Adaptive Authentication Integration Options. John Murray Manager, RSA Systems Engineering

(1)

Adaptive Authentication Integration Options

(2)

#RSAsummit

What is RSA Adaptive Authentication?



Comprehensive authentication

and fraud detection platform



Powered by Risk-Based

Authentication technology

–

Measures risk associated with a

user’s login and post-login

activities

–

Determines level of

authentication required based on

risk, policies, and customer

(3)

#RSAsummit

The Risk Engine

Gathers Facts

Build Profiles, Generates

_{Predictors, & Learns}

Assesses Risk

Internet Protocol (IP)

Information

Proprietary Device

Fingerprints

User Behavior

RSA eFraudNetwork

RSA

Risk Engine

Scoring

Results

(4)

#RSAsummit

(5)

#RSAsummit

On Premise



J2EE Java Based Application

installed and maintained within

a customer’s own datacenter.



Flexible Platform Support

Including:

–

OS: Windows Server, Red Hat Enterprise

Linux, Solaris and AIX

–

Application Servers: WebSphere, Web

Logic, JBoss, Tomcat

(6)

#RSAsummit

Hosted



AA fully hosted in the cloud by

RSA.



Integration handled via SOAP

calls over HTTPS.



Access to back office tools

granted via online web portals.



New re-architected 12.0 platform

to be released Q4 2014, running

on an elastic cloud provider.

(7)

#RSAsummit

Integration Method

(8)

#RSAsummit

Direct Integration



Standard code (SOAP) based

integration following

Request-Response model between

Application and AA Server



Customer integrate into their own

applications by developing against

the AA WSDL



Standard methods include:

–

Analyze, Notify, Query, Challenge,

UpdateUser, CreateUser,

Authenticate

(9)

#RSAsummit

SOAP Request Example

<soapenv:Envelope xmlns:soapenv="http://schemas.xmlsoap.org/soap/envelope/">

<soapenv:Body>

<ws:analyze>

<ws:genericActionTypes>SessionSignIn</ws:genericActionTypes>

<ns1:httpAcceptChars>ISO-8859-1,utf-8;q=0.7,*;q=0.3</ns1:httpAcceptChars>

<ns1:httpAcceptLanguage>en-US,en;q=0.8</ns1:httpAcceptLanguage>

<ns1:httpReferrer>http://rsademos.com:8080/demobank/index</ns1:httpReferrer>

<ns1:ipAddress>158.24.172.5</ns1:ipAddress>

<ns1:userAgent>Mozilla/5.0 (Windows NT 5.2; WOW64) AppleWebKit/537.17 (KHTML, like

Gecko) Chrome/24.0.1312.57 Safari/537.17</ns1:userAgent>

<ws:userName>jmurray</ws:userName>

<ws:userStatus>VERIFIED</ws:userStatus>

<ws:userType>PERSISTENT</ws:userType>

<ws:apiType>DIRECT_SOAP_API</ws:apiType>

<ws:requestType>ANALYZE</ws:requestType>

<ws:version>7.0</ws:version>

<ws:callerCredential>Password</ws:callerCredential>

<ws:callerId>Caller</ws:callerId>

</ws:analyze>

</soapenv:Body>

</soapenv:Envelope>

(10)

#RSAsummit

Credential

store

Customer

browser

Web

servers

App servers

App

_database

Firewall

DMZ

Firewall

TRUSTED ZONE

AA SaaS – Direct Integration Architecture

RSA Adaptive

Authentication

(SaaS)

INTERNET

(11)

#RSAsummit

Credential

store

Customer

browser

Web

servers

App servers

RSA Adaptive

Authentication

App

database

RSA AA

database

Firewall

DMZ

TRUSTED ZONE

AA – Direct Integration

AA On Prem – Direct Integration Architecture

INTERNET

(12)

#RSAsummit

Adapter



Pre-built integrations with popular

enterprise portals



No software development

required



Full customizable pages handle

entire workflow and interaction

with AA Server including:

–

Enrollment

–

Forensics Collection

–

Challenging

–

Blocking

Current RSA Adapters

RSA Access Manager*

Tivoli Access Manager

CA SiteMinder

Juniper SSL VPN

Cisco SSL VPN

Citrix NetScaler

Microsoft UAG

(13)

#RSAsummit

(14)

#RSAsummit

(15)

#RSAsummit

Mobile Browser - Data Collection

Data collected via JavaScript:

Browser characteristics: Browser type,

version, language, etc.

