0125137451

Handbook of

Advanced Electronic and Photonic

l\/laterials and Devices

Handbook of

Advanced Electronic and Photonic

[\/laterials and Devices

Volume 8

Conducting Polymers

Edited by

Hari Singh Nalwa, M.Sc, Ph.D.

Stanford Scientific Corporation

Los Angeles, California, USA

Formerly at

Hitachi Research Laboratory

Hitachi Ltd., Ibaral<i, Japan

ACADEMIC PRESS

San Diego San Francisco New York Boston London Sydney Tokyo

The image for the cover of this book was reprinted with permission from Jingsong Wang, Young, Yoo, Chen Gao, Ichiro Takeuchi, Xiaodong Sun, Hauyee Chang, X.-D. Xiang, and Peter G. Schultz, Science 279: 1712 (1998). Copyright 1998 American Association for the Advancement of Science.

This book is printed on acid-free paper. ® Copyright © 2001 by Academic Press All rights reserved.

No part of this publication may be reproduced or transmitted in any form or by any means, elec-tronic or mechanical, including photocopy, recording, or any information storage and retrieval system, without permission in writing from the pubhsher.

The appearance of the code at the bottom of the first page of a chapter in this book indicates the Publisher's consent that copies of the chapter may be made for personal or internal use of specific clients. This consent is given on the condition, however, that the copier pay the stated per-copy fee through the Copyright Clearance Center, Inc. (222 Rosewood Drive, Danvers, Massachusetts 01923), for copying beyond that permitted by Sections 107 or 108 of the U.S. Copyright Law. This consent does not extend to other kinds of copying, such as copying for general distribution, for advertising or promotional purposes, for creating new collective works, or for resale. Copy fees for pre-2001 chapters are as shown on the title pages; if no fee code appears on the title page, the copy fee is the same as for current chapters. 01 $35.00.

The information provided in this handbook is compiled from reliable sources but the authors, editor, and the pubhsher cannot assume any responsibility whatsoever for the validity of all state-ments, illustrations, data, procedures, and other related materials contained herein or for the consequence of their use.

ACADEMIC PFUBSS

A Harcourt Science and Technology Company

525 B Street, Suite 1900, San Diego, CA 92101-4495, USA http:/Avww.academicpress.com

Academic Press

Harcourt Place, 32 Jamestown Road, London, NWl 7BY, UK Library of Congress Catalog Number: 00-102887

International Standard Book Number: 0-12-513758-3

Printed in the United States of America

To my wife

Dr. Beena Singh Nalwa

(MA., M.Phil., Ph.D.)

Foreword

Since the realization of the first laser 40 years ago, the merging of the fields of quantum electronics and quantum optics has stimulated the development of many new materials and devices. These, in turn, support a flourishing optoelectronics market for optical com-munications, optical data processing, medical diagnostics, materials processing, display technology, and many other applications.

Therefore, in the year 2000, it is timely to publish The Handbook of Advanced Elec-tronic and Photonic Materials and Devices. The editor, Hari Singh Nalwa, is well known for his original work on nonlinear optics of organic molecules and polymers. Together with Seizo Miyata, he edited a comprehensive volume under this title that provides a broad overview of this particular subject. The same authors also edited a volume on organic electroluminescent materials and devices.

The present 10 volume handbook has a much broader scope. It includes semicon-ductor materials, quantum wells and quantum dots, liquid crystals, conducting poly-mers, laser materials, photoconductors, electroluminescent and photorefractive mate-rials, nanostructured, supramolecular, and self-assembled matemate-rials, ferroelectrics, and superconductors. Applications of these materials in photoconductors, optical fibers, xe-rography, solar cells, dynamic random access memory, and sensors are described. The Handbook contains contributions by 180 leading experts from 25 different countries. It truly represents the worldwide research efforts and results that support the global market of optoelectronics. All scientific and technical workers in this broad field are in-debted to the contributing authors, the editor and Academic Press for publishing this comprehensive handbook for the new millennium. It will support further growth in a field that already has surpassed my wildest expectations of 40 years ago.

