NeuroMAX: A High Throughput, Multi-Threaded, Log-Based Accelerator for Convolutional Neural Networks

(1)

NeuroMAX: A High Throughput, Multi-Threaded, Log-Based

Accelerator for Convolutional Neural Networks

Mahmood Azhar Qureshi

Kansas State University Manhattan, KS, US [email protected]

Arslan Munir

Kansas State University Manhattan, KS, US

[email protected]

ABSTRACT

Convolutionalneuralnetworks(CNNs)requirehighthroughput

hardwareacceleratorsforrealtimeapplicationsowingtotheir

hugecomputationalcost.MosttraditionalCNNacceleratorsrely

onsinglecore,linearprocessingelements(PEs)inconjunctionwith

1Ddataflowsforacceleratingconvolutionoperations.Thislimits

themaximumachievableratioofpeakthroughputperPEcount

tounity.Mostofthepastworksoptimizetheirdataflowstoattain

closetoa100%hardwareutilizationtoreachthisratio.Inthispaper,

weintroduceahighthroughput,multi-threaded,log-basedPEcore.

Thedesignedcoreprovidesa200%increaseinpeakthroughput

perPEcountwhileonlyincurringa6%increaseinareaoverhead

comparedtoasingle,linearmultiplierPEcorewithsameoutputbit

precision.Wealsopresenta2Dweightbroadcastdataflowwhich

exploitsthemulti-threadednatureofthePEcorestoachievea

highhardwareutilizationperlayerforvariousCNNs.Theentire

architecture,whichwe refertoasNeuroMAX,isimplemented

onXilinxZynq7020SoCat200MHzprocessingclock.Detailed

analysisisperformedonthroughput,hardwareutilization,areaand

powerbreakdown,andlatencytoshowperformanceimprovement

comparedtopreviousFPGAandASICdesigns.

KEYWORDS

Convolutionalneuralnetworks (CNNs) ,hardware accelerator,

multi-threaded,throughput,hardwareutilization

ACMReferenceFormat:

MahmoodAzharQureshiandArslanMunir.2020.NeuroMAX:AHigh Throughput,Multi-Threaded,Log-BasedAcceleratorforConvolutional NeuralNetworks.InProceedingsofIEEE/ACMInternationalConferenceon Computer-AidedDesign(ICCAD’20).ACM,NewYork,NY,USA,9pages. https://doi.org/10.1145/3400302.3415638

1 INTRODUCTION

Convolutionalneuralnetworks(CNNs)enableembeddingofAI

intodevicesforvision-basedapplicationswithanunprecedented

ac-curacy.TheearlyproposedhighaccuracyCNNs[1–3]requiredtens

ofmillionsofparametersandcomputationsforoneinferencepass.

Thiscomputationalcomplexityalongwithhighmemory

require-mentsgreatlyhamperedtheirdeploymentonlowenergy,resource

constraineddevices.Inadditiontothis,manyCNNarchitectures

usedvaryingkernelsizeswhichresultsinreconfigurability

require-mentaswellaslowhardwareutilizationinacceleratordesigns.

Separable convolution for CNNs was introduced the first time in mobilenets [4, 5] to reduce the number of multiply and accumulates

(MACs). In addition, many modern CNNs use kernels of size 3×3 to

promote ease of accelerator design with high hardware utilization and throughput.

Design of an efficient dataflow for scheduling data into the ac-celerator is equally important. An inefficient dataflow results in reduced hardware utilization which causes a decrease in through-put. Dataflow should also promote the reusability of data since, in most cases, the same kernels are being applied on the entire input feature map. It has been shown previously that the

move-ment of data to/from DDR memory is 200×more costly in terms

of energy consumption than a standard MAC operation [6]. Thus, the dataflow design should not only optimize the throughput and area, but also the data movement, in order to ensure reduced energy expenditure. Log-based accelerators have recently gained quite a lot of traction because of their simpler structure as compared to traditional accelerators with linear processing elements (PEs). Each PE in traditional CNN accelerator cores is essentially responsible for one multiplication in convolution operation. Log PEs replace

the bulky multiplier cores with lowcostbarrel shifters without

incurring a significant loss in accuracy. We clarify that cost here primarily refers to the area cost, which is determined by the num-ber of LookUp Tables (LUTs) for field-programmable gate arrays (FPGAs) and gate count for application-specific integrated circuits (ASICs). This area cost is important because there are limited re-sources on-chip and thus this area cost also translates to monetary cost of system-on-chip (SoC). Many past approaches have designed log-based PE elements but have not exploited the low cost and over-head of such PEs. They instead rely on already established spatial architectures and 1D dataflows used for linear PEs. Our proposed

NeuroMAXaccelerator core comprises of 108 PEs arranged in a

6×3×6, 3D spatial grid. The presented accelerator optimizes the

most commonly used 3×3 and 1×1 kernel sizes to achieve high

throughput and utilization. It can also be used for larger kernel sizes because of its grid structure and configurable 2D dataflow. Our main contributions are as follows:

• We design a multi-threaded, low cost, log-based PE core.

