CONTEXT

Understanding petroleum composition provides the context for subsequent analytical measurements. This modern theory

• Describes petroleum composition on the basis of continuous changes as a function of the atmospheric equivalent boiling point (AEBP)

• Provides an organizing principle for relating molecular structure/properties to AEBP

• Defines the AEBP scale that encompasses the entire crude oil ABSTRACT

The model is based on the concept of the continuous variation of the chemi-cal composition and properties of petroleum as a function of the atmospheric equivalent boiling point (AEBP). The model provides an organizing principle that relates molecular structures and molecular weights to the AEBP. The hypothetical AEBP scale encompasses the entire crude oil, including the “non-distillable” residuum, allowing the comparison of crude oils and their fractions on a common, rational basis.

CONTENTS

1.1 Introduction ...4 1.2 Crude Oil Composition Conundrum ...4 1.3 “Light” and “Heavy” Crude Oils ...5 1.4 Deep-Cut Distillation and Sequential Extraction Fractionation ...9 1.5 Hypothetical AEBP Scale ... 10 1.6 Crude Oil Elemental Composition as a Function of AEBP ... 10 1.7 Crude Oil Molecular Composition as a Function of AEBP—

The Continuity Model ... 15 Acknowledgments ...30 References ...30

(28)

1.1 INTRODUCTION

A better understanding of the molecular composition of crude oil, and linking that knowledge to its physical and chemical behavior, is the key to better crude oil value assessments and predictions of the outcome of upstream and downstream operations.

This chapter discusses key aspects of the petroleum molecular composition

con-tinuity model proposed a number of years ago in a series of articles and in the book

Composition and Analysis of Heavy Petroleum Fractions [1–6].

The model is based on the concept of the continuous variation of the chemical composition and properties of petroleum as a function of the atmospheric equivalent boiling point (AEBP). This concept can be applied in a wide range of subjects, from basic thermodynamics to phase behavior, process design, and conversion unit moni-toring. It was influential in supporting the development of numerical methods used in engineering process simulators to routinely represent crude oil as a continuous mixture.

The model provides an organizing principle that relates molecular structures and molecular weights to the AEBP. The hypothetical AEBP scale encompasses the entire crude oil, including the “nondistillable” residuum, allowing the comparison of crude oils and their fractions on a common, rational basis. The continuity of chang-ing molecular composition is important when interpolatchang-ing and extrapolatchang-ing the physical and chemical properties of crude oil fractions.

The most contentious model prediction states that heavy crude oil components, including asphaltenes, have a molecular weight of <2000 Da. It recognizes the exis-tence of what we now call “archipelago”- and “island”-type molecules. All model predictions have been recently confirmed for the full range of crude oil components [7–11].

1.2 CRUDE OIL COMPOSITION CONUNDRUM

The unraveling of crude oil composition is a formidable challenge since there are hundreds of different crude oils in the world and no two crude oils are alike. The issue is further complicated by the fact that the traditional upstream and downstream approaches to crude oil composition differ, as shown in Figure 1.1.

Upstream 12% 39% 35% 14% Saturates Aromatics Resins Asphaltenes Crude oil Downstream Naphtha Distillates Vacuum gas oil

Residuum 16% 34% 23% 27%

(29)

5

Petroleum Molecular Composition Continuity Model

The upstream approach defines the gross composition of a crude oil accord-ing to the content of the four group-type components, namely saturates, aromat-ics, resins, and asphaltenes (SARA). The first step in the so-called SARA analysis involves precipitation of asphaltenes (insolubles), which are operationally defined. Their content and composition depend on the solvent used (e.g., n-C5, n-C6, or

n-C7) and the conditions of the precipitation procedure. The second step of SARA

analysis involves the use of liquid chromatography to separate maltenes (solubles) into fractions of saturates, aromatics, and resins (also known as polars). Different chromatographic methods produce different results. The use of similar terms to describe the group-type components produced by different methods introduces fur-ther ambiguity.

The downstream approach defines the gross composition of crude oil in terms of the attainable yield and quality of the fractions produced by crude oil distilla-tion as the primary refinery process. Further downstream processing involves con-version of feedstock molecules into new ones to meet the requirements of specific products.

Light transportation fuels are the highest-value petroleum products. Motor gaso-line and jet and diesel fuels together account for approximately 90% of the crude oil consumption.

This is illustrated in Figure 1.2. Major conversion processes include catalytic cracking, hydrocracking, and coking. The difficulty of downstream processing deter-mines the value of crude oil and requires molecular-level compositional information. 1.3 “LIGHT” AND “HEAVY” CRUDE OILS

Density is one of the most important properties of crude oils and their fractions, and it is a good indicator of crude oil quality. Density can be easily and precisely mea-sured at a standard temperature, usually 60°F (15°C). Specific gravity is the ratio of the density of sample to the density of water at the same temperature.

