Asis Elektronik Bilişim Sistemleri A.Ş. (Asis Electronic & IT Systems, Inc.) was established in 2007. Asis Electronic conducts R&D activities and develops software and hardware for Smart Ticket Systems, Automation Systems, Card Access Systems, and People Counting Systems. The company develops all hardware and software used in the products using its own resources. With its experiences and achievements to date at many special projects implemented, Asis is the only Turkish company in its field that manufactures electronic automation and identification systems and offers turnkey solutions.
With head offices located in Istanbul, and Regional Directorates covering each and every region in Turkey, as well as specialist and experienced personnel, Asis Electronic aims to become a real “Solution Partner” that meets all software and hardware requirements of its clients with high-quality services and affordable pricing policy.
Today, our company has developed, and continues to develop, special projects in many fields, including Smart Card Systems, Smart Bus Stop Systems, Smart Ticket Systems, Smart Token Systems, Personnel Attendance Control Systems, Access Control Systems, Refectory Credit Systems, People Counting Systems, etc. Asis has included these projects in its application range by means of agreements and sales contracts concluded with corporate and individual clients.
Asis Electronic attaches considerable importance to R&D activities. The Company takes firm steps using innovative technology developed by itself with its sustainable pioneer identity.
Tel: (0212) 855 54 84 Fax:(0212) 855 62 28
Company Profile
w w w . a s i s e l e k t r o n i k . c o m . t r
www.asiselektronik.com.trİstanbul Teknokent | İstanbul Üniversitesi Avcılar Yerleşkesi - Argem Binası
Ofis No: Z01
34320 Avcılar / İstanbul / Türkiye
Validators
Multi-Media Validator (VAL5)
Multi-Media Validator (VAL3)
Multi-Media Validator (VAL95)
Following paper-tickets, which is now only a history in the memories of most of us, the validators with magnetic readers have entered our lives in the mass transportation industry. Asis Electronic has been a pioneer in making quantum leaps in the field with the recently developed technologies, and developed validators that instantly and securely read both MIFARE and MIFARE PLUS ultralight cards as per the requirements of the sector. Since the beginning of 2013, our Company has developed validators that are capable of reading mobile phones with NFC capabilities, which do not require any cards and visiting a card reloading center, and the required infrastructure for the first time in Turkey, and the system has been offered to the service of the people on metropolitan level.
7” 18-bit Color TFT Display. ARM Cortex A8 + 500 Mhz DSP processor architecture. Capability to use all types of smart cards conforming to ISO14443A/B. Enables use of NFC, Bank and Credit Cards. The system stands out in its class with its Media Management features.
7” 18-bit Color TFT Display. ARM Cortex A8 CPU + Video DSP processor architecture. Capability to use all types of smart cards conforming to ISO14443A/B. Enables use of NFC, Bank and Credit Cards, as well as magnetic paper tickets. The product stands out among similar technological products with its Media Management features.
4,3” 18-bit Color TFT Display. ARM CORTEX M3 processor architecture, Capability to us all types of smart cards conforming to ISO14443A/B. Enables use of NFC, Bank and Credit Cards. With its capability to be integrated on the Driver Control Panel, it alone provides ease and speed of use on board all means mass transportation.
Elektronik ve Bilişim Sistemleri A.Ş.
Driver Control Panel
The Driver Control Panel is designed for installation in a position that will allow effective control without compromising the safety of driving. The panel allows control of passengers boarding the vehicle by means of the driver panel display and audible warnings. The driver panel also serves as an indispensable tool for the fleet, personnel and for call management. Drivers can send emergency messages to the Transport Control Center with the click of a button, and receive text or audio messages from the Transport Control Center. Personnel attendance can be controlled by means of the driver card read by the control panel. Operating times, Service Routes and pay roll calculations can be done automatically. Any line changes performed by drivers are instantly transmitted to the route panel wirelessly.1GHz Cortex A8 CPU + Video DSP processor architecture, 7'' TFT color touch-screen graphical LCD display, optional 3G/GPRS 7.2/5.7 Mbps fast data exchange, 2-way live video streaming, Audio and Video announcements, capability to broadcast location-based commercials, emergency announcements (blood donation announcements, etc.), arrivals information on map, new bulletins, weather forecast bulletins, etc. on a separate VGA monitor.