Using this core, we generate a spatial grid of 108 PEs, capable of performing a wide variety of convolution operations with high hardware utilization.

• We develop a 2D dataflow which exploits the thread based

PE design to maximize the throughput and enhance data reuse to minimize the DDR memory access.

• We implement the entire NeuroMAX architecture in an

FPGA and show improved performance in terms of area, throughput, hardware utilization, latency and power effi-ciency compared to past approaches.

(2)

Figure 1: Linear vs. Log Quantization (a) 1.5 bits linear VGG16 net (b) 5.0 bits log VGG16 (c) 5.1 bits log VGG16 (d) 1.5 bits linear SqueezeNet (e) 5.0 bits log SqueezeNet (f) 5.1 bits log SqueezeNet

2 RELATED WORK

Many hardware accelerators have been proposed recently and in the past. [7] proposed a non-systolic array, reconfigurable spatial

archi-tecture along with a new dataflow scheme calledrow stationaryto

maximize the data reuse. However, this design incurs high PE cost owing to local storage and control in PE. It also has low hardware utilization which results in low throughput per PE. [8] proposes an FPGA-based CNN accelerator with integrated depth-wise separable mode of operation. This accelerator, however, has low throughput because of the usage of 32-bit floating point format. [9] proposes an FPGA-based CNN accelerator having a dedicated matrix multiplica-tion engine (MME) on Arria 10 SoC. It achieves a frame rate of 266 fps, however, its MME engine has a huge digital signal processing (DSP) cost of 1200+ DSP blocks. [10] is the improved version of [7] with higher hardware utilization and throughput. [11] introduced the concept of logarithmic data representation for neural network accelerator designs. It also gives accuracy comparison between linear and log quantization. [12] proposes an accelerator design using arbitrary log base. It, however, does not utilize the low hard-ware overhead of the log-based PE and instead rely on linear PE arrangements. [13] proposes a reconfigurable design for various convolution kernels. It uses a propagated input data flow scheme but incurs high latency and low hardware utilization. [14] proposes a rescheduled dataflow for convolution to optimize the energy effi-ciency. [15] proposes a vectorwise accelerator architecture with the goal of maximizing the hardware utilization. It supports various

kernel sizes from 1×1 to 5×5.

Although some of the recent designs achieve high hardware utilization, they are not able to increase the peak throughput per PE count beyond unity owing to the use of single core, linear PEs with high area cost. This paper overcomes the limitations of prior

works by leveraginglogPEs with multiple low cost threads within

each log PE, and designing a 2D dataflow which promises high throughput by exploiting multi-level parallelism.

3 LOG MAPPING

Log mapping or log quantization maps an input value𝑥to a

log-arithmically quantized value𝑥′. Many trained neural nets have

weightswand input activationsawhich are non-uniformly

dis-tributed. Mapping these 32-bit floating point (fp32), non-uniformly distributed values over fixed point, linearly quantized values intro-duces significant amount of quantization noise for small bit width.

Most hardware platforms use fixed point arithmetic for data

manip-ulation where the fixed point number is represented in signed𝑄𝑚 .𝑛

format. Here,𝑚represents the integer part whereas𝑛represents

the fractional part. The range of values which can be represented are𝑟 𝑎𝑛𝑔𝑒_{𝑙 𝑖𝑛}=[−2𝑚−1,2𝑚−1−𝜖]where,𝜖=2−𝑛, is the step size.