Naphtha Distillate 650°F (343°C)

Heavy ends Gas oil Residue Feedstock

Refining

Gasoline

Jet and diesel

Other products Products

650°F (343°C)

(30)

The American Petroleum Institute (API) introduced the API gravity scale to expand the narrow range in specific gravity values. The API gravity is a modified inverse specific gravity with values ranging from about 50 for very “light” crudes to about ≤10 for very “heavy” crudes (see Figure 1.3). Thus, the term “heavy” means dense. Crude oils are ranked by the API gravity. Crude oil viscosity increases rapidly with decreasing API gravity (increasing density). The relation between crude oil API gravity and viscosity is illustrated in Figure 1.4.

Distillation is the primary refinery process that separates crude oil into progres-sively higher boiling fractions or “cuts” for further downstream processing. The API gravity values for crude oil fractions decrease with increasing boiling point. In other words, the deeper we cut, the heavier it gets. This is illustrated in Figure 1.5. The API gravities for the example crude oil range from a high value of about 70°API for the first naphtha cut to a negative value of −1.6°API for deep-cut vacuum residuum (nondistillable residuum).

A barrel of 13.6°API gravity crude oil weighs 42.4 lb (19.3 kg) more than a barrel of 34.2°API gravity crude oil

42 US gal. 159 L 341.8 lb 155.1 kg 13.6°API Heavy 34.2°API 42 US gal. 159 L 299.1 lb 135.8 kg Light Gravity = – 131.5 (°API)_{Sp. Gr., 60F/60F}141.5

FIGURE 1.3 Crude oil API gravity.

Crude oil viscosity vs. API gravity 10,000 1000 100 10 1 0 10 20 30 40 50

Crude oil gravity (°API)

Vi sc osity at 50°C (c St )

(31)

7

Distillation

Naphth

as

Middle distillates Vacuum gas oil

s Va cuum re siduum 1 2 3 4 5 6 7 8 _{9 10 11 12 13 14} Cr ude oi l Naphth as Middl e distillate s Va cuum ga s oils Deep -cut vacuum residuum 80 70 60 50 40 30 20 10 0 _–10 _–20 0 10 20 30 40 50 60 70 80 90 100 Cu mu la

tive yield from cr

ude oil (w t.%) Increa sing bo iling po in t Example: 18.6°API gr av ity cr ude oi l Gravity (°API) FIG UR E 1 .5 E ff ec t o f d is ti ll at ion on A PI g ra vi ty o f c ru de o il f ra ct ion s.

(32)

The adjectives “heavy” and “high molecular weight” are commonly but incor-rectly used as synonymous terms to describe crude oils and their fractions. Figure 1.6 illustrates the dramatic effect of molecular structure on API gravity. The three compound types (paraffins, naphthenes, and aromatics) have the same carbon

num-ber but differ greatly in hydrogen content. The hydrogen-rich paraffin (C18H38) with

the highest molecular weight of 254 is the lightest of the three compounds, having

a gravity value of 48.6°API. The four-ring naphthene (C18H30), with the molecular

weight of 242, has a lower gravity value of 12.0°API. Finally, the hydrogen-poor

four-ring aromatic (C18H12), having the lowest molecular weight of 228, is the

heavi-est of the three, with a negative gravity value of −10.7°API.

Figure 1.7 shows three members of the homologous series CnH2n–24, spanning

the carbon number range from C18 to C30 and the molecular weight range from 228

to 396. The alkyl-substituted chrysene C30H36, having the highest molecular weight

of 396, is the lightest of the three compounds, with the gravity value of 6.3°API as

compared with the unsubstituted chrysene C18H12 with the lowest molecular weight

of 228 and negative gravity value of −10.7°API. The data further demonstrate that “heavy” does not necessarily mean “high molecular weight.”

Structure CH3–(CH2)16–CH3 Formula C18H38 CnH2n+2 C18H30 CnH2n–6 CnH2n–24 C18H12 Z 2 –6 –24 API Gr. 48.6 12.0 –10.7 Sp. Gr. 0.7857 0.9861 1.1714

FIGURE 1.6 Molecular structure and gravity relation.

C19H14 C30H36 CnH2n−24 (CH2)11−CH3 CH3 CnH2n–24 CnH2n–24 C18H12 228 242 396 −10.7 −8.5 6.3 1.1714 1.1504 0.9574 Formula MW API Gr. Sp. Gr.

FIGURE 1.7 Effect of increasing molecular weight on gravity for members of the

(33)

9

Petroleum Molecular Composition Continuity Model 1.4 DEEP-CUT DISTILLATION AND SEQUENTIAL

EXTRACTION FRACTIONATION

A combination of the deep-cut distillation and sequential extraction (elution) frac-tionation (SEF) was used to separate the entire heavy crude oil into a series of “nar-row” fractions down to the bottom of the barrel. This “volatility and solubility” separation scheme was developed to demonstrate the continuity of changing crude oil composition and properties.

The distillation scheme involved three distillation steps: (i) atmospheric distilla-tion, (ii) vacuum distilladistilla-tion, and (iii) short-path distilladistilla-tion, also known as molecu-lar distillation. This is illustrated in Figure 1.8.

