In-situ infrared thermography measurements to master transmission laser welding process parameters of PEKK

(1)

To cite this version :

Villar, Miguel

and Garnier, Christian

and Chabert, France

and

Nassiet, Valérie

and Samélor, Diane

and Diez, Juan Carlos and

Sotelo, Andres and Madre, Maria A. In-situ infrared thermography

measurements to master transmission laser welding process parameters of

PEKK. (2018) Optics and Lasers in Engineering, vol. 106. pp. 94-104.

ISSN 0143-8166

Open Archive TOULOUSE Archive Ouverte (OATAO)

OATAO is an open access repository that collects the work of some Toulouse researchers

and makes it freely available over the web where possible.

This is an author’s version published in : http://oatao.univ-toulouse.fr/19615

Official URL :

https://dx.doi.org/10.1016/j.optlaseng.2018.02.016

Any correspondence concerning this service should be sent to the repository administrator :

[email protected]

(2)

In-situ

infrared

thermography

measurements

to

master

transmission

laser

welding

process

parameters

of

PEKK

M. Villar

a

_,

_C.

_Garnier

a ,∗

_,

_F.

_Chabert

a

_,

_V.

_Nassiet

a

_,

_D.

_Samélor

b

_,

_J.C.

_Diez

c

_,

_A.

_Sotelo

c

_,

M.A.

Madre

c

a_{LGP-ENIT-INPT,}_{Université de}_Toulouse,₄₇_Avenue_d’Azereix,_Tarbes_cedex_{BP1629-65016,}_France

b_CIRIMAT,_{Université de}_Toulouse,_CNRS,_INPT,_UPS,_ENSIACET-4_allée_Emile_Monso,_Toulouse_cedex₄_{BP44362-31030,}_France c_Institute_of_materials_science_of_Aragon,_{CSIC-University}_of_Zaragoza,_Calle_de_Pedro_Cerbuna,_12,_Zaragoza_50009,_Spain

a

r

t

i

c

l

e

i

n

f

o

Keywords:

Assemblingprocess Transmissionlaserwelding Polymericmaterial PEKK

Infraredthermography Variabilitytest

a

b

s

t

r

a

c

t

Thetemperaturefieldalongthethicknessofthespecimenshasbeenmeasuredduringtransmissionlaserwelding. Polyetherketoneketone(PEKK)isaveryhighperformancethermoplasticwithtunableproperties.Wehaveshown thatthisgradeofPEKKcanbeturnedtoquasi-amorphousorsemi-crystallinematerial,duetoitsslowkinetics ofcrystallization.Itsglasstransitiontemperatureis150°C.Theeffectofitscrystallineratedirectlyimpacts itsopticalproperties:thetransmittanceofquasi-amorphousPEKKisabout60%intheNIRregion(wavelength rangefrom0.4to1.2µm)whereasitislessthan3%forthesemi-crystallinematerial.Theweldingtestshavebeen carriedoutwithan808nmlaserdiodeapparatus.Theheatfieldisrecordedduringtheweldingexperimentby infraredthermographywiththecamerasensorperpendiculartothelasersheetandtothesample’slengthtofocus ontheweldedinterface.Thestudyisdividedintwosteps:firstly,asinglespecimenisirradiatedwithanenergy densityof22J.mm−2_:_the_whole_sample_thickness_is_heated_up,_the_maximum_temperature_reaches₂₂₂_±₇_°C.

ThistemperaturecorrespondstoaboutTg+ 70°C,butthepolymerdoesnotreachitsmeltingtemperature.After

that,weldingtestswereperformed:atransparent(quasi-amorphous)sampleastheupperpartandanopaque (semi-crystalline)oneasthelowerpartwereassembledinstaticconditions.Themaximumtemperaturereached attheweldedinterfaceisabout295°Cwhentheupperspecimenisirradiatedfor16swithanenergydensity of28J.mm−2_._The_temperature_at_the_welded_interface_stays_above_T

gduring55sandreachedthemelting

temperatureduring5sbeforerapidcooling.Theseparametersaresuitabletoassemblebothpolymericpartsina strongweld.Thisworkshowsthatinfraredthermographyisanappropriatetechniquetoimprovethereliability oflaserweldingprocessofhighperformancethermoplastics.

1. Introduction

Highperformancethermoplasticsgraduallyreplacemetallicalloys insomeindustrialﬁelds,suchasaerospaceandpowerelectronics. In-deed,theyattesthighmechanicalstrengthcombinedtoheatresistance higherthan200°Caswellasresistancetocorrosion,withthe advan-tageoflightness.Thelatterresultsinprogresstowardssustainability. Amongthem,thepolyaryletherketone(PAEK)familyhasbeen demon-stratedtobethemostresistanttothermo-oxidativedegradation[1] .In particular,polyetherketoneketone(PEKK)withanEther/Ketoneratioof 1

2,keepsaconservativemodulushigherthan1GPauptoitsglass tran-sition(Tg)atabout150°C.TheadvantageofPEKKisitsslower

crystal-lization,allowingtoeasilyturnPEKKintoamorphousorsemi-crystalline polymer,comparedtowell-knownpolyetheretherketone(PEEK).More

∗ _{Corresponding}_author.

E-mailaddress:[email protected](C.Garnier).

knowledgeandknow-howaboutassemblingprocessesofPAEKwould seeminglyleadtowidespreadindustrialuses.

Among assembling processes for thermoplastics, laserwelding is anenvironmentally-friendly,fast,reliableandnon-contactprocess[2] . Weldingbytransmissionrequirestheupperparttobetransparentto thelaserwavelengthwhereastheinferiorpartabsorbsthesame wave-length.Thus,theenergyofthebeamisstoppedattheinterface, allow-ingbothpolymericpartstoheatup.Earlytheoriesonweldingstrength werebasedon diﬀusion[2] .Upon temperature,theinterdiﬀusionof polymericchainstakesplaceattheinterface,creatingmacromolecular entanglementsbetweenbothparts,resultinginastrongassembly.Laser weldingisinprincipleapplicabletoanythermoplastic,providedthat theupperpartistransparenttothelaserwavelength.Thisprocessis alreadyappliedintheindustrywithcommonpolymerssuchas polycar-bonateandPMMA[3] .