A linear quantizer rounds the fp32 value to the nearest multiple

of𝜖and then clips it as follows:

𝑥𝑞=𝑐𝑙 𝑖 𝑝 h 𝑟 𝑜𝑢𝑛𝑑( 𝑥 𝜖 )·𝜖,−2𝑚−1,2𝑚−1−𝜖 i (1) where, 𝑐𝑙 𝑖 𝑝(𝑥 , 𝑚𝑖𝑛, 𝑚𝑎𝑥)=          max, 𝑥 ≥𝑚𝑎𝑥 𝑥, 𝑚𝑖𝑛<𝑥<𝑚𝑎𝑥 min, otherwise (2)

A log quantizer takes as input,𝑥and the quantization parameters

<𝑚, 𝑛, 𝑏 >, where𝑏is the logarithmic base, and produces a log

quantized value𝑥′as output. The quantization process can be

written as: 𝑥′=𝑐𝑙 𝑖 𝑝(𝑟 𝑜𝑢𝑛𝑑(𝑙𝑜𝑔_𝑏(|𝑥|))),−2𝑚−1,2𝑚−1−𝜖 (3) 𝑥𝑞= ( 0, 𝑥 =0 𝑠𝑖𝑔𝑛(𝑥) ·𝑏𝑥 ′ , 𝑜𝑡 ℎ𝑒𝑟 𝑤 𝑖𝑠𝑒 (4) Figure 1 shows some of the quantization results for the first five convolution layers of VGG16 [2] and SqueezeNet [16]. Instead

of using log base-2 for quantization, we use log base-√2 for more

accurate mapping as shown in Figure 1(c) and (f). Infact, we observe that VGG16, pretrained on ImageNet dataset, with fp32 data, after

base-√2 quantization, has top-1 accuracy decrement by only≈3.5%

from 67.5% to 63.8%. This is opposed to log base-2 quantization

which decreases the accuracy by≈10%. This observation has also

been verified in [11].

4 HARDWARE ARCHITECTURE

4.1 Top-Level

Figure 2 shows the top level hardware architecture of the pro-posed NeuroMAX CNN accelerator on Zynq-7020 SoC. The CONV core is the accelerator module containing a memory block, a state controller, PE grid, adder stages and post processing module. The memory block contains the weight, input and output SRAMs with a total cumulative size of 3.8Mb. The PE grid consists of 108 PEs

arranged in 6×3×6 3D array. Figure 2 also shows the internal

(3)

Figure 2: NeuroMAX System Architecture

The PE matrices are all connected to their respective input, weight and output SRAM blocks. Each PE matrix processes independent channels in parallel for standard and separable convolutions for maximizing the throughput. The outputs from the PE matrices are provided to their respective adder nets within the PE grid. A total of six adder net 0s are present corresponding to six PE matrices. The configuration of these adder nets remain constant regardless of the type of convolution used or the filter size. The output from the adder net 0 is provided to six configurable two-stage adders whose input connections change based on the filter size and the convolution type. The first adder stage is referred to as adder net 1 and the second stage is the channel accumulation stage.

To perform a convolution operation, a tile of log quantized input fmap and weight data is loaded from the off-chip DDR memory into the SRAMs in the CONV core by AXI DMA and interconnect. The processor also sends the parameter information containing the values for filter size, input width, input height, output width, output height and total channels to the state controller inside the CONV core. The state controller modifies the configurable adders and determines the dataflow to be used for convolution operation. The linear convolution outputs are sent to the post processing block which performs ReLU operation and quantizes the results back into log values using pre-computed log table. These output log values are loaded into the output SRAMs and sent back to the off-chip DDR memory to be used for processing the next layer. No intermediate outputs or partial sums are stored in the DDR memory and all the intermediate processing is done within the CONV core to minimize the off-chip traffic.

4.2 PE Matrix

Figure 3 shows the hierarchical design of a single PE matrix (PE matrix 0) from left to right in a bottom up view. Each PE receives a 1D vector of weight values and one input value. It should be

noted that both the input (i0’) and the weight values (w00-2’) are log

quantized. The output vectors from PEs are provided to the adder net 0 which generates 18 psums (o1-o18). This adder net works by summing the same color coded values generated within a row of PEs as shown in Figure 4.

Figure 3(b) shows the internal structure of a single PE element (PE0_0_0). There are three compute cores or threads, each processing a single weight data and the input value, and in turn, produce three

outputs (p11,p12,p13). The lowest level of the PE matrix is a thread

within an individual PE as shown in Figure 3(a). Basic log-based multiplication operation is performed in a single thread. Assuming

we have two log quantized values,wq’andaq’, representing the

original weight (wq) and the activation input (aq) respectively, the

multiplication of these values in log domain can be carried out as: 𝑤𝑞𝑎𝑞=𝑠𝑖𝑔𝑛(𝑤𝑞) ·2 𝑔𝑞 ′ (5) where, 𝑔 ′ 𝑞=𝑤 ′ 𝑞+𝑎 ′ 𝑞 (6)

[12] showed a method to implement the exponential in equation (5) in hardware by decomposing the exponent into its integer and fractional part as:

𝑤𝑞𝑎𝑞=𝑠𝑖𝑔𝑛(𝑤𝑞) ·2 𝐼 𝑁 𝑇(𝑔𝑞 ′ ) ·2𝐹 𝑅𝐴𝐶(𝑔𝑞 ′ ) ₍₇₎

The integer part 2𝐼 𝑁 𝑇(𝑔𝑞

′

)_{can be implemented by a shift}

opera-tion, whereas, the fractional part can be pre-computed and stored within the thread. The total number of fractional computations depends on the total number of fractional bits (n) used. In our case,

we have𝑛=1 and thus store 2𝑛=2 values in the thread memory.

Equation (7) can now be rewritten as: 𝑤𝑞𝑎𝑞=𝑠𝑖𝑔𝑛(𝑤𝑞) · (𝐿𝑈 𝑇(𝐹 𝑅𝐴𝐶(𝑔𝑞

′

))>>¬𝐼 𝑁 𝑇( (𝑔𝑞 ′

))) (8)

The hardware implementation of equation (8) is shown in Figure 3(a). Since weights can have negative values, which is not accounted for in the log computations, we use an additional bit to represent the

log weight data with the most significant bit𝑤′

𝑞[6]representing the

sign of the weight before quantization. This is not required for the input fmap values since most modern CNNs use ReLU activations which eliminate the negative outputs.

5 DATA FLOW AND PROCESSING

The main idea behind designing an efficient dataflow is to minimize the data movement to/from the costly off-chip DDR memory. One MAC operation typically requires three memory reads correspond-ing to weight, ifmap, psum and one memory write correspondcorrespond-ing to the updated psum. A neural net like AlexNet, with 724M MACs, will

need≈3000M DDR memory accesses. Many efficient dataflows have

been presented in literature to minimize this data movement. Some

of these includeoutput stationary,weight stationaryand,row

sta-tionary[17]. Since convolution operation requires the reuse of filter

weights, input and psums in successive operations, the dataflows are designed to optimize the re-usability without accessing the DDR memory. We introduce a 2D weight broadcast dataflow for maximizing the re-usability of the weights, input and psums.

5.1 3 x 3 Convolution

Figure 5 shows a 3×3 convolution example. Here, a 12×6 input is

convolved with a 3×3 filter to produce a 10×4 output for stride 1

and a 6×3 output for stride 2. A total of 108 bits, corresponding

to the 6×3 input tile, are received from the AXI4 interconnect

and stored in the input SRAM. This input tile is modified by the state controller and provided to the PE matrix in a row shifted pattern as shown in Figure 6(a) and (c) for stride 1 and stride 2, respectively. We also acquire a 2D weight array and broadcast it to the PE matrix as shown in Figure 6(b). Figure 7 shows the dataflow and the operation of the PE matrix for the first 6x3 input tile and the weight matrix at time stamp t = 1. The entire input tile and

(4)

Figure 3: (a) Compute Thread (b) Collection of Threads to Make a PE (d) 6x3 PE Matrix 0 and Adder Net 0

Figure 4: Adder Net 0 psum Generation

Figure 5: A Convolution Example with 12×6 Input, 3×3 Filter for Stride 1 and 2

the 2D weight array is loaded into the PE matrix simultaneously. Because of the multi-threaded structure of PEs, each PE performs three multiplication operations using three threads and the outputs are row-wise summed to generate the psums (o1-o18) using adder net 0 (Figure 4). The dataflow chart and the processing of the entire

12×6 input is shown in Figure 8. The output a₀wa₀₁₂, in Figure

8, represents the three outputs a0wa0, a0wa1, a0wa2generated by

three threads within a PE. The adder net 0 computes the partial

Figure 6: State Controller Operation (a) Input, Stride 1 (b) Filter Weights (c) Input, Stride 2

Figure 7: 2D Weight Broadcast Dataflow

sum outputs (o1-o18) the same way as shown in Figure 4, where

p11= a0wa0, p14= b0wb0and p17= c0wc0are the same colored

(5)

