characteristics of a security lock are combined with those of an anti-panic lock.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by a single acting electro-magnet and immediately blocked by means of a deadlock. The lock will now switch from activation to holding current. In order to unlock , a connection must be made, by means of a switch, between terminal clamp 2 and 3. The current to the solenoid is then interrupted by the internal printed circuit board, forcing the bolt to retract by means of springs. Using a cylinder, the lock can also be unlocked mechanically, in which case the current supply to the solenoid is also interrupted (using a microswitch on the slider). After the door has been opened, the key must be turned back and removed from the cylinder. The bolt will remain retracted until the door closes and the sriker plate has been detected (when no permanent contact is made between the 2 terminal clamps mentioned before).

· Cylinder block : stainless steel AISI 304 (investment casting) – solid block

o 2,2 A activation current (moment of locking)

o 130 mA holding current (permanent locking)

· unlocked without power

· mechanical opening with the cylinder is always possible

(open/closed)

· stainless steel locking components, cylinder block, baseplate and striker plate

· standaard striker plate (3mm) with casted on striker cup included

OPERATION:

MATERIALS:

FEATURES:

Prescription text : B&B

A1 Basic SA

(48)

· specially designed security escutcheon (SE-17 of SE-22)

· both 17mm and 22mm cylinders can be used

· available in backsets of 25mm, 30mm and 50 mm

locked

not used !

Escape doors, entrance doors and communicating doors in public buildings, hotels, airports, shopping centers, parliament buildings, hospitals etc.

When installing the lock, make sure there is a proper and spotless recess. The cylinder recess must allow easy installation of the cylinder even after the lock has been mounted. This way, there will be no tension on the base plate when the cylinder is tightened. Furthermore, make sure the clearance between the cover plate of the lock and the striker plate is at least 2mm and maximum 6mm.

· Security escutcheon SE-17 or SE-22 (solid casted piece) fixed with 2 x M8 screws, offers

a strong protection against aggression on the cylinder and gives an extra anchoring for the lock.

· SRC-1: Din rail box, which translates the information coming from the A1-SRC lock and

turns them into potential free outputs (position of the bolt and the door, use of the key and the handle).

APPLICATIONS:

INSTALLATION:

OPTIONS:

Prescription text : B&B

A1 Basic SA

(49)

solenoid or mechanically by using a key. Locking by spring force when no power is supplied. Due to its solid construction (massive casted base plate and case-hardened locking components) and to the fact the lock is permanently secured when the bolt is thrown out, the lock offers high resistance against all kinds of burglar attempts.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by spring force and immediately blocked by means of a deadlock. In order to unlock the door, 2 terminal clamps (n° 2 and 3) must be connected by means of a switch, following which an electronic control print will activate the solenoid, which pulls in the bolt. The lock will now switch from activation to holding current. Using a profile cylinder, the lock can also be released mechanically following which the solenoid is also activated. After the door has been opened, the key must be turned back and removed from the cylinder. The lock will remain electronically unlocked until the door again closes (when there is no permanent contact between the 2 terminal clamps mentioned before). When the door does not open after the unlocking impulse has been given the lock will relock automatically after 5 seconds.

o 2,2 A activation current (moment of unlocking)

o 130 mA holding current (permanent unlocking)

· locked without power

(open/closed)

OPERATION:

MATERIALS:

FEATURES:

Prescription text : B&B

A1 Basic SX

(50)

locked

not used !

Doors that require permanent locking : banks, prisons, post offices, jewelry shops, computer departments, laboratories, exchange offices, etc.

· Security escutcheon SE-17 or SE-22 (solid casted piece) fixed with 2 x M8 screws, offers

a strong protection against aggression on the cylinder and gives an extra anchoring for the lock.

APPLICATIONS:

INSTALLATION:

OPTIONS:

Prescription text : B&B

A1 Basic SX

(51)

mechanically by using a key. Locking by spring force when no power is supplied and the deadlocking bolt is pushed in (door closed). Due to its solid construction (massive casted base plate and case-hardened locking components) and to the fact the lock is permanently secured when the bolt is thrown out, the lock offers high resistance against all kinds of burglar attempts.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by spring force (only when deadlocking bolt is pushed in) and immediately blocked by means of a deadlock. In order to unlock the door, 2 terminal clamps (n° 2 and 3) must be connected by means of a switch, following which an electronic control print will activate the solenoid, which pulls in the bolt. The lock will now switch from activation to holding current. Using a profile cylinder, the lock can also be unlocked mechanically following which the solenoid is also activated. After the door has been opened, the key must be turned back and removed from the cylinder. The lock will remain unlocked electronically and mechanically until the door again closes and the striker plate is detected (when there is no permanent contact between the 2 terminal clamps mentioned before). When the door does not open after the unlocking impulse has been given the lock will relock automatically after 5 seconds.

