Introduction 3

FluidX OrbitTM_{and Scope}TM_{Range of Single Tube Readers} ₄

Orbit SIngle Tube Reader 5

Scope USB Single Tube Reader 6

Scope WirelessTM_{Single Tube Reader} ₈

FluidX ImpressionTM_{Range of Whole Rack 1D and 2D Barcode Scanners} ₁₀

FluidX Active Cryoprotection® System 12

Impression Rapid Rack Scanner 14

Impression Enhanced Rack Scanner 16

Impression Enhanced Rack Scanner (LE) 18

Impression Multi Rack Scanner 20

FluidX PerceptionTM_{Range of Whole Rack 1D and 2D Barcode Readers} ₂₂

Perception Industrial Rack Reader 24

Perception Rapid Rack Reader for SBS Racks 26

Perception Rapid Rack Reader for Legacy Cryo Racks 28

FluidX Software

EasyTrack Sample Management Software 30

IntelliCodeTM_{Decoding Software} ₃₂

Starter Packs

Sample Storage Starter Pack 34

Perception Starter Pack 35

Reader Overview Tables 36

Key to symbols used

No mains power required Compatible with Windows operating systems

(See product speciﬁcations for details)

Read time less than 1 second Compatible with iOS

(See product speciﬁcations for details)

Reader ﬁtted with FluidX Compatible with Android Operating Systems

Active Cryoprotection® System (See product speciﬁcations for details)

Reader compatible with Requires only 1 USB connection

SBS format racks for both power and data transfer

(3)

FluidX range of 1D & 2D Barcoded Tube and Rack Readers

| Introduction

The team at FluidX probably know more about 2D barcoded storage tubes and readers than any other group in the world. As part of the team that developed the very ﬁrst 2D datamatrix barcoded tubes back in 1999 we also introduced the ﬁrst scanner capable of identifying a whole rack of 96 tubes.

Our latest range of single tube and whole rack readers are the result of over ﬁfteen years of continuous development and innovation. While our competitors play “catch-up” we focus on continual development and innovation to bring the best products, with the most useful features, to our customers.

Our latest decoding software, IntelliCode™, is built on the very latest development platform to ensure continuity for many years to come. We‘ve incorporated all the elements from our previous software to ensure compatibility with current FluidX systems, while adding new options and features. IntelliCode has been designed to meet today’s, and tomorrow’s, requirements.

FluidX believes in developing the right product for the right use. We achieve this by listening to our customers, making sure that we understand their applications and goals, and then identifying the best solution - sometimes we manage this even before our customers know they have a problem that needs solving!

We appreciate that not every customer can use our range of 2D sample storage tubes, even if we do have the best and widest range of tubes on the market, so we make sure our readers can be used with all 2D barcoded tubes available. We also provide active support to all FluidX customers, whatever tube type they use. Nothing surprises us. Over the past ﬁfteen years we’ve dealt with every tube style, and make, imaginable!

We hope you ﬁnd our latest range of scanners and readers as exciting as we do. Here are a few highlights to whet your appetite...

The FluidX ScopeTM_{WirelessSingle Tube Reader}

The Scope Single Tube Reader features built-in hardware decoding so it can be used without installing software ﬁrst, simply “Plug and Play”.

Compatible with a wide range of operating systems. The Scope Wireless is the ﬁrst wireless single tube 2D reader that connects to a tablet, including iPad and Android devices.

The FluidX PerceptionTM_{Industrial Rack Reader}

The ﬁrst rack reader which is impervious to water, dust and gases (IP65 rated) and proven to be capable of reliable decoding at -40°C.

The FluidX Perception Industrial Reader is used in many of the world’s largest, fully automated Biobanks.

FluidX PerceptionTM_{Rapid Rack Reader}

The fastest rack reader on the market. The Perception Rapid reader is capable of reading at a speed of 3ms per tube, just 300ms to read a rack of 96 tubes, and it can be used with all 2D barcoded sample storage tubes.

The Perception Rapid also possesses the smallest footprint of all rack readers currently available to save bench space.

The FluidX ImpressionTM _{Multi Rack Scanner}

FluidX were the ﬁrst group to develop a scanner capable of reading more than one rack at a time.

Our Impression range of rack scanners oﬀers unrivalled speciﬁcations for a competitive price. Try us, we will never be beaten on cost.

The FluidX Active Cryoprotection®System

FluidX developed the very ﬁrst cryoprotective system for rack readers 4 years ago. Only FluidX readers feature an active cryoprotection system that not only enables multiple racks to be read without diﬃculty straight from a freezer but also prevents the damage to electronic components often associated with passive technology.

Simultaneous rack 2D identiﬁer reading

FluidX were the ﬁrst to supply a unique 2D Data Matrix barcode identiﬁer to racks to provide automatic rack orientation.

All our rack readers will read both rack and tube 2D barcodes simultaneously and auto-orientate the rack.

(4)

Single Tube Readers for 1D and 2D Barcodes

| Orbit

TM

_{and Scope}

TM

_{Single Tube Readers}

_{| Overview}

Data exported directly to any application

The FluidX keyboard wedge lets you to enter the results into any application.

Simply place the cursor where the data is to be be entered and scan the tube, the results will be instantly displayed wherever the cursor is positioned.

All FluidX single tube readers will insert data into any application, including Excel, Notepad etc.

Large scanning window and target lights

When combined with our superior decoding technology, the large scanning window makes tube reading fool-proof, even using gloves.

All Scope readers feature blue LED target lights to make positioning even easier.

Quick set up

All Scope Single Tube Readers are “Plug and Play”, there’s no software to install so just unpack and go. Pairing the Scope Wireless Reader with a tablet is easy, simply scan the barcode supplied in the manual.

Wireless connection to tablet

The Scope Wireless Single Tube Reader, for 1D and 2D barcodes, connects to both iPad and Android tablets. With Bluetooth connection you can identify samples anywhere, anytime.

FluidX OrbitTM

Single Tube Reader

For high performance and dependable decoding at a low cost.

(cat no 20-1001)

FluidX ScopeTM_USB

Single Tube Reader

Instant “Plug and Play” reading of all 2D barcoded tubes and 1D barcoded racks. (cat no 20-1003)

FluidX ScopeTM _Wireless

Single Tube Reader with Bluetooth modem

Allows wireless reader to be connected instantly to any laptop, PC or Mac.

