INTELLIGENT MEDIA STORAGE
WATER & DUST PROTECTED • SECURE • CERTIFIED!
HARD DRIVES LTO CONTAINERS & INSERTS CERTIFICATIONS MASTERPAX
3 1
We use high-impact absorbing customized resin that takes a beating. Drop it. Hit it. Kick it around. This container is certified to last.
DIMENSIONS
Ext: 27” x 11.5” ax 5.9” Int: 25” x 9.75 x 5.5”
Strong, positive double latching system with butterfly clasps and lockable hasps. Latches are riveted to the conatiner and tested for durability. (Locks not included)
1) Ergonomic molded handle is metal rived to container. 2) Oversized bumper protects container.
3) Sturdy, comfortable grips for carrying containers.
3 1
2
We use high-impact absorbing customized resin that takes a beating. Drop it. Hit it. Kick it around. This container is certified to last.
DIMENSIONS
Ext: 14.75” x 11.5” ax 5.9” Int: 12.25” x 9.75 x 5.5”
Strong, positive double latching system with butterfly clasps and lockable hasps. Latches are riveted to the conatiner and tested for durability. (Locks not included)
1) Ergonomic molded handle is metal rived to container. 2) Oversized bumper protects container.
3) Sturdy, comfortable grips for carrying containers.
2
The XpresspaX™, Inc. interchangeable color-coded media tray insert system, is a unique storage method that allows you to use the same size containers for nearly any media available —including tapes, CD/ DVD and hard drives.
The XpresspaX system provides a clear advantage over the limiting approaches of most competitors. Our “one size fits nearly everything” system offers you flexibility and ease of use for all your off-site or in house media transportation and storage needs.
Whether you need an off the shelf solution or have a custom data storage requirement, XpresspaX systems have you covered. It’s easy, it’s quick and it’s what we do every day.
Key advantages of the XpresspaX system: • Secure, weather-resistant container design.
• Media specific trays ensure the ideal fit for any media.
• Common tray sizes interchangeably fit our single and dual tray containers.
• System is compliant with media manufacturers storage and transit requirements.
• Media-specific inserts are designed to maintain tape manufacturers’ recommended storage orientation. Containers can be stored in either of two orientations—horizontally (on their base) or vertically (on their spine)—which keeps media on its’ proper axis. • Quick, convenient customer service ready to help find solutions to
unique challenges and custom applications.
DUAL TRAY CONTAINER SKU: XPX C2 SINGLE TRAY CONTAINER SKU: XPX C1
Designed and manufactured in the USA using custom-formulated high-strength resin, our containers withstand significant impact and protect your media through normal transit and storage situations. XpresspaX delivers the best quality and value you’ll find anywhere. And because we value the trust placed in us by our customers, XpresspaX offers a lfetime warranty against defects in material and workmanship in each of our products. Please see www.xpresspax.com for complete warranty and liability details.
Made from the same high-impact absorbing resin used in our larger containers, but purpose built for compact portability.
DIMENSIONS
Ext: 11.25” x 7.5” x 6” Int: 9” x 5.5” x 5.5” Weight empty: 2.25 pounds
Strong, positive single-latching system with butterfly clasp and lockable hasp. (Locks not included.)
This container when used with the XPX I-60 insert (shown above) is Fuji certified for storage and transportation of LTO tapes without case! Particulate-free and impact protection.
All XpresspaX containers and inserts are made in
the USA and come with a lifetime warranty against
manufacturer’s defects in material or workmanship.
Hundreds of thousands of XpresspaX containers are
currently in service around the world.
XpresspaX offers a complete system of interchangable insert trays and containers to suit any data storage need. All inserts are standard sized to fit in all single or double containers. Mini container inserts for tapes and drives are also available.
MINI CONTAINER SKU: XPX C3
CONTAINERS & INSERTS
CERTIFICATIONS
WATER & DUST PROTECTED • SECURE • CERTIFIED!
For over 15 years, XpresspaX has been introducing innovative protective features that are now considered the industry-standard for the world’s largest data storage companies, data creators, and tape manufacturers. These include higher thresholds of protection from particulates, water, impact and overall security. Now XpresspaX has independent lab testing to prove superiority across the board! As the value and density of data stored on back-up tapes and drives continues to dramatically increase, choose the containers that meet or exceed these critical certifications.
XPRESSPAX KEY IMPACT PROTECTION FEATURES
• Custom-formulated rubberized polymer absorbs energy on impact, even in hot and cold temperatures. IEC certified to resist penetration to Level 4 - 4.