(3)

Sinceamorphouspolymersarecommonlytransparenttolaserbeam, lasertransmissionweldingisfeasible.Thus,thebeamgoesthroughthe materialwithoutinducingmajorchangesinitschemicalstructure.From aphysical pointof view,a theory todescribetheadhesion of simi-larpolymers,alsocalledautohesion,basedonthediﬀusionof macro-moleculesaboveTgwasproposedin1960sbyVoyutskii[4] andVanenin

[5] .Then,thetheoryofreptationexposedbyDeGennes[6,7] described themotionof polymericchainsandwas successfulin predictingthe molecularweightdependencyoftheself-diﬀusion.Fromthesetheories, anumberofattemptshavebeenmadeinordertolinktheprocess pa-rameterstotheinterfacialstrengthinweldingprocesses.Amongthem, Wool’smodel[8] ,predictingthemechanicalenergyrequiredtoseparate twoweldedpolymericpartsasafunctionoftime,pressure,temperature andmolecularweight,appearstobestﬁttheexperimentaldata.

Weldingasemi-crystallinepolymerisachallenge:mostofthe theo-riespredictingtheinterfacialstrengthdonottakeintoaccounttherole ofcrystallinityonself-diffusionandtheroleofthekineticsof crystal-lization.Moreover,lasertransmissionweldingrequirestheupperpart tobetransparentandtostaytransparenttothelaserbeamallalongthe process.Semi-crystallinepolymerssuchasPAEKareopaqueto visible-nearinfraredlight.Nevertheless,somestudiesgoinsidemore knowl-edgeabouttransmissionlaserweldingofPEEK:Amanatetal.[9] give theparametersrangestogetstrongweldsof250µmthickfilmswith aninfraredabsorbingmediumattheinterface,withapulsedfiberlaser withawavelengthof1060nm.Asaresult,somebubblesaretrappedat theinterface:theexplanationgivenbytheauthorsisthepresenceof wa-terinthespecimens.Potenteetal.[10] weldedundriedandpre-dried PEEK,theynoticedbubblesintheundriedPEEKweldsonly.Sometimes, heatdamagesarereported[9] onamorphousPEEKatapowerof20W withafocalplanespeedof4mm.s−1_._Despite_the_fact_that_authors_agree

abouttheeffectofwater,theprocessparameters,suchaspowerand samplespeed,arenotwelldefinedyet.Additionally,theexperimental studiesoflaserweldingprocesslackconclusivelinksbetweenprocess parametersandtheireffect onassemblies.Forinstance,theeffectof laserpoweronthetemperatureofspecimensisindefiniteuntilnow.

Measuringthetemperaturesinvolvedduringthelaserwelding pro-cessismeaningfulformanyreasons:(a)checkingthatthetemperature reachedishighenoughtoinsureself-diffusionaccordingtoautohesion theoriestogetinterfacialstrength(b)checkingthatthetemperature in-sidethepolymericpartsstayslowenoughtoavoidthermaldegradation ofthematerial,and(c)locatingtheHeat-AffectedZone(HAZ),thelatter haspossiblyundergonemorphologicalchangesandthus,modification ofpropertiesanddimensions.In-situtemperaturemeasurementswould allowgettinginsightthetransmissionlaserweldingprocesstomakeit morereliable.

Measuringthetemperatureattheinterfaceisademandingtask be-causebothpolymericpartsareinclosedcontactallalongtheprocess. So,contact-freetemperaturemeasurementtechniquessuchasinfrared (IR)thermographyhavebeenimplementedtothelaserweldingprocess insomestudies[11–14] .Inparalleltotheexperimentalwork,these au-thorshavedevelopedanumericalsimulationtopredictthetemperature attheinterface.Tovalidatetheirmodel,thechosenmaterialsareeither PMMAassemi-transparentelementandABS/PCasabsorbentpartor, inanotherstudy,polycarbonatebasedFRP(ﬁberreinforcedpolymer). Bothareamorphouspolymers,withwell-knowntransmission,reﬂection andabsorptionfactorsatnear-andmedium-IRspectrum.Todate,the laserweldingofPEKKhasnotbeenreported,duetothenoveltyofthis high-performancethermoplastic.Also,theoriginalityofthisworkisto weldtwosamplesofthesamepolymertunedintoamorphous(A-PEKK, transparent)andsemi-crystalline(C-PEKK,opaque)state.

AlthoughIRthermographyseemstobesuitedtothetransmission laserweldingprocess,nostudyusesitasatechniqueforcontrolling tem-peraturesdistributionalongthesample’sthickness.Intheexisting stud-ies,measurementswereperformedwiththecamerasensorparallelto theweldedinterface.Withsuchanexperimentalsetup,thetemperature ismeasuredattheupperorlowersurfaceofthepolymericparts.These

Fig.1. ChemicalstructureofPEKK.

calculated/experimentalresultswereimplementedtonumerical simu-lation,usingahybridcodethatcombinesMietheory[15,16] andthe MonteCarlomethod[17] toquantifythescatteringphenomena.The ex-perimentalandnumericalresultsmatchforthetemperaturesmeasured attheupperandlowersurfaces,nevertheless,thetemperatureatthe interfaceisforecastfromthesemeasurementsbutnotreallymeasured. Withthecamerasensorperpendiculartothelasersheetand perpendic-ulartothesample’slength,thetemperatureattheinterfaceofwelded assemblyisreportedfortheﬁrsttime.