(cat no 20-1025-C)

FluidX ScopeTM_Wireless

Single Tube Reader with Bluetooth and Tablet

As above, but supplied with 10" Lenovo Android Tablet.

(cat no 20-1025-B)

FluidX ScopeTM_Wireless

Single Tube Reader with Bluetooth

The ﬁrst single tube 1D and 2D barcode reader to connect to iPad and Android tablets.

“Plug and Play”, no software required. (cat no 20-1025-A)

Scope Wireless Single Tube Reader with iPad Orbit Single Tube Reader

(5)

Code formats Datamatrix, ISO 16022, square and rectangular format, ECC200, 0 to 20 grid sizes, white on black, black on white, numeric and alphanumeric

Sensor type 1/3” CCD Light source R LED

Read time Less than 1 second per tube Ambient operating

temperature 5 to 50°C

Tube compatibility All tubes in 24, 48, 96, 240 and 384-formats.

Glass compound storage tubes, cryo tubes, biological sample tubes

Dimensions 90mm (H) X 100mm (W) X 100mm (D)

Weight 0.25 Kg

Power requirements 5V DC 0.1A max. supplied through USB User interface FluidX GUI

Speciﬁcations The FluidX OrbitTM_{Single Tube Reader.}

For high performance decoding at a low price. Use with all 2D barcoded tubes, any make, any size.

All FluidX Single Tube Readers are compatible with any 2D Data Matrix barcoded tubes including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX.

Size does not matter, the FluidX Orbit Reader will quickly scan tubes in 24, 48, 96, 240 and 384 rack formats, as well as larger capacity tubes including glass compound storage tubes, cryo tubes and biological sample tubes.

Quick to set up

The FluidX Orbit Single Tube Reader takes just moments to set up with automatic calibration. Simply plug into a PC or laptop and our software will do the rest!

Want to read a less common tube type? No problem, simply select the auto-learn feature and our software will take care of that too.

Uses a USB connection to laptop or PC, so no additional power supply is required.

Easy to use with gloves

The large scanning window and superior decoding technology makes tube reading fool-proof!

Results in an instant

All our Single Tube Readers take less than a second to scan and decode any 2D barcoded tube.

Single Tube Readers for 1D and 2D Barcodes

| FluidX Orbit

TM

_Range

_|

_{Single Tube Reader}

Dependable decoding

The team at FluidX were involved in developing the very ﬁrst 2D barcoded tubes and readers and today our scanners are the result of more than 15 years of continuous development. We know our stuﬀ!

(6)

The FluidX ScopeTM_{USB Single Tube Reader.}

Instant “Plug and Play” decoding of both 1D and 2D barcodes. Use with all 2D barcoded tubes, any make, any size.

FluidX Single Tube Readers are compatible with any 2D Data Matrix barcoded tubes including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

Size does not matter, the FluidX USB Single Tube Reader will quickly scan tubes in 24, 48, 96, 240 and 384 rack formats, and also larger capacity tubes including glass compound storage tubes, cryo tubes and biological sample tubes.

Instant 1D and 2D barcode reading

The total time between scanning a barcode and seeing the result displayed is less than a second!

The tube ID is displayed instantly on the computer screen for identiﬁcation or sample entry, or you may chose to run the application in the background.

Use straight away

Simply “Plug and Play” to start using.

There’s no need to calibrate, and no drivers or software to install, before scanning your ﬁrst 1D or 2D barcode.

With a USB connection to laptop, PC or Mac, no additional power supply is needed.

Data exported direct to any application

Simply place your cursor where you want results to be entered and scan the tube. Data will be instantly displayed wherever the cursor is positioned.

The reader will insert data into any application including Excel, Notepad, etc.

Easy reading of linear barcodes on racks and tubes

With a large scan window, and superior decoding technology, the Scope USB Single Tube Reader easily decodes 1D barcodes on racks and tubes.

Simple to use, even with gloves

Blue LED target lights are emitted so that positioning the barcode for scanning is easy, even wearing gloves.

The reader then automatically scans the barcode (either 1D or 2D) and conﬁrms a “good read”.

The team at FluidX were involved in developing the very ﬁrst 2D barcoded tubes and readers, today our scanners are the result of more than 15 years of continuous development. We know our stuﬀ!

We supply a 5 year warranty on all FluidX Single Tube Readers.

Single Tube Readers for 1D and 2D Barcodes

|

FluidX Scope

TM

_Range

_|

_{USB Single Tube Reader}

* Unfortunately the Scope USB Single Tube reader is not compatible with all tablets, please contact us for further information.

(7)

Code formats Data Matrix®, ISO 16022, Square and Rectangular Format, ECC 200, 0 - 20 grid sizes, White on Black and Black on White, Numeric and Alphanumeric

Sensor type Sensor CMOS 1.2 Megapixel (1280 x 960) gray scale Read time Less than 1 second per tube/rack (either 1D or 2D) Tube compatibility All tubes in 24, 48, 96, 240 and 384-formats.

Glass compound storage tubes, cryo tubes, biological sample tubes.

Rack compatibility FluidX Scope readers can be used with the following linear barcodes:

Codabar, Code 11, Code 32, Code 39, Code 93, Code 128 Light source Light source Red LED with Blue Targeting LED Dimensions 75 x 196 x 45mm (WxDxH)

Power requirements USB Connection.

5vdc (mA): Typical = less than 450 mA; Idle = less than 80mA; Sleep = less than 31 mA User interface USB 2.0 HID Keyboard

Ambient operating

temperature -20° to 55 °C ( -4° to 131 °F) Operating humidity

(non-condensing) 10- 90%

Operating system Windows XP, Windows Vista, Windows 7, Windows 8, Windows CE, Mac OSX and Linux

Waranty 5 years

Single Tube Readers for 1D and 2D Barcodes

|

FluidX Scope

TM

_Range

_|

_{USB Single Tube Reader}

_cont.

Speciﬁcations

Ordering Information

Catalog No Description

20-1003 FluidX Scope USB Single Tube Reader

For “Plug and Play” scanning of all types of 2D Data Matrix barcoded tubes. Instant decoding of both 1D and 2D barcodes.

(8)

The FluidX ScopeTM_{Wireless Single Tube Reader.}

The VERY FIRST single tube 1D and 2D barcode reader to connect with iPad and Android tablets.