Touch-Screen Driver Control Panel
(DCP4)
128 x 64-Pixel LCD display, communication with the validator using USART Serial Communication protocol, Capable of reading Mifare Classical 1Kbyte; Mifare Classical 4kByte; Mifare Ultralight cards and Mifare Plus Cards, Mastercard PayPass, Visa payWave cards.
Driver Control Panel (DCP83)
The kiosks developed for reloading smart cards, collection of invoices and Private Public Bus operators provide 24/7 payment and card reloading opportunities using credit/bank cards, and are capable of accepting banknotes and coins, and give change. Designed completely with the state-of-the-art technology by Asis' engineers, the kiosks provide ease of use with their user-friendly user interface.
Many transactions conducted at sales offices, reloading points or pay-desks can be conducted using these kiosks easily without any time-restrictions and with high speed, increasing customer satisfaction. Alternative language options offered allow particularly tourists and foreign customers to own and reload smart cards easily on self-service basis.
Asis Kiosks accept payment by banknotes and coins, and are capable of giving change. They can be used for a variety of optional purposes, including sale of Disposable Tickets, Electronic Cards and Electronic Tokens, reloading the cards, etc. The touch-screen display speeds up the online transaction times. Asis Kiosks facilitates maintenance and service works owing to its front cover, and provides high security with their strong and resistant structures. Asis Kiosks are completely protected against dust and water, meeting the IP64 standards. Thus, they can be easily used for both interior and exterior applications.
Reloading Systems
Kiosks
- 60mm or 80mm Thermal Printer, - Ticket Printer,
- Card Reader,
- Credit Card Payment System, - Banknote Acceptance Mechanism, - Banknote Refund Feature,
Accepts banknotes for reloading
Issues receipt Smart Card Reader
Accepts Coins for reloading Touch-Screen Display
- Coin Acceptance Mechanism, - Coin Change Giving Feature, - Electronic Token Dispenser, - Card Dispenser,
- GPRS Modem (3G Optional), - Wireless.
Reloading Systems
POS Terminals
The POS Terminals manufactured by Asis Electronic are used for reloading the passenger cards on retail basis, using the credits purchased by dealers with prepayment. These reloading systems have high reliability and data security features against risks such as forgery and similar external risks. High battery life and a variety of connection interfaces of the system enable it to be used in various environments, including fixed and mobile locations.
The POS Terminals that are extremely easy to use with their ergonomic keypad and LCD display are plug-play systems, which do not require special installation.
Areas of Application
- Electronic Fare Collection Systems, - Bank and Credit Card Applications,
- Data Collection and Interpretation Systems.
Features
- Capability to read Mifare Classical 1 kByte - 4kByte, Mifare Plus and Mifare Ultralight cards,
- Accepts payment by Mastercard PayPass, Visa payWave cards, - Integrated ISO14443A/B & ISO18092 reader,
- Readability range up to 100 mm,
- Easy-to-use dual-protocol capability for the USART serial communication protocol, - Encryptable serial communication feature,
- Information screen on LCD Display with backlight,
- Capable of operating within a temperature range between -35°C and +85°C - ARM7 processor,
- Security mechanism software ensuring high availability of the POS device in case of faults,
- Capability to read contactless cards with 300 ms range,
- Contains 1 x SAM slot, and has DES-3DES and RSA data encryption security.
On-Board Computer
DVR4AFC is a digital video recording (DVR) and digital signage (DS) computer, intended for use in automatic fare collection (AFC) systems in public transport. Along with the video and voice capabilities, DVR4AFC incorporates additional set of features, increasing security and reliability in public transport IT applications. DVR4AFC is based on a multi CPU design: one system and power management CPU (will be referred as PMIC CPU), one DVR CPU and one communication and digital signage CPU (will be referred as MAIN CPU).