Inthiswork,thefeasibilityofdeterminingthetemperature distri-butionattheinterfacealongthesample’sthicknessduringthewelding processofPEKKisoutlined.Toachievethis,theheatfieldisrecorded byinfraredthermographywiththecamerasensorperpendiculartothe lasersheetandperpendiculartheweldedinterface.Thisstudyisdivided intwosteps:Firstly,atestoflaserbeam/specimeninteractionwas per-formedinordertobringabetterunderstandingoffastheatingeffects duetohighconcentratedpowerlaserspotonasemi-crystallinePEKK. Then,fortheweldingtest,anassemblymadeofamorphousPEKKasthe upperpartandsemi-crystallinePEKKasthelowerpartwasused.The effectsofprocessparametersonthepropertiesofPEKKareexplained. 2. Materialsandmethods

AhighperformancePAEK,thepolyetherketoneketone(PEKK) Kep-stan6002byArkema waschosen.Itschemicalstructureis shownin Fig. 1 ,itismadeofetherandketonecopolymersin1

2 ratio.

Quasi-amorphousandsemi-crystallinePEKKspecimenswereused fortheweldingtest.Inthefollowing,quasi-amorphousPEKKwillbe re-ferredasA-PEKKandsemi-crystallinePEKKasC-PEKK.Bothspecimens wereprocessedbycompressionmoldingfromdriedpellets.An800kN PinetteEmidecauLAB800Photplatespresswasused;withcontrolled heatingandcoolingtemperaturesfrom2to10°C.min−1_._For_controlling

thecrystallinerateandplatedimensions,thesamplesweremadeintwo steps.Intheﬁrststep,thepelletsweremeltedat340°C,slightly com-pressedandcooleddowntoroomtemperature.Thecoolingratewas 2°C.min−1_for_the_crystallized_sample;_and_liquid_nitrogen_was_used_for

afastcoolingratetogetthequasi-amorphoussample.Inthesecondstep, thesampleswereﬂattenedupto2mmthickwhileheatingat2°C.min−1

untilglasstransitioninordertoremoveanyresidualstress.The com-pressionmoldedspecimensweredriedduring24hat140°Ctoremove waterbeforewelding.

Transmissionfactorsandreﬂectionfactorsinthewavelengthrange of400–1100nmhavebeenmeasuredwithaPerkinElmerLambda19 spectrophotometerequippedwithanintegratingsphere.Theincidence beamanglewas8° withrespecttotheperpendiculardirectionofthe samplesurface.Beforetheexperiments,thedevicewascalibratedwith aBaSbackground.Testswereperformedat20°C.

Transmissionfactorsinthewavelengthrangeof3–5µmhavebeen measuredwithaPerkinElmerSpectrumOnespectrophotometerinthe transmissionmode.Theincidencebeamangleis0° withrespecttothe perpendiculardirectionofthesamplesurface.Testswereperformedat 20°C.

DiﬀerentialScanningCalorimetry(DSC)scanswerecarriedoutwith aDSCQ200fromTAInstrumentscalibratedwithindium,startingat roomtemperatureto400°Cwitharampof5°C.min−1_._Samples_were

(4)

Fig.2. Schemeoftheprojectedlaserbeamonthespecimen,a)singlespecimen, b)assembly.

studiedasprocessed,bykeepingtheirthermomechanicalhistoryof com-pressionmoldingprocess,tobeascloseaspossibletoindustrial condi-tions.Glasstransitiontemperature(T_g),coldcrystallizationtemperature (Tcc)andmeltingtemperature(Tm)wereobtained.Coolingrampswere

performedat2°C.min−1_and₁₀_°C.min−1_from₄₀₀_to₂₀_°C.

Crystalliza-tionenthalpyandmeltingenthalpywerecalculatedbyintegrationof theareaoftheexothermicandendothermicpeaksrespectively.

Experimental near infrared laser device performs a continuous 808nmbeam,projectingasingle100×1mm2lasersheet,asrepresented

inFig. 2 .Lasersourceisfedby90diodesbranchedon6stacksof15 diodes.Laserpower issetbydiode feedingintensity,starting power emissionat13Aandreaching230Wfor40A.Nonetheless,poweris spreadoutallalongthelasersheet,soonlyactualirradiatedzonemust beconsideredininteractionforenergycalculations.Eventhoughlaser weldingisusuallyperformedindynamicsetup,statictestswerecarried outforamoreaccurateinterfacialmeasurement,andtosuppress para-siteaccumulativethermaleffectsappearingfordynamiclaserwelding. Infraredtemperaturefieldsmeasurementswereperformedwithan IRcameraCEDIP©_Jade_III_MWIR_retrofitted_FLIR©_titanium_SC₇₂₀₀

withathermalresolutionof20mKat30°C.Theuseddetectorisa mid-waveIndiumAntimonide(InSb)oneandthesensoris aclose-upx1 coveringaspectralrangefrom3.70to5.15µmwithafocalplanearray (FPA)windowingof7.6×9.9mm2_._Based_on_literature,_we_assume_the reﬂectivityofthematerialsismuchlessthan1[11] andso,thereﬂection factorisassumedtobe lessthan15%foramorphousspecimens.The detectorresolution is320×256 pixelsandthepitchof thesensoris 30µm.Soon,thepixelsizeonbothdirectionsis0.03mm.Calibration anddatarecordingweremanagedbyAltairsoftware.

Specimenswerelaidout300mmfarfromthecloseupx1sensorto havethebestsharpness.Inordertomeasuretheinterfacialtemperature andthedistributionofthermalﬁeldalongbothdirections(thicknessand lengthofthesample),side-byrecordingswereperformedscopingthe regionofinterest(Fig. 3 ).Thewholeexperimentsweredoneina25°C inathermoregulateddarkroomtoreduce theeﬀectofenvironment onIRmeasurement.Withregardtomeasuretherapidtemperaturerise

Fig.3. Infraredareaofinterestofthesamples,a)singlespecimen,b)assembly.

Fig.4. Experimentallaserdevice.

duringlaserirradiation,integrationtimewassetupat16µs,obtaining atemperaturerangefrom140to300°C.IRMovieswererecordedat 125Hzwith5imagesaveragingconducivetominimizingtherandom noise.Soon,theeﬀectivefrequencywas25Hz.Thewholeexperimental setupisshowninFigs. 4 and5 .