“Plug and play”, no software required.

Use with all 2D barcoded tubes, any make, any size.

All FluidX Single Tube Readers are compatible with any 2D Data Matrix barcoded tubes including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

Size does not matter, the FluidX Scope Wireless Reader will quickly scan tubes in 24, 48, 96, 240 and 384 rack formats, also larger capacity tubes including glass compound storage tubes, cryo tubes and biological sample tubes.

Instant 1D and 2D barcode reading

The total time between scanning a barcode and seeing the result displayed is less than a second!

Tube ID is displayed instantly on the screen for identiﬁcation or sample entry, or you can run the application in the background.

Easy reading of linear barcodes on racks and tubes

With a large scan window and superior decoding technology the Scope Wireless Single Tube Reader easily decodes 1D barcodes on racks and tubes.

Read barcodes anywhere, any time

With this unique reader you can read 1D and 2D barcodes anywhere, at any time. Uses Bluetooth connectivity so the Scope Wireless Single Tube Reader is completely mobile.

Battery powered, able to scan 50,000 tubes before recharging.

Use straight away

There’s no need to calibrate, no drivers or software to install, before scanning your ﬁrst tube or rack.

Simply scan the barcode provided in the operation manual to connect the reader to your tablet.

Use with multiple mobile devices

Need to use more than one tablet with your reader? Switching between diﬀerent mobile devices can be performed in just a few seconds.

The Scope Wireless Single Tube Reader can be connected to your iPad, Android tablet, iPod, iPhone or Android phone.

Want to use a PC or laptop instead of a tablet?

Scope Wireless Single Tube Reader is available with a Bluetooth modem to provide an instant connection with any laptop, PC or Mac, without installing drivers or software. Just scan the barcode found on the modem to establish connection.

Data exported direct to any application

Simply place your cursor where you would like the results to be entered and scan the tube. Data will be instantly displayed wherever the cursor is positioned. The reader will insert data into any application including Excel, Notepad, etc.

Simple to use, even with gloves

Blue LED target lights are emitted so that positioning the barcode for scanning is easy, even wearing gloves. The reader then automatically scans the barcode (either 1D or 2D) and conﬁrms a “good read”.

We supply a 5 year warranty on all FluidX Single Tube Readers.

(9)

Single Tube Readers for 1D and 2D Barcodes

|

FluidX Scope

TM

_Range

_|

_{Wireless Single Tube Reader}

_cont.

Speciﬁcations Ordering Information

20-1025-A Scope Wireless Single Tube Reader with Bluetooth.

Portable single tube wireless reader with large scan window for all 2D Data Matrix labelled tubes and 1D linear barcodes.

Hardware decoding with Bluetooth, no drivers or software required. Compatible with iPad / Android Tablets and PC / Mac computers with Bluetooth.

20-1025-B Scope Wireless Single Tube Reader with Bluetooth. Supplied with tablet.

Hardware decoding with Bluetooth, no drivers or software required. Supplied with 10" Lenovo Android Tablet.

20-1025-C Scope Wireless Single Tube Reader with Bluetooth modem.

Hardware decoding with Bluetooth, no drivers or software required. Bluetooth USB Modem does not require installation of drivers or software. Provides quick connection of FluidX Scope Wireless Single Tube Reader with any PC.

20-1008 Modem for Scope Wireless Single Tube Reader

Bluetooth USB modem for use with Scope Wireless Single Tube Readers when using with PC. No drivers or software required.

Sensor type Sensor CMOS 1.2 Megapixel (1280 x 960) gray scale

Light source Light source Red LED with Blue Targeting LED Read time Less than 1 second per tube/rack

(either 1D or 2D)

Tube compatibility All tubes in 24, 48, 96, 240 and 384-formats. Glass compound storage tubes, cryo tubes, biological sample tubes.

Rack compatibility Scope Single Tube Readers can be used with the following linear barcodes:

Codabar, Code 11, Code 32, Code 39, Code 93, Code 128 Dimensions 75 x 196 x 45mm (WxDxH)

Power requirements Battery powered.

4.2vdc (mA): Typical and Peak = 362 mA; Idle = 80 mA; Sleep = 20 mA. Up to 50,000 scans per charge User interface Bluetooth (Class II) HID Keyboard Ambient operating

temperature -20° to 55 °C (-4° to 131 °F) Operating humidity

(non-condensing) 10 - 90%

Operating system In Wireless Bluetooth HID Mode:

iOS (iPad, iPod, iPhone), Android OS (Tablet and Phones), Windows 8 (Mobile Edition)

(Also Windows XP, Windows Vista, Windows 7, Windows 8, Windows CE, Mac OSX and Linux) With USB Bluetooth modem:

Windows XP, Windows Vista, Windows 7, Windows 8, Windows CE, Mac OSX and Linux

(10)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_Overview

FluidX ImpressionTM

Enhanced Rack Scanner

Enhanced focal depth for dependable scanning of any 2D barcoded tube type - Single Tube Reading Position - With Integrated “Mirror” Linear

Barcode Reader

Provides automatic and simultaneous scanning of rack linear barcodes. (cat no 20-2102-A)

Multi Rack Scanner

The ﬁrst multi-rack scanner capable of telling you where each rack was placed. - With Integrated “Mirror ” Linear

Barcode Reader

- With Active Cryoprotection® (cat no 20-2109)

- With Opticon Linear Barcode Reader Simpliﬁes robotic integration, ideal for decoding more challenging (non-FluidX) linear barcodes.

(cat no 20-2102-B)

- With Integrated “Mirror” Linear Barcode Reader

- With Active Cryoprotection® Enables accurate scanning of multiple racks straight from freezer. (cat no 20-2102-C)

- With Opticon Linear Barcode Reader - With Active Cryoprotection® Accurate scanning of multiple racks straight from freezer

(cat no 20-2102-D)

Enhanced Rack Scanner (LE)

- With Active Cryoprotection® Enables accurate scanning of multiple racks straight from freezer. (cat no 20-2002-B)

Enhanced Rack Scanner (LE)

A high performance scanner without the frills.

(cat no 20-2002-A)

Rapid Rack Scanner

For desktop use.

Fast identiﬁcation of racked 2D barcoded sample storage tubes.