In case of a power failure when the door is open, the bolt will remain retracted mechanically (because of the small deadlocking bolt). When the door is then closed the bolt will be thrown out (using spring force) as soon as the deadlocking bolt is pushed in.

The SE model can therefore be used totally mechanically without losing any of its user-friendly characteristics!

· Bolt and locking mechanism : case hardened (45 RC) chromium-nickel steel (investment

casting)

· Housing, cover plates and striker plate : stainless steel AISI 304 (partly laser cut, partly

investment casting)

· electro-mechanical security lock working with 24 V and low consumption (using a custom made

solenoid for fast action and low heating):

· locked without power (bolt only thrown out when door is closed!)

· integrated signalisation of the bolt position (unlocked/locked) and the door position (open/closed),

which can signal the status of the lock at a remote control room OPERATION:

MATERIALS:

FEATURES:

Prescription text : B&B

A1 Basic SE

Fail secure lock with cylinder block, without handle

(52)

· standaard striker (3mm) plate with casted on striker cup included

· restart : the lock will re-do 3 attempts to close after the first attempt when not properly locked

· power supply PS24D52 : 24V = direct current +/- 5%. Warranty of lock invalid if this power supply

is not used !

· B&B Locks Cable (2 x 1,5 mm² + 3 x 0,22mm²) – Warranty of lock invalid if this cable is not used !

Doors that require permanent locking : banks, prisons, post offices, jewelry shops, computer departments, laboratories, exchange offices, etc.

· Security escutcheon SE-17 or SE-22 (solid casted piece) fixed with 2 x M8 screws, offers a strong

protection against aggression on the cylinder and gives an extra anchoring for the lock.

· REL-1: Printed circuit board to transform the bolt and door signals coming from the A1-BASIC

lock into potential free outputs.

· SRC-1: Din rail box, which translates the information coming from the A1-SRC lock and turns

them into potential free outputs (position of the bolt and the door, use of the key and the handle). APPLICATIONS:

INSTALLATION:

OPTIONS:

Prescription text : B&B

A1 Basic SE

Fail secure lock with cylinder block, without handle

(53)

mechanically by using a key. From the secure side this lock can also be unlocked mechanically using the handle (or push bar). Therefore one can always leave the building according to EN179 or EN1125. Locking by spring force when no power is supplied. Due to its solid construction (massive casted base plate and case-hardened locking components) and to the fact the lock is permanently secured when the bolt is thrown out, the lock offers high resistance against all kinds of burglar attempts.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by spring force and immediately blocked by means of a deadlock. In order to unlock the door, 2 terminal clamps (n° 2 and 3) must be connected by means of a switch, following which an electronic control print will activate the solenoid, which pulls in the bolt. The lock will now switch from activation to holding current. Using a cylinder (from either side), handle or push bar (from the secure side) the lock can also be released mechanically after which the solenoid is also activated. After the door has been opened, the key must be turned back and removed from the cylinder. The lock will remain electronically unlocked until the door again closes (when there is no permanent contact between the 2 terminal clamps mentioned before). When the door does not open after the unlocking impulse has been given the lock will relock automatically after 5 seconds.

· Bolt and locking mechanism : case hardened (45 RC) chromium-nickel steel (investment

casting)

· Housing, cover plates and striker plate : stainless steel AISI 304 (partly laser cut, partly

investment casting)

· electro-mechanical security lock working with 24 V and low consumption (using a custom made

solenoid for fast action and low heating):

· mechanical opening with the cylinder is always possible from either side of the door

· mechanical opening with the handle or push bar is always possible from the secure side

· integrated signalisation of the bolt position (unlocked/locked) and the door position (open/closed)

· the locking components are mounted on the solid, 10mm thick, baseplate using M6 axes, which

improves the free movement of the components and the lifespan of the lock

OPERATION:

MATERIALS:

FEATURES:

Prescription text : B&B

A1 Basic HX

(54)

· specially designed security escutcheon with handle (SEH-17 of SEH-22)

· available for both 17mm and 22mm cylinders

· available in backsets of 35mm and 60 mm

· restart : the lock will re-do 3 attempts to close after the first attempt when not properly locked

· power supply PS24D52 : 24V = direct current +/- 5%. Warranty of lock invalid if this power supply

is not used !