Further separation of the nondistillable residuum into a series of solubility frac-tions was accomplished by using the SEF method illustrated in Figure 1.9. Detailed information on these separation methods can be found in earlier publications [1,2].

The underlying principles of both methods, distillation and SEF, are the various molecular interactions, called van der Waals forces. These consist of the dispersion (London) forces, permanent dipole–dipole forces, and hydrogen-bonding forces. For each homologous series of compounds, or for each compound type, the dispersion forces increase with molecular weight. As the dispersion forces increase, so does the boiling point, and so does the solubility parameter that governs the separation in liquid fractionations such as the SEF. Thus, the SEF can be considered as the “equivalent distillation.” Atmospheric distillation Naphthas Middle distillates Atmospheric residuum 8.5°API 67.0 wt.% Crude oil 18.6°API 100 wt.% Vacuum

gas oils Short-path_distillation Vacuum gas oil 13.5 wt.%10.7°API

~1200°F+ ~649°C+ Nondistillable residuum –1.6°API 28.0 wt.% Vacuum residuum 2.2°API 41.5 wt.% 1 2 3 4 5 6 7 8 9 10 11 12 13 14 Vacuum distillation

(34)

1.5 HYPOTHETICAL AEBP SCALE

The development of the hypothetical AEBP scale, extending into the nondistillable residuum fractions, was necessary to demonstrate the continuity of changing crude oil composition and properties as a function of AEBP. The AEBP scale encompasses the entire boiling range of crude oil, starting with that of atmospheric pressure, continuing with those accessible by reduced pressure, and including the equivalent boiling ranges of nondistillable residuum solubility fractions. By this stratagem of including the nondistillable residue, an entire crude oil can now be described in terms of its various physical and chemical properties as they change with increasing AEBP.

The AEBP values for distillable fractions were derived from simulated distillation measurements and represent mid-boiling point values (at 50%). The AEBP values for the nondistillable residuum solubility (SEF) fractions were calculated using earlier developed correlations, involving vapor phase osmometry (VPO) average molecular weights [4,5].

The AEBP distribution curve for the example heavy crude oil is shown in Figure 1.10. The AEBP values for nondistillable residuum fractions are inflated owing to erroneously high VPO average molecular weight values. Nevertheless, these results allow for extending the AEBP scale to cover the entire heavy crude oil on a consis-tent basis.

1.6 CRUDE OIL ELEMENTAL COMPOSITION AS A FUNCTION OF AEBP

Carbon and hydrogen are the major building blocks of petroleum molecules. Changes of carbon and hydrogen contents with increasing AEBP are illustrated in Figure 1.11. Contents of both elements decrease with increasing AEBP at the expense of increas-ing hetero-element content.

Nondistillable residuum

SEF-1 pentane soluble

SEF-2 cyclohexane soluble/pentane insoluble SEF-3 toluene soluble/cyclohexane insoluble

SEF-4 methylene chloride–methanol soluble/toluene insoluble Sequential extraction fractionation (SEF) SEF-1 SEF-2 SEF-3 SEF-4 UV/Vis profiles of the “SEF” fractions

FIGURE 1.9 Sequential extraction fractionation (SEF). (Reprinted with permission from

(35)

11

Naphth

as

Middle distillates Va

cuum

gas oils _{Residuum solubility fractions}

Cu

mu

la

tive yield from cr

ude oil (w t.%) AEBP (°F) 3000 2500 2000 1500 1000 500 0 0 10 20 30 40 50 60 70 80 90 100 Distillable fractions (1−14)

Nondistillable residuum solubility fractions (15−17

) Mid-AEBP (c alc .) Mid-AEBP (SimDis) Cr ude oil fractions 1 2 3 4 5 6 7 8 _{9 10 11 12} _{13 14} ₁₅ _{16 17 18} FIG UR E 1 .1 0 E xa m pl e h ea vy c ru de o il A E B P d is tr ibu ti on c ur ve .

(36)

Naphth

as

s

Residuum solubility fractions

Cr ude oi l fractions 100 90 80 70 60 50 40 30 20 10 0 0 300 600 900 1200 1800 2100 2400 2700 3000 1500 AEBP (°F ) H ydrogen Carb on Distillable fractions (1−4 )

Nondistillable residuum solubility fractions (15−17)

Content (wt.%) 1 2 3 4 5 6 7 8 _{9 10 11 12} _{13 14} ₁₅ _{16 17 18} FIG UR E 1 .1 1 C ar bon a nd h yd ro ge n c on te nt v ar ia ti on s a s a f unc ti on o f A E B P.

(37)

13

Sulfur is the most abundant hetero-element in crude oils. The sulfur content in different crude oils varies, as shown in Figure 1.12. Heavy crudes have high sulfur content. The high cost of sulfur removal makes sulfur content the second most sig-nificant variable (after gravity) in the cost and value of crude oil.

Figure 1.13 compares changes of hydrogen and sulfur contents with increasing AEBP. The hydrogen and sulfur concentrations in the example whole crude oil are 11.5 and 3.3 wt.%, respectively. The hydrogen content decreases from a high value of about 15 wt.% for a low-boiling naphtha fraction to a low value of about 7 wt.% for the nondistillable residuum solubility fraction SEF-3 (#17). The hydrogen dis-tribution pattern is consistent with the earlier-discussed API gravity changes (see Figure 1.5).