Professor Nicolaas Bloembergen Nobel Laureate in Physics, 1981 Harvard University

Cambridge, MA, USA

Preface

Electronic and photonic materials are the key elements of continued scientific growth and technological advances in the new millennium. The electronic and photonic materi-als discussed in this handbook include semiconductors, superconductors, ferroelectrics, low- and high-K dielectrics, sol-gel materials, fuUerenes and carbon nanotubes, liquid crystals, conducting polymers, organic conductors, nonlinear optical materials, elec-trochromic materials, laser materials, photoactive chalcogenide glasses, photoconduc-tors, photovoltaic and electroluminescent materials, nanostructured materials, confined systems, supramolecular and self-asemblies, and soft magnetic materials. Compared to electronic materials, photonic materials enable the transport and processing of infor-mation at the speed of light. In the communication age of the 21st century, a major technological thrust is to move forward with photonic and optoelectronic technologies as a replacement to the traditional electronic technologies currently utilized to perform various functions such as the acquisition, processing, transmission, storage, and display of information. The present boom in fiber optics technology is an excellent example of how much impact photonic technologies have on the advancement of our society. These materials have already been used and will be the most important components of the next generation of semiconductor devices, the internet, computers, information technology, wireless and telecommunications, satellite communications, integrated circuits, photo-copiers, wireless telephones, solar cells, batteries, light-emitting diodes, liquid crystal dis-plays, magnetooptic memories, audio and video systems, recordable compact discs, video cameras, coatings. X-ray technology, advanced lithium batteries, nonvolatile memories, multilayer capacitors, color imaging, printing, flat-panel displays, waveguides, cable tele-visions, modulators, computer chips, magnetooptic disks, transducers, optoelectronics, lithography, holographic recording, solid-state lasers, and molecular-sized transistors and switches, as well as other emerging cutting edge technologies. Electronic and pho-tonic materials are expected to grow to a trillion-dollar industry in the new millennium and will be the most dominant forces in various fields of science and engineering.

This is the first handbook ever published on electronic and photonic materials, that summarizes the advances made over past the three decades. This handbook is a unique source of in-depth knowledge of molecular design, synthesis, processing, spectroscopy, physical properties and applications of electronic and photonic materials. This handbook contains 73 state-of-the-art review chapters written by more than 180 world leading ex-perts from 25 different countries. With over 25,000 bibliographic citations and thousands of figures, tables, photographs, chemical structures, and equations, this handbook repre-sents the work of the most renowned scientists in the international scientific community. It has been divided into 10 parts based on thematic topics:

Volume 1: Semiconductors Volume 2: Semiconductor Devices

Volume 3: High Tc Superconductors and Organic Conductors Volume 4: Ferroelectrics and Dielectrics

Volume 5: Chalcogenide Glasses and Sol-Gel Materials Volume 6: Nanostructured Materials

Volume 7: Liquid Crystals, Display, and Laser Materials Volume 8: Conducting Polymers

Volume 9: Nonlinear Optical Materials

Volume 10: Light-Emitting Diodes, Lithium Batteries, and Polymer Devices

PREFACE

Volume 1 includes topics on the growth and doping of Te-based II-VI layers and quantum structures by molecular beam epitajg^, gallium arsenide heterostructures, pho-toluminesence in GaN and InGaN and their photonic applications, processing of com-pound semiconductors, hydrogen in wide bandgap semiconductors, wet etching of semi-conductors, combinatorial synthesis and high throughput evaluation of electronic and photonic material chips, and coherent effects in semiconductor heterostructures.

The applications of semiconductors materials are discussed in Volume 2. The various topics on semiconductor devices include Si/GeSi heterostructures for Si-based nanoelec-tronics, impact ionization in compound semiconductor devices, quantum dot optoelec-tronic devices, failure mechanisms in compound semiconductors, electron devices, semi-conductor quantum materials and their applications in electronics and optoelectronics, and photoelectromotive force effects in semiconductors.

Volume 3 focuses on high Tc superconductors and organic conductors. Topics on superconductors include high Tc superconductors for small scale devices, processing and characterization of Bi-based single crystals and tapes, grain connectivity and vor-tex pinning in high-temperature superconductors, and yttrium-barium-copper oxide as an infrared sensing materials. The various topics on organic conductors include high magnetic field studies of quasi-two-dimensional organic conductors based on BEDT-TTF, quinonoid TT-extended tetrathiafulvalenes, supramolecular aspects of organic con-ductors, intramolecular electronic transfer phenomena in organic mixed-valence com-pounds, and organic conducting composites.

Ferroelectric and dielectric materials comprise Volume 4. This volume contains re-views on pyroelectricity: the fundamentals and applications, crystal growth, character-ization and domain studies in lithium niobate and lithium tantalate ferroelectrics, bis-muth vanadate, the electric field influence on acoustic waves, dielectric ceramics, and low dielectric constant materials for microelectronics interconnects.