(cat no 20-2101-A)

Rapid Rack Scanner

- With Opticon Linear Barcode Reader Simpliﬁes robotic integration, ideal for decoding more challenging (non-FluidX) linear barcodes.

(11)

Opticon linear barcode reader

The use of an Opticon linear barcode reader simpliﬁes robotic integration and is ideal for decoding more challenging (non-FluidX) linear barcodes.

Rack proﬁles save set up time

When a specific rack layout is used routinely a custom rack profile can be set up. E.g. When a row remains empty within a 96 format rack, or control tubes are placed in specific positions on a regular basis.

Swap between 96 and 48 format racks without making changes

Once rack profiles have been set up (or using the rack profiles provided) our IntelliCode software will automatically determine which rack type is being used and select the appropriate profile for decoding and exporting tube data. Now you can switch between 96 and 48 format racks without making any changes to the reader or software.

Automation friendly

All FluidX rack readers have a gripper cutout section around the scan window to provide easy robotic handling of shallow racks.

“No tube” feature

FluidX whole rack readers are able to discriminate between a tube with a barcode that cannot be decoded and an empty rack position. The reader will not attempt to decode empty tube positions and so data ﬁles are kept “clean”.

Reading speed is optimised as wasted data entry is avoided.

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_Overview

The FluidX ImpressionTM _{Range of Rack Scanners for 2D barcoded tubes are based} on scanning technology and form the backbone of many sample storage and tracking systems.

Our Impression systems oﬀer the best optical quality within a rapid, small footprint, scanner form.

Advanced data export options and report design

When used in conjunction with our new IntelliCodeTM _{software, Impression} scanners oﬀer the most advanced data export options available and link easily to database sample tracking and LIMS systems.

Compatible with MS Word templates with powerful design and formatting capabilities to create professional customised reports.

Reading rack unique 2D barcode identiﬁer

FluidX racks can be supplied with a unique 2D barcode identiﬁer.

All our rack readers are able to read rack and tube 2D barcodes simultaneously to provide automatic rack orientation and additional sample security.

“Mirror” Linear Barcode Reader

FluidX rack scanners with an integrated “mirror” linear barcode reader provide automatic and simultaneous scanning of rack linear barcodes.

(12)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Active Cryoprotection}

®

FluidX Active Cryoprotection®System

Storing biological samples at low temperature created reading challenges for traditional 2D barcoded tube rack readers.

When scanning multiple racks, the accumulated amount of time that the cold racks spend in contact with the reader glass causes a drop in air temperature on the underside of the glass. The resulting condensation and frost then reduces reading ability and can cause damage to the scanning head.

All FluidX 2D barcoded tubes adhere to ECC200 standards and our readers employ superior decoding algorithms, but even in these conditions unreliable reading can occur when condensation builds up as the code is obscured and the contrast between the code and the background is diminished.

FluidX readers ﬁtted with our unique Active Cryoprotection® system are capable of reading multiple racks of tubes without the build-up of frost or condensation on the underside of the glass aﬀecting decoding reliability. Unlike passive versions, an active cryoprotection system also helps to prevent damage to electronic components within the reader caused by the build up of moisture.

This system was introduced 4 years ago and now has a proven track record. Here’s one of the ﬁrst reviews we received:

“The new Xtr-96 (whole rack reader) with anti misting scanning window has allowed us to batch scan multiple -80 frozen racks, unlike the previous model which required scanning to be interrupted by application of a heat block to the scanning window every few racks. The ease and trouble free use has resulted in stock control and quality control being a stress free experience.”

Kaetan Ladhani, CJD Resource Centre, NIBSC.

N0. o f r ack s r ead be fo re r ead in g issu es ar ose _More than 40 racks

Rack Reader with FluidX Active Cryoprotection System

Non-FluidX Rack Readers

Readers tested with tubes stored at -80o_C

The FluidX Active Cryoprotection System achieves 100% decoding after reading more than 40 racks from a -20ºC freezer.

2 racks _{1 rack}

Tube image before frosting of

glass surface Tube image after frosting of glass surface Without FluidX Active Cryoprotection System With FluidX Active

(13)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Active Cryoprotection}

®

Readers and Scanners available with FluidX Active Cryoprotection®System

FluidX ImpressionTM_{Enhanced Rack Scanner} _{FluidX Impression}TM_{Enhanced Rack Scanner (LE)} _{FluidX Impression}TM_{Multi Rack Scanner}

(14)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Rapid Rack Scanner}

The FluidX ImpressionTM_{RapidRack Scanner for desktop use.}

For fast identiﬁcation of racked 2D barcoded sample storage tubes. Use with 2D barcoded tubes in SBS format racks

The Impression Rapid Rack Scanner can be used with most 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, or 96 format) including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

In some instances, when the tube sits high within the rack, the Rapid Rack Scanner may not be compatible and the FluidX Impression Enhanced Rack Scanner, with greater focus depth, should be used instead.

Fast 2D barcode reading

The Rapid Rack Scanner will scan and decode a full rack of 96 tubes in just 4 seconds.

No warm-up time is required, the Rapid Rack Scanner gets straight to work.

Easy to use with a wide range of data output options

The Rapid Rack Scanner can output data to common LIMS compatible files such as text files, CSV files and Excel.

With a simple and intuitive Graphical User Interface, results can be viewed directly or integrated with other applications.

Output to database applications can be easily achieved via ODBC.

Easily integrated

The Rapid Rack Scanner features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube.

The Rapid Rack Scanner will not attempt to decode empty tube positions and data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Rack templates

Custom templates can be set up when a speciﬁc rack layout is used routinely. E.g. When a row remains empty within a 96 format rack or control tubes are placed in speciﬁc positions on a regular basis.

All FluidX rack readers have a gripper cutout section for easy robotic handling of shallow racks.

Automatic rack orientation

Always the innovators, FluidX were the ﬁrst to supply a unique 2D Data Matrix barcode identiﬁer on racks to provide automatic rack orientation.

All our whole rack readers are able to read rack and tube 2D barcodes simultaneously so scan and decode time remains low.

Available with attachable Opticon linear barcode reader

(15)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Rapid Rack Scanner}

_cont.

Speciﬁcations

Sensor type Colour CIS (contact image sensor) (CMOS CIS) Light source R,G,B, LED (variable light source)

Read time 4 seconds

(Total scan and decode time for rack of 96 tubes) Tube compatibility Most tubes in SBS format rack (24, 48 or 96 format).