Device forensics: Time zone, Screen

resolution.

Geolocation: Latitude, Longitude, Accuracy,

Additional Information:

• User Agent String

• IP Address

• Cookie

• FSO

WAP sites:

• WAP header sent as the HTTP header

(16)

#RSAsummit

Mobile Apps – Data Collection



Data elements collected and sent to AA using either Mobile SDK

or a native API

–

Location information collection

–

Mobile device identification data

Device model

multitasking

Device

supported

Device Name

Device System

Name

Device System

Version

Language

Wi-Fi Mac

Address

Wi-Fi Networks

data: Station

Name

Wi-Fi Networks

data: BBSID

Wi-Fi Networks

data: Signal

Strength

Wi-Fi Networks

data: Channel

Wi-Fi Networks

data: SSID

Cell Tower ID

Location area

code

Screen size

address book

Number of

entries

RSA Application

(17)

#RSAsummit

What To Protect

(18)

#RSAsummit

Transaction Monitoring



Allows AA Risk Analysis and Actions to be applied to Post

Login Events



Has the ability to monitor both:

–

Profile Changes – Changes to the user’s password, address,

e-mail, security question, phone numbers, etc.

–

Funds or Financial Transfers – Add Payee, Add Beneficiaries,

Request Credit Increase, Request Checks, etc.



Events will utilize additional information as part of risk

model. E.g. Payment:

(19)

#RSAsummit

AA Full Event Type List

CREATE USER

DEPOSIT

EDIT PAYEE

ENROLL

FAILED CHANGE PASSWORD

ATTEMPT

FAILED LOGIN

AUTHENTICATION

FAILED OLB ENROLLED

ATTEMPT

OLB ENROLL

OPEN NEW ACCOUNT

OPTIONS TRADE

PAYMENT

READ SECURE MESSAGE

ACTIVATE CARD

ADD PAYEE

CHANGE ADDRESS

CHANGE ALERT SETTINGS

CHANGE AUTH DATA

CHANGE EMAIL

CHANGE LIFE QUESTIONS

CHANGE LOGIN ID

CHANGE PASSWORD

CHANGE PHONE

CHANGE STATEMENT

SETTINGS

CHANGE STU

CLIENT DEFINED

REQUEST CHECK_COPY

REQUEST CHECKS

REQUEST CREDIT

REQUEST NEW CARD

REQUEST NEW PIN

REQUEST STATEMENT COPY

SEND SECURE MESSAGE

SESSION SIGNIN

STOCK TRADE

UPDATE USER

USER DETAILS

VIEW CHECK

VIEW STATEMENT

(20)

#RSAsummit

More Fraud Stopped and Fewer Customers Challenged

Transaction Monitoring

Increase in fraud detected when adding

transaction level protection

Increase in fraud detected from Device

ID to Device ID & eFraudNetwork

(21)

#RSAsummit

Challenge Methods

(22)

#RSAsummit

An additional factor or procedure that validates a user’s identity,

out-of-the-box options include:

“Step-up” Authentication

•Secret questions that have been selected & answered by end user during

enrollment

Challenge

Questions

•One time passcode sent to the end user via phone call, SMS text message or

email.

•Transaction details, such as transfer amount, can be included

Out-of-Band

Authentication

•Dynamic questions that are unique to the end user, and generated from publically

& commercially available data in real-time

•Provided by LexisNexis Identity Verification service (available in US & UK)

Dynamic

Knowledge-Based Authentication

(KBA)

•Allows organizations to use “in-house” or third party method through a RSA