PMIC CPU subsystem specs: - 100 MHz ARM Cortex M3 CPU,
- Separate power control over each subsystem (like main CPU, DVR CPU, 3G Modem, e.t.c), including all external peripherals, connected to DVR4AFC, like camera, GPS, terminals connected over Ethernet and USB ports, e.t.c.
- Capable of playing a watchdog role, so that in case of any system failure PMIC CPU restarts the failed subsystem or the entire system,
- Acts as a bridge between MAIN CPU and the vehicle CAN Bus,
On-Board Computer
MAIN CPU subsystem specs:
DVR CPU subsystem specs:
- - - - - - - - - - - - -
1 GHz ARM Cortex A8 CPU, 512 Mbytes DDR3 RAM, 256 Mbytes NAND Flash,
RTC (real time clock) with battery backup, High endurance memory (8 Kbytes),
HDSPA+ 3G modem (7.2 MBps /5.76 Mbps), USB Host port (allows connection of additional peripherals, like Wi Fi, Bluetooth, e.t.c.),
USB OTG port, RS-232,
4 X 100 MBPs Ethernet ports, allowing
Driver Panels, LED Signs, Printers, e.t.c), Supports one SD Flash memory, up to 32 Gbytes,
VGA video output, supports resolutions up to Full HD,
Audio input/output (microphone/speaker integration of any AFC equipment (Validators,
allows live 2 way voice communication over IP). - 270 MHz ARM926 CPU,
- 128 Mbytes DDR2 RAM, - 256 Mbytes NAND Flash,
- High precision RTC (real time clock) with battery backup,
- High endurance memory (8 Kbytes), - 3 X USB Host ports (one of them with DC12V
enabling Hard Disc connection), - Supports 2 X SD Flash memories, each up to 32 GBytes,
- 5 X optically isolated digital inputs, - 4 X MOSFET outputs,
- 3 axis acceleration sensor,
- Supports connection of up to 4 analog cameras (composite video),4 X MOSFET outputs,
- Supports connection of up to 4 X microphones,
- Simultaneous 30fps VGA quality recording of all 4 channels,
On-Board Camera
Mass transportation vehicles are monitored on 24/7 basis with the DVR systems comprising special cameras integrated into the Validator system manufactured by Asis Electronic for prevention of any potential problems between drivers and passengers, and minimizing any crimes such as theft on board the vehicles. High-quality audio and video recordings can be simultaneously stored on both SD cards and portable HDDs. Images can be instantly transmitted to the centre using the 3G, GPRS and Wi-Fi infrastructure. The system allows multiple-users to view the images simultaneously. Data obtained are the most accurate source of information for operators and public authorities to improve service quality and confidence and security in transportation.
Features - Long-time recordings, - Prevents abuses, - Secure voyages, - Full Supervision, - Continuous recording, - Recordings with sound,
- 4 Channel recording in D1 (720x576) resolution, - Remote Access through 3G network,
- Wi-Fi, Wireless Image Transmission, - Automatic Switching to Day/Night modes,
- Advanced and selectable white balance adjustment (ATW), - Automatic Gain Control (AGC) adjustable by means of OSD Menu, - BLC feature adjustable by means of OSD Menu,
- Backlight compensation feature to enable viewing under strong backlight conditions. On-Board Camera
On-Board Media and Camera
- Commercials, news and weather and road condition bulletins suitable for the target audience can be automatically broadcast on the on-board displays.
- Central software allows detection, transmission and downloading of new movies, commercial contents automatically.
- Commercials suitable for the demographic characteristics of passengers on board can be broadcast owing to the Smart Ticket System.
- Capability to run video, picture, mp3, mp4 files, - Capability to use subtitles, marquees, bursts, etc.,
- Adjustment of volume and sound quality from the centre,
- Anti-distortion feature against vibrations and shocks on the vehicle.