Figure 8: Dataflow Chart for 3×3 Stride 1 Convolution in Figure 5

Figure 9: Adder Net 1 Configuration (a) Stride 1 (b) Stride 2

The dark red outputs (row 5 and 6) in Figure 5 for stride 1 and green outputs (row 3) for stride 2 represent the boundary outputs. The boundary condition occurs when the filter overlaps two dif-ferent column-wise input tile sectors. For clarity, we assume that the first input tile at t = 1 is processed by the PE matrix. This cor-responds to the first six rows and the first three columns of the input. The PE matrix will process the last row-wise input tile at t = 4 which corresponds to the first six rows and the last three columns of the input as shown in Figure 6(a). The input tile will then jump to the next column-wise 6x3 input tile which corresponds to the last six rows and the first three columns at t = 5 as shown in Figure 6(a). However, it can be seen that the row 5 and 6 in the output are dependent on the overlapping results from the two concurrent column-wise input tile sectors (e.g. at t = 1 and t = 5, t = 2 and t = 6 and so on). To resolve this, the three dependent psums (o13, o17 and o16), generated from row 5 and row 6, of first column-wise tile sector of the 12x6 input, are passed through a variable length shift

Figure 10:1×1Convolution Example

register with the maximum length equal to the width of the input. These psums are subsequently utilized when the next column-wise

6x3 input tile (a6to a11) is being processed. Thus, the rows 1 to 4

in the output are generated during the time intervals t = 1 to t = 4, whereas the rows 5 to 10 are generated during the time interval t = 5 to t= 8.

The output in Figure 5, for stride 1, is generated by alternate colored, column-wise summation of the psums in the adder net 1 as shown in Figure 9(a). Figure 9(b) shows the output generation for stride 2 case. The shift registers (VAR Len SR) for generating the boundary outputs are also shown in Figure 9. It can be observed that because of the optimized dataflow, only 2 out of 18 or 11% psums require local storage as opposed to >50% psums requiring storage (local or off-chip) in previously proposed dataflows. The throughput for the above example is 45 OPS/cycle (total OPS/total cycles =

360/8 = 45), which results in an 83.3% overall thread utilization

(45/(3×6×3))×100. We will simply use thread utilization as hardware

utilization in this context.

5.2 1 x 1 Convolution

1×1 convolutions are very popular in modern CNNs. These

con-volutions, along with the depth-wise separable, are replacing the normal 2-D convolutions because of the less number of MAC

oper-ations [4]. The 1×1 CONV operation convolves 1×1×𝐶×𝑃filters

with a𝑀×𝑁×𝐶input to produce𝑀×𝑁×𝑃outputs. Here, C is

the number of channels, P is the number of filters, M is the input width and N is the input height.

Figure 10 shows a 1×1 CONV example where a 3×6×6 input is

convolved with 6, 1×1×6 filters to produce a 3×6×6 output. Since

this convolution generates the psums by channel accumulation, the outputs from the multiple PE matrices are utilized. For the example

(6)

Figure 11: State Controller Load Operation

Figure 12: Dataflow Chart for 1×1 Convolution in Figure 10

in Figure 10, the state controller data scheduling for PE matrix 0 and 1 is shown in Figure 11. It can be seen that the first three channels of the input are convolved with the first three channels of all the filters in PE matrix 0, whereas, the last three channels of the input are convolved with the last three channels of all the filters in PE matrix 1. The time stamps during specific processing of input and weights in PE matrices are also shown in Figure 11. It should be noted that for an input with more channels, the rest of the PE matrices will also be used. Thus, by using the dataflow in Figure 11, the architecture can process 18 channels concurrently by using the 6 PE matrices, with each PE matrix processing 3 input and filter channels.

The dataflow chart for the PE matrix 0 for the example in Figure 10 is shown in Figure 12. The same dataflow chart can also be

generated for the PE matrix 1. As mentioned earlier, the psums in 1×

1 convolution are calculated using channel-wise accumulation. The eighteen outputs (o1-o18) generated by the individual PE matrices are summed in their respective adder net 1s. The input connections for adder net 1 (AN 1_0) and the channel accumulator (CA 0) of PE

Figure 13: (a) Channel-wise accumulation for PE matrix 0 (b) All channel-wise accumulations

Figure 14: (a)5×5Convolution Example (b) Input Load Op-eration (c) Weight Load OpOp-eration

matrix 0 are shown in Figure 13(a). Here, o10is the psum output

from the PE matrix 0 and o15is the psum output from the PE matrix

5. Since the example in Figure 10 is small, it only requires the first

two PE matrices and their outputs, that is, only o10-180and o11

-181are active. The output in Figure 10 is generated by using all

six adder net 1s and the channel accumulators as shown in Figure 13(b). The throughput for the above example is 108 OPS/cycle (total

OPS/total cycles = (6×6×3×6/6=108), which results in a 100%

overall thread utilization (108/(3×6×3×2))×100.