· B&B Locks Cable (2 x 1,5 mm² + 3 x 0,22mm²) – Warranty of lock invalid if this cable is not used !

Doors that require permanent locking : banks, prisons, post offices, jewelry shops, computer departments, laboratories, exchange offices, etc., but where a mechanical exit using a handle or panic bar should always be possible.

· Security escutcheon with handle SEH-17 or SEH-22 (solid casted piece) fixed with 2 x M8 screws,

offers a strong protection against aggression on the cylinder and gives an extra anchoring for the lock.

· REL-1: Printed circuit board to transform the bolt and door signals coming from the A1-BASIC

lock into potential free outputs.

· SRC-1: Din rail box, which translates the information coming from the A1-SRC lock and turns

them into potential free outputs (position of the bolt and the door, use of the key and the handle). APPLICATIONS:

INSTALLATION:

OPTIONS:

Prescription text : B&B

A1 Basic HX

(55)

solenoid or mechanically by using a key. From the secure side this lock can also be unlocked mechanically using the handle (or push bar). Therefore one can always leave the building according to EN179 or EN1125. Locking by spring force when no power is supplied and the deadlocking bolt is pushed in (door closed). Due to its solid construction (massive casted base plate and case-hardened locking components) and to the fact the lock is permanently secured when the bolt is thrown out, the lock offers high resistance against all kinds of burglar attempts.

After the door has been closed, the lock will detect the striker plate using a hall sensor on the PCB. Then the bolt is thrown out by spring force (only when deadlocking bolt is pushed in) and immediately blocked by means of a deadlock. In order to unlock the door, 2 terminal clamps (n° 2 and 3) must be connected by means of a switch, following which an electronic control print will activate the solenoid, which pulls in the bolt. The lock will now switch from activation to holding current. Using a cylinder (from either side), handle or push bar (from the secure side) the lock can also be released mechanically after which the solenoid is also activated. After the door has been opened, the key must be turned back and removed from the cylinder. The lock will remain electronically unlocked until the door again closes (when there is no permanent contact between the 2 terminal clamps mentioned before). When the door does not open after the unlocking impulse has been given the lock will relock automatically after 5 seconds.

In case of a power failure when the door is open, the bolt will remain retracted mechanically (because of the small deadlocking bolt). When the door is then closed the bolt will be thrown out (using spring force) as soon as the deadlocking bolt is pushed in.

The HE model can therefore be used totally mechanically without losing any of its user-friendly characteristics!

OPERATION:

MATERIALS:

Prescription text : B&B

A1 Basic HE

Fail secure lock with cylinder block and handle

(56)

FEATURES:

APPLICATIONS:

· mechanical opening with the cylinder is always possible from either side of the door

· mechanical opening with the handle or push bar is always possible from the secure side

(open/closed)

· standaard striker (3mm) plate with casted on striker cup included

· specially designed security escutcheon (SEH-17 of SEH-22)

· available for both 17mm and 22mm cylinders

· available in backsets of 35mm and 60 mm

locked

not used !

Doors that require permanent locking : banks, prisons, post offices, jewelry shops, computer departments, laboratories, exchange offices, etc., but where a mechanical exit using a handle or panic bar should always be possible.

For fire doors it is important that when a power failure accurs when the door is open, the bolt stays retracted so the door can close, after which the bolt will be thrown out and the door will be locked.

Prescription text : B&B

A1 Basic HE

Fail secure lock with cylinder block and handle

(57)

OPTIONS:

· Security escutcheon with handle SEH-17 or SEH-22 (solid casted piece) fixed with 2 x

M8 screws, offers a strong protection against aggression on the cylinder and gives an extra anchoring for the lock.

Prescription text : B&B

A1 Basic HE

Fail secure lock with cylinder block and handle

(58)