The sulfur content increases from a fraction of 1 wt.% in low-boiling distillate

fractions to >7 wt.% in the nondistillable residuum solubility fraction SEF-3 (#17). The sulfur concentration follows a general sulfur distribution pattern in crude oils, where distillate fractions boiling up to 650°F (343°C) account typically for about 10% of the total sulfur content in crude oil. The remaining 90% of the total sul-fur content in crude oil is usually evenly divided between the high-boiling (650– 1200°F, 343–649°C) vacuum gas oil fractions and the nondistillable residuum (1200°F+, 649°C+).

The nitrogen content in crude oils is significantly lower than sulfur, ranging from a few parts per million (ppm) by weight to <1 wt.%. Figure 1.14 illustrates the nitrogen content in different crude oils. Heavy crude oils have a high nitrogen content. Changes in nitrogen content with increasing AEBP for a sample heavy crude oil are shown in Figure 1.15. The nitrogen content in the example whole crude oil is 0.37 wt.%. Low-boiling naphtha fractions are essentially free of nitrogen. Nitrogen concentration gradually increases from a few ppm in middle distillates to about 1.4 wt.% in the SEF-3 (#17) solubility fraction derived from the nondistillable residuum.

Sulf ur content (w t.%) 8 6 4 2 0 0 10 20 30 40 50

(38)

Naphth as Middle distillates Va cuum gas oil s

Content (wt.%) 16 14 12 10 8 6 4 2 0 0 300 600 900 1200 1500 1800 2100 2400 2700 3000 AEBP (°F ) H ydrogen Sulf ur Distillable fractions (1−4 )

Cr ude oi l fractions 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 FIG UR E 1 .1 3 H yd ro ge n a nd s ul fu r c on te nt s i n h ea vy c ru de o il f ra ct ion s.

(39)

15

Figure 1.16 provides a close look at nitrogen distribution in the middle distillate boiling range. The plot shows carbon and nitrogen chromatograms (“signatures”) obtained by using gas chromatography simulated distillation (GC-SimDis) with nitrogen chemiluminescence detection.

Crude oil fractions boiling below 650°F (343°C) typically account for <1% of the total nitrogen content in crude oil. Nitrogen content in the vacuum gas oil boiling range (650–1200°F, 343–649°C) usually accounts for about 25% to 40% of the total nitrogen content in crude oil. The nondistillable residuum (1200°F+, 649°C+) con-tains the bulk of nitrogen, accounting for 60% to 75% of the total nitrogen content in crude oil.

Vanadium and nickel contents in different crude oils are shown in Figures 1.17 and 1.18, respectively. Most crude oils have a much higher vanadium than nickel content.

Variations of vanadium and nickel contents with the increasing AEBP are illus-trated in Figures 1.19 and 1.20, respectively. Both metals (V and Ni) have a bimodal distribution pattern, showing a little “hump” in the vacuum gas oil (VGO) boiling range. Direct measurement of V and Ni distribution by using high-temperature GC-SimDis with inductively coupled plasma mass spectrometry detection provides a close look at metal distribution in the deep-cut VGO boiling range (see Figure 1.21).

Literature data on oxygen concentration in petroleum are scarce, mainly because of low oxygen content in most crude oils and also because of difficulty in obtaining reliable results. Oxidation of the sample may further compromise the analysis. 1.7 CRUDE OIL MOLECULAR COMPOSITION AS A

FUNCTION OF AEBP—THE CONTINUITY MODEL

Petroleum is a complex continuous mixture of homologous series of hydrocarbons and hetero-compounds, spanning a broad molecular weight and carbon number ranges. The increased complexity arises from the progression of initially narrow molecular weight (carbon number) ranges for low-boiling fractions, consisting primarily of hydrocarbons, to wider molecular weight (carbon number) ranges for high-boiling and nondistillable fractions, containing high concentrations of hetero-elements (S, N, O, V, and Ni).

1.0 0.8 0.4 0.2 0.0 0.6 0 10 20 30 40 50

Nitrogen content (w

t.%)

(40)

Cr ude oi l fractions N content (wt.%) 2.0 1.8 1.6 1.4 1.2 1.0 0.8 0.6 0.4 0.2 0.0 0 300 600 900 1200 1500 1800 2100 2400 2700 3000 AEBP (°F ) Distillable fractions (5−14)

1 2 3 4 5 6 7 8 _{9 10 11 12} _{13 14} ₁₅ _{16 17 18} FIG UR E 1 .1 5 N it ro ge n c on te nt i n h ea vy c ru de o il f ra ct ion s.

(41)

17

0.06 0.05 0.04 0.03 0.02 0.01 0.00 200 250 300 350 400 450 500 550 600 650 700 Boiling point (°F) 0.24 0.20 0.16 0.12 0.08 0.04 0.00 NC D si gn al (c oun ts ) Carbon signature Nitrogen signature

Heavy crude oil distillate

FID sig nal (c oun ts )

FIGURE 1.16 Nitrogen distribution in the middle distillate boiling range.