5.3 Higher Order Convolutions

The proposed NeuroMAX accelerator is designed to optimize 3×3

and 1×1 convolutions. It can, however, also be used to accelerate

larger kernel sizes. [18] proposed a kernel decomposition method

such that an additional support for 4×4 and 5×5 filter is needed

to implement any filter size. Figure 14(a) gives an example of 5×5

convolution. As the size of the PE matrix is 6×3, a filter of width

greater than 3 and height greater than 6 needs multiple cycles to calculate the output value. This can be seen in Figure 14(b) and (c) where the last two columns of the input matrix and the weight matrix are loaded at time stamp t = 2. Figure 15 shows the dataflow

(7)

Figure 15: Dataflow Chart for 5 × 5 Convolution in Fig-ure 14(a)

Figure 16: Adder Configuration for5×5Convolution

chart which accounts for this configuration. The generated psums (o1-o18) are provided to the adder net 1 as shown in Figure 16. For this convolution, the output values are calculated as:

𝑉 𝑎0, 𝑉 𝑎2=( (𝑜1+𝑜5+𝑜9) + (𝑜10+𝑜14))𝑜𝑙 𝑑+ (𝑜1+𝑜5+𝑜9)𝑛𝑒 𝑤 (9) 𝑉 𝑎1=( (𝑜4+𝑜8+𝑜12) + (𝑜13+𝑜17))𝑜𝑙 𝑑+ (𝑜4+𝑜8+𝑜12)𝑛𝑒 𝑤 (10)

In equations (9) and (10), theoldvalue corresponds to the

con-volution output from the first three columns of the input and the

weight matrix at𝑡=1, whereas, thenewvalue corresponds to the

last two columns at𝑡=2. The adder net 1 and the channel

accumu-lator configuration for this convolution is shown in Figure 16. A similar configuration and dataflow chart is used for implementing

a 4×4 convolution. In addition to this, the CONV core can also

perform pooling operation by choosing the appropriate stride and kernel.

6 IMPLEMENTATION AND RESULTS

This section discusses the implementation of the proposed Neuro-MAX accelerator and presents the area cost, power consumption, performance, throughput, and hardware utilization results. The accelerator has been implemented on the PL side of Xilinx Zynq-7020 SoC operating at 200MHz. Figure 17 shows cost comparison between our multi-threaded log PE core and an area optimized linear multiplier core with equal output bit precision and latency. It can be seen that by choosing a thread count of 3 (shown as log (3)

in Figure 17), the LUT and FF cost is only 1.05×and 1.14×that of

the linear PE. Thus, a total of 108 linear PEs would be equivalent,

in cost, to≈122 multi-threaded log PEs. For fairness, we will use

the cost adjusted PE number for performance comparison.

Figure 17: Linear vs Log PE LUT and FF Cost (16-bit) Table 1: Resource Utilization

Property Accelerator Utilization

#LUTs 20680 38%

#FFs 17207 16%

#36kB BRAMs 108 77%

Power 2.727 W NA

Figure 18: Breakdown of (a) LUT cost (b) FF cost (c) Power Consumption for NeuroMAX

Table 1 shows the resource utilization of the implemented ac-celerator core as well as the total power consumption (static + dynamic). Figure 18 (a), (b), (c) shows the breakdown of LUT cost, FF cost and power consumption among different modules of the accelerator. The PE grid and the adder net 0 combined have the highest LUT and FF count (81% and 91%, respectively). The post processing block consumes negligible resources. The processing system (ARM core) dominates the power consumption (57%), while the PE grid and adder net 0 have the second highest consumption (26%) of the total.

Figure 19 shows layer by layer hardware utilization for various CNN architectures. We achieve an average utilization of 95%, 84% and, 86% for VGG-16, MobileNet v1 and, ResNet-34, respectively. The dip in hardware utilization in some layers of mobilenet and ResNet-34 is because of stride 2 convolutions which utilize only 50% of the available PE cores. The low utilization in the first layer of VGG16 is because it only has 3 channels and since each PE matrix processes one channel, the last 3 PE matrices remain idle which gives an exact utilization of 50%.

