Mitigating Security Risks with Citrix Server Hardening and Encryption
Management
Mitigating Security Risks with Citrix Server Hardening and Encryption
Management
N. Brian Stearman Systems Engineer
Citrix Systems Barry Flanagan
Senior Systems Engineer Citrix Systems
N. Brian Stearman Systems Engineer
Citrix Systems
Barry Flanagan
Non Disclosure Agreement
•
This presentation is
Citrix Confidential
Objectives…
•
Secure remote access
•
Citrix security architecture
•
Brief look at encryption/certificates
•
Security Basics
Why are we here?
“I need to mobilize my workforce,
making access to the information and tools needed for their jobs as easy as ordering a book from Amazon.com, with the security of a traditional VPN.”
Solution…
Citrix Security Architecture
Secure Gateway Architecture (External Users) DNS Server ICA Client Web Browser Secure Gateway Server 4 43 Web InterfaceServer 44 3 Web Site R S A A ce /A ge nt 5
.0 80 STA
Citrix Confidential
Secure Gateway Architecture (Internal Users) DNS Server ICA Client Web Browser Secure Gateway Server 4 43 Web Inerface Web Server 4
43 Web Site
R S A A ce /A ge n t 5. 0 STA 8 0 1 49 4 MetaFrame Server
80 XML Service
DNS Server
80
Technical Requirements
Secure Gateway
• Windows 2000 or Solaris (SPARC) server –
SSL/TLS gateway between ICA clients and Metaframe farm.
• Microsoft Windows 2000 Server with SP 2
or later.
• Recommended minimum requirements for
Citrix Confidential
Technical Requirements
Web Server
• Metaframe Web Interface 1.61 or later
• IIS5, Apache or Tomcat
Secure Ticket Authority
• Windows 2000 + IIS5, Recommended
minimum requirements for Windows 2000 Server
Technical Requirements
• ICA client version 6.3 or later (to take advantage of TLS security)
Encryption
Encryption
Defined:
“…The transformation or scrambling of data into an unreadable format using a
mathematical algorithm.” Benefits:
• Protects against eavesdropping or
password sniffing
Citrix Confidential
SSL vs. TLS
SSL v3 Key Material Generation
master_secret =
MD5(pre_master_secret + SHA('A' + pre_master_secret + ClientHello.random + ServerHello.random)) + MD5(pre_master_secret + SHA('BB' + pre_master_secret +
ClientHello.random + ServerHello.random)) +
MD5(pre_master_secret + SHA('CCC' + pre_master_secret + ClientHello.random + ServerHello.random));
key_block =
MD5(master_secret + SHA(`A' + master_secret + ServerHello.random +
ClientHello.random)) +
MD5(master_secret + SHA(`BB' + master_secret + ServerHello.random +
ClientHello.random)) +
MD5(master_secret + SHA(`CCC' + master_secret + ServerHello.random +
SSL vs. TLS
TLS v1 Key Material Generation
PRF(secret, label, seed) = P_MD5(S1, label + seed) XOR
P_SHA-1(S2, label + seed); master_secret = PRF(pre_master_secret, "master secret",
ClientHello.random + ServerHello.random)
key_block = PRF(SecurityParameters.master_secret, "key expansion", SecurityParameters.server_random +
Intro to SSL/Certificates
Why SSL
•The threats:
– Server masquerading – Network sniffers
•Secure Sockets Layer (SSL) provides:
– Authentication
• Digital certificates prove identity on the Internet
• This prevents “man-in-the-middle” or DNS attacks
– Encryption
• Using 128-bit key lengths
• This prevents network sniffers from viewing your
Citrix Confidential
19
SSL Certificates
A certificate consists of
– A public key
– Information about the certificate
• The subject name (as an X.500 distinguished name)
• The issuer name (as an X.500 distinguished name)
• Period of validity (not-before and not-after dates)
• Serial number (assigned by the issuer)
• Description of the public key and signature algorithms
used (public key is nearly always RSA)
SSL Certificates
• A new concept for many of our customers
• Need to be very careful – can be difficult
• Obtain certificates from:
– Private Certificate Authority (CA)
– Public CA
– Evaluation cert from Public CA (Baltimore,
Verisign)
• Possible need to install root CA on Client. Windows 6.20 ICA client supports all
Citrix Confidential
Could I see some ID please?
• SSL Certificates are like Driver’s Licenses
Driver’s License SSL Certificate
Issued to Individual citizens Individual users or servers
Issued by Department of Motor
Vehicles (DMV) Certifying Authority (CA)
Verification mechanism
DMV hologram,
well-known license format CA digital signature, public key, thumbprint
Application requirements
Birth certificate, Social
security number, etc. Business license, Dun & Bradstreet number, etc.