10,000 1000 100 10 1 0 10 20 30 40 50

Vanadium content (ppm

w)

FIGURE 1.17 Vanadium content in different crude oils.

10,000 1000 100 10 10 20 30 40 50 1 0 Nickel content (ppm w)

(42)

Cr ude oi l fractions V content (ppm wt .%) 2000 1800 1600 1400 1200 1000 800 600 400 200 300 600 900 1200 1500 AEBP (° F) 1800 2100 2400 2700 3000 0 0 Distillable fractions (1−4 )

1 2 3 4 5 6 7 8 _{9 10 11 12} _{13 14} ₁₅ _{16 17 18} FIG UR E 1 .1 9 V an ad iu m c on te nt s i n h ea vy c ru de o il f ra ct ion s.

(43)

19

Cr ude oi l fractions Ni content (ppm wt .%) 500 450 400 350 300 250 200 150 100 50 0 0 300 600 900 1200 1500 1800 2100 2400 2700 3000 AEBP (° F)

Distillable fractions (1−14) 1 2 3 4 5 6 7 8 _{9 10 11 12} _{13 14} ₁₅ _{16 17 18} FIG UR E 1 .2 0 N ic ke l c on te nt s i n h ea vy c ru de o il f ra ct ion s.

(44)

All crude oil components can be described by the following general formula:

CnH2n+ZX

where C—carbon; H—hydrogen; X—hetero-elements (S, N, O, V, Ni); Z = −2(R+DB−1), (hydrogen deficiency value), where R—number of rings and DB— number of double bonds.

The composition of a low-boiling crude naphtha fraction is a proverbial “tip of the iceberg” as compared with the composition of high-boiling and nondistillable crude oil fractions. The number of possible compounds in naphtha fractions increases rap-idly with increasing boiling point, making the determination of the detailed naphtha composition a challenge. This is shown in Figure 1.22. There are 74 possible indi-vidual compounds, spanning the narrow C5–C8 carbon number range.

Me tal content (ppmw) 300 270 240 210 180 150 120 90 60 30 0 900 950 1000 1050 1100 1150 1200 1250 Boiling point (°F) 100 90 80 70 60 50 40 30 20 10 0 Cu m. yield (w t.%) Deep-cut VGO V (47 ppmw) Ni (32 ppmw) Cum. yield

FIGURE 1.21 Vanadium and nickel distribution profiles in deep-cut vacuum gas oil.

Normal b oiling p oint (°F ) 350 300 250 200 150 100 50 0 3 4 5 6 7 8 9 −50 Carbon number n-Paraffins iso-Paraffins Naphthenes Aromatics (4) (8) (17) (45)

FIGURE 1.22 Number of possible individual compounds in naphtha fractions increases

(45)

21

The number of possible compounds increases rapidly with increasing car-bon number, making the analysis of high-boiling fractions in terms of individual compounds a formidable challenge. The number of possible isomers for paraffins alone (see Figure 1.23) increases exponentially with increasing carbon number (and increasing boiling point).

The diversity of compound types, each involving numerous homologous series, increases with increasing boiling point. The carbon number for each homologous series also increases with increasing boiling point. Furthermore, each individual car-bon number homologue may be represented by a large number of possible isomers, resulting in very low relative concentrations of individual compounds. The immense complexity of crude oil composition, and in particular the composition of high- boiling and nondistillable “heavy” fractions, makes compositional characterization in terms of individual compounds (isomers) virtually impossible.

Great progress was made in recent years by Alan G. Marshall’s research group [7–11], using ultrahigh-resolution Fourier transform ion cyclotron resonance mass spectrometry (FT-ICR MS) to provide detailed characterization of high-boiling and nondistillable petroleum fractions.

FT-ICR MS allows detailed characterization of complex petroleum fractions at the level of elemental composition assignment, providing unambiguous molecular formula assignment for each of the thousands of peaks in the mass spectrum. The authors reported that detailed compositional characterization of a heavy vacuum gas oil provided elemental compositions for >150,000 mass spectral peaks, which allowed for the calculation of double-bond equivalent (DBE) values for the identified homologous series.

Figure 1.24 illustrates the essential fact of petroleum composition: “Diverse com-pounds with similar molar masses cover a broad boiling range, and conversely, a nar-row boiling range cut can contain a wide molar mass range” [1]. The chart serves as the foundation of the petroleum molecular composition continuity model. It provides

n-Paraffin NBP (°F ) 1600 1400 1200 1000 800 600 400 200 0 0 10 20 30 40 50 60 70 80 Carbon number 1.0E+32 1.0E+28 1.0E+24 1.0E+20 1.0E+16 1.0E+12 1.0E+08 1.0E+04 1.0E+00 No. of isomers Deep-cut VR n-Paraffin NBP No. of isomers Deep-cut VGO

(46)

an organizing principle that relates molecular structures and molecular weights to the AEBP. The chart reveals that at any given boiling point, hydrogen-rich paraffins have higher molar mass than the hydrogen-deficient polycyclic aromatic compounds and polar, polyfunctional hetero-compounds. The higher the boiling point, the wider the molar mass range.