• Integrated molded soft lid-pad adds extra protection • ISTA-certified to withstand vibration and shock
WATER PROTECTED AND ZERO PARTICULATE DESIGN
• Molded gaskets are integrated right into our container design to uniquely protect your valuable media from water and contaminants • IEC-certified to resist penetration
SECURITY:
• Integrated and positive lockable latch system on all XpresspaX Containers
• Improved tamper-resistant hinge assembly
XpresspaX’s proprietary zero-particulate, impact absorbing LTO without case insert Dual-tray Container,
holds up to 36 LTO tapes
Single-tray Container, holds up to 18 LTO tapes
ISTA 1A CERTIFIED
10-POINT DROP TEST INDIVIDUAL LTO TAPE WITH CASE* TURTLE LTO WITH CASE 20 PACK XPX LTO WITH CASE 18 PACK XPX SOFT LTO W/OUT CASE 18 PACK XPX SOFT LTO W/OUT CASE 36 PACK
TOTAL 3020 2203 1880 1468 1371
AVERAGE 335.5 220.3 188 146.8 137.1
33% lower than turtle 56% lower than single tape 15% lower than turtle
*LTO tape dropped 9 times due to accelerometer mounting on final drop face.
G - F O R C E S M E A S U R E D AT I M PAC T
60% lower than single tape
SINGLE-TRAY CONTAINERS DUAL-TRAY CONTAINER THE
DATA PROTECTION SYSTEM THAT
OUTPERFORMS TUR TLE
IN HEAD TESTINGTO HEAD
See all of our current
product certifications at
LTO
According to Fujifilm—the world’s largest tape manufacturer— one of the greatest challenges IT groups face today is the exponentially growing volume of data.
Tape storage is the ideal method for managing todays’ data growth challenge in a reliable and cost effective manner. And, with LTFS (Linear Tape File System) making tape faster and easier to use, it has now become the best solution for long term data storage. As IT professionals continue to demand more reliable and
cost-effective data backup and recovery systems, it’s critical that the containers used to transport and store data are built to withstand all potential risks. XpresspaX Containers are designed and tested to meet or exceed the needs of today’s high-volume data storage and transportation industry. XpresspaX has the ONLY container system certified and approved by Fujifilm to protect LTO cartridges. When you need data storage tapes to get there, and back again, you need XpresspaX intelligent media storage products.
LTO & HARD DRIVE SPECIFIC STORAGE
As internal and external hard drives become more cost-effective as backup devices, companies are using more than just tape to backup data. The unique XpresspaX interchangeable insert system makes it easy to transition your system from tape type to
tape type, or from tapes to drives, and back again. By using our custom-designed hard drive inserts in our certified container system, you can store virtually any drive type available without having to switch containers.
HARD DRIVES
Internal and External
Hard Drives
XPX Mini with I-60 LTO without case XPX C1 with I-11 LTO with case XPX C1 with I-8 LTO without case XPX C2 with I-8 LTO without case XPX C2 with I-11 LTO with case
XPX Mini with I-34 Internal Hard Drive XPX Mini with I-34 Internal Hard Drive I-20 Wavy PixpaX Customizable
MasterpaX
™
Extremely rugged containers that expand with your business
MASTERPAXFrom laptops to servers to work stations, todays companies
need a secure transport and storage system for more than
just tapes and hard drives. XpresspaX offers a full line of
military-grade containers for storing and transporting your
valuable IT assets.
MasterpaX products are designed with security and physical
protection in mind, to protect your valuable hardware and
data storage media, whether it’s being archived or stored as
an integral piece of your disaster recovery plan.
MasterpaX containers provide an air-tight, water-tight and
tamper-resistant line of products that give you the flexibility
and confidence to consolidate all of your IT component
stor-age. The XpresspaX foam insert system allows you to form-fit
your components in endless configurations resulting in the
most cost-effective, shock-resistant, and space-efficient
stor-age system available.
Standard MasterpaX features include interlocked stacking
capability, locking latches and air and water-tight seals. Most
containers also have retractable handles and corner wheels.
XPX4412* XPX5822*/23 XPX5823HD XPX5833 XPX7630
17.5 X 13.5 X 4.9 INTERNAL 22.8 X 17.3 X 8.6 INTERNAL 22.8 X 17.3 X 8.6 INTERNAL 22.8 x 17.3 x 13 INTERNAL 30.1 x 19.1 x 12 INTERNAL 18.6 X 16.3 X 5.8 EXTERNAL 25.5 X 20 X 9.5 EXTERNAL 25.5 X 20 X 9.5 EXTERNAL 26.3 x 20 x 14 EXTERNAL 33.8 x 22 x 13 EXTERNAL *does not include corner wheels or retractable handle Holds up to 28 internal hard drives!