May not be compatible with tubes that sit high within the rack.

Dimensions 154 x 256 x 51mm (WxDxH) Power requirements AC 100 to 240 V, +/-10%, less than 8 W. User interface FluidX GUI, including Windows TCP/IP. ODBC Ambient operating

temperature 5° to 55 °C (41° to 131 °F) Operating humidity

Operating system Windows XP, Windows 7 and Windows 8

Warranty 5 years

20-2101-A Rapid Rack Scanner

Small whole rack scanner for racks of 48 / 96 2D datamatrix labelled tubes; small-footprint scanner based solution for rapid reading and integration. Note: The FluidX Rapid Rack Scanner has a lower depth of focus than the FluidX Enhanced Rack Scanner and is not compatible with all rack types. 20-2101-B Rapid Rack Scanner with attachable Opticon Linear Barcode Reader

Small whole rack scanner for racks of 48 / 96 2D datamatrix labelled tubes; small-footprint scanner based solution for rapid reading and integration. Note: The FluidX Rapid Rack Scanner has a lower depth of focus than the FluidX Enhanced Rack Scanner and is not compatible with all rack types. With attachable Opticon USB Linear Barcode Reader.

(16)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Enhanced Rack Scanner}

The FluidX ImpressionTM _{Enhanced Rack Scanner}

With enhanced focal depth for dependable scanning of any 2D barcoded tube type, a choice of linear barcode readers and a single tube reading position. Use with 2D barcoded tubes in SBS format racks

The Impression Enhanced Rack Scanner can be used with all 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, 96, 240 or 384 format) including those supplied by Greiner, Matrix, Nunc, Micronic and, of course, FluidX tubes.

Integrated single tube reader

Just want to check a single tube? No need to set up another reader, simply position the tube over the single tube scanning window for instant identiﬁcation.

The Enhanced Rack Scanner will scan and decode a full rack of 96 tubes in just 8 seconds.

No warm-up time is required, the Enhanced Rack Scanner gets straight to work.

The Enhanced Rack Scanner can output data to common LIMS compatible files such as text files, CSV files and Excel.

The Enhanced Rack Scanner features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells.

All FluidX whole rack scanners have a gripper cutout section for easy robotic handling of shallow racks.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Enhanced Rack Scanner will not attempt to decode empty tube positions and data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Rack templates

Custom templates can be set up when a speciﬁc rack layout is used routinely. E.g. When a row remains empty within a 96 format rack, or control tubes are placed in speciﬁc positions on a regular basis.

Provided with a linear barcode reader as standard Choice of two linear reader options:

1. Attachable Opticon linear barcode reader

2. Integrated “mirror” linear barcode reader

An integrated “mirror” linear barcode reader provides automatic and simultaneous scanning of rack linear barcodes.

Available with integrated Active Cryoprotection®system The FluidX Active Cryoprotection system really works!

All FluidX Rack Scanners ﬁtted with our Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20ºC freezer!

Always the innovators, FluidX were the ﬁrst to supply a unique 2D Data Matrix barcode identiﬁer on racks to provide automatic rack orientation. All our rack scanners are able to read rack and tube 2D barcodes simultaneously so scan and decode time remains low.

(17)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Enhanced Rack Scanner}

_cont.

Sensor type CCD image sensor

Light source CCFL (cold cathode ﬂuorescent light source) Read time 8 seconds

(Total scan and decode time for rack of 96 tubes) Tube compatibility All 2D Data Matrix labelled tubes in SBS footprint racks.

(24, 48, 96, 240 and 384 formats)

Includes glass compound storage tubes, cryo tubes, biological sample tubes.

Dimensions 175 x 291 x 71mm (WxDxH)

Weight 0.5kg

Power requirements AC 100 to 240 V, +/-10%, less than 8 W. User interface FluidX GUI, including Windows TCP/IP. ODBC Cable Interface USB 2.0/ USB 1.1, USB type B

Warranty 5 years

20-2102-A Enhanced Optic Rack Scanner with Integrated “Mirror” Linear Barcode Reader

Compact whole rack scanner for all types of 2D Data Matrix labelled tubes in SBS footprint racks.

Compatible with 24, 48, 96, 240, and 384 format racked tubes. Suitable for integration into larger systems.

With integrated “mirror” linear barcode reader for use with tubes and racks. Single tube reading position.

20-2102-B Enhanced Optic Rack Scanner with Opticon Linear Barcode Reader attachment

With attachable Opticon USB Linear Barcode Reader. Single tube reading position.

20-2102-C Enhanced Optic Rack Scanner with Integrated “mirror” Linear Barcode Reader and Active Cryoprotection®

Compatible 24, 48, 96, 240, and 384 format racked tubes. Suitable for integration into larger systems

With integrated “mirror” linear barcode reader for use with tubes and racks. Active Cryoprotection system.

Single tube reading position.

20-2102-D Enhanced Optic Rack Scanner with Integrated Linear Barcode Reader, Active Cryoprotection® and Opticon Linear Barcode Reader attachment

With attachable Opticon USB Linear Barcode Reader. Active Cryoprotection system.

Speciﬁcations

With FluidX Active

Cryoprotection® system Without FluidX Active Cryoprotection® system

(18)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Enhanced Rack Scanner (LE)}

The FluidX ImpressionTM_{Enhanced Rack Scanner (LE)}

For dependable barcode reading at a reduced cost. A high performance scanner without the frills.

With enhanced focal depth for dependable scanning of any 2D barcoded tube type, this reader is a stripped-down version of the Enhanced Rack Scanner for those who simply want a good, whole rack 2D tube reader at a reduced cost.

Use with 2D barcoded tubes in SBS format racks

The Impression Enhanced Rack Scanner (LE) can be used with all 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, or 96 format) including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

The Enhanced Rack Scanner (LE) will scan and decode a full rack of 96 tubes in just 8 seconds.

No warm-up time is required, the Enhanced Rack Scanner (LE) gets straight to work.

The Enhanced Rack Scanner can output data to common LIMS compatible files such as text files and CSV files.

With a simple and intuitive Graphical User Interface, results can be viewed directly or with other applications such as Excel and Notepad.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Enhanced Rack Scanner (LE) will not attempt to decode empty tube positions and data ﬁles are kept “clean”.

This leads to faster rack reading as wasted data entry is avoided.