3. Resultsanddiscussion

UnlessthetechniqueofDSCiscontrovertedfortheanalysisofthe crystallinityof PAEKbecauseofthenearnessofmelting and crystal-lization[18] ,wechooseittocomparethethermaltransitionsofthe quasi-amorphousandcrystallized materialsbecauseof thesimplicity of use.ThethermaltransitionsattheﬁrstheatingofA-PEKKand

(5)

C-Fig.5. Layoutofinfraredrecordingscene. 50 100 150 200 250 300 350 −1.5 −1 −0.5 Temperature (°C) Heat Flow (mW)

C−PEKK−Annealed at 250°C − Heating 2°C/min A−PEKK−Heating 2°C/min

Fig.6. DSCthermogramofA-PEKKandC-PEKK:ﬁrstheatingat2°C.min−1_of

moldedsamples.

PEKK are seen in Fig. 6 . For both materials, the thermograms dis-playaglasstransitionat150°C,whenthemacromolecularchainshave gained enough mobility tomove slightly. Then, for A-PEKK, a cold crystallizationpeakis observed withamaximum at220°C followed byadoublemeltingpeakcenteredat300°C.Theenthalpyof crystal-lization(ΔHc=18.6±0.5J.g−1)islowerthantheenthalpyofmelting

(ΔH_mA=20.0±0.5J.g−1₎ _indicating _that_the_specimens _were_slightly

crystallinebeforetesting,duetothecompressionmoldingprocess.The crystallinerateisusuallygivenby:ΔHm/ΔH100%,assumingΔH100%is

122J.g−1 _like_for _PEEK _[19]_,_it_gives _an_{insigniﬁcant} _rate_of _0.01%

foramorphousA-PEKK.ForC-PEKK,nocold-crystallizationoccurs,the coolingrateappliedduringthecompressionprocessisslowenoughto al-lowthemacromoleculestoself-organizedintocrystallinephaseatmost astheycan.TheenthalpyofmeltingisΔHmC=25.6±0.5J.g−1,

corre-spondingto20.9%of crystallinitystillassumingΔH100%=122J.g−1.

SincetheC-PEKKisprocessedwithalongannealingtime,thismelting enthalpyapproachesthemaximumcrystallinityreachedbythisgrade ofPEKK.

Weldingasemi-crystallinepolymerisachallenge,sincetheupper partastostaytransparenttothelaserbeamallalongtheprocess.As soonasthecrystallinerateincreases,anysemi-crystallinepolymerturns transparenttosemi-transparenttoopaqueforhighestcrystallinerates. Itiswellknownthatitispossibletocontrolthecrystallinityby apply-ingacoolingratefasterthanthekineticsofcrystallization.Thisway, PEKKcanbeobtainedastransparentoropaquematerial.Thekineticsof crystallizationisslowforthisgradeofPEKKcomparedtootherPAEK

50 100 150 200 250 300 350 0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5 Temperature (°C) Heat Flow (mW)

PEKK−Annealed at 250°C − Cooling 10°C/min PEKK annealed at 250°C − Cooling 2°C/min

Fig.7. DSCthermogramofPEKK:coolingrampsfrommeltingstateat380°C.

400 500 600 700 800 900 1000 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Wavelength (nm) Transmission

C−PEKK

A−PEKK

Fig.8. TransmissionfactorforA-PEKKandC-PEKKmeasuredby spectropho-tometry.

[16] ,allowingthoroughlycontrollingthecrystallinityalong the pro-cessingsteps.Togofurtherthekineticsofcrystallizationofthisgrade ofPEKK,coolingrampsatvariousrateshavebeenperformed,asseenin Fig. 7 .Fromthemeltingstate,nocrystallizationoccurswhenthecooling rateis10°C.min−1_or_faster._The_glass_transition_is_broad_at₁₅₀_°C._At

(6)

400 500 600 700 800 900 1000 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Wavelength (nm)

Specular + Diffuse Reflection

C−PEKK

A−PEKK

Fig.9. ReﬂectionfactorforA-PEKKandC-PEKKmeasuredby spectrophotom-etrywithanintegratingsphere.

400 500 600 700 800 900 1000 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Wavelength (nm) Calculated Absorption

C−PEKK

A−PEKK

Fig.10. Absorbancefactor(𝛼)forA-PEKKandC-PEKK,calculatedwithEq.(1).

3.4 3.6 3.8 4 4.2 4.4 4.6 4.8 5 5.2 5.4 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Wavelength (µm) Transmission

C−PEKK

A−PEKK

Fig.11. TransmissionfactorforA-PEKKandC-PEKKmeasuredby spectropho-tometry. 0 5 10 15 20 25 140 150 160 170 180 190 200 210 220 230 240 Time (s) Temperature (°C)

0,98

0,96

0,91

0,85

0,80

Fig.12. Impactoftheemissivityratevariabilityonmaximumtemperature.

Table1

Impactoftheemissivityvariabilityontemperaturemeasurements.

Emissivity𝜺 0.80 0.85 0.91 0.96 0.98

Maxtemperature(°C) 232.25 227.55 222.35 218.34 216.81

𝚫T(°C) + 9.9 + 5.2 – − 4.01 − 5.54

2°C.min−1_,_an_exothermic_peak_indicates_the_{crystallization:}_it_could_be

interpretedastheorganizationoftheshortestchains,thelatterhaving moremobilitythanthelongestones.Theglasstransition,stillat150°C islessobviouswhenthecoolingrateislower.Asacomparison,the crys-tallinityofPEEKismaximumevenwithacoolingrateof25°C.min−1

[16] .

Forthetransmissionlaserweldingprocess,thepolymericmaterial usedastopelementhastobetransparentenoughforthelaserbeamto gothrough.Inthesameidea,thelowerelementoftheassemblyhastobe absorbenttothewavelength.TheopticalpropertiesofbothA-PEKKand C-PEKKhavebeendeterminedinthevisible-nearinfraredrange,from 400to1100nm.Anythermoplasticistransparentwhenamorphousand itturnstoopaquewhenitissemi-crystalline.