The molecular weight (carbon number) distribution of heavy crude oil components has been a subject of many studies and controversies. Earlier reported results sug-gested that the great majority of heavy crude oil components, including asphaltenes, do not exceed a molecular weight of 2000 Da [1,2,6].

Molecular weight measurements for all distillable crude oil fractions and the first nondistillable residuum solubility fraction (SEF-1, #15) were performed using field ionization mass spectrometry (FIMS). The average molecular weights for all three nondistillable residuum solubility fractions, SEF-1, SEF-2, and SEF-3 (#15–17), were measured using VPO in pyridine. The results are shown in Figure 1.25. The VPO average molecular weight values for the three nondistillable residuum solubility frac-tions are erroneously high (particularly for SEF-2, #16 and SEF-3, #17) due to inter-molecular associations.

Atmospheric equivalent boiling point

0 200 400 600 800 1000 1200 1400 °F °C −18 93 204 315 427 538 649 760 n-C70 at 1200°F 30 28 26 24 22 18 16 14 12 10 8 6 4 2 0 20 422 282 142 0 “Nondistillable” “Distillable” n-C28 n-C20 n-C14 n-C16 n-C14 n-C10 n-C6 Carb on numb er Molar ma ss —a cy clic alkanes Cn H2n +2 n-C10 Polar p olyfunctional compound s H H H H N H N N D D N N O

(47)

23

Naphth

as

Molecular weigh t

s

Cr ude oi l fractions 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 5000 4500 4000 3500 3000 2500 2000 1500 1000 500 0 0 10 20 30 40 50 60 70 80 90 100 Cu mu la

tive yield from cr

ude (w t.%) Ligh t gr ay circles —FIM S Da rk gr ay circle s— VP O Distillable fractions (1–14)

Nondistillable residuum solubility fractions (15–17)

FIG UR E 1 .2 5 M ol ec ul ar w ei gh t d is tr ibu ti on o f h ea vy c ru de o il f ra ct ion s.

(48)

The hydrogen deficiency Z value in the general formula CnH2n+Z is a function of

the number of rings and double bonds in the molecular structure. The hydrogen defi-ciency (or “aromaticity”) can also be defined by the DBE value.

Figure 1.26 shows examples of fused aromatic ring–core structures and the rela-tion between the hydrogen deficiency (Z and DBE) values and demand for hydrogen to hydrogenate (saturate) aromatic ring–cores without ring opening.

Figure 1.27 shows changes of the average Z values as a function of AEBP. The average Z values for all of the example heavy crude oil fractions were calculated using the average molecular weight values and carbon and hydrogen contents.

The hydrogen deficiency (“aromaticity”) affects both the API gravity and the pro-pensity to form coke. Figure 1.28 illustrates changes in micro carbon residue (MCR) with increasing AEBP. The very high MCR values for nondistillable residuum solu-bility fractions suggest a high degree of aromaticity.

The Z values for the nondistillable residuum solubility fractions are erroneously low due to the inflated, erroneously high VPO average molecular weights. To illus-trate the effect of molecular weight on the calculated average Z value, three dif-ferent average molecular weight values of 1000, 1500, and 2000 Da were used to calculate the average Z value for the whole nondistillable residuum. Figure 1.29 shows variations of the average Z value with changing average molecular weight. The plot also illustrates the relation between hydrogen deficiency Z value and API gravity.

The results suggest that the average molecular weight of approximately 1000 Da and the corresponding average Z value of approximately −48 best represent the non-distillable residuum. These results also suggest that the compositional continuity for the nondistillable residuum solubility fractions (SEF-1, SEF-2, and SEF-3) is deter-mined mainly by higher hydrogen deficiency of the molecular structures (higher “aromaticity”) rather than by higher molecular weight. Figures 1.30 and 1.31 pro-vide a graphic illustration of the concept of the petroleum composition continuity model.

All model predictions have been recently confirmed for the full range of crude oil components [7–11].

CnH2n–12 CnH2n–18 CnH2n–22

C_nH_2n–36 CnH2n–28

DBE = 7 DBE = 10 DBE = 12

DBE = 18 DBE = 15

7500* 8534* 9241*

10,125* 9417*

FIGURE 1.26 Hydrogen deficiency values and demand for hydrogen in SCF H2/ Bbl

(49)

25

Cr ude oi l fractions 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 –48 –98 _–148 _–198 _–248 _–298 2 0 300 600 900 1200 1500 1800 2100 2400 2700 3000 AEBP (° F) Avg. Z value Distillable fractions (1–14) Av g. Z (MW by FIMS) Av g. Z (MW by VP O in pyridine)

FIG UR E 1 .2 7 A ve ra ge h yd ro ge n d efi ci enc y Z v al ue s a s a f unc ti on o f A E B P.