Rack templates

All FluidX Rack Scanners ﬁtted with our Active Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20ºC freezer!

(19)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Enhanced Rack Scanner (LE)}

_cont.

20-2002-A Enhanced Optic Rack Scanner (LE)

Limited Edition, compact, whole rack scanner for all 2D Data Matrix labelled tubes in SBS footprint racks.

Fast reading on the bench top.

20-2002-C Enhanced Optic Rack Scanner (LE) with Active Cryoprotection

Limited Edition, compact, whole rack scanner for all 2D Data Matrix labelled tubes in SBS footprint racks.

Fast reading on the bench top. With Active Cryoprotection system. Speciﬁcations

Light source CCFL (cold cathode ﬂuorescent light source) Read time 8 seconds

(24, 48, or 96 formats)

Weight 0.5kg

Power requirements AC 100 to 240 V, +/-10%, less than 8 W. User interface FluidX GUI

Cable Interface USB 2.0/ USB 1.1, USB type B Operating system Windows XP, Windows 7 and Windows 8

(20)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Multi Rack Scanner}

The FluidX ImpressionTM_{Multi Rack Scanner}

The ﬁrst multi-rack scanner capable of telling you where each rack was placed. Use with 2D barcoded tubes in SBS format racks

The Impression Multi Rack Scanner can be used with all 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, 96, 240 or 384 format) including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

Scan and decode time is just 10 seconds per rack.

The Impression Multi Rack Scanner can output data to common LIMS compatible files such as text files, CSV files and Excel.

The Impression Multi Rack Scanner features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Impression Multi Rack Scanner will not attempt to decode empty tube positions and data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Rack templates

With integrated “mirror” linear barcode reader for each rack

The Impression Multi Rack Scanner is ﬁtted with linear “mirror” barcode readers at each rack position for simultanous tube and rack identiﬁcation.

All FluidX Whole Rack Scanners ﬁtted with our Active Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20ºC freezer!

Always the innovators, FluidX were the ﬁrst to supply a unique 2D Data Matrix barcode identiﬁer on racks to provide automatic rack orientation. All our whole rack readers are able to read rack and tube 2D barcodes simultaneously so scan and decode time remains low.

(21)

Whole Rack 1D & 2D Barcode Scanners

|

FluidX Impression

TM

_Range

_|

_{Multi Rack Scanner}

_cont.

20-2109 Impression Multi Rack Scanner with Integrated “mirror” Linear Barcode Readers and Active Cryoprotection®

Expanded scanner capable of the simultaneous reading of 4 racks of 2D barcoded tubes.

Compatible with all SBS footprint racks, (24, 48 or 96 formats).

Integrated linear barcode readers at each rack position scan the 4 rack codes at the same time as 2D barcodes are being read.

With Active Cryoprotection system. Speciﬁcations

Light source R,G,B, LED (variable light source) Read time 8 seconds

(24, 48 or 96 formats)

Dimensions 154 x 256 x 51mm (WxDxH) Power requirements AC 100 to 240 V, +/-10%, less than 8 W. User interface FluidX GUI, including Windows TCP/IP. ODBC Cable Interface USB 2.0/ USB 1.1, USB type B

Ambient operating

(22)

Whole Rack 1D & 2D Barcode Scanners |

FluidX Perception

TM

_{Range |}

_Overview

FluidX PerceptionTM_{Rapid Legacy}

Rack Reader for Both Legacy Racks and SBS Format Racks

- With Active Cryoprotection®

- With Integrated USB Linear Barcode Reader Automatic and simultaneous scanning of rack 1D barcodes.

(cat no 20-4005-B)

FluidX PerceptionTM_{Rapid Legacy}

Rack Reader for Both Legacy Racks and SBS Format Racks

Enables accurate scanning of multiple racks straight from freezer.

(cat no 20-4005-A)

FluidX PerceptionTM_Industrial

Rack Reader

For industrial automation, especially at low temperatures.

(cat no 20-2102-C)

FluidX PerceptionTM_Rapid

Rack Reader for SBS Format Racks

Fast, small and needs only USB cable for data transfer and power.

(cat no 20-4001-A)

FluidX PerceptionTM_{Rapid SBS}

Rack Reader for SBS Format Racks

Fast, small and needs only USB cable for data transfer and power.

(cat no 20-4001-B)

FluidX PerceptionTM_Industrial

Rack Reader

- With Integrated USB Linear Barcode Reader - With Active Cryoprotection®

- With Enhanced Contrast Lighting System Makes light work of hard to read, low contrast 2D barcodes.

(23)

Whole Rack 1D & 2D Barcode Readers |

FluidX Perception

TM

_{Range |}

_Overview

FluidX PerceptionTM_{rack readers}

Using advanced camera-based systems, these readers are ideal for more challenging situations such as integration into robotic systems, cold enviroments or simply when speed and size are important.

Requires only a single USB connection

Perception rack readers (except Industrial model) require only a single USB connection to your PC or laptop. No additional power cable (or dongle) is required, so they’re simple to install and maintain.

Advanced data export options and report design

When used in conjunction with our new IntelliCodeTM _{software, Perception} readers oﬀer the most advanced data export options available, linking easily to database sample tracking and LIMS systems.

Compatible with MS Word templates with powerful design and formatting capabilities to create professional customised reports.

Read rack 2D barcode identiﬁer

FluidX racks can be supplied with a unique 2D barcode identiﬁer.

All our rack readers are able to read rack and tube 2D barcodes simultaneously to provide automatic rack orientation and additional sample security.

Linear barcode reader

The optional linear barcode reader helps to simplify robotic integration, is ideal for decoding more challenging (non-FluidX) linear barcodes and provides rack orientation. Plugs directly into the Perception reader so only one USB connection to a PC or laptop is required.

Rack proﬁles save set up time

When a specific rack layout is used routinely a custom rack profile can be set up. E.g. When a row remains empty within a 96 format rack, or control tubes are placed in specific positions on a regular basis.

Swap between 96 and 48 format racks without making any changes

Once rack profiles have been set up (or using the rack profiles that are provided) our IntelliCode software will automatically determine which rack type is being used and select the appropriate profile for decoding and exporting tube data. Now you can switch between 96 and 48 format racks without making any changes to the reader or software.

All FluidX rack readers have a gripper cutout section around the scan window to enable easy robotic handling of shallow racks.