TheabsorbanceA𝜆,transmittanceT𝜆andreﬂectanceR𝜆arelinkedto

theintensityofthelightﬂux𝜑𝛾

𝜆byEq. (1 ),where??istfortransmitted

flux,iforincidentfluxandrforreflectedflux:

𝐴_𝜆+𝑇_𝜆+𝑅_𝜆=1 𝑇_𝜆= 𝜑𝑡 𝜆 𝜑𝑖 𝜆 𝑅_𝜆= 𝜑𝑟 𝜆 𝜑𝑖 𝜆 (1)

Thetransmissivitycoefficientandthereflectivity coefficienthave beenmeasuredusingaspectrophotometerwithanintegratingsphere. Forthesametemperature,thetransmissionfactorisinfluencedbythe surfaceroughness,thelightincidenceangleandthesamplethickness. The results of transmission andreflection are shown in Figs. 8 and 9 respectively.ThetransmissionoftheamorphousPEKKisnegligible between 200 and400nm,then, thetransmission factorincreases to reach65±5%atmaximumfor1100nm.Atthewavelengthof inter-est(808nm),thetransmissionfactoris60±5%at20°Cforthe2mm thicksamples.Forthesemi-crystallinesample,thetransmissionisabout 3%alloverthestudiedwavelengthrange.

(7)

0 50 100 150 200 250 300 0 50 100 150 200 250 Time (s) Maximum temperature (°C) Maximum temperature

a)

b)

c)

a)

b)

c)

Fig.13. IRthermogramduringandafterirradiation:temperature(°C)versustime(s).Theverticalboldblacklinesindicatethetimewhentheimageswererecorded.

0 2 4 6 8 10 80 100 120 140 160 180 200 220 Distance (mm) Temperature (°C) a) 0 0.5 1 1.5 2 2.5 3 3.5 4 80 100 120 140 160 180 200 220 Distance (mm) Temperature (°C) b)

Fig.14. IRproﬁlesoftheHAZ– a)AlongYaxis(lengthwise)– b)AlongZaxis(thickness).

Fig.15. Opticalphotographyofthesampleafterlaserbeam/specimen interac-tionexperiments:ontheleft:topview,ontheright:sideview.

Globalreflectionistheadditionofthespecularreflectionanddiffuse reflection.Fortheamorphoussample(A-PEKK),theglobalreflection factorisatmost12%at1000nm.

From the transmission factor and the reﬂection factor, the ab-sorbancefactor(𝛼)hasbeencalculated.TheresultsareshowninFig. 10 .

Theabsorbanceiscloseto100%forthelowestwavelengthanddecrease withwavelength.At808nm,theabsorbanceisabout25%.

Tosum up,at 808nm, the transmissionfactor is about 60%for thequasi-amorphoussample, A-PEKKreferred astransparentsample, whereasthetransmissionfactorofthesemi-crystallineC-PEKKisless than3%.Thelatterisconsideredasopaquematerialinthefollowing. Theseresultsconﬁrmwhatissupposedinotherstudies[21] ,the reﬂec-tionfactorisverylow(lessthan12%)comparedtotransmissionand absorptionfactor.

Theblackbodyisoftenusedasareferencefordeterminingthe emis-sivitycoefficientofmaterials.Theblackbodyabsorbslightinthe visi-blewavelengthrangeandtransmitsintheinfraredrange.Despite poly-meremissivitymeasurementshavebeenshowntobehighlyimprecise [20,21] ,polymersareusuallyconsideredtohavehighemissivity coef-ficients[12,22] ,theirbehaviorwithinvisibleandIRrangearecloseto thoseoftheblackbody.DuetothenoveltyofthepolymersofthePAEK family,afewopticalpropertiesareavailableintheliterature. Never-theless,theiropticalpropertiesareexpectedtobethesameasanyhigh performancepolymerinthiswavelengthrange.Toconfirmthis assump-tion,thetransmissionfactorhasbeenmeasured.Thesensorusedfor IRthermographymeasurementscoversaspectralrangefrom3.70to

(8)

0 20 40 60 80 100 120 140 160 180 200 0 50 100 150 200 250 300 Time (s) Maximum temperature (°C) Maximum temperature

a)

b)

c)

a)

b)

c)

b)

140 160 180

Fig.16. IRthermogramforweldingtest:duringandafterirradiationoftheassembly:temperature(°C)versustime(s).Theverticalboldblacklinesindicatethe timewhentheimageswererecorded.

Fig.17. Photographyoftheweldedsamples:Ontheleft:topviewofthe as-sembly,onthemiddle:sideview,ontheright:bottomviewoftheassembly– dimensionsgiveninmm.

5.15µm.Inthisrange,thetransmissionislessthan5%forA-PEKKand C-PEKK,asseeninFig. 11 .

Assuminglikeotherauthors[13] thatthereﬂectionfactorislow,we concludethatthePEKKabsorbsalmostthewholeincidentradiationin the3.70to5.15µmrange.

Thetemperaturecalculatedfromtheinfrared thermography mea-surementsdependsontheemissivityofthematerials.Toestimatethe impact of temperature variation due to theemissivity, a variability testwasundertaken. Theemissivitywassetup as0.91forthe semi-transparentPEKKand0.96fortheopaqueone;thesevaluesarein agree-mentwithpreviousstudies[12,23] .Forourvariabilitytest,the emissiv-ityfactorvariesfrom0.8to0.98.Theeﬀectontheresultingmaximum temperatureisplottedinFig. 12 .TheresultsarereportedinTable 1 , where𝜀=0.91ischosenasareference:variationsofthemaximum

tem-peraturearewithintherangeof−5.5°C–+9.9°C.Standarddeviation𝜎

andaverageµ ofthisdatasetarerespectively6.44°Cand223.46°C. ThecoeﬃcientofvariationC_v,canbecalculatedasfollow:

𝐶_𝑣 = (1+ 1 4𝑛

)

×σ

μ (2)

wherenisthepopulation,𝜎isthestandarddeviationandµ isthe

av-erage.Withexperimentaldata,C_v is0.03.Duetotheverylowvalue ofCv,thefollowingemissivitycoeﬃcientsareﬁnallyused:0.91forthe transparentmaterialand0.96foropaqueone.