Chang et al. [15] recently presented an accelerator design with 1D broadcast dataflow which promises higher utilization and through-put (GOPS) then all the previous designs. We, therefore, compare our design against [15] in Figure 20 for various CNNs. [15] uses a total of 168 PE cores and provides a utilization of 99% with

(8)

Table 2: Comparison of NeuroMAX with Previous Designs

Property NeuroMAX [7] [8] [9] [10] [12] [15]

Technology Zynq-7020 SoC 65nm Zynq-7100 Arria 10 SoC 65nm Virtex-7 40nm

Precision(bits) 6-bit log 16-bit 32fp 16-bit 8-20 bits 5-bit log 16-bit

PE number 122(adjusted) 168 1926 1278 192 256 168

Processing clock (MHz) 200 200 100 133 200 Unreported 500

Peak Throughput (GOPS) 324 84 17.11 170.6 153.6 Unreported 168

Peak Throughput/PE 2.7(adjusted) 0.5 0.008 0.13 0.8 Unreported 1

Cost (LUTs(a),gates(b)) 20.6k(a) 1176k(b) 142k(a) 66k(a) 2695k(b) 29k(a) 266k(b)

Power (W) 2.72 0.278 4.083 Unreported 0.460 3.756 0.155

Figure 19: Hardware Utilization of NeuroMAX for (a)VGG-16 (b) MobileNet v1 (c) ResNet-34

Figure 20: PE count vs Utilization vs Throughput Compari-son of NeuroMAX with [15]

with throughput 151.54 GOPS for VGG16, ResNet-34 and mobilenet,

respectively. We use 122 PE cores (cost adjusted), a 28% decrease

from [15], and provide a throughput of 307.8 GOPS, an 85% increase,

281.8 GOPS, a 79.4% increase, and 268.92 GOPS, a 77.4% increase,

for the three CNNs, respectively. This increase in throughput with lower PE count is attributed towards our low cost, multi-threaded PE core design and an efficient 2D dataflow. We also achieve

some-what similar hardware utilization, that is, 94% for VGG16, 87.3%

for ResNet-34 and, 83% for mobilenet. It should be noted that [15] implements the accelerator on an ASIC, whereas, we use an FPGA, thus, an accurate comparison in LUT count, FF count and, power consumption cannot be made. It is, however, evident that the design

in [15] when ported into FPGA will have≈31% more LUTs and FFs

owing to more number of PEs used.Table 2 shows the comparison of our accelerator with previous state of the art ASIC and FPGA designs. We see an improved performance in terms of PE number, peak throughput and peak throughput/PE ratio. Only [15] has a peak throughput/PE ratio equal to unity with average around 0.85. Our peak throughput/PE is 3 with average around 2.7 after cost adjustment. The power comparison reveals that the FPGA-based de-signs inherently consume more power compared to ASICs. We can,

however, see that NeuroMAX consumes significantly less power and has lower cost in terms of LUT count compared to other FPGA designs. Table 3 gives a layer-by-layer processing latency compari-son for VGG16. Both [7] and [15] benchmark the latency of their accelerators on this CNN, therefore, we also evaluate and compare NeuroMAX’s performance on VGG16. It should be noted however that [15] uses 500MHz processing clock in their design. For fair comparison, we make suitable adjustments in their reported values. Our proposed NeuroMAX accelerator has 93% and, 47% decrease in latency, when compared to [7] and [15], respectively, at 200 MHz

clock. _{Table 3: VGG16 Latency Comparison}

Layer NeuroMAX [7] [15] CONV1_1(ms) 1.35 38.0 2.57 CONV1_2(ms) 28.9 810.6 55.04 CONV2_1(ms) 14.4 405.3 27.43 CONV2_2(ms) 29.26 810.8 55.7 CONV3_1(ms) 14.54 204 27.7 CONV3_2(ms) 28.6 408.1 54.5 CONV3_3(ms) 28.7 408.1 54.6 CONV4_1(ms) 14.4 105.1 27.42 CONV4_2(ms) 29 210.0 55.23 CONV4_3(ms) 29.5 210.0 56.19 CONV5_1(ms) 7.24 48.3 13.79 CONV5_2(ms) 7.23 48.5 13.77 CONV5_3(ms) 7.11 48.5 13.54 Total(ms) 240.23 3755.3 457.5

7 CONCLUSION

This paper proposes NeuroMAX, a high throughput accelerator using multi-threaded, log-based PE cores. The designed PE cores are capable of providing a 200% increase in peak throughput while only increasing the area overhead by 6%, when compared to a standard multiplier-based PE core. We also design an efficient 2D weight broadcast dataflow scheme which exploits the multi-level parallelism of our processing engine and enables hardware uti-lization close to 100%. The accelerator is capable of performing a wide variety of convolutions including standard and separable

3×3 stride 1 and 2, 4×4, 5×5 and 1×1 depthwise, required in

modern CNN architectures. We have implemented NeuroMAX on Xilinx Zynq-7020 SoC and have evaluated various performance parameters. The design can provide at least a throughput increase

of 77.4% and a latency decrease of 47% with a 28% decrease in PE

count against recently proposed accelerator designs for modern CNNs. NeuroMAX also provides at least a 27% and a 29% decrease in power consumption and LUT count, respectively, against prior FPGA-based CNN accelerators.