The Perception Rapid Rack Reader for SBS format racks has the smallest footprint of any reader available, barely larger than a SBS format rack, for greater compatibility with automated systems including liquid handling.

FluidX whole rack readers are able to discriminate between a tube with a barcode that cannot be decoded and an empty rack position. The reader will not attempt to decode empty tube positions and so data ﬁles are kept “clean”.

(24)

Whole Rack 1D & 2D Barcode Readers |

FluidX Perception

TM

_{Range |}

_{Industrial Rack Reader}

The FluidX PerceptionTM_{Industrial Whole Rack Reader}

The only choice for industrial automation, especially at low temperatures. Proven track record.

Use with 2D barcoded tubes in SBS format racks

The Perception Industrial Rack Reader can be used with all 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, 96 format) including those supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX tubes.

Completely sealed, ideal for cold storage conditions

The Perception Industrial Rack Reader is contained within a sealed housing which is impervious to water, dust and gases (IP65 rated) and oﬀers reliable decoding at low temperatures (to -40o_C).

4 seconds total scan and decode time for a complete rack of 96 tubes! The Perception Industrial Rack Reader uses eight CCD cameras to achieve an almost instant read.

Easy to use with a wide variety of data capture options.

With ODBC connectivity for database integration.

The Perception Industrial Rack Reader can output data to common LIMS compatible files such as text files, CSV files and Excel.

Automation friendly, easily integrated

The Perception Industrial Rack Reader features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells.

All FluidX rack readers have a gripper cutout section for easy robotic handling of shallow racks.

Always the innovators, FluidX were the ﬁrst to supply a unique 2D Data Matrix barcode identiﬁer on racks to provide automatic rack orientation. All our rack readers are able to read rack and tube 2D barcodes simultaneously so scan and decode time remains low.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Industrial Rack Reader will not attempt to decode empty tube positions and data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Rack templates

With integrated linear barcode reader

An integrated USB linear barcode reader provides automatic and simultaneous scanning of rack 1D barcodes.

With integrated Active Cryoprotection®system

The FluidX Active Cryoprotection system really works!

All FluidX Rack Readers ﬁtted with our Active Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20ºC freezer!

Available with Contrast Enhancing REMP Lighting System

Makes light work of hard to read, low contrast 2D barcodes. All FluidX readers come with a 5 year warranty.

(25)

Whole Rack 1D & 2D Barcode Readers |

FluidX Perception

TM

_{Range |}

_{Industrial Rack Reader}

_cont.

20-3101-A Perception Industrial Whole Rack Reader with integrated USB Linear Barcode reader

Robust whole rack reader for racks of 96 2D datamatrix labeled tubes, ideal for integration.

Camera-based. Very rapid reading and ideal for integration. Suitable for use in cold conditions (down to -40 degC). IP65 rated sealed reading head resistant to water, dust and gases. With integrated USB linear barcode reader and Active Cryoprotection. Requires a PC running Windows 7 and a Spare PCIe Card slot. Supplied with 1M Cable as standard, longer cables available to order.

20-3101-B Perception Industrial Whole Rack Reader with integrated USB Linear Barcode reader and Contrast Enhancing REMP Lighting System

Robust whole rack reader for racks of 96 2D datamatrix labeled tubes, ideal for integration.

Camera-based. Very rapid reading and ideal for integration. Suitable for use in cold conditions (down to -40 degC). IP65 rated sealed reading head resistant to water, dust and gases. With integrated USB linear barcode reader and Active Cryoprotection. Requires a PC running Windows 7 and a Spare PCIe Card slot. Supplied with 1M Cable as standard, longer cables available to order. With Contrast Enhancing REMP Lighting System for hard to read, low contrast 2D barcodes.

Speciﬁcations

Sensor type 8 x 1.3 million pixel CMSO

Light source LED

Read time 4 seconds

(24, 48, 96, 240 and 384 formats)

Weight 2kg

Power requirements Input: 100-240Vac Output: 12V dc, 5.0A, (60W)

Operating voltage and current: Up to 12V, 0.41A User interface FluidX GUI, including Windows TCP/IP. ODBC Cable Interface USB 2.0/ USB 1.1, USB type B

Ambient operating

(non-condensing) 10 - 90% Operating system Windows 7

(26)

The FluidX PerceptionTM_{Rapid Rack Reader for SBS Racks}

With better speed, better footprint and better connectivity Use with any 2D barcoded tubes in SBS format rack

This Perception SBS Rapid Rack Reader can be used with all 2D Data Matrix barcoded tubes in an SBS footprint rack (24, 48, 96, 240 or 384 format) tubes supplied by Greiner, Matrix, Nunc, Micronic and of course, FluidX.

The smallest rack reader available

The SBS Rapid Rack Reader has a much smaller footprint than any other whole rack reader available, saving precious bench space.

Better speed

Other readers measure their speed in terms of grab time, capture time or decode time, but we believe that the real measure is the amount of time it takes from pressing “scan” to receiving the data you want.

All Perception Rapid Rack Readers will do this, for a complete rack of tubes, in just 0.75 seconds!

Better connectivity

Only one simple USB cable is needed for both data transfer and power. Can be connected with any standard USB cable up to 5m in length. (Supplied with standard 1.5m cable).

By using just one cable, without additional interface boxes, routing within integrated environments becomes simple!

Results can be viewed directly or integrated with other applications, with ODBC connectivity for database integration.

Direct data output to Excel, CSV, Text, Windsock, TCP/IP, ODBC.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Rapid Rack Reader will not attempt to decode empty tube positions and data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Automation friendly and easily integrated

The Rapid Rack Reader features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells. All FluidX rack readers have a gripper cutout section for easy robotic handling of shallow racks.

Fits most SBS racks, or plate nests, neatly with no overhang to obstruct liquid handling systems so only one plate position is needed.

Rack templates

Available with integrated USB linear barcode reader

An integrated USB linear barcode reader provides automatic and simultaneous scanning of rack 1D barcodes. Plugs directly into the Rapid Rack Reader so there’s still only a single USB connection to a PC.

The FluidX Active Cryoprotection system was developed over 4 years ago and it really works!

All FluidX Rack Readers ﬁtted with our Active Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20ºC freezer! All FluidX readers come with a 5 year warranty.