3.1. Laserbeam/specimeninteraction

Inordertosetupalltheinfraredmeasurements,experimentswere performedonasinglesample.Laserpower,measuredinWatt,isset dur-ingagiventime(s)uponthespottedarea(mm2₎_brings_energy_density_in

J.mm−2_._Energy_density_was₂₂_J.mm−2_for_the_laser_{beam/specimen} in-teractiontests.AnIRmoviewasrecordedusingtheparametersdefined intheexperimentalsection.Alltheimageswereprocessedseekingto matchmeasuredareatothespecimensize.Aplotofthemaximum tem-peratureandthreeimagesatdifferentstepsareprovidedinFig. 13 to showaqualitativedistributionofthethermalfieldsinthesample thick-ness.

Duetotheintegrationtimeapplied,onlytemperatureabove140°C isconsidered.Thisthermogramconﬁrmsthatrealirradiationtimelasts about20s.Theheatingrateisveryfast;itiscalculatedat600°C.min−1

inaverage.

Attheendoftheirradiationat22J.mm−2_,_the_maximum tempera-turereachedis222±7°C.Thistemperatureisabout70°Chigherthan theglasstransitionofthepolymer.Thewholethickness(2mm)ofthe sampleisaﬀecteduniformlybythetemperaturerise.Theheat-aﬀected zone(HAZ)iswiderinthedirectionparalleltothelaserbeamatthe endoftheirradiation.Assoonastheirradiationisstopped,theHAZ be-comeswiderandwiderduetoheatconduction.Afterirradiation, ther-malwavespropagateperpendicularlytoleadtoahomogeneouscircular

(9)

shapeHAZintheobservedplane,attheendoftheexperiment.The cool-ingrateofthesampleis270°C.min−1_in_the_ﬁrst₁₀_s_and_decreases_to

150°C.min−1 _in_the_following₂₀_s._According_to_the_results_obtained

byDSC,thetemperaturealongthesample’sthicknesswashigherthan theglasstransition(150°C)during34sforanirradiationof21s.The polymerdoesnotreachitsmeltingpointwiththistimeandpowerof exposure.

ThedimensionsoftheHAZisdeterminedusingprofileonboth di-rectionsfortemperatureabove150°C.InFig. 14 , bothprofilesbring HAZsize:4mmlengthwiseand4mmallalongthesample’sthickness. Thewholethicknessisthermallyaffected,thatmatcheswithvisual ob-servationinFig. 15: theHAZappearsonbothsurfacesofthesample, wheretheaffectedzoneslookbrighterandsmootherthantherestofthe sample.Thesameisobservedontheuppersurfaceofthesample. 3.2. Weldingtests

Afterthetestoflaserbeam/specimeninteraction,IRmeasurements wereperformedduringweldingofacoupleof2mmthickspecimens. A-PEKKwasusedastopelement,C-PEKKforthebottom.Theenergy densitywasdeterminedpreviouslyandfixedat28J.mm−2_for_this_test. Theevolutionof themaximum temperatureof theassemblywas recordedduringwelding,stillwiththecamerasensorperpendicularto thelasersheetandperpendiculartothesample’slength.Theresultsare plottedinFig. 16 ,aswellasimagesatdifferentstepsoftheprocessto haveaqualitativedistributionofthethermalfields.

Aspreviously,onlytemperatureabove140°Cisconsidereddueto theintegrationtimeapplied.Realirradiationtimeisabout16s.As ex-pectedintransmissionlaserwelding,theenergyofthebeamisstopped attheinterfacesincethelowerpartisabsorbentat808nm.The max-imumtemperatureduringtheprocessis295±7°Cforanirradiation

at28J.mm−2_._This_temperature_is_about₁₄₀_°C_higher_than_the_glass transition,andabout20°Chigherthanthebeginningofthemeltingof PEKKoccurringat275°C.Theheatingrateduringirradiationismore than600°C.min−1_._Unlike_for_the_laser_{beam/specimen}_interaction

pre-sentedinFig. 13 ,theheat-aﬀectedzoneinthelowersampleis symmet-ricalinbothdirections,alongsideandperpendicularlytothelasersheet, whereastheHAZisstretchedoutintheupperpart.

Whentheirradiationisstopped,thetemperatureinthelowerpart graduallydecreases.Thecoolingrateisabout300°C.min−1_the_ﬁrst₁₀_s

justaftertheirradiationisstopped.ThetimeneededtoreachT_gon cool-ingfromthemaximumtemperature(295°C)is42s.Theaveragecooling ratebetweentheirradiationisstoppedandtheTgisabout200°C.min−1.

FromDSCresults,weexpectnocrystallizationofA-PEKKuponcooling, thecoolingrateistoofast.

Uponcooling,theHAZintheupperpartincreases,andmore,the HAZinthelowerparttremendouslystretchesout.Inall,thetemperature attheinterfaceof bothsampleswashigherthantheglass transition during55sandhigherthanthemeltingtemperatureduring5sforan irradiationtimeof16s.

ThephotographyoftheresultingassemblyispresentedinFig. 17 . ThedimensionsoftheHAZmeasuredfromthesepicturesarein agree-mentwiththedimensionsobtainedbyinfraredimages.