XPX7641 XPX10840 XPXC1MST XPXC2MST XPX 100PACK
30.1 X 19.1 X 16.6 INTERNAL 42.5 x 24.2 x 16 INTERNAL 30.1 X 19.1 X 16.6 INTERNAL 30.1 X 19.1 X 16.6 INTERNAL 53 X 14 X 5.3 INTERNAL 33.8 X 22 X 17.6 EXTERNAL 46.3 x 28.25 x 16.8 EXTERNAL 33.8 X 22 X 17.6 EXTERNAL 33.8 X 22 X 17.6 EXTERNAL 55.5 X 16.3 X 6.25 EXTERNAL
M E D I A I N S E R T S A V A I L A B L E F O R X P R E S S P A X
™C O N T A I N E R S
PRODUCT DESCRIPTION SKU CAPACITY PRODUCT NOTES
SINGLE DOUBLE
1 LTO WITH CASE I–11 18 36 THE PREFERRED INSERT FOR LTO TAPES
2 SOFT LTO WITHOUT CASE I–8 18 36 IMPACT-ABSORBING & CLEAN! THE PREFERRED INSERT FOR LTO TAPES WITHOUT CASES 3 HALF-INCH TAPE I–2 20 40 HOLDS HALF-INCH TAPES, INCLUDING T10000
4 DLT WITH CASE / MICROFILM I–4 16 32 THE PREFERRED INSERT FOR DLT TAPES
5 DLT WITHOUT CASE I–9 20 40
6 CD/DVD I–7 32 64
7 MIXED-MEDIA UTILITY I–U 1 TO 30 1 TO 60 ADJUSTABLE INSERT TO HOLD 4mm, 8mm, AND MANY VARIETIES OF MIXED MEDIA 8 EXTERNAL HARD DRIVE I–15 1 2 IMPACT-ABSORBING FOAM, VARIOUS VERSIONS AVAILABLE
9 CUSTOMIZABLE EXTERNAL DRIVE I–20 1 TO 3 2 TO 6 IMPACT-ABSORBING FOAM CUSTOMIZES TO FORM FIT NEARLY ANY SIZE DRIVE 10 OPTICAL DISK I–16 12 24 IMPACT-ABSORBING FOAM
11 MAGSTAR™ TAPE I–17 16 32 IMPACT-ABSORBING FOAM 12 TERAPACK TRAY I–18, 19 1 2 IMPACT-ABSORBING FOAM
13 INTERNAL HARD DRIVE I–14 7 14 ELECTRO-STATIC DISSIPATIVE FOAM FOR ALL SIZE INTERNAL DRIVES 14 MINI LTO WITHOUT CASE I–60 6 NA HOLDS 6 LTO TAPES W/O TAPES
15 MINI GENERIC I–36 1 TO 3 NA ELECTRO-STATIC DISSIPATIVE FOAM, IMPACT-ABSORBING, FLEXIBLE FIT 16 MINI INTERNAL DRIVE I–34 1 TO 3 NA ELECTRO-STATIC DISSIPATIVE FOAM FOR ALL SIZES OF INTERNAL DRIVES 17 CALL-CENTER HARD DRIVE I–22 NA 4 TO 6 ELECTRO-STATIC DISSIPATIVE FOAM FOR CALL CENTER DRIVES WITH CHASIS
HAVE A CUSTOM REQUIREMENT NOT COVERED BY THE INSERTS YOU
SEE HERE?
CALL XPRESSPAX TODAY AND WE’LL WORK WITH YOU TO CREATE
ONE. 1-800-979-5175
Media-specific inserts are made of high-density polyethylene and foam, and are available in a wide variety of configurations to fit virtually any media storage need. Inserts and containers are completely interchangeable so you can mix and match for maximum flexibility.
LTO WITH CASE SOFT LTO WITHOUT CASE HALF-INCH TAPE DLT WITH CASE / MICROFILM
1 2 3 4 5
MIXED-MEDIA UTILITY EXTERNAL HARD DRIVE CUSTOMIZABLE EXTERNAL DRIVE OPTICAL DISK
9 10
7 8
INTERNAL HARD DRIVE MINI LTO WITHOUT CASE MINI GENERIC MINI INTERNAL HARD DRIVE
15 16
13 14 17
CALL CENTER HARD DRIVE
DLT WITHOUT CASE CD/DVD
6
11 12
MAGSTAR™ TAPE TERAPACK TRAY
Visit
www.xpresspax.com for
the most up to date product
VISIT XPRESSPAX.COM FOR CURRENT PRODUCT LISTINGS, DEMONSTRATIONS AND ADDITIONAL APPLICATIONS Master lock distributor.
OVERPAX CARTON
ISTA certified to protect media. OverpaX shipping cartons and foam end caps are available for all three standard XpresspaX containers.
OverpaX: Certified to protect media even better than containers and inserts alone. Provides excellent “blind” shipment protection of critical data, minimizing theft or
pilferage of attractive container contents. Reusable and durable.