(9)

REFERENCES

[1] Alex Krizhevsky, Ilya Sutskever, and Geoffrey E. Hinton. Imagenet classification with deep convolutional neural networks. InProceedings of the 25th International Conference on Neural Information Processing Systems - Volume 1, NIPS’12, page 1097–1105, Red Hook, NY, USA, 2012. Curran Associates Inc.

[2] Karen Simonyan and Andrew Zisserman. Very deep convolutional networks for large-scale image recognition, 2014.

[3] Christian Szegedy, Wei Liu, Yangqing Jia, Pierre Sermanet, Scott Reed, Dragomir Anguelov, Dumitru Erhan, Vincent Vanhoucke, and Andrew Rabinovich. Going deeper with convolutions. InComputer Vision and Pattern Recognition (CVPR), 2015.

[4] Andrew G. Howard, Menglong Zhu, Bo Chen, Dmitry Kalenichenko, Weijun Wang, Tobias Weyand, Marco Andreetto, and Hartwig Adam. Mobilenets: Effi-cient convolutional neural networks for mobile vision applications, 2017. [5] Mark Sandler, Andrew Howard, Menglong Zhu, Andrey Zhmoginov, and

Liang-Chieh Chen. Mobilenetv2: Inverted residuals and linear bottlenecks, 2018. [6] Mark Horowitz. 1.1 computing’s energy problem (and what we can do about it).

volume 57, pages 10–14, 02 2014.

[7] Y. Chen, T. Krishna, J. S. Emer, and V. Sze. Eyeriss: An energy-efficient recon-figurable accelerator for deep convolutional neural networks.IEEE Journal of Solid-State Circuits, 52(1):127–138, 2017.

[8] Bing Liu, Danyin Zou, Lei Feng, Shou Feng, Ping Fu, and Junbao Li. An fpga-based cnn accelerator integrating depthwise separable convolution.Electronics, 8(3):281, 2019.

[9] L. Bai, Y. Zhao, and X. Huang. A cnn accelerator on fpga using depthwise separable convolution.IEEE Transactions on Circuits and Systems II: Express Briefs,

65(10):1415–1419, 2018.

[10] Yu-Hsin Chen, Tien-Ju Yang, Joel Emer, and Vivienne Sze. Eyeriss v2: A flexible accelerator for emerging deep neural networks on mobile devices, 2018. [11] Daisuke Miyashita, Edward H. Lee, and Boris Murmann. Convolutional neural

networks using logarithmic data representation, 2016.

[12] Sebastian Vogel, Mengyu Liang, Andre Guntoro, Walter Stechele, and Gerd Ascheid. Efficient hardware acceleration of cnns using logarithmic data repre-sentation with arbitrary log-base. InProceedings of the International Conference on Computer-Aided Design, ICCAD ’18, New York, NY, USA, 2018. Association for Computing Machinery.

[13] Y. Huan, J. Xu, L. Zheng, H. Tenhunen, and Z. Zou. A 3d tiled low power acceler-ator for convolutional neural network. In2018 IEEE International Symposium on Circuits and Systems (ISCAS), pages 1–5, 2018.

[14] J. Jo, S. Kim, and I. Park. Energy-efficient convolution architecture based on rescheduled dataflow.IEEE Transactions on Circuits and Systems I: Regular Papers, 65(12):4196–4207, 2018.

[15] K. Chang and T. Chang. Vwa: Hardware efficient vectorwise accelerator for convolutional neural network. IEEE Transactions on Circuits and Systems I: Regular Papers, 67(1):145–154, 2020.

[16] Forrest N. Iandola, Song Han, Matthew W. Moskewicz, Khalid Ashraf, William J. Dally, and Kurt Keutzer. Squeezenet: Alexnet-level accuracy with 50x fewer parameters and <0.5mb model size, 2016.

[17] V. Sze, Y. Chen, T. Yang, and J. S. Emer. Efficient processing of deep neural networks: A tutorial and survey.Proceedings of the IEEE, 105(12):2295–2329, 2017. [18] Y. Lin and T. S. Chang. Data and hardware efficient design for convolutional neural network. IEEE Transactions on Circuits and Systems I: Regular Papers, 65(5):1642–1651, 2018.