(50)

Cr ude oi l fractions 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 80 70 60 50 40 30 20 10 0 0 300 600 900 1200 1500 1800 2100 2400 2700 3000 AEBP (° F)

Micro carbon residue (w t.%)

Distillate fractions (9–14

)

FIG UR E 1 .2 8 M ic ro c ar bon r es id ue ( M C R ) a s a f unc ti on o f A E B P.

(51)

27

Distillable fractions (1–4) MW by FIMS Nondistillable residuum –1.6°API gravity MW = 1000 MW = 1500 MW = 2000 MW = ? Av g. Z value 2 –8 –18 –28 –38 –48 –58 –68 –78 –88 –98 –20 –10 0 10 20 30 40 50 60 70 80 –108 Gravity (°API)

FIGURE 1.29 Variations of hydrogen deficiency Z value with changing average molecular

(52)

0 ₁₀ ₂₀ ₃₀ ₄₀ ₅₀ ₆₀ ₇₀ ₈₀ ₉₀ 100 01 0 20 30 40 50 60 70 80 90 100 0 Aromatic s Sa turate s Comp ound-cla ss distributions Concentration, wt .% 40 08 00 1200 1600 2000 Molar ma ss distributions 45 1 59 2 722 825 887 955 ₁₀₂₃ ₁₀₈₂ ₁₁₉₉ ₁₂₅₇ Mono- Di-Tri- Tetra-Pe nta- om xar _He ati cs and/or alkane s Distillation Percent di stilled, wt.% Increasing AEBP Nondistillable re sidues Mid -To p, °F 2.4°API 5.5°API 8.7°API 13.6°API API grav ity Molar ma ss Po lars FIG UR E 1 .3 0 C om po un d-cl as s a nd m ol ec ul ar w ei gh t d is tr ibu ti on s.

(53)

29

2 3 4 5 6 7 8 9 1 Sa turate s FIMS Cu t no. Mid- Top, °F 1 2 3 4 5 6 7 8 _{9 10} Sa turate s Tr ic yclic Te trac yclic Pe nt ac yclic Hexac yclic Mono cy clic Di cy clic 0 ₁₀ ₂₀ ₃₀ ₄₀ ₅₀ ₆₀ ₇₀ ₈₀ ₉₀ 100 01 020 30 40 50 60 70 80 90 100 Concentration, wt .% 45 1 59 2 72 2 82 5 88 7 95 5 1023 1082 1199 1257 Nondistillable re sidue s “Comp ound-cl as s” fractions 1. 6 Carbon n umb er 0 Percent of to tal Homologous series Cn H2n +2 Distillation Percent di stilled, wt.% Cn H2n +2 tetrac yclic alkane s Hexa cy clic 0.217 wt .% Pe nt ac ycli c 0.399 wt .% Te trac yclic 0.385 wt .% Tr ic yclic 0.252 wt .% Ac yclic 0.105 wt .% Mono cy clic 0.112 wt .% Dic yclic 0.182 wt .% C30 C35 C40 C44 C50 C25 Ac yclic Increas ing AEBP FIG UR E 1 .3 1 H om ol og ou s s er ie s a nd c ar bon n um be r d is tr ibu ti on s.

(54)

ACKNOWLEDGMENTS

The author would like to thank Drs. Carl Rechsteiner and César Ovalles from Chevron Energy Technology Company for reading the manuscript and providing helpful comments.

REFERENCES

1. M. M. Boduszynski, “Composition of heavy petroleums. 1. Molecular weight, hydrogen deficiency, and heteroatom concentration as a function of atmospheric equivalent boil-ing point up to 1400°F (760°C),” Energy & Fuels, 1987, 1, 2–11.

2. M. M. Boduszynski, “Composition of heavy petroleums. 2. Molecular characterization,”

Energy & Fuels, 1988, 2, 597–613.

3. K. H. Altgelt and M. M. Boduszynski, “Composition of heavy petroleums. 3. An improved boiling point–molecular weight relation,” Energy & Fuels, 1992, 6, 68–72. 4. M. M. Boduszynski and K. H. Altgelt, “Composition of heavy petroleums. 4. Significance

of the extended atmospheric equivalent boiling point (AEBP) scale,” Energy & Fuels, 1992, 6, 72–76.

5. M. M. Boduszynski, J. F. McKay and D. R. Latham, “Asphaltenes, where are you?,”

Proceedings of the Association of Asphalt Paving Technologists, Louisville, KY, February 18–20, 1980, vol. 49, pp. 123–143.

6. K. H. Altgelt and M. M. Boduszynski, Composition and Analysis of Heavy Petroleum

Fractions, Marcel Dekker Inc., New York, 1994, 495 p.

7. A. M. McKenna, J. M. Purcell, R. P. Rodgers and A. G. Marshall, “Heavy petroleum composition. 1. Exhaustive compositional analysis of Athabasca bitumen HVGO distil-lates by Fourier transform ion cyclotron resonance mass spectrometry: A definitive test of the Boduszynski model,” Energy & Fuels, 2010, 24 (5), 2929–2938.