Volume 5 includes topics on chalcogenide glasses and sol-gel materials. This vol-ume focuses on conduction and its related phenomena in ion-conducting glasses, pho-toinduced phenomena in amorphous chalcogenides from phenomenology to nanoscale, photoinduced and electron-beam phenomena in Ag-rich amorphous chalcogenide semi-conductors, photoinduced anisotropy in chalcogenide glasses, the nonlinear optical and spectral hole-burning properties of photonic glasses, the structure, chemistry, and ap-plications of sol-gel derived materials, modified sol-gel and metallo-organic deposition techniques for processing oxide films, and sol-gel coatings for optical and dielectric ap-plications.

In Volume 6, various topics related to nanotechnology and nanostructured materi-als are discussed. The topics include electrochemically self-assembled ordered structured arrays (quantum dots, dashes and wires), mechanical spectroscopy of nano-structured metallic systems, soft amorphous and nanocrystalline magnetic materials, nanoporous materials for microlasers and microresonators, nanoporous materials for optical applications, optical properties and impurity states in nanostructured materials, and confined systems and nanostructured materials.

Volume 7 summarizes new trends on liquid crystals, display, and laser materials. The topics include liquid crystals for electro-optic applications, switchable holographic polymer-dispersed liquid crystals, electrochromism and electrochromic materials for dis-plays, materials for solid-state dye lasers, photophysical properties of laser dyes and correlations with the lasing characteristics, interplay of anisotropy and orientational re-laxation processes in luminescence, and lasing of dyes and photosensitive materials for holographic recording.

Electrically conducting polymers are discussed in Volume 8. The coverage in this vol-ume includes the synthesis, and electrical and optical properties of conjugated poly-mers, conjugated polymer films for molecular and ionic recognition, polyacetylene and its analogs, synthesis, properties, and applications of poly(/^-phenylenevinylenes), self-organized supramolecular polymer structures to control electrical conductivity, spectro-electrochemistry of conducting polymers, electronic spectra of conjugated polymers and oligomers, and the degradation and stability of electrically conducting polymers.

Nonlinear optical materials and their applications are discussed in Volume 9. The var-ious topics include calculation of dynamic hyperpolarizabilities for small and medium sized molecules, theoretical aspects of the design of organic molecular and polymeric nonlinear optical materials, design and characterization of organic and organometallic molecules for second-order nonlinear optics, crystal growth, processing, and physical properties of photonic crystals, hyper-Rayleigh scattering: molecular, supramolecular, and device characterization by incoherent second-order nonlinear light scattering, non-linear optical properties of fuUerenes and carbon nanotubes, third-order optical nonlin-earity in polydiacetylene waveguides at telecommunications wavelengths, organic mate-rials for optical limiting, and Bragg grating in optical fibers.

Volume 10 includes topics on organic and polymer-based Hght emitting diodes, optical devices based on conducting polymers, intercalation compounds for advanced lithium batteries, polymer electrets for electronics, sensor, and photonic applications, charge transporting polymers and molecular glasses, and electrochemically prepared thin films for solar cells.

I hope these volumes will be very useful for libraries in universities and industrial insti-tutions, governments, and independent institutes, upper-level undergraduate and grad-uate students, individual research groups, and scientists working in the field of materials science, soHd-state physics, chemistry, nanotechnology, electrical and electronics engi-neering, polymer science, spectroscopy, crystallography, electrochemistry, xerography, superconductivity, optical engineering, device engineering, computational engineering, photophysics, data storage and information technology, and for the technocrats, who are involved in the science and engineering of electronic and photonic materials and devices. This handbook is the end product of marvelous cooperation of many distinguished experts, who devoted their valuable time and effort to write excellent state-of-the-art review chapters. I am highly thankful to all contributing authors. I highly appreciate all publishers and authors for granting us copyright permissions to use their illustra-tions for the review chapters in this handbook. I am grateful to my former mentors. Dr. Akio Mukoh and Dr. Shuuichi Oohara at Hitachi Research Laboratory, Hitachi Ltd., for their kind support and encouragement during my stay in Japan. I also extend my special thanks to Krishi Pal Raghuvanshi, Rakesh Misra, Professor Satya Vir Arya, Professor Padma Vasudevan, Jagmer Singh, Ranvir Singh Chaudhary, and other colleagues who supported my efforts to bringing this handbook to fruition. Finally, I greatly appreciate my wife. Dr. Beena Singh Nalwa, for her continuous cooperation and patience for en-during this work at home en-during weekends and late nights. The moral support of my parents, Sri Kadam Singh and Srimati Sukh Devi, and the love of my children, Surya, Ravina, and Eric during this exciting enterprise are also appreciated.