On-board passenger information system allows audio and visual broadcasting of commercials, news, weather forecast and road condition bulletins, present and next stop info, etc. based on the target audiences existing on board, on the display installed on the vehicles. Mass transportation vehicles are monitored on 24/7 basis with the DVR systems comprising special cameras integrated into the Validator system manufactured by Asis Electronic for prevention of any potential problems between drivers and passengers, and minimizing any crimes such as theft on board the vehicles. High-quality audio and video recordings can be simultaneously stored on both SD cards and portable HDDs. Images can be instantly transmitted to the centre using the 3G,
NFC is a short-range contactless technology standard designed for easy, simple and secure communication between two electronic devices. This state-of-the-art technology product is offered to the service of the people on metropolitan level under a cooperation agreement between Asis Electronic and Turkcell, the leading GSM operator in Turkey, for NFC-based contactless applications such as payment and mass-transportation fare payments for the first time in Turkey. The fact that this technological development, has been applied by Asis Electronic has not been surprising for our clients; to the contrary, it has once more strengthened the trust of those who have confidence in our Company. Now, any Asis Electronic customer can use the mass transportation services using their mobile phones with the NFC capabilities without having to own a transport card or visit a reloading center. Transportation fares can be added to the mobile phone invoices, credit card or any Smart Card owned, using the Asis Smart Card application that can be downloaded on mobile phones easily.
NFC
NFC Download Steps
Advantages provided by the NFC technology to customers
- No need to buy and carry a special ticket or card,
- Provides multiple payment options (by credit card, bank card, or mobile phone invoices), - No need to go to dealers or sales points for reloading,
- Ability to receive information on the mass transportation vehicles that will pass through a specific stop, as well as transport line information, by tapping the mobile phones with the NFC capabilities on the smart NFC tags.
NFC
Technology
Asis Electronic, Turkey's leading technology and R&D company, has added a new solution to its range of products that facilitate the life in transportation.
Public Transport Operators: Citizens:
to use any means of transportation using their mobile phones without any transportation cards, reload credit at any time and place, check the remaining credit on their mobile phones,
check the card usage history on their phones, receive SMS messages warning limited remaining credit.
to provide added value to the Electronic Fare Collection systems, decrease costs of distribution and sales, communicate with the customers easily, advertising and marketing opportunities for mobile commerce services.
The system developed by Asis allows the;
Smart Bus Stop
The Smart Bus Stop system is designed to provide information to passengers about the means of mass transportation within a specific city. The Smart Bus Stop system informs the passengers on the service routes, locations and conditions of vehicles, etc. The system allows passengers on board the vehicles or waiting at the stops to receive information on the routes of specific mass transportation vehicles instantly. The Smart Bus Stop system provides extra revenues to operators through the commercials broadcast on the displays of the system. The Smart Bus Stop systems are designed with the state-of-the-art technology to maximize the service quality.
These questions will no longer burden the passengers memory anymore. We develop the modern urban solutions having state-of-the-art technology, thanks to the Smart Bus Stops.
- When will my bus come? - I wonder whether I missed the bus? - Does the bus I am waiting for pass from this stop? - What is the occupancy rate on the bus I am waiting for, are there any spaces available? - Would there be any delays along my route?
NO NEED TO WAIT IN VAIN
LED 96 OD-SBSD-26
Route Tracking System
Locations, speeds, routes, stop points, fuel consumptions, and many other parameters relating to vehicles of a fleet can be tracked in real-time on 24/7 basis with the Vehicle Tracking and Fleet Management system, which operates in integration with the validators. Relevant data can be reported retrospectively, and alarms can be created.Areas of Application of the Route Tracking System;
Bus, share tax, minibus lines, Short-Distance Travel Companies,
Companies with fixed distribution network.