8. A. M. McKenna, G. T. Blakney, F. Xian, P. B. Glaser, R. P. Rodgers and A. G. Marshall, “Heavy petroleum composition. 2. Progression of the Boduszynski model to the limit of distillation by ultrahigh-resolution FT-ICR mass spectrometry,” Energy & Fuels, 2010,

24 (5), 2939–2946.

9. A. M. McKenna, L. J. Donald, J. E. Fitzsimmons, P. Juyal, V. Spicer, K. G. Standing, A. G. Marshall and R. P. Rodgers, “Heavy petroleum composition. 3. Asphaltene aggre-gation,” Energy & Fuels, 2013, 27 (3), 1246–1256.

10. A. M. McKenna, A. G. Marshall and R. P. Rodgers, “Heavy petroleum composition. 4. Asphaltene compositional space,” Energy & Fuels, 2013, 27 (3), 1257–1267.

11. D. C. Podgorski, Y. E. Corillo, L. Nyadong, V. V. Lobodin, B. J. Bythel, W. K. Robbins, A. M. McKenna, A. G. Marshall and R. P. Rodgers, “Heavy petroleum composition. 5. Compositional and structural continuum of petroleum revealed,” Energy & Fuels, 2013,

(55)

31

2

Process and Laboratory

Sampling for

Analytical Systems

Similarities and Subtle

Differences

William M. Cost

CONTEXT

Collection of good samples is a critical step before measuring crude oil proper-ties. A modular system is described which

• Provides acquisition of samples at the point of interest • Provides control to ensure representative sampling

• Is compatible with use both in laboratories and at the process line ABSTRACT

The objective of any analytical measurement, especially for tremendously com-plex materials such as crude oil and its fractions, is to accurately represent the measured parameter. The first step in the measurement process is to obtain a representative sample of the material of interest. A further challenge is to obtain CONTENTS

2.1 Background ... 32 2.2 Modular Sampling Platform—Why? ... 37 2.3 Modularity for Process Sampling Applications—Why? ... 37 2.4 Modular Sampling Systems for Laboratory Applications—Why? ... 42

2.4.1 Modular Laboratory System Example #1—Fermentation Off-Gas Measurement ... 42 2.4.2 Modular Laboratory System Example #2—Gas Calibration Systems ... 43 2.4.3 Modular Laboratory System Example #3—Microreactor

Monitoring Systems ... 43 2.4.4 Modular Sampling System Example #4—At-Line Laboratory

(56)

the sample from a production or process environment that is representative of the material being sampled while the sample composition continuously varies.

Conventional tube and valve sample conditioning systems are widely used to obtain samples for in-the-field measurements or for later laboratory measurements. The physical size of such systems makes them impractical for laboratory use.

A recent miniaturized, modular sample conditioning system (ANSI/ISA SP 76.00l02, sometimes called NeSSI—New Sampling/Sensor Initiative) bridges this gap. NeSSI systems have found increasing use in both the laboratory and process environments with features such as ease of use, simplicity in design, easy maintenance, and the ability to bring advanced analytical measurements to the point of interest, ideally mated to flowing systems.

This chapter discusses the application of such modular systems for the oil and petrochemical industries.

2.1 BACKGROUND

For operations in chemical manufacturing, refining, pharmaceutical, food and beverage, and biotechnology industries, as well as in municipalities, continuous monitoring of process stream chemistries or physical states is critical in sustaining production activi-ties. Analytical systems typically employed for analyzing key component(s) in process fluids (liquids or gases) are of a wide variety dependent on stream matrix and compo-nent chemical structure. The currently used technologies span a wide range, with gas chromatography being the leading technique for high-level critical process measure-ment. In process control architectures, sampling and analysis are almost always sup-ported or measured against a plant laboratory. Although laboratory measurements are completed under ideal (“ideal” is used here to describe a consistent environmental con-dition) conditions, the sample and how it was taken is critically important. In this regard, the process analyzer and laboratory instruments are similar. Both sampling approaches (process and laboratory applications) require a sample that is conditioned properly for generation of reliable data transmitted to the plant operator or controls engineer.

There are basic fundamentals of sample conditioning that must be maintained or controlled in both sampling operational schemes. As a general rule, the fundamental parameters of pressure, flow, and temperature form the framework of all sampling techniques and their proper control will limit the effectiveness of any analytical mea-surement. Each of these parameters will have varying levels of importance in each application based on stream chemistries encountered and the type(s) of analytical mea-surement implemented. Also, the conditioning location (process or laboratory environ-ment) will have a direct impact on how samples are conditioned. For instance, process analytics will require proper temperature control for applications where sample con-densation or vaporization is critical to the presentation to analytical instrumentation. Also, in process environments, flow is the most critical parameter owing to the direct impact of correlating sample flow to process changes during dynamic operation. Flow is a fundamental parameter for separation techniques such as gas or liquid chromatog-raphy but is also critical in providing consistent sample to a process analytical system. Therefore, in a process application, flow could be considered the baseline requirement of the physical parameters mentioned previously. A key difference in flow control or