I express my sincere gratitude to Professor N. Bloembergen for his insightful fore-word.

Hari Singh Nalwa Los Angeles, CA, USA October 2000

Contents

About the Editor xvii List of Contributors xix Volume Listing xxi Chapter 1. SYNTHESIS, ELECTMCAL, AND OPTICAL PROPERTIES OF

CONJUGATED POLYMERS

Rafael KieboomSy Reghu Menoriy Kwanghee Lee

1. Introduction 1 2. Synthesis 5 2.1. Polyacetylenes 6 2.2. Polyaromatics 8 2.3. Poly(/7-phenylene vinylene)s 26 2.4. Polyanilines 32 2.5. Chemical Structure and Electronic Properties 33

3. Electrical Properties 47 3.1. Metallic State 49 3.2. Critical and Insulating States 60

4. Optical Properties 62 4.1. Theoretical Considerations 63

4.2. Optical Properties of "Doped" Conducting Polymers 65

4.3. Photophysics of Semiconducting Polymers 78 4.4. Electroluminescence in Conjugated Polymers: Polymer LED 81

4.5. Photoinduced Charge Transfer in Conjugated Polymer/FuUerene Composites . 82

5. Concluding Remarks 84 Acknowledgments 86 References 86 Chapter 2. CONJUGATED POLYMER FILMS FOR MOLECULAR AND

IONIC RECOGNITION

Bruno Fabre

1. Introduction 103 1.1. Background 103 1.2. Electrochemistry: A Powerful Tool for Recognition 104

1.3. Redox-Active Conjugated Polymer-Based Recognition 104

2. Molecular Recognition 105 2.1. Enzyme-Containing Polymers 105

2.2. Analytes of Biological and Pharmacological Interest Ill

2.3. Gases and Vapors 112 2.4. Other Molecules 113 3. Cationic Recognition 114

3.1. Polyether-Functionalized Polymers 114 3.2. Calixarene-Functionalized Polymers 119

3.3. Polyrotaxanes 120 3.4. Polymers Containing Other Functional Groups 121

4. Anionic Recognition 122 5. Conclusions 124

References 124

XIV CONTENTS

C h a p t e r 3 . P O L Y A C E T Y L E N E A N D I T S A N A L O G S : S Y N T H E S I S A N D P H Y S I C A L P R O P E R T I E S

KristenJ. SteenbergHarrell, SonBinh T.Nguyen

1. Introduction 132 2. Polyacetylene 132

2.1. The Discovery of PA 132 2.2. Shirakawa's Method for the Polymerization of Acetylene 132

2.3. Properties of Shirakawa-Type PA 133 2.4. Modifications of the Shirakawa Method 134 2.5. Other Catalysts for the Polymerization of Acetylene 137

2.6. Precursor Routes to PA 138 2.7. Copolymers of PA 141 3. Substituted PA 145 3.1. Synthesis of Substituted PA 145 3.2. Living Systems 148 3.3. Stereospecific Polymerizations 148

3.4. Silicon-Substituted Alkyne Monomers 148

3.5. ROMPofRCOT 149

3.6. a, w-Diynes 149 3.7. Indirect Routes to Substituted PA 150

3.8. Properties of Substituted PA 150 4. Electronic Properties of PA and Its Analogs 150

4.1. Conductivity and Chemical Doping 150

4.2. Solitons 151 4.3. cw-to ^«/i5-Isomerization 154

4.4. Electrochemical Doping 154 4.5. Photochemical Doping 154 5. Applications of PA and Its Analogs 154

5.1. Semiconductor Devices 155 5.2. Rechargeable Batteries 155

5.3. Solar Cells 155 5.4. Environmental Sensing Technology Based on PA 155

5.5. Gas-Liquid Separation Membranes 156 5.6. Other Applications of PA and Its Analogs 157

6. Conclusion 157 Acknowledgments 157 Nomenclature 157 References 158 C h a p t e r 4 . S Y N T H E S I S , P R O P E R T I E S , A N D A P P L I C A T I O N S O F P O L Y ( / ? - P H E N Y L E N E V I N Y L E N E ) S