4.Conclusion

Thetemperaturedistributiononthesurfacealongthesample’s thick-nesshasbeenmeasuredduringtransmissionlaserwelding.The origi-nalityofthisworkistoplacethecamerasensorperpendiculartothe lasersheetandperpendiculartotheweldedinterface.Withsuchan ex-perimentalsetup,thetemperaturesattheweldedinterfaceandalong thethicknessofthespecimenshavebeenmeasured.Weareawarethat thetemperaturesmeasuredarenotrepresentativeoftheonesinsidethe sample(xaxis),duetothediﬀerenceofpropagationofheatwaves in-sidethematerialandinair.Nevertheless,thetemperaturemeasuredon

thesurfaceofassembliesishelpfultolinktheprocessparameters(laser powerandlaserspeed)tothemechanicalstrengthofweldedinterfaces. Forthisstudy,ahigh-performancethermoplastic,PEKKwaschosen, itsglasstransitionwasmeasuredat150°Canditsmeltingrangebetween 275and320°C.Thematerialwasprocessedbycompressionmoldingto getquasi-amorphoussamples,referredasA-PEKKandfullycrystallized, referredasC-PEKK.Theiropticalpropertiesaswellaskineticsof crys-tallizationhavebeenoutlined.Itistheﬁrsttimethelaserweldingof PEKKisreported.

Thelaser beam/specimeninteractiontestwas performedwith C-PEKKirradiatedat22J.mm−2_._The_maximum_temperature_reached_by

thesampleisabout220°Candthetemperaturealongthesample’s thick-nessstaysaboveTgduring34swhentheirradiationsteplasts21s.When

theirradiationisstopped,theheat-aﬀectedzone(HAZ)hasinitiallya longitudinalshapealongthewholethicknessofthesample.Theshape oftheHAZbecomessymmetricalintheobservedplanefor20safterthe irradiationisstopped.

Forthe welding test, anassembly made of a transparent (quasi-amorphous)sampleastheupperpartandopaque (fullycrystallized) sampleasthelowerpartwasused.Themaximumtemperaturereached attheinterfaceisabout295°Cwhentheupperspecimenisirradiated for16swithanenergydensityof28J.mm−2_._The_temperature_along thesample’sthicknessstaysaboveTgduring55sandabovethemelting

temperatureduring5s.Thistimeisobviouslyenoughtoallow macro-moleculestoself-diﬀuseandtocreateentanglements.Indeed,the ob-tainedassemblylooksstrong,althoughnomechanicaltesthasbeen per-formeduntilnow.

ThisgradeofPEKK,withaslowkineticsofcrystallizationissuitable forlasertransmissionwelding.Withtheenergybeamandirradiation timestudied,themaximumtemperatureinsidethesampleiskeptfar fromthedegradationofPEKK.Finally,thelocationandsizeofthe heat-aﬀectedzone(HAZ)havebeendetermined.Thisworkisasteptowards morereliabilityofthelaserweldingprocess.Infutureworks,the in-terfacialstrengthofweldedassemblieswillbestudiedbymechanical tests.

Acknowledgment

TheauthorswouldliketothanktheFrenchMinistryofHigher Edu-cationandResearchforFinancialsupportthroughaPhDfunding. References

[1] TarrieuJ.Etudeetdurabilité desolutionsdepackagingpolymèred’uncomposant diamantpourl’électroniquedepuissancehautetempératurePhDThesis.Institut NationalPolytechniquedeToulouse;2012.

[2] WiseRJ.Thermalweldingofpolymers.AbingtonPublishing;1999.p.21.

[3] KleinR.Laserweldingofplastics.Wiley-VCH;2012.

[4] VoyutskiiSS.Autohesionandadhesionofhighpolymers.Wiley;1963.

[5] VaseninRM.Adhesionpressureinthediﬀusiontheoryoftheadhesionofpolymers. PolymSciU.S.S.R1962;3(4):608–15.

[6] DeGennesPG.ComptesRendusdel’AcadémiedesSciences1980;B291:219–21 Paris(inFrench).

[7] DeGennesPG.Reptationofapolymerchaininapresenceofﬁxedobstacles.JChem Phys1971;55(2):572–9.

[8] WoolRP,YuanBL,McGarelOJ.Weldingofpolymerinterfaces.PolymEngSci 1989;29(19):1340–67.

[9] AmanatN,etal.Transmissionlaserweldingofamorphousandsemi-crystalline polyetheretherketoneforapplicationsinthemedicaldeviceindustry.MaterDes 2010;31:4823–30.

[10]PotenteH,etal.Investigationstowardsapplicationofanewtechniqueonlaser transmissionwelding.WeldWorld2001;45(5-6):15–20.

[11]IlieM,etal.Through-transmissionlaserweldingofpolymers– ﬁeldmodelingand infraredinvestigation.InfraredPhysTechnol2007;51:73–9.

[12]SpekaM,etal.Theinfraredthermographycontrolofthelaserweldingofamorphous polymers.NDT&EInt2008;41:178–83.

[13]Akué AssékoA,etal.Lasertransmissionweldingofcomposites-partA: thermo-phys-icalandopticalcharacterizationofmaterials.InfPhysTechol2015;72:293–9.

[14]Akué AssékoA,etal.Lasertransmissionweldingofcomposites-partB:experimental validationofnumericalmodel.InfPhysTechol2015;73:304–11.

[15]GouesbetG,GréhanG.GeneralizedLorenz–Mietheories,frompasttofuture.Atomic Sprays2000;10(3–5):277–334.

[16]GouesbetG,GréhanG.GeneralizedLorenz–Mietheoriesforassembliesofspheres andaggregates.JOpt1999;1:706–12.

(10)

[17]BlancaCM,SalomaC.MonteCarloanalysisoftwo-photonﬂuorescenceimaging throughascatteringmedium.ApplOpt1998;37(34):8092–102.

[18]JonasA,LegrasR,IssiJP.Diﬀerentialscanningcalorimetryandinfraredcrystallinity determinationsofpoly(aryletheretherketone).Polymer1991;32(18):3364–70.

[19]Mehmet-AlkanAA,HayJN.Thecrystallinityofpoly(etheretherketone).Polymer 1992;33(16):3527–30.

[20]BeckerF.Asteptowardsunderstandingtheheatingphaseoflasertransmission weld-inginpolymers.PolymEngSci2002;42(2):365–74.