Public usage Prove identity; operate a
vehicle on public roads Prove identity; operate a secure web server on public networks
I trust it because
I trust the DMV to
Server Certificates
• Server certificates are
unique to a particular server name
• The “subject” of the
certificate is the FQDN of the server
• Server certificates also
include fields dictating what the certificate can be used for
• View the Certification
Citrix Confidential
Root Certificates
• Root certificates (aka
CA certificates) are self-signed entities that are used to verify server certificates
• If you trust a CA, install
their root certificate.
• Windows ships with
Client needs the root, server needs a cert
Citrix Confidential
Default root certificates
• Root certificates need to be installed into the Windows operating system
Citrix Confidential
Common Threats
What attacks are we securing
against?
Brute Force password crack IP spoofing
Security…in a nutshell
Security basics:
• Design well – including physical security
• Audit – Third-party, or self-assessment tools
• Lockdown local file system – Windows or
Unix
• Maintain required hot fixes and security
patches
File System
Securing Windows
Securing the Windows 2000 File system:
• DumpSec
• Hyena
• Windows 2000 Resource kit tools
All means of checking or dumping file system, share, printer and other system resource
Citrix Confidential
Securing Windows
File
Permissions
Securing Windows
Share list
Citrix Confidential
Securing Windows
• Keep up with manufacturer security patches and fixes
– http://www.Microsoft.com/security/
• Use some form of host –based security scanner to check vulnerabilities
– Symantec Net Recon
– ISS System Scanner
Citrix Confidential
Metaframe Policy – Create OU
Start, click Programs then Administrative Tools, then Active Directory Users and Computer, then Action and New
Metaframe Policy – Move servers
Citrix Confidential
Local Security Policy - Server
Open the Local Computer Policy and drill down to:
Computer Configuration, Administrative
Templates, System,
Group Policy folder and
doube-click to select User Group Policy loopback
Citrix Confidential
Assign GPO Permissions
Citrix Confidential
Design
Firewall
• Traffic cop to control protocol access to protected networks
Demilitarized Zone – What is it?
• A perimeter network – also known as a DMZ – is an additional network added between a
protected and external network to provide another layer of security.
• Location of public resources like FTP, Telnet
and Web servers
Physical Security
Secure Ticket Authority:
• Security server
• Contains important connection information
• Isapi.dll service CAN run on Citrix/file server
Citrix Confidential
Auditing
Auditing local events
• MMC Security and Analysis Snap-in
• Event log size increased to 500MB
• Regular backups on event log
• Audit specific objects:
• Account management • Logon events
Authentication
• Secure Gateway is a remote access solution
• Use some form of secure authentication as with VPN
• Use industry standard, two-factor authentication
– Certificates
– Token-based such as RSA SecureID
– Secure Computing
Citrix Confidential
Two-factor Authentication
Two-factor Authentication
Citrix Confidential
Alternate Authentication
Local User Authentication
•
Use Windows NT LAN Manager (NTLM)
for authentication only if local or GPO
specifies NTLMv2 authentication only.
•
MMC Security and Analysis + Security
Templates
•
Modify Securews template to specify
Authentication
New
Citrix Confidential
Locking down IIS
• Microsoft IIS lockdown tool
• Secure the server
• Alternative to manual changes
Locking down IIS
To lock down Metaframe Web Interface on Microsoft IIS:
Citrix Confidential
Locking down IIS
Click next to leave
Locking down IIS
Citrix Confidential
Locking down IIS
Uncheck
Locking down IIS
Citrix Confidential
Locking down IIS
Locking down IIS
Citrix Confidential
Locking down IIS
Locking down IIS
Citrix Confidential
Locking down IIS
Local Policy
Password Policy
–
History requirement
–
Password age
–
Character length
–
Force requirements to be met
User Accounts
– Disable unnecessary user accounts
Citrix Confidential
Unused Services
• Default Windows 2000 servers have about 31 unneeded services
– Computer Browser, DHCP, DFS, Fax Service, Internet Connection Sharing, Messenger…
• Disable in the Services MMC Snap-in on Windows 2000
• Applies equally to Solaris
– Armoring Solaris II, July 2002, Lance Spitner
Citrix Confidential
Additional Resources…
• “Applied Cryptography” by Bruce Schneier
• “Hacking Exposed”, Second Edition
• “Solaris Security”, Sun Microsystems
• www.tweakcitrix.com
• www.nsa.gov
• www.itwhitepapers.com
• www.citrix.com
• www.securityfocus.com
Citrix Authorized Training
• With Citrix training:
– Learn tips and techniques for managing and administering Citrix software
– Obtain valuable lab time for hands-on practice
– Prepare for Citrix certification exams
– Learn quickly and efficiently in the classroom
• New courses and certification include:
– CTX-720x Citrix Web Interface Elite Administration
– CTX-6100 Citrix Core Technologies and Architecture
– Citrix Certified Integration Architect (CCIA) program to be launched in Q4 2003
• Available worldwide from 350 Citrix Authorized Learning Centers (CALCs)
• To find a CALC near you, go to Training Locations from www.citrix.com/training