Jonas Gruber, Rosamaria Wu Chia Li, Ivo Alexandre Hummelgen

1. Introduction 163 2. Methods of Synthesis 164

2.1. Via the Wittig Reaction 164 2.2. Soluble Precursor Routes 165 2.3. Electrochemical Routes 167 2.4. Other Synthetic Routes 167

3. Spectroscopy 169 3.1. Vibrational Spectra 169

3.2. Ultraviolet-Visible 170 3.3. Nuclear Magnetic Resonance 171

4. Thin-Film Preparation 171 4.1. Methods and Processes 171

5. Physical Properties 172 5.1. Structural, Mechanical, and Thermal Properties 172

5.2. Electrical Properties 173 6. Interfaces with Other Materials 176

6.2. Interfaces with Oxides 177 6.3. Interfaces with Other Conjugated Polymers and Polymer Blends 178

7. Applications 178 7.1. Light-Emitting Diodes 178

7.2. Photodiodes and Photodetectors 179

7.3. Lasers 180 7.4. Triodes 180 7.5. Light-Emitting Electrochemical Cells 180

7.6. Optocouplers 180 Acknowledgments 180 References 181 Chapter 5. SELF-ORGANIZED SUPRAMOLECULAR POLYMER

STRUCTURES TO CONTROL ELECTRICAL CONDUCTIVITY

Ollilkkala, Gerrit ten Brinke

1. Introduction 185 2. Background on Self-Organization and Supramolecular Concepts 186

2.1. Self-Organization 186 2.2. Supramolecular Assembly 188 2.3. Self-Organized Supramolecular Structures 189

3. Conducting and Semiconducting Polymer Systems Containing Self-Organized

Supramolecular Polymers 194 3.1. lonically Conducting Self-Organized Supramolecular Structures of Polymers

Hydrogen-Bonded to Amphiphiles 194 3.2. Self-Organization and Stacking of Disclike Organic Molecules 195

3.3. Self-Organization of Hairy Rods 197 3.4. Self-Organization of Supramolecular Hairy Rods 200

3.5. Externally Controllable Self-Organized Supramolecular Polymer Systems

Allowing Electrical Switching 204

4. Concluding Remarks 205 Acknowledgments 205 References 206 Chapter 6. SPECTROELECTROCHEMISTRY OF CONDUCTING POLYMERS Rudolf Holze 1. Introduction 209 2. Spectroelectrochemistry: An Introduction 211 2.1. Fundamentals 211 2.2. Spectroscopy at Surfaces 211 2.3. Spectroelectrochemistry 211 3. Polyaniline and Related Polymers 217

3.1. Formation of Polyaniline and Related Polymers 218 3.2. Properties of Polyaniline and Related Polymers and their Electrochemically

Induced Changes 227 3.3. Redox Processes of Polyaniline and Polymers of Substituted Anilines 251

3.4. Redox Processes and Electrocatalysis at Polyaniline and Related Polymers . . . 252

3.5. Degradation of Polymers 254 4. Polypyrrole and Related Polymers 256

4.1. Formation of Polypyrrole and Related Polymers 257 4.2. Properties of Polypyrrole and Related Polymers and their Electrochemically

Induced Changes 258 4.3. Degradation of Polypyrrole and Related Polymers 265

5. Polythiophene and Related Polymers 266 5.1. Formation of Polythiophene and Related Polymers 267

5.2. Properties of Polythiophene and Related Polymers and their

Electrochemically Induced Changes 269

xvi CONTENTS

Appendix 284 Acknowledgments 286 References 286 Chapter 7. ELECTRONIC SPECTRA OF CONJUGATED POLYMERS

AND OLIGOMERS

Yukio Furukawa

1. Introduction 303 2. Charge Carriers in Conjugated Polymers 304

2.1. Ground-State Structures 304 2.2. Self-Localized Excitations 305

3. Electronic Spectra 305 3.1. Neutral and Charged Oligomers 305

3.2. Neutral and Doped Polymers 313

4. Concluding Remarks 317 Acknowledgments 317 References 318 Chapter 8. STABILITY OF ELECTRICALLY CONDUCTING POLYMERS

E Mohammad

1. Introduction 321 1.1. Electrically Conducting Polymers 321

1.2. Stability of Electrically Conducting Polymers 322

1.3. Stabilization 324 2. Stability of Individual Polymeric Systems 325

2.1. Polyacetylenes 325 2.2. Polyheterocyclics 326 2.3. Polyaromatics 334 2.4. Inorganic and Silicon Polymers 341

2.5. Phthalocyanines 342 2.6. Miscellaneous Systems 343

Acknowledgments 344 References 345