(27)

Whole Rack 1D & 2D Barcode Readers |

FluidX Perception

TM

_{Range |}

_{Rapid Rack Reader for SBS Racks}

_cont.

20-4001-A Perception SBS Rapid Rack Reader For 2D barcoded tubes in 96 format SBS racks With Active Cryoprotection

Compact whole rack reader for 2D barcoded tubes in 96 format SBS racks. Small footprint. Single camera-based.

Very rapid reading and ideal for integration. Single USB connection.

With Active Cryoprotection. 20-4001-B Perception SBS Rapid Rack Reader

For 2D barcoded tubes in 96 format SBS racks

With Active Cryoprotection and integrated USB Linear Barcode Reader

Compact whole rack reader for 2D barcoded tubes in 96 format SBS racks. Small footprint. Single camera-based.

Very rapid reading and ideal for integration. Single USB connection.

With Active Cryoprotection and integrated USB linear barcode reader.

Speciﬁcations

Sensor type 5 Megapixel variable focus CCD sensor Light source 2x Diﬀused LED light boards

Read time 0.75 seconds

(Total scan and decode time for rack of 96 tubes) Tube compatibility All 2D barcoded sample storage tubes in SBS rack format

including glass compound storage tubes and cryo tubes Dimensions 100 x 140 x 160mm(WxDxH)

Power requirements USB

Cable Interface USB 2.0/ USB 1.1, USB type B Ambient operating

Operating system Windows 7 and Windows 8

(28)

Whole Rack 1D & 2D Readers |

FluidX Perception

TM

_{Range |}

_{Rapid Rack Reader for Legacy Cryo Racks}

The FluidX PerceptionTM_{Legacy Rapid Rack Reader.}

Ridiculously fast reading of both legacy and SBS footprint racked tubes. For use with 2D barcoded tubes in both legacy cryo rack and SBS rack formats

The Legacy Rapid Rack Reader can be used with all 2D Data Matrix barcoded tubes in legacy cryo racks, in 10x10, 9x9 or 5x5 format.

Can also be used with SBS foootprint racked tubes in 24, 48 and 96 format.

Better speed

Other readers measure their speed in terms of grab time, capture time or decode time, but we believe that the real measure is the amount of time it takes from pressing “scan” to receiving the data you want.

The Rapid Rack Readers will do this for a complete rack of tubes in just 0.75 seconds!

Better connectivity

Only one simple USB cable needed for both data transfer and power. Can be connected with any standard USB cable up to 5m in length. (Supplied with standard 1.5m cable).

Using just the one cable, without additional interface boxes, makes routing within integrated environments simplicity itself!

Results can be viewed directly or integrated with other applications, with ODBC connectivity for database integration.

Direct data output to Excel, CSV, Text, Windsock, TCP/IP, ODBC.

Able to discriminate between a tube with a barcode that cannot be decoded and a rack position with no tube. The Rapid Rack Reader will not attempt to decode empty tube positions. Data ﬁles are kept “clean” as wasted data entry is avoided, leading to faster rack reading.

Automation friendly and easily integrated

The Rapid Rack Reader features TCP/IP Winsock connectivity for remote control of reader functions for integration into robotic/liquid handling work cells. With interchangeable inserts, this Rapid Rack Reader will ﬁt most legacy 10x10 and 9x9 square cryo racks andSBS footprint racks in 24, 48 and 96 formats.

Rack templates

Available with integrated USB linear barcode reader

An integrated USB linear barcode reader provides automatic and simultaneous scanning of rack 1D barcodes, plugs directly into the Rapid Rack Reader so there’s still only a single USB connection to a PC.

The FluidX Active Cryoprotection system was developed over 4 years ago and it really works.

All FluidX Rack Readers ﬁtted with our Active Cryoprotection system achieve 100% decoding after reading more than 40 racks straight from a -20°C freezer! All FluidX readers come with a 5 year warranty.

(29)

Whole Rack 1D & 2D Readers |

FluidX Perception

TM

_{Range |}

_{Rapid Rack Reader for Legacy Cryo Racks}

20-4005-A Perception Legacy Rapid Rack Reader

For 2D barcoded tubes in Legacy Cryo Racks (and SBS Footprint Racks) With Active Cryoprotection

Compact whole rack reader for 2D barcoded tubes in 10x10, 9x9 and 5x5 legacy rack formats and 24, 48 and 96 format SBS racks.

Small footprint. Single camera-based. Very rapid reading and ideal for integration. Single USB connection.

With Active Cryoprotection. 20-4005-B Perception Legacy Rapid Rack Reader

For 2D barcoded tubes in Legacy Cryo Racks (and SBS Footprint Racks) With Active Cryoprotection and integrated USB Linear Barcode Reader

Compact whole rack reader for 2D barcoded tubes in 10x10, 9x9 and 5x5 legacy rack formats, and 24, 48 and 96 format SBS racks.

Small footprint. Single camera-based. Very rapid reading and ideal for integration. Single USB connection.

With Active Cryoprotection and integrated USB linear barcode reader.

Speciﬁcations

Sensor type 5 Megapixel variable focus CCD sensor Light source 2x Diﬀused LED light boards Read time 0.75 seconds per rack

Tube compatibility 2D Data Matrix barcoded tubes in legacy cryo racks, (10x10, 9x9 and 5x5 format) and SBS footprint racks (24, 48 and 96 formats).

Dimensions 147 x 147 x 224mm (WxDxH) Power requirements USB

Cable Interface USB 2.0/ USB 1.1, USB type B Ambient operating

Operating system Windows 7 and Windows 8

(30)

FluidX Software |

EasyTrack Sample Management Software

FluidX EasyTrack Software is a graphical sample archiving package for sample management which has been developed and tested for use in most sample storage environments including molecular biology, cell biology, virology, microbiology and biochemistry.

EasyTrack is easy to use and provides the ability to conﬁrm sample ID, search and retrieve samples, archive, re-array and cherry pick samples, and is ideal for small or medium sized laboratories.

Suitable for storing and tracking both 1D and 2D barcoded samples, even complete boxes of tubes can be processed.

The storage environment can be customised by the user to meet speciﬁc requirements and access can be tailored to enable diﬀerent groups to use the same software.

Available in 2 versions; EasyTrack Single or EasyTrack Multi (see next page for details).

Archive samples Re-array samples Cherry pick samples Conﬁrm samples