- Driver Trip Report, - Vehicle Report,
- Report,
- Vehicle - Report, - Stop-Line-Route Report, - Status,
- Non Bus Stop Boarding Report - Monthly Route Assignment, - Time Assignment, etc.
Trip Route Trip Route Route Trip
Reports
- Where are your vehicles in a given moment?- Have drivers actually arrived at their planned destinations during a specific day?
- Do the drivers drive their vehicles fast or dangerously?
- Are there long-time stops and long idling times? - Do the drivers use the vehicles out of their working hours?
- Are the kilometer logs kept for specific routes correct? - Is fuel consumption as per your calculations?
Advantages of the System
The systems allows;
Prevention of unfair competition in mass transportation, and their unfavorable reflections on the passengers, within the framework of “Equity Principle”.
Smart Ticket Web Application
The most important issue during application design and development process was that every user (whether is smart card owner or not, bus owner, bus driver, dealer, authorities of municipalities or associations/cooperatives responsible for transport operations) with internet connection from any environment could easily use this application. With this purpose, on the same application have been created different user profiles (means sets of functions).
Users from every city where "Asis - Smart Ticket system" is running, are able to:
- Monitor own card transaction history, - Inquiry card balance,
- Give top up instructions for their smart cards by using Bank or Credit cards, - For selected bus stop, to get information for comming buses and travel time, - For choosen bus, to get information for arrival times to every bus stop on route,
- Send all kinds of information, complaints, suggestions, and so on to our company via "Request Form", - Monitor the current position of the vehicles on the map,
- Get information about departure times of buses; - Get information about current ticket prices; - Many other transactions...
Another feature providing facilities to mobile users is the Asis Smart Ticket Mobile Transport Directory. This application enables users to conduct many transactions at any location with Internet connection via mobile phones or tablets. Users can use the application by selecting their current province from among those included in the Smart Ticket application.
Some of most used transactions are:
- Card balance, - Where is my bus, - Smart station,
- Balance control and reminder.
References
Providing high-technology solutions needed by modern cities in mass transportation, Asis has provided services in many Countries, Metropolises, Provinces, Towns and Districts since 2007. Focusing on developing new technologies that facilitate the lives of people, Asis continues to offer high-level of service quality with its NFC, Bank Card, Smart Ticket, Magnetic Paper Ticket, and Automatic Reloading Systems.With the Smart Ticket Systems that stand out with their many benefits and advantages in the cities they are used, Asis will continue to provide services with innovative solutions in the future as well.
Afyon Private Public Busses - (Turex)
Bartın Municipality Private Public Busses Batman Municipality
Bingöl Municipality Private Public Busses
Çorum Municipality Private Public Busses
Erzincan Municipality Private Public Busses Amasya - Doğantepe Municipality Amasya - Yenice Municipality Ayvalık Municipality
Burdur - Gölhisar Municipality Private Public Busses Burhaniye Municipality
Bursa - İnegöl / Yenice Municipality Private Public Busses Çanakkale - Umurbey Municipality
Çorlu Municipality
Denizli Metropolitan Municipality Private Public Busses - (Turex) Diyarbakır Metropolitan Municipality
Eskişehir Metropolitan Municipality
Erzincan - Üzümlü Municipality - Private Public Busses Erzurum Metropolitan Municipality
Gümüşhane Municipality
Kızıltepe Municipality Private Public Busses Konya - Ilgın Municipality
Malatya Metropolitan Municipality - Motaş
Samsun Metropolitan Municipality Busses and Private Public Buses
Special Projects Boğaziçi University Dentur Avrasya Overseas Projects Azerbaijan - Baku Kosovo - Prizren Kosovo - Peja Şanlıurfa - Ceylanpınar Municipality
Şanlıurfa Metropolitan Municipality Tekirdağ Metropolitan Municipality Private Public Busses - (Tetaş)
Tokat - Turhal Municipality Tokat - Üzümören Municipality
Tokat - Zile Municipality Tunceli Municipality
Yalova Municipality Zonguldak - Kozlu Private Public Busses