[21]VandeVenJ,ErdmanA.Lasertransmissionweldingofthermoplastics– partII: experimentalmodelvalidation.ManufSciEng2007;129:859–67.

[22]IlieM,etal.Laserbeamscatteringeﬀectsinnon-absorbentinhomogenouspolymers. OptLasersEng2007;45:405–12.

[23]CossonB,etal.Infraredheatingstagesimulationofsemi-transparentmedia(PET) usingraytracingmethod.IntJMaterForm2011;4(1):1–10.

(11)

M.Villarisamechanicalengineerwithaspecializationinmaterialsscience,thermalandenergytechnologies.Afterbeinginvolvedinsomeindustrialprojects, hewentontodevelophisscientiﬁcproﬁlewithaPhDthesisinPolymerPhysics.HisPhDthesistopicsapplythetransmissionlaserweldingtoassemblea newkindofpolymerofthePAEKfamily.Forthetimebeing,theworkshehasaccomplishedcoversthethermal,opticalandmechanicalcharacterizationof materialsandprocesses.

C.GarnierhasbeengraduatedbytheNationalEngineeringSchoolofTarbes.In2011,hedefendedhisPhDthesisuntitled“DynamicBehaviorofLRI’s compositestructures:applicationtoimpactandfatigue”.In2013,hejoinedtheLaboratoryofManufacturingEngineeringinTarbes,partoftheUniversityof Toulouse,France,asassociateprofessor.Hisresearchinterestsincludeallaspectsofcompositematerials(manufacturing,behavior,FEM,inspection,tests). Hisresearchspeciallyfocusesoncompositematerialbehaviorinstatic,fatigueandmultiaxialfatigue,onexperimentalmechanicsandonthermalﬁelds measurements.

F.ChabertobtainedaPhDdegreeinMaterialsandProcessEngineeringin2004attheInstitutNationalPolytechniqueofGrenoble– Franceintheﬁeldof materialsforfuelcells.SheworkedaspostdoctoralfellowsuccessivelyattheChemicalEngineeringDepartmentattheUniversityofMelbourne,Australia andESPCIParistech,France.Since2010,sheisateacher-researcherattheInterfaceandFunctionalMaterialsgroupoftheLaboratoryofManufacturing EngineeringinTarbes,partoftheUniversityofToulouse.Herresearchfocusesonpolymerprocessing,assemblingprocessesforthermoplasticsaswellas nanoandmicro-compositeswithcontrolledproperties.Shehasco-authored4patentsand15scientiﬁcarticles.

V.NassietisProfessorofmaterialsengineeringattheNationalEngineeringSchoolofTarbes(ENIT)since2012.ShegraduatedwithaPh.D.inPhysics fromtheUPPAUniversity,France,in1995.AssociateProfessorfrom1997to2012attheLaboratoryofManufacturingEngineeringinTarbes,partofthe UniversityofToulouse,sheholdsahabilitationthesis(HDR)attheInstitutNationalPolytechniqueofToulouse,France.Herresearchinterestsfocusonthe physical,chemicalandmechanicalpropertiesofadhesiveinterfacesinmulti-materialsandoninterfacedurability.Themainaimistheestablishmentof reliablerelationshipsbetweenthepolymeric(adhesiveorresinmatrix)structureanditspropertiessuchasmechanical,rheological,thermalandadhesives intotheinterface.

D.SamélorhasbeengraduatedinMaterialsEngineeringbyEvry-Val-d’EssonneUniversityin2001.ShecompletedherMasterswithspecializationonmethods ofpreparationandcharacterizationofthinﬁlmsinthesameuniversityin2002.In2003,shejoinedtheCIRIMATlaboratoryinToulouseasanengineer.Her activitiesarefocusedonpreparationofceramics,metalsandcompositesbyMetalOrganicChemicalVaporDeposition(MOCVD)andcharacterizationofthe coatingsbyconventionalormorespeciﬁctechniques.

J.C.DiezteachesattheUniversityofZaragoza’sSchoolofEngineeringandArchitecture(DepartmentofMaterialsScience).HeholdsaPhysicsDegree andPh.D.fromtheUniversityofZaragoza.Since1989heteachesinthisUniversity,insubjectsmainlyrelatedwithGeneralPhysics,MaterialsScience, TechnologyofCeramicsandMaterialsLaserProcesses.Heismainlyinterestedontheuseoflasertechnologytoimprovethepropertiesoffunctionalceramics (HTcsuperconductorsandthermoelectricoxides).Hehasalsoexperienceintheuseoflaserradiationonmetals,polymers,andcompositematerials,especially onthemoldsectorandinaeronauticapplications.

(12)

A.SotelohadhisDoctoraldegreeinChemistryattheUniversidaddeZaragozain1994.Hehasgotatwo‐yearspostdoctoralpositionatMax‐PlanckInstitute forMetalsResearchinStuttgart(Germany)in1995.In1997hegottwoyearsMarieCuriegrantinCRISMATLaboratoire,Caen(France).From2000heis ProfessorattheUniversidaddeZaragozaintheDepartmentofMaterialsScience.Hehaspublishedmorethan135scientiﬁcarticlesandbookchapters,most ofthemrelatedtothermoelectricandsuperconductingceramicswithemphasisonlaserprocessingtechniques.

M.A.MadrehasbeengraduatedinChemistrybytheUniversityofZaragoza.ShehasgotPh.D.inEngineeringbytheUniversidaddeZaragozawith qualification:CumLaudewithExtraordinaryDoctorateAward.Since1991sheisUniversityProfessorattheDpt.MaterialsScienceintheSchoolofEngineering andArchitecture.Herresearchinterestsincludeaspectsof:Thermoelectricandsuperconductingceramics.Texturingofceramicsbylasertechniques,laser appliancesinotherfields,solutionchemicalsynthesistechniques,andmechanicalproperties.Shehaspublishedmorethan110scientificarticlesandbook chapters.
